When installing a child-restraint system to the rear seat, refer to the child-restraint
system manufacturer's instructions and the Using ISOFIX Lower Anchor on page
2-50.

Seating position

Passenger

Rear (Left)

Rear (Center)

Rear (Right)

Seating position
suitable for univer-
sal belted (Yes/No)

Yes (UF)

Yes (U)

i-Size seating posi-
tion (Yes/No)

Largest suitable
rearward facing ﬁx-
ture (R1)

Yes (IL)

Largest suitable
rearward facing ﬁx-
ture (R2)

Yes (IL)

Largest suitable
rearward facing ﬁx-
ture (R2X)

Yes (IL)

Largest suitable
rearward facing ﬁx-
ture (R3)

Yes (IL)

Largest suitable for-
ward facing ﬁxture
(F2)

Yes (IUF)

Largest suitable for-
ward facing ﬁxture
(F2X)

Yes (IUF)

Largest suitable for-
ward facing ﬁxture
(F3)

Yes (IUF)

Largest suitable lat-
eral facing ﬁxture
(L1)

Largest suitable lat-
eral facing ﬁxture
(L2)

Largest suitable
booster ﬁxture (B2)

Yes (IUF)

Largest suitable
booster ﬁxture (B3)

Yes (IUF)

Essential Safety Equipment

Child Restraint

2-40

Seating position

Passenger

Rear (Left)

Rear (Center)

Rear (Right)

Non i-size compat-
ible with a support
leg (Yes/No)

Yes

Lower ISOFIX an-
chorages but with-
out Top Tether
(Yes/No)

U = Suitable for “universal” category restraints approved for use in this mass group.
UF = Suitable for forward-facing “universal” category restraints approved for use in this mass group.
IUF = Suitable for ISOFIX forward child restraints systems of universal category approved for use in the
mass group.
L = Suitable for particular child restraints given on attached list. These restraints may be of the “speciﬁc
vehicle”, “restricted” or “semi-universal” categories.
IL = Suitable for particular ISOFIX child restraint systems (CRS) given in the attached list. These ISOFIX CRS
are those of the “speciﬁc vehicle”, “restricted” or “semi-universal” categories.
i-U = Suitable for i-Size “universal” Child Restraint Systems forward and rearward facing.
i-UF = Suitable for forward-facing i-Size “universal” Child Restraint Systems only.
Yes = Child-restraint system can be secured on the seat.
No = Child-restraint system cannot be secured on the seat, or there is no ﬁxture.
X = Child-restraint system cannot be installed.

Child restraint system can only be installed in the forward-facing position.

A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be
installed, refer to the accessories catalog.

(Except Mexico)

Regarding child-restraint systems which can be installed to your Mazda, consult an
Authorized Mazda Dealer.

A child-restraint system with a support leg cannot be installed on the rear center
seat position.

Please comply with the legal regulations concerning the use of child-restraint
systems in your country.

For the CRS which do not carry the ISO/XX size class identiﬁcation (A to G), for
the applicable mass group, the child seat manufacturer shall indicate the vehicle
speciﬁc LATCH child-restraint systems recommended for each position.

Essential Safety Equipment

Child Restraint

2-41

Installing Child-Restraint

Systems

▼

Installing Child-Restraint Systems

Accident statistics reveal that a child is
safer in the rear seat. The front
passenger's seat is clearly the worst
choice for any child under 12, and
with rear-facing child-restraint systems
it is clearly unsafe due to air bags.

NOTE

Even if your vehicle is equipped with
front passenger occupant classiﬁcation
sensor (page 2-71), which
automatically deactivates the front
passenger air bag, a rear seat is the
safest place for a child of any age or
size.

Some child-restraint systems now
come with tethers and therefore must
be installed on the seats that take
tethers to be effective. In your Mazda,
tethered child-restraint systems can
only be accommodated in the three
positions on the rear seat.

Some child-restraint systems also
employ specially designed ISOFIX/
LATCH

attachments; refer to "Using

ISOFIX Lower Anchor (Mexico)/Using
LATCH Lower Anchor (Except
Mexico)" (page 2-50).

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

WARNING

Tethered Child-Restraint Systems
Work Only on Tether-Equipped Rear
Seats:

Installation of a tether equipped
child-restraint system in the front
passenger's seat defeats the safety
design of the system and will result in
an increased chance of serious injury if
the child-restraint system goes forward
without beneﬁt of being tethered.
Place tether equipped child-restraint
systems where there are tether
anchors.

▼

Anchor Bracket

Anchor brackets for securing
child-restraint systems are equipped in
the vehicle. Locate each anchor
position using the illustration.
To install a child-restraint system,
remove the head restraint. Always
follow the instruction manual
accompanying the child-restraint
system.

Anchor bracket location

Use the indicated anchor bracket
locations when installing a
child-restraint system equipped with a
tether.

(4–Door)

1. For right
2. For center (Except Mexico)
3. For left

Essential Safety Equipment

Child Restraint

2-42

4. Anchor bracket

(5–Door)

1. For right
2. For center (Except Mexico)
3. For left

WARNING

Always attach the tether strap to the
correct tether anchor position:

Attaching the tether strap to the
incorrect tether anchor position is
dangerous. In a collision, the tether
strap could come off and loosen the
child-restraint system. If the
child-restraint system moves it could
result in death or injury to the child.

Always remove the head restraint and
install child-restraint system:

Installing a child-restraint system
without removing the head restraint is
dangerous. The child-restraint system
cannot be installed correctly which
may result in death or injury to the
child in a collision.

(4–Door)

1. Tether strap
2. Anchor bracket

Essential Safety Equipment

Child Restraint

2-43

(5–Door)

1. Tether strap
2. Anchor bracket
3. Forward

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system:

Driving with the head restraint
removed is dangerous as impact to the
occupant's head cannot be prevented
during emergency braking or in a
collision, which could result in a
serious accident, injury or death.
Refer to Head Restraints on page 2-17.

▼

Using Automatic Locking Mode
(Except Mexico)

Follow these instructions when using a
child-restraint system, unless you are
attaching a LATCH-equipped
child-restraint system to the rear
LATCH lower anchors. Refer to “Using
LATCH Lower Anchor” (page 2-50).

NOTE

Follow the child-restraint system
manufacturer's instructions carefully. If
you are not sure whether you have a
LATCH system or tether, check in the
child-restraint system manufacturer's
instructions and follow them
accordingly. Depending on the type of
child-restraint system, it may use
LATCH system instead of seat belts or if
the belt goes across the child's chest,
may recommend against using
automatic locking mode.

1. Make sure the seatback is securely

latched by pushing it back until it is
fully locked.

2. Remove the head restraint.

However, when installing a backless
booster seat, always install the
vehicle head restraint to the seat
where the backless booster seat is
installed.
Refer to Head Restraints on page
2-17.

3. Secure the child-restraint system

with the lap portion of the lap/
shoulder belt. See the
manufacturer's instructions on the
child-restraint system for belt
routing instructions.

Essential Safety Equipment

Child Restraint

2-44

4. To get the retractor into the

automatic locking mode, pull the
shoulder belt portion of the seat
belt until the entire length of the
belt is out of the retractor.

5. Push the child-restraint system

ﬁrmly into the vehicle seat. Be sure
the belt retracts as snugly as
possible. A clicking noise from the
retractor will be heard during
retraction if the system is in the
automatic locking mode. If the belt
does not lock the seat down tight,
repeat this step.

NOTE

Inspect this function before each
use of the child-restraint system.
You should not be able to pull the
shoulder belt out of the retractor
while the system is in the
automatic locking mode. When
you remove the child-restraint
system, be sure the belt fully
retracts to return the system to
emergency locking mode before
occupants use the seat belts.

6. If your child-restraint system

requires the use of a tether strap,
refer to the manufacturer's
instructions to hook and tighten the
tether strap.

WARNING

Use the tether and tether anchor only
for a child-restraint system:

Using the tether or tether anchor to
secure anything but a child-restraint
system is dangerous. This could
weaken or damage the tether or tether
anchor and result in injury.

Always remove the head restraint and
install child-restraint system (except
when installing a backless booster
seat):

Essential Safety Equipment

Child Restraint

2-45

(4–Door)

1. Tether strap
2. Anchor bracket

(5–Door)

1. Tether strap
2. Anchor bracket
3. Forward

Always attach the tether strap to the
correct tether anchor position:

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system:

Essential Safety Equipment

Child Restraint

2-46

▼

If You Must Use the Front Seat for
Children

If you cannot put all children in the
rear seat, at least put the smallest
children in the rear and be sure the
largest child up front uses the shoulder
belt over the shoulder.
NEVER put a rear-facing child-restraint
system on the front passenger seat
whether your vehicle is equipped with
an occupant classiﬁcation sensor or
not.
This seat is also not set up for tethered
child-restraint systems, put them in
one of the rear seat positions set up
with tether anchors.
Likewise the ISOFIX/LATCH

child-restraint system cannot be
secured in the front passenger's seat
and should be used in the rear seat.
Do not allow anyone to sleep against
the side window since your vehicle has
side and curtain air bags, it could
cause serious injuries to an out of
position occupant. As children more
often sleep in cars, it is better to put
them in the rear seat. If installing the
child-restraint system on the front seat
is unavoidable, follow these
instructions when using a front-facing
child-restraint system in the front
passenger's seat.

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

NOTE

To check if your front seats have side
air bags:
Mazda vehicles equipped with side
air bag will have a "SRS AIRBAG" tag
on the outboard shoulder of the
front seats.

To check if your vehicle has curtain
air bags:
Mazda vehicles equipped with
curtain air bag will have an "SRS
AIRBAG" marking on the window
pillars along the roof edge.

WARNING

Always move the front passenger seat
as far back as possible if installing a
front-facing child-restraint system on
it is unavoidable:

As your vehicle has front air bags and
doubly so because your vehicle has
side air bags, a front-facing
child-restraint system should be put on
the front passenger seat only when it is
unavoidable.
Even if the front passenger air bag
deactivation indicator light illuminates,
always move the seat as far back as
possible, because the force of a
deploying air bag could cause serious
injury or death to the child.

Never use a rear-facing child-restraint
system in the front seat with an air
bag that could deploy:

Rear-facing child-restraint systems on
the front seat are particularly
dangerous.
Even in a moderate collision, the
child-restraint system can be hit by a
deploying air bag and moved violently
backward resulting in serious injury or
death to the child. Even though you
may feel assured that the front
passenger air bag will not deploy
based on the fact that the front
passenger air bag deactivation
indicator light illuminates, you should
not use a rear-facing child-restraint
system in the front seat.

Essential Safety Equipment

Child Restraint

2-47

Do not allow a child or anyone to
lean over to or against the side
window of a vehicle with side and
curtain air bags:

It is dangerous to allow anyone to lean
over to or against the side window, the
area of the front passenger seat, the
front and rear window pillars and the
roof edge along both sides from which
the side and curtain air bags deploy,
even if a child-restraint system is used.
The impact of inﬂation from a side or
curtain air bag could cause serious
injury or death to an out of position
child. Furthermore, leaning over to or
against the door could block the side
and curtain air bags and eliminate the
advantages of supplemental
protection. Because the front seats are
equipped with front air bags, the rear
seat is always a better location for
children. Take special care not to allow
a child to lean over to or against the
side window, even if the child is seated
in a child-restraint system.

Always remove the head restraint and
install child-restraint system (except
when installing a backless booster
seat):

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system:

Front Passenger's Seat Child-Restraint
System Installation (With Front
Passenger Occupant Classiﬁcation
System)

1. Make sure the ignition is switched

off.

2. Slide the seat as far back as

possible.

3. Remove the head restraint.

However, when installing a backless
booster seat, always install the
vehicle head restraint to the seat
where the backless booster seat is
installed.

4. Place the child-restraint system on

the seat without putting your
weight on the seat and fasten the
seat belt. See the manufacturer's
instructions on the child-restraint
system for belt routing instructions.

Essential Safety Equipment

Child Restraint

2-48

5. To get the retractor into the

automatic locking mode, pull the
shoulder belt portion of the seat
belt until the entire length of the
belt is out of the retractor.

6. Push the child-restraint system

ﬁrmly into the vehicle seat. Be sure
the belt retracts as snugly as
possible. A clicking noise from the
retractor will be heard during
retraction if the system is in
automatic locking mode. If the belt
does not lock the seat down tight,
repeat the previous step and also
this one.

NOTE

Follow the child-restraint system
manufacturer's instructions
carefully.
Depending on the type of
child-restraint system, it may not
employ seat belts which are in
automatic locking mode.

7. Seat your child safely in the

child-restraint system and secure
the child according to the
instructions from the child-restraint
system manufacturer.

8. Switch the ignition ON and make

sure the front passenger air bag
deactivation indicator light
illuminates after installing a
child-restraint system on the front
passenger seat.
If the front passenger air bag
deactivation indicator light does
not illuminate, remove the
child-restraint system, switch the
ignition to OFF, and then re-install
the child-restraint system (page
2-71).

Essential Safety Equipment

Child Restraint

2-49

WARNING

Do not seat a child in a child-restraint
system on the front passenger seat if
the front passenger air bag
deactivation indicator light does not
illuminate:

While it is always better to install any
child-restraint system on the rear seat,
it is imperative that a child-restraint
system

ONLY

be used on the front

passenger seat if the deactivation
indicator light illuminates when the
child is seated in the child-restraint
system (page 2-71). Seating a child in
a child-restraint system installed on the
front passenger seat with the front
passenger air bag deactivation
indicator light not illuminated is
dangerous. If this indicator light does
not illuminate, this means that the
front passenger front and side air bags,
and knee air bags, and seat belt
pretensioners are ready for
deployment. If an accident were to
deploy an air bag, a child in a
child-restraint system sitting in the
front passenger seat could be seriously
injured or killed. If the indicator light
does not illuminate after seating a
child in a child-restraint system on the
front passenger seat, seat a child in a
child-restraint system on the rear seat
and consult an Authorized Mazda
Dealer as soon as possible.

▼

Using ISOFIX Lower Anchor
(Mexico)/Using LATCH Lower
Anchor (Except Mexico)

Your Mazda is equipped with ISOFIX/
LATCH

lower anchors for attachment

of specially designed ISOFIX/LATCH

child-restraint systems in the rear seats.
Both anchors must be used, otherwise
the seat will bounce around and put
the child in danger. Most ISOFIX/
LATCH

child-restraint systems must

also be used in conjunction with a
tether to be effective. If they have a
tether you must use it to better assure
your child's safety.

WARNING

Follow the manufacturer's
instructions for the use of the
child-restraint system:

An unsecured child-restraint system is
dangerous. In a sudden stop or a
collision it could move causing serious
injury or death to the child or other
occupants. Make sure the
child-restraint system is properly
secured in place according to the
child-restraint system manufacturer's
instructions.

Essential Safety Equipment

Child Restraint

2-50

Never attach two child-restraint
systems to the same ISOFIX/LATCH

lower anchor:

Attaching two child-restraint systems
to the same ISOFIX/LATCH

lower

anchor is dangerous. In a collision, one
anchor may not be strong enough to
hold two child-restraint system
attachments, and it may break, causing
serious injury or death. If you use the
seat position for another child-restraint
system when an outboard ISOFIX/
LATCH

position is occupied, use the

center seat belts instead, and the
tether if tether-equipped.

Make sure the child-restraint system is
properly secured:

An unsecured child-restraint system is
dangerous. In a sudden stop or a
collision it could move causing serious
injury or death to the child or other
occupants. Follow the child-restraint
system manufacturer's instructions on
belt routing to secure the seat just as
you would with a child in it so that
nobody is tempted to put a child in an
improperly secured seat later on.
When not in use, remove it from the
vehicle or fasten it with a seat belt, or
attach it to BOTH ISOFIX/LATCH

lower anchors for ISOFIX/LATCH

child-restraint systems.

Make sure there are no seat belts or
foreign objects near or around the
ISOFIX/LATCH

child-restraint

system:

Not following the child-restraint system
manufacturer's instructions when
installing the child-restraint system is
dangerous. If seat belts or a foreign
object prevent the child-restraint
system from being securely attached to
the ISOFIX/LATCH

lower anchors

and the child-restraint system is
installed improperly, the child-restraint
system could move in a sudden stop or
collision causing serious injury or death
to the child or other occupants. When
installing the child-restraint system,
make sure there are no seat belts or
foreign objects near or around the
ISOFIX/LATCH

lower anchors.

Always follow the child-restraint
system manufacturer's instructions.

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

Installation on rear outboard seats

1. First, adjust the front seat to allow

clearance between the
child-restraint system and the front
seat.
Refer to Adjusting the Driver's Seat
on page 2-5.
Refer to Adjusting the Front
Passenger's Seat on page 2-13.

2. Make sure the seatback is securely

latched by pushing it back until it is
fully locked.

Essential Safety Equipment

Child Restraint

2-51

3. Remove the cover of the

child-restraint system's ISOFIX/
LATCH

lower anchors to verify the

locations of the ISOFIX/LATCH

lower anchors.

1. Lower anchor

NOTE

The ISOFIX/LATCH

lower

anchors marking on the cover
indicates the position of the
ISOFIX/LATCH

lower anchors

for the attachment of a
child-restraint system.

Store the removed cover so that it
does not get lost.

4. Remove the head restraint.

However, when installing a backless
booster seat, always install the
vehicle head restraint to the seat
where the backless booster seat is
installed.
Refer to Head Restraints on page
2-17.

5. Secure the child-restraint system

using BOTH ISOFIX/LATCH

lower

anchors, following the
child-restraint system
manufacturer's instruction. Pull on
the child-restraint to be sure both
anchors are engaged.

6. If your child-restraint system came

equipped with a tether, that means
it is very important to properly
secure the tether for child safety.
Please carefully follow the
child-restraint system
manufacturer's instructions when
installing tethers.

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

WARNING

Use the tether and tether anchor only
for a child-restraint system:

Using the tether or tether anchor to
secure anything but a child-restraint
system is dangerous. This could
weaken or damage the tether or tether
anchor and result in injury.

Always remove the head restraint and
install child-restraint system (except
when installing a backless booster
seat):

(4–Door)

1. Tether strap

Essential Safety Equipment

Child Restraint

2-52

2. Anchor bracket

(5–Door)

1. Tether strap
2. Anchor bracket
3. Forward

Always attach the tether strap to the
correct tether anchor position:

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system:

Installation on rear center seat

The ISOFIX/LATCH

lower anchors at

the center of the rear seat are much
further apart than the sets of ISOFIX/
LATCH

lower anchors for

child-restraint system installation at
other seating positions. Child-restraint
systems with rigid ISOFIX/LATCH

attachments cannot be installed on the
center seating position. Some ISOFIX/
LATCH

equipped child-restraint

systems can be placed in the center
position and will reach the nearest
ISOFIX/LATCH

lower anchors which

are 434 mm (17.1 in) apart. ISOFIX/
LATCH

compatible child-restraint

systems (with attachments on belt
webbing) can be used at this seating
position only if the child-restraint
system manufacturer's instructions
state that the child-restraint system can
be installed to ISOFIX/LATCH

lower

anchors that are 434 mm (17.1 in)
apart. Do not attach two child-restraint
systems to the same ISOFIX/LATCH

lower anchor. If your child-restraint
system has a tether, it must also be
used for your child's optimum safety.

The procedure is the same as the
installation for the rear outboard seats.

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

Essential Safety Equipment

Child Restraint

2-53

ISOFIX/LATCH

lower anchor

location

WARNING

Always remove the head restraint and
install child-restraint system (except
when installing a backless booster
seat):

(4–Door)

1. Tether strap
2. Anchor bracket

(5–Door)

1. Tether strap
2. Anchor bracket
3. Forward

Always attach the tether strap to the
correct tether anchor position:

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system:

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

Essential Safety Equipment

Child Restraint

2-54

Supplemental Restraint

System (SRS) Precautions

▼

Supplemental Restraint System
(SRS) Precautions

The front and side supplemental
restraint systems (SRS) include different
types of air bags.

Please verify the

different types of air bags which are
equipped on your vehicle by locating
the “SRS AIRBAG” location indicators.

These indicators are visible in the area
where the air bags are installed.
The air bags are installed in the
following locations:

The steering wheel hub (driver air
bag)

The front passenger dashboard (front
passenger air bag)

Under the instrument panel (driver
and front passenger

knee air bags)

The outboard sides of the front
seatbacks (side air bags)

The front and rear window pillars,
and the roof edge along both sides
(curtain air bags)

Vehicles with the Front Passenger
Occupant Classiﬁcation System have a
sensor which detects an impending
roll-over accident.

The air bag supplemental restraint
systems are designed to provide
supplemental protection in certain
situations so seat belts are always
important in the following ways:

Without seat belt usage, the air bags
cannot provide adequate protection
during an accident. Seat belt usage is
necessary to:

Keep the occupant from being
thrown into an inﬂating air bag.

Reduce the possibility of injuries
during an accident that is not
designed for air bag inﬂation, such as
rear impact.

Reduce the possibility of injuries in
frontal, near frontal or side collisions
or roll-over accidents that are not
severe enough to activate the air
bags.

Reduce the possibility of being
thrown from your vehicle.

Reduce the possibility of injuries to
lower body and legs during an
accident because the air bags
provide no protection to these parts
of the body.

Hold the driver in a position which
allows better control of the vehicle.

Essential Safety Equipment

SRS Air Bags

*Some models.

2-55

Mazda 3 Hatchback (2022 year). Manual in english - page 4
