Before Driving
Doors and Locks
¾ Be careful when opening/closing the
Liftgate
liftgate during strong winds. If a strong
gust blows against the liftgate, it could
WARNING
close suddenly resulting in injury.
¾ Fully open the liftgate and make sure
that it stays open. If the liftgate is only
Never allow a person to ride in the luggage
opened partially, it could slam shut by
compartment:
vibration or wind gusts resulting in
Allowing a person to ride in the luggage
injury.
compartment is dangerous. The person in
¾ When loading or unloading luggage in
the luggage compartment could be
seriously injured or killed during sudden
the luggage compartment, turn off the
braking or a collision.
engine. Otherwise, you could get burned
by the heat of the exhaust gas.
Do not drive with the liftgate open:
¾ Be careful not to apply excessive force to
Exhaust gas in the cabin of a vehicle is
the damper stay on the liftgate such as
dangerous. An open liftgate in a moving
by putting your hand on the stay.
vehicle will cause exhaust gas to be drawn
Otherwise, the damper stay may bend
into the cabin. This gas contains CO
and affect the liftgate operation.
(carbon monoxide), which is colorless,
odorless, and highly poisonous, and it can
cause loss of consciousness and death.
Moreover, an open liftgate could cause
occupants to fall out in an accident.
Do not stack or leave loaded luggage
Damper stay
unsecured in the luggage compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an accident.
In addition, do not load luggage higher
¾ Do not modify or replace the liftgate
than the seatbacks. It may affect the side or
damper stay. Consult an Authorized
rear field of view.
Mazda Dealer if a liftgate damper stay is
deformed or damaged for reasons such
CAUTION
as a collision or if there is some other
problem.
¾ Before opening the liftgate, remove any
snow and ice accumulation on it.
Opening and Closing the Liftgate
Otherwise, the liftgate could close under
Opening the liftgate with Electric
the weight of the snow and ice resulting
liftgate opener
in injury.
Unlock the doors and liftgate, then press
the electric liftgate opener on the liftgate
3-19
Before Driving
Doors and Locks
and raise the liftgate when the latch
Press the electric liftgate opener again.
releases.
To close
For the power liftgate operation, refer to
To close the liftgate from its slightly
Power Liftgate on page 3-21.
raised position, open it first by pressing
the electric liftgate opener, then close it
after waiting at least 1 second.
If the liftgate is not fully closed, the
driver is notified by a warning indicated
in the instrument cluster.
Electric liftgate
opener
If the vehicle battery is dead or there is
a malfunction in the electrical system
and the liftgate cannot be unlocked, the
liftgate can be opened by performing the
emergency procedure.
Refer to When Liftgate Cannot be
NOTE
Opened on page 7-46.
(With the advanced keyless function)
Closing the liftgate
A locked liftgate can also be opened
while the key is being carried.
Lower the liftgate slowly using the liftgate
When opening the liftgate with the doors
grip recess, then push the liftgate closed
and the liftgate locked, it may require a
using both hands.
few seconds for the liftgate latch to
Do not slam it. Pull up on the liftgate to
release after the electric liftgate opener
make sure it is secure.
is pressed.
For the power liftgate operation, refer to
The liftgate can be closed when the
Power Liftgate on page 3-21.
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the liftgate can be
opened by pressing the electric liftgate
opener. If the liftgate cannot be opened
despite doing this procedure, first push
Liftgate grip
the liftgate completely closed, then press
recess
the electric liftgate opener to fully open
the liftgate.
When the liftgate latch is released by
NOTE
pressing the electric liftgate opener, the
Confirm that the liftgate is securely closed.
liftgate raises slightly. If the liftgate is
The liftgate, move it without pressing the
not operated for a certain period of
electric liftgate opener to verify that the
time, the liftgate cannot be raised.
liftgate has not been left ajar.
To open
3-20
Before Driving
Doors and Locks
Power Liftgate*
Allowing children to operate the power
liftgate switch and the keyless entry system
The power liftgate opens/closes
is dangerous. Children are not aware of the
electrically by operating the switches in
dangers of people getting fingers and
the vehicle or the buttons on the keyless
hands caught in a moving liftgate. If
entry system transmitter.
someone's neck, head or hands get caught
in a closing door, it could result in death or
WARNING
serious injury.
Be sure to watch the power liftgate as it
CAUTION
opens or closes, and make sure that it
closes completely:
¾ When closing the power liftgate, make
Opening or closing the power liftgate while
sure there are no foreign objects around
not watching it move is dangerous.
the striker. If foreign objects are
Because of unseen obstacles and the
obstructing the striker, the liftgate may
jam-safe feature, a liftgate may not close
not close properly.
completely and, if left unnoticed, could
result in serious injury or death if an
occupant were to fall out of the vehicle.
Always be sure that the area around the
liftgate is clear before activating it.
Striker
Always confirm the safety of the area
around the power liftgate before operating
it electrically.
Not checking the area around the liftgate
for people before operating it using the
¾ Do not install accessories to the power
power liftgate switch or the button on the
liftgate other than specified accessories.
keyless entry system is dangerous. A person
Otherwise, it cannot be opened/closed
could become caught between the liftgate
automatically and could result in a
and an obstruction while it is opening
malfunction.
electrically or between the liftgate and
¾ Be careful when switching the power
vehicle while it is closing electrically,
liftgate from electrical to manual
resulting in an accident and serious injury.
operation. The power liftgate may open/
close unexpectedly depending on its
Never allow children to operate the power
position which could result in injury.
liftgate system:
*Some models.
3-21
Before Driving
Doors and Locks
NOTE
When opening the liftgate by pressing
the power liftgate button on the
Do not apply unnecessary force to the
transmitter, the liftgate can be opened
power liftgate when it is opening/closing
even when it is locked.
electrically. Unnecessary force on the
If the power liftgate button on the
liftgate may cause it to reverse direction
transmitter is pressed while the liftgate
of movement automatically. Also, it
is opening/closing electrically, the beep
could result in a malfunction.
is activated and the liftgate stops. When
The power liftgate may not open/close
pressing the power liftgate button again,
electrically if the vehicle is parked on an
the liftgate moves in the reverse
incline, or there is strong wind, or the
direction.
liftgate is laden with snow.
If a power liftgate system fuse has
Operation using each switch
blown, the liftgate cannot be opened
Operation conditions
using the power liftgate switch or the
electric liftgate opener. Use the
Opening the liftgate
emergency lever to open the liftgate.
If the vehicle has satisfied all the
Fully close the power liftgate before
following operation conditions, the power
disconnecting the vehicle battery. If the
liftgate can be opened using the power
battery is disconnected with the liftgate
function.
open, it cannot be opened or closed
All doors and the liftgate are unlocked.
automatically after the battery is
The ignition is switched OFF, or the
reconnected. If this happens, fully close
selector lever is in P with the ignition
the liftgate manually to restore the auto
switched ON.
full open/close function.
If the liftgate is snow-laden, remove the
Closing the liftgate
snow before operating the power
The ignition is switched OFF, or the
liftgate. Operating the power liftgate
selector lever is in P with the ignition
with excessive force applied to the
switched ON.
liftgate may damage the liftgate.
NOTE
Operation using the transmitter
If the vehicle moves with the selector
Press the power liftgate button for one
lever shifted to a position other than P
second or longer. The hazard warning
while the liftgate is opening/closing
lights flash twice and the liftgate opens/
electrically, the liftgate moves as
closes after the beep sounds.
follows:
Refer to Transmitter on page 3-5.
While opening electrically
NOTE
When the ignition is switched ON, the
transmitter does not operate.
3-22
Before Driving
Doors and Locks
The buzzer is activated, and the liftgate
A locked liftgate can also be opened while
moves in the reverse direction
the key is being carried.
automatically and closes. When the
selector lever is shifted to P, you can
resume the power liftgate operation
using the switches.
While closing electrically
Electric liftgate
The buzzer is activated, but the liftgate
opener
continues closing.
Operation from the driver's seat (To
open/close)
Press the power liftgate switch for about
one second or longer while the liftgate is
Operation from outside (To close)
in the fully closed/open position. The
hazard warning lights flash twice and the
Press the power liftgate close switch while
liftgate opens/closes fully after the beep
the liftgate is fully opened. The hazard
sound is heard.
warning lights flash twice and the liftgate
closes automatically after the beep sound
Power liftgate switch
is heard.
Power liftgate
close switch
Operation from outside (To open)
Press the electric liftgate opener on the
NOTE
liftgate and raise the liftgate. The hazard
If the power liftgate switch/power liftgate
warning lights flash twice and the liftgate
close switch is pressed or the electric
opens automatically after the beep sound
liftgate opener is operated while the
is heard.
liftgate is opening/closing electrically, the
(With the advanced keyless function)
beep sound is heard and the liftgate stops.
Then, it reverses when any of the switches
are pressed again.
3-23
Before Driving
Doors and Locks
Changing the power liftgate fully open
WARNING
position
The power liftgate fully-open position can
Always check the area around the power
be changed according to the height of a
liftgate before opening/closing it:
garage.
Not checking for occupants and objects
When changing the position
around the power liftgate before opening/
closing it is dangerous. The jam-safe
1. Stop the liftgate at the desired position.
equipment is designed to prevent jamming
2. Press the power liftgate close switch
in the event an obstruction is in the
for about three seconds.
liftgate's path. The system may not detect
A beep sound is activated two times to
certain objects obstructing the liftgate
indicate that the position change has
depending on the way they are positioned
been completed.
and their shape. However, if the jam-safe
NOTE
function detects an obstruction and moves
Set the desired fully-open position of the
the liftgate in the reverse direction, an
liftgate at the position where it is open
occupant in the liftgate's path could be
more than halfway. The position where it
seriously injured.
is less than halfway open cannot be set.
To reset
CAUTION
1. Open the liftgate.
Sensors are installed on both ends of the
2. Press the power liftgate close switch
power liftgate. Be careful not to allow the
for about seven seconds.
sensors to be scratched or damaged by
A beep sound is activated three times
sharp objects, otherwise the liftgate may
to indicated that the reset has been
no longer open/close automatically. In
completed.
addition, if the sensor is damaged while the
NOTE
liftgate is closing automatically, the system
After about 3 seconds have elapsed since
will stop.
the switch was pressed, a beep sound is
Sensor
activated 2 times to indicate that the
liftgate fully-open position has changed.
Continuously press the switch for about 7
seconds to complete the reset.
Jam-safe equipment
While the power liftgate is opening/
closing electrically and the system detects
a person or an object in the liftgate's path,
the liftgate will move in the reverse
direction automatically and stops.
3-24
Before Driving
Doors and Locks
NOTE
The jam-safe equipment does not activate
during easy closure operation when the
power liftgate is between the near-shut
position and fully closed position.
When the power liftgate is moving in the
open/close direction and an obstruction is
detected, the beep sound will be heard and
the liftgate moves in the reverse direction
and stops.
Liftgate easy closure
The Easy Closure system automatically
closes the liftgate completely from the
near-shut position.
This system also operates when the liftgate
is closed manually.
WARNING
When closing a liftgate, always keep hands
and fingers away from the liftgate:
Placing hands or fingers around a liftgate is
dangerous because the liftgate closes
automatically from the near-shut position,
which could cause hands and fingers to be
pinched and injured.
NOTE
If the electric liftgate opener is pressed
while the easy closure function is
operating, the liftgate can be opened.
If the liftgate is opened/closed
repeatedly in a short period of time, the
easy closure function may not operate.
Wait for about 2 seconds and then try
again.
3-25
Before Driving
Fuel and Emission
Fuel and Engine Exhaust Precautions
Fuel Requirements
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.
To achieve maximum engine performance, use the specified fuel.
Fuel
Octane Rating*1 (Anti-knock index)
Regular unleaded fuel
87 [(R+M)/2 method] or above (91 RON or above)
*1
U.S. federal law requires that octane ratings be posted on gas station pumps.
Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission control
system performance and could also cause engine knocking and serious engine damage.
CAUTION
¾ USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.
¾ This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by
volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop using gasohol of any kind if your vehicle engine
is performing poorly.
¾ Never add fuel system additives other than a Mazda genuine product, otherwise the
emission control system could be damaged. Consult an Authorized Mazda Dealer for
details.
Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".
Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.
Gasohol containing more than 10 % ethanol.
Gasoline or gasohol containing methanol.
Leaded fuel or leaded gasohol.
3-26
Before Driving
Fuel and Emission
Emission Control System
This vehicle is equipped with an emission control system (the catalytic converter is part of
this system) that enables the vehicle to comply with existing exhaust emissions
requirements.
WARNING
Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.
CAUTION
Ignoring the following precautions could cause lead to accumulate on the catalyst inside the
converter or cause the converter to get very hot. Either condition will damage the converter
and cause poor performance.
¾ USE ONLY UNLEADED FUEL.
¾ Do not drive your Mazda with any sign of engine malfunction.
¾ Do not coast with the ignition switched off.
¾ Do not descend steep grades in gear with the ignition switched off.
¾ Do not operate the engine at high idle for more than 2 minutes.
¾ Do not tamper with the emission control system. All inspections and adjustments must be
made by a qualified technician.
¾ Do not push-start or tow-start this vehicle.
NOTE
Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.
While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a
self-checking device and it operates while the engine is off.
3-27
Before Driving
Fuel and Emission
Engine Exhaust (Carbon monoxide)
WARNING
Do not drive your vehicle if you smell exhaust gas inside the vehicle:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is colorless,
odorless, and poisonous. When inhaled, it can cause loss of consciousness and death. If you
smell exhaust gas inside the vehicle, keep all windows fully open and contact an Authorized
Mazda Dealer immediately.
Do not run the engine when inside an enclosed area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust gas,
which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.
Open the windows or adjust the heating or cooling system to draw fresh air when idling the
engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and the
engine running for a long time even in an open area, exhaust gas, which contains poisonous
carbon monoxide, could enter the cabin. Loss of consciousness or even death could occur.
Clear snow from underneath and around your vehicle, particularly the tail pipe, before
starting the engine:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust pipe
could be blocked by the snow, allowing exhaust gas to enter the cabin. Because exhaust gas
contains poisonous carbon monoxide, it could cause loss of consciousness or even death to
occupants in the cabin.
3-28
Before Driving
Fuel and Emission
Fuel-Filler Lid and Cap
CAUTION
Always use only a genuine Mazda fuel-filler
WARNING
cap or an approved equivalent, available
at an Authorized Mazda Dealer. The wrong
When removing the fuel-filler cap, loosen
cap can result in a serious malfunction of
the cap slightly and wait for any hissing to
the fuel and emission control systems.
stop, then remove it:
(U.S.A. and Canada)
Fuel spray is dangerous. Fuel can burn skin
It may also cause the check engine light in
and eyes and cause illness if ingested. Fuel
the instrument cluster to illuminate.
spray is released when there is pressure in
Refueling
the fuel tank and the fuel-filler cap is
removed too quickly.
Before refueling, close all the doors,
windows, and the liftgate, and switch the
Before refueling, stop the engine, and
ignition OFF.
always keep sparks and flames away from
1.
To open the fuel-filler lid, pull the
the filler neck:
remote fuel-filler lid release.
Fuel vapor is dangerous. It could be ignited
by sparks or flames causing serious burns
and injuries.
Additionally, use of the incorrect fuel-filler
cap or not using a fuel-filler cap may result
in a fuel leak, which could result in serious
burns or death in an accident.
Do not continue refueling after the fuel
pump nozzle shuts off automatically:
Continuing to add fuel after the fuel pump
nozzle has shut off automatically is
Remote fuel-filler lid release
dangerous because overfilling the fuel tank
2.
To remove the fuel-filler cap, turn it
may cause fuel overflow or leakage. Fuel
counterclockwise.
overflow and leakage could damage the
vehicle and if the fuel ignites it could cause
a fire and explosion resulting in serious
injury or death.
3-29
Before Driving
Fuel and Emission
3.
Attach the removed cap to the inner
CAUTION
side of the fuel-filler lid.
(U.S.A. and Canada)
Fuel-filler lid
If the check fuel cap warning light
illuminates, the fuel-filler cap may not be
properly installed. If the warning light
illuminates, park your vehicle safely off the
right-of-way, remove the fuel-filler cap and
reinstall it correctly. After the cap has been
correctly installed, the fuel cap warning
Fuel-filler cap
light may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of starting
4.
Insert the refueling nozzle all the way
the engine (after four or more hours with
and begin refueling. Pull out the
the engine off) and driving the vehicle on
refueling nozzle after the refueling
city and highway roads.
stops automatically.
Continuing to drive with the check fuel cap
5.
To close the fuel-filler cap, turn it
warning light illuminated could cause the
clockwise until a click is heard.
check engine light to illuminate as well.
6.
To close, press the fuel-filler lid until it
locks securely.
3-30
Before Driving
Mirrors
2. Press the mirror switch in the
Mirrors
appropriate direction.
Before driving, adjust the inside and
Center position
outside mirrors.
Outside Mirrors
WARNING
Be sure to look over your shoulder before
changing lanes:
Changing lanes without taking into
Mirror switch
account the actual distance of the vehicle
After adjusting the mirror, lock the control
in the convex mirror is dangerous. You
by rotating the switch in the center
could have a serious accident. What you
position.
see in the convex mirror is closer than it
appears.
Folding outside mirror
Mirror type
WARNING
Flat type (driver's side)
Flat surface mirror.
Convex type (front passenger side)
Always return the outside mirrors to the
The mirror has single curvature on its
driving position before you start driving:
surface.
Driving with the outside mirrors folded in is
dangerous. Your rear view will be
Power mirror adjustment
restricted, and you could have an accident.
The ignition must be switched to ACC or
Manual folding outside mirror
ON position.
Fold the outside mirror rearward until it is
To adjust:
flush with the vehicle.
1. Rotate the mirror switch to the left or
right to choose the left or right side
mirror.
3-31
Before Driving
Mirrors
Power folding outside mirror
To return the mirror to the driving
position, rotate the switch to the center
position.
WARNING
Center position
Do not touch a power folding outside
mirror while it is moving:
Touching the power folding outside mirror
when it is moving is dangerous. Your hand
could be pinched and injured or the mirror
could be damaged.
Fold-in position
Use the outside mirror switch to set the
mirror to the on-road position:
Setting the power folding outside mirror to
Automatic folding function*
the on-road position by hand is dangerous.
The mirror will not lock in position and will
The automatic folding function operates
prevent effective rearview visibility.
when the ignition is switched to OFF.
When the outside mirror switch is in a
Only operate the power folding outside
position other than the fold-in position, the
mirror with the vehicle safely parked:
outside mirrors automatically fold in and
Operating the power folding outside mirror
out when the doors are locked and
while the vehicle is moving is dangerous.
unlocked.
Wind blast on the mirror will cause them to
Also, when the ignition is switched ON or
collapse and you will be unable to return it
the engine is started, the outside mirrors
to the on-road position, preventing
fold out automatically.
rearview visibility.
NOTE
The ignition must be switched to ACC or
The outside mirrors may not fold in and
ON position.
out automatically under cold weather
To fold, rotate the outside mirror switch.
conditions.
If the outside mirrors do not fold in and
out automatically, remove any ice or snow,
and then operate the outside mirror switch
to fold the outside mirrors in or out.
Canceling the automatic folding
function
To cancel the automatic folding function,
carry out the following procedure using
the master control switches.
1. Switch the ignition ON.
3-32
*Some models.
Before Driving
Mirrors
2. If the power window lock switch is in
Rearview Mirror
the unlock position, switch it to the
lock position.
WARNING
3. Press and hold the front passenger's
power window switch and rear left/
right power window switches on the
Do not stack cargo or objects higher than
driver's door at the same time for 3
the seatbacks:
seconds or longer.
Cargo stacked higher than the seatbacks is
dangerous. It can block your view in the
NOTE
rearview mirror, which might cause you to
The automatic folding function cannot
hit another car when changing lanes.
be canceled if the procedure is not
Rearview mirror adjustment
completed within the specified times, or
the procedure is changed along the way.
Before driving, adjust the rearview mirror
To redo the procedure, first switch the
to center on the scene through the rear
ignition off and proceed from the
window.
beginning.
If you are unable to cancel the function
despite doing the cancellation
procedure, consult an Authorized Mazda
Dealer.
Restoring the automatic folding
function
With the automatic folding function in the
canceled state, repeat the previous
NOTE
procedure for canceling the function and it
For the manual day/night mirror, perform
will be restored.
the adjustment with the day/night lever in
the day position.
NOTE
If you are unable to restore the function
despite carrying out the restore procedure,
consult an Authorized Mazda Dealer.
Engine-off outside mirror operation*
The outside mirrors can be operated for
about 40 seconds after the ignition is
switched from ON to off.
*Some models.
3-33
Before Driving
Mirrors
Reducing glare from headlights
To reactivate the auto-dimming function,
press the ON/OFF button (
). The
Manual day/night mirror
indicator light will illuminate.
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.
Indicator light
Day/Night lever
ON/OFF button
Night
Day
NOTE
Auto-dimming mirror
Do not use glass cleaner or suspend
The auto-dimming mirror automatically
objects on or around the light sensor.
reduces the glare of headlights from
Otherwise, light sensor sensitivity will
vehicles at the rear when the ignition is
be affected and may not operate
switched ON.
normally.
(With Homelink wireless control
(With Homelink wireless control
system)
system)
(Type A)
(Type A)
Press the OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto-dimming function,
press the ON button (
). The indicator
Light sensor
light will illuminate.
Indicator light
OFF button
ON button
(Type B)
Press the ON/OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
3-34
Before Driving
Mirrors
(Type B)
Light sensor
(Without Homelink wireless control
system)
Light sensor
(With Homelink wireless control
system)
For information regarding the 3 buttons
(Type A
,
,
/Type B
,
,
)
on the auto-dimming mirror.
Refer to HomeLink Wireless Control
System on page 4-87.
The auto-dimming function is canceled
when the ignition is switched ON and
the shift/selector lever is in the R
position.
3-35
Before Driving
Windows
Power Windows
The windows can be opened/closed by operating the power window switches.
WARNING
Make sure the opening is clear before closing a window:
Closing a power window is dangerous. A person's hands, head, or even neck could be caught
by the window and result in serious injury or even death. This warning applies especially to
children.
Never allow children to play with power window switches:
Power window switches that are not locked with the power window lock switch would allow
children to operate power windows unintentionally, which could result in serious injury if a
child's hands, head or neck becomes caught by the window.
Make sure nothing blocks the window just before it reaches the fully closed position or while
fully holding up the power window switch:
Blocking the power window just before it reaches the fully closed position or while fully
holding up the power window switch is dangerous.
In this case, the jam-safe function cannot prevent the window from closing all the way. If
fingers are caught, serious injuries could occur.
NOTE
When driving with only 1 of the rear windows open, your ears might experience a
resonating sound. However, this does not indicate a problem. The sound can be reduced by
slightly opening a front window or by changing the size of the rear window opening.
Opening/Closing Windows
The window opens while the switch is pressed and it closes while the switch is pulled up
with the ignition switched ON. Do not open or close 3 or more windows at the same time.
3-36
Before Driving
Windows
The front passenger's side and rear windows can be opened/closed when the power window
lock switch on the driver's door is in the unlock position. Keep this switch in the locked
position while children are in the vehicle.
Master control switches
Front passenger's
Locked position
Power window
window switch
lock switch
Rear window switches
Close
Driver's
Open
Close
window
Unlocked position
Left rear
Open
window
Front passenger's
window
Right rear window
NOTE
A power window may no longer open/close if you continue to press the switch after fully
opening/closing the power window. If the power window does not open/close, wait a
moment and then operate the switch again.
The passenger windows may be opened or closed using the master control switches on the
driver's door.
The power window can be operated for about 40 seconds after the ignition is switched
from ON to ACC or off with all doors closed. If any door is opened, the power window
will stop operating.
For engine-off operation of the power window, the switch must be held up firmly
throughout window closure because the auto-closing function will be inoperable.
When the power window lock switch is in the locked position, the light on each power
window switch, except for the driver's power window switch, turns off. The light may be
difficult to see depending on the surrounding brightness.
Auto-opening/Closing
release. The window will fully close
automatically.
To fully open the window automatically,
press the switch completely down, then
To stop the window partway, pull or press
release. The window will fully open
the switch in the opposite direction and
automatically.
then release it.
To fully close the window automatically,
pull the switch completely up, then
NOTE
Power window system initialization
procedure
3-37
Before Driving
Windows
If the battery was disconnected during
In the event the jam-safe function
vehicle maintenance, or for other reasons
activates and the power window cannot
(such as a switch continues to be operated
be closed automatically, pull and hold
after the window is fully open/closed), the
the switch and the window will close.
window will not fully open and close
The jam-safe window function does not
automatically.
operate until the system has been reset.
The power window auto function will only
Remote Power Window Operation
resume on a power window that has been
reset.
All power windows can be opened from
1. Switch the ignition ON.
outside the vehicle after the doors are
2. Make sure that the power window lock
closed.
switch located on the driver's door is
The power windows can be operated
not depressed.
remotely when the power window lock
3. Press the switch and fully open the
switch on the driver's door is in the lock or
window.
unlocked position.
4. Pull up the switch to fully close the
Remote power window operation is
window and continue holding the
activated under the following conditions.
switch for about 2 seconds after the
All the doors and liftgate are closed.
window fully closed.
The ignition is switched OFF.
5. Make sure that the power windows
operate correctly using the door
NOTE
switches.
The power windows cannot be opened
Jam-safe Window
from the outside of the vehicle if the power
window initialization has not been
If foreign matter is detected between the
completed.
window and the window frame while the
window is closing automatically (refer to
Opening
Auto-opening/Closing on page 3-37), the
The windows can be opened for
window stops closing and automatically
ventilating the cabin before getting in the
opens partway.
vehicle.
NOTE
Press the unlock button on the key quickly
and briefly 3 times and then immediately
The jam-safe function may operate
afterwards, press and hold the unlock
under the following conditions:
button to open the windows.
A strong impact is detected while the
window is closing automatically.
Window is closing automatically in
very low temperatures.
To stop the windows from opening,
release the button. If the operation is
performed from the beginning again, the
windows open.
3-38
Before Driving
Windows
Moonroof*
CAUTION
The moonroof can be opened or closed
¾ Do not sit on or put heavy items on the
when operating the overhead tilt/slide
area where the moonroof opens and
switch at the front seats.
closes. Otherwise, the moonroof could be
damaged.
WARNING
¾ Do not open or close the moonroof
forcefully during freezing temperatures
Do not let passengers stand up or extend
or snowfall. Otherwise, the moonroof
part of the body through the open
could be damaged.
moonroof while the vehicle is moving:
¾ The sunshade does not tilt. To avoid
Extending the head, arms, or other parts of
damaging the sunshade, do not push it
the body through the moonroof is
up.
dangerous. The head or arms could hit
¾ Do not close the sunshade while the
something while the vehicle is moving. This
moonroof is opening. Trying to force the
could cause serious injury or death.
sunshade closed could damage it.
Never allow children to play with the tilt/
Tilt/Slide Operation
slide switch:
The moonroof can be opened or closed
The tilt/slide switch would allow children to
electrically only when the ignition is
operate the moonroof unintentionally,
switched ON.
which could result in serious injury if a
Before leaving the vehicle or washing
child's hands, head or neck becomes
caught by the moonroof.
your Mazda, make sure the moonroof is
completely closed so that water does not
Make sure the opening is clear before
get inside the cabin area.
closing the moonroof:
After washing your Mazda or after it
A closing moonroof is dangerous. The
rains, wipe the water off the moonroof
hands, head, or even neck of a person,
before operating it to avoid water
especially a child, could be caught in it as it
penetration which could cause rust and
closes, causing serious injury or even death.
water damage to your headliner.
Tilt/Slide switch
Make sure nothing blocks the moonroof
just before it reaches the fully closed
position:
Blocking the moonroof just before it
reaches the closed position is dangerous.
In this case, the jam-safe function cannot
prevent the moonroof from closing. If
fingers are caught, serious injuries could
occur.
*Some models.
3-39
Before Driving
Windows
Tilt Operation
the moonroof and then do a slide
operation.
The rear of the moonroof can be tilted
open to provide more ventilation.
Open
To fully tilt automatically, momentarily
press the tilt/slide switch.
To fully close automatically, momentarily
press the tilt/slide switch in the forward
direction.
To stop tilting partway, press the tilt/slide
Close
switch.
When the moonroof is already slid open
NOTE
If the moonroof does not operate normally,
and you want to tilt it open, first close the
do the following procedure:
moonroof and then do a tilt operation.
1. Switch the ignition ON.
2. Press the tilt switch, to partially tilt
open the rear of the moonroof.
3. Repeat Step 2. The rear of the
moonroof tilts open to the fully open
position, then closes a little.
If the reset procedure is performed while
Tilt up
the moonroof is in the slide position
Close (Tilt down)
(partially open) it will close before the
rear tilt opens.
Slide Operation
Jam-safe Moonroof
To fully open automatically, momentarily
press the tilt/slide switch in the backward
If a person's hands, head or an object
direction.
blocks the moonroof while it is closing,
To fully close automatically, momentarily
the moonroof will stop and move in the
press the tilt/slide switch in the forward
open direction.
direction.
NOTE
To stop sliding partway, press the tilt/slide
switch.
The jam-safe function may operate
When the moonroof is already tilted open
under the following conditions:
and you want to slide it open, first close
A strong impact is detected while the
moonroof is closing automatically.
The moonroof is closing automatically
during very low temperatures.
3-40
Before Driving
Windows
In the event the jam-safe function
activates and the moonroof cannot be
closed automatically, press the tilt/slide
switch and the moonroof will close.
The jam-safe moonroof function does
not operate until the system has been
reset.
Sunshade
The sunshade can be opened and closed by
hand.
The sunshade opens at the same time as
the moonroof slides open, but it must be
closed by hand.
Sunshade
3-41
Before Driving
Security System
Modification and Add-On
Immobilizer System
Equipment
The immobilizer system allows the engine
to start only with a key the system
Mazda cannot guarantee the immobilizer
recognizes.
and the theft-deterrent systems' operation
if the system has been modified or if any
If someone attempts to start the engine
add-on equipment has been installed.
with an unrecognized key, the engine will
not start, thereby helping to prevent
CAUTION
vehicle theft.
If you have a problem with the
To avoid damage to the vehicle, do not
immobilizer system or the key, consult an
modify the system or install any add-on
Authorized Mazda Dealer.
equipment to the immobilizer and the
theft-deterrent systems or the vehicle.
CAUTION
¾ Radio equipment like this is governed by
laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
¾ To avoid damage to the key, do not:
¾ Drop the key.
¾ Get the key wet.
¾ Expose the key to any kind of magnetic
field.
¾ Expose the key to high temperatures
on places such as the dashboard or
hood, under direct sunlight.
¾ If the engine does not start with the
correct key, and the security indicator
light keeps illuminating or flashing, the
system may have a malfunction. Consult
an Authorized Mazda Dealer.
3-42
Before Driving
Security System
NOTE
The security indicator light in the
instrument cluster flashes every 2 seconds
The keys carry a unique electronic code.
until the system is disarmed.
For this reason, and to assure your
safety, obtaining a replacement key
requires some waiting time. They are
only available through an Authorized
Mazda Dealer.
Always keep a spare key in case one is
Disarming
lost. If a key is lost, consult an
The system is disarmed when the ignition
Authorized Mazda Dealer as soon as
is switched ON with the correct
possible.
programmed key. The security indicator
If you lose a key, an Authorized Mazda
light illuminates for about 3 seconds and
Dealer, will reset the electronic codes of
then turns off. If the engine does not start
your remaining keys and immobilizer
with the correct key, and the security
system. Bring all the remaining keys to
indicator light remains illuminated or
the Authorized Mazda Dealer to reset.
flashing, try the following:
Starting the vehicle with a key that has
Make sure the key is within the
not been reset is not possible.
operational range for signal transmission.
Operation
Switch the ignition off, and then restart the
engine. If the engine does not start after 3
NOTE
or more tries, contact an Authorized
Mazda Dealer.
The engine may not start and security
indicator light may illuminate or flash if
NOTE
the key is placed in an area where it is
If the security indicator light flashes
difficult for the system to detect the
continuously while you are driving, do
signal, such as on the dashboard or in
not shut off the engine. Go to an
the glove compartment. Move the key to
Authorized Mazda Dealer, and have it
a location within the signal range,
checked. If the engine is shut off while
switch the ignition off, and then restart
the indicator light is flashing, you will
the engine.
not be able to restart it.
Signals from a TV or radio station, or
Because the electronic codes are reset
from a transceiver or mobile telephone
when the immobilizer system is repaired,
could interfere with your immobilizer
the keys are needed. Make sure to bring
system. If you are using the proper key
all the keys to an Authorized Mazda
and the engine fails to start, check the
Dealer, so that they can be programmed.
security indicator light.
Arming
The system is armed when the ignition is
switched from ON to off.
3-43
Before Driving
Security System
NOTE
Theft-Deterrent System*
The liftgate does not open while the
If the theft-deterrent system detects an
theft-deterrent system is operating.
inappropriate entry into the vehicle, which
For vehicles equipped with the power
could result in the vehicle or its contents
liftgate, the liftgate can be opened even
being stolen, the alarm alerts the
while the theft-deterrent system is
surrounding area of an abnormality by
operating by pressing the power liftgate
sounding the horn and flashing the hazard
button on the transmitter or the electric
warning lights.
liftgate opener switch while carrying the
key.
The system will not function unless it's
If the battery goes dead while the
properly armed. So when you leave the
theft-deterrent system is armed, the horn
vehicle, follow the arming procedure
will activate and the hazard warning
correctly.
lights will flash when the battery is
charged or replaced.
Operation
How to Arm the System
System triggering conditions
The horn sounds intermittently and the
1.
Close the windows and the moonroof*
hazard warning lights flash for about 30
securely.
seconds when the system is triggered by
2.
Switch the ignition OFF.
any one of the following:
3.
Make sure the hood, the doors, and the
liftgate are closed.
Unlocking a door with the auxiliary key,
4.
Press the lock button on the transmitter
door lock switch, or an inside door-lock
or lock the driver's door from the
knob.
outside with the auxiliary key.
Forcing open a door, the hood or the
The hazard warning lights will flash
liftgate.
once.
Opening the hood by operating the hood
The following method will also arm
release handle.
the theft-deterrent system:
Switching the ignition ON without using
Press the door-lock switch “
” while
the push button start.
any door is open and then close all of
If the system is triggered again, the lights
the doors.
and horn will activate until the driver's
(With the advanced keyless function)
door or the liftgate is unlocked with the
Press a request switch.
transmitter.
(With the advanced keyless function)
The security indicator light in the
The lights and horn can also be
instrument cluster flashes twice per
deactivated by pressing the request switch
second for 20 seconds.
on a door.
3-44
*Some models.
Before Driving
Security System
5. After 20 seconds, the system is fully
NOTE
armed.
When the doors are unlocked by pressing
the unlock button on the transmitter while
NOTE
the theft-deterrent system is turned off, the
The theft-deterrent system can also be
hazard warning lights will flash twice to
armed by activating the auto relock
indicate that the system is turned off.
function with all the doors, the liftgate
To Stop the Alarm
and the hood closed.
Refer to Transmitter on page 3-5.
A triggered alarm can be turned off using
The system will disarm if one of the
any one of the following methods:
following operations takes place within
Pressing the unlock button on the
20 seconds after pressing the lock
transmitter.
button:
Starting the engine with the push button
Unlocking any door.
start.
Opening any door.
(With the advanced keyless function)
Opening the hood.
Pressing a request switch on the
Switching the ignition ON.
doors.
To rearm the system, do the arming
Pressing the electric liftgate opener
procedure again.
while the key is being carried.
When the doors are locked by pressing
Pressing the power liftgate button on
the lock button on the transmitter or
the transmitter.
using the auxiliary key while the
The hazard warning lights will flash twice.
theft-deterrent system is armed, the
hazard warning lights will flash once to
indicate that the system is armed.
To Turn Off an Armed System
An armed system can be turned off using
any one of the following methods:
Pressing the unlock button on the
transmitter.
Starting the engine with the push button
start.
(With the advanced keyless function)
Pressing a request switch on the
doors.
The hazard warning lights will flash twice.
3-45
Before Driving
Driving Tips
Break-In Period
Saving Fuel and Protection
No special break-in is necessary, but a few
of the Environment
precautions in the first 1,000 km (600
How you operate your Mazda determines
miles) may add to the performance,
how far it will travel on a tank of fuel. Use
economy, and life of the vehicle.
these suggestions to help save fuel and
Do not race the engine.
reduce CO2.
Do not maintain one constant speed,
Avoid long warm-ups. Once the engine
either slow or fast, for a long period of
runs smoothly, begin driving.
time.
Avoid fast starts.
Do not drive constantly at full-throttle or
Drive at lower speeds.
high engine rpm for extended periods of
Anticipate when to apply the brakes
time.
(avoid sudden braking).
Avoid unnecessary hard stops.
Follow the maintenance schedule (page
Avoid full-throttle starts.
6-4) and have an Authorized Mazda
Do not tow a trailer.
Dealer perform inspections and
servicing.
Use the air conditioner only when
necessary.
Slow down on rough roads.
Keep the tires properly inflated.
Do not carry unnecessary weight.
Do not rest your foot on the brake pedal
while driving.
Keep the wheels in correct alignment.
Keep windows closed at high speeds.
Slow down when driving in crosswinds
and headwinds.
WARNING
Never stop the engine when going down a
hill:
Stopping the engine when going down a
hill is dangerous. This causes the loss of
power steering and power brake control,
and may cause damage to the drivetrain.
Any loss of steering or braking control
could cause an accident.
3-46
Before Driving
Driving Tips
Avoid sudden braking and sudden
Hazardous Driving
maneuvering.
Do not pump the brakes. Continue to
WARNING
press down on the brake pedal.
Refer to Antilock Brake System (ABS)
on page 4-106.
Be extremely careful if it is necessary to
If you get stuck, select a lower gear and
downshift on slippery surfaces:
accelerate slowly. Do not spin the front
Downshifting into lower gear while driving
wheels.
on slippery surfaces is dangerous. The
For more traction in starting on slippery
sudden change in tire speed could cause
surfaces such as ice or packed snow, use
the tires to skid. This could lead to loss of
sand, rock salt, chains, carpeting, or
vehicle control and an accident.
other nonslip material under the front
wheels.
Avoid sharp turns, excessive speed and
abrupt maneuvers when driving this
NOTE
vehicle:
Use snow chains only on the front wheels.
Sharp turns, excessive speed and abrupt
maneuvering of this vehicle are dangerous
as it could result in the increased risk of loss
of vehicle control, vehicle roll-over,
personal injury or death.
This vehicle has a higher center of gravity.
Vehicles with a higher center of gravity
such as utility vehicles handle differently
than vehicles with a lower center of gravity.
Utility vehicles are not designed for
cornering at high speeds any more than
low profile sports cars are designed to
perform satisfactorily under off-road
conditions.
In addition, utility vehicles have a
significantly higher rollover rate than other
types of vehicles.
In a rollover crash, an unbelted person is
significantly more likely to die than a
person wearing a seat belt.
When driving on ice or in water, snow,
mud, sand, or similar hazards:
Be cautious and allow extra distance for
braking.
3-47
Before Driving
Driving Tips
Floor Mat
Rocking the Vehicle
We recommend the use of Genuine
Mazda floor mats.
WARNING
WARNING
Do not spin the wheels at more than 56
km/h (35 mph), and do not allow anyone
Make sure the floor mats are hooked on the
to stand behind a wheel when pushing the
retention pins to prevent them from
vehicle:
bunching up under the foot pedals:
When the vehicle is stuck, spinning the
Using a floor mat that is not secured is
wheels at high speed is dangerous. The
dangerous as it will interfere with the
spinning tire could overheat and explode.
accelerator and brake pedal operation,
This could cause serious injuries.
which could result in an accident.
CAUTION
Do not install two floor mats, one on top of
the other, on the driver's side:
Too much rocking may cause engine
Installing two floor mats, one on top of the
overheating, transaxle failure, and tire
other, on the driver's side is dangerous as
damage.
the retention pins can only keep one floor
mat from sliding forward.
If you must rock the vehicle to free it from
Loose floor mat(s) will interfere with the
snow, sand or mud, depress the accelerator
foot pedals and could result in an accident.
slightly and slowly move the selector lever
If using an all-weather mat for winter use
from D to R position.
always remove the original floor mat.
When setting a floor mat, position the
floor mat so that its grommets are inserted
over the pointed end of the retention posts.
3-48
Before Driving
Driving Tips
Drive slowly. Braking performance can
Winter Driving
be adversely affected if snow or ice
Carry emergency gear, including tire
adheres to the brake components. If this
chains, window scraper, flares, a small
situation occurs, drive the vehicle
shovel, jumper cables, and a small bag of
slowly, releasing the accelerator pedal
sand or salt.
and lightly applying the brakes several
Ask an Authorized Mazda Dealer to check
times until the brake performance
the following:
returns to normal.
Have the proper ratio of antifreeze in the
Snow Tires
radiator.
Use snow tires on all 4 wheels
Refer to Engine Coolant on page 6-22.
Inspect the battery and its cables. Cold
Do not go faster than 120 km/h (75 mph)
reduces battery capacity.
while driving with snow tires. Inflate snow
Use an engine oil appropriate for the
tires 30 kPa (0.3 kgf/cm2, 4.3 psi) more
lowest ambient temperatures that the
than recommended on the tire pressure
vehicle will be driven in (page 6-20).
label (driver's door frame), but never more
Inspect the ignition system for damage
than the maximum cold-tire pressure
and loose connections.
shown on the tires.
Use washer fluid made with
antifreeze―but do not use engine
Mexico
coolant antifreeze for washer fluid (page
6-24).
The vehicle is originally equipped with
summer tires designed for optimum
NOTE
traction on wet and dry roads. If your
Remove snow before driving. Snow left
vehicle is to be used on snow and ice
on the windshield is dangerous as it
covered roads, Mazda recommends that
could obstruct vision.
you replace the tires originally equipped
Do not apply excessive force to a
on your vehicle with snow tires during the
window scraper when removing ice or
winter months.
frozen snow on the mirror glass and
Except Mexico
windshield.
Never use warm or hot water for
The vehicle is originally equipped with all
season radials designed to be used all year
removing snow or ice from windows and
mirrors as it could result in the glass
around. In some extreme climates you
cracking.
may find it necessary to replace them with
snow tires during the winter months to
further improve traction on snow and ice
covered roads.
3-49
Before Driving
Driving Tips
¾ Chains may scratch or chip aluminum
WARNING
wheels.
Use only the same size and type tires (snow,
NOTE
radial, or non-radial) on all 4 wheels:
The tire pressure monitoring system may
Using tires different in size or type is
not function correctly when using tire
dangerous. Your vehicle's handling could
chains.
be greatly affected and result in an
accident.
Install the chains on the front tires only.
Do not use chains on the rear tires.
Please consult an Authorized Mazda
CAUTION
Dealer.
Check local regulations before using
Installing the chains
studded tires.
1.
Secure the chains on the front tires as
tightly as possible.
NOTE
Always follow the chain
The tire pressure monitoring system may
manufacturer's instructions.
not function correctly when using tires
2.
Retighten the chains after driving
with steel wire reinforcement in the
1/2―1 km (1/4―1/2 mile).
sidewalls (page 4-277).
Tire Chains
Check local regulations before using tire
chains.
CAUTION
¾ Chains may affect handling.
¾ Do not go faster than 50 km/h (30 mph)
or the chain manufacturer's
recommended limit, whichever is lower.
¾ Drive carefully and avoid bumps, holes,
and sharp turns.
¾ Avoid locked-wheel braking.
¾ Do not use chains on a temporary spare
tire; it may result in damage to the
vehicle and to the tire.
¾ Do not use chains on roads that are free
of snow or ice. The tires and chains could
be damaged.
3-50















Content      ..     2      3      4      5     ..
