If the front passenger weight sensors
are normal, the indicator light
illuminates when the ignition is
switched ON. The light turns off after a
few seconds. Then, the indicator light
illuminates or is off under the following
conditions:

Front passenger air bag deactivation
indicator light on/off condition chart

Condition

detected

by the

front pas-

senger oc-

cupant

classifica-

tion sys-

tem

Front pas-

senger air

bag deacti-

vation indi-

cator light

Front pas-

senger

front and

side and

knee air

bags

Front

passen-
ger seat

belt pre-

tensioner

system

Empty
(Not occu-
pied)

On

Deactivat-

ed

Deacti-

vated

Child or
child-re-
straint sys-
tem

*1

On

Deactivat-

ed

Deacti-

vated

Adult

*2

Off

Ready

Ready

*

1

If a larger child sits on the front passenger
seat, the sensors might detect the child as
being an adult depending on the child's
physique.

*

2

If a smaller adult sits on the front passenger
seat, the sensors might detect the person as
being a child depending on the person's
physique.

The curtain air bag is ready for inflating
regardless of what the front passenger air bag
deactivation indicator light on/off condition
chart indicates.

If the front passenger air bag
deactivation indicator light does not
illuminate when the ignition is
switched ON and does not illuminate
as indicated in the front passenger air
bag deactivation indicator light on/off
condition chart, do not allow a child to
sit in the front passenger seat and
consult an Authorized Mazda Dealer
as soon as possible. The system may
not work properly in an accident.

WARNING

Do not decrease the total seated
weight on the front passenger seat:

When an adult or large child sits on the
front passenger seat, decreasing the
total seated weight on the front
passenger seat required for air bag
deployment is dangerous. The front
passenger seat weight sensors will
detect the reduced total seated weight
condition and the front passenger front
and side air bags and knee air bags,
and the seat belt pretensioner system
will not deploy during an accident. The
front passenger will not have the
supplementary protection of the air
bag, which could result in serious
injury. Decreasing the total seated
weight on the front passenger seat
could result in an air bag not deploying
under the following conditions, for
example:

Essential Safety Equipment

SRS Air Bags

2-72

¾

A front passenger is seated as shown
in the following figure:

¾

A rear passenger pushes up on the
front passenger seat with their feet.

¾

Luggage or other items placed under
the front passenger seat or between
the front passenger seat and driver
seat that push up the front passenger
seat bottom.

¾

Any accessories which might
decrease the total seated weight on
the front passenger seat are attached
to the front passenger seat.
The front passenger front and side air
bags and knee air bags, and the seat
belt pretensioner system will
deactivate if the front passenger air
bag deactivation indicator light
illuminates.

Do not increase the total seated
weight on the front passenger seat:

When an infant or small child sits on
the front passenger seat, increasing the
total seated weight on the front
passenger seat is dangerous. The front
passenger seat weight sensors will
detect the increased total seated
weight, which could result in the
unexpected deployment of the front
passenger front and side air bags and
knee air bags, and seat belt
pretensioner system in an accident and
may cause serious injury. Increasing the
total seated weight on the front
passenger seat could result in the front
passenger front and side air bags and
knee air bags, and seat belt
pretensioner system deployment in an
accident under the following
conditions, for example:

¾

Luggage or other items are placed on
the seat with the child in the
child-restraint system.

¾

A rear passenger or luggage push or
pull down on the front passenger
seatback.

Essential Safety Equipment

SRS Air Bags

2-73

¾

A rear passenger steps on the front
passenger seat rails with their feet.

¾

Luggage or other items are placed on
the seatback or hung on the head
restraint.

¾

Heavy items are placed in the
seatback map pocket.

¾

The seat is washed.

¾

Liquids are spilled on the seat.

¾

The front passenger seat is moved
backward, pushing into luggage or
other items placed behind it.

¾

The front passenger seatback
contacts the rear seat.

¾

Luggage or other items are placed
between the front passenger seat
and driver seat.

¾

Any accessories which might increase
the total seated weight on the front
passenger seat are attached to the
front passenger seat.

CAUTION

¾

To assure proper deployment of the
front air bag and to prevent damage
to the sensors in the front seat
bottoms:

¾

Do not place sharp objects on the
front seat bottoms or leave heavy
luggage on them.

¾

Do not spill any liquids on the
front seats or under the front seats.

¾

To allow the sensors to function
properly, always perform the
following:

¾

Adjust the front seats as far back as
possible and always sit upright
against the seatbacks with seat
belts worn properly.

¾

If you place your child on the front
passenger seat, secure the
child-restraint system properly and
slide the front passenger seat as far
back as possible (page 2-47).

NOTE

x

The system requires about 10
seconds to alternate between turning
the front passenger front and side air
bags and knee air bags, and seat belt
pretensioner system on or off.

x

The front passenger air bag
deactivation indicator light may
illuminate repeatedly if luggage or
other items are put on the front
passenger seat, or if the temperature
of the vehicle's interior changes
suddenly.

x

The front passenger air bag
deactivation indicator light may
illuminate for 10 seconds if the total
seated weight on the front passenger
seat changes.

x

The air bag/front seat belt
pretensioner system warning light
might illuminate if the front
passenger seat receives a severe
impact.

x

If the front passenger air bag
deactivation indicator light does not
illuminate after installing a
child-restraint system on the front
passenger seat, first, re-install your
child-restraint system according to
the procedure in this owner's
manual. Then, if the front passenger
air bag deactivation indicator light
still does not illuminate, install the
child-restraint system on the rear seat
and consult an Authorized Mazda
Dealer as soon as possible.

Essential Safety Equipment

SRS Air Bags

2-74

x

If the front passenger air bag
deactivation indicator light
illuminates when an adult is seated
in the front passenger seat, have the
passenger re-adjust their posture by
sitting with their feet on the floor,
and then re-fastening the seat belt. If
the front passenger air bag
deactivation indicator light still
illuminates, move the passenger to
the rear seat. If sitting in the rear seat
is not possible, slide the front
passenger seat as far back as
possible. Consult an Authorized
Mazda Dealer as soon as possible.

Driver and Front Passenger Buckle
Switches

The buckle switches on the front seat
belts detect whether or not the front
seat belts are securely fastened and
further control the deployment of the
air bags.

Constant Monitoring

Constant Monitoring

The following components of the air
bag systems are monitored by a
diagnostic system:

x

Front air bag sensors

x

Crash sensors, and diagnostic
module (SAS unit)

x

Side crash sensors

x

Air bag modules

x

Front seat belt pretensioners

x

Air bag/Front seat belt pretensioner
system warning light

x

Related wiring

(With Driver and Front Passenger
Occupant Classification System)

x

Driver seat slide position sensor

x

Front passenger occupant
classification sensor

x

Front passenger occupant
classification module

x

Front passenger air bag deactivation
indicator light

x

Front passenger seat belt buckle
switch

The diagnostic module continuously
monitors the system's readiness. This
begins when the ignition is switched
ON and continues while the vehicle is
being driven.

Essential Safety Equipment

SRS Air Bags

2-75

3

Before Driving

Use of various features, including keys, doors, mirrors and
windows.

Keys........................................ 3-2

Keys......................................3-2
Keyless Entry System...............3-4

Advanced Keyless Entry
System.....................................3-9

Advanced Keyless Entry
System

*

................................. 3-9

Operational Range...............3-10

Doors and Locks..................... 3-11

Door Locks..........................3-11
Liftgate/Trunk Lid.................3-20
Inside Trunk Release Lever (4-
door)

*

................................. 3-24

Fuel and Emission................... 3-26

Fuel and Engine Exhaust
Precautions......................... 3-26
Fuel-Filler Lid and Cap..........3-28

Mirrors.................................. 3-31

Mirrors................................3-31

Windows............................... 3-35

Power Windows...................3-35

Moonroof

*

.......................... 3-38

Security System.......................3-42

Modification and Add-
On Equipment..................... 3-42
Immobilizer System..............3-42
Theft-Deterrent System

*

........3-44

Driving Tips............................ 3-46

Break-In Period.................... 3-46
Saving Fuel and Protection of the
Environment........................ 3-46
Hazardous Driving............... 3-47
Floor Mat............................ 3-48
Rocking the Vehicle..............3-48
Winter Driving..................... 3-49
Driving In Flooded Area........3-51
Overloading........................ 3-51
Driving on Uneven Road.......3-52
Turbocharger Information
(SKYACTIV-G 2.5T).............. 3-52

Towing.................................. 3-53

Trailer Towing...................... 3-53
Recreational Towing.............3-53

*Some models.

3-1

Keys

Keys

WARNING

Do not leave the key in your vehicle
with children and keep them in a
place where your children will not
find or play with them:

Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may find these keys to
be an interesting toy to play with and
could cause the power windows or
other controls to operate, or even
make the vehicle move.

CAUTION

¾

Because the key (transmitter) uses
low-intensity radio waves, it may not
function correctly under the
following conditions:

¾

The key (transmitter) is carried with
communication devices such as
cellular phones.

¾

The key (transmitter) contacts or is
covered by a metal object.

¾

The key (transmitter) is near
electronic devices such as personal
computers.

¾

Non-Mazda genuine electronic
equipment is installed in the
vehicle.

¾

There is equipment which
discharges radio waves near the
vehicle.

¾

The key (transmitter) may consume
battery power excessively if it
receives high-intensity radio waves.
Do not place the key (transmitter)
near electronic devices such as
televisions or personal computers.

¾

To avoid damage to the key
(transmitter), DO NOT:

¾

Drop the key (transmitter).

¾

Get the key (transmitter) wet.

¾

Disassemble the key (transmitter).

¾

Expose the key (transmitter) to
high temperatures on places such
as the dashboard, under direct
sunlight.

¾

Expose the key (transmitter) to any
kind of magnetic field.

¾

Place heavy objects on the key
(transmitter).

¾

Put the key (transmitter) in an
ultrasonic cleaner.

¾

Put any magnetized objects close
to the key (transmitter).

NOTE

The driver must carry the key
(transmitter) to ensure the system
functions properly.

Before Driving

Keys

3-2

Transmitter

1. Transmitter (page 3-5)

Auxiliary key

There is a removable auxiliary key
inside the transmitter.

Removing the auxiliary key

1. Remove the lower cover while

sliding the knob in the direction of
the arrow.

2. Remove the auxiliary key.

Installing the auxiliary key

1. Install the auxiliary key as the

illustration.

2. Insert the tabs of the lower cover

into the slots of the transmitter and
install the lower cover.

Key code number plate

A code number is stamped on the
plate attached to the key set; detach
this plate and store it in a safe place
(not in the vehicle) for use if you need
to make a replacement key (auxiliary
key).
Also write down the code number and
keep it in a separate safe and
convenient place, but not in the
vehicle.
If your key (auxiliary key) is lost, consult
an Authorized Mazda Dealer and have
your code number ready.

1. Key code number plate

Before Driving

Keys

3-3

Keyless Entry System

Keyless Entry System

This system uses the key buttons to
remotely lock and unlock the doors,
liftgate, and fuel-filler lid, and opens
the trunk lid.
The system can start the engine
without having to take the key out of
your purse or pocket.
It can also help you signal for attention
or help.
Operating the theft-deterrent system is
also possible on theft-deterrent
system-equipped vehicles.

System malfunctions or warnings are
indicated by the following warning
lights or beeps.
Check the displayed message for more
information and, if necessary, have the
vehicle inspected at an Authorized
Mazda Dealer, according to the
indication.

x

KEY Warning Indication/Warning
Light (Red)
Refer to KEY Warning Indication/
Warning Light (Red) on page 7-34.

x

Ignition Not Switched Off (STOP)
Warning Beep
Refer to Ignition Not Switched Off
(STOP) Warning Beep on page
7-44.

x

Key Removed from Vehicle Warning
Beep
Refer to Key Removed from Vehicle
Warning Beep on page 7-44.

If you have a problem with the key,
consult an Authorized Mazda Dealer.

If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to
make the lost or stolen key inoperative.

CAUTION

Radio equipment like this is governed
by laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.

NOTE

x

The keyless entry system operation
may vary due to local conditions.

x

The keyless entry system is fully
operational when the ignition is
switched off. The system does not
operate if the ignition is switched to
any position other than off.

x

If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be weak. To install a new
battery, refer to Key Battery
Replacement (page 6-30).

x

Battery life is about 1 year. Replace
the battery with a new one if the
messages are displayed in the
instrument cluster. Replacing the
battery about once a year is
recommended because the KEY
warning indication may not display
depending on the rate of battery
depletion.

x

Additional keys can be obtained at
an Authorized Mazda Dealer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorized Mazda Dealer
when additional keys are required.

Before Driving

Keys

3-4

Transmitter

1. Operation indicator light
2. Lock button ( )

3. Unlock button ( )

4. Trunk button (4–door) ( )

5. Panic button ( )

NOTE

x

The headlights turn on/off by
operating the transmitter. Refer to
Leaving Home Light on page 4-60.

x

(With theft-deterrent system)

The hazard warning lights flash when
the theft-deterrent system is armed
or turned off.
Refer to Theft-Deterrent System on
page 3-44.

x

(With the advanced keyless
function)

A beep sound can be heard for
confirmation when the doors,
liftgate, and fuel-filler lid are locked/
unlocked using the key. If you prefer,
the beep sound can be turned off.
The volume of the beep sound can
also be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.

The operation indicator light flashes
when the buttons are pressed.

Lock button

To lock the doors, liftgate, and
fuel-filler lid, press the lock button and
the hazard warning lights will flash
once.

(With the advanced keyless function)

A beep sound will be heard once.

To confirm that all the doors, liftgate,
and fuel-filler lid have been locked,
press the lock button again within 5
seconds. If they are closed and locked,
the horn will sound.

NOTE

x

The doors can be locked when the
lock button on the transmitter is
pressed while any door is open.

x

To prevent the transmitter from being
left in the vehicle, make sure that the
driver carries the transmitter when
locking the doors with any door
open.

x

When any door or the liftgate/trunk
lid is open and the lock button is
pressed, the closed doors can be
locked. After that, any other open
door or the liftgate/trunk lid can be
locked by closing them.

Before Driving

Keys

3-5

x

Confirm that all the doors, liftgate,
and fuel-filler lid are locked visually
or audibly by use of the double click.

x

Make sure all the doors, liftgate, and
fuel-filler lid are locked after pressing
the button.

x

(With theft-deterrent system)

If the lock button is pressed with all
the doors and liftgate closed, the
hazard warning lights will flash and
the theft-deterrent system is armed.

Unlock button

To unlock the driver's door and the
fuel-filler lid, press the unlock button
and the hazard warning lights will flash
twice.

(With the advanced keyless function)

A beep sound will be heard twice.

To unlock the other doors and liftgate,
press the unlock button again within 5
seconds and two more beep sounds
will be heard.

NOTE

x

The system can be set to unlock all
the doors, liftgate, and fuel-filler lid
when pressing the unlock button
once.
Refer to the Settings section in the
Mazda Connect Owner's Manual.

x

(Auto re-lock function)

After unlocking with the key, all the
doors, liftgate, and fuel-filler lid will
automatically lock if any of the
following operations are not
performed within about 60 seconds.
If your vehicle has a theft-deterrent
system, the hazard warning lights will
flash for confirmation.
The time required for the doors to
lock automatically can be changed.

Refer to the Settings section in the
Mazda Connect Owner's Manual.

x

A door or the liftgate/trunk lid is
opened.

x

The ignition is switched to any
position other than off.

x

(With theft-deterrent system)

When the doors are unlocked by
pressing the unlock button on the
key while the theft-deterrent system
is turned off, the hazard warning
lights will flash twice to indicate that
the system is turned off.

Trunk button (4–door)

To open the trunk lid, press and hold
the trunk button until the trunk lid
opens.

Panic button

If you witness from a distance
someone attempting to break into or
damage your vehicle, press and hold
the panic button to activate the
vehicle's alarm. Call emergency
services if necessary.

NOTE

The panic button will work whether
any door or the liftgate/trunk lid is
open or closed.

Before Driving

Keys

3-6

(Turning on the alarm)

Pressing the panic button for 1 second
or more will trigger the alarm for about
2 minutes and 30 seconds, and the
following will occur:

x

The horn sounds intermittently.

x

The hazard warning lights flash.

(Turning off the alarm)

The alarm stops by pressing any button
on the key.

Power saving function

By turning on the transmitter power
saving function, the advanced keyless
entry

*1

 system functions turn off and

the battery power consumption of the
transmitter is restricted.
The remote control function is
operational by operating the
transmitter switch even while the
power saving function is turned on.
However, the operation indicator light
of the transmitter does not turn on/
flash.

Turning on the power saving function

After you have turned on the power
saving function according to the
following procedure, the hazard
warning lights and sound operate

*1

one time.
1. Press the lock button on the

transmitter 4 times within 3
seconds to turn on the operation
indicator light.

2. Press the lock button continuously

for 1.5 seconds or longer while the
operation indicator light turns on
(for 5 seconds).

3. Press any of the buttons on the

transmitter to make sure that the
operation indicator light does not
turn on/flash.

Turning off the power saving function

After you have turned off the power
saving function according to the
following procedure, the hazard
warning lights and sound operate

*1

one time.
1. Press any of the buttons on the

transmitter to make sure that the
operation indicator light does not
turn on/flash.

2. Press the lock button on the

transmitter 4 times within 3
seconds to turn on the operation
indicator light.

3. Press the lock button continuously

for 1.5 seconds or longer while the
operation indicator light turns on
(for 5 seconds).

*

1

With the advanced keyless function

Operational Range

The system operates only when the
driver is in the vehicle or within
operational range while the key is
being carried.

Starting the engine

NOTE

x

Starting the engine may be possible
even if the key is outside of the
vehicle and extremely close to a door
and window, however, always start
the engine from the driver's seat.
If the vehicle is started and the key is
not in the vehicle, the vehicle will not
restart after it is shut off and the
ignition is switched off.

x

The luggage compartment/trunk is
out of the assured operational range,
however, if the key (transmitter) is
operable the engine will start.

Before Driving

Keys

3-7

With the advanced keyless function

1. Interior antenna
2. Operational range

Without the advanced keyless
function

1. Interior antenna
2. Operational range

NOTE

The engine may not start if the key is
placed in the following areas:

x

Around the dashboard

x

In the storage compartments such as
the glove compartment or the center
console

x

On the rear parcel shelf (4–door)

Key Suspend Function

If a key is left in the vehicle, the
functions of the key left in the vehicle
are temporarily suspended to prevent
theft of the vehicle.
To restore the functions, press the
unlock button on the
functions-suspended key in the
vehicle.

Before Driving

Keys

3-8

Advanced Keyless Entry

System

*

Advanced Keyless Entry System

WARNING

Radio waves from the key may affect
medical devices such as pacemakers:

Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will affect
the device.

The advanced keyless function allows
you to lock/unlock the door, liftgate,
and fuel-filler lid, or open the liftgate/
trunk lid while carrying the key.

System malfunctions or warnings are
indicated by the following warning
beeps.

x

Touch Sensor Inoperable Warning
Beep
Refer to Touch Sensor Inoperable
Warning Beep (With the advanced
keyless function) on page 7-45.

x

Liftgate Door-lock Switch Inoperable
Warning Beep
Refer to Liftgate Door-lock Switch
Inoperable Warning Beep (With the
advanced keyless function) on page
7-45.

x

Key Left-in-luggage Compartment/
Trunk Warning Beep
Refer to Key Left-in-luggage
Compartment/Trunk Warning Beep
(With the advanced keyless function)
on page 7-45.

x

Key Left-in-vehicle Warning Beep
Refer to Key Left-in-vehicle Warning
Beep (With the advanced keyless
function) on page 7-45.

NOTE

The advanced keyless entry system
functions can be deactivated to
prevent any possible adverse effect on
a user wearing a pacemaker or other
medical device. If the system is
deactivated, you will be unable to start
the engine by carrying the key. Consult
an Authorized Mazda Dealer for
details. If the advanced keyless entry
system has been deactivated, you can
start the engine by following the
procedure indicated when the key
battery goes dead.
Refer to Engine Start Function When
Key Battery is Dead on page 4-8.

Before Driving

Advanced Keyless Entry System

*Some models.

3-9

Operational Range

Operational Range

The system operates only when the
driver is in the vehicle or within
operational range while the key is
being carried.

NOTE

When the battery power is low, or in
places where there are high-intensity
radio waves or noise, the operational
range may become narrower or the
system may not operate. For
determining battery replacement,
Refer to Keyless Entry System on page
3-4.

Locking/Unlocking Using Touch
Sensor

1. Exterior antenna
2. 80 cm (31 in)
3. Operational range

NOTE

x

The system may not operate if you
are too close to the windows or door
handles.

x

If the key is left in the following areas
and you leave the vehicle, the doors
may be locked depending on the
radio wave conditions even if the key
is left in the vehicle.

x

Around the dashboard

x

In the storage compartments such
as the glove compartment or the
center console

x

On the rear parcel shelf (4–door)

x

Next to a communication device
such as a mobile phone

Locking Using Door-Lock Switch
(5–door)/Unlocking Using Electric
Opener

1. Exterior antenna
2. 80 cm (31 in)
3. Operational range

Before Driving

Advanced Keyless Entry System

3-10

Door Locks

Door Locks

WARNING

Always take all children and pets with
you or leave a responsible person
with them:

Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle
can become high enough to cause
brain damage or even death.

Do not leave the key in your vehicle
with children and keep them in a
place where your children will not
find or play with them:

Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed.

Keep all doors locked when driving:

Unlocked doors in a moving vehicle
are dangerous. Passengers can fall out
if a door is accidentally opened and
can more easily be thrown out in an
accident.

Always close all the windows and
moonroof, lock the doors, fuel-filler
lid, and liftgate and take the key with
you when leaving your vehicle
unattended:

Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle
left unlocked becomes an easy target
for thieves and intruders.

After closing the doors and the
liftgate/trunk lid, always verify that
they are securely closed:

Doors and the liftgate/trunk lid not
securely closed are dangerous, if the
vehicle is driven with a door and the
liftgate/trunk lid not securely closed,
the door and the liftgate/trunk lid
could open unexpectedly resulting in
an accident.

Always confirm the safety around the
vehicle before opening a door and the
liftgate/trunk lid:

Suddenly opening a door and the
liftgate/trunk lid is dangerous. A
passing vehicle or a pedestrian could
be hit and cause an accident.

CAUTION

¾

Always confirm the conditions
around the vehicle before opening/
closing the doors and the liftgate/
trunk lid and use caution during
strong winds or when parked on an
incline. Not being aware of the
conditions around the vehicle is
dangerous because fingers could get
caught in the door and the liftgate/
trunk lid or a passing pedestrian
could be hit, resulting in an
unexpected accident or injury.

Before Driving

Doors and Locks

3-11

NOTE

x

Always stop the engine and lock the
doors. In addition, to prevent theft of
valuables, do not leave them inside
the cabin.

x

If the key is left in the following areas
and you leave the vehicle, the doors
may be locked depending on the
radio wave conditions even if the key
is left in the vehicle.

x

Around the dashboard

x

In the storage compartments such
as the glove compartment or the
center console

x

On the rear parcel shelf (4–door)

x

Next to a communication device
such as a mobile phone

x

When the ignition is switched to
ACC or ON, the vehicle lock-out
prevention feature prevents you from
locking yourself out of the vehicle.
All doors, fuel-filler lid, and liftgate
will automatically unlock if they are
locked using the power door locks
with any door or the liftgate open.
The vehicle lock-out prevention
feature does not operate while the
ignition is switched off.
When all doors, fuel-filler lid, and
liftgate are locked using the power
door lock with any door or the
liftgate/trunk lid open, the closed
doors, fuel-filler lid, and liftgate are
locked. After that, when all doors
and the liftgate/trunk lid are closed,
all doors and the liftgate/trunk lid
are locked. However, if the key is
inside the vehicle, all doors,
fuel-filler lid, and liftgate are
automatically unlocked.

(With the advanced keyless
function)

The beep sound is heard for about
10 seconds to notify the driver that
the key has been left in the vehicle.

(Without the advanced keyless
function)

The horn sound is heard twice to
notify the driver that the key has
been left in the vehicle.

x

(Door unlock (control) system with
collision detection)

This system automatically unlocks the
doors, fuel-filler lid, and liftgate in
the event the vehicle is involved in an
accident to allow passengers to get
out of the vehicle immediately and
prevent being trapped inside. While
the ignition is switched ON and in
the event the vehicle receives an
impact strong enough to inflate the
air bags, all the doors, fuel-filler lid,
and liftgate are automatically
unlocked after about 6 seconds have
elapsed from the time of the
accident.
The doors, fuel-filler lid, and liftgate
may not unlock depending on how
an impact is applied, the force of the
impact, and other conditions of the
accident.
If door-related systems or the battery
is malfunctioning, the doors,
fuel-filler lid, and liftgate may not
unlock depending on your vehicle
type.

Before Driving

Doors and Locks

3-12















Content      ..     4      5      6      7     ..
