Before Driving

Electric Vehicles



Use of the charge connector lock is

^ When the charging is completed

prohibited at a public charging

using the Charge When Connected

station.

setting, the charging timer schedule

is restored.

Functions using a Smartphone

Charging Schedule

You can check the remaining high

voltage battery power, operate the

Selects desired vehicle charging days

charging, and operate the air

and times.

conditioner remotely by using a

Function

Available setting changes

Smartphone.

Please refer to local Mazda website for

1 ----

more Connected Service information.

2 ----

▼ Charging Settings

3 ----

Enable, Disa-

4 ----

Edit, Delete^*2

How to set up the charging

ble^*1

5 ----

1. Select Settings from the home

screen on Mazda Connect.

6 ----

2. Select EV Settings from the setting

7 ----

screen.

3. Select the setting item you want to

^*1

If a list selected using the cursor has been

change from the displayed content.

set, the item can be Enable or Disable.

^*2

Settings can be Edit/Delete by sliding a list

selected using the cursor to the right.

Charge When Connected

NOTE

Cancels charging schedule to allow im-

mediate charging.

^ The charging timer does not work

immediately after the lead-acid

Available setting changes

battery is removed or installed, or

Enable, Disable

when no GPS signal has been

received. When charging without

NOTE

receiving GPS, quick charging begins.

When GPS signals are received, the

^ The charging timer can also be

charging timer becomes operational.

canceled on the screen displayed on

the center display when the power

switch is switched OFF.

3-21

Before Driving

Electric Vehicles



Immediately after switching to

surrounding environment. Check the actual

daylight savings, charging may occur

remaining distance-to-full discharge.

at the charging timer time set before

If you change the distance unit after setting

the switch to daylight savings until

the Estimated Range, the Estimated Range

the power switch is switched ON.

will be calculated in the unit after the

change. (If you change the units to miles

after setting the estimated range to 100 km,

Edit

the charge distance will be for 60 miles.)

Available setting

Function

NOTE

changes

^ A charging day is set using Repeat

Start Time

Time

If 1 repeat day is set, charging is

Select the desired charging

(10-minute inter-

repeated every week on the set day

start time.

vals)

of the week.

End Time

Time

Depending on the set days of the

Select the desired charging

(10-minute inter-

week, the Repeat indication is

end time.

vals)

displayed as Weekdays, Weekends,

Repeat

and Daily. Otherwise, it is displayed

Monday ― Sun-

Select the day(s) of the

as Custom.

day

week to repeat.

Setting example

According to Bat-

Charge Limit

Available setting

Function

tery Charge Level,

changes

Select the desired charge

According to Esti-

limit method.

Start Time

21 : 00

mated Range

End Time

6 : 00

Battery Charge Level^*1

100% ― 10%

Repeat

Friday

Select the desired maxi-

(10 levels)

mum charge level.

According to Bat-

Charge Limit

tery Charge Level

Estimated Range^*2

In 10 km incre-

Select the desired estimat-

Battery Charge Level

80 %

ments

ed range.

In this case, charging is done every

^*1

Can be changed when According to Battery

week from Friday at 21 : 00 hours to

Charge Level is selected for Charge Limit.

Saturday at 6:00 hours. However, if

Use when you want to charge only the

the Battery Charge Level reaches

amount of charging you need. This helps you

80%, the charging is stopped even if

save power and prevent high voltage battery

it is before the End Time.

deterioration.

^ No day is set using Repeat

^*2

Can be changed when According to

If no Repeat day is designated,

Estimated Range is selected for Charge

charging is done only 1 time at the

Limit.

set hours.

Use when you want to charge according to

your planned driving distance.

The distance-to-full discharge changes

depending on the driving conditions and

3-22

Before Driving

Electric Vehicles

Setting example (if settings below are

In this case, charging is done from

made at 13 : 00 hours)

the next day at 1 : 00 hours to 8 : 00

hours. However, if the Battery

Available setting

Function

Charge Level reaches 100% is

changes

reached, the charging is stopped

Start Time

12 : 00

even if it is before the End Time.

End Time

18 : 00

Repeat

Once

Charge Limit for AC Charging

According to Esti-

Charge Limit

Sets the charge limit when using an AC

mated Range

charger.

Estimated Range

50 km

Available setting changes

In this case, when the charge

100% ― 10% (10 levels)

connector is connected, charging

starts immediately for charging to

18 : 00 hours on the same day.

NOTE

However, if a charging amount

For normal charge, set the maximum

allowing a 50 km trip is reached, the

charge limit of the high voltage battery.

charging is stopped even if it is

Set the Battery Charge Level of the

before the end time.

charging timer for each charging timer

setting.

Setting example (if settings below are

made at 13 : 00 hours)

Charge Limit for DC Fast Charging

Available setting

Function

changes

Sets the charge limit when using a DC

Fast charger.

Start Time

1 : 00

End Time

8 : 00

Available setting changes

Repeat

Once

100% ― 10% (10 levels)

According to Bat-

Charge Limit

tery Charge Level

Charge Connector Lock

Battery Charge Level

100 %

Configures when the charge connector

is locked.

Available setting changes

Locked When Charging

Unlocks connector when charging is complete

or vehicle is unlocked.

Locked When Connected

Unlocks connector only when vehicle is un-

locked.

3-23

Before Driving

Electric Vehicles

Available setting changes

Off

Charge connector remains unlocked at all

times.

High Voltage Battery Heater

Configures the high voltage battery

heater operation.

Available setting changes

Automatic, Off

3-24

Before Driving

Keys

¾ To avoid damage to the key

Keys

(transmitter), DO NOT:

▼ Keys

¾ Drop the key (transmitter).

¾ Get the key (transmitter) wet.

WARNING

¾ Disassemble the key (transmitter).

¾ Expose the key (transmitter) to

Do not leave the key in your vehicle

high temperatures on places such

as the dashboard, under direct

with children and keep them in a

place where your children will not

sunlight.

¾ Expose the key (transmitter) to any

find or play with them:

Leaving children in a vehicle with the

kind of magnetic field.

key is dangerous. This could result in

¾ Place heavy objects on the key

someone being badly injured or even

(transmitter).

killed. Children may find these keys to

¾ Put the key (transmitter) in an

be an interesting toy to play with and

ultrasonic cleaner.

could cause the power windows or

¾ Put any magnetized objects close

other controls to operate, or even

to the key (transmitter).

make the vehicle move.

NOTE

CAUTION

The driver must carry the key

(transmitter) to ensure the system

¾ Because the key (transmitter) uses

low-intensity radio waves, it may not

functions properly.

function correctly under the

Transmitter

following conditions:

¾ The key (transmitter) is carried with

communication devices such as

cellular phones.

¾ The key (transmitter) contacts or is

covered by a metal object.

¾ The key (transmitter) is near

electronic devices such as personal

computers.

¾ Non-Mazda genuine electronic

equipment is installed in the

vehicle.

¾ There is equipment which

discharges radio waves near the

vehicle.

¾ The key (transmitter) may consume

battery power excessively if it

receives high-intensity radio waves.

Do not place the key (transmitter)

near electronic devices such as

televisions or personal computers.

3-25

Before Driving

Keys

1. Transmitter (page 3-28)

2. Insert the tabs of the lower cover

into the slots of the transmitter and

install the lower cover.

Auxiliary key

There is a removable auxiliary key

inside the transmitter.

Removing the auxiliary key

1. Remove the lower cover while

sliding the knob in the direction of

the arrow.

Key code number plate

A code number is stamped on the

plate attached to the key set; detach

this plate and store it in a safe place

(not in the vehicle) for use if you need

to make a replacement key (auxiliary

key).

Also write down the code number and

2. Remove the auxiliary key.

keep it in a separate safe and

convenient place, but not in the

vehicle.

If your key (auxiliary key) is lost, consult

an Authorized Mazda Dealer and have

your code number ready.

1. Key code number plate

Installing the auxiliary key

1. Install the auxiliary key as the

illustration.

3-26

Before Driving

Keys

Changes or modifications not expressly

Keyless Entry System

approved by the party responsible for

compliance could void the user's

▼ Keyless Entry System

authority to operate the equipment.

This system uses the key buttons to

remotely lock and unlock the doors,

NOTE

liftgate, and charge lid.

^ The keyless entry system operation

The system can start the EV system

may vary due to local conditions.

without having to take the key out of

^ The keyless entry system is fully

your purse or pocket.

operational when the power switch

It can also help you signal for attention

is switched off. The system does not

or help.

operate if the power switch is

switched to any position other than

System malfunctions or warnings are

off.

indicated by the following warning

^ If the key does not operate when

lights or beeps.

pressing a button or the operational

Check the displayed message for more

range becomes too small, the battery

information and, if necessary, have the

may be weak. To install a new

vehicle inspected at an Authorized

battery, refer to Key Battery

Mazda Dealer, according to the

Replacement (page 6-21).

indication.

^ Battery life is about 1 year. Replace

^ KEY Warning Indication/Warning

the battery with a new one if the

Light (Red)

messages are displayed in the

Refer to KEY Warning Indication/

instrument cluster. Replacing the

Warning Light (Red) on page 7-28.

battery about once a year is

^ Power switch Not Switched Off

recommended because the KEY

(STOP) Warning Beep

warning indication may not display

Refer to Power switch Not Switched

depending on the rate of battery

Off (STOP) Warning Beep on page

depletion.

7-37.

^ Additional keys can be obtained at

^ Key Removed from Vehicle Warning

an Authorized Mazda Dealer. Up to

Beep

6 keys can be used with the keyless

Refer to Key Removed from Vehicle

functions per vehicle. Bring all keys

Warning Beep on page 7-37.

to an Authorized Mazda Dealer

when additional keys are required.

If you have a problem with the key,

consult an Authorized Mazda Dealer.

If your key is lost or stolen, consult an

Authorized Mazda Dealer as soon as

possible for a replacement and to

make the lost or stolen key inoperative.

CAUTION

Radio equipment like this is governed

by laws in the United States.

3-27

Before Driving

Keys

▼ Transmitter

(With the advanced keyless function)

A beep sound will be heard once.

To confirm that all the doors, liftgate,

and charge lid have been locked, press

the lock button again within 5

seconds. If they are closed and locked,

the horn will sound.

NOTE

^ When any door or the liftgate is open

1. Operation indicator light

and the lock button is pressed, the

2. Lock button (

)

closed doors can be locked. After

3. Unlock button (

)

that, any other open door or the

liftgate can be locked by closing

4. Panic button (

)

them.

NOTE

^ Confirm that all the doors, liftgate,

and charge lid are locked visually or

^ The headlights turn on/off by

audibly by use of the double click.

operating the transmitter. Refer to

^ Make sure all the doors, liftgate, and

Leaving Home Light on page 4-37.

charge lid are locked after pressing

 (With the advanced keyless

the button.

function)

A beep sound can be heard for

Unlock button

confirmation when the doors,

To unlock the driver's door and the

liftgate, and charge lid are locked/

charge lid, press the unlock button and

unlocked using the key. If you prefer,

the hazard warning lights will flash

the beep sound can be turned off.

twice.

The volume of the beep sound can

(With the advanced keyless function)

also be changed.

A beep sound will be heard twice.

Refer to the Settings section in the

Mazda Connect Owner's Manual.

To unlock the other doors and liftgate,

The operation indicator light flashes

press the unlock button again within 5

when the buttons are pressed.

seconds and two more beep sounds

will be heard.

Lock button

To lock the doors, liftgate, and charge

lid, press the lock button and the

hazard warning lights will flash once.

3-28

Before Driving

Keys

NOTE

^ The hazard warning lights flash.

^ The system can be set to unlock all

(Turning off the alarm)

the doors, liftgate, and charge lid

The alarm stops by pressing any button

when pressing the unlock button

on the key.

once.

Refer to the Settings section in the

Power saving function

Mazda Connect Owner's Manual.

By turning on the transmitter power

 (Auto re-lock function)

saving function, the advanced keyless

After unlocking with the key, all the

entry*1 system functions turn off and

doors, liftgate, and charge lid will

the battery power consumption of the

automatically lock if any of the

transmitter is restricted.

following operations are not

The remote control function is

performed within about 60 seconds.

operational by operating the

The time required for the doors to

transmitter switch even while the

lock automatically can be changed.

power saving function is turned on.

Refer to the Settings section in the

However, the operation indicator light

Mazda Connect Owner's Manual.

of the transmitter does not turn on/

^ A door or the liftgate is opened.

flash.

^ The power switch is switched to

Turning on the power saving function

any position other than off.

After you have turned on the power

Panic button

saving function according to the

If you witness from a distance

following procedure, the hazard

someone attempting to break into or

warning lights and sound operate*1

damage your vehicle, press and hold

one time.

the panic button to activate the

1. Press the lock button on the

vehicle's alarm. Call emergency

transmitter 4 times within 3

services if necessary.

seconds to turn on the operation

indicator light.

2. Press the lock button continuously

for 1.5 seconds or longer while the

operation indicator light turns on

(for 5 seconds).

3. Press any of the buttons on the

NOTE

transmitter to make sure that the

The panic button will work whether

operation indicator light does not

any door or the liftgate is open or

turn on/flash.

closed.

Turning off the power saving function

(Turning on the alarm)

After you have turned off the power

Pressing the panic button for 1 second

saving function according to the

or more will trigger the alarm for about

following procedure, the hazard

2 minutes and 30 seconds, and the

warning lights and sound operate*1

following will occur:

one time.

^ The horn sounds intermittently.

3-29

Before Driving

Keys

1. Press any of the buttons on the

1. Interior antenna

transmitter to make sure that the

2. Operational range

operation indicator light does not

turn on/flash.

Without the advanced keyless

2. Press the lock button on the

function

transmitter 4 times within 3

seconds to turn on the operation

indicator light.

3. Press the lock button continuously

for 1.5 seconds or longer while the

operation indicator light turns on

(for 5 seconds).

^*1

With the advanced keyless function

1. Interior antenna

▼ Operational Range

2. Operational range

The system operates only when the

driver is in the vehicle or within

NOTE

operational range while the key is

The EV system may not start if the key

being carried.

is placed in the following areas:

Starting the EV system

^ Around the dashboard

^ In the storage compartments such as

the glove compartment or the center

NOTE

console

^ Starting the EV system may be

possible even if the key is outside of

▼ Key Suspend Function

the vehicle and extremely close to a

If a key is left in the vehicle, the

door and window, however, always

functions of the key left in the vehicle

start the EV system from the driver's

are temporarily suspended to prevent

seat.

theft of the vehicle.

If the vehicle is started and the key is

To restore the functions, press the

not in the vehicle, the vehicle will not

unlock button on the

restart after it is shut off and the

functions-suspended key in the

power switch is switched off.

vehicle.

^ The luggage compartment is out of

the assured operational range,

however, if the key (transmitter) is

operable the EV system will start.

With the advanced keyless function

3-30

Before Driving

Advanced Keyless Entry System

NOTE

Advanced Keyless Entry

The advanced keyless entry system

System*

functions can be deactivated to

prevent any possible adverse effect on

▼ Advanced Keyless Entry System

a user wearing a pacemaker or other

medical device. If the system is

deactivated, you will be unable to start

WARNING

the EV system by carrying the key.

Consult an Authorized Mazda Dealer

Radio waves from the key may affect

for details. If the advanced keyless

medical devices such as pacemakers:

entry system has been deactivated, you

Before using the key near people who

can start the EV system by following

use medical devices, ask the medical

the procedure indicated when the key

device manufacturer or your physician

battery goes dead.

if radio waves from the key will affect

Refer to Starting the EV System When

the device.

the Key Battery is Dead on page 4-6.

The advanced keyless function allows

you to lock/unlock the door, liftgate,

and charge lid, or open the liftgate

while carrying the key.

System malfunctions or warnings are

indicated by the following warning

beeps.

^ Touch Sensor Inoperable Warning

Beep

Refer to Touch Sensor Inoperable

Warning Beep (With the advanced

keyless function) on page 7-38.

^ Liftgate Door-lock Switch Inoperable

Warning Beep

Refer to Liftgate Door-lock Switch

Inoperable Warning Beep (With the

advanced keyless function) on page

7-38.

^ Key Left-in-luggage Compartment

Warning Beep

Refer to Key Left-in-luggage

Compartment Warning Beep (With

the advanced keyless function) on

page 7-38.

^ Key Left-in-vehicle Warning Beep

Refer to Key Left-in-vehicle Warning

Beep (With the advanced keyless

function) on page 7-38.

*Some models.

3-31

Before Driving

Advanced Keyless Entry System

^ Next to a communication device

Operational Range

such as a mobile phone

▼ Operational Range

▼ Locking Using Door-Lock Switch/

The system operates only when the

Unlocking Using Electric Liftgate

driver is in the vehicle or within

Opener

operational range while the key is

being carried.

NOTE

When the battery power is low, or in

places where there are high-intensity

radio waves or noise, the operational

range may become narrower or the

system may not operate. For

1. Exterior antenna

determining battery replacement,

2.

80 cm (31 in)

Refer to Keyless Entry System on page

3. Operational range

3-27.

▼ Locking/Unlocking Using Touch

Sensor

1. Exterior antenna

2.

80 cm (31 in)

3. Operational range

NOTE

^ The system may not operate if you

are too close to the windows or door

handles.

^ If the key is left in the following areas

and you leave the vehicle, the doors

may be locked depending on the

radio wave conditions even if the key

is left in the vehicle.

^ Around the dashboard

^ In the storage compartments such

as the glove compartment or the

center console

3-32

Before Driving

Doors and Locks

After closing the doors and the

Door Locks

liftgate, always verify that they are

securely closed:

▼ Door Locks

Doors and the liftgate not securely

closed are dangerous, if the vehicle is

WARNING

driven with a door and the liftgate not

securely closed, the door and the

Always take all children and pets with

liftgate could open unexpectedly

you or leave a responsible person

resulting in an accident.

with them:

Leaving a child or a pet unattended in

Always confirm the safety around the

a parked vehicle is dangerous. In hot

vehicle before opening a door and the

weather, temperatures inside a vehicle

liftgate:

can become high enough to cause

Suddenly opening a door and the

brain damage or even death.

liftgate is dangerous. A passing vehicle

or a pedestrian could be hit and cause

Do not leave the key in your vehicle

an accident.

with children and keep them in a

place where your children will not

CAUTION

find or play with them:

Leaving children in a vehicle with the

¾ Always confirm the conditions

key is dangerous. This could result in

around the vehicle before opening/

someone being badly injured or even

closing the doors and the liftgate and

killed.

use caution during strong winds or

when parked on an incline. Not

Keep all doors locked when driving:

being aware of the conditions

Unlocked doors in a moving vehicle

around the vehicle is dangerous

are dangerous. Passengers can fall out

because fingers could get caught in

if a door is accidentally opened and

the door and the liftgate or a passing

can more easily be thrown out in an

pedestrian could be hit, resulting in

accident.

an unexpected accident or injury.

Always close all the windows and

NOTE

moonroof, lock the doors, charge lid,

and liftgate and take the key with you

^ Always stop the EV system and lock

the doors. In addition, to prevent

when leaving your vehicle

unattended:

theft of valuables, do not leave them

inside the cabin.

Leaving your vehicle unlocked is

dangerous as children could lock

^ If the key is left in the following areas

and you leave the vehicle, the doors

themselves in a hot vehicle, which

could result in death. Also, a vehicle

may be locked depending on the

radio wave conditions even if the key

left unlocked becomes an easy target

for thieves and intruders.

is left in the vehicle.

^ Around the dashboard

3-33

Before Driving

Doors and Locks



In the storage compartments such

This system automatically unlocks the

as the glove compartment or the

doors, charge lid, and liftgate in the

center console

event the vehicle is involved in an

^ Next to a communication device

accident to allow passengers to get

such as a mobile phone

out of the vehicle immediately and

^ When the power switch is switched

prevent being trapped inside. While

to ACC or ON, the vehicle lock-out

the power switch is switched ON

prevention feature prevents you from

and in the event the vehicle receives

locking yourself out of the vehicle.

an impact strong enough to inflate

All doors, charge lid, and liftgate will

the air bags, all the doors, charge lid,

automatically unlock if they are

and liftgate are automatically

locked using the power door locks

unlocked after about 6 seconds have

with any door or the liftgate open.

elapsed from the time of the

The vehicle lock-out prevention

accident.

feature does not operate while the

The doors, charge lid, and liftgate

power switch is switched off.

may not unlock depending on how

When all doors, charge lid, and

an impact is applied, the force of the

liftgate are locked using the power

impact, and other conditions of the

door lock with any door or the

accident.

liftgate open, the closed doors,

If door-related systems or the battery

charge lid, and liftgate are locked.

is malfunctioning, the doors, charge

After that, when all doors and the

lid, and liftgate may not unlock

liftgate are closed, all doors and the

depending on your vehicle type.

liftgate are locked. However, if the

▼ Unlocking with Auxiliary Key

key is inside the vehicle, all doors,

charge lid, and liftgate are

Only the driver's door can be unlocked

automatically unlocked.

using the auxiliary key.

(With the advanced keyless

Refer to Keys on page 3-25.

function)

Insert the auxiliary key while the

The beep sound is heard for about

driver's door handle is pulled and turn

10 seconds to notify the driver that

the key to the unlock side. Turn the

the key has been left in the vehicle.

auxiliary key back to its original

(Without the advanced keyless

position before removing it.

function)

The horn sound is heard twice to

notify the driver that the key has

been left in the vehicle.



(Door unlock (control) system with

collision detection)

3-34

Before Driving

Doors and Locks

NOTE

Unlocking

If you attempt to open the driver’s

door using an unauthorized auxiliary

key, the key cylinder will spin around

but the door will not unlock.

▼ Locking, Unlocking with Touch

Sensor, Door Handle (With the

advanced keyless function)

^ The system may not operate normally

By touching the sensing area of the

under the following conditions.

touch sensor, various locking/

unlocking operations can be done

^ You touch the sensing area of the

without taking the key out of a bag or

door lock touch sensor and the

pocket.

sensing area of the door release

There are two types of touch sensors

touch sensor at the same time.

used for locking and unlocking, and

each sensor is built into the outer door

handle on the driver and front

passenger's doors.

1. Sensing area of door lock touch

^ You touch the sensing area of the

sensor (Depression on outer side of

touch sensor while wearing gloves.

door handle)

^ Foreign matter such as snow or dirt

2. Sensing area of door release touch

is stuck on the sensing area of the

sensor (Inner side of door handle)

touch sensor.

^ You pull the door handle just after

NOTE

touching the sensing area of the

^ When locking/unlocking with the

touch sensor.

transmitter carried, securely touch

^ The system may operate if the outer

the sensing area of the touch sensor

side door handle of a front door is

as follows.

splashed with water by a car wash or

Locking

rain while the transmitter is in the

operation range.

^ If the system does not operate even

though you touch the sensing area of

the touch sensor correctly, release

the touch sensor once, and then

touch the sensing area of the touch

sensor again after waiting about 3

seconds.

3-35

Before Driving

Doors and Locks

A beep sound is heard when all

^ Liftgate

doors and the liftgate are closed

▼ Locking, Unlocking with

while the transmitter is being carried.

Door-Lock Switch

All the doors, charge lid, and liftgate

are locked automatically when the

Door-lock switch on driver’s and front

transmitter is out of the operational

passenger's door

range. Also, the hazard warning

The following locations are locked/

lights flash once. (Even if the driver is

unlocked by pressing the door-lock

in the operational range, all the

switch.

doors, charge lid, and liftgate are

locked automatically after about 30

^ All doors

seconds.) If you are out of the

^ Charge lid

operational range before the doors

^ Liftgate

and the liftgate are completely

Driver's door

closed or another transmitter is left

in the vehicle, the walk-away auto

lock function will not work. Always

make sure that all doors and the

liftgate are closed and locked before

leaving the vehicle. The walk-away

auto lock function does not close the

power windows.



(Auto re-lock function)

After unlocking with the touch

sensor, all the doors , charge lid, and

1. Unlock

liftgate will automatically lock if any

2. Lock

of the following operations are not

Front passenger's door

performed within about 60 seconds.

^ Opening a door or the liftgate.

^ Switching the power switch to any

position other than off.

The time required for the doors to

lock automatically can be changed.

Refer to the Settings section in the

Mazda Connect Owner's Manual.

▼ Locking, Unlocking with

1. Unlock

Transmitter

2. Lock

The following locations can be locked/

NOTE

unlocked by operating the keyless

^ To prevent the transmitter from being

entry system transmitter. Refer to

left in the vehicle, make sure that you

Keyless Entry System (page 3-27).

carry the transmitter before locking.

^ All doors

^ Charge lid

3-37

Before Driving

Doors and Locks



After locking by pressing the

^ You are carrying the transmitter.

door-lock switch and when the

^ The power switch is switched OFF.

liftgate is closed last with the

^ All the doors are closed.

transmitter left in the vehicle, only

When locking, the hazard warning

the liftgate is unlocked.

lights and a beep sound operate 1

Locking from the outside using the

time.

door-lock switch

NOTE

When locking from the outside using

^ To prevent the transmitter from being

the door-lock switch, press the lock

left in the vehicle, make sure that you

side of the door-lock switch with all of

carry the transmitter before locking.

the following conditions met and then

^ After locking by pressing the

close all the doors.

door-lock switch and when the

^ The power switch is switched OFF.

liftgate is closed with the transmitter

^ Any door is open.

left in the vehicle, the liftgate is

unlocked.

NOTE

▼ Auto Lock/Unlock Function

After locking by pressing the door-lock

switch and when all the doors are

closed with the transmitter left in the

WARNING

vehicle, all the doors, liftgate, and

charge lid are unlocked.

Do not pull the inner handle on a

front door:

Pulling the inner handle on a front

Door-lock switch on liftgate (With the

door while the vehicle is moving is

advanced keyless function)

dangerous. Passengers can fall out of

the vehicle if the door opens

All doors, charge lid, and the liftgate

accidentally, which could result in

can be locked by pressing the

death or serious injury.

door-lock switch.

^ When the vehicle speed exceeds 20

km/h (12 mph), all the doors,

charge lid, and liftgate lock

automatically.

^ When the power switch is switched

off, all the doors, charge lid, and

liftgate unlock automatically.

The auto lock/unlock function settings

can be changed.

Refer to the Settings section in the

Mazda Connect Owner's Manual.

When locking using the door-lock

switch, press the door-lock switch with

all of the following conditions met and

then close the liftgate.

3-38

Before Driving

Doors and Locks

▼ Locking, Unlocking with

This does not operate the other door

Door-Lock Knob

locks.

Operation from inside

To lock any door from the inside, press

the door-lock knob.

To unlock, pull it outward.

This does not operate the other door

locks.

1. Unlocked: Red indicator

2. Lock

3. Unlock

Operation from outside

NOTE

To lock any door using its door-lock

When locking the door this way:

knob from the outside, press the

^ Be careful not to leave the key inside

door-lock knob to the lock position

the vehicle.

and close the door (holding the door

^ The doors cannot be locked using

handle in the open position is not

the driver's door lock knob if any

required).

door or liftgate is open when the

power switch is switched to ACC or

ON.

^ All the doors, charge lid , and liftgate

are unlocked when the lock knob on

all the doors is pressed down to the

lock side and all the doors are closed

with the transmitter left in the

vehicle.

▼ Freestyle Doors

With freestyle doors, the rear door is

hinged at its rear and opens in the

opposite direction to the front door.

3-39

Before Driving

Doors and Locks

2. Pull the rear door handle and open

CAUTION

the rear door.

¾ Do not close the front door first.

Closing the rear door with the front

door closed first could damage or

scratch the front door.

¾ When opening the rear door, do not

close the front door. Otherwise,

occupants getting in or out of the

vehicle could be injured.

¾ When opening the rear door, make

sure that the front door does not

interfere. The rear door could

1. Rear door handle

contact the front door and cause

damage or scratches if the front door

Closing the doors

is not sufficiently clear of the rear

1. Close the rear door.

door.

NOTE

^ The child safety lock mechanism is

not equipped on the vehicle because

it is not possible to open only the

rear door.

^ Before opening the rear door, make

sure that the front seat belt is

unfastened.

2. Close the front door.

Opening the doors

1. Open the front door.

3-40

Before Driving

Doors and Locks

¾ Be careful not to apply excessive

Liftgate

force to the damper stay on the

liftgate such as by putting your hand

▼ Liftgate

on the stay. Otherwise, the damper

stay may bend and affect the liftgate

WARNING

operation.

Never allow a person to ride in the

luggage compartment:

Allowing a person to ride in the

luggage compartment is dangerous.

The person in the luggage

compartment could be seriously

injured or killed during sudden braking

or a collision.

Do not stack or leave loaded luggage

1. Damper stay

unsecured in the luggage

¾ Do not modify or replace the liftgate

compartment:

damper stay. Consult an Authorized

Otherwise, the luggage may move or

Mazda Dealer if a liftgate damper

collapse, resulting in injury or an

stay is deformed or damaged for

accident. In addition, do not load

reasons such as a collision or if there

luggage higher than the seatbacks. It

is some other problem.

may affect the side or rear field of view.

▼ Opening and Closing the Liftgate

Additionally, if the air bags deploy, the

cargo may scatter which could result in

Opening the liftgate

serious injury or death.

Using the electric liftgate opener

Unlock the doors and liftgate, then

CAUTION

press the electric liftgate opener on the

¾ Before opening the liftgate, remove

liftgate and raise the liftgate when the

any snow and ice accumulation on it.

latch releases.

Otherwise, the liftgate could close

under the weight of the snow and ice

resulting in injury.

¾ Be careful when opening/closing the

liftgate during strong winds. If a

strong gust blows against the liftgate,

it could close suddenly resulting in

injury.

¾ Fully open the liftgate and make sure

that it stays open. If the liftgate is

only opened partially, it could slam

shut by vibration or wind gusts

NOTE

resulting in injury.

(With the advanced keyless function)

3-41

Before Driving

Doors and Locks



A locked liftgate can also be opened

Do not slam it. Pull up on the liftgate

while the key is being carried.

to make sure it is secure.

^ When opening the liftgate with the

doors and the liftgate locked, it may

require a few seconds for the liftgate

latch to release after the electric

liftgate opener is pressed.

^ The liftgate can be closed when the

doors are locked with the key left in

the vehicle. However, to prevent

locking the key in the vehicle, the

liftgate can be opened by pressing

the electric liftgate opener. If the

liftgate cannot be opened despite

WARNING

doing this procedure, first push the

liftgate completely closed, then press

Do not drive the vehicle with the

the electric liftgate opener to fully

liftgate-ajar warning indication

open the liftgate.

displayed :

^ When the liftgate latch is released by

Otherwise, the liftgate may open

pressing the electric liftgate opener,

unexpectedly and result in an accident.

the liftgate raises slightly. If the

liftgate is not operated for a certain

period of time, the liftgate cannot be

NOTE

raised.

Confirm that the liftgate is securely

To open

closed.

Press the electric liftgate opener

Move the liftgate without pressing the

again.

electric liftgate opener to verify that the

To close

liftgate has not been left ajar.

To close the liftgate from its slightly

▼ Luggage Compartment

raised position, open it first by

pressing the electric liftgate opener,

Luggage compartment cover*

then close it after waiting at least 1

second.

WARNING

^ If the vehicle battery is dead or there

is a malfunction in the electrical

Do not place anything on top of the

system and the liftgate cannot be

cover:

unlocked, the liftgate can be opened

Placing luggage or other cargo on top

by performing the emergency

of the luggage compartment cover is

procedure.

dangerous. During sudden braking or a

Refer to When Liftgate Cannot be

collision, the cargo could become a

Opened on page 7-42.

projectile that could hit and injure

Closing the liftgate

someone.

Lower the liftgate slowly using the

liftgate grip recess, then push the

liftgate closed using both hands.

3-42

*Some models.

Before Driving

Doors and Locks

Make sure luggage and cargo are

and remove the luggage

secured before driving:

compartment cover from the pins.

Not securing cargo while driving is

dangerous as it could move or be

crushed during sudden braking or a

collision and cause injury.

CAUTION

¾ Make sure the luggage compartment

cover is firmly secured. If it is not

firmly secured, it could unexpectedly

disengage resulting in injury.

The luggage compartment can be

1. Pin

accessed by opening the liftgate when

the straps are attached to the sides of

3. Lift the front end of the luggage

the liftgate.

compartment cover and remove it.

Removing the luggage compartment

cover

This cover can be removed for more

room.

1. Remove the straps from the hooks.

2. Press the luggage compartment

cover upward from near the pins

3-43

Before Driving

Mirrors

2.

Press the adjustment switch to

Mirrors

adjust the angle of the outside

mirror.

▼ Mirrors

Before driving, adjust the inside and

outside mirrors.

▼ Outside Mirrors

WARNING

Be sure to look over your shoulder

before changing lanes:

Changing lanes without taking into

account the actual distance of the

vehicle in the convex mirror is

dangerous. You could have a serious

accident. What you see in the convex

mirror is closer than it appears.

Mirror type

Flat type (driver's side)

1.

Indicator light

Flat surface mirror.

2.

Select switch

Convex type (front passenger side)

3.

Adjustment switch

The mirror has single curvature on its

surface.

After adjusting the angle of the outside

mirror, press the select switch for the

Power mirror adjustment

outside mirror to be adjusted to turn

The power switch must be switched to

off the indicator light.

ACC or ON position.

NOTE

To adjust:

(With driving position memory

1. Press the select switch for the

function)

outside mirror to be adjusted to

The on-road outside mirror position

turn on the indicator light.

can be programmed in conjunction

with the driving position memory

function.

Refer to Driving Position Memory on

page 2-10.

Power mirrors with reverse tilt down

function*

The outside mirrors tilt downward to

facilitate the view of the lower area on

each side of the vehicle.

1. Switch the power switch ON.

3-44

*Some models.

Before Driving

Mirrors

2. Press the select switch for the

WARNING

outside mirror to be tilted

downward to turn on the indicator

Do not touch a power folding outside

light of the select switch.

mirror while it is moving:

3. Shift the selector lever to the R

Touching the power folding outside

position to tilt the outer mirror on

mirror when it is moving is dangerous.

the side where the select button

Your hand could be pinched and

was pressed downward.

injured or the mirror could be

NOTE

damaged.

When any of the following condition is

met, the outer mirrors return to their

Use the switch to set the mirror to the

normal positions.

on-road position:

Setting the power folding outside

^ The power switch is switched to a

mirror to the on-road position by hand

position other than ON.

is dangerous. The mirror will not lock

^ The selector lever is shifted to a

in position and will prevent effective

position other than R.

rearview visibility.

^ The select switch is pressed again.

Folding outside mirror

Only operate the power folding

outside mirror with the vehicle safely

parked:

WARNING

Operating the power folding outside

mirror while the vehicle is moving is

Always return the outside mirrors to

dangerous. Wind blast on the mirror

the driving position before you start

will cause them to collapse and you

driving:

will be unable to return it to the

Driving with the outside mirrors folded

on-road position, preventing rearview

in is dangerous. Your rear view will be

visibility.

restricted, and you could have an

accident.

The power switch must be switched to

ACC or ON position.

Manual folding outside mirror

To fold the mirrors, press the outside

Fold the outside mirror rearward until

mirror folding switch.

it is flush with the vehicle.

To return the mirrors to their on-road

positions, press the switch again.

Power folding outside mirror

3-45

Before Driving

Mirrors

Automatic folding function

Driver's side auto-dimming outside

mirror*

When the power switch is switched to

OFF, the outside mirrors automatically

The movement of the auto-dimming

fold in and out when the doors are

outside mirror is interlocked with the

locked and unlocked.

auto-dimming rearview mirror in the

Also, when the power switch is

interior to automatically reduce glare

switched ON or the EV system is

from rear on-coming vehicles.

started, the outside mirrors fold out

Refer to Rearview Mirror on page

automatically.

3-46.

NOTE

NOTE

The front passenger-side outside

^ The outside mirrors may not fold in

mirror does not have the

and out automatically under cold

auto-dimming feature.

weather conditions.

If the outside mirrors do not fold in

▼ Rearview Mirror

and out automatically, remove any

ice or snow, and then press the

WARNING

outside mirror folding switch to fold

the outside mirrors in or out.

^ The automatic folding function can

Do not stack cargo or objects higher

be turned on or off.

than the seatbacks:

Refer to the Settings section in the

Cargo stacked higher than the

Mazda Connect Owner's Manual.

seatbacks is dangerous. It can block

^ In the following cases, the outside

your view in the rearview mirror, which

mirrors do not fold out

might cause you to hit another car

automatically. Press the outside

when changing lanes.

mirror folding switch to fold out the

Rearview mirror adjustment

outside mirrors.

Before driving, adjust the rearview

^ Pressing the outside mirror folding

mirror to center on the scene through

switch to fold in the outside

the rear window.

mirrors. *1

^ Disconnecting the battery

terminals after the outside mirrors

fold in automatically.

^*1

When the automatic folding function is

changed from off to on after folding in the

outside mirrors, the outside mirrors fold out

automatically.

EV system-off outside mirror

operation

The outside mirrors can be operated

for about 40 seconds after the power

switch is switched from ON to off.

3-46

*Some models.

Before Driving

Mirrors

NOTE

To reactivate the auto-dimming

For the manual day/night mirror,

function, press the ON/OFF button

perform the adjustment with the day/

(

). The indicator light will illuminate.

night lever in the day position.

Reducing glare from headlights

Manual day/night mirror

Push the day/night lever forward for

day driving. Pull it back to reduce glare

of headlights from vehicles at the rear.

1. ON/OFF button

2. Indicator light

NOTE

^ Do not use glass cleaner or suspend

objects on or around the light

sensor. Otherwise, light sensor

1. Day/Night lever

sensitivity will be affected and may

2. Night

not operate normally.

3. Day

Auto-dimming mirror

The auto-dimming mirror

automatically reduces the glare of

headlights from vehicles at the rear

when the power switch is switched

ON.

(With ON/OFF button)

Press the ON/OFF button ( ) to cancel

the auto-dimming function. The

1. Light sensor

indicator light will turn off.



(With Homelink wireless control

system)

For information regarding the 3

buttons ( ,

,

) on the

auto-dimming mirror.

Refer to HomeLink Wireless Control

System on page 4-47.

3-47

Before Driving

Windows

If the person's hand or head hits

Power Windows

something outside the vehicle, or

sudden braking is applied, it could

▼ Power Windows

result in serious injury or death.

The windows can be opened/closed

by operating the power window

▼ Opening/Closing Windows

switches.

The window opens while the switch is

pressed and it closes while the switch

WARNING

is pulled up with the power switch

switched ON.

Make sure the opening is clear before

The front passenger's window can be

closing a window:

opened/closed when the power

Closing a power window is dangerous.

window lock switch on the driver's

A person's hands, head, or even neck

door is in the unlocked position. Keep

could be caught by the window and

this switch in the locked position while

result in serious injury or even death.

children are in the vehicle.

This warning applies especially to

children.

Master control switches

Never allow children to play with

power window switches:

Power window switches that are not

locked with the power window lock

switch would allow children to operate

power windows unintentionally, which

could result in serious injury if a child's

hands, head or neck becomes caught

by the window.

Make sure nothing blocks the window

just before it reaches the fully closed

position or while fully holding up the

power window switch:

Blocking the power window just before

it reaches the fully closed position or

while fully holding up the power

window switch is dangerous.

In this case, the jam-safe function may

not prevent the window from closing

all the way. If fingers are caught,

1.

Close

serious injuries could occur.

2.

Open

3.

Passenger's window

Do not let a child put a hand or head

4.

Power window lock switch

out of the window while driving the

5.

Driver's window

vehicle:

6.

Locked position

3-49

Before Driving

Windows

7. Unlocked position

NOTE

Power window system initialization

Passenger's window switch

procedure

If you operate the switch any number

of times with the power window not

fully closed, the window may no longer

fully open/close automatically.

The power window auto function will

only resume on a power window that

has been reset.

1. Close

1. Switch the power switch ON.

2. Open

2. Make sure that the power window

lock switch located on the driver's

door is not depressed.

NOTE

3. Press the switch and fully open the

^ A power window may no longer

window.

open/close if you continue to press

4. Pull up the switch to fully close the

the switch for a long time. If the

window and continue holding the

power window does not open/

switch for about 2 seconds after the

close, wait for a while and then

window fully closed.

operate the switch again.

5. Make sure that the power windows

^ The passenger windows may be

operate correctly using the door

opened or closed using the master

switches.

control switches on the driver's door.

^ The power window can be operated

▼ Jam-safe Window

for about 40 seconds after the power

When the window is closing and a

switch is switched from ON to ACC

foreign object is detected between the

or off with all doors closed. If any

window and the window frame, the

door is opened, the power window

window stops closing and

will stop operating.

automatically opens partway.

▼ Auto-opening/Closing

NOTE

To fully open the window

^ The jam-safe function may operate

automatically, press the switch

under the following conditions:

completely down, then release. The

window will fully open automatically.

^ A strong impact is detected while

To fully close the window

the window is closing.

automatically, pull the switch

^ The window is closing in very low

completely up, then release. The

temperatures.



(A window cannot be closed)

window will fully close automatically.

If the jam-safe function has operated

To stop the window partway, pull or

and the window cannot be closed,

press the switch in the opposite

check around the window frame for

direction and then release it.

a foreign object.

3-50

Before Driving

Windows

If there is no foreign object around

Moonroof

the window frame, forcibly close a

window using the following

▼ Moonroof

procedure.

1.

After switching the power switch

The moonroof can be opened or

OFF, wait for 45 seconds or

closed when operating the overhead

longer.

tilt/slide switch at the front seats.

2.

Switch the power switch ON.

3.

Operate the switch in the

WARNING

direction to close the window

until the jam-safe function

Do not let passengers stand up or

operates and the window stops.

extend part of the body through the

Repeat this operation a total of 5

open moonroof while the vehicle is

times.

moving:

4.

Continue pulling up the switch to

Extending the head, arms, or other

fully close the window.

parts of the body through the

moonroof is dangerous. The head or

arms could hit something while the

vehicle is moving. This could cause

serious injury or death.

Never allow children to play with the

tilt/slide switch:

The tilt/slide switch would allow

children to operate the moonroof

unintentionally, which could result in

serious injury if a child's hands, head

or neck becomes caught by the

moonroof.

Make sure the opening is clear before

closing the moonroof:

A closing moonroof is dangerous. The

hands, head, or even neck of a person,

especially a child, could be caught in it

as it closes, causing serious injury or

even death.

Make sure nothing blocks the

moonroof just before it reaches the

fully closed position:

Blocking the moonroof just before it

reaches the closed position is

dangerous.

*Some models.

3-51

Content      ..     2      3      4      5     ..
