REAR COMBINATION LAMP

CHASSIS ELECTRICAL

54A-162

16DB524A

1

CLIP

SECTION A – A

1

3

2

A

A

4.9 ± 0.7 N·m
44± 6 in-lb

NOTE
          : CLIP POSITION

REMOVAL STEPS

•

TRUNK ROOM FLOOR BOARD,
REAR END TRIMS (REFER TO
GROUP 52A, TRIM

P.52A-11

.)

1.

REAR COMBINATION LAMP

2.

SOCKET ASSEMBLY

3.

BULB

REMOVAL STEPS (Continued)

DOME LAMP

CHASSIS ELECTRICAL

54A-163

DOME LAMP

DIAGNOSIS

M1542000701388

The dome lamp is controlled by the Simplified Wiring
System (SWS). For troubleshooting, refer to GROUP
54B, SWS Diagnosis

P.54B-57

.

SPECIAL TOOLS

M1542000601024

DOME LAMP

REMOVAL AND INSTALLATION

M1542006300028

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

MB990784
Ornament remover

General service
tool

Removal of map light,
cover etc.

MB990784

AC307690

AB

1

2

3

4

5

6

7

9

8

A

A

A

A

A

A

NOTE
          : CLIP POSITION

SECTION A – A

1, 3

CLIP

HEADLINING

OVERHEAD
CONSOLE
BRACKET

DOME LAMP

CHASSIS ELECTRICAL

54A-164

REMOVAL SERVICE POINT

.

<<A>> COVER REMOVAL

Insert a straight blade (flat) screwdriver into the lens and
                pry gently to remove it.

• When fitting cover, ensure you insert the 3 lugs in

first then clip in cover.

MAPLIGHT ASSEMBLY
REMOVAL STEPS

1.

MAP LAMP ASSEMBLY

2.

BULB
OVERHEAD CONSOLE
ASSEMBLY REMOVAL STEPS

3.

OVERHEAD COSOLE ASSEMBLY

4.

BULB

REAR DOME LAMP ASSEMBLY
REMOVAL STEPS

<<A>>

5.

COVER

6.

REAR DOME LAMP

7.

BULB
TRUNK LAMP REMOVAL STEPS

8.

TRUNK LAMP

9.

BULB

16DB525A

Front

16DB526A

Front

LICENSE PLATE LAMPS

CHASSIS ELECTRICAL

54A-165

LICENSE PLATE LAMPS

REMOVAL AND INSTALLATION

M1542004200207

• While pushing the tab (A) in the direction of the

arrow, remove the lamp assembly.

• Remove the socket by turning it anticlockwise,

and then remove the bulb by pulling out.

• When mounting the lamp unit, put the hooks (B)

on the right side of the lamp unit into the body
first.

16DB527A

2

3

1

REMOVAL STEPS

1.

LICENSE PLATE LAMP ASSEMBLY

2.

SOCKET

3.

BULB
