For this reason, you should always switch off
the windshield wipers in dry weather.
1
$ Windshield wiper off
2
Ä Intermittent wipe, low (rain sensor set
to low sensitivity)
3
Å Intermittent wipe, high (rain sensor
set to high sensitivity)
4
° Continuous wipe, slow
5
¯ Continuous wipe, fast
B
í Single wipe/î to wipe the wind-
shield using washer fluid
X
Switch on the power supply with the Start/
Stop button or the SmartKey (
Y
page 162).
X
Turn the combination switch to the corre-
sponding position.
In the Ä or Å position, the appropriate
wiping frequency is set automatically according
to the intensity of the rain. In the Å position,
the rain sensor is more sensitive than in
the Ä position, causing the windshield wip-
ers to wipe more frequently.
Vehicles with MAGIC VISION CONTROL: the
washer fluid is fed through the wiper blades and
when wiping with washer fluid î the washer
fluid is emitted directly from the blades.
Vehicles with MAGIC VISION CONTROL: if you
push and hold the combination switch beyond
the point of resistance in the direction of arrow
B, the manual wash program is activated. If you
briefly push and hold the combination switch
beyond the point of resistance in the direction of
arrow B, the automatic wash program is acti-
vated.
If the wiper blades are worn, the windshield will
no longer be wiped properly. This could prevent
you from observing the traffic conditions.
Replacing the wiper blades
Important safety notes
G
WARNING
If the windshield wipers begin to move while
you are changing the wiper blades, you could
be trapped by the wiper arm. There is a risk of
injury.
Always switch off the windshield wipers and
ignition before changing the wiper blades.
!
To avoid damaging the wiper blades, make
sure that you touch only the wiper arm of the
wiper.
!
Never open the hood if a windshield wiper
arm has been folded away from the wind-
shield.
Hold the windshield wiper arm firmly when
you change the wiper blade. If you release the
windshield wiper arm without a wiper blade
and it falls onto the windshield, the windshield
may be damaged by the force of the impact.
Mercedes-Benz recommends that you have
the wiper blades changed at a qualified spe-
cialist workshop.
!
Always position the windshield wiper arms
vertically before folding them away from the
windshield. By doing so, you will avoid dam-
age to the hood.
Replacing the wiper blades (standard
windshield wipers)
Moving the wiper arms to a vertical posi-
tion
On vehicles without KEYLESS-GO:
X
Turn the SmartKey to position 0 in the ignition
lock (
Y
page 162).
X
Set the windshield wiper to the ° position.
X
Turn the SmartKey to position 1 in the ignition
lock (
Y
page 162).
X
As soon as the wiper arms are vertical to the
hood, turn the SmartKey to position 0 in the
ignition lock (
Y
page 162).
X
Remove the SmartKey.
X
Fold the wiper arms away from the windshield
until you feel them snap into place.
