If Trouble Arises
Flat Tire
Locking Lug Nuts*
WARNING
If your vehicle has Mazda optional
Do not jack up the vehicle higher than
antitheft wheel lug nuts, each wheel will
is necessary:
have one locking lug nut that locks the
Jacking up the vehicle higher than is
wheel and tire, and you must use a special
key to unlock the locking lug nut. This key
necessary is dangerous as it could
destabilize the vehicle resulting in an
is stored in the glove compartment.
accident.
Register the key and lug nuts with the lock
manufacturer by filling out the card
Do not start the engine or shake the
provided in the glove compartment and
vehicle while it is jacked up:
mailing it in the accompanying envelope.
Starting the engine or shaking the
If you lose this key, consult an Authorized
vehicle while it is jacked up is
Mazda Dealer or use the lock
dangerous as it could cause the vehicle
manufacturer's order form, which is with
to fall off the jack resulting in an
the registration card.
accident.
Accessory wheel locks cannot be used on
steel wheels. This includes situations when
Never go under the vehicle while it is
the spare tire is installed. When installing
jacked up:
a spare tire, original lug nut must be used
Going under the vehicle while it is
in place of the wheel lock.
jacked up is dangerous as it could result
Antitheft lug nut
Special key
in death or serious injury if the vehicle
were to fall off the jack.
8.
Remove the lug nuts by turning them
counterclockwise; then remove the
wheel.
To remove an antitheft lug nut
1. Obtain the special key for the antitheft
lug nut.
2. Place the special key on top of the
antitheft lug nut, and be sure to hold
the key square to it. If you hold the key
at an angle, you may damage both key
and nut. Do not use a power impact
wrench.
7-20
*Some models.
If Trouble Arises
Flat Tire
3. Place the lug wrench on top of the key
WARNING
and apply pressure. Turn the wrench
counterclockwise.
Make sure the mounting surfaces of the
To install the antitheft lug nut
wheel, hub and lug nuts are clean
1. Place the special key on top of the nut,
before changing or replacing tires:
and be sure to hold the key square to it.
When changing or replacing a tire, not
If you hold the key at an angle, you
removing dirt and grime from the
may damage both key and nut. Do not
mounting surfaces of the wheel, hub
use a power impact wrench.
and hub bolts is dangerous. The lug
2. Place the lug wrench on top of the
nuts could loosen while driving and
special key, apply pressure, and turn it
cause the tire to come off, resulting in
clockwise.
an accident.
2.
Mount the tire.
Nut tightening torque
3.
Install the lug nuts with the beveled
108ʊ147 (12ʊ14,
N·m (kgf·m, ft·lbf)
edge inward; tighten them by hand.
80ʊ108)
Mounting the Tire
1. Remove dirt and grime from the
mounting surfaces of the wheel and
hub, including the hub bolts, with a
cloth.
WARNING
Do not apply oil or grease to lug nuts
and bolts and do not tighten the lug
nuts beyond the recommended
tightening torque:
Applying oil or grease to lug nuts and
bolts is dangerous. The lug nuts could
loosen while driving and cause the tire
to come off, resulting in an accident. In
addition, lug nuts and bolts could be
damaged if tightened more than
necessary.
7-21
If Trouble Arises
Flat Tire
4. Turn the lug wrench counterclockwise
Be sure to reinstall the same nuts you
and lower the vehicle.
removed or replace them with metric
5. Use the lug wrench to tighten the nuts
nuts of the same configuration:
in the order shown.
Because the wheel studs and lug nuts
on your Mazda have metric threads,
using a non-metric nut is dangerous.
On a metric stud, it would not secure
the wheel and would damage the stud,
which could cause the wheel to slip off
and cause an accident.
6. Remove the tire blocks and store the
tools and jack.
7. Check the inflation pressure. Refer to
Tires on page 9-9.
If you are unsure of how tight the nuts
WARNING
should be, have them inspected at an
Authorized Mazda Dealer.
Do not drive with any tires that have
incorrect air pressure:
Nut tightening torque
Driving on tires with incorrect air pressure
108ʊ147 (12ʊ14,
N·m (kgf·m, ft·lbf)
80ʊ108)
is dangerous. Tires with incorrect pressure
could affect handling and result in an
accident. When you check the regular tires'
WARNING
air pressure, check the spare tire, too.
Always securely and correctly tighten
NOTE
the lug nuts:
To prevent the jack and tool from rattling,
Improperly or loosely tightened lug
store them properly.
nuts are dangerous. The wheel could
wobble or come off. This could result in
loss of vehicle control and cause a
serious accident.
7-22
If Trouble Arises
Battery Runs Out
Jump-Starting
Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel
unsure about jump-starting, we strongly recommend that you have a competent service
technician do the work.
WARNING
Follow These Precautions Carefully:
To ensure safe and correct handling of the battery, read the following precautions carefully
before using the battery or inspecting it.
Keep flames and sparks away from open battery cells and do not allow metal tools to
contact the positive (
) or negative (
) terminal of the battery when working near a battery.
Do not allow the positive (
) terminal to contact the vehicle body:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and cause the battery to explode. An exploding battery
can cause serious burns and injuries. Keep all flames including cigarettes and sparks away
from open battery cells.
Keep all flames and sparks away from open battery cells because hydrogen gas is
produced from open battery cells while charging the battery or adding battery fluid:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and cause the battery to explode. An exploding battery
can cause serious burns and injuries. Keep all flames including cigarettes and sparks away
from open battery cells.
Do not jump-start a frozen battery or one with a low fluid level:
Jump-starting a frozen battery or one with a low fluid level is dangerous. It may rupture or
explode, causing serious injury.
Connect the negative cable to a good ground point away from the battery:
Connecting the end of the second jumper cable to the negative (
) terminal of the discharged
battery is dangerous.
A spark could cause the gas around the battery to explode and injure someone.
7-23
If Trouble Arises
Battery Runs Out
Route the jumper cables away from parts that will be moving:
Connecting a jumper cable near or to moving parts (cooling fans, belts) is dangerous. The
cable could get caught when the engine starts and cause serious injury.
CAUTION
Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other
electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V
motor generator set).
1. Move the booster vehicle so that its battery is as close as possible to your vehicle's
battery.
2. Make sure that the power such as for the headlights and air conditioner is turned off.
3. Remove the battery cover.
4. Turn off the booster vehicle's engine and connect the jumper cables in the following
order.
Make sure that the jumper cables are securely connected so that they do not disconnect
due to engine vibrations.
1st lead
Positive (+) terminal on the discharged battery
Positive (+) terminal on booster vehicle's battery
7-24
If Trouble Arises
Battery Runs Out
2nd lead
Negative (-) terminal on booster vehicle's battery
Location shown in the figure (do not connect to the negative (-) terminal of the
battery)
Jumper cables
Discharged battery
Booster battery
5. Start the booster vehicle's engine and rev the engine.
6. Start the engine of your vehicle. Run the engines for about 3 minutes to temporarily
charge the battery of your vehicle.
7. Disconnect the jumper cables in the reverse order of their connection.
8. Install the battery cover.
9. Have your vehicle inspected by an Authorized Mazda Dealer as soon as possible.
7-25
If Trouble Arises
Emergency Starting
Starting a Flooded Engine
Push-Starting
If the engine fails to start, it may be
Do not push-start your Mazda.
flooded (excessive fuel in the engine).
WARNING
Follow this procedure:
Never tow a vehicle to start it:
1. If the engine does not start within 5
Towing a vehicle to start it is dangerous.
seconds on the first try, wait 10
The vehicle being towed could surge
seconds and try again.
forward when its engine starts, causing the
2. Make sure the parking brake is on.
2 vehicles to collide. The occupants could
3. Depress the accelerator all the way and
be injured.
hold it there.
4. Depress the clutch pedal (Manual
transmission) or the brake pedal
CAUTION
(Automatic transmission), then press
Do not push-start a vehicle that has a
the push button start. If the engine
manual transmission. It can damage the
starts, release the accelerator
emission control system.
immediately because the engine will
suddenly rev up.
NOTE
5. If the engine fails to start, crank it
You cannot start a vehicle with an
without depressing the accelerator.
automatic transmission by pushing it.
If the engine still does not start using the
previous procedure, have your vehicle
inspected by an Authorized Mazda Dealer.
7-26
If Trouble Arises
Overheating
If the temperature gauge indicates
Overheating
overheating or the high engine coolant
If the temperature gauge indicates
temperature warning light turns on:
overheating or the high engine coolant
temperature warning light turns on, the
1.
Drive safely to the side of the road and
vehicle loses power, or you hear a loud
park off the right-of-way.
knocking or pinging noise, the engine is
2.
Put a vehicle with an automatic
probably too hot.
transmission in park (P), a manual
transmission in neutral.
WARNING
3.
Apply the parking brake.
4.
Turn off the air conditioner.
5.
Check whether coolant or steam is
escaping from the engine
Pull over to a safe location, then switch
compartment.
the ignition off and make sure the fan is
not running before attempting to work
If steam is coming from the engine
near the cooling fan:
compartment:
Working near the cooling fan when it is
Do not go near the front of the vehicle.
running is dangerous. The fan could
Stop the engine.
continue running indefinitely even if the
Wait until the steam dissipates, then
engine has stopped and the engine
open the hood and start the engine.
compartment temperature is high. You
could be hit by the fan and seriously
If neither coolant nor steam is
injured.
escaping:
Open the hood and idle the engine
until it cools.
Do not remove either cooling
CAUTION
system cap when the engine and radiator
are hot:
If the cooling fan does not operate
When the engine and radiator are hot,
while the engine is running, the engine
scalding coolant and steam may shoot out
temperature will increase. Stop the
under pressure and cause serious injury.
engine and call an Authorized Mazda
Dealer.
Open the hood ONLY after steam is no
longer escaping from the engine:
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.
7-27
If Trouble Arises
Overheating
6. Make sure the cooling fan is operating,
then turn off the engine after the
temperature has decreased.
7. When cool, check the coolant level.
If it is low, look for coolant leaks from
the radiator and hoses.
If you find a leak or other damage, or if
coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.
Cooling system cap
Coolant reservoir
Cooling fan
If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required (page
6-22).
CAUTION
If the engine continues to overheat or
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.
7-28
If Trouble Arises
When Fuel-Filler Lid Cannot be Opened
3. Partially peel back the cover inside the
When Fuel-Filler Lid
trunk, then pull the emergency release
Cannot be Opened
lever.
If the battery is dead, the fuel-filler lid
cannot be opened.
In this case, the fuel-filler lid can be
opened by taking care of the dead battery
situation.
Refer to Jump-Starting on page 7-23.
Emergency release
lever
If the fuel-filler lid cannot be opened even
if the dead battery situation has been
resolved, the electrical system may have a
malfunction.
In this case, the fuel-filler lid can be
opened using the following procedure as
an emergency measure.
1. Open the trunk lid.
Refer to Opening and Closing the
Trunk Lid on page 3-19.
2. Pull the center section of the plastic
fastener and remove the fasteners.
7-29
If Trouble Arises
Emergency Towing
Towing Description
CAUTION
We recommend that towing be done only
¾ Do not tow the vehicle pointed backward
by an Authorized Mazda Dealer or a
with driving wheels on the ground. This
commercial tow-truck service.
may cause internal damage to the
transmission.
Proper lifting and towing are necessary to
prevent damage to the vehicle.
Government and local laws must be
followed.
A towed vehicle usually should have its
drive wheels (rear wheels) off the ground.
If excessive damage or other conditions
prevent this, use wheel dollies.
¾ Do not tow with sling-type equipment.
This could damage your vehicle. Use
wheel-lift or flatbed equipment.
Wheel dollies
When towing with the rear wheels on the
ground, release the parking brake.
7-30
If Trouble Arises
Emergency Towing
Rear
Tiedown Hooks*
CAUTION
Do not use the front and rear tiedown
eyelets for towing the vehicle.
They have been designed only for securing
the vehicle to a transport vessel during
shipping.
Using the eyelets for any other purpose
could result in the vehicle being damaged.
Tiedown Hooks
CAUTION
1. Remove the tiedown eyelet and the lug
Do not use excessive force as it may
wrench from the luggage compartment
damage the cap or scratch the painted
(page 7-3).
bumper surface.
2. Wrap a flathead screwdriver or similar
tool with a soft cloth to prevent
NOTE
damage to a painted bumper, and open
Remove the cap completely and store it
the cap located on the front or rear
so as not to lose it.
bumper.
3.
Securely install the tiedown eyelet
Front
using the lug wrench or equivalent.
Consult an Authorized Mazda Dealer.
Front
Lug wrench
Tiedown eyelet
*Some models.
7-31
If Trouble Arises
Emergency Towing
Rear
Lug wrench
Tiedown eyelet
4. Hook the tying rope to the tiedown
eyelet.
CAUTION
If the tiedown eyelet is not securely
tightened, it may loosen or disengage
from the bumper when tying the
vehicle. Make sure that the tiedown
eyelet is securely tightened to the
bumper.
7-32
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
If a Warning Light Turns On or Flashes
If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, however if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
The details for some warnings can be viewed on the center display.
1. If the warning light is turned on, select the
icon on the home screen to display the
application screen.
2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warning to view the warning details.
Stop Vehicle in Safe Place Immediately
If any of the following warning lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized Mazda Dealer.
Signal
Warning
This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the parking brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is fully released.
Low brake fluid level warning
If the brake warning light remains illuminated even though the parking brake is reဨ
leased, the brake fluid may be low or there could be a problem with the brake system.
Park the vehicle in a safe place immediately and contact an Authorized Mazda Dealer.
WARNING
Brake System Warning
Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Light
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.
CAUTION
In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.
7-33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
If the electronic brake force distribution control unit determines that some compoဨ
nents are operating incorrectly, the control unit may illuminate the brake system
warning light and the ABS warning light simultaneously. The problem is likely to be
the electronic brake force distribution system.
WARNING
Electronic Brake Force
Distribution System
Do not drive with both the ABS warning light and brake warning light illuminated.
Warning
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning light and ABS warning light are illuminated
simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an emer-
gency stop than under normal circumstances.
If the warning light illuminates while driving, it indicates a malfunction of the alterဨ
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.
Charging System Warnဨ
ing Indication/Warning
CAUTION
Light
Do not continue driving when the charging system warning light is illuminated be-
cause the engine could stop unexpectedly.
This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level (page 6-21). If it's low, add the appropriate amount of
Engine Oil Warning
engine oil while being careful not to overfill.
Light
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.
If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
7-34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
The light flashes when the engine coolant temperature is extremely high, and illumiဨ
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe place to stop the vehicle
and wait for the engine to cool down.
Illuminated light
(Red)
This indicates the possibility of overheating. Park the vehicle in a safe place immediဨ
High Engine Coolant
ately and stop the engine.
Temperature Warning
Refer to Overheating on page 7-27.
Indication/Warning
Light
CAUTION
Do not drive the vehicle with the high engine coolant temperature warning light illumi-
nated. Otherwise, it could result in damage to the engine.
The message is displayed if the electric power steering has a malfunction.
If the message is displayed, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the message in the display turns off after a
while. Contact an Authorized Mazda Dealer if the message is displayed continuously.
NOTE
If the message is displayed, the power steering will not operate normally. In this
Power Steering Malဨ
case, the steering wheel can still be operated, however, the operation may feel
function Indication*
heavy compared to normal, or the steering wheel could vibrate when turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
The light illuminates/flashes if the electric power steering has a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the light turns off after a while. Contact an Auဨ
thorized Mazda Dealer if the light illuminates/flashes continuously.
NOTE
If the indicator light illuminates/flashes, the power steering will not operate norఆ
Power Steering Malဨ
mally. If this happens, the steering wheel can still be operated, however, the operaఆ
function Indicator
tion may feel heavy compared to normal, or the steering wheel could vibrate when
Light*
turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
*Some models.
7-35
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Contact Authorized Mazda Dealer and Have Vehicle Inspected
If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.
Signal
Warning
Type A instrument cluster
(Master warning indication)
Displays when notification of the system malfunctions is required.
Check the message indicated in the display and consult an Authorized Mazda Dealer.
(Master warning light)
The master warning light displays when a warning message occurs.
This indicates a malfunction with the vehicle system. Check the message indicated in the
display and consult an Authorized Mazda Dealer.
For details, refer to the explanations for the warning/indicator lights, in the warning/indiဨ
Master Warning Inဨ
cator lights section, which match the symbol in the upper part of the display.
dication/Warning
If a message is not indicated in the display, operate the INFO switch to display the “Warnဨ
ing” screen.
Light*
Refer to Message Indicated in Multi-information Display and INFO switch on page 4-19.
Type B instrument cluster
The light illuminates continuously if any one of the following occurs. Consult an Authorဨ
ized Mazda Dealer.
There is a malfunction in the battery management system.
There is a malfunction in the brake switch.
The light turns on if the electric vacuum pump system has a problem. Have your vehicle
Electric Vacuum
inspected at an Authorized Mazda Dealer.
Pump Warning
Light
If the ABS warning light stays on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.
NOTE
ABS Warning Light
When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.
The brake assist system does not operate while the ABS warning light is illuminated.
7-36
*Some models.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
If this light illuminates while driving, the vehicle may have a problem. It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:
The engine's electrical system has a problem.
The emission control system has a problem.
Check Engine Light
The fuel tank level being very low or approaching empty.
The fuel-filler cap is missing or not tightened securely.
If the check engine light remains on, or it flashes continuously , do not drive at high
speeds and consult an Authorized Mazda Dealer as soon as possible.
The indication/light illuminates when the transmission has a problem.
CAUTION
Automatic Transဨ
mission Indication/
If the automatic transmission warning indication/light illuminates, the transmission has an
Warning Light*
electrical problem. Continuing to drive your Mazda in this condition could cause damage to
your transmission. Consult an Authorized Mazda Dealer as soon as possible.
If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
(Turns on)
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.
TCS/DSC Indicator
Light
A system malfunction is indicated if the warning light constantly flashes, constantly illuဨ
minates or does not illuminate at all when the ignition is switched ON. If any of these ocဨ
cur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident.
WARNING
Air Bag/Seat Belt
Pretensioner System
Warning Light
Never tamper with the air bag/pretensioner systems and always have an Authorized Mazda
Dealer perform all servicing and repairs:
Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner could
accidentally activate or become disabled causing serious injury or death.
*Some models.
7-37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
If the tire pressure monitoring system has a malfunction, the tire pressure warning light
flashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.
WARNING
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres-
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres-
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
(Flashing)
perform sudden maneuvering or braking. Vehicle drivability could worsen and result in an
Tire Pressure Moniဨ
accident.
toring System
To determine if you have a slow leak or a flat, pull over to a safe position where you can
Warning Light
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.
Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa-
tion that could lead to tire failure and a dangerous accident.
“Keyless System malfunction” is displayed
This message is displayed if the advanced keyless entry & push button start system has a
problem.
Contact an Authorized Mazda Dealer.
CAUTION
If the message is indicated, or the push button start indicator light (amber) flashes, the en-
gine may not start. If the engine cannot be started, try starting it using the emergency oper-
ation for starting the engine, and have the vehicle inspected at an Authorized Mazda Deal-
er as soon as possible.
(Amber)
Refer to Emergency Operation for Starting the Engine on page 4-10.
KEY Warning Indiဨ
“Ignition is on” is displayed
cation*
This message is displayed when the driver's door is opened without switching the ignition
off.
“Key not detected” is displayed
This message is displayed when any of the following operations is performed with the key
out of the operational range or placed in areas inside the cabin where it is difficult for the
key to be detected.
The push button start is pressed with the ignition switched off
The ignition is switched on
All doors are closed without switching the ignition off
7-38
*Some models.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
If any malfunction occurs in the keyless entry system, it illuminates continuously.
CAUTION
(Red)
If the key warning indicator light illuminates or the push button start indicator light (amber)
(Turns on)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
KEY Warning
emergency operation for starting the engine, and have the vehicle inspected at an Author-
Light*
ized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10.
The warning indication/warning light illuminates if there is a problem with the system.
Have your vehicle inspected at an Authorized Mazda Dealer.
The LDWS does not operate when the warning indication/warning light illuminates.
CAUTION
¾ A problem in the system may be indicated under the following conditions. Have your ve-
hicle inspected at an Authorized Mazda Dealer.
¾ When the warning indication/warning light illuminates while driving the vehicle.
When the system is canceled automatically, the warning indication/warning light illu-
(Turns on)
minates. Normally, the system restores automatically and the warning indication/
Lane Departure
warning light turns off, however, if the warning indication/warning light illuminates,
Warning System
there may be a problem with the system.
(LDWS) Warning
¾ The warning indication/warning light does not illuminate when the ignition is switch-
Indication/Warning
ed ON.
Light*
¾ Always use tires for all wheels that are of the specified size, and the same manufacture,
brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the LDWS may not operate
normally.
¾ When an emergency spare tire is used, the system may not operate normally.
NOTE
If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or obఆ
structed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.
The warning indication/warning light illuminates if there is a problem with the system.
Have your vehicle inspected at an Authorized Mazda Dealer.
(Amber)
High Beam Control
NOTE
System (HBC)
If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or obఆ
Warning Indication/
structed, the warning indication/warning light illuminates temporarily. If the warning inఆ
Warning Light*
dication/warning light illuminates, there may be a problem with the system.
*Some models.
7-39
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
The message is displayed when the system has a malfunction. Have your vehicle inspectဨ
ed by an Authorized Mazda Dealer.
Blind Spot Monitorဨ
NOTE
ing (BSM) Warning
If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
Indication*
can detect, the system may pause. However, it does not indicate a malfunction.
A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.
The light does not turn on when the ignition is switched ON.
The light remains on even when the Blind Spot Monitoring (BSM) system can be operဨ
ated.
Blind Spot Monitorဨ
The light turns on while driving the vehicle.
ing (BSM) OFF Inဨ
dicator Light*
NOTE
If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.
The message is displayed when the system has a malfunction. Have your vehicle inspectဨ
Retractable Hardtop
ed by an Authorized Mazda Dealer.
Warning Indication*
This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
LED Headlight
inspected by an Authorized Mazda Dealer.
Warning Light
Taking Action
Take the appropriate action and verify that the warning light turns off.
Signal
Warning
Action to be taken
Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is illuဨ
(Amber)
The light turns on if the windshield is dirty
minated is due to a dirty windshield, clean
or there is a malfunction in the system.
Smart City Brake Supဨ
the windshield.
port (SCBS) Warning
For any other reasons, have the vehicle inဨ
Light*
spected at an Authorized Mazda Dealer.
7-40
*Some models.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
Action to be taken
The seat belt warning light turns on if the
driver or passenger's seat is occupied and
the seat belt is not fastened with the ignition
switched ON.
If the driver or passenger's seat belt is unဨ
fastened (only when the passenger's seat is
occupied) and the vehicle is driven at a
speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but reဨ
mains illuminated.
NOTE
Fasten the seat belts.
Seat Belt Warning
The warning light flashes for about 6
Light
seconds if the driver's seat belt is not fasఆ
tened when the ignition is switched ON.
To allow the passenger occupant classifiఆ
cation sensor to function properly, do not
place and sit on an additional seat cushఆ
ion on the passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause senఆ
sor interference.
If a small child is seated on the passengఆ
er's seat, the warning light may not operఆ
ate.
The light turns on if any door/trunk lid is
Door-Ajar/Trunk
Close the door/trunk lid securely.
not closed securely.
lid-Ajar Warning Indiဨ
cation/Warning Light
The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).
NOTE
Add fuel.
Low Fuel Warning
The light illumination timing may vary beఆ
Light
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture.
If the check fuel cap warning light illumiဨ
Stop the engine and reinstall the fuel-filler
nates while driving, the fuel-filler cap may
cap.
Check Fuel Cap Warnဨ
not be installed properly.
Refer to Refueling on page 3-25
ing Light
7-41
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
Action to be taken
This warning light indicates that little washဨ
Low Washer Fluid
Add washer fluid (page 6-24).
er fluid remains.
Level Warning Indicaဨ
tion/Warning Light*
Tire Pressure Monitoring System Warning Light (Turns on)
Take the appropriate action and verify that the warning light turns off.
Warning
When the warning light illuminates, and the warning beep sound is heard when tire pressure is too low in one or
more tires.
WARNING
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, decrease vehicle speed immediately and avoid sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, it is dangerous to drive the vehicle at high speeds, or perform sudden maneuvering or braking. Vehicle
drivability could worsen and result in an accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can check the visual condition
of the tire and determine if you have enough air to proceed to a place where air may be added and the system
monitored again by an Authorized Mazda Dealer or a tire repair station.
Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have the problem taken
care of as soon as possible before it develops into a more serious situation that could lead to tire failure and a
dangerous accident.
7-42
*Some models.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Action to be taken
Inspect the tires and adjust to the specified inflation pressure (page 6-34).
CAUTION
When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the
tire pressure sensors may be damaged.
NOTE
Perform tire pressure adjustment when the tires are cold. Tire pressure will vary according to the tire temperఆ
ature, therefore let the vehicle stand for 1 hour or only drive it 1.6 km (1 mile) or less before adjusting the
tire pressures. When pressure is adjusted on hot tires to the cold inflation pressure, the TPMS warning light/
beep may turn on after the tires cool and pressure drops below specification.
Also, an illuminated TPMS warning light, resulting from the tire air pressure dropping due to cold ambient
temperature, may turn off if the ambient temperature rises. In this case, it will also be necessary to adjust the
tire air pressures. If the TPMS warning light illuminates due to a drop in tire air pressure, make sure to check
and adjust the tire air pressures.
After adjusting the tire air pressures, it may require some time for the TPMS warning light to turn off. If the
TPMS warning light remains illuminated, drive the vehicle at a speed of at least 25 km/h (16 mph) for 10
minutes, and then verify that it turns off.
Tires lose air naturally over time and the TPMS cannot tell if the tires are getting too soft over time or you
have a flat. However, when you find one low tire in a set of four-that is an indication of trouble; you should
have someone drive the vehicle slowly forward so you can inspect any low tire for cuts and any metal objects
sticking through tread or sidewall. Put a few drops of water in the valve stem to see if it bubbles indicating a
bad valve. Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous
ʊ take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order
the best replacement tire for your vehicle.
If the warning light illuminates again even after the tire pressures are adjusted, there may be a tire puncture.
7-43
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
KEY Indication (White)/KEY Warning Light (Red)
Take the appropriate action and verify that the warning light turns off.
Signal
Cause
Action to be taken
(White)
KEY Indication*
The advanced key battery is dead.
Replace the key battery (page 6-31).
(Red)
(Flashing)
KEY Warning Light*
The advanced key is not within the operaဨ
tion range.
Bring the advanced key into the operation
The advanced key is placed in areas inside
range (page 3-9).
the cabin where it is difficult for the key to
be detected.
(Red)
Take the key from another manufacturer
A key from another manufacturer similar to
(Flashing)
similar to the advanced key out of the opဨ
the advanced key is in the operation range.
KEY Warning Light*
eration range.
Without the ignition switched off, the adဨ
Bring the advanced key back into the cabဨ
vanced key is taken out of the cabin, and
in.
then all the doors are closed.
7-44
*Some models.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated in Multi-information Display*
If there is a notification from the vehicle, a message is displayed in the multi-information
display. Check the information and take the necessary action.
(Display example)
If the warning light turns on/flashes simultaneously or a symbol is indicated in the display,
check the information regarding the warning light or symbol.
Refer to If a Warning Light Turns On or Flashes on page 7-33.
Display
Content
Action to be taken
Indicated when the push button start is
pressed while the selector lever is not in
Shift the selector lever to the P position.
the P position.
Indicated when the push button start is
Depress the brake pedal and press the
pressed without depressing the brake
push button start.
pedal.
Indicated when the push button start is
Depress the clutch pedal and press the
pressed without depressing the clutch
push button start.
pedal.
*Some models.
7-45
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Display
If a message is displayed in the center display, take appropriate action (in a calm manner)
according to the displayed message.
(Display example)
Stop Vehicle in Safe Place Immediately
If the following messages are displayed in the center display, a vehicle system may be
malfunctioning. Stop the vehicle in a safe place and contact an Authorized Mazda Dealer.
Display
Indicated Condition
Displays if the engine coolant temperature has increased excessively.
Displays if the charging system has a malfunction.
7-46
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Verify Display Content
Displays in the following cases:
Display
Indicated Condition/Action to be taken
The following message is displayed when the temperature around the
center display is high.
Lowering the temperature in the cabin or the temperature around the
center display by avoiding direct sunlight is recommended.
7-47
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
The air bag and front seat belt pretensioner
Warning Sound is
system warning beep sound will continue
Activated
to be heard for approximately 35 minutes.
Have your vehicle inspected at an
Lights-On Reminder
Authorized Mazda Dealer as soon as
possible.
The lights-on reminder is operable when
the time setting*1 of the auto headlight off
WARNING
function is off.
If lights are on and the ignition is switched
Do not drive the vehicle with the air bag/
to ACC or off, a continuous beep sound
front seat belt pretensioner system warning
will be heard when the driver's door is
beep sounding:
opened.
Driving the vehicle with the air bag/front
*1
If the light switch is left on, the auto
seat belt pretensioner system warning beep
headlight off function automatically
sounding is dangerous. In a collision, the
turns off the lights about 30 seconds
air bags and the front seat belt
after switching the ignition off. The
pretensioner system will not deploy and
time setting can be changed.
this could result in death or serious injury.
Refer to the Settings section in the
Contact an Authorized Mazda Dealer to
Mazda Connect Owner's Manual.
have the vehicle inspected as soon as
NOTE
possible.
When the ignition is switched to ACC,
Seat Belt Warning Beep
the “Ignition Not Switched Off (STOP)
Except Mexico
Warning Beep” (page 7-49) overrides
the lights-on reminder.
If the driver's seat belt is not fastened
A personalized function is available to
when the ignition is switched ON, a beep
change the sound volume for the
sound will be heard for about 6 seconds. If
lights-on reminder.
the driver or the passenger's seat belt is not
Refer to the Settings section in the
fastened and the vehicle is driven at a
Mazda Connect Owner's Manual.
speed faster than about 20 km/h (12 mph),
a beep sound will be heard again for a
Air Bag/Seat Belt Pretensioner
specified period of time.
System Warning Beep
Until a seat belt is fastened or a given
If there is a problem with the air bag/front
period of time has elapsed, the beep sound
seat belt pretensioner systems and the
will not stop even if the vehicle speed falls
warning light illumination, a warning beep
below 20 km/h (12 mph).
sound will be heard for about 5 seconds
every minute.
7-48
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
NOTE
If a small child is seated on the
passenger's seat, the warning beep may
To allow the passenger occupant
not operate.
classification sensor to function
properly, do not place and sit on an
Retractable Hardtop Warning Beep*
additional seat cushion on the
When operating the retractable hardtop
passenger's seat. The sensor may not
switch, the warning beep is activated when
function properly because the additional
the retractable hardtop operation begins
seat cushion could cause sensor
and when it is completed.
interference.
If there is a problem with the retractable
If a small child is seated on the
hardtop, the warning beep is activated
passenger's seat, the warning beep may
continuously while operating the switch. If
not operate.
the warning beep is activated continuously
Mexico
while operating the switch, have the
vehicle inspected at an Authorized Mazda
If the vehicle speed exceeds about 20
Dealer.
km/h (12 mph) with the driver or
passenger's seat belt unfastened, a warning
Ignition Not Switched Off (STOP)
beep sounds continuously. If the seat belt
Warning Beep
remains unfastened, the beep sound stops
once and then continues for about 90
If the driver's door is opened with the
seconds. The beep stops after the driver or
ignition switched to ACC, a beep will be
passenger's seat belt is fastened.
heard continuously in the cabin to notify
Until a seat belt is fastened or a given
the driver that the ignition has not been
period of time has elapsed, the beep sound
switched OFF (STOP). Under this
will not stop even if the vehicle speed falls
condition, the keyless entry system will
below 20 km/h (12 mph).
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.
NOTE
Key Removed from Vehicle Warning
Placing heavy items on the passenger's
Beep
seat may cause the passenger's seat belt
warning function to operate depending
Vehicles with advanced keyless function
on the weight of the item.
If the key is taken out of the vehicle while
To allow the passenger seat weight
the ignition is not switched OFF and all
sensor to function properly, do not place
the doors are closed, the beep which
and sit on an additional seat cushion on
sounds outside of the vehicle will be heard
the passenger's seat. The sensor may not
6 times, the beep which sounds inside the
function properly because the additional
vehicle will be heard 6 times.
seat cushion could cause sensor
interference.
*Some models.
7-49
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Vehicles without advanced keyless
Key Left-in-vehicle Warning Beep
function
(With the advanced keyless
function)
If the key is taken out of the vehicle while
the ignition is not switched OFF and all
If all the doors and trunk are locked using
the doors are closed, a beep will be heard
another key while the key is left in the
in the cabin 6 times.
cabin, the beep which sounds outside of
the vehicle will be heard for about 10
NOTE
seconds to notify the driver that the key is
Because the key utilizes low-intensity
in the cabin. In this case, take out the key
radio waves, the Key Removed From
by opening the door. A key taken out of
Vehicle Warning may activate if the key is
the vehicle using this method may not
carried together with a metal object or it
operate because its functions have been
is placed in a poor signal reception area.
temporarily stopped. To restore the key's
Request Switch Inoperable Warning
functions, perform the applicable
Beep (With the advanced keyless
procedure (page 3-9).
function)
Power Steering Warning Buzzer
If the request switch is pressed with the
If the power steering system has a
door open or ajar, or the ignition is not
malfunction, the power steering
switched OFF with a key being carried, a
malfunction indication/malfunction
beep will be heard outside for about 2
indicator light turns on or flashes and the
seconds to notify the driver that the door
buzzer operates at the same time.
or trunk lid cannot be locked.
Refer to Stop Vehicle in Safe Place
Key Left-in-trunk Compartment
Immediately on page 7-33.
Warning Beep (With the advanced
Tire Inflation Pressure Warning
keyless function)
Beep
If the key is left in the trunk with all the
The warning beep sound will be heard for
doors locked and the trunk lid closed, a
about 3 seconds if the tire pressures
beep will be heard outside for about 10
decrease.
seconds to notify the driver that the key is
Refer to Tire Pressure Monitoring System
in the trunk. In this case, take out the key
on page 4-114.
by pressing the electric trunk lid opener
and opening the trunk lid. The key taken
Blind Spot Monitoring (BSM)
out of the trunk may not operate because
Warning Beep*
its functions have been temporarily
stopped. To restore the key's functions,
Driving forward
perform the applicable procedure (page
The warning beep operates when the turn
3-9).
signal lever is operated to the side where
the Blind Spot Monitoring (BSM) warning
light is illuminated.
7-50
*Some models.















Content      ..     11      12      13      14     ..
