Mazda CX-9 (2022 year). Manual in english - page 6





When Driving
Start/Stop Engine
Ignition Switch
WARNING
Push Button Start Positions
Before leaving the driver's seat, always
The system operates only when the key is
switch the ignition off, set the parking
within operational range.
brake, and make sure the selector lever is in
Each time the push button start is pressed,
P position:
the ignition switches in the order of off,
Leaving the driver's seat without switching
ACC, and ON. Pressing the push button
the ignition off, setting the parking brake,
start again from ON switches the ignition
and shifting the selector lever to P position
off.
is dangerous. Unexpected vehicle
movement could occur which could result
in an accident.
In addition, if your intention is to leave the
vehicle for even a short period, it is
Indicator light
important to switch the ignition off, as
leaving it in another position will disable
some of the vehicle's security systems and
run the battery down.
ACC (Accessory)
Some electrical accessories will operate
NOTE
and the indicator light (amber) illuminates.
The engine starts by pressing the push
NOTE
button start while depressing the brake
The keyless entry system does not function
pedal. To switch the ignition position,
while the push button start has been
press the push button start without
pressed to ACC, and the doors will not
depressing the pedal.
lock/unlock even if they have been locked
Do not leave the ignition switched ON
manually.
while the engine is not running. Doing
ON
so could result in the battery going
dead. If the selector lever is in the P
This is the normal running position after
position, and the ignition is in ACC, the
the engine is started. The indicator light
ignition switches off automatically after
(amber) turns off. (The indicator light
about 25 minutes.
(amber) illuminates when the ignition is
switched ON and the engine is not
Off
running.)
The power supply to electrical devices
Some indicator lights/warning lights
turns off and the push button start
should be inspected before the engine is
indicator light (amber) also turns off.
started (page 4-11).
4-4
When Driving
Start/Stop Engine
NOTE
Starting the Engine
When the push button start is pressed to
ON, the sound of the fuel pump motor
operating near the fuel tank can be heard.
WARNING
This does not indicate an abnormality.
Radio waves from the key may affect
medical devices such as pacemakers:
Before using the key near people who use
medical devices, ask the medical device
manufacturer or your physician if radio
waves from the key will affect the device.
NOTE
The key must be carried because the key
carries an immobilizer chip that must
communicate with the engine controls at
short range.
The engine can be started when the push
button start is pressed from off, ACC, or
ON.
The push button start system functions
(function which can start the engine by
only carrying the key) can be
deactivated to prevent any possible
adverse effect on a user wearing a
pacemaker or other medical device. If
the system is deactivated, you will be
unable to start the engine by carrying
the key. Consult an Authorized Mazda
Dealer for details. If the push button
start system functions have been
deactivated, you can start the engine by
following the procedure indicated when
the key battery goes dead.
Refer to Engine Start Function When
Key Battery is Dead on page 4-8.
After starting a cold engine, the engine
speed increases and a whining sound
from the engine compartment can be
heard.
4-5
When Driving
Start/Stop Engine
This is for improved exhaust gas
cluster and the push button start
purification and does not indicate any
indicator light (green) illuminate.
parts defect.
Engine-starting is controlled by the
spark ignition system.
This system meets all Canadian
Indicator light
Interference-Causing Equipment
Standard requirements regulating the
impulse electrical field strength of radio
noise.
1.
Make sure you are carrying the key.
2.
Occupants should fasten their seat
Push button start
belts.
3.
Make sure the parking brake is on.
4.
Continue to press the brake pedal
firmly until the engine has completely
NOTE
started.
5.
Put the vehicle in park (P). If you must
If the push button start indicator
restart the engine while the vehicle is
light (green) flashes, make sure that
moving, shift into neutral (N).
the key is being carried (for vehicles
with a type A/type B instrument
NOTE
cluster (page 7-28), messages are
The starter will not operate if the
displayed in the instrument cluster).
selector lever is not in P or N position
If the push button start indicator
and the brake pedal is not depressed
light (green) flashes with the key
sufficiently.
being carried, touch the key to the
6.
Verify that the KEY indicator light
push button start and start the
(green) (if equipped) in the instrument
engine (for vehicles with a type A/
type B instrument cluster (page
7-28), messages are displayed in
the instrument cluster). Refer to
Engine Start Function When Key
Battery is Dead on page 4-8.
4-6
When Driving
Start/Stop Engine
If the KEY warning light (red)
CAUTION
illuminates, or the push button start
indicator light (amber) flashes, this
If the KEY warning light (red)
could indicate that the engine may
illuminates, or the push button start
not start using the usual starting
indicator light (amber) flashes, this
method (for vehicles with a type A/
could indicate a problem with the
type B instrument cluster (page
engine starting system. This may
7-28), messages are displayed in
prevent the engine from starting or
the instrument cluster). Have your
from switching the ignition to ACC or
vehicle inspected at an Authorized
ON (for vehicles with a type A/type B
Mazda Dealer as soon as possible. If
instrument cluster (page 7-28),
this occurs, the engine can be
messages are displayed in the
force-started. Press and hold the
instrument cluster). Have your vehicle
push button start until the engine
inspected at an Authorized Mazda
starts. Other procedures necessary
Dealer as soon as possible.
for starting the engine, such as
having the key in the cabin, and
NOTE
depressing the brake pedal are
Under the following conditions, the
required.
KEY warning light (red) flashes after
When the engine is force-started, the
the push button start is pressed. This
KEY warning light (red) (if
informs the driver that the push
equipped) remains illuminated and
button start will not switch to ACC,
the push button start indicator light
even if it is pressed from off (for
(amber) remains flashing.
vehicles with a type A/type B
When the selector lever is in the
instrument cluster (page 7-28),
neutral (N) position, the KEY
messages are displayed in the
indicator light (green) (if equipped)
instrument cluster).
and the push button start indicator
light (green) do not illuminate.
The key battery is dead.
7.
Press the push button start after both
The key is out of operational
range.
the KEY indicator light (green) (if
equipped) in the instrument cluster and
The key is placed in areas where it
the push button start indicator light
is difficult for the system to detect
(green) illuminate.
the signal (page 3-8).
A key from another manufacturer
NOTE
similar to the key is in the
After starting the engine, the push
operational range.
button start indicator light (amber)
(Forced engine starting method)
turns off and the ignition switches to
the ON position.
4-7
When Driving
Start/Stop Engine
After pressing the push button start
¾ Metal parts of other keys or metal objects
and before the engine starts, the
touch the key.
operation sound of the fuel pump
motor from near the fuel tank can be
heard, however, this does not
indicate a malfunction.
8.
After starting the engine, let it idle for
about 10 seconds.
¾ Spare keys or keys for other vehicles
NOTE
equipped with an immobilizer system
touch or come near the key.
Do not use high engine speeds until
reaching the operating temperature.
Whether the engine is cold or warm,
it should be started without the use
of the accelerator.
If the engine does not start the first
¾ Devices for electronic purchases, or
time, refer to Starting a Flooded
security passage touch or come near the
Engine under Emergency Starting. If
key.
the engine still does not start, have
If the engine cannot be started due to a
your vehicle inspected by an
dead key battery, the engine can be started
Authorized Mazda Dealer (page
using the following procedure:
7-22).
1. Continue to depress the brake pedal
Engine Start Function When Key
firmly until the engine has completely
Battery is Dead
started.
2. Make sure that the push button start
indication light (green) flashes.
CAUTION
3. Align the center area of the emblem on
the transmitter with the center area of
When starting the engine by holding the
the push button start while the push
transmitter over the push button start due
to a dead key battery or a malfunctioning
key, be careful not to allow the following,
otherwise the signal from the key will not
be received correctly and the engine may
not start.
4-8
When Driving
Start/Stop Engine
button start indicator light (green)
2. Press the push button start to
flashes.
switch the ignition position. The
ignition switches in the order of
ACC, ON, and off each time the
push button start is pressed. To
switch the ignition position
again, perform the operation
Emblem
from the beginning.
Emergency Operation for Starting
Push
the Engine
button
start
If the KEY warning light (red) illuminates,
Transmitter
or the push button start indicator light
(amber) flashes, this could indicate that
4.
Make sure that the push button start
the engine may not start using the usual
indicator light (green) turns on.
starting method (for vehicles with a type
5.
Press the push button start to start the
A/type B instrument cluster (page 7-28),
engine.
messages are displayed in the instrument
NOTE
cluster). Have your vehicle inspected at an
Authorized Mazda Dealer as soon as
The engine cannot be started unless
possible. If this occurs, the engine can be
the brake pedal is fully depressed.
force-started. Press and hold the push
If there is a malfunction with the
button start until the engine starts. Other
push button start function, the push
procedures necessary for starting the
button start indicator light (amber)
engine such as having the key in the cabin,
flashes. In this case, the engine may
and depressing the brake pedal are
start, however, have the vehicle
required.
checked at an Authorized Mazda
Dealer as soon as possible.
If the push button start indicator
light (green) does not illuminate,
perform the operation from the
beginning again. If it does not
illuminate, have the vehicle checked
at an Authorized Mazda Dealer.
To switch the ignition position
without starting the engine, perform
the following operations after the
push button start indicator light
(green) turns on.
1. Release the brake pedal.
4-9
When Driving
Start/Stop Engine
A message is indicated in the display of
Turning the Engine Off
the instrument cluster.
Refer to Taking Action on page 7-36.
WARNING
If the engine is turned off while the
selector lever is in a position other than
P, the ignition switches to ACC.
Do not stop the engine while the vehicle is
moving:
Emergency Engine Stop
Stopping the engine while the vehicle is
moving for any reason other than in an
Continuously pressing the push button
emergency is dangerous. Stopping the
start or quickly pressing it any number of
engine while the vehicle is moving will
times while the engine is running or the
result in reduced braking ability due to the
vehicle is being driven will turn the engine
loss of power braking, which could cause
off immediately. The ignition switches to
an accident and serious injury.
ACC.
1. Stop the vehicle completely.
2. Shift the selector lever to the P
position and set the parking brake.
3. Press the push button start to turn off
the engine. The ignition position is off.
CAUTION
¾ When leaving the vehicle, make sure the
push button start is off.
NOTE
The cooling fan in the engine
compartment could turn on for a few
minutes after the ignition is switched
from ON to OFF, whether or not the A/C
is on or off, to cool the engine
compartment quickly.
If the system detects that the remaining
battery power of the key is low when the
ignition is switched from ON to ACC or
OFF, the following is indicated.
Replace with a new battery before the
key becomes unusable.
Refer to Key Battery Replacement on
page 6-32.
4-10
When Driving
Instrument Cluster and Display
Instrument Cluster and Display
Instrument Cluster
Type A
Type B
Active Driving Display
Instrument Cluster (Type A)
page 4-12
Instrument Cluster (Type B)
page 4-29
Active Driving Display
page 4-45
4-11
When Driving
Instrument Cluster and Display
Instrument Cluster (Type A)
Speedometer
page 4-12
Tachometer
page 4-12
Multi-information Display (Type A)
page 4-13
Engine Coolant Temperature Gauge
page 4-16
Fuel Gauge
page 4-17
Dashboard Illumination
page 4-17
Speed Unit Selector
page 4-18
Speedometer
This may cause severe engine damage.
The speedometer indicates the speed of the
RED ZONE
STRIPED ZONE
vehicle.
Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
NOTE
needle in the RED ZONE.
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
4-12
When Driving
Instrument Cluster and Display
Multi-information Display (Type A)
Dashboard illumination knob
Multi-information Display (Type A)
INFO switch
The multi-information display indicates the following information.
Speedometer
Odometer
Trip meter
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display
Cruise Control Display
Compass Display
Door-Ajar/Liftgate-Ajar Warning Indication
Message Display
4-13
When Driving
Instrument Cluster and Display
The screen content changes each time the INFO switch is pressed.
Press the INFO switch
*1
Basic display
*2
Warning message
Press the INFO switch
display
Trip Meter A display
Press the INFO switch
Press the INFO switch
Compass display
Trip Meter B display
Press the INFO switch
Maintenance Monitor
Press the INFO switch
display
i-ACTIVSENSE display
Press the INFO switch
*1: Displayed when opening/closing door/Liftgate.
*2: Displayed only when a warning occurs.
4-14
When Driving
Instrument Cluster and Display
The screen content changes each time the dashboard illumination knob is pressed and held.
Gauge indication
Press and hold dashboard
illumination knob
Press and hold
Numerical indication
dashboard illumination
knob
Press and hold dashboard
illumination knob
Display off
Odometer, Trip Meter and Trip
Meter Selector
The odometer is constantly displayed on
the screen when the ignition is switched
ON, and the TRIP A or TRIP B screen can
4-15
When Driving
Instrument Cluster and Display
be displayed by operating the INFO
meter B can record the distance from
switch.
where the fuel tank is filled.
INFO switch
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
The trip meter and average fuel economy
can be reset by pressing the INFO switch
for 1.5 seconds or more while in each
Trip Meter A
mode.
display
NOTE
Only the trip meters record tenths of
kilometers (miles).
Press the INFO switch
The trip record will be erased when:
The power supply is interrupted
Trip Meter B
(blown fuse or the battery is
display
disconnected).
The vehicle is driven over 9999.9 km
(mile).
Odometer
Engine Coolant Temperature Gauge
The odometer records the total distance
Displays the engine coolant temperature.
the vehicle has been driven.
The blue range of the gauge indicates that
Trip meter
the engine coolant temperature is low, and
the red range of the gauge indicates that
The driving distance for a specified
the engine coolant temperature is high and
interval is indicated. Two types (TRIP A,
overheating.
TRIP B) of interval distance and the
average fuel economy for each can be
measured.
For instance, trip meter A can record the
distance from the point of origin, and trip
4-16
When Driving
Instrument Cluster and Display
If the low fuel warning light illuminates or
CAUTION
the fuel level is very low, refuel as soon as
possible.
If the engine coolant temperature gauge
If inconsistency in engine performance or
needle is in the red range, there is the
stalling occurs due to low fuel level
possibility of overheating. Drive slowly to
conditions, refuel the vehicle as soon as
reduce engine load until you can find a safe
possible and add at least 10 L (2.7 US gal,
place to stop the vehicle and wait for the
2.2 Imp gal) of fuel.
engine to cool down.
Refer to Taking Action on page 7-36.
Refer to Overheating on page 7-23.
NOTE
NOTE
After refueling, it may require some time
If the engine coolant temperature is high
for the indicator to stabilize. In addition,
or the engine is hot, the engine output
the indicator may deviate while driving
may be limited.
on a slope or curve since the fuel moves
in the tank.
Fuel Gauge
The direction of the arrow (
) indicates
The fuel gauge shows approximately how
that the fuel-filler lid is on the left side
much fuel is remaining in the tank when
of the vehicle.
the ignition is switched ON. We
Dashboard Illumination
recommend keeping the tank over 1/4 full.
When the lights are turned on with the
Full
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
1/4 Full
NOTE
When the ignition is switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
Empty
however, the dimming may cancel after
the brightness is detected.
When the lights are turned on, the
lights-on indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-58.
4-17
When Driving
Instrument Cluster and Display
The brightness of the instrument cluster
Speed Unit Selector
and dashboard illuminations can be
In some countries, you may have to
adjusted by rotating the knob.
change the speed units between km/h and
The brightness decreases by rotating the
mph.
knob to the left. A beep sound will be
When pressing the dashboard illumination
heard when the knob has been rotated to
knob, the speed units in the instrument
the maximum dim position.
cluster will change.
The brightness increases by rotating the
knob to the right.
Dashboard illumination knob
Dim
Bright
Outside Temperature Display
When the ignition is switched ON, the
Function for canceling illumination
outside temperature is displayed.
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
NOTE
heard while the instrument cluster is
Under the following conditions, the
dimmed with the ignition switched ON. If
outside temperature display may differ
the instrument cluster's visibility is
from the actual outside temperature
reduced due to glare from surrounding
depending on the surroundings and
brightness, cancel the illumination
vehicle conditions:
dimmer.
Significantly cold or hot temperatures.
NOTE
Sudden changes in outside
When the illumination dimmer is
temperature.
canceled, the instrument cluster cannot
The vehicle is parked.
be dimmed even if the lights are turned
The vehicle is driven at low speeds.
on.
Changing the Temperature Unit of the
When the illumination dimmer is
Outside Temperature Display
canceled, the screen in the center
display switches to constant display of
The outside temperature unit can be
the daytime screen.
switched between Celsius and Fahrenheit.
4-18
When Driving
Instrument Cluster and Display
Settings can be changed by operating the
The distance-to-empty is the
center display screen.
approximate remaining distance the
Refer to the Settings section in the Mazda
vehicle can be driven until all the
Connect Owner's Manual.
graduation marks in the fuel gauge
indicating the remaining fuel supply
NOTE
disappear.
When the temperature unit indicated in the
If there is no past fuel economy
outside temperature display is changed,
information such as after first
the temperature unit indicated in the
purchasing your vehicle or the
engine coolant gauge display changes in
information is deleted when the battery
conjunction with it.
cables are disconnected, the actual
Distance-to-empty
distance-to empty/range may differ from
the amount indicated.
This displays the approximate distance
you can travel on the remaining fuel based
Average Fuel Economy
on the fuel economy.
The average fuel economy is calculated
The distance-to-empty will be calculated
every minute from the total traveled
and displayed every second.
distance on the trip meter and the total fuel
consumption, and the average fuel
economy for either TRIP A or TRIP B is
displayed.
NOTE
The average fuel economy and trip meters
Even though the distance-to-empty
can be reset by pressing the INFO switch
display may indicate a sufficient amount
for 1.5 seconds or more while in each
of remaining driving distance before
mode. After the data is cleared, the fuel
refueling is required, refuel as soon as
consumption is recalculated and the - - -
possible if the fuel level is very low or
km/L (- - - mpg) for the 1 minute prior to
the low fuel warning light illuminates.
it being displayed is indicated.
The display will not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
4-19
When Driving
Instrument Cluster and Display
Current Fuel Economy
Refer to the Information section in the
Mazda Connect Owner's Manual.
This displays the current fuel economy by
calculating the amount of fuel
Blind Spot Monitoring (BSM)
consumption and the distance traveled.
Display
Displays the system status.
Refer to Blind Spot Monitoring (BSM) on
NOTE
page 4-109.
Indicates the 0 position when the vehicle
Lane-keep Assist System (LAS) &
speed is about 5 km/h (3 mph) or slower.
Lane Departure Warning System
The arrow on the scale indicates the
(LDWS) Display*
average fuel economy.
Displays the system status.
Maintenance Monitor
The following maintenance period
notifications can be displayed by turning
the Maintenance Monitor on.
Scheduled Maintenance
Tire Rotation
Oil Change
When the remaining days to the
Refer to Lane-keep Assist System (LAS)
maintenance period is 15 days or less, or
& Lane Departure Warning System
the remaining distance is 1,000 km (600
(LDWS) on page 4-146.
miles) or shorter, a message is indicated
when the ignition is switched ON.
For the setting method and indications for
the maintenance monitor, refer to the
Maintenance Monitor.
4-20
*Some models.
When Driving
Instrument Cluster and Display
Mazda Radar Cruise Control with
Cruise Control Set Vehicle Speed
Stop & Go function (MRCC with
Display*
Stop & Go function) Display*
The vehicle speed preset using the cruise
Displays the currently set system status.
control is displayed.
Refer to Mazda Radar Cruise Control with
Refer to Cruise Control on page 4-235.
Stop & Go function (MRCC with Stop &
Compass Display
Go function) on page 4-131.
The direction the vehicle is moving is
Distance Recognition Support
displayed in one of eight directions while
System (DRSS) Display*
the vehicle is being driven.
Displays the distance between your
vehicle and the vehicle ahead.
Display
Direction
N
North
S
South
E
East
W
West
NE
Northeast
NW
Northwest
Refer to Distance Recognition Support
SE
Southeast
System (DRSS) on page 4-121.
SW
Southwest
Message Display
A message such as the system operation
status, a malfunction, or an abnormality is
indicated.
Warning/indicator light in instrument
cluster turns on/flashes or symbol is
*Some models.
4-21
When Driving
Instrument Cluster and Display
indicated on display at same time as
message
Check the information regarding the
warning/indicator light or indicated
symbol.
Refer to If a Warning Indication/Warning
Lights on page 4-23.
Refer to If a Indication/Indicator Lights on
page 4-25.
Message only is indicated on display
Follow the instructions indicated on the
display. For the display content, refer to
the next page.
Refer to If a Message Indicated on
Multi-information Display on page 7-43.
4-22
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Instrument Cluster
Center of Dashboard
Warning lights will appear in any of the highlighted areas
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Warning
Page
Brake System Warning Indication/Warning Light*1*2
7-28
Electronic Brake
Force Distribu-
tion System
ABS Warning Light*1
Warning
7-28
ABS warning
7-31
Charging System Warning Indication/Warning Light*1
7-28
Engine Oil Warning Light*1
7-28
High Engine Coolant Temperature Warning Indication
7-28
Power Steering Malfunction Indication
7-28
Master Warning Indication
7-31
4-23
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Electric Parking Brake (EPB) Warning Indication/Warning Light*1
7-31
Check Engine Light*1
7-31
Automatic Transaxle Warning Indication
7-31
*AWD Warning Indication
7-31
Air Bag/Front Seat Belt Pretensioner System Warning Light*1
7-31
Flashing
7-31
Tire Pressure Monitoring System Warning Light*1
Turns on
7-36
Amber
7-31
KEY Warning Indication
White
(Amber/White)
7-36
*High Beam Control System (HBC) Warning Indication/Warning Light*1
7-31
(Amber)
*Blind Spot Monitoring (BSM) Warning Indication
7-31
*Driver Attention Alert (DAA) Warning Indication
7-31
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
7-31
& Go function) Warning Indication
(Amber)
*Lane-keep Assist System (LAS) & Lane Departure Warning System
7-31
(LDWS) Warning Indication
(Amber)
LED Headlight Warning Light*1
7-31
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) Warning In-
7-36
dication
Low Fuel Warning Indication/Warning Light
7-36
Check Fuel Cap Warning Indication/Warning Light*1
7-36
Engine Oil Level Warning Light*1
7-36
4-24
*Some models.
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Seat Belt Warning Light (Front seat)
7-36
Seat Belt Warning Light (Rear seat)
7-36
(Red)
*Low Washer Fluid Level Warning Indication
7-36
Door-Ajar Warning Indication
7-36
Liftgate-Ajar Warning Indication
7-36
Door-Ajar Warning Light
7-36
*1
The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2
The light turns on continuously when the parking brake is applied.
Indication/Indicator Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Indicator
Page
Seat Belt Indicator Light (Rear seat)
2-39
(Green)
*Front Passenger Air Bag Deactivation Indicator Light*1
2-85
Security Indicator Light*1
3-44
Wrench Indication
4-28
Shift Position Indication
4-49
*Some models.
4-25
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
Lights-On Indication/Indicator Light
4-58
Headlight
High-Low Beam
4-62
Headlight High-Beam Indicator Light
Flashing the
Headlights
4-62
Turn and
Lane-Change
Signals
Turn Signal/Hazard Warning Indicator Lights
4-65
Hazard Warning
Flasher
4-72
AUTOHOLD Active Indicator Light*1
4-86
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-142
& Go function) indicator Light*1
Traction Control
System (TCS)
4-91
Dynamic Stabil-
TCS/DSC Indicator Light*1
ity Control
(DSC)
4-93
Turns on
7-31
TCS OFF Indicator Light (FWD) *1
4-92
Off-Road Traction Assist Indicator Light (AWD) *1
4-95
Select Mode Indication
4-97
*High Beam Control System (HBC) Indicator Light
4-107
(Green)
4-26
*Some models.
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
Malfunction
7-31
*Blind Spot Monitoring (BSM) OFF Indicator Light*1
Except malfunc-
tion
4-113
*Driver Attention Alert (DAA) Indication
4-126
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-136
& Go function) Main Indication
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-136
& Go function) Set Indication
(Green)
*Lane-keep Assist System (LAS) & Lane Departure Warning System
4-148
(LDWS) Indication
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
4-159
*Smart City Brake Support (SCBS) Indication
Smart City
Brake Support
[Reverse]
(SCBS R)
4-166
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
4-159
Smart City
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Indica-
Brake Support
tor Light*1
[Reverse]
(SCBS R)
4-166
Smart Brake
Support (SBS)
System
4-168
*Cruise Main Indication
4-236
(White)
*Some models.
4-27
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
*Cruise Set Indication
4-236
(Green)
*1
The light turns on when the ignition is switched on for an operation check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda Dealer.
Wrench Indicator Light
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to the Information section in the
Mazda Connect Owner's Manual.
When the engine oil replacement period
has arrived.
NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit is
necessary.
Refer to the Information section in the
Mazda Connect Owner's Manual.
4-28
*Some models.
When Driving
Instrument Cluster and Display
Instrument Cluster (Type B)
Speedometer
page 4-29
Tachometer
page 4-29
Multi-information Display (Type B)
page 4-30
Dashboard Illumination
page 4-34
Speedometer
NOTE
When the tachometer needle enters the
The speedometer indicates the speed of the
STRIPED ZONE, this indicates to the
vehicle.
driver that the gears should be shifted
before entering the RED ZONE.
Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.
STRIPED
ZONE
RED ZONE
4-29
When Driving
Instrument Cluster and Display
Multi-information Display (Type B)
Multi-information Display (Type B)
INFO switch
The multi-information display indicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display
Cruise Control Display
Compass Display
Message Display
4-30
When Driving
Instrument Cluster and Display
The screen content changes each time the INFO switch is pressed.
Press the INFO switch
*1
Current Fuel Economy,
Trip Meter A, Average
Warning message,
Fuel Economy, Outside
Outside Temperature,
Temperature,
Odometer, Fuel Gauge
Odometer, Fuel Gauge
Press the INFO switch
Press the INFO switch
Current Fuel Economy,
Engine Coolant
Trip Meter B, Average
Temperature Gauge,
Fuel Economy, Outside
Compass,
Temperature,
Distance-to-empty,
Odometer, Fuel Gauge
Outside Temperature,
Odometer, Fuel Gauge
Press the INFO switch
Press the INFO switch
Engine Coolant
Temperature Gauge,
i-ACTIVSENSE display,
Maintenance Monitor,
Outside Temperature,
Outside Temperature,
Odometer, Fuel Gauge
Odometer, Fuel Gauge
Press the INFO switch
*1: Displayed only when a warning occurs.
Odometer, Trip Meter and Trip
Meter Selector
The odometer is constantly displayed on
the screen when the ignition is switched
ON, and the TRIP A or TRIP B screen can
4-31
When Driving
Instrument Cluster and Display
be displayed by operating the INFO
meter B can record the distance from
switch.
where the fuel tank is filled.
INFO switch
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
The trip meter and average fuel economy
can be reset by pressing the INFO switch
for 1.5 seconds or more while in each
mode.
Odometer,
Trip meter A
NOTE
Only the trip meters record tenths of
kilometers (miles).
Press the INFO switch
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
Odometer,
Trip meter B
disconnected).
The vehicle is driven over 9999.9 km
(mile).
Odometer
Engine Coolant Temperature Gauge
The odometer records the total distance
Displays the engine coolant temperature.
the vehicle has been driven.
The blue range of the gauge indicates that
the engine coolant temperature is low, and
Trip meter
the red range of the gauge indicates that
The driving distance for a specified
the engine coolant temperature is high and
interval is indicated. Two types (TRIP A,
overheating.
TRIP B) of interval distance and the
average fuel economy for each can be
measured.
For instance, trip meter A can record the
distance from the point of origin, and trip
4-32
When Driving
Instrument Cluster and Display
the ignition is switched ON. We
CAUTION
recommend keeping the tank over 1/4 full.
If the high engine coolant temperature
Full
warning light (red) flashes, there is a
possibility of overheating. Drive slowly to
reduce engine load until you can find a safe
place to stop the vehicle and wait for the
engine to cool down.
Refer to Overheating on page 7-23.
1/4 Full
NOTE
If the engine coolant temperature is high
or the engine is hot, the engine output
may be limited.
The temperature unit (Centigrade/
Fahrenheit) of the engine coolant gauge
Empty
display changes in conjunction with the
temperature unit of the outside
temperature display.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
If the fuel level is low, (
) and ( ) turn an
amber color. Refuel as soon as possible.
Fuel Gauge
If inconsistency in engine performance or
The fuel gauge shows approximately how
stalling occurs due to low fuel level
much fuel is remaining in the tank when
conditions, refuel the vehicle as soon as
possible and add at least 10 L (2.7 US gal,
2.2 Imp gal) of fuel.
Refer to Taking Action on page 7-36.
NOTE
After refueling, it may require some time
for the indicator to stabilize. In addition,
the indicator may deviate while driving
on a slope or curve since the fuel moves
in the tank.
The direction of the arrow (
) indicates
that the fuel-filler lid is on the left side
of the vehicle.
4-33
When Driving
Instrument Cluster and Display
Dashboard Illumination
The brightness increases by rotating the
knob to the right.
(Without auto-light control)
When the lights are turned on with the
Dim
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
(With auto-light control)
When the lights are turned on with the
Bright
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
Function for canceling illumination
when the lights are turned on in the
dimmer
daytime, the dashboard illumination does
not dim.
The illumination dimmer can be canceled
by rotating the dashboard illumination
NOTE
knob to the right until a beep sound is
(With auto-light control)
heard while the instrument cluster is
When the ignition is switched ON in the
dimmed with the ignition switched ON. If
early evening or at dusk, the dashboard
the instrument cluster's visibility is
illumination is dimmed for several
reduced due to glare from surrounding
seconds until the light sensor detects the
brightness, cancel the illumination
brightness of the surrounding area,
dimmer.
however, the dimming may cancel after
the brightness is detected.
NOTE
When the lights are turned on, the
The illumination dimmer can be
lights-on indicator light in the
canceled by pressing the dashboard
instrument cluster turns on.
illumination knob.
Refer to Headlights on page 4-58.
When the illumination dimmer is
canceled, the instrument cluster cannot
The brightness of the instrument cluster
be dimmed even if the lights are turned
and dashboard illuminations can be
on.
adjusted by rotating the knob.
When the illumination dimmer is
The brightness decreases by rotating the
canceled, the screen in the center
knob to the left. A beep sound will be
display switches to constant display of
heard when the knob has been rotated to
the daytime screen.
the maximum dim position.
4-34
When Driving
Instrument Cluster and Display
Outside Temperature Display
The distance-to-empty will be calculated
and displayed every second.
When the ignition is switched ON, the
outside temperature is displayed.
NOTE
NOTE
Even though the distance-to-empty
Under the following conditions, the
display may indicate a sufficient amount
outside temperature display may differ
of remaining driving distance before
from the actual outside temperature
refueling is required, refuel as soon as
depending on the surroundings and
possible if the fuel level is very low or
vehicle conditions:
the low fuel warning light illuminates.
The display will not change unless you
Significantly cold or hot temperatures.
add more than approximately 9 L (2.3
Sudden changes in outside
US gal, 1.9 Imp gal) of fuel.
temperature.
The distance-to-empty is the
The vehicle is parked.
approximate remaining distance the
The vehicle is driven at low speeds.
vehicle can be driven until all the
Changing the Temperature Unit of the
graduation marks in the fuel gauge
Outside Temperature Display
indicating the remaining fuel supply
disappear.
The outside temperature unit can be
If there is no past fuel economy
switched between Celsius and Fahrenheit.
Settings can be changed by operating the
information such as after first
center display screen.
purchasing your vehicle or the
information is deleted when the battery
Refer to the Settings section in the Mazda
Connect Owner's Manual.
cables are disconnected, the actual
distance-to empty/range may differ from
NOTE
the amount indicated.
When the temperature unit indicated in the
outside temperature display is changed,
Average Fuel Economy
the temperature unit indicated in the
The average fuel economy is calculated
engine coolant gauge display changes in
every minute from the total traveled
conjunction with it.
distance on the trip meter and the total fuel
Distance-to-empty
consumption, and the average fuel
This displays the approximate distance
you can travel on the remaining fuel based
on the fuel economy.
4-35















Content      ..     4      5      6      7     ..
