Maintenance and Care
Owner Maintenance
NOTE
Before performing battery
Always keep batteries out of
maintenance, remove the battery
the reach of children:
cover.
Allowing children to play near batteries
is dangerous. Battery fluid could cause
serious injuries if it gets in the eyes or
on the skin.
Keep flames and sparks away
from open battery cells and do not
allow metal tools to contact the
positive (+) or negative (-) terminal of
the battery when working near a
battery. Do not allow the positive (+)
Battery Maintenance
terminal to contact the vehicle body:
Flames and sparks near open battery
cells are dangerous. Hydrogen gas,
produced during normal battery
operation, could ignite and cause the
battery to explode. An exploding
battery can cause serious burns and
injuries. Keep all flames including
cigarettes and sparks away from open
battery cells.
To get the best service from a battery:
Keep all flames and sparks
Keep it securely mounted.
away from open battery cells because
Keep the top clean and dry.
hydrogen gas is produced from open
Keep terminals and connections
battery cells while charging the
clean, tight, and coated with
battery or adding battery fluid:
petroleum jelly or terminal grease.
Flames and sparks near open battery
Rinse off spilled electrolyte
cells are dangerous. Hydrogen gas,
immediately with a solution of water
produced during normal battery
and baking soda.
operation, could ignite and cause the
If the vehicle will not be used for an
battery to explode. An exploding
extended time, disconnect the
battery can cause serious burns and
battery cables and charge the battery
injuries. Keep all flames including
every 6 weeks.
cigarettes and sparks away from open
battery cells.
Battery Replacement
Contact an Authorized Mazda Dealer
for battery replacement.
6-28
Maintenance and Care
Owner Maintenance
The system does not operate and the
Key Battery Replacement
operation indicator light on the
transmitter does not flash when the
Key Battery Replacement
buttons are pressed.
If the buttons on the transmitter are
The system's operational range is
inoperable and the operation indicator
reduced.
light does not flash, the battery may be
Incorrect battery replacement
dead.
operation may damage the key.
Replace with a new battery before the
Replacing the battery at an Authorized
transmitter becomes unusable.
Mazda Dealer is recommended. If
replacing the battery by yourself,
CAUTION
follow the instruction.
¾ Make sure the battery is installed
Replacing the key battery
correctly. Battery leakage could occur
if it is not installed correctly.
1.
Remove the lower cover while
¾ When replacing the battery, be
sliding the knob in the direction of
careful not to touch any of the
the arrow.
internal circuitry and electrical
terminals, bend the electrical
terminals, or get dirt in the
transmitter as the transmitter could
be damaged.
¾ There is the danger of explosion if
the battery is not correctly replaced.
¾ Dispose of used batteries according
to the following instructions.
2.
Press in the tab to unlock the upper
¾ Insulate the plus and minus
cover.
terminals of the battery using
cellophane or equivalent tape.
¾ Never disassemble.
¾ Never throw the battery into fire or
water.
¾ Never deform or crush.
¾ Replace only with the same type
battery (CR2032 or equivalent).
The following conditions indicate that
the battery power is low:
A message, “Low Key Fob Battery.
Replace Battery” is displayed on the
multi-information display when the
ignition is switched OFF.
6-29
Maintenance and Care
Owner Maintenance
3. Insert a tape-wrapped flathead
7. Insert a new battery into the
screwdriver into the gap and slide it
transmitter so that the positive pole
in the direction of the arrow.
is facing up.
8. Install the cap.
9. Install the upper cover.
4. Twist the flathead screwdriver in the
direction of the arrow and remove
the upper cover.
10.Insert the tabs of the lower cover
5. Remove the cap using the
into the slots of the transmitter and
tape-wrapped flathead screwdriver.
install the lower cover.
6. Remove the battery using
tape-wrapped flathead screwdriver.
6-30
Maintenance and Care
Owner Maintenance
Use only a Mazda-genuine tire valve
Tires
cap:
Use of a non-genuine part is
Tires
dangerous as the correct tire air
For reasons of proper performance,
pressure cannot be maintained if the
safety, and better fuel economy, always
tire valve becomes damaged. If the
maintain recommended tire inflation
vehicle is driven under this condition,
pressures and stay within the
the tire air pressure will decrease
recommended load limits and weight
which could result in a serious
distribution.
accident. Do not use any part for the
tire valve cap that is not a
WARNING
Mazda-genuine part.
Inspect all tire pressures monthly
Using Different Tire Types:
(including the spare) when the tires are
Driving your vehicle with different
cold. Maintain recommended
types of tires is dangerous. It could
pressures for the best ride, handling,
cause poor handling and poor braking;
and minimum tire wear.
leading to loss of control.
Refer to the specification charts (page
Except for the limited use of the
9-8).
temporary spare tire, use only the
same type tires (radial, bias-belted,
NOTE
bias-type) on all four wheels.
Always check tire pressure when tires
are cold.
Using Wrong-Sized Tires:
Warm tires normally exceed
Using any other tire size than what is
recommended pressures. Do not
specified for the vehicle (page 9-8)
release air from warm tires to adjust
is dangerous. It could seriously affect
the pressure.
ride, handling, ground clearance, tire
Underinflation can cause reduced
clearance, and speedometer
fuel economy, uneven and
calibration. This could cause you to
accelerated tire wear, and poor
have an accident. Use only tires that
sealing of the tire bead, which will
are the correct size specified for the
deform the wheel and cause
vehicle.
separation of tire from rim.
Tire Inflation Pressure
Overinflation can produce a harsh
ride, uneven and accelerated tire
wear, and a greater possibility of
WARNING
damage from road hazards.
Keep your tire pressure at the correct
Always inflate the tires to the correct
levels. If one frequently needs
pressure:
inflating, have it inspected.
Overinflation or underinflation of tires
is dangerous. Adverse handling or
unexpected tire failure could result in a
serious accident.
Refer to Tires on page 9-8.
6-31
Maintenance and Care
Owner Maintenance
Tire Rotation
CAUTION
Rotate unidirectional tires and radial
WARNING
tires that have an asymmetrical tread
pattern or studs only from front to rear,
Rotate tires periodically:
not from side to side. Tire performance
Irregular tire wear is dangerous. To
will be reduced if rotated from side to
equalize tread wear for maintaining
side.
good performance in handling and
braking, rotate the tires periodically or
Replacing a Tire
sooner if irregular wear develops.
Please refer to Scheduled maintenance
WARNING
for your tire rotation interval.
During rotation, inspect them for
Always use tires that are in good
correct balance.
condition:
Driving with worn tires is dangerous.
Reduced braking, steering, and
traction could result in an accident.
Replace all four tires at the same
time:
Replacing just one tire is dangerous. It
could cause poor handling and poor
braking resulting in loss of vehicle
control. Mazda strongly recommends
1. Forward
that you replace all four tires at the
Do not include (TEMPORARY USE
same time.
ONLY) spare tire in rotation.
If a tire wears evenly, a wear indicator
will appear as a solid band across the
Also, inspect them for uneven wear
tread.
and damage. Abnormal wear is usually
Replace the tire when this happens.
caused by one or a combination of the
following:
Incorrect tire pressure
Improper wheel alignment
Out-of-balance wheel
Severe braking
After rotation, inflate all tire pressures
to specification on page 9-8 and
inspect the lug nuts for tightness.
1. New tread
2. Worn tread
6-32
Maintenance and Care
Owner Maintenance
3. Tread wear indicator
CAUTION
You should replace the tire before the
¾ Do not use your temporary spare tire
band crosses the entire tread.
rim with a snow tire or a
conventional tire. Neither will
NOTE
properly fit and could damage both
Tires degrade over time, even when
tire and rim.
they are not being used on the road. It
¾ The temporary spare tire has a tread
is recommended that tires generally be
life of less than 5,000 km (3,000
replaced when they are 6 years or
miles). The tread life may be shorter
older. Heat caused by hot climates or
depending on driving conditions.
frequent high loading conditions can
¾ The temporary spare tire is for
accelerate the aging process. You
limited use, however, if the tread
should replace the spare tire when you
wear solid-band indicator appears,
replace the other road tires due to the
replace the tire with the same type of
aging of the spare tire. The period in
temporary spare (page 6-32).
which the tire was manufactured (both
week and year) is indicated by a 4-digit
NOTE
number.
Refer to Tire Labeling on page 8-23.
Tires degrade over time, even when
they are not being used on the road. It
Temporary Spare Tire
is recommended that tires generally be
replaced when they are 6 years or
Inspect the temporary spare tire at
older. Heat caused by hot climates or
least monthly to make sure it is
frequent high loading conditions can
properly inflated and stored.
accelerate the aging process. You
NOTE
should replace the spare tire when you
The temporary spare tire condition
replace the other road tires due to the
gradually deteriorates even if it has not
aging of the spare tire. The period in
been used.
which the tire was manufactured (both
week and year) is indicated by a 4-digit
The temporary spare tire is easier to
number.
handle because of its construction
Refer to Tire Labeling on page 8-23.
which is lighter and smaller than a
conventional tire. This tire should be
Replacing a Wheel
used only for an emergency and only
for a short distance.
WARNING
Use the temporary spare tire only until
Always use wheels of the correct size
the conventional tire is repaired, which
on your vehicle:
should be as soon as possible.
Using a wrong-sized wheel is
Refer to Tires on page 9-8.
dangerous. Braking and handling could
be affected, leading to loss of control
and an accident.
6-33
Maintenance and Care
Owner Maintenance
CAUTION
Light Bulbs
A wrong-sized wheel may adversely
Light Bulbs
affect:
Front
¾ Tire fit
¾ Wheel and bearing life
¾ Ground clearance
¾ Snow-chain clearance
¾ Speedometer calibration
¾ Headlight aim
¾ Bumper height
¾ Tire Pressure Monitoring System
NOTE
1. Vanity mirror lights*
2. Front overhead lights/Front map
When replacing a wheel, make sure
the new one is the same as the
lights
original factory wheel in diameter,
3. Side turn signal lights*
rim width, and offset (inset/outset).
4. Front side-marker lights
For details, contact an Authorized
5. Front turn signal lights/Parking
Mazda Dealer.
lights
6. Headlights (High/Low beam)/
Daytime running lights
Proper tire balancing provides the best
riding comfort and helps reduce tread
Rear
wear. Out-of-balance tires can cause
vibration and uneven wear, such as
cupping and flat spots.
1. Luggage compartment light
2. High-mount brake light
3. Rear overhead light
4. Rear side-marker lights
5. Taillights*
6. Rear turn signal lights
7. Brake lights/Taillights
8. Taillights (Liftgate side)*
9. Reverse lights
10.License plate lights
6-34
*Some models.
Maintenance and Care
Owner Maintenance
Replacing Light Bulbs
Fuses
All the light bulbs are the LED type.
Fuses
The LED bulb cannot be replaced as a
single unit because it is an integrated
Your vehicle's electrical system is
unit.
protected by fuses.
The LED bulb has to be replaced with
the unit. If a replacement is necessary,
If any lights, accessories, or controls do
consult an Authorized Mazda Dealer.
not work, inspect the appropriate
circuit protector. If a fuse has blown,
the inside element will be melted.
If the same fuse blows again, avoid
using that system and consult an
Authorized Mazda Dealer as soon as
possible.
Fuse Replacement
Replacing the fuses on the vehicle's
left side
If the electrical system does not work,
first inspect the fuses on the vehicle's
left side.
1. Make sure the ignition is switched
off, and other switches are off.
2. Open the fuse panel cover.
6-35
Maintenance and Care
Owner Maintenance
3. Pull the fuse straight out with the
Replacing the fuses under the hood
fuse puller provided on the fuse
If the headlights or other electrical
block located in the engine
components do not work and the fuses
compartment.
in the cabin are normal, inspect the
fuse block under the hood.
If a fuse is blown, it must be replaced.
Follow these steps:
1. Make sure the ignition is switched
off, and other switches are off.
2. Remove the fuse block cover.
4. Inspect the fuse and replace it if it is
blown.
1. Normal
3. If any fuse but the MAIN fuse is
2. Blown
blown, replace it with a new one of
the same amperage rating.
5. Insert a new fuse of the same
amperage rating, and make sure it
fits tightly. If it does not fit tightly,
have an expert install it. Consult an
Authorized Mazda Dealer.
If you have no spare fuses, borrow
one of the same rating from a
circuit not essential to vehicle
operation, such as the audio or
1. Normal
accessory socket circuit.
2. Blown
CAUTION
Always replace a fuse with a
genuine Mazda fuse or equivalent
of the same rating. Otherwise, you
may damage the electric system.
6. Reinstall the cover and make sure
that it is securely installed.
6-36
Maintenance and Care
Owner Maintenance
WARNING
Do not replace the main fuse by
yourself. Have an Authorized
Mazda Dealer perform the
replacement:
Replacing the fuse by yourself is
dangerous because the MAIN fuse
is a high current fuse. Incorrect
replacement could cause an
electrical shock or a short circuit
resulting in a fire.
4. Reinstall the cover and make sure
that it is securely installed.
6-37
Maintenance and Care
Owner Maintenance
Fuse Panel Description
Fuse block (Engine compartment)
FUSE RAT-
No.
PROTECTED COMPONENT
ING
F1
F2
20 A
Windshield wiper de-icer*
F3
30 A
Engine control system
F4
20 A
S-VT
F5
40 A
Engine control system
F6
F7
20 A
Fuel pump
6-38
*Some models.
Maintenance and Care
Owner Maintenance
FUSE RAT-
No.
PROTECTED COMPONENT
ING
F8
15 A
Engine control system
F9
15 A
Transmission control system
F10
15 A
Engine control system
F11
7.5 A
Air conditioner
F12
15 A
Engine control system
F13
F14
20 A
Front seat warmer*
F15
F16
15 A
For protection of various circuits
F17
F18
15 A
For protection of various circuits
F19
60 A
Power steering system
F20
15 A
Headlight (LH) 1
F21
15 A
Headlight (RH) 1
F22
15 A
Keyless system
F23
30 A
ABS, Dynamic stability control system
F24
15 A
Headlight (LH) 2
F25
15 A
Headlight (RH) 2
F26
7.5 A
On board diagnostics
F27
25 A
For protection of various circuits
F28
25 A
For protection of various circuits
F29
15 A
Windshield washer
F30
15 A
Accessory sockets
F31
15 A
Horn
F32
15 A
Headlights
F33
F34
F35
50A
ABS, Dynamic stability control system
F36
F37
40 A
Rear window defogger
F38
50 A
For protection of various circuits
F39
F40
40 A
Air conditioner
*Some models.
6-39
Maintenance and Care
Owner Maintenance
FUSE RAT-
No.
PROTECTED COMPONENT
ING
F41
F42
20 A
Windshield wipers
F43
30 A
Cooling fan*
F44
30 A
Starter
F45
10 A
Engine control system
F46
15 A
Audio
F47
15 A
For protection of various circuits
F48
7.5 A
Air bag
F49
15 A
Instrument cluster
F50
15 A
Room light
F51
25 A
Audio
F52
10 A
Moonroof*
F53
15 A
Engine control system
F54
15 A
i-ACTIVSENSE
F55
F56
15 A
Electric water pump*
6-40
*Some models.
Maintenance and Care
Owner Maintenance
Fuse block (Left side)
FUSE RAT-
No.
PROTECTED COMPONENT
ING
F1
F2
F3
F4
15 A
Power door locks (Driver)
F5
15 A
Power door locks (Passenger)
F6
F7
25 A
Power liftgate*
F8
F9
30 A
Power windows (Driver)
F10
30 A
Power windows (Passenger)
F11
30 A
Power seat (Driver)*
F12
F13
15 A
Audio
F14
F15
15 A
Liftgate lock
*Some models.
6-41
Maintenance and Care
Owner Maintenance
FUSE RAT-
No.
PROTECTED COMPONENT
ING
F16
15 A
Illumination
F17
10 A
Brake lights
F18
10 A
Reverse lights
F19
10 A
Rear turn signal lights
F20
10 A
Taillights
F21
10 A
Taillights
F22
7.5 A
Air bag*
F23
6-42
*Some models.
Maintenance and Care
Appearance Care
Damage Caused by Bird Dropping,
Exterior Care
Insects, or Tree Sap
Exterior Care
Occurrence
The paintwork on your Mazda
Bird droppings contain acids. If these
represents the latest technical
are not removed they can eat away the
developments in composition and
clear and color base coat of the
methods of application.
vehicle's paintwork.
Environmental hazards, however, can
When insects stick to the paint surface
harm the paint's protective properties,
and decompose, corrosive compounds
if proper care is not taken.
form. These can erode the clear and
color base coat of the vehicle's
Here are some examples of possible
paintwork if they are not removed.
damage, with tips on how to prevent
them.
Tree sap will harden and adhere
permanently to the paint finish. If you
Etching Caused by Acid Rain or
scratch the sap off while it is hard,
Industrial Fallout
some vehicle paint could come off
Occurrence
with it.
Industrial pollutants and vehicle
Prevention
emissions drift into the air and mix
It is necessary to have your Mazda
with rain or dew to form acids. These
washed and waxed to preserve its
acids can settle on a vehicle's finish. As
finish according to the instructions in
the water evaporates, the acid
this section. This should be done as
becomes concentrated and can
soon as possible.
damage the finish.
And the longer the acid remains on the
Bird droppings can be removed with a
surface, the greater the chance is for
soft sponge and water. If you are
damage.
traveling and these are not available, a
Prevention
moistened tissue may also take care of
the problem. The cleaned area should
It is necessary to wash and wax your
be waxed according to the instructions
vehicle to preserve its finish according
in this section.
to the instructions in this section.
Insects and tree sap are best removed
These steps should be taken
with a soft sponge and water or a
immediately after you suspect that acid
commercially available chemical
rain has settled on your vehicle's finish.
cleaner.
Another method is to cover the
affected area with dampened
newspaper for 1 to 2 hours. After
removing the newspaper, rinse off the
loosened debris with water.
6-43
Maintenance and Care
Appearance Care
Water Marks
Chipped paint can lead to rust
forming on your Mazda. Before this
Occurrence
happens, repair the damage by using
Rain, fog, dew, and even tap water can
Mazda touch-up paint according to
contain harmful minerals such as salt
the instructions in this section.
and lime. If moisture containing these
Failure to repair the affected area
minerals settles on the vehicle and
could lead to serious rusting and
evaporates, the minerals will
expensive repairs.
concentrate and harden to form white
rings. The rings can damage your
Follow all label and container
vehicle's finish.
directions when using a chemical
Prevention
cleaner or polish. Read all warnings
and cautions.
It is necessary to wash and wax your
vehicle to preserve its finish according
Maintaining the Finish
to the instructions in this section.
Washing
These steps should be taken
immediately after you find water marks
on your vehicle's finish.
CAUTION
Paint Chipping
¾ Before lifting the windshield wiper
blades off the windshield, always
Occurrence
follow the procedure for moving the
Paint chipping occurs when gravel
windshield wiper blades. Otherwise,
thrown in the air by another vehicle's
a wiper blade, wiper arm, or the
tires hits your vehicle.
hood could be damaged.
Refer to the Replacing Windshield
How to avoid paint chipping
Wiper Blades (page 6-22) section for
Keeping a safe distance between you
the procedure on how to move the
and the vehicle ahead reduces the
windshield wiper blades to the
chances of having your paint chipped
service position.
by flying gravel.
¾ When the ignition is switched ON
and the wiper lever is in the AUTO
NOTE
position, the windshield wipers may
The paint chipping zone varies with
operate automatically in the
the speed of the vehicle. For
following cases:
example, when traveling at 90 km/h
(56 mph), the paint chipping zone is
¾ The area of the windshield above
the rain sensor is touched or wiped
50 m (164 ft).
In low temperatures a vehicle's finish
with a cloth.
¾ The windshield or the rain sensor
hardens. This increases the chance of
paint chipping.
area in the cabin is hit.
6-44
Maintenance and Care
Appearance Care
When the ignition is switched ON
The vehicle is washed with a rough,
and the wiper lever is in the AUTO
dry, or dirty cloth.
position, do not touch the
The vehicle is washed at a car wash
windshield or the windshield wipers
that uses brushes that are dirty or too
Otherwise, the windshield wipers
stiff.
will operate automatically which
Cleansers or wax containing
could catch your fingers or damage
abrasives are used.
the windshield wipers.
When removing ice or snow, or
NOTE
cleaning the windshield, always
Mazda is not responsible for
make sure the wiper lever is in the
scratches caused by automatic car
OFF position.
washes or improper washing.
¾ Do not spray water in the engine
Scratches are more noticeable on
compartment. Otherwise, it could
vehicles with darker paint finishes.
result in engine-starting problems or
To minimize scratches on the vehicle's
damage to electrical parts.
paint finish:
¾ When washing and waxing the
vehicle, be careful not to apply
Rinse off any dirt or other foreign
excessive force to any single area of
matter using lukewarm or cold water
the vehicle roof or the antenna.
before washing.
Otherwise, you could dent the
Use plenty of lukewarm or cold
vehicle or damage the antenna.
water and a soft cloth when washing
¾ Make sure that the fuel-filler lid is
the vehicle. Do not use a nylon cloth.
closed and lock the doors.
Rub gently when washing or drying
Otherwise, the fuel-filler lid may be
the vehicle.
forcefully opened by water pressure
Take your vehicle only to a car wash
causing damage to the vehicle or
that keeps its brushes well
fuel-filler lid.
maintained.
Do not use abrasive cleansers or wax
To help protect the finish from rust and
that contain abrasives.
deterioration, wash your Mazda
thoroughly and frequently, at least
once a month, with lukewarm or cold
CAUTION
water.
¾ Do not use steel wool, abrasive
cleaners, or strong detergents
If the vehicle is washed improperly, the
containing highly alkaline or caustic
paint surface could be scratched. Here
agents on chrome-plated or
are some examples of how scratching
anodized aluminum parts. This may
could occur.
damage the protective coating; also,
cleaners and detergents may discolor
Scratches occur on the paint surface
or deteriorate the paint.
when:
Pay special attention to removing salt,
The vehicle is washed without first
dirt, mud, and other foreign material
rinsing off dirt and other foreign
from the underside of the fenders, and
matter.
make sure the drain holes in the lower
6-45
Maintenance and Care
Appearance Care
edges of the doors and rocker panels
force of the spray could damage or
are clean.
deform the molding, affect the
sealability of parts, and allow water to
Insects, tar, tree sap, bird droppings,
penetrate the interior. Keep a sufficient
industrial fallout, and similar deposits
space (30 cm (12 in) or more)
can damage the finish if not removed
between the nozzle and the vehicle. In
immediately. When prompt washing
addition, do not spend too much time
with plain water is ineffective, use a
spraying the same area of the vehicle,
mild soap made for use on vehicles.
and be very careful when spraying
between gaps in doors and around
Thoroughly rinse off all soap with
windows.
lukewarm or cold water. Do not allow
Waxing
soap to dry on the finish.
Your vehicle needs to be waxed when
After washing the vehicle, dry it with a
water no longer beads on the finish.
clean chamois to prevent water spots
Always wash and dry the vehicle before
from forming.
waxing it. In addition to the vehicle
body, wax the metal trim to maintain
WARNING
its luster.
Dry off brakes that have become wet
1. Use wax which contains no
by driving slowly, releasing the
abrasives.
accelerator pedal and lightly applying
Wax containing abrasives will
the brakes several times until the
remove paints and could damage
brake performance returns to normal:
bright metal parts.
Driving with wet brakes is dangerous.
2. Use a good grade of natural wax for
Increased stopping distance or the
metallic, mica, and solid colors.
vehicle pulling to one side when
3. When waxing, coat evenly with the
braking could result in a serious
sponge supplied or a soft cloth.
accident. Light braking will indicate
4. Wipe off the wax with a soft cloth.
whether the brakes have been
NOTE
affected.
A spot remover to remove oil, tar, and
When using an automatic car wash
similar materials will usually also take
off the wax. Rewax these areas even if
Retract the door mirrors.
the rest of the vehicle does not need it.
The automatic car wash brushes
could reduce the paint luster or
Repairing Damage to the Finish
hasten paint deterioration.
Deep scratches or chips on the finish
When using a high water pressure car
should be repaired promptly. Exposed
wash
metal quickly rusts and can lead to
major repairs.
High water temperature and high
water pressure car washers are
available depending on the type of car
wash machine. If the car washer nozzle
is put too close to the vehicle, the
6-46
Maintenance and Care
Appearance Care
even though these parts may be coated
CAUTION
with anti-corrosive material.
If your Mazda is damaged and needs
metal parts repaired or replaced, make
Thoroughly flush the underbody and
sure the body shop applies
wheel housings with lukewarm or cold
anti-corrosion materials to all parts,
water at the end of each winter. Try
both repaired and new. This will
also to do this every month.
prevent them from rusting.
Pay special attention to these areas
Bright-Metal Maintenance
because they easily hide mud and dirt.
It will do more harm than good to wet
Use tar remover to remove road tar
down the road grime without
and insects. Never do this with a
removing it.
knife or similar tool.
To prevent corrosion on bright-metal
The lower edges of doors, rocker
surfaces, apply wax or chrome
panels, and frame members have drain
preservative and rub it to a high
holes that should not be clogged.
luster.
Water trapped there will cause rusting.
During cold weather or in coastal
areas, cover bright-metal parts with a
WARNING
coating of wax or preservative
heavier than usual. It would also help
to coat them with noncorrosive
Dry off brakes that have become wet
petroleum jelly or some other
by driving slowly, releasing the
protective compound.
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to normal:
CAUTION
Driving with wet brakes is dangerous.
Increased stopping distance or the
Do not use steel wool, abrasive
vehicle pulling to one side when
cleaners, or strong detergents
braking could result in a serious
containing highly alkaline or caustic
accident. Light braking will indicate
agents on chrome-plated or anodized
whether the brakes have been
aluminum parts. This may result in
affected.
damage to the protective coating and
cause discoloration or paint
Aluminum Wheel Maintenance*
deterioration.
A protective coating is provided over
Underbody Maintenance
the aluminum wheels. Special care is
needed to protect this coating.
Road chemicals and salt used for ice
and snow removal and solvents used
CAUTION
for dust control may collect on the
underbody. If not removed, they will
Do not use any detergent other than
speed up rusting and deterioration of
mild detergent. Before using any
such underbody parts as fuel lines,
detergent, verify the ingredients.
frame, floor pan, and exhaust system,
Otherwise, the product could discolor
or stain the aluminum wheels.
*Some models.
6-47
Maintenance and Care
Appearance Care
NOTE
it could deform plastic parts or
damage the paint.
Do not use a wire brush or any
Do not use wax containing
abrasive cleaner, polishing
compounds (polish). Otherwise, it
compound, or solvent on aluminum
could result in paint damage.
wheels. They may damage the
In addition, do not use an electrical
coating.
or air tool to apply wax. Otherwise,
Always use a sponge or soft cloth to
the frictional heat generated could
clean the wheels.
result in deformation of plastic parts
Rinse the wheels thoroughly with
or paint damage.
lukewarm or cold water. Also, be
sure to clean the wheels after driving
on dusty or salted roads to help
prevent corrosion.
Avoid washing your vehicle in an
automatic car wash that uses
high-speed or hard brushes.
Plastic Part Maintenance
When cleaning the plastic lenses of
the lights, do not use gasoline,
kerosene, rectified spirit, paint,
thinner, highly acidic detergents, or
strongly alkaline detergents.
Otherwise, these chemical agents
can discolor or damage the surfaces
resulting in a significant loss in
functionality. If plastic parts become
inadvertently exposed to any of these
chemical agents, flush with water
immediately.
If plastic parts such as the bumpers
become inadvertently exposed to
chemical agents or fluids such as
gasoline, oil, engine coolant, or
battery fluid, it could cause
discoloration, staining, or paint
peeling. Wipe off any such chemical
agents or fluids using a soft cloth
immediately.
High water temperature and high
water pressure car washers are
available depending on the type of
high pressure car washer device. If
the car washer nozzle is put too
close to the vehicle or aimed at one
area for an extended period of time,
6-48
Maintenance and Care
Appearance Care
Seat Belt Maintenance
Interior Care
1. Clean the soiled area by lightly
Interior Care
dabbing it with a soft cloth soaked
in a mild detergent (approx. 5%)
WARNING
diluted with water.
2. Wipe off the remaining detergent
using a cloth soaked in clean water
Do not spray water into the vehicle
and wrung out well.
cabin:
3. Before retracting seat belts which
Spraying water into the vehicle cabin is
have been pulled out for cleaning,
dangerous as electrical devices such as
dry them off thoroughly and make
the audio and switches could get wet
sure there is no remaining moisture
resulting in a malfunction or vehicle
on them.
fire.
WARNING
NOTE
Do not wipe the interior using
If a seat belt appears frayed or has
alcohol, chlorine bleach, or organic
abrasions, have it replaced by an
solvents such as thinner, benzene,
Authorized Mazda Dealer:
and gasoline. Otherwise, it may
If a seat belt is used under such a
cause discoloration or stains.
condition, it cannot function at its full
Rubbing hard with a stiff brush or
capacity which could result in serious
cloth may cause damage.
injury or death.
If the vehicle interior becomes soiled
Use a mild detergent to remove
by any of the following, wipe it off
soiling from a seat belt:
immediately using a soft cloth.
If organic solvents are used for cleaning
Leaving it uncleaned could cause
the seat belts or they become stained
discoloration, stains, cracks, or peeling
or bleached, there is the possibility of
of the coating, and it will make it hard
them becoming weakened and as a
to wipe off later.
result, they may not function at their
Beverage or fragrance
full capacity which could cause serious
Grease or oil
injury or death.
Soiling
NOTE
Clean seat belts diligently if they get
dirty. Leaving them uncleaned will
make it difficult to clean them later,
and it may affect the smooth retracting
of the seat belt.
6-49
Maintenance and Care
Appearance Care
Vinyl Upholstery Maintenance
If the leather upholstery comes into
contact with any of the following,
Remove dust and dirt from the vinyl
clean it immediately.
upholstery using a brush or vacuum.
Leaving it uncleaned could cause
Remove soiling from vinyl upholstery
premature wear, mold, or stains.
using a leather and vinyl upholstery
cleaner.
Sand or dirt
Grease or oil, such as hand cream
Upholstery Maintenance
Alcohol, such as in cosmetic or
hair dressing items
1.
Clean the soiled area by lightly
If the leather upholstery gets wet,
dabbing it with a soft cloth soaked
promptly remove moisture with a dry
in a mild detergent (approx. 5%)
cloth. Remaining moisture on the
diluted with water.
surface may cause deterioration such
2.
Wipe off the remaining detergent
as hardening and shrinkage.
using a cloth soaked in clean water
Exposure to direct sunlight for long
and wrung out well.
periods may cause deterioration and
Leather Upholstery Maintenance*
shrinkage. When parking the car
under direct sunlight for long
1.
Remove dust and sand using a
periods, shade the interior using
vacuum cleaner.
sunshades.
2.
Wipe off the soiled area with a soft
Do not leave vinyl products on the
cloth and a suitable, special cleaner
leather upholstery for long periods.
or a soft cloth soaked in a mild
They may affect the leather quality
detergent (about 5%) diluted with
and coloring. If the cabin
water.
temperature becomes hot, the vinyl
3.
Wipe off the remaining detergent
may deteriorate and adhere to the
using a cloth soaked in clean water
genuine leather.
and wrung out well.
4.
Remove moisture with a dry, soft
Plastic Part Maintenance
cloth and allow the leather to
further dry in a well-ventilated,
CAUTION
shaded area. If the leather gets wet
such as from rain, remove the
Do not use polishing agents.
moisture and dry it as soon as
Depending on the product ingredients,
possible.
they could cause discoloration, stains,
cracks or peeling of the coating.
NOTE
Because genuine leather is a natural
Instrument Panel Top (Soft pad)
material, its surface is not uniform
Maintenance
and it may have natural scars,
Extremely soft material is used for the
scratches, and wrinkles.
soft pad surface. If the soft pad surface
To maintain the quality for as long as
is rubbed harshly with a dry cloth, it
possible, periodical maintenance,
could result in the surface being
about twice a year, is recommended.
damaged and leaving white scratch
marks.
6-50
*Some models.
Maintenance and Care
Appearance Care
1. Wipe the soiled area with a soft
Cleaning the Window Interiors
cloth soaked in a mild detergent
If the windows become covered with
(approx. 5%) diluted with water.
an oily, greasy, or waxy film, clean
2. Wipe off the remaining detergent
them with glass cleaner. Follow the
using a cloth soaked in clean water
directions on the container.
and wrung out well.
Active Driving Display
CAUTION
Maintenance*
¾ Do not scrape or scratch the inside
The dust-proof sheet has a coating.
of the window glass. It could
When cleaning, do not use a hard or
damage the thermal filaments and
rough-surface cloth, or cleaning
the antenna lines.
detergent. In addition, if a chemical
¾ When washing the inside of the
solvent gets on the active driving
window glass, use a soft cloth
display, wipe it off immediately. The
dampened in lukewarm water, gently
dust-proof sheet could be damaged
wiping the thermal filaments and the
and the surface coating could be
antenna lines.
scratched. Use a fine, soft cloth such as
Use of glass cleaning products could
those used for cleaning eyeglasses.
damage the thermal filaments and
the antenna lines.
NOTE
Use of compressed air when cleaning
Cleaning the Floor Mats
the dust-proof sheet is recommended.
Rubber floor mats should be cleaned
Panel Maintenance
with mild soap and water only.
If a panel becomes soiled, wipe it off
WARNING
with a soft cloth soaked in clean water
and thoroughly wrung out.
Do not use rubber cleaners, such as
If some areas require further cleaning,
tire cleaner or tire shine, when
use the following procedure:
cleaning rubber floor mats:
1. Wipe the soiled area with a soft
Cleaning the rubber floor mats with
cloth soaked in a mild detergent
rubber cleaning products makes the
(approx. 5 %) diluted with water.
floor mats slippery.
2. Wipe off the remaining detergent
This may cause an accident when
using a cloth soaked in clean water
depressing the accelerator or brake
and wrung out well.
pedal or when getting in or out of the
NOTE
vehicle.
Be particularly careful when cleaning
After removing the floor mats for
shiny surface panels and metallic parts
cleaning, always reinstall them securely
such as plating as they can be
(page 3-52).
scratched easily.
*Some models.
6-51
MEMO
6-52
If Trouble Arises
7
Helpful information on what to do if a problem arises with the
vehicle.
Parking in an Emergency
7-2
Warning/Indicator Lights and
Parking in an Emergency
7-2
Warning Sounds
7-22
If a Warning Light Turns On or
Flashes
7-22
Flat Tire
7-3
Message Indicated on Multi-
Spare Tire and Tool Storage
information Display
7-35
............................................ 7-3
Warning Sound is
Changing a Flat Tire
7-5
Activated
7-38
Battery Runs Out
7-13
When Liftgate Cannot be
Jump-Starting
7-13
Opened
7-44
When Liftgate Cannot be
Emergency Starting
7-16
Opened
7-44
Starting a Flooded Engine
7-16
Push-Starting
7-16
Active Driving Display Does Not
Operate
7-45
Overheating
7-17
If the Active Driving Display Does
Overheating
7-17
Not Operate*
7-45
Emergency Towing
7-19
Windshield Wipers Operate at High
Towing Description
7-19
Speed
7-46
Tiedown Hooks*
7-20
Windshield Wipers Operate at
High Speed
7-46
*Some models.
7-1
If Trouble Arises
Parking in an Emergency
Parking in an Emergency
Parking in an Emergency
The hazard warning lights should
always be used when you stop on or
near a roadway in an emergency.
The hazard warning lights warn other
drivers that your vehicle is a traffic
hazard and that they must take
extreme caution when near it.
Depress the hazard warning flasher
and all the turn signals will flash. The
hazard warning indicator lights in the
instrument cluster flash simultaneously.
NOTE
The turn signals do not work when
the hazard warning lights are on.
Check local regulations about the
use of hazard warning lights while
the vehicle is being towed to verify
that it is not in violation of the law.
7-2
If Trouble Arises
Flat Tire
Jack
Spare Tire and Tool
To remove the jack
Storage
1. Remove the luggage mat.
Spare Tire and Tool Storage
Spare tire and tools are stored in the
locations illustrated in the diagram.
Type A
2. Remove the jack.
1. Jack lever
2. Spare tire hold-down bolt
3. Tiedown eyelet*
4. Jack
5. Spare tire
6. Flat tire bolt
7. Lug wrench
To secure the jack
Type B
Perform the removal procedure in
reverse.
Maintenance
Always keep the jack clean.
Make sure the moving parts are kept
free from dirt or rust.
Make sure the screw thread is
adequately lubricated.
Spare Tire
1. Jack lever
Your Mazda has a temporary spare tire.
2. Spare tire hold-down bolt
The temporary spare tire is lighter and
3. Tiedown eyelet*
smaller than a conventional tire, and is
4. Jack
designed only for emergency use and
5. Spare tire
should be used only for VERY short
6. Lug wrench
periods. Temporary spare tires should
NEVER be used for long drives or
extended periods.
*Some models.
7-3
If Trouble Arises
Flat Tire
To remove the spare tire
WARNING
1.
Remove the luggage mat.
Do not install the temporary spare tire
on the front wheels (driving wheels):
Driving with the temporary spare tire
on one of the front driving wheels is
dangerous. Handling will be affected.
You could lose control of the vehicle,
especially on ice or snow bound roads,
and have an accident. Move a regular
tire to the front wheel and install the
temporary spare tire to the rear.
2.
(Vehicles with sub-woofer)
Uncouple the sub-woofer
CAUTION
connector.
¾ When using the temporary spare tire,
driving stability may decrease
compared to when using only the
conventional tire. Drive carefully.
¾ To avoid damage to the temporary
spare tire or to the vehicle, observe
the following precautions:
¾ Do not exceed 80 km/h (50 mph).
¾ Avoid driving over obstacles. Also,
do not drive through an automatic
car wash. This tire's diameter is
smaller than a conventional tire, so
the ground clearance is reduced.
NOTE
¾ Do not use a tire chain on this tire
Extra strength may be required to
because it will not fit properly.
uncouple the connector. Be sure to
¾ Do not use your temporary spare
squeeze the tab firmly.
tire on any other vehicle, it has
3.
(Vehicles with sub-woofer)
been designed only for your
Turn the spare tire hold-down bolt
Mazda.
counterclockwise and remove the
¾ Use only one temporary spare tire
sub-woofer and the spare tire.
on your vehicle at the same time.
7-4
If Trouble Arises
Flat Tire
(Vehicles without sub-woofer)
Changing a Flat Tire
Turn the spare tire hold-down bolt
counterclockwise and remove the
Changing a Flat Tire
spare tire.
NOTE
If the following occurs while driving, it
could indicate a flat tire.
Steering becomes difficult.
The vehicle begins to vibrate
excessively.
The vehicle pulls in one direction.
If you have a flat tire, drive slowly to a
level spot that is well off the road and
out of the way of traffic to change the
1. Spare tire hold-down bolt
tire.
Stopping in traffic or on the shoulder
NOTE
of a busy road is dangerous.
If the spare tire hold-down bolt
cannot be loosened, hold the edge
WARNING
of the tire and turn it
counterclockwise until the spare
Be sure to follow the directions for
tire hold-down bolt rotates.
changing a tire:
Changing a tire is dangerous if not
To secure the spare tire
done properly. The vehicle can slip off
Store the spare tire in the reverse order
the jack and seriously injure someone.
of removal. After storing, verify that the
No person should place any portion of
spare tire is stored securely.
their body under a vehicle that is
supported by a jack.
Never allow anyone inside a vehicle
supported by a jack:
Allowing someone to remain in a
vehicle supported by a jack is
dangerous. The occupant could cause
the vehicle to fall resulting in serious
injury.
NOTE
Make sure the jack is well lubricated
before using it.
1. Park on a hard, level surface off the
right-of-way and firmly set the
parking brake.
7-5
If Trouble Arises
Flat Tire
2. Shift into Park (P) and turn off the
Removing a Flat Tire
engine.
3. Turn on the hazard warning flasher.
WARNING
4. Have passengers get out of the
vehicle and away from the vehicle
When jacking-up a vehicle, always
and traffic.
shift the selector lever to P position,
5. Remove any luggage, the jack,
apply the parking brake, and place
tools, and spare tire (page 7-3).
wheel blocks in the position
6. Block the wheel diagonally
diagonally opposed to the jack:
opposite the flat tire. When
Changing a flat tire without using
blocking a wheel, place a tire block
wheel blocks is dangerous because the
both in front and behind the tire.
vehicle may move and fall off the jack
even with the selector lever is in P
position, which could result in an
accident.
1. If your vehicle is equipped with a
wheel cover, pry off the wheel
cover with the beveled end of the
jack lever.
NOTE
When blocking a tire, use rocks or
wood blocks of sufficient size if
possible to hold the tire in place.
NOTE
Force the end of the jack lever
firmly between wheel and cover, or
removal will be difficult.
7-6
If Trouble Arises
Flat Tire
3. Place the jack on the ground.
CAUTION
4. Turn the jack screw in the direction
Align the notch on the wheel cover
shown in the figure and adjust the
with the valve stem when installing
jack head so that it is close to the
it.
jack-up position.
1. Jack head
1. Notch
5. Place the jack under the jack-up
2. Tire valve
position closest to the tire being
changed with the jack head
Damage could occur during
squarely under the jack-up point.
installation if the wheel cover is not
properly aligned.
2. Loosen the lug nuts by turning them
counterclockwise one turn each,
but do not remove any lug nuts
until the tire has been raised off the
ground.
1. Jacking position
NOTE
If your Mazda is equipped with the
optional antitheft wheel lug nuts, a
special key must be used to unlock
the locking lug nut for each wheel.
For details, refer to the Locking Lug
Nuts on page 7-10.
7-7















Content      ..     13      14      15      16     ..
