Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
7. Repeat with each tire, including the
road when it's mounted on the
spare.
vehicle.
NOTE
Seating capacity means the total
Some spare tires require higher
allowable number of vehicle
inflation pressure.
occupants. Seating capacity is
8. Visually inspect the tires to make
described on the tire label.
sure there are no nails or other
objects embedded that could poke
Production options weight is the
a hole in the tire and cause an air
combination weight of installed regular
leak.
production options weighing over 2.3
9. Check the sidewalls to make sure
kilograms in excess of the standard
there are no gouges, cuts, bulges,
items which they replace, and not
cracks or other irregularities.
previously considered in the curb
Glossary of Terms
weight or accessory weight, including
heavy duty brakes, ride levelers, roof
Tire Placard: A label indicating the OE
rack, heavy duty battery, and special
tire sizes, recommended inflation
trim.
pressure, and the maximum weight the
vehicle can carry.
Rim is the metal support (wheel) for a
Tire Identification Number (TIN): A
tire or a tire and tube assembly upon
number on the sidewall of each tire
which the tire beads are seated.
providing information about the tire
brand and manufacturing plant, tire
size, and date of manufacture.
Inflation Pressure: A measure of the
amount of air in a tire.
kPa: Kilopascal, the metric unit for air
pressure.
psi: Pounds per square inch, the
English unit for air pressure.
B-pillar: The structural member at the
side of the vehicle behind the front
door.
Original Equipment (OE): Describes
components originally equipped on
the vehicle.
Vehicle Load Limit: The maximum
value of the combination weight of
occupants and cargo.
Bead Area of the Tire: Area of the tire
next to the rim.
Sidewall Area of the Tire: Area
between the bead area and the tread.
Tread Area of the Tire: Area on the
perimeter of the tire that contacts the
8-28
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Improper wheel alignment
Tire Maintenance
Out-of-balance wheel
Severe braking
Tire Maintenance
After rotation, inflate all tire pressures
Improper or inadequate vehicle
to specification on page 9-10 and
maintenance can cause tires to wear
inspect the lug nuts for tightness.
abnormally. Here are some important
maintenance points:
CAUTION
Tire Inflation Pressure
Rotate unidirectional tires and radial
Inspect all tire pressure monthly
tires that have an asymmetrical tread
(including the spare) when the tires are
pattern or studs only from front to rear,
cold. Maintain recommended
not from side to side. Tire performance
pressures for the best ride, top
will be weakened if rotated from side
handling, and minimum tire wear. Use
to side.
the pressures specified on the vehicle
tire information placard or tire label for
Replacing a Tire
optimum service.
WARNING
Tire Rotation
To equalize tread wear, rotate the tires
Always use tires that are in good
every 16,000 km (10,000 miles) at the
condition:
latest or sooner if irregular wear
Driving with worn tires is dangerous.
develops. Mazda recommends to
Reduced braking, steering, and
rotate every 8,000 km (5,000 miles) to
traction could result in an accident.
help increase tire life and distribute
wear more evenly.
If a tire wears evenly, a wear indicator
will appear as a solid band across the
tread.
Replace the tire when this happens.
1. Forward
Do not include (TEMPORARY USE
ONLY) spare tire in rotation.
1. New tread
Inspect the tires for uneven wear and
2. Worn tread
damage. Abnormal wear is usually
3. Tread wear indicator
caused by one or a combination of the
following:
You should replace the tire before the
band crosses the entire tread.
Incorrect tire pressure
8-29
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
NOTE
Safety Practices
Tires degrade over time, even when
The way you drive has a great deal to
they are not being used on the road. It
do with your tire mileage and safety.
is recommended that tires generally be
So cultivate good driving habits for
replaced when they are 6 years or
your own benefit.
older. Heat caused by hot climates or
frequent high loading conditions can
Observe posted speed limits and
accelerate the aging process. You
drive at speeds that are safe for the
should replace the spare tire when you
existing weather conditions
replace the other road tires due to the
Avoid fast starts, stops and turns
aging of the spare tire. The period in
Avoid potholes and objects on the
which the tire was manufactured (both
road
week and year) is indicated by a 4-digit
Do not run over curbs or hit the tire
number.
against the curb when parking
Refer to Tire Labeling on page 8-23.
CAUTION
If you feel a sudden vibration or ride
disturbance while driving or you
suspect your tire or vehicle has been
damaged, immediately reduce your
speed. Drive with caution until you can
safely pull off the road. Stop and
inspect the tire for damage. If the tire
is under-inflated or damaged, deflate
it, remove the tire and rim and replace
it with your spare tire. If you cannot
detect a cause, have the vehicle towed
to the nearest vehicle or tire dealer to
have the vehicle inspected.
8-30
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Overloading makes a vehicle harder to
Vehicle Loading
drive and control. It also increases the
distance required for stopping. In cases
Vehicle Loading
of serious overloading, brakes can fail
completely, particularly on steep
WARNING
grades. The load a tire will carry safely
is a combination of the size of the tire,
Do not tow a trailer with this vehicle:
its load range, and corresponding
Towing a trailer with this vehicle is
inflation pressure.
dangerous because it has not been
Never overload the vehicle and always
designed to tow a trailer and doing so
observe the vehicle's weight ratings
will affect the drive system which could
from the vehicle's Safety Certification
result in vehicle damage.
and Tire and Load Information labels.
This section will guide you in the
Base Curb Weight is the weight of the
proper loading of your vehicle, to keep
vehicle including a full tank of fuel
your loaded vehicle weight within its
and all standard equipment. It does
design rating capability. Properly
not include passengers, cargo, or
loading your vehicle will provide
optional equipment.
maximum return of vehicle design
performance. Before loading your
Vehicle Curb Weight is the weight of
vehicle, familiarize yourself with the
your new vehicle when you picked it
following terms for determining your
up from your dealer plus any
vehicle's weight ratings, from the
aftermarket equipment.
vehicle's Safety Certification Label and
Tire and Load Information Label:
PAYLOAD
WARNING
Overloaded Vehicle:
Overloading a vehicle is dangerous.
The results of overloading can have
serious consequences in terms of
passenger safety. Too much weight on
a vehicle's suspension system can
cause spring or shock absorber failure,
brake failure, handling or steering
problems, irregular tire wear, tire
failure or other damage.
8-31
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Payload is the combination weight of
The cargo weight limit decreases
cargo and passengers that the vehicle
depending on the number of vehicle
is designed to carry. The maximum
occupants. The cargo weight limit can
payload for your vehicle can be found
be calculated by subtracting the total
on the Tire and Load Information label
weight of the vehicle occupants from
on the driver's door frame or door
the “combination weight of occupants
pillar. Look for “THE COMBINATION
and cargo should never exceed” value
WEIGHT OF OCCUPANTS AND
on the tire label.
CARGO SHOULD NEVER EXCEED XXX
kg or XXX lbs” for your maximum
Examples: Based on a single occupant
payload. The payload listed on the tire
weight of 68 kg (150 lbs), and a value
label is the maximum payload for the
of 385 kg (849 lbs) for the
vehicle as built by the assembly plant.
“combination weight of occupants and
If any aftermarket or dealer installed
cargo should never exceed”:
equipment has been installed on the
The cargo weight limit with one
vehicle, the weight of the equipment
occupant is 385 kg (849 lbs) 68 kg
must be subtracted from the payload
(150 lbs) = 317 kg (699 lbs)
listed on the tire label in order to be
The cargo weight limit with two
accurate.
occupants is 385 kg (849 lbs) (68 ×
2) kg ( (150 × 2) lbs) = 249 kg (549
SAMPLE
lbs)
If the weight of the occupant increases,
the cargo weight limit decreases by
that much.
GAW (Gross Axle Weight) is the total
weight placed on each axle (front and
rear) - including vehicle curb weight
and all payload.
CARGO
GAWR (Gross Axle Weight Rating) is
the maximum allowable weight that
can be carried by a single axle (front or
rear). These numbers are shown on
Cargo Weight includes all weight
the Safety Compliance Certification
added to the Base Curb Weight,
Label located on the driver's door
including cargo and optional
frame or door pillar. The total load on
equipment.
each axle must never exceed its
GAWR.
GVW
8-32
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
GVW (Gross Vehicle Weight) is the
GCW (Gross Combination Weight) is
Vehicle Curb Weight + cargo +
the weight of the loaded vehicle
passengers.
(GVW).
GVWR (Gross Vehicle Weight Rating)
GCWR (Gross Combination Weight
is the maximum allowable weight of
Rating) is the maximum allowable
the fully loaded vehicle (including all
weight of the vehicle - including all
options, equipment, passengers and
cargo and passengers - that the vehicle
cargo). The GVWR is shown on the
can handle without risking damage.
Safety Compliance Certification Label
The GCW must never exceed the
located on the driver's door frame or
GCWR.
door pillar. The GVW must never
exceed the GVWR.
WARNING
SAMPLE
Never Exceed GVWR or GAWR
Specifications:
Exceeding the GVWR or the GAWR
specified on the certification label is
dangerous. Exceeding any vehicle
rating limitation could result in a
serious accident, injury, or damage to
the vehicle.
Do not use replacement tires with
WARNING
lower load carrying capacities than the
originals because they may lower the
Never Exceed Axle Weight Rating
vehicle's GVWR and GAWR
Limits:
limitations. Replacement tires with a
Exceeding the Safety Certification
higher limit than the originals do not
Label axle weight rating limits is
increase the GVWR and GAWR
dangerous and could result in death or
limitations.
serious injury as a result of substandard
Never exceed the GVWR or the GAWR
vehicle handling, performance, engine,
specified on the certification label.
transmission and/or structural
damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle
weight rating limits.
GCW
8-33
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Steps for Determining the Correct Load Limit
Steps for Determining the Correct Load Limit
Steps for Determining Correct Load Limit-
(1) Locate the statement “The combined weight of occupants and cargo should
never exceed XXX kg or XXX lbs.” on your vehicle's placard.
(2) Determine the combined weight of the driver and passengers that will be riding
in your vehicle.
(3) Subtract the combined weight of the driver and passengers from XXX kg or XXX
lbs.
(4) The resulting figure equals the available amount of cargo and luggage load
capacity. For example, if the “XXX” amount equals 1400 lbs. and there will be
five 150 lb passengers in your vehicle, the amount of available cargo and
luggage load capacity is 650 lbs. (1400 750 (5 × 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the
vehicle. That weight may not safely exceed the available cargo and luggage load
capacity calculated in Step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to
your vehicle. Consult this manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
8-34
Specifications
Identification Numbers
Chassis Number
Vehicle Information
Open the cover shown in the figure to
Labels
check the chassis number.
Vehicle Identification Number
The vehicle identification number
legally identifies your vehicle. The
number is on a plate attached to the
cowl panel located on the left corner
of the dashboard. This plate can easily
be seen through the windshield.
Vehicle Emission Control
Information Label (U.S.A. and
Canada)
Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
Tire Pressure Label
9-2
Specifications
Identification Numbers
Engine Number
1. Forward
9-3
Specifications
Specifications
Specifications
Engine
Specification
Item
SKYACTIV-G 2.0
SKYACTIV-G 2.5
SKYACTIV-G 2.5T
Type
DOHC-16V in-line, 4-cylinder
83.5 × 91.2 mm (3.29 ×
Bore × Stroke
89.0 × 100 mm (3.50 × 3.94 in)
3.59 in)
Displacement
1,997.6 ml (1,997.6 cc)
2,488.5 ml (2,488.5 cc)
Compression
13.0
10.5
ratio
Electrical System
Classification
Specification
U.S.A. and Cana-
12V-60Ah/20HR or 12V-65Ah/20HR
Battery*1
da
Mexico
12V-60Ah/20HR
SKYACTIV-G 2.0,
Mazda Genuine spark
PE5R-18-110 or PE5S-18-110
Spark-plug num-
SKYACTIV-G 2.5
plug*2
ber
Mazda Genuine spark
SKYACTIV-G 2.5T
PY8V-18-110
plug*2
*1
Check the battery installed on the vehicle and use a battery with an equal or higher performance.
However, the performance of the battery may vary even among the same battery types, consult an
Authorized Mazda Dealer for replacement.
*2
This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized
Mazda Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and platinum tips could be damaged.
9-4
Specifications
Specifications
Lubricant Quality
Lubricant
Classification
Engine oil
Refer to Recommended Oil on page 6-16.
Coolant
FL-22 type
Manual transmission oil
Mazda Long Life Gear Oil G7
Automatic transmission fluid*1
Mazda Genuine ATF FZ
Transfer case oil*2
Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil*2
Mazda Long Life Hypoid Gear Oil SG1
Brake/Clutch fluid
SAE J1703 or FMVSS116 DOT-3
*1
Periodic replacement is unnecessary.
*2
Replacement is necessary when the component is submerged in water.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your
investment.
Capacities
(Approximate Quantities)
Item
Capacity
With oil filter re-
4.2 L (4.4 US qt, 3.7 Imp qt)
placement
SKYACTIV-G 2.0
Without oil filter re-
4.0 L (4.2 US qt, 3.5 Imp qt)
placement
With oil filter re-
4.5 L (4.8 US qt, 4.0 Imp qt)
placement
Engine oil
SKYACTIV-G 2.5
Without oil filter re-
4.3 L (4.5 US qt, 3.8 Imp qt)
placement
With oil filter re-
4.8 L (5.1 US qt, 4.2 Imp qt)
placement
SKYACTIV-G 2.5T
Without oil filter re-
4.6 L (4.9 US qt, 4.0 Imp qt)
placement
9-5
Specifications
Specifications
Item
Capacity
Manual transmis-
6.2 L (6.6 US qt, 5.5 Imp qt)
sion
SKYACTIV-G 2.0
Automatic trans-
6.5 L (6.9 US qt, 5.7 Imp qt)
mission
Manual transmis-
6.3 L (6.7 US qt, 5.5 Imp qt)
Coolant
sion
SKYACTIV-G 2.5
Automatic trans-
6.6 L (7.0 US qt, 5.8 Imp qt)
mission
For engine
8.3 L (8.8 US qt, 7.3 Imp qt)
SKYACTIV-G 2.5T
For water-cooled
1.6 L (1.7 US qt, 1.4 Imp qt)
charge air cooler
Manual transmis-
SKYACTIV-G 2.0
1.70 L (1.80 US qt, 1.50 Imp qt)
sion oil
SKYACTIV-G 2.5
1.65 L (1.74 US qt, 1.45 Imp qt)
Automatic trans-
SKYACTIV-G 2.0, SKYACTIV-G 2.5
7.6 L (8.0 US qt, 6.7 Imp qt)
mission fluid
SKYACTIV-G 2.5T
8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil
0.35 L (0.37 US qt, 0.31 Imp qt)
Rear differential oil
0.35 L (0.37 US qt, 0.31 Imp qt)
FWD
50.0 L (13.2 US gal, 11.0 Imp gal)
U.S.A. and Canada
AWD
48.0 L (12.7 US gal, 10.6 Imp gal)
Fuel tank
FWD
51.0 L (13.5 US gal, 11.2 Imp gal)
Mexico
AWD
48.0 L (12.7 US gal, 10.6 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
Dimensions
4-Door
Item
Vehicle specification
Overall length
4,662 mm (183.5 in)
Overall width
1,797 mm (70.7 in)
Overall height
1,445 mm (56.9 in)
Front tread
1,568 mm (61.7 in)
FWD
1,581 mm (62.2 in)
Rear tread
AWD
1,580 mm (62.2 in)
Wheelbase
2,726 mm (107.3 in)
9-6
Specifications
Specifications
5-Door
Item
Vehicle specification
Overall length
4,459 mm (175.6 in)
Overall width
1,797 mm (70.7 in)
Overall height
1,440 mm (56.7 in)
Front tread
1,568 mm (61.7 in)
FWD
1,581 mm (62.2 in)
Rear tread
AWD
1,580 mm (62.2 in)
Wheelbase
2,726 mm (107.3 in)
Weights
U.S.A. and Canada
SKYACTIV-G 2.0
(4-Door)
Weight
Item
Manual transmission
Automatic transmission
GVWR (Gross Vehicle Weight
1,804 kg (3,977 lbs)
1,825 kg (4,023 lbs)
Rating)
GAWR (Gross Axle
Front
966 kg (2,130 lbs)
989 kg (2,180 lbs)
Weight Rating)
Rear
843 kg (1,858 lbs)
841 kg (1,854 lbs)
(5-Door)
Weight
Item
Manual transmission
Automatic transmission
GVWR (Gross Vehicle Weight
1,810 kg (3,990 lbs)
1,833 kg (4,041 lbs)
Rating)
GAWR (Gross Axle
Front
965 kg (2,127 lbs)
989 kg (2,180 lbs)
Weight Rating)
Rear
848 kg (1,870 lbs)
847 kg (1,867 lbs)
SKYACTIV-G 2.5
(4-Door)
Weight
Item
FWD
AWD
GVWR (Gross Vehicle Weight
1,850 kg (4,079 lbs)
1,910 kg (4,211 lbs)
Rating)
GAWR (Gross Axle
Front
1,016 kg (2,240 lbs)
1,030 kg (2,271 lbs)
Weight Rating)
Rear
839 kg (1,850 lbs)
885 kg (1,951 lbs)
9-7
Specifications
Specifications
(5-Door)
Weight
FWD
Item
Automatic transmis-
AWD
Manual transmission
sion
GVWR (Gross Vehicle Weight
1,822 kg (4,017 lbs)
1,849 kg (4,076 lbs)
1,915 kg (4,222 lbs)
Rating)
GAWR (Gross Axle
Front
987 kg (2,176 lbs)
1,016 kg (2,240 lbs)
1,046 kg (2,306 lbs)
Weight Rating)
Rear
838 kg (1,847 lbs)
836 kg (1,843 lbs)
872 kg (1,922 lbs)
SKYACTIV-G 2.5T
(4-Door)
Item
Weight
GVWR (Gross Vehicle Weight
1,950 kg (4,299 lbs)
Rating)
GAWR (Gross Axle
Front
1,066 kg (2,350 lbs)
Weight Rating)
Rear
889 kg (1,960 lbs)
(5-Door)
Item
Weight
GVWR (Gross Vehicle Weight
1,950 kg (4,299 lbs)
Rating)
GAWR (Gross Axle
Front
1,085 kg (2,392 lbs)
Weight Rating)
Rear
868 kg (1,914 lbs)
Mexico
SKYACTIV-G 2.0
Item
Weight
GVW (Gross Vehicle Weight)
1,881 kg (4,147 lbs)
SKYACTIV-G 2.5
(4-Door)
Weight
Item
Manual transmission
Automatic transmission
GVW (Gross Vehicle Weight)
1,861 kg (4,103 lbs)
1,870 kg (4,123 lbs)
9-8
Specifications
Specifications
(5-Door)
Weight
Item
Manual transmission
Automatic transmission
GVW (Gross Vehicle Weight)
1,848 kg (4,074 lbs)
1,870 kg (4,123 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVW (Gross Vehicle Weight)
1,950 kg (4,299 lbs)
Light Bulbs
Exterior light
Category
Light bulb
Wattage
UN-R*1 (SAE)
Headlights
LED
()
Daytime running lights
LED
()
LED type
LED
()
Parking lights
Bulb type
5
WY5W ()
Front turn signal lights
LED
()
LED type
LED
()
Front side-marker lights
Bulb type
5
WY5W ()
Side turn signal lights*
LED
()
High-mount brake light
LED
()
Rear turn signal lights
LED
()
Rear side-marker lights
LED
()
Brake lights
LED
()
Taillights
LED
()
Reverse lights
LED
()
License plate lights
LED
()
*1
UN-R stands for United Nations Regulation.
Interior light
Category
Light bulb
Wattage
UN-R*1
Overhead light (Front)/Map lights
LED
Overhead light (Rear)
LED
Vanity mirror lights*
LED
*Some models.
9-9
Specifications
Specifications
Category
Light bulb
Wattage
UN-R*1
Trunk light (4-Door)
5
Luggage compartment light (5-Door)
LED
*1
UN-R stands for United Nations Regulation.
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-33.
Standard tire
(U.S.A. and Canada)
Inflation pressure
Tire size
Front
Rear
205/60R16 92H M+S
250 kPa (36 psi)
250 kPa (36 psi)
SKYACTIV-G 2.0,
215/45R18 89V
250 kPa (36 psi)
250 kPa (36 psi)
SKYACTIV-G 2.5
M+S
SKYACTIV-G 2.5T
260 kPa (38 psi)
250 kPa (36 psi)
(Mexico)
Inflation pressure
Tire size
Up to 3 persons
Full load
Fron
250 kPa (2.5 bar, 36 psi)
260 kPa (2.6 bar, 38 psi)
205/60R16 92V
t
Rear
250 kPa (2.5 bar, 36 psi)
290 kPa (2.9 bar, 42 psi)
Fron
SKYAC-
250 kPa (2.5 bar, 36 psi)
270 kPa (2.7 bar, 39 psi)
t
TIV-G 2.5
Rear
250 kPa (2.5 bar, 36 psi)
290 kPa (2.9 bar, 42 psi)
215/45R18 89W
Fron
SKYAC-
260 kPa (2.6 bar, 38 psi)
270 kPa (2.7 bar, 39 psi)
t
TIV-G 2.5T
Rear
250 kPa (2.5 bar, 36 psi)
290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
9-10
Specifications
Specifications
Temporary spare tire
Tire size
Inflation pressure
T125/70D16 96M*
420 kPa (60 psi)
T125/80D16 97M*2
420 kPa (60 psi)
*1
FWD
*2
AWD
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108147 N·m (1214 kgf·m, 80108 ft·lbf)
Fuses
Refer to Fuses on page 6-39.
9-11















Content      ..     17      18      19
