DESCRIPTION
N·m
Ft. Lbs.
In. Lbs.
Bolt- Fuel Filter to Charge
Air Distribution Pipe
14
-
124
Exhaust System
Bolt- Catalytic Converter
Bracket to Crankcase
20
-
177
Bolt - Turbocharger Oil
Supply Line at Turbo-
charger
25
18
-
Bolt - Turbocharger Oil
Return Line at Turbo-
charger
10
-
89
Clamp-Connection Be-
tween Front Exhaust Pipe
and Rear Exhaust System
55
41
-
Clip-Front Catalytic Con-
verter to Engine Mount
20
-
177
Exhaust Manifold to Cylin-
der Head
29
21
-
Nut-EGR Valve
9
-
80
Nut-Bracket to Tail Pipe
55
40.5
-
Nut-Exhaust Bracket to
Threaded Plate of Center
Exhaust Pipe
20
-
177
Support-Exhaust Bracket
on Transmission
20
-
177
Refrigerant Compressor
Bolt-Refrigerant Compres-
sor to Timing Case Cover
20
-
177
Bolt-Refrigerant Compres-
sor to Bracket
20
-
177
Bolt-Refrigerant Lines to
Refrigerant Compressor
20
-
177
Timing Chain, Chain Tensioner
Bolt-Camshaft Sprocket to
Exhaust Camshaft
18
-
159
Bolt-Intermediate Gear of
High Pressure Pump to
Cylinder Head
40
29.5
-
Timing Chain Tensioner to
Timing Case Cover
80
59
-
Camshaft
Bolt-Camshaft Bearing
Cap to Cylinder Head
9
-
80
Bolt-Driver to Inlet Cam-
shaft
50
37
-
Common Rail Diesel Injection
Bolt-Banjo Bolt of Leak
Oil Line to Rail
20
-
177
VA
ENGINE
9 - 15
