Warning Lights

If any warning/indicator light turns
on/ﬂashes, take appropriate action for
each light. If the warning/indicator
light does not turn oﬀ, or it turns on or
ﬂashes again, consult an Authorized
Mazda Dealer.

WARNING

If the warning light/indicator light
turns on or ﬂashes, park the vehicle in
a safe place immediately and take
appropriate measures.
Continuing to drive the vehicle while
ignoring the illumination/ﬂashing of
the warning light/indicator light is
dangerous because a problem may
occur to a vehicle system, the engine
may be damaged, or it could lead to
an accident.

The details for some warnings can be
viewed on the center display or
instrument cluster.

Checking Using the Center Display

1. Select “Information” on the home

screen.

2. Select “Vehicle Status Monitor”.
3. Select the applicable warning to

view the warning details.

Checking Using the Instrument
Cluster

Press the INFO switch on the steering
switch to display the warning
indication screen.
Refer to How to Use the
Multi-information Display on page
5-27.

Brake System Warning

Light

This warning has the following
functions:

Warning light inspection

For an operation check, make sure that
the light turns on when the vehicle
power is switched on, and turns oﬀ a
few seconds later or when the engine
is started.

When the light turns on

The light turns on continuously if any
one of the following occurs:



Insuﬃcient brake ﬂuid



Brake system (electronic brake force
distribution system) has a problem

Park the vehicle in a safe place
immediately and contact an
Authorized Mazda Dealer.

WARNING

Do not drive with the brake system
warning light illuminated. Contact an
Authorized Mazda Dealer to have the
brakes inspected as soon as possible.

Driving with the brake system warning
light illuminated is dangerous. It
indicates that your brakes may not
work at all or that they could
completely fail at any time. If this light
remains illuminated, after checking
that the parking brake is fully released,
have the brakes inspected
immediately.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-39

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

If the brake system warning light and

the ABS warning light

turn on at

the same time, stop the vehicle in a
safe place immediately and contact an
Authorized Mazda Dealer.

The rear wheels could lock more
quickly in an emergency stop than
under normal circumstances which
could result in an accident.

CAUTION



In addition, the eﬀectiveness of the
braking may diminish so you may
need to depress the brake pedal
more strongly than normal to stop
the vehicle.



(e-SKYACTIV G)
The brake warning light may turn on
when the engine is started. In this
case, park the vehicle in a safe
location and release the brake pedal.
If the brake warning light remains
illuminated, have the vehicle
inspected by an Authorized Mazda
Dealer.

Charging System Warning

Light

The light turns on if the charging
system has a problem.
Park the vehicle in a safe place
immediately and contact an
Authorized Mazda Dealer.

WARNING

Do not continue driving with the
charging system warning light turned
on:

Otherwise, the engine may stop, which
could result in an accident.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-40

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Engine Oil Warning Light

The light turns on when the engine oil
pressure decreases.

CAUTION

Do not drive the vehicle with the
engine oil warning light turned on.
Driving the vehicle with decreased
engine oil pressure may cause engine
damage.

If the engine oil warning light turns on
while driving, stop the vehicle in a safe
place and stop the engine.
After that, contact an Authorized
Mazda Dealer.

High Engine Coolant

Temperature Warning

Light

The light turns on if the engine coolant
temperature has increased excessively.
Check the contents of the message
displayed and take the necessary
action.

CAUTION

Do not drive the vehicle with the high
engine coolant temperature warning
light turned on. Driving the vehicle
with the engine not cooled down may
cause engine damage.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-41

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Electric Power Steering

Warning Light

The warning light turns on if the
electric power steering has a
malfunction.
If the warning light turns on, stop the
vehicle in a safe place and switch the
vehicle power OFF.
There is no problem if the warning light
turns oﬀ when the engine is restarted
after some time has passed.
If the warning light turns on even after
the engine is restarted, contact an
Authorized Mazda Dealer.

NOTE



If the warning light turns on, the
electric power steering will not
operate normally. In this case, the
steering wheel can still be operated,
however, the operation may feel
heavy compared to normal.



Repeatedly jerking the steering
wheel left and right while the vehicle
is stopped or moving extremely
slowly will cause the power steering
system to go into protective mode
which will make the steering feel
heavy, but this does not indicate a
problem. If this occurs, park the
vehicle safely and do not operate the
steering wheel. The system will
return to normal after a few minutes.

ABS Warning Light

The light remains on if the system has a
problem.
Have your vehicle inspected by an
Authorized Mazda Dealer.

WARNING

If the brake system warning light
and the ABS warning light turn on at
the same time, stop the vehicle in a
safe place immediately and contact an
Authorized Mazda Dealer.

The rear wheels could lock more
quickly in an emergency stop than
under normal circumstances which
could result in an accident.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-42

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Electric Parking Brake

(EPB) Indicator Light

The light turns on when applying the
parking brake and it turns oﬀ when
releasing the parking brake.

Parking brake warning/Indicator light
inspection

The light illuminates when the parking
brake is applied with the vehicle power
switched to START or ON. It turns oﬀ
when the parking brake is released.

Turning on

If the light remains on even with the
electric parking brake (EPB) switch
turned oﬀ, the system may have a
malfunction. Have the vehicle
inspected by an Authorized Mazda
Dealer.

Flashing

The light ﬂashes if the system has a
problem. If the light remains ﬂashing
even if the electric parking brake (EPB)
switch is pressed, consult an
Authorized Mazda Dealer as soon as
possible.

Check Engine Warning

Light

WARNING

Do not disconnect the lead-acid
battery cables when the check engine
warning light is turned on/ﬂashing.

The engine may be damaged when
reconnecting the lead-acid battery
cables, which could result in a ﬁre.

The light turns on if the engine has a
problem while it is running.
Park the vehicle in a safe place
immediately and contact an
Authorized Mazda Dealer.
If any of the following problems occur,
the check engine warning light turns
on.



There is a problem with the engine
control system



There is a problem with the emission
control system



There is a problem with the
transmission control system



(e-SKYACTIV G)

There is a problem with the M
Hybrid



The fuel tank level being very low or
approaching empty.



The fuel-ﬁller cap is missing or not
tightened securely

If the check engine warning light
remains turned-on/ﬂashing, do not
drive at high speed and have the
vehicle inspected by an Authorized
Mazda Dealer as soon as possible.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-44

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

i-stop Warning Light

(Amber)



After the engine is started, the light
turns on/ﬂashes continuously if the
system has a problem.
Have the vehicle inspected by an
Authorized Mazda Dealer.

Automatic Transmission

Warning Light

The light turns on if the system has a
problem.
Contact an Authorized Mazda Dealer.

CAUTION

Do not drive the vehicle with the
automatic transmission warning light
turned on. If the vehicle continues to
be driven while the automatic
transmission warning light is turned on,
the transmission could be damaged.
Have your vehicle inspected by an
Authorized Mazda Dealer as soon as
possible.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

*Some models.

8-45

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

AWD Warning Light

The light turns on if the system has a
problem or if the tire sizes do not
match.
Check the contents of the message
displayed and take the necessary
action.

Tire Pressure Monitoring

System (TPMS) Warning

Light (Flashing)

The light ﬂashes if there is a
malfunction in the system.
Contact an Authorized Mazda Dealer.

WARNING

Do not drive the vehicle at high
speeds if the TPMS warning light turns
on or ﬂashes:

Driving the vehicle at high speeds
while the TPMS warning light is turned
on or ﬂashing is dangerous because
the brake performance and the
steering wheel operability will be
reduced. If the vehicle is driven at high
speeds or the brakes are suddenly
applied, it could lead to an accident.
Gradually apply the brakes to lower the
vehicle's speed.

Do not ignore the TPMS warning light
when it is turned on or ﬂashing:

Continuing to drive the vehicle while
ignoring the illumination/ﬂashing of
the TPMS warning light is dangerous
because a tire may burst which could
lead to an accident. Take appropriate
measures as soon as possible.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-46

*Some models.

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

TCS/DSC Indicator Light

(Turns on)

There may be a problem with the DSC,
TCS, or Hill Launch Assist (HLA) under
the following conditions.
Have your vehicle inspected by an
Authorized Mazda Dealer.



The light does not turn on or remains
on even if the vehicle power is
switched ON.



It turns on while driving the vehicle.

Air Bag/Seat Belt

Pretensioner System

Warning Light

A problem in the system might be
indicated under the following
conditions.
Have your vehicle inspected by an
Authorized Mazda Dealer.



Does not turn on even if the vehicle
power is switched ON.



Remains turned-on/ﬂashing.

WARNING

Never tamper with the air bag/
pretensioner systems and always have
an Authorized Mazda Dealer perform
all servicing and repairs.

Self-servicing or tampering with the
systems is dangerous. An air bag/
pretensioner could accidentally
activate or become disabled causing
serious injury or death.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-47

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

KEY Warning Light (Red)

The light turns on if the system has a
problem or if the key is out of the
operation range.
Check the contents of the message
displayed and take the necessary
action.

CAUTION

If the push button start indicator light
(amber) ﬂashes at the same time, the
engine may not start. Have the vehicle
inspected by an Authorized Mazda
Dealer as soon as possible.

Security Indicator Light

If the security indicator light turns on/
ﬂashes while driving, do not stop the
engine (leave it operating) and have
the vehicle inspected at an Authorized
Mazda Dealer. If you stop the engine ,
you may not be able to start it again.
If the engine cannot be started, switch
the vehicle power OFF, place the key in
another position within the operation
range, and then restart the engine.
Check the security indicator light and if
it does not turn oﬀ, such as it remains
on or ﬂashes, switch the vehicle power
OFF, wait for a while, and then restart
the engine.
If the engine does not start after three
attempts, a system malfunction may
have occurred. Have the vehicle
inspected by an Authorized Mazda
Dealer.

NOTE

When repairing the immobilizer
system, the key codes will need to be
reprogrammed. Bring all the remaining
keys to an Authorized Mazda Dealer.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-48

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Exterior Lights Warning

Light

The light turns on if the exterior lights
(not including the license plate lights)
has a problem.
Have your vehicle inspected by an
Authorized Mazda Dealer.

CAUTION

Do not drive the vehicle while an
exterior light has a malfunction. Poor
visibility, and not being able to signal
braking and turns may cause an
accident. In addition, if the vehicle is
driven with the lights not turned on, it
may conﬂict with laws and regulations
due to poor maintenance.

Low Fuel Warning Light

The light turns on/ﬂashes when the
remaining fuel in the tank is near
empty.
When the light ﬂashes, a warning
sound is activated.
Refuel immediately.

NOTE

The light illumination timing may vary
because fuel inside the fuel tank moves
around according to the driving
conditions and the vehicle posture.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-50

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Seat Belt Warning Light

(Front Seat)

(Except Mexico)

The warning light ﬂashes for about 6
seconds if the driver or front
passenger's seat is occupied and the
seat belt is not fastened with the
vehicle power switched ON.
If the driver or front passenger's seat
belt is unfastened (only when the front
passenger's seat is occupied) and if the
vehicle is driven at about 20 km/h (12
mph) or faster, or about 10 km/h (6
mph) or faster for a continuous 30
seconds, with the seat belt unfastened,
the warning light ﬂashes for a certain
period.
After a short time, the warning light
stops ﬂashing, but remains illuminated.
In addition, when the warning light
ﬂashes, a warning sound is activated.
Wear the seat belt.

NOTE



Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning
function to operate depending on
the weight of the item.



To allow the sensor that detects an
occupant to function properly, do
not sit on the front passenger's seat
with a cushion or other object on it.
The sensor may not function properly
because the additional seat cushion
could cause sensor interference.



If a small child is seated on the front
passenger's seat, the warning light
may not operate.

(Mexico)

The warning light turns on if the driver
or front passenger's seat is occupied
and the seat belt is not fastened with
the vehicle power switched ON.
If the driver or front passenger's seat
belt is unfastened (only when the front
passenger's seat is occupied) and if the
vehicle is driven at about 20 km/h (12
mph) or faster, the warning light
ﬂashes for a certain period.
After a short time, the warning light
stops ﬂashing, but remains illuminated.
In addition, when the warning light
ﬂashes, a warning sound is activated.
Wear the seat belt.

NOTE



Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning
function to operate depending on
the weight of the item.



If a small child is seated on the front
passenger's seat, the warning light
may not operate.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-52

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Seat Belt Warning Light

(Rear Seat) (Red)

When the vehicle power is switched
ON, the warning lights turn on if the
seat belts are not fastened.

After the engine is started, the warning
lights turn oﬀ after a short period of
time.
In addition, if a fastened seat belt is
unfastened, the warning light ﬂashes
for a short period of time and then
turns oﬀ.
When the warning light ﬂashes, a
warning sound is activated.
Wear the seat belt.

1 The warning light also turns on

when the rear seat is unoccupied.

Rear Seat Alert Warning

Light

The warning light turns on continuously
if the system has a problem. Have the
vehicle inspected by an Authorized
Mazda Dealer.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

*Some models.

8-53

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

KEY Indicator Light

(Green) (Flashing)

The light ﬂashes if the battery power of
the key is low when the vehicle power
is switched from ON to OFF.
Replace the key battery.

Wrench Indicator Light

The wrench indication/indicator light
is displayed/turns on under the
following conditions.



When the preset maintenance
period has arrived.
Refer to the Information section in
the Mazda Connect Owner's
Manual.

CAUTION



When the maintenance period
arrives, have your vehicle inspected
by an Authorized Mazda Dealer as
soon as possible. If maintenance is
neglected, a decrease in vehicle
performance may occur which
could cause damage. Have your
vehicle inspected before the
maintenance period arrives.



If the vehicle continues to be
driven after the engine oil
replacement period has passed, it
could cause damage to the engine.
Replace the engine oil before the
maintenance period arrives.

NOTE



The wrench indication/indicator
light may display/turn on earlier than
the preset period depending on
vehicle usage conditions.



Whenever the engine oil is replaced,
a reset of the vehicle engine control
unit is necessary.
Refer to the Information section in
the Mazda Connect Owner's
Manual.

What to Do in Case of Emergency

Warning/Indicator Light Turns On

8-55

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Key Removed from

Vehicle Warning Sound

Vehicles with advanced keyless
function

If the key is taken out of the vehicle
while the vehicle power is switched to
ACC or ON, and all the doors are
closed, a sound is activated 6 times
outside of the vehicle and a sound is
activated 1 time in the vehicle.

Vehicles without advanced keyless
function

If the key is taken out of the vehicle
while the vehicle power is switched to
ACC or ON, and all the doors are
closed, a sound is activated 1 time in
the vehicle.

Make sure that you leave the vehicle
while carrying the key, or switch the
vehicle power OFF.

Key Left-in-Vehicle

Warning Sound

If all the doors and luggage
compartment/trunk are locked using
another key while the key is left in the
cabin, the beep which sounds outside
of the vehicle will be heard for about
10 seconds to notify the driver that the
key is in the cabin. In this case, take
out the key by opening the door.
A key taken out of the vehicle using
this method may not operate because
its functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure
(page 8-9).

What to Do in Case of Emergency

Warning Sound is Activated

8-57

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Key Left-In-Luggage

Compartment/Trunk

Warning Sound (Vehicles

With Advanced Keyless

Function)

If the key is left in the luggage
compartment/trunk with all the doors
locked and the liftgate/trunk lid
closed, a beep will be heard outside
for about 10 seconds to notify the
driver that the key is in the luggage
compartment/trunk. In this case, take
out the key by pressing the electric
liftgate/trunk lid opener and opening
the liftgate/trunk lid.
The key taken out of the luggage
compartment/trunk may not operate
because its functions have been
temporarily stopped. To restore the
key's functions, perform the applicable
procedure (page 8-9).

Door Lock Inoperable

Warning Sound

Operation Using Touch Sensor

A warning beep is activated to notify
the driver that the doors are not locked
when all of the following conditions
are met:



The vehicle power is switched OFF.



All the doors are not fully closed.



The lock is operated 3 times within 5
seconds.

Check the vehicle power and whether
the doors are open or closed, and then
operate the lock again.

Operation Using Door-lock Switch on
the Liftgate

When the door-lock switch on the
liftgate is pressed under any of the
following conditions, a warning sound
is activated.



The vehicle power is switched to a
position other than OFF.



Any door is open.

Make sure that none of the above
conditions are present, and then press
the door-lock switch again.

What to Do in Case of Emergency

Warning Sound is Activated

8-58

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Brake System Warning

Sound

A warning sound is activated if a
problem with the brake system occurs
and the brakes may not work as
intended. Decelerate the vehicle while
checking the safety of the surrounding
area, and park the vehicle in a safe
place. After stopping the vehicle,
contact an Authorized Mazda Dealer.

Electric Parking Brake

(EPB) Warning Sound

The warning sound is activated under
the following conditions:



The vehicle is driven with the parking
brake applied.



The Electric Parking Brake (EPB)
switch is pulled while the vehicle is
driven.



You attempt to start driving the
vehicle while the conditions for
releasing the Electric Parking Brake
(EPB) automatically have not been
met.

Check the condition of the parking
brake.

What to Do in Case of Emergency

Warning Sound is Activated

8-59

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Inspection and Servicing/Cleaning

Inspection and Servicing............ 9-4

Inspection and Servicing.........9-4

Scheduled Maintenance............ 9-6

Scheduled Maintenance (U.S.A.,
Canada, and Puerto Rico)...... 9-6
Scheduled Maintenance
(Mexico)............................... 9-9

Daily Inspection......................9-12

Daily Inspection...................9-12
Warnings and Cautions for Daily
Inspection........................... 9-13

Engine Compartment
Inspection..............................9-14

Checking the Inspection
Locations and Inspection
Items.................................. 9-14
Inspecting Engine Oil........... 9-16
Inspecting the Coolant......... 9-18
Inspecting the Brake/Clutch
Fluid................................... 9-20
Replenishing Windshield Washer
Fluid................................... 9-21
Inspecting Lead-acid
Battery................................ 9-22
Replacing the Fuses..............9-24
Fuse Panel Description......... 9-26
Inspecting Body
Lubrication.......................... 9-31

Vehicle Exterior Inspection....... 9-32

Checking the Inspection
Locations and Inspection
Items.................................. 9-32
Replacing Windshield Wiper
Blade Rubbers..................... 9-32
Inspecting the Tires.............. 9-36
Rotating the Tires................. 9-38
Replacing a Tire or a
Wheel.................................9-39
Replacing Light Bulbs........... 9-40

Vehicle Interior Inspection....... 9-44

Checking the Inspection
Locations and Inspection
Items.................................. 9-44
Air Conditioner
Maintenance....................... 9-45

Key Inspection........................9-46

Warnings and Cautions about Key
Battery Replacement............ 9-46
How to Replace the Key
Battery................................ 9-46

Exterior Maintenance.............. 9-49

Exterior Maintenance........... 9-49
Wheel Maintenance.............9-50

Interior Maintenance...............9-51

Interior Maintenance........... 9-51
Instrument Panel Top (Soft pad)
Maintenance....................... 9-51
Upholstery and Synthetic Leather
Maintenance....................... 9-52

9-1

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Inspection and Servicing

Be careful not to hurt yourself when
inspecting your vehicle, replacing a
tire, or doing some kind of
maintenance such as changing the oil
and ﬁlter.
In particular, wear thick work gloves
such as cotton gloves when touching
areas that are diﬃcult to see while
inspecting or working on your vehicle.
Doing inspections or procedures with
your bare hands could cause injury.

If you are unsure about any procedure
this manual describes, we strongly urge
you to have a reliable and qualiﬁed
service shop perform the work,
preferably an Authorized Mazda
Dealer.

Factory-trained Mazda technicians and
genuine Mazda parts are best for your
vehicle. Without this expertise and the
parts that have been designed and
made especially for your Mazda,
inadequate, incomplete, and
insuﬃcient servicing may result in
problems. This could lead to vehicle
damage or an accident and injuries.

For expert advice and quality service,
consult an Authorized Mazda Dealer.

To continue warranty eligibility and to
protect your investment, it is your
responsibility to properly maintain your
vehicle according to factory
recommended schedules outlined in
this manual. As part of this you must
keep your maintenance records,
receipts, repair orders and any other
documents as evidence this
maintenance was performed. You must
present these documents, should any
warranty coverage disagreement occur.

Failure to do so can result in your
warranty being voided either in whole
or in part.

This evidence may consist of the
following:



The Mazda Scheduled Maintenance
Record, refer to the Warranty
Booklet, must be completely ﬁlled
out showing mileage, repair order
number, date for each service, and
signed by a qualiﬁed automotive
service technician who service
vehicles.



Original copies of repair orders or
other receipts that include the
mileage and date the vehicle was
serviced. Each receipt should be
signed by a qualiﬁed automotive
service technician.



For self maintenance, a statement
that you completed the maintenance
yourself, displaying mileage and the
date the work was performed. Also,
receipts for the replacement parts
(ﬂuid, ﬁlters, etc.) indicating the date
and mileage must accompany this
statement.

NOTE

If you elect to perform maintenance
yourself or have your vehicle serviced
at a location other than an Authorized
Mazda Dealer, Mazda requires that all
ﬂuids, parts and materials must meet
Mazda standards for durability and
performance as described in this
manual.

Claims against the warranty resulting
from lack of maintenance, as opposed
to defective materials or authorized
Mazda workmanship, will not be
honored.

Inspection and Servicing/Cleaning

Inspection and Servicing

9-4

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Scheduled Maintenance (U.S.A., Canada, and Puerto

Rico)

Vehicles utilizing the vehicle status monitor feature:
The vehicle status monitor feature alerts you of maintenance needs by turning on the
wrench indicator light or displaying a message in the instrument panel, or both.
Every maintenance must be done when the display/wrench indication comes on.
The display/wrench indication will come on before reaching the maximum interval
of 16,000 km (10,000 miles), or 12 months (after the previous maintenance).
If you drive your vehicle under any of the following conditions, follow the Severe
Driving Scheduled Maintenance and replace the engine oil and ﬁlter every 8,000 km
(5,000 miles) or 6 months, whichever comes ﬁrst.
Otherwise, follow the Normal Driving Scheduled Maintenance intervals.
1. The vehicle is idled for long periods or driven at low speeds, such as with police

cars, taxis, or driver's education school car.

2. The vehicle is driven mainly unpaved road.
3. The vehicle is driven mainly on mountain roads or uphill roads.
If you are following the Severe Driving Scheduled Maintenance (8,000 km (5,000
miles) or 6 months oil replacement interval), set the vehicle status monitor manually.
Refer to the Information section in the Mazda Connect Owner's Manual. Please
contact an Authorized Mazda Dealer if necessary.

USA, Canada and Puerto Rico Residents (Normal Driving Scheduled Mainte-
nance):

Maintenance Item

Number of times, maintenance was performed.

Engine oil & ﬁlter

Spark plugs

SKYACTIV-G
2.5T

Replace every 64,000 km (40,000 miles).

Except SKY-
ACTIV-G
2.5T

Replace every 120,000 km (75,000 miles).

Air ﬁlter

Fuel lines & hoses

Hoses and tubes for emission

Drive belts

Vacuum brake booster and hose

Exhaust system and heat shields

Coolant level

Inspection and Servicing/Cleaning

Scheduled Maintenance

9-6

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Maintenance Item

Number of times, maintenance was performed.

Coolant

Replace at ﬁrst 192,000 km (120,000 miles) or 120

months; after that, every 96,000 km (60,000 miles) or

60 months.

Brake lines, hoses and connections

Brake and clutch ﬂuid level

Disc brakes

Steering operation and linkages

Front and rear suspension, ball joints and
wheel bearing axial play

Body condition inspection for
rust, corrosion and perfora-
tion

Canada

Driveshaft dust boot

Bolts and nuts on chassis and body

Cabin air ﬁlter

Replace every 48,000 km (30,000 miles) or 24 months.

Tire rotation

Rotate every 16,000 km (10,000 miles).

Tire inﬂation pressure and tire wear

Emergency ﬂat tire repair kit (if equipped)

Inspect annually.

Function of all lights

Chart symbols:

Inspect: Inspect and clean, repair, adjust, ﬁll up, or replace if necessary.

Replace

Tighten

Remarks:

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench
indicator light display.

According to state/provincial and federal regulations, failure to perform maintenance on these items
will not void your emissions warranties. However, Mazda recommends that all maintenance services
be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.

Use of FL-22 is recommended when replacing coolant. Using coolant other than FL-22 may cause
serious damage to the engine and cooling system.

Inspect a spare tire if equipped.

Check the tire repair ﬂuid expiration date every year when performing the periodic maintenance.
Replace the tire repair ﬂuid bottle with new one before the expiration date.

Inspection and Servicing/Cleaning

Scheduled Maintenance

9-7

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

USA, Canada and Puerto Rico Residents (Severe Driving Scheduled Maintenance):

Number of months or kilometers (miles), whichever comes ﬁrst.

Months

× 1000 km

× 1000 miles

Engine oil & ﬁlter

Maintenance Interval (other than engine oil
& ﬁlter replacement)

1st

2nd

3rd

4th

Chart symbols:

Replace

Remarks:

Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench
indicator light display.

Follow Maintenance Interval listed in Normal Driving Scheduled Maintenance.

Inspection and Servicing/Cleaning

Scheduled Maintenance

9-8

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Mazda 3 (2024 year). Manual in english - page 15
