Do not operate a vehicle with a
damaged seat belt:

Using a damaged seat belt is
dangerous. An accident could damage
the belt webbing of the seat belt in
use. A damaged seat belt cannot
provide adequate protection in a
collision. Have an Authorized Mazda
Dealer inspect all seat belt systems in
use during an accident before they are
used again.

Have your seat belts changed
immediately if the pretensioner or
load limiter has been expended:

Always have an Authorized Mazda
Dealer immediately inspect the seat
belt pretensioners and air bags after
any collision. Like the air bags, the seat
belt pretensioners and load limiters
will only function once and must be
replaced after any collision that caused
them to deploy. A seat belt with an
expended pretensioner or load limiter
is still better than wearing no seat belt
at all; however, if the seat belt
pretensioners and load limiters are not
replaced, the risk of injury in a collision
will increase.

Positioning the Shoulder Portion of
the Seat Belt:

Improper positioning of the shoulder
portion of the seat belt is dangerous.
Always make sure the shoulder portion
of the seat belt is positioned across
your shoulder and near your neck, but
never under your arm, on your neck, or
on your upper arm.

Positioning the Lap Portion of the Seat
Belt:

The lap portion of the seat belt worn
too high is dangerous. In a collision,
this would concentrate the impact
force directly on the abdominal area,
causing serious injury. Wear the lap
portion of the belt snugly and as low as
possible.

CAUTION

Belt retraction may become difficult if
the belts and rings are soiled, so try to
keep them clean. For more details
about cleaning the seat belts, refer to
"Seat Belt Maintenance" (page
6-53).

1. Ring

Essential Safety Equipment

Seat Belt Systems

2-24

Pregnant Women and Persons with
Serious Medical Conditions

Pregnant women should always wear
seat belts. Ask your doctor for specific
recommendations.
The lap belt should be worn SNUGLY
AND AS LOW AS POSSIBLE OVER THE
HIPS.
The shoulder belt should be worn
across your shoulder properly, but
never across the stomach area.
Persons with serious medical
conditions also should wear seat belts.
Check with your doctor for any special
instructions regarding specific medical
conditions.

Emergency Locking Mode

When the seat belt is fastened, it will
always be in the emergency locking
mode.
In the emergency locking mode, the
belt remains comfortable on the
occupant and the retractor will lock in
position during a collision.
If the belt is locked and cannot be
pulled out, retract the belt once, and
then try pulling it out slowly. If this
fails, pull the belt strongly 1 time and
loosen, then pull it out again slowly.

(Seat Belt with Automatic Locking
Mode)

When the seat belt is fastened, it will
always be in the emergency locking

mode until it is switched to automatic
locking mode by pulling it all the way
out to its full length. If the belt feels
tight and hinders comfortable
movement while the vehicle is stopped
or in motion, it may be in the
automatic locking mode because the
belt has been pulled too far out. To
return the belt to the more
comfortable emergency locking mode,
wait until the vehicle has stopped in a
safe, level area, retract the belt fully to
convert it back to emergency locking
mode and then extend it around you
again.

Automatic Locking Mode (Except
Mexico)

Always use the automatic locking
mode to keep the child-restraint
system from shifting to an unsafe
position in the event of an accident. To
enable seat belt automatic locking
mode, pull it all the way out and
connect it as instructed on the
child-restraint system. It will retract
down to the child-restraint system and
stay locked on it. See the section on
child restraint (page 2-44).

Essential Safety Equipment

Seat Belt Systems

2-25

Seat Belt

Fastening the Seat Belt

Insert the seat belt tongue into the
buckle.

1. Seat belt tongue
2. Seat belt buckle

Position the lap belt as low as possible,
not on the abdominal area, then adjust
the shoulder belt so that it fits snugly
against your body.

1. Keep low on hip bone
2. Take up slack
3. Too high

Before fastening the rear seat belt,
make sure that the seat belt passes
through the seat belt guide correctly
and it is not twisted.

Unfastening the Seat Belt

Depress the button on the seat belt
buckle. If the belt does not fully retract,
pull it out and check for kinks or twists.
Then make sure it remains untwisted as
it retracts.

1. Button

NOTE

If a belt does not fully retract, inspect it
for kinks and twists. If it is still not
retracting properly, have it inspected at
an Authorized Mazda Dealer.

Essential Safety Equipment

Seat Belt Systems

2-26

Front Shoulder Belt Adjuster

The front seat belts have a front
shoulder belt adjuster. If the seat belt
contacts your neck or it slips off the
shoulder, adjust the seat belt height.

To raise

To heighten the seat belt, move the
front shoulder belt adjuster upward.

To lower

To lower the seat belt, hold the front
shoulder belt adjuster and lower the
seat belt with the knob of the front
shoulder belt adjuster pressed.

After adjusting, press the front
shoulder belt adjuster downward and
make sure that it is securely locked.

Seat Belt Warning

Systems

Seat Belt Warning Systems

If it detects that the occupant seat belt
is unfastened, the warning light or
beep alerts the occupant.
Refer to Seat Belt Warning Indication/
Warning Light (Front seat) on page
7-36.
Refer to Seat Belt Warning Light (Rear
seat) (Red) on page 7-37.
Refer to Seat Belt Warning Beep on
page 7-43.

Seat belt indicator light (rear seat)
(green)

The light turns on when the rear seat
belt is fastened while the ignition is
switched ON, and it turns off after a
certain period.

Essential Safety Equipment

Seat Belt Systems

2-27

Front Seat Belt

Pretensioner and Load

Limiting Systems

Front Seat Belt Pretensioner and
Load Limiting Systems

For optimum protection, the driver and
front passenger seat belts are
equipped with pretensioner and load
limiting systems. For both these
systems to work properly you must
wear the seat belt properly.

Pretensioners:

When a collision is detected, the
pretensioners deploy simultaneously
with the air bags.
For vehicles with the front passenger
occupant classification system, the
pretensioners deploy simultaneously
with the air bags when a roll-over is
also detected.
For deployment details, refer to the
SRS Air Bag Deployment Criteria (page
2-67).

The seat belt retractors remove slack
quickly as the air bags are expanding.
Any time the air bags and seat belt
pretensioners have fired they must be
replaced.
A system malfunction or operation
conditions are indicated by a warning.
Refer to Air Bag/Front Seat Belt
Pretensioner System Warning
Indication/Warning Light on page
7-33.

(With Front Passenger Occupant
Classification System)

In addition, the pretensioner system
for the front passenger, like the front
and side passenger air bag, is designed
to only deploy in accordance with the
total seated weight on the front
passenger seat.
For details, refer to the front passenger
seat weight sensors (page 2-71).

Load limiter:

The load limiting system releases belt
webbing in a controlled manner to
reduce belt force on the occupant's
chest. While the most severe load on a
seat belt occurs in frontal collisions,
the load limiter has an automatic
mechanical function and can activate
in any accident mode with sufficient
occupant movement.
Even if the pretensioners have not
fired, the load limiting function must
be checked by an Authorized Mazda
Dealer.

WARNING

Wear seat belts only as recommended
in this owner's manual:

Incorrect positioning of the seat belts is
dangerous. Without proper
positioning, the pretensioner and load
limiting systems cannot provide
adequate protection in an accident
and this could result in serious injury.
For more details about wearing seat
belts, refer to "Fastening the Seat Belt"
(page 2-26).

Essential Safety Equipment

Seat Belt Systems

2-28

Have your seat belts changed
immediately if the pretensioner or
load limiter has been expended:

Always have an Authorized Mazda
Dealer immediately inspect the seat
belt pretensioners and air bags after
any collision. Like the air bags, the seat
belt pretensioners and load limiters
will only function once and must be
replaced after any collision that caused
them to deploy. A seat belt with an
expended pretensioner or load limiter
is still better than wearing no seat belt
at all; however, if the seat belt
pretensioners and load limiters are not
replaced, the risk of injury in a collision
will increase.

Do not modify the components or
wiring, or use electronic testing
devices on the pretensioner system:

Modifying the components or wiring of
the pretensioner system, including the
use of electronic testing devices is
dangerous. You could accidentally
activate it or make it inoperable which
would prevent it from activating in an
accident. The occupants or repairers
could be seriously injured.

Properly dispose of the pretensioner
system:

Improper disposal of the pretensioner
system or a vehicle with
non-deactivated pretensioners is
dangerous. Unless all safety
procedures are followed, injury could
result. Have an Authorized Mazda
Dealer safely dispose of the
pretensioner system or scrap a
pretensioner system equipped vehicle.

NOTE

x

The pretensioner system may not
operate depending on the type of
the collision. For details, refer to the
SRS Air Bag Deployment Criteria
(page 2-67).

x

Some smoke (non-toxic gas) will be
released when the air bags and
pretensioners deploy. This does not
indicate a fire. This gas normally has
no effect on occupants, however,
those with sensitive skin may
experience light skin irritation. If
residue from the deployment of the
air bags or the pretensioner system
gets on the skin or in the eyes, wash
it off as soon as possible.

Essential Safety Equipment

Seat Belt Systems

2-29

Seat Belt Extender

Seat Belt Extender

If your seat belt is not long enough,
even when fully extended, a seat belt
extender may be available to you at no
charge from your Authorized Mazda
Dealer.
This extender will be only for you and
for the particular vehicle and seat. Even
if it plugs into other seat belts, it may
not hold in the critical moment of a
crash.
When ordering an extender, only order
one that provides the necessary
additional length to fasten the seat belt
properly. Please contact your
Authorized Mazda Dealer for more
information.

WARNING

Do not use a seat belt extender unless
it is necessary:

Using a seat belt extender when not
necessary is dangerous. The seat belt
will be too long and not fit properly. In
an accident, the seat belt will not
provide adequate protection and you
could be seriously injured. Only use
the extender when it is required to
fasten the seat belt properly.

Do not use an improper extender:

Using a seat belt extender that is for
another person or a different vehicle or
seat is dangerous. The seat belt will not
provide adequate protection and the
user could be seriously injured in an
accident. Only use the extender
provided for you and for the particular
vehicle and seat. NEVER use the
extender in a different vehicle or seat.
If you sell your Mazda, do not leave
your seat belt extender in the vehicle.
It could be used accidentally by the
new owner of the vehicle. After
removing the seat belt extender,
discard it. Never use the seat belt
extender in any other vehicle you may
own in the future.

Do not use an extender that is too
long:

Using an extender that is too long is
dangerous. The seat belt will not fit
properly. In an accident, the seat belt
will not provide adequate protection
and you could be seriously injured. Do
not use the extender or choose one
shorter in length if the distance
between the extender's buckle and the
center of the user's body is less than
15 cm (6 in).

Essential Safety Equipment

Seat Belt Systems

2-30

Do not leave a seat belt extender
connected to the buckle:

Leaving a seat belt extender connected
to the buckle without using the seat
belt is dangerous. When the seat belt
extender is connected to the driver's
seat belt buckle (or front passenger's
seat belt buckle), the SRS driver's (or
front passenger's) air bag system will
determine that the driver (or front
passenger) is wearing the seat belt
even if the driver (or front passenger) is
not wearing it. This condition could
cause the driver's (or front
passenger's) air bag to not activate
correctly and result in death or serious
injury in the event of collision. Always
wear the seat belt with the seat belt
extender.

Do not use the seat belt extender
when installing a child-restraint
system on the front or rear passenger
seat:

Using a seat belt extender to fasten a
child-restraint system on any seat is
dangerous. Always follow the
child-restraint system manufacturer's
installation instructions and never use
a seat belt extender.

NOTE

When not in use, remove the seat belt
extender and store it in the vehicle. If
the seat belt extender is left
connected, the seat belt extender
might get damaged as it will not retract
with the rest of the seat belt and can
easily fall out of the door when not in
use and be damaged. In addition, the
seat belt warning light will not
illuminate and function properly.

Essential Safety Equipment

Seat Belt Systems

2-31

Child-Restraint

Precautions

Child-Restraint Precautions

Mazda strongly urges the use of
child-restraint systems for children
small enough to use them.

You are required by law to use a
child-restraint system for children in
the U.S. and Canada.
Check your local and state or
provincial laws for specific
requirements regarding the safety of
children riding in your vehicle.

Whatever child-restraint system you
consider, please pick the appropriate
one for the age and size of the child,
obey the law and follow the
instructions that come with the
individual child-restraint system.

A child who has outgrown
child-restraint systems should sit in the
rear and use seat belts, both lap and
shoulder. If the shoulder belt crosses
the neck or face, move the child closer
to the center of the vehicle in the
outboard seats, and towards the
buckle on the right if the child is seated
on the center seat.

Statistics confirm that the rear seat is
the best place for all children up to 12
years of age, and more so with a
supplemental restraint system (air
bags).

A rear-facing child-restraint system
should

NEVER

 be used on the front

seat with the air bag system activated.
The front passenger's seat is also the
least preferred seat for other
child-restraint systems.

(With Front Passenger Occupant
Classification System)

To reduce the chance of injuries
caused by deployment of the front
passenger air bag, the front passenger
seat weight sensors occupant
classification sensor works as a part of
the supplemental restraint system. This
system deactivates the front passenger
front and side air bags and knee air
bags, and also the front passenger seat
belt pretensioner system when the
front passenger air bag deactivation
indicator light illuminates.

When an infant or small child sits on
the front passenger seat, the system
shuts off the front passenger front and
side air bags and knee air bags, and
seat belt pretensioner system, so make
sure the front passenger air bag
deactivation indicator light illuminates.

Even if the front passenger air bag is
shut off, Mazda strongly recommends
that children be properly restrained
and child-restraint systems of all kinds
are properly secured on the rear seats
which are the best place for children.

For more details, refer to "Front
passenger seat weight sensors" (page
2-71).

Essential Safety Equipment

Child Restraint

2-32

WARNING

Use the correct size child-restraint
system:

For effective protection in vehicle
accidents and sudden stops, a child
must be properly restrained using a
seat belt or child-restraint system
depending on age and size. If not, the
child could be seriously injured or even
killed in an accident.

Follow the manufacturer's
instructions and always keep the
child-restraint system buckled down:

An unsecured child-restraint system is
dangerous. In a sudden stop or a
collision it could move causing serious
injury or death to the child or other
occupants. Make sure any
child-restraint system is properly
secured in place according to the
child-restraint system manufacturer's
instructions. When not in use, remove
it from the vehicle or fasten it with a
seat belt, or attach it to BOTH ISOFIX/
LATCH

*1

 lower anchors for ISOFIX/

LATCH

*1

 child-restraint systems and

the corresponding tether anchor.

*

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

Always secure a child in a proper
child-restraint system:

Holding a child in your arms while the
vehicle is moving is extremely
dangerous. No matter how strong the
person may be, he or she cannot hold
onto a child in a sudden stop or
collision and it could result in serious
injury or death to the child or other
occupants. Even in a moderate
accident, the child may be exposed to
air bag forces that could result in
serious injury or death to the child, or
the child may be slammed into an
adult, causing injury to both child and
adult.

Never use a rear-facing child-restraint
system in the front seat with an air
bag that could deploy:

Rear-facing child-restraint systems on
the front seat are particularly
dangerous even though you may feel
assured that a front passenger air bag
will not deploy based on the fact that
the front passenger air bag
deactivation indicator light illuminates.
The child-restraint system can be hit by
a deploying air bag and moved
violently backward resulting in serious
injury or death to the child.

Essential Safety Equipment

Child Restraint

2-33

(Mexico)

NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it, DEATH
or SERIOUS INJURY to the CHILD can
occur.
Vehicles with a front passenger air bag
have the following warning label. The
warning label reminds you not to put a
rear-facing child-restraint system on
the front passenger seat at any time.

(Except Mexico)

Vehicles with a front passenger air bag
have the following warning label. The
warning label reminds you not to put a
rear-facing child-restraint system on
the front passenger seat at any time.

Do not install a front-facing
child-restraint system on the front
passenger seat unless it is
unavoidable:

In a collision, the force of a deploying
air bag could cause serious injury or
death to the child. If installing a
front-facing child-restraint system on
the front passenger seat is
unavoidable, move the front passenger
seat as far back as possible.

Seating a child in a child-restraint
system on the front passenger seat is
dangerous under certain conditions
(With Front Passenger Occupant
Classification System):

Your vehicle is equipped with front
passenger seat weight sensors. Even
with the front passenger seat weight
sensors, if you must use the front
passenger seat to seat a child, using a
child-restraint system on the front
passenger seat under the following
conditions increases the danger of the
front passenger air bag deploying and
could result in serious injury or death
to the child.

Essential Safety Equipment

Child Restraint

2-34

¾

The front passenger air bag
deactivation indicator light does not
illuminate when seating a child in the
child-restraint system.

¾

Luggage or other items are placed on
the seat with the child in the
child-restraint system.

¾

A rear passenger or luggage pushing
or pulling down on the front
passenger seatback.

¾

Luggage or other items are placed on
the seatback or hung on the head
restraint.

¾

The seat is washed.

¾

Liquids are spilled on the seat.

¾

The front passenger seat is moved
backward, pushing into luggage or
other items placed behind it.

¾

The front passenger seatback
contacts the rear seat.

¾

Luggage or other items are placed
between the front passenger seat
and driver seat.

¾

An electric device is put on the front
passenger's seat.

¾

An additional electrical device, such
as a seat warmer is installed to the
surface of the front passenger seat.

¾

Any accessories, which might
increase the total seated weight on
the front passenger seat, are
attached to the front passenger seat.

The designated positions with seat
belts on the rear seats are the safest
places for children. Always use seat
belts and child restraints.

Do not allow a child or anyone to
lean over to or against the side
window of a vehicle with side and
curtain air bags:

It is dangerous to allow anyone to lean
over to or against the side window, the
area of the front passenger seat, the
front and rear window pillars and the
roof edge along both sides from which
the side and curtain air bags deploy,
even if a child-restraint system is used.
The impact of inflation from a side or
curtain air bag could cause serious
injury or death to an out of position
child. Furthermore, leaning over to or
against the door could block the side
and curtain air bags and eliminate the
advantages of supplemental
protection. Because the front seats are
equipped with front air bags, the rear
seat is always a better location for
children. Take special care not to allow
a child to lean over to or against the
side window, even if the child is seated
in a child-restraint system.

Never use one seat belt on more than
one person at a time:

Using one seat belt for more than one
person at a time is dangerous. A seat
belt used in this way cannot spread the
impact forces properly and the two
passengers could be crushed together
and seriously injured or even killed.
Never use one belt for more than one
person at a time and always operate
the vehicle with each occupant
properly restrained.

CAUTION

A seat belt or child-restraint system can
become very hot in a closed vehicle
during warm weather. To avoid burning
yourself or a child, check them before
you or your child touches them.

Essential Safety Equipment

Child Restraint

2-35

NOTE

Your Mazda is equipped with ISOFIX/
LATCH

*1

 lower anchors for attachment

of specially designed ISOFIX/LATCH

*1

child-restraint systems on the rear
seats. When using these anchors to
secure a child-restraint system, refer to
"Using ISOFIX Lower Anchor
(Mexico)/Using LATCH Lower Anchor
(Except Mexico)" (page 2-50).

*

1 ISOFIX (Mexico)/LATCH (Except

Mexico)

Essential Safety Equipment

Child Restraint

2-36

Child-Restraint System Installation

Categories of Child-Restraint Systems

NOTE

When purchasing, ask the manufacturer of the child-restraint system which type of
child-restraint system is appropriate for your child and vehicle.

(Mexico)

Child-restraint systems are classified into the following 5 groups according to the
UN-R 44 and UN-R 129 regulation.

Group

Age

Weight

Size Classification/

Fixture (CRF)

0

Up to about 9 months old

Up to 10 kg (up to 22 lb)

ISO/L1

ISO/L2

ISO/R1

0+

Up to about 2 years old

Up to 13 kg (up to 29 lb)

ISO/R1

ISO/R2

ISO/R3

1

About 8 months to 4 years old

9 kg

ʊ

 18 kg (20 lb

ʊ

 40 lb)

ISO/R2

ISO/R3

ISO/F2

ISO/F2X

ISO/F3

2

About 3 to 7 years old

15 kg

ʊ

 25 kg (33 lb

ʊ

 55 lb)

ʊ

3

About 6 to 12 years old

22 kg

ʊ

 36 kg (48 lb

ʊ

 79 lb)

ʊ

(Except Mexico)

Please comply with the legal regulations concerning the use of child-restraint
systems in your country.

Child-Restraint System Types

In this owner's manual, explanation of
child-restraint systems is provided for
the following three types of popular
child-restraint systems: infant seat,
child seat, booster seat.

NOTE

x

Installation position is determined by
the type of child-restraint system.
Always read the manufacturer's
instructions and this owner's manual
carefully.

Essential Safety Equipment

Child Restraint

2-37

x

Due to variations in the design of
child-restraint systems, vehicle seats
and seat belts, all child-restraint
systems may not fit all seating
positions. Before purchasing a
child-restraint system, it should be
tested in the specific vehicle seating
position (or positions) where it is
intended to be used. If a previously
purchased child-restraint system
does not fit, you may need to
purchase a different one that will.

Infant seat

An infant seat provides restraint by
bracing the infant's head, neck and
back against the seating surface.
Equal to Group 0 and 0+ of the UN-R
44 and UN-R 129 regulation.

Child seat

A child seat restrains a child's body
using the harness.
Equal to Group 1 of the UN-R 44 and
UN-R 129 regulation.

Booster seat

A booster seat is a child restraint
accessory designed to improve the fit
of the seat belt system around the
child's body.
Equal to Group 2 and 3 of the UN-R
44 and UN-R 129 regulation.

1. Full booster seat
2. Backless booster seat

When using a backless booster seat,
always install the vehicle head restraint
to the seat where the backless booster
seat is installed.

Essential Safety Equipment

Child Restraint

2-38

Child-Restraint System Suitability for Various Seat

Positions Table

Child-Restraint System Suitability for Various Seat Positions Table

(Mexico)

Provided information in the table shows your child-restraint system suitability for
various seating position. For installation suitability of other manufacturer
child-restraint system, carefully consult the manufacturer's instructions which
accompany the child-restraint system.
When installing a child-restraint system, the following points must be observed:

x

Always remove the head restraint before installing a child-restraint system.
However, when installing a backless booster seat, always install the vehicle head
restraint to the seat where the backless booster seat is installed. In addition,
always use a tether strap and attach it securely. Refer to Head Restraints on page
2-17.

x

When installing a child-restraint system to the front passenger seat, adjust the seat
slide position as far back as possible.
Refer to Adjusting the Front Passenger's Seat on page 2-13.

x

When it is difficult to install a child-restraint system to the front passenger seat, or
the seat belt cannot be secured to the child-restraint system, perform the
following operations to adjust the seat holding the child-restraint system so that
the seat belt can be secured completely to it.

x

Move the seat forward or back.

x

Move the seatback forward or back.

x

Move the seat upward or downward. (Vehicles with height adjustment function)

x

When installing a child-restraint system to the rear seat, adjust the front seat
position so that the front seat does not contact the child-restraint system.
Refer to Adjusting the Driver's Seat on page 2-5.
Refer to Adjusting the Front Passenger's Seat on page 2-13.

x

When installing a child-restraint system equipped with a tether, remove the head
restraint.
Refer to Head Restraints on page 2-17.

x

An i-Size child-restraint system refers to a child-restraint system which has
acquired i-Size category certification for the UN-R 129 regulation.

Essential Safety Equipment

Child Restraint

2-39

















Content      ..     1      2      3      4      ..
