C220 - (CIGARETTE SIDE)

CAV

CIRCUIT

1

16RD/YL

2

16BR

3

16GY/DG/RD

C220 - (DASH SIDE)

CAV

CIRCUIT

1

16RD/YL

2

16BR

3

16GY/DG/RD

C221 - (MAIN BODY SIDE)

CAV

CIRCUIT

1

16BL/WT

2

16BK/YL/DG

3

16BK/WT

C221 - (PASSENGER DOOR SIDE)

CAV

CIRCUIT

1

16BL/WT

2

16BK/YL/DG

3

16BK/WT

C224 - (BLOWER MOTOR/SOLENOID SIDE)

CAV

CIRCUIT

1

12RD

2

12BK

2

16BK

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 25

C224 - (MAIN BODY SIDE)

CAV

CIRCUIT

1

12RD

2

12BR

C225 - (BLOWER MOTOR/SOLENOID SIDE)

CAV

CIRCUIT

1

12RD

2

12RD/BL

3

16RD

C225 - (DASH SIDE)

CAV

CIRCUIT

1

12RD/BL

2

12BL

3

16RD

C226 - (CABIN SIDE)

CAV

CIRCUIT

1

16GY

2

-

3

16RD/DG

4

16RD/BL

5

16BK

6

16BR

C300 - (BODY SIDE)

CAV

CIRCUIT

1

16RD/YL

1

20RD

2

20YL

3

20WT

8W - 80 - 26

8W-80 CONNECTOR PIN-OUTS

VA

C300 - (RAIN SENSOR SIDE)

CAV

CIRCUIT

1

20DG

2

20BR

3

20BK/DG

4

16RD/YL

C301 - (BODY SIDE)

CAV

CIRCUIT

1

20RD

2

20YL

3

20WT

4

-

5

-

6

-

7

-

8

-

C301 - (CABIN SIDE)

CAV

CIRCUIT

1

20RD

2

20YL

3

20WT

4

-

5

-

6

-

7

-

8

-

C306 - (ROOF SIDE)

CAV

CIRCUIT

2

14BR

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 27

C306 - (BODY SIDE)

CAV

CIRCUIT

FUNCTION

2

14BR

C307 - (BODY SIDE)

CAV

CIRCUIT

1

16BR

2

16BL

C307 - (TEMPERATURE SENSOR SIDE)

CAV

CIRCUIT

1

16BR

2

16BL

CABIN HEATER ASSEMBLY

CAV

CIRCUIT

FUNCTION

B

16BL/YL (CABIN HEATER MODULE)

CIRCULATION PUMP RELAY HIGH SIDE CONTROL

B

16BL/YL (REST SYSTEM)

HEATER BOOSTER MODE

CABIN HEATER MODULE (CHM)

CAV

CIRCUIT

FUNCTION

1

14RD

FUSED B(+)

2

14BR

GROUND

3

16BL/YL

FAN STAGE 1 RELAY HIGH SIDE CONTROL

4

16DG

DOSING PUMP CONTROL

5

16BL/RD

K-IC/ATC/HBM/CHM

6

16BK/BL/DG (EXCEPT PROGRAM TIM-
ER)

FUSED OPTIONAL EQUIPMENT RELAY OUTPUT

6

16BL (PROGRAM TIMER)

CABIN HEATER CONTROL

7

16BL (EXCEPT PROGRAM TIMER)

AUXILIARY HEATER SWITCH

7

16YL (PROGRAM TIMER)

CABIN HEATER CONTROL

8W - 80 - 28

8W-80 CONNECTOR PIN-OUTS
