FRONT SEAT ASSEMBLY

INTERIOR

52A-36

DISASSEMBLY STEPS

<<A>>

HEADREST

1.

HINGE COVER

2.

INNER SEAT BELT

3.

MANUAL RECLINER ADJUSTER
(VEHICLES WITH MANUAL
RECLINER)

4.

SIDE SHIELD COVER

5.

POWER RECLINER ADJUSTER
(VEHICLES WITH POWER
RECLINER)

6.

SEAT HEIGHT ADJUSTER
KNOB

7.

MAIN POWER SWITCH

8.

LUMBAR POWER SWITCH
(VEHICLES WITH POWER
RECLINER)

9.

MEMORY BUTTON MODULE
(VEHICLES WITH MEMORY
SEATS)

10. SIDE SHIELD MOUNT BRACKET

11. FRONT SEAT BACK ASSEMBLY

12. CUSHION ASSEMBLY

13. SEAT CUSHION COVER

14. SEAT CUSHION PAD

15. SEAT CUSHION FRAME

16. SEAT BACK PANEL

17. SIDE AIRBAG MODULE

<<B>>

18. HEADREST GUIDE

19. MANUAL LUMBAR ADJUSTER

HANDLE

<<C>>

20. SEAT BACK COVER

21. SEAT BACK PAD

22. LUMBAR ASSEMBLY

23. RECLINER LEVER RETURN

SPRING

24. RECLINER LEVER SHAFT

25. SEAT BACK PATCH HARNESS

(VEHICLES FITTED WITH
POWER SEAT BACK)

26. SEAT BACK FRAME

27. SEAT POWER HARNESS

28. SEAT SLIDE ADJUSTER

DISASSEMBLY STEPS

FRONT SEAT ASSEMBLY

INTERIOR

52A-37

<LH SIDE>

LHS:  380 (fabric),  380VRX (fabric and leather)

19DB011A

1

2

3

4

7

10

11

12

9

17

18

15

15

14

22

13

21

20

24

8

35 N·m

45 N·m

5 N·m

19

35 N·m

FRONT SEAT ASSEMBLY

INTERIOR

52A-38

LHS:  380LS (fabric)

19DB012A

17

18

15

15

22

16

14

10

11

12

13

21

20

3

4

24

1

2

7

19

8

9

35 N·m

35 N·m

45 N·m

5 N·m

32 N·m

FRONT SEAT ASSEMBLY

INTERIOR

52A-39

LHS:  380LS,  380LX (leather)

19DB013A

15

15

8

17

18

22

13

19

14

16

21

20

10

11

12

1

2

7

6

3

5

4

23

24

9

35 N·m

35 N·m

45 N·m

5 N·m

32 N·m
