C209 - (DASH SIDE)

CAV

CIRCUIT

1

16BR/BL

2

16WT/BL

3

16BR/GY

4

16WT/GY

C210 - (DRIVER DOOR SIDE)

CAV

CIRCUIT

1

14BR

2

16BK/YL

3

16BK/YL/DG

4

16BK/WT

5

16BL/WT

6

-

C210 - BLACK (MAIN BODY SIDE)

CAV

CIRCUIT

1

14BR

2

16BK/YL

3

16BK/YL/DG

4

16BK/WT

5

16BL/WT

6

-

C211 - (POWER MIRROR SWITCH SIDE)

CAV

CIRCUIT

1

18BR

2

18BK/RD

3

-

4

18BL/DG

5

18DG

6

18WT/GY

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 21

C211 - BLACK (POWER MIRROR SIDE)

CAV

CIRCUIT

1

18BR

2

18BK/RD

3

-

4

18BL/DG

5

18DG

6

18WT/GY

C214 - LT. BLUE (CABIN SIDE)

CAV

CIRCUIT

1

16YL

2

16VT

3

16BK

4

16BR

5

-

6

-

C214 - LT. BLUE (DASH SIDE)

CAV

CIRCUIT

1

16YL

2

16VT

3

16BK

4

16BR

5

-

6

-

C215 - BLACK (CABIN SIDE)

CAV

CIRCUIT

1

16RD/YL

2

16BK/RD

3

-

4

-

5

16BR/WT

6

14BR

8W - 80 - 22

8W-80 CONNECTOR PIN-OUTS

VA

C215 - BLACK (MAIN BODY)

CAV

CIRCUIT

1

16RD/YL

2

16BK/RD

3

-

4

-

5

20BR/WT

6

14BR

C216 - BLACK (CABIN SIDE)

CAV

CIRCUIT

1

12RD

2

-

C216 - BLACK (MAIN BODY SIDE)

CAV

CIRCUIT

1

12RD

2

-

C217 - (CABIN SIDE)

CAV

CIRCUIT

1

16RD/YL

2

16YL

3

16DG

4

16YL

C217 - (MAIN BODY SIDE)

CAV

CIRCUIT

1

16RD/YL

2

16YL

3

16DG

4

16YL

VA

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 23

C218 - (CABIN SIDE)

CAV

CIRCUIT

1

16BR/WT

2

16BR/YL

3

16RD/DG

4

16DG/YL

5

20DG/BK

6

20GY/BK

7

20DG/WT/BL

8

-

C218 - (MAIN BODY SIDE)

CAV

CIRCUIT

1

16BR/WT

2

16BR/YL

3

16RD/DG

4

16DG/YL

5

20DG/BK

6

20GY/BK

7

20DG/WT/BL

C219 - (MAIN BODY SIDE)

CAV

CIRCUIT

5

16BK/RD

6

16BL/RD

7

16YL/WT

8

16DG/BK

9

16BK/RD

10

16BL/RD

11

16YL/RD

12

16DG/YL

C219 - BLACK (CABIN SIDE)

CAV

CIRCUIT

5

16BK/RD

6

16BL/RD

7

16YL/WT

8

16DG/BK

9

16BK/RD

10

16BL/RD

11

16YL/RD

12

16DG/YL

8W - 80 - 24

8W-80 CONNECTOR PIN-OUTS

VA
