Reporting Safety Defects (U.S.A.)

If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway Traﬃc
Safety Administration (NHTSA) in addition to notifying Mazda Motor Corporation or
your Mazda Importer/Distributor.

If NHTSA receives similar complaints, it may open an investigation, and if it ﬁnds
that a safety defect exists in a group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in individual problems
between you, your dealer, or Mazda Motor Corporation or your Mazda Importer/
Distributor.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY:1-800-424-9153); go to http://www.safercar.gov; or write
to: Administrator, NHTSA, 1200 New Jersey Avenue, SE., Washington, DC, 20590.
You can also obtain other information about motor vehicle safety from http://
www.safercar.gov.

NOTE

If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be
forwarded to:

Mazda North American Operations
200 Spectrum Center Drive Suite 100
Irvine, California 92618
or
P.O. Box 19734
Irvine, CA 92623-9734
Customer Experience Center or toll free at 1 (800) 222-5500

If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown
in this manual.



Refer to CANADA on page 10-17.



Refer to PUERTO RICO/U.S. Virgin Island on page 10-18.



Refer to MEXICO on page 10-18.



Refer to GUAM on page 10-19.



Refer to SAIPAN on page 10-19.



Refer to AMERICAN SAMOA on page 10-20.

Speciﬁcations/Customer Information and Reporting Safety Defects

Reporting Safety Defects

10-21

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Warranties for Your

Mazda



New Vehicle Limited Warranty



Powertrain Limited Warranty



Safety Restraint System Limited
Warranty



Anti-perforation Limited Warranty



Federal Emission Control Warranty/
California Emission Control Warranty



Emission Defect Warranty



Emission Performance Warranty



Emission Control Warranty



Replacement Parts and Accessories
Limited Warranty



Tire Warranty

NOTE

Warranty information varies depending
on the country. Refer to the Warranty
Booklet for detailed warranty
information.

Outside the United

States/Canada

Government regulations in the United
States/Canada require that
automobiles meet speciﬁc emission
regulations and safety standards.
Therefore, vehicles built for use in the
United States/Canada may diﬀer from
those sold in other countries.

The diﬀerences may make it diﬃcult or
even impossible for your vehicle to
receive satisfactory servicing in other
countries. We strongly recommend
that you NOT take your Mazda outside
the United States/Canada.

United States

However, in the event that you are
moving to Canada permanently,
Mazda vehicles built for use in the
United States could be eligible for
exportation to Canada with speciﬁc
vehicle modiﬁcations to comply with
the Canadian Motor Vehicle Safety
Standards (CMVSS).

Canada

However, in the event that you are
moving to the United States
permanently, Mazda vehicles built for
use in Canada could be eligible for
exportation to the United States with
speciﬁc vehicle modiﬁcations to
comply with the United States Federal
Motor Vehicle Safety Standards
(FMVSS).

NOTE

The above is applicable for a
permanent import/export situation
and not related to travelers on
vacation.

Speciﬁcations/Customer Information and Reporting Safety Defects

Warranty

10-23

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

You may have the following problems
if you do take your vehicle outside of
the United States/Canada:



Recommended fuel may be
unavailable. Any kind of leaded fuel
or low-octane fuel will aﬀect vehicle
performance and damage the
emission controls and engine.



Proper repair facilities, tools, testing
equipment, and replacement parts
may not be available.

Please refer to your Manufacturer's
Warranty Booklet for more
information.

Registering Your Vehicle

in A Foreign Country

(Except United States and

Canada)

Registering your vehicle in a foreign
country may be problematic
depending on whether it meets the
speciﬁc emission and safety standards
of the country in which the vehicle will
be driven. Consequently, your vehicle
may require modiﬁcations at personal
expense in order to meet the
regulations.
In addition, you should be aware of
the following issues:
Satisfactory vehicle servicing may be
diﬃcult or impossible in another
country.

The fuel speciﬁed for your vehicle may
be unavailable.

Parts, servicing techniques, and tools
necessary to maintain and repair your
vehicle may be unavailable.

There might not be an Authorized
Mazda Dealer in the country you plan
to take your vehicle.

The Mazda warranty is valid only in
certain countries.

Speciﬁcations/Customer Information and Reporting Safety Defects

Warranty

10-24

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Add-On Non-Genuine

Parts and Accessories

Non-genuine parts and accessories for
Mazda vehicles can be found in stores.
These may ﬁt your vehicle, but they are
not approved by Mazda for use with
Mazda vehicles. When you install
non-genuine parts or accessories, they
could aﬀect your vehicle's
performance or safety systems; the
Mazda warranty doesn't cover this.
Before you install any non-genuine
parts or accessories, consult an
Authorized Mazda Dealer.

WARNING

Always consult an Authorized Mazda
Dealer before you install non-genuine
parts or accessories.

Improperly designed parts or
accessories could seriously aﬀect your
vehicle's performance or safety
systems. This could cause you to have
an accident or increase your chances of
injuries in an accident.

Be very careful in choosing and
installing add-on electrical
equipment, such as mobile
telephones, two-way radios, stereo
systems, and car alarm systems.

Incorrectly choosing or installing
improper add-on equipment or
choosing an improper installer is
dangerous. Essential systems could be
damaged, causing engine stalling,
air-bag (SRS) activation,
ABS/TCS/DSC inactivation, or a ﬁre in
the vehicle.

Mazda assumes no responsibility for
death, injury, or expenses that may
result from the installation of add-on
non-genuine parts or accessories.

Speciﬁcations/Customer Information and Reporting Safety Defects

Warranty

10-25

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Traction-AA, A, B, C

The traction grades, from highest to
lowest, are AA, A, B, and C. These
grades represent the tire's ability to
stop on wet pavement as measured
under controlled conditions on
speciﬁed government test surfaces of
asphalt and concrete. A tire marked C
may have poor traction performance.

WARNING

The traction grade assigned to this tire
is based on braking (straight ahead)
traction tests and does not include
acceleration cornering (turning),
hydroplaning, or peak traction
characteristics.

Temperature-A, B, C

The temperature grades A (the
highest), B, and C, represent the tire's
resistance to the generation of heat
and its ability to dissipate heat when
tested under controlled conditions on
a speciﬁed indoor laboratory test
wheel.
Sustained high temperature can cause
the material of the tire to degenerate
and reduce tire life, and excessive
temperatures can lead to sudden tire
failure.

Grade C corresponds to a level of
performance which all passenger
vehicle tires must meet under the
Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent
higher levels of performance on the
laboratory test wheel than the
minimum required by law.

WARNING

Keep your vehicle's tires properly
inﬂated and not overloaded.

Driving with improperly inﬂated or
overloaded tires is dangerous.
Excessive speed, underinﬂation, or
excessive loading, either separately or
in combination, can cause heat
buildup and possible tire failure. The
temperature grade for this tire is
established for a tire that is properly
inﬂated and not overloaded.

These grades will be added to the
sidewalls of passenger vehicle tires
over the next several years according to
a schedule established by the NHTSA
and the tire manufacturers.

The grade of tires available as standard
or optional equipment on Mazda

Speciﬁcations/Customer Information and Reporting Safety Defects

Uniform Tire Quality Grading System (UTQGS)

10-28

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Tire Labeling

Federal law requires tire manufacturers
to place standardized information on
the sidewall of all tires. This
information identiﬁes and describes
the fundamental characteristics of the
tire and also provides a tire
identiﬁcation number for safety
standard certiﬁcation and in case of a
recall.

Information on Passenger

Vehicle Tires

Please refer to the sample below.

1. SAFETY WARNING
2. Passenger car tire
3. Nominal width of tire in millimeters
4. Ratio of height to width (aspect

ratio)

5. Radial
6. Run-ﬂat tire
7. Rim diameter code
8. TIN: U.S. DOT tire identiﬁcation

number

9. Load index & speed symbol
10.Severe snow conditions
11.Tire ply composition and materials

used

12.Max. load rating
13.Tread wear, traction and

temperature grades

14.Max. permissible inﬂation pressure

P215/65R15 95H is an example of a
tire size and load index rating. Here is
an explanation of the various
components of that tire size and load
index rating. Note that the tire size and
load index rating may be diﬀerent from
the example.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-30

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Indicates a tire that may be installed on
cars, SUVs, minivans and light trucks as
designated by the Tire and Rim
Association (T&RA).

NOTE

If your tire size does not begin with a
letter this may mean it is designated by
either ETRTO (European Tire and Rim
Technical Organization) or JATMA
(Japan Tire Manufacturing
Association).

215

“215” is the nominal width of the tire
in millimeters. This three-digit number
gives the width in millimeters of the
tire from sidewall edge to sidewall
edge. In general, the larger the
number, the wider the tire.

“65” is the aspect ratio. This two-digit
number indicates the tire's ratio of
height to width.

“R” is the tire construction symbol. R
indicates “Radial ply construction”.

“15” is the wheel rim diameter in
inches.

“95” is the Load Index. This two-or
three-digit number indicates how
much weight each tire can support.

“H” is the speed rating. The speed
rating denotes the maximum speed for
which the use of the tire is rated.

Letter Rating

Speed Rating

99 mph

106 mph

112 mph

118 mph

124 mph

130 mph

149 mph

168

mph

186

mph

For tires with a maximum speed capability over

149 mph, tire manufacturers sometimes use the
letters ZR. For tires with a maximum speed
capability over 186 mph, tire manufacturers
always use the letters ZR.

M+S or M/S: Mud and Snow

AT: All Terrain.
AS: All Season. The “M+S” or “M/S”
indicates that the tire has some
functional use in mud and snow.

U.S. DOT Tire Identiﬁcation Number
(TIN)

This begins with the letters “DOT”
which indicates the tire meets all
federal standards. The next two
numbers or letters are the plant code
where it was manufactured, and the
last four numbers represent the week
and year the tire was manufactured.
For example, the numbers 457 means
the 45st week of 1997. After 2000 the
numbers go to four digits. For
example, the number 2102 means the
21th week of 2002. The other
numbers are marketing codes used at
the manufacturer's discretion. This
information is used to contact
consumers if a tire defect requires a
recall.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-31

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Tire Ply Composition and Materials
Used

The number of plies indicates the
number of layers of rubber-coated
fabric in the tire. In general, the greater
the number of plies, the more weight a
tire can support. Tire manufacturers
also must indicate the tire materials,
which include steel, nylon, polyester,
and other.

Maximum Load Rating

This number indicates the maximum
load in kilograms and pounds that can
be carried by the tire.

Maximum Permissible Inﬂation
Pressure

This number is the greatest amount of
air pressure that should ever be put in
the tire under normal driving
conditions.

Tread Wear, Traction and Temperature
Grades

Tread wear:

The tread wear grade is a

comparative rating based on the wear
rate of the tire when tested under
controlled conditions on a speciﬁed
government test course. For example,
a tire graded 150 would wear one and
one-half (1 1/2) times as well on the
government course as a tire graded
100.

Traction:

The traction grades, from

highest to lowest are AA, A, B, and C.
The grades represent the tire's ability
to stop on wet pavement as measured
under controlled conditions on
speciﬁed government test surfaces of
asphalt and concrete. A tire marked C
may have poor traction performance.

Temperature:

The temperature grades

are A (the highest), B and C,
representing the tire's resistance to the
generation of heat and its ability to

dissipate heat when tested under
controlled conditions on a speciﬁed
indoor laboratory test wheel.

Snow Tires

In some heavy snow areas, local
governments may require true snow
tires, those with very deeply cut tread.
These tires should only be used in pairs
or placed on all four wheels. Make
sure you purchase snow tires that are
the same size and construction type as
the other tires on your vehicle.

SAFETY WARNING

The following safety warning appears
on the tire's sidewall.
SERIOUS INJURY MAY RESULT FROM:



EXPLOSION OF TIRE/RIM ASSEMBLY
DUE TO IMPROPER
MOUNTING-MATCH TIRE
DIAMETER TO RIM DIAMETER;
NEVER EXCEED 40 psi (275 kPa) TO
SEAT BEADS-ONLY SPECIALLY
TRAINED PERSONS SHOULD
MOUNT TIRES.



TIRE FAILURE DUE TO
UNDER-INFLATION/
OVERLOADING/DAMAGE-FOLLOW
OWNER'S MANUAL AND PLACARD
IN VEHICLE-FREQUENTLY CHECK
INFLATION PRESSURE AND INSPECT
FOR DAMAGE.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-32

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Information on

Temporary Tires

Please refer to the sample below.

1. Temporary tires
2. Nominal width of tire in millimeters
3. Ratio of height to width (aspect

ratio)

4. Diagonal
5. Rim diameter code
6. Load index & speed symbol

T115/70D16 90M is an example of a
tire size and load index rating. Here is
an explanation of the various
components of that tire size and load
index rating. Note that the tire size and
load index rating may be diﬀerent from
the example.

Indicates a tire that may be installed on
cars, SUVs, minivans and light trucks as
designated by the Tire and Rim
Association (T&RA).

115

“115” is the nominal width of the tire
in millimeters. This three-digit number
gives the width in millimeters of the
tire from sidewall edge to sidewall
edge. In general, the larger the
number, the wider the tire.

“70” is the aspect ratio. This two-digit
number indicates the tire's ratio of
height to width.

“D” is the tire construction symbol. D
indicates “diagonal ply construction”.

“16” is the wheel rim diameter in
inches.

“90” is the Load Index. This two-or
three-digit number indicates how
much weight each tire can support.

“M” is the speed rating. The speed
rating denotes the maximum speed for
which the use of the tire is rated.

Letter Rating

Speed Rating

81 mph

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-33

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Location of the Tire Label

(Placard)

You will ﬁnd the tire label containing
tire inﬂation pressure by tire size and
other important information on the
driver's side B-pillar or on the edge of
the driver's door frame.

SAMPLE

Recommended Tire

Inﬂation Pressure

On the tire label you will ﬁnd the
recommended tire inﬂation pressure in
both kPa and psi for the tires installed
as original equipment on the vehicle. It
is very important that the inﬂation
pressure of the tires on your vehicle is
maintained at the recommended
pressure. You should check the tire
pressure regularly to insure that the
proper inﬂation pressure is maintained.
Refer to Tires on page 10-69.

NOTE

Tire pressures listed on the vehicle
placard or tire information label
indicate the recommended cold tire
inﬂation pressure, measured when the
tires are cold, after the vehicle has
been parked for at least 3 hours. As
you drive, the temperature in the tire
warms up, increasing the tire pressure.

WARNING

Always check the tire inﬂation
pressures on a regular basis according
to the recommended tire inﬂation
pressure on the tire label and in
conjunction with the information in
this owner's manual.

Driving your vehicle with
under-inﬂated tires is dangerous.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-34

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Under-inﬂation is the most common
cause of failures in any kind of tire and
may result in severe cracking, tread
separation or “blowout”, with
unexpected loss of vehicle control and
increased risk of injury. Under-inﬂation
increases sidewall ﬂexing and rolling
resistance, resulting in heat buildup
and internal damage to the tire. It
results in unnecessary tire stress,
irregular wear, loss of control and
accidents. A tire can lose up to half of
its air pressure and not appear to be
ﬂat!
It is impossible to determine whether
or not tires are properly inﬂated just by
looking at them.

Checking Tire Pressure

1. When you check the air pressure,

make sure the tires are cold

―

meaning they are not hot from

driving even a mile.

2. Remove the cap from the valve on

one tire.

3. Firmly press a tire gauge onto the

valve.

4. Add air to achieve recommended

air pressure.

5. If you overﬁll the tire, release air by

pushing on the metal stem in the
center of the valve. Then recheck
the pressure with your tire gauge.

6. Replace the valve cap.
7. Repeat with each tire, including the

spare.

NOTE

Some spare tires require higher
inﬂation pressure.

8. Visually inspect the tires to make

sure there are no nails or other
objects embedded that could poke
a hole in the tire and cause an air
leak.

9. Check the sidewalls to make sure

there are no gouges, cuts, bulges,
cracks or other irregularities.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-35

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Glossary of Terms

Tire Placard:

A label indicating the OE

tire sizes, recommended inﬂation
pressure, and the maximum weight the
vehicle can carry.

Tire Identiﬁcation Number (TIN):

number on the sidewall of each tire
providing information about the tire
brand and manufacturing plant, tire
size, and date of manufacture.

Inﬂation Pressure:

A measure of the

amount of air in a tire.

kPa:

Kilopascal, the metric unit for air

pressure.

psi:

Pounds per square inch, the

English unit for air pressure.

B-pillar:

The structural member at the

side of the vehicle behind the front
door.

Original Equipment (OE):

Describes

components originally equipped on
the vehicle.

Vehicle Load Limit:

The maximum

value of the combination weight of
occupants and cargo.

Bead Area of the Tire:

Area of the tire

next to the rim.

Sidewall Area of the Tire:

Area

between the bead area and the tread.

Tread Area of the Tire:

Area on the

perimeter of the tire that contacts the
road when it's mounted on the
vehicle.

Seating capacity

means the total

allowable number of vehicle
occupants. Seating capacity is
described on the tire label.

Production options weight

is the

combination weight of installed regular
production options weighing over 2.3
kilograms in excess of the standard
items which they replace, and not
previously considered in the curb

weight or accessory weight, including
heavy duty brakes, ride levelers, roof
rack, heavy duty battery, and special
trim.

Rim

is the metal support (wheel) for a

tire or a tire and tube assembly upon
which the tire beads are seated.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-36

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Tire Rotation

To equalize tread wear, rotate the tires
every 16,000 km (10,000 miles) at the
latest or sooner if irregular wear
develops. Mazda recommends to
rotate every 8,000 km (5,000 miles) to
help increase tire life and distribute
wear more evenly.

Do not include (TEMPORARY USE
ONLY) spare tire in rotation.

Inspect the tires for uneven wear and
damage. Abnormal wear is usually
caused by one or a combination of the
following:



Incorrect tire pressure



Improper wheel alignment



Out-of-balance wheel



Severe braking

After rotation, inﬂate all tire pressures
to speciﬁcation on page 10-69 and
inspect the lug nuts for tightness.

CAUTION

Rotate unidirectional tires and radial
tires that have an asymmetrical tread
pattern or studs only from front to rear,
not from side to side. Tire performance
will be weakened if rotated from side
to side.

Replacing a Tire

WARNING

Always use tires that are in good
condition.

Driving with worn tires is dangerous.
Reduced braking, steering, and
traction could result in an accident.

If a tire wears evenly, a wear indicator
will appear as a solid band across the
tread.
Replace the tire when this happens.

1. New tread
2. Worn tread
3. Tread wear indicator

You should replace the tire before the
band crosses the entire tread.

NOTE

Tires degrade over time, even when
they are not being used on the road. It
is recommended that tires generally be
replaced when they are 6 years or
older. Heat caused by hot climates or
frequent high loading conditions can
accelerate the aging process. You
should replace the spare tire when you
replace the other road tires due to the
aging of the spare tire. The period in
which the tire was manufactured (both
week and year) is indicated by a 4-digit
number.
Refer to Tire Labeling on page 10-30.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-38

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Safety Practices

The way you drive has a great deal to
do with your tire mileage and safety.
So cultivate good driving habits for
your own beneﬁt.



Observe posted speed limits and
drive at speeds that are safe for the
existing weather conditions



Avoid fast starts, stops and turns



Avoid potholes and objects on the
road



Do not run over curbs or hit the tire
against the curb when parking

CAUTION

If you feel a sudden vibration or ride
disturbance while driving or you
suspect your tire or vehicle has been
damaged, immediately reduce your
speed. Drive with caution until you can
safely pull oﬀ the road. Stop and
inspect the tire for damage. If the tire
is under-inﬂated or damaged, deﬂate
it, remove the tire and rim and replace
it with your spare tire. If you cannot
detect a cause, have the vehicle towed
to the nearest vehicle or tire dealer to
have the vehicle inspected.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-39

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Vehicle Loading

This section will guide you in the proper loading of your vehicle and/or trailer, to
keep your loaded vehicle weight within its design rating capability, with or without a
trailer. Properly loading your vehicle will provide maximum return of vehicle design
performance. Before loading your vehicle, familiarize yourself with the following
terms for determining your vehicle's weight ratings, with or without a trailer, from
the vehicle's Safety Certiﬁcation Label and Tire and Load Information Label:

WARNING

Overloaded Vehicle.

Overloading a vehicle is dangerous. The results of overloading can have serious
consequences in terms of passenger safety. Too much weight on a vehicle's
suspension system can cause spring or shock absorber failure, brake failure, handling
or steering problems, irregular tire wear, tire failure or other damage.
Overloading makes a vehicle harder to drive and control. It also increases the
distance required for stopping. In cases of serious overloading, brakes can fail
completely, particularly on steep grades. The load a tire will carry safely is a
combination of the size of the tire, its load range, and corresponding inﬂation
pressure.
Never overload the vehicle and always observe the vehicle's weight ratings from the
vehicle's Safety Certiﬁcation and Tire and Load Information labels.

Base Curb Weight is the weight of the vehicle including a full tank of fuel and all
standard equipment. It does not include passengers, cargo, or optional
equipment.

Vehicle Curb Weight

is the weight of your new vehicle when you picked it up from

your dealer plus any aftermarket equipment.

PAYLOAD

Payload

is the combination weight of cargo and passengers that the vehicle is

designed to carry. The maximum payload for your vehicle can be found on the Tire
and Load Information label on the driver's door frame or door pillar. Look for “THE
COMBINATION WEIGHT OF OCCUPANTS AND CARGO SHOULD NEVER EXCEED
XXX kg or XXX lbs” for your maximum payload. The payload listed on the tire label is
the maximum payload for the vehicle as built by the assembly plant. If any
aftermarket or dealer installed equipment has been installed on the vehicle, the
weight of the equipment must be subtracted from the payload listed on the tire
label in order to be accurate.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-40

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

SAMPLE

CARGO

Cargo Weight

includes all weight added to the Base Curb Weight, including cargo

and optional equipment. When towing, trailer tongue load or king pin weight is also
part of cargo weight.

The cargo weight limit decreases depending on the number of vehicle occupants.
The cargo weight limit can be calculated by subtracting the total weight of the
vehicle occupants from the “combination weight of occupants and cargo should
never exceed” value on the tire label.

Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385
kg (849 lbs) for the “combination weight of occupants and cargo should never
exceed”:
The cargo weight limit with one occupant is 385 kg (849 lbs)

－

68 kg (150 lbs) =

317 kg (699 lbs)
The cargo weight limit with two occupants is 385 kg (849 lbs)

－

(68 × 2) kg ( (150

× 2) lbs) = 249 kg (549 lbs)
If the weight of the occupant increases, the cargo weight limit decreases by that
much.

GAW (Gross Axle Weight)

is the total weight placed on each axle (front and rear) -

including vehicle curb weight and all payload.

GAWR (Gross Axle Weight Rating)

is the maximum allowable weight that can be

carried by a single axle (front or rear).

These numbers are shown on the Safety

Compliance Certiﬁcation Label located on the driver's door frame or door pillar.
The total load on each axle must never exceed its GAWR.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-41

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

GVW

GVW (Gross Vehicle Weight)

is the Vehicle Curb Weight + cargo + passengers.

GVWR (Gross Vehicle Weight Rating)

is the maximum allowable weight of the fully

loaded vehicle (including all options, equipment, passengers and cargo).

The GVWR

is shown on the Safety Compliance Certiﬁcation Label located on the driver's
door frame or door pillar. The GVW must never exceed the GVWR.

SAMPLE

WARNING

Never Exceed Axle Weight Rating Limits.

Exceeding the Safety Certiﬁcation Label axle weight rating limits is dangerous and
could result in death or serious injury as a result of substandard vehicle handling,
performance, engine, transmission and/or structural damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle weight rating limits.

GCW

GCW (Gross Combination Weight)

is the weight of the loaded vehicle (GVW) plus

the weight of the fully loaded trailer.

GCWR (Gross Combination Weight Rating)

is the maximum allowable weight of

the vehicle and the loaded trailer - including all cargo and passengers - that the
vehicle can handle without risking damage. (Important: The towing vehicle's braking
system is rated for operation at GVWR, not at GCWR. Separate functional brakes
should be used for safe control of towed vehicles and for trailers weighing more than
1,500 lbs).

The GCW must never exceed the GCWR.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-42

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Maximum Loaded Trailer Weight

is the highest possible weight of a fully loaded

trailer the vehicle can tow. It assumes a vehicle with only mandatory options, no
cargo (internal or external), a tongue load of 10

－

15% (conventional trailer) or king

pin weight of 15

－

25% (ﬁfth-wheel trailer), and driver only (150 lbs).

Consult your

dealership (or the RV and Trailer Towing Guide provided by your dealership) for
more detailed information.
Tongue Load or Fifth-Wheel King Pin Weight

refers to the amount of the weight that

a trailer pushes down on a trailer hitch.

Examples:

For a 5000 lb conventional trailer, multiply 5000 by 0.10 and 0.15 to

obtain a proper tongue load range of 500 to 750 lbs. For an 11,500 lb ﬁfth-wheel
trailer, multiply by 0.15 and 0.25 to obtain a proper king pin load range of 1,725 to
2,875 lbs.

WARNING

Never Exceed GVWR or GAWR Speciﬁcations.

Exceeding the GVWR or the GAWR speciﬁed on the certiﬁcation label is dangerous.
Exceeding any vehicle rating limitation could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower load carrying capacities than the originals
because they may lower the vehicle's GVWR and GAWR limitations. Replacement
tires with a higher limit than the originals do not increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR speciﬁed on the certiﬁcation label.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-43

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Steps for Determining the Correct Load Limit

Steps for Determining Correct Load Limit-
(1) Locate the statement “The combined weight of occupants and cargo should

never exceed XXX kg or XXX lbs.” on your vehicle's placard.

(2) Determine the combined weight of the driver and passengers that will be riding

in your vehicle.

(3) Subtract the combined weight of the driver and passengers from XXX kg or XXX

lbs.

(4) The resulting ﬁgure equals the available amount of cargo and luggage load

capacity. For example, if the “XXX” amount equals 1400 lbs. and there will be
ﬁve 150 lb passengers in your vehicle, the amount of available cargo and
luggage load capacity is 650 lbs. (1400

－

750 (5 × 150) = 650 lbs.)

(5) Determine the combined weight of luggage and cargo being loaded on the

vehicle. That weight may not safely exceed the available cargo and luggage load
capacity calculated in Step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to

your vehicle. Consult this manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.

Speciﬁcations/Customer Information and Reporting Safety Defects

Tire Information (U.S.A.)

10-44

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

M Hybrid Battery (e-SKYACTIV G)

Item

Speciﬁcation

Type

Lithium-ion battery

Temperature range

Operation guaranteed temperature:

－

℃

(

－

℉

)

―

℃

(140

℉

)

Storage guaranteed temperature:

－

℃

(

－

℉

)

―

℃

(194

℉

)

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-61

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Electrical System

Battery

Classiﬁcation

Speciﬁcation

U.S.A. and Cana-
da

LN2 (12V-60Ah/20HR) or 55D23L (12V-60Ah/20HR) or 75D23L (12V-65Ah/

20HR)

Mexico

LN2 (12V-60Ah/20HR) or 55D23L (12V-60Ah/20HR)

The battery speciﬁcation diﬀers depending on the country or region. Check the battery installed on
the vehicle and use a battery with an equal or higher performance. However, the performance of the
battery may vary even among the same battery types, consult an Authorized Mazda Dealer for
replacement.

Spark-plug

Classiﬁcation

Speciﬁcation

SKYACTIV-G 2.0

Mazda Genuine spark
plug

PE5R-18-110–A or PE5S-18-110

SKYACTIV-G 2.5

With Cylinder
Deactivation

Mazda Genuine spark
plug

P5SP-18110

Without Cylin-
der Deactiva-
tion

Mazda Genuine spark
plug

PE5R-18-110–A or PE5S-18-110

SKYACTIV-G 2.5T

Mazda Genuine spark
plug

PY8V-18-110

This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized
Mazda Dealer for details.

CAUTION

When cleaning the iridium plugs, do not use a wire brush. The ﬁne particulate
coating on the iridium alloy and platinum tips could be damaged.

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-62

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Lubricant Quality

Lubricant

Classiﬁcation

Engine oil

Refer to Recommended Oil on page 9-16.

Coolant

FL-22 type

Manual transmission oil

With Cylinder Deactiva-
tion

Mazda Long Life Gear Oil G8

Without Cylinder Deac-
tivation

Mazda Long Life Gear Oil G7

Automatic transmission
ﬂuid

With Cylinder Deactiva-
tion

Mazda Genuine ATF A7

Without Cylinder Deac-
tivation

Mazda Genuine ATF FZ

Transfer case oil

Mazda Long Life Hypoid Gear Oil SG1

Rear diﬀerential oil

Brake ﬂuid

e-SKYACTIV G

Mazda Genuine Brake Fluid or equivalent

SKYACTIV-G

SAE J1703 or FMVSS116 DOT-3

Periodic replacement is unnecessary.

Replacement is necessary when the component is submerged in water.

NOTE

Refer to Introduction on (page 9-4) for owner's responsibility in protecting your
investment.

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-63

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Capacities

(Approximate Quantities)

Item

U.S.A. and Canada

Mexico

Engine oil

SKYACTIV-G
2.0

With oil ﬁlter re-
placement

4.2 L (4.4 US qt, 3.7 Imp qt)

Without oil ﬁlter
replacement

4.0 L (4.2 US qt, 3.5 Imp qt)

SKYACTIV-G
2.5

With oil ﬁlter re-
placement

4.5 L (4.8 US qt, 4.0 Imp qt)

Without oil ﬁlter
replacement

4.3 L (4.5 US qt, 3.8 Imp qt)

SKYACTIV-G
2.5T

With oil ﬁlter re-
placement

4.8 L (5.1 US qt, 4.2 Imp qt)

Without oil ﬁlter
replacement

4.6 L (4.9 US qt, 4.0 Imp qt)

Coolant

SKYACTIV-G 2.0

―

6.1 L (6.4 US qt, 5.4 Imp

qt)

SKYACTIV-G
2.5

Manual transmis-
sion

6.6 L (7.0 US qt, 5.8 Imp

qt)

5.9 L (6.2 US qt, 5.2 Imp

qt)

Automatic trans-
mission

6.9 L (7.3 US qt, 6.1 Imp

qt)

6.1 L (6.4 US qt, 5.4 Imp

qt)

SKYACTIV-G
2.5T

For engine

7.9 L (8.3 US qt, 7.0 Imp qt)

For water-cooled
charge air cooler

1.6 L (1.7 US qt, 1.4 Imp qt)

Manual transmission oil

1.65 L (1.74 US qt, 1.45 Imp qt)

Automatic
transmis-
sion ﬂuid

SKYACTIV-G 2.0, SKYACTIV-G 2.5

7.6 L (8.0 US qt, 6.7 Imp qt)

SKYACTIV-G 2.5T

8.0 L (8.5 US qt, 7.0 Imp qt)

Transfer case oil

0.35 L (0.37 US qt, 0.31 Imp qt)

Rear diﬀerential oil

0.35 L (0.37 US qt, 0.31 Imp qt)

Fuel tank

FWD

50.0 L (13.2 US gal, 11.0

Imp gal)

51.0 L (13.5 US gal, 11.2

Imp gal)

AWD

48.0 L (12.7 US gal, 10.6 Imp gal)

Check oil and ﬂuid levels with dipsticks or reservoir gauges.

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-64

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Dimensions

4-Door

Item

Vehicle speciﬁcation

Overall length

4,662 mm (183.5 in)

Overall width

1,797 mm (70.7 in)

Overall height

1,445 mm (56.9 in)

Front tread

1,568 mm (61.7 in)

Rear tread

FWD

1,581 mm (62.2 in)

AWD

1,580 mm (62.2 in)

Wheelbase

2,726 mm (107.3 in)

5-Door

Item

Vehicle speciﬁcation

Overall length

4,459 mm (175.6 in)

Overall width

1,797 mm (70.7 in)

Overall height

1,440 mm (56.7 in)

Front tread

1,568 mm (61.7 in)

Rear tread

FWD

1,581 mm (62.2 in)

AWD

1,580 mm (62.2 in)

Wheelbase

2,726 mm (107.3 in)

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-65

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Weights

U.S.A. and Canada

SKYACTIV-G 2.5
(4-Door)

Item

FWD

AWD

GVWR (Gross Vehicle Weight
Rating)

1,850 kg (4,079 lbs)

1,923 kg (4,239 lbs)

GAWR (Gross Axle
Weight Rating)

Front

1,016 kg (2,240 lbs)

1,045 kg (2,304 lbs)

Rear

839 kg (1,850 lbs)

888 kg (1,958 lbs)

(5-Door)

Item

FWD

AWD

Manual transmission

Automatic transmis-

sion

GVWR (Gross Vehicle Weight
Rating)

1,830 kg (4,034 lbs)

1,856 kg (4,092 lbs)

1,927 kg (4,248 lbs)

GAWR (Gross Axle
Weight Rating)

Front

1,003 kg (2,211 lbs)

1,029 kg (2,269 lbs)

1,053 kg (2,321 lbs)

Rear

842 kg (1,856 lbs)

839 kg (1,850 lbs)

874 kg (1,927 lbs)

SKYACTIV-G 2.5T
(4-Door)

Item

Weight

GVWR (Gross Vehicle Weight
Rating)

1,955 kg (4,310 lbs)

GAWR (Gross Axle
Weight Rating)

Front

1,068 kg (2,355 lbs)

Rear

892 kg (1,967 lbs)

(5-Door)

Item

Weight

GVWR (Gross Vehicle Weight
Rating)

1,955 kg (4,310 lbs)

GAWR (Gross Axle
Weight Rating)

Front

1,087 kg (2,396 lbs)

Rear

874 kg (1,927 lbs)

Mexico

SKYACTIV-G 2.0

Item

Weight

GVW (Gross Vehicle Weight)

1,881 kg (4,147 lbs)

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-66

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

SKYACTIV-G 2.5
(4-Door)

Item

Weight

Manual transmission

Automatic transmission

GVW (Gross Vehicle Weight)

1,861 kg (4,103 lbs)

1,870 kg (4,123 lbs)

(5-Door)

Item

Weight

Manual transmission

Automatic transmission

GVW (Gross Vehicle Weight)

1,848 kg (4,074 lbs)

1,870 kg (4,123 lbs)

SKYACTIV-G 2.5T

Item

Weight

GVW (Gross Vehicle Weight)

1,950 kg (4,299 lbs)

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-67

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Light Bulbs

Exterior light

Light bulb

Category

Wattage

UN-R

(SAE)

Headlights

LED

―

(

―

)

Daytime running lights

LED

―

(

―

)

Parking lights

LED type

LED

―

(

―

)

Bulb type

WY5W (

―

)

Front turn signal lights

LED

―

(

―

)

Front side-marker lights

LED type

LED

―

(

―

)

Bulb type

WY5W (

―

)

Side turn signal lights

LED

―

(

―

)

High-mount brake light

LED

―

(

―

)

Rear turn signal lights

LED

―

(

―

)

Rear side-marker lights

LED

―

(

―

)

Brake lights

LED

―

(

―

)

Taillights

LED

―

(

―

)

Reverse lights

LED

―

(

―

)

License plate lights

LED

―

(

―

)

UN-R stands for United Nations Regulation.

Interior light

Light bulb

Category

Wattage

UN-R

Overhead light (Front)/Map lights

LED

―

Overhead light (Rear)

LED

―

Vanity mirror lights

LED

―

Trunk light (4-Door)

―

Luggage compartment light (5-Door)

LED

―

UN-R stands for United Nations Regulation.

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-68

*Some models.

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Tires

NOTE

The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally ﬁtted to your vehicle. For details, contact an Authorized Mazda Dealer.

Check the tire pressure label for tire size and inﬂation pressure.



Refer to Tire Pressure Label on page 10-58.

Standard tire

(U.S.A. and Canada)

Tire size

Inﬂation pressure

Front

Rear

205/60R16 92H M+S

250 kPa (36 psi)

215/45R18 89V
M+S

SKYACTIV-G 2.0,
SKYACTIV-G 2.5

250 kPa (36 psi)

SKYACTIV-G
2.5T

260 kPa (38 psi)

250 kPa (36 psi)

(Mexico)

Tire size

Inﬂation pressure

Up to 3 persons

―

Full load

205/60R16 92V

Front

250 kPa (2.5 bar, 36 psi)

260 kPa (2.6 bar, 38 psi)

Rear

250 kPa (2.5 bar, 36 psi)

290 kPa (2.9 bar, 42 psi)

215/45R18 89W

Front

250 kPa (2.5 bar, 36 psi)

270 kPa (2.7 bar, 39 psi)

Rear

250 kPa (2.5 bar, 36 psi)

290 kPa (2.9 bar, 42 psi)

1 person's weight: About 75 kg

Temporary spare tire

Tire size

Inﬂation pressure

T125/80D16 97M

420 kPa (60 psi)

Lug nut tightening torque

When installing a tire, tighten the lug nut to the following torque.
108

―

147 N·m (12

―

14 kgf·m, 80

―

108 ft·lbf)

Speciﬁcations/Customer Information and Reporting Safety Defects

Vehicle Speciﬁcation

10-69

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Index

Active Driving Display................5-37

Active driving display does not
operate................................ 8-38
Maintenance of the dust-proof
sheet................................... 9-53

Add-On Non-Genuine Parts and
Accessories............................. 10-25
Air Bags...................................... 3-4

Driver and front passenger
occupant classiﬁcation
system................................. 3-18
Front passenger occupant
classiﬁcation system..............3-18

Air-Conditioning

Air vents................................ 6-2
Maintenance........................ 9-45
Operating each switch............ 6-7

Automatic Transmission

Canceling shift-lock system....8-20
Selector lever....................... 5-44
Steering shift switches........... 5-50

AWD

i-ACTIV AWD.......................5-91

Battery

Electrical system................. 10-62
Inspecting Lead-acid
battery................................. 9-22
Taking action with depleted lead-
acid battery..........................8-12

Brakes

Antilock Brake System
(ABS)................................... 5-84
AUTOHOLD......................... 5-63
AUTOHOLD cannot be
canceled.............................. 8-19
Brake override system........... 5-61

Dynamic Stability Control
(DSC).................................. 5-87
Electric Parking Brake (EPB)....5-56
Hill Launch Assist (HLA)........ 5-66
Inspecting the brake ﬂuid...... 9-20
Problem with the brake system
(foot brake)..........................8-18
Traction Control System
(TCS)................................... 5-85

Cell Phones............................ 10-26
Climate Control System

Fully Automatic Climate Control
System Overview.................... 6-6
Manual Climate Control System
Overview............................. 6-15

Cruise Control........................ 5-194
Customer Assistance (Canada)... 10-9
Customer Assistance (Mexico)...........
.............................................. 10-15
Customer Assistance (Puerto
Rico)...................................... 10-13
Customer Assistance (U.S.A.)..... 10-4

Doors

Doors.................................. 4-12
Liftgate.................................4-18

Drive Selection..........................5-89

Engine

Cylinder deactivation............ 5-23
Engine................................10-60
Engine cannot be stopped.....8-17
Engine number................... 10-59
Inspecting the coolant.......... 9-18
Inspecting/replenishing engine
oil........................................9-16

11-2

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Index

i-stop...................................5-21
Overheating......................... 8-21
Push button start.................. 5-13
Starting a ﬂooded engine...... 8-16
Starting the engine with a dead
key battery........................... 8-10
Taking action with depleted lead-
acid battery..........................8-12

Fuses

Panel description.................. 9-26

Hood........................................4-22

Inspection and Maintenance

Air conditioner
maintenance........................ 9-45
Capacities.......................... 10-64
Dimensions........................ 10-65
Lubricant quality................. 10-63
Motor Vehicle Safety Standard
Label..................................10-57
Vehicle Emission Control
Information Label............... 10-58
Weights..............................10-66

Inspection and Servicing

Body lubrication................... 9-31
Brake ﬂuid............................9-20
Coolant............................... 9-18
Engine oil.............................9-16
Fuses................................... 9-24
Inspecting the tires............... 9-36
Inspection and servicing..........9-4
Lead-acid battery..................9-22
Light bulbs........................... 9-40
Replacing a tire or a wheel.... 9-39
Rotating the tires.................. 9-38

Windshield washer ﬂuid........ 9-21
Windshield wiper blade
rubbers................................ 9-32

Instrument Cluster

Average fuel economy
display................................. 5-33
Compass display.................. 5-35
Dashboard illumination........ 5-30
Deceleration regeneration charge
display................................. 5-34
Engine coolant temperature
gauge...................................5-29
Fuel gauge........................... 5-30
Instantaneous fuel economy
display................................. 5-34
Instrument cluster.................5-24
i-ACTIVSENSE display........... 5-35
Maximum driving distance
display................................. 5-32
Message display................... 5-36
Multi-information display......5-26
Odometer/Trip meter...........5-28
Outside temperature
display................................. 5-32
Speedometer....................... 5-24
Tachometer.......................... 5-25
Warning/Indicator light turns
on....................................... 8-39

Interior Equipment

Accessory sockets................. 7-37
Bottle holder........................ 7-25
Center console..................... 7-27
Cup holders......................... 7-24
Glove compartment..............7-26
How to use the assist grips.... 7-43
Illuminated entry system........7-33
Luggage compartment.......... 7-30
Luggage compartment
lights....................................7-36
Map lights............................7-35
Overhead console................ 7-28

11-3

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Index

Overhead lights.................... 7-34
Rear coat hooks................... 7-29
Sunvisor............................... 7-31
Trunk lights.......................... 7-35
Vanity mirrors.......................7-32
Wireless charger (Qi)............ 7-39

i-ACTIVSENSE

Adaptive Front Lighting System
(AFS)................................. 5-121
Blind Spot Monitoring
(BSM)................................ 5-127
Cameras............................ 5-118
Cruising & Traﬃc Support
(CTS)................................. 5-156
Distance & Speed Alert
(DSA)................................ 5-133
Driver Attention Alert
(DAA)................................ 5-135
Driver monitoring camera....5-120
Driver Monitoring (DM)...... 5-137
Forward Sensing Camera
(FSC)................................. 5-108
Front Cross Traﬃc Alert
(FCTA)............................... 5-141
High Beam Control System
(HBC)................................ 5-122
i-ACTIVSENSE mute switch ...........
......................................... 5-107
i-ACTIVSENSE status symbol
(Warning/risk avoidance support
system).............................. 5-106
Lane Departure Warning System
(LDWS).............................. 5-125
Lane-keep Assist System
(LAS)..................................5-169
Mazda Radar Cruise Control
(MRCC)............................. 5-146
Radar sensors..................... 5-112
Rear Cross Traﬃc Alert
(RCTA)............................... 5-144

Secondary Collision
Reduction.......................... 5-192
Smart Brake Support (SBS)...5-172
Traﬃc Sign Recognition
System (TSR)...................... 5-130
360° View Monitor.............5-178

Key.............................................4-5

Canceling the key temporary
suspension function................8-9
Replacing the key battery...... 9-46
Starting the engine with a dead
key battery........................... 8-10
Unlocking using the auxiliary
key........................................ 8-9

Liftgate..................................... 4-18

Liftgate cannot open............. 8-32

Light

Washer ﬂuid does not spray...8-37

Lights

Hazard warning lights........... 5-82
Light bulbs......................... 10-68
Light switch.......................... 5-67
Replacing light bulbs.............9-40
Turn signal lever................... 5-72

Maintenance

Dashboard........................... 9-51
Dust-proof sheet of the active
driving display...................... 9-53
Exterior................................ 9-49
Interior.................................9-51
Leather upholstery................ 9-52
Seat belts............................. 9-54
Upholstery and synthetic
leather................................. 9-52

11-4

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Index

Wheel..................................9-50

Manual Transmission

Shift lever.............................5-40

Mazda Connect

Connected service (If
applicable)...........................7-13
Mazda connect...................... 7-4
Mazda connect overview........ 7-7

Mirrors

Mirror defogger.................... 5-79
Outside mirrors...................... 5-9
Rearview mirror....................5-11

Moonroof................................. 4-29
M Hybrid

M Hybrid............................. 5-16
M Hybrid Battery................ 10-61

Parking Sensor.........................5-203

Rear View Monitor.................. 5-198
Refueling.................................. 5-98

Fuel requirements............... 5-100

Registering Your Vehicle in A Foreign
Country.................................. 10-24

Safety Defects, Reporting
(Canada)................................ 10-22
Safety Defects, Reporting
(U.S.A.).................................. 10-21
Seat

Child-restraint system........... 3-47

Seats

Driving Position Memory.......3-36
Front seats........................... 3-34
Leather upholstery
maintenance........................ 9-52
Rear seats............................ 3-40

Seat warmer.........................6-21
Upholstery and synthetic leather
maintenance........................ 9-52

Seat Belts..................................3-24

Maintenance........................ 9-54

Security System......................... 4-30

Immobilizer system...............4-32
Theft-Deterrent System......... 4-33

Steering Wheel

Heated steering wheel.......... 6-24
Power steering......................5-92
Steering shift switches........... 5-50

Sunroof.....................................4-29

Tires

Inspecting the tires............... 9-36
Replacing a tire or a wheel.... 9-39
Rotating the tires.................. 9-38
Tires...................................10-69
Tire pressure label...............10-58
Tire Pressure Monitoring System
(TPMS)................................ 5-93
Uniform tire quality grading
system (UTQGS)................. 10-27
Wheel maintenance..............9-50

Tire Information

Location of the tire label
(placard)............................ 10-34
Steps for determining the correct
load limit........................... 10-44
Tire labeling....................... 10-30
Tire maintenance................ 10-37
Vehicle loading...................10-40

Towing

Having the vehicle towed........ 8-5
Using the towing hooks.......... 8-6

Turbocharged vehicles............. 5-212

11-5

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Mazda 3 (2024 year). Manual in english - page 18
