Specifications
Specifications
Specifications
Engine
Item
Specification
Type
DOHC-16V in-line, 4-cylinder
Bore × Stroke
83.5 × 91.2 mm (3.29 × 3.59 in)
Displacement
1,997.6 ml (1,997.6 cc)
Compression ratio
13.0
Electrical System
Item
Classification
Battery*1
12V-45Ah/20HR
Spark-plug number
Mazda Genuine spark plug*2
PE5R-18-110-A or PE5S-18-110
*1
Check the battery installed on the vehicle and use a battery with an equal or higher performance. However, the
performance of the battery may vary even among the same battery types, consult an Authorized Mazda Dealer
for replacement.
*2
The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
9-4
Specifications
Specifications
Lubricant Quality
Lubricant
Classification
Engine oil
Refer to Recommended Oil on page 6-20.
Coolant
FL-22 type
Manual transmission oil
Mazda Original Long Life Gear Oil IS*1
Automatic transmission fluid*2
Mazda Genuine JWS3309
Rear differential oil*3
Mazda Long Life Hypoid Gear Oil SG1
Brake/Clutch fluid
SAE J1703 or FMVSS116 DOT-3
*1
Mazda Original Long Life Gear Oil IS is superior oil for optimum shift-feel. Using Mazda Original Long Life
Gear Oil IS is recommended.
If Mazda Original Long Life Gear Oil IS cannot be obtained, use standard oil (API Service GL-4 (SAE
75W-90)). However, shifting in very low temperatures may become difficult.
*2
Periodic replacement is unnecessary.
*3
Replacement is necessary when the component is submerged in water.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
Capacities
(Approximate Quantities)
Item
Capacity
With oil filter replacement
4.3 L (4.5 US qt, 3.8 Imp qt)
Engine oil
Without oil filter replacement
4.1 L (4.3 US qt, 3.6 Imp qt)
Manual transmission
6.0 L (6.3 US qt, 5.3 Imp qt)
Coolant
U.S.A. and Canada
5.7 L (6.0 US qt, 5.0 Imp qt)
Automatic transmission
Mexico
5.8 L (6.1 US qt, 5.1 Imp qt)
Manual transmission oil
2.0 L (2.1 US qt, 1.8 Imp qt)
Automatic transmission fluid
7.2 L (7.6 US qt, 6.3 Imp qt)
Rear differential oil
0.6 L (0.6 US qt, 0.5 Imp qt)
Fuel tank
45.0 L (11.9 US gal, 9.90 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
9-5
Specifications
Specifications
Dimensions
U.S.A. and Canada
Vehicle specification
Item
Soft top model
Hardtop model
Overall length
3,915 mm (154.1 in)
3,915 mm (154.1 in)
Overall width
1,735 mm (68.3 in)
1,735 mm (68.3 in)
16 inch wheel vehicle
1,235 mm (48.6 in)
ʊ
Overall height
17 inch wheel vehicle
1,240 mm (48.8 in)
1,245 mm (49.0 in)
Front tread
1,496 mm (58.9 in)
1,496 mm (58.9 in)
Rear tread
1,503 mm (59.2 in)
1,503 mm (59.2 in)
Wheelbase
2,310 mm (90.9 in)
2,310 mm (90.9 in)
Mexico
Vehicle specification
Item
Soft top model
Hardtop model
Overall length
3,915 mm (154.1 in)
3,915 mm (154.1 in)
Overall width
1,735 mm (68.3 in)
1,735 mm (68.3 in)
Overall height
1,230 mm (48.4 in)
1,235 mm (48.6 in)
Front tread
1,496 mm (58.9 in)
1,496 mm (58.9 in)
Rear tread
1,503 mm (59.2 in)
1,503 mm (59.2 in)
Wheelbase
2,310 mm (90.9 in)
2,310 mm (90.9 in)
9-6
Specifications
Specifications
Weights
U.S.A. and Canada
Weight
Soft top model
Hardtop model
Item
Manual
Automatic
Manual
Automatic
transmission
transmission
transmission
transmission
1,245 kg
1,265 kg
1,298 kg
1,312 kg
GVWR (Gross Vehicle Weight Rating)
(2,745 lbs)
(2,789 lbs)
(2,862 lbs)
(2,892 lbs)
628 kg (1,384
642 kg (1,415
636 kg (1,402
644 kg (1,420
Front
lbs)
lbs)
lbs)
lbs)
GAWR (Gross Axle Weight Rating)
620 kg (1,367
626 kg (1,380
664 kg (1,464
670 kg (1,477
Rear
lbs)
lbs)
lbs)
lbs)
Mexico
Weight
Soft top model
Item
Manual transဨ
Automatic transဨ
Hardtop model
mission
mission
1,242 kg (2,738
1,277 kg (2,851
1,305 kg (2,877
Total
lbs)
lbs)
lbs)
GVW (Gross Vehicle Weight)
Front
627 kg (1,382 lbs)
653 kg (1,440 lbs)
639 kg (1,409 lbs)
Rear
615 kg (1,356 lbs)
624 kg (1,376 lbs)
666 kg (1,468 lbs)
Front
630 kg (1,389 lbs)
653 kg (1,440 lbs)
639 kg (1,409 lbs)
GAW (Permissible axle load)
Rear
615 kg (1,356 lbs)
624 kg (1,376 lbs)
666 kg (1,468 lbs)
9-7
Specifications
Specifications
Light Bulbs
Exterior light
Category
Light bulb
Wattage
UN-R*1 (SAE)
High beam
LED
ʊ (ʊ)
Headlights
Low beam
LED
ʊ (ʊ)
LED type
LED
ʊ (ʊ)
Daytime running lights
Bulb type
21
W21W (7440)
Parking lights
LED
ʊ (ʊ)
Front side-marker lights
5
W5W (ʊ)
Front turn signal lights
28/8
ʊ (7444NA)
Side turn signal lights
5*2
WY5W (ʊ)
High-mount brake light
LED
ʊ (ʊ)
Rear turn signal lights
21
WY21W (7443NA)
Rear side-marker lights
5
W5W (ʊ)
Brake lights
LED
ʊ (ʊ)
Taillights
LED
ʊ (ʊ)
Reverse lights
21
W21W (7440)
License plate lights
5
W5W (ʊ)
*1
UN-R stands for United Nations Regulation.
*2
Bulb replacement is not possible because it is built into the unit. Replace the unit.
Interior light
Category
Light bulb
Wattage
UN-R*1
Overhead light
10
ʊ
Trunk light
5
ʊ
*1
UN-R stands for United Nations Regulation.
9-8
Specifications
Specifications
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 6-34.
Standard tire
Inflation pressure
Tire size
Front
Rear
195/50R16 84V
200 kPa (2.0 bar, 29 psi)
200 kPa (2.0 bar, 29 psi)
205/45R17 84W
200 kPa (2.0 bar, 29 psi)
200 kPa (2.0 bar, 29 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108ʊ147 N·m (12ʊ14 kgf·m, 80ʊ108 ft·lbf)
Fuses
Refer to Fuses on page 6-47.
9-9
