Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Location of the Tire Label
WARNING
(Placard)
Always check the tire inflation
pressures on a regular basis according
Location of the Tire Label (Placard)
to the recommended tire inflation
You will find the tire label containing
pressure on the tire label and in
tire inflation pressure by tire size and
conjunction with the information in
other important information on the
this owner's manual:
driver's side B-pillar or on the edge of
Driving your vehicle with
the driver's door frame.
under-inflated tires is dangerous.
Under-inflation is the most common
SAMPLE
cause of failures in any kind of tire and
may result in severe cracking, tread
separation or “blowout”, with
unexpected loss of vehicle control and
increased risk of injury. Under-inflation
increases sidewall flexing and rolling
resistance, resulting in heat buildup
and internal damage to the tire. It
results in unnecessary tire stress,
Recommended Tire Inflation
irregular wear, loss of control and
Pressure
accidents. A tire can lose up to half of
its air pressure and not appear to be
On the tire label you will find the
flat!
recommended tire inflation pressure in
It is impossible to determine whether
both kPa and psi for the tires installed
or not tires are properly inflated just by
as original equipment on the vehicle. It
looking at them.
is very important that the inflation
pressure of the tires on your vehicle is
Checking Tire Pressure
maintained at the recommended
1. When you check the air pressure,
pressure. You should check the tire
make sure the tires are cold
pressure regularly to insure that the
meaning they are not hot from
proper inflation pressure is maintained.
driving even a mile.
Refer to Tires on page 9-8.
2. Remove the cap from the valve on
NOTE
one tire.
Tire pressures listed on the vehicle
3. Firmly press a tire gauge onto the
placard or tire information label
valve.
indicate the recommended cold tire
4. Add air to achieve recommended
inflation pressure, measured when the
air pressure.
tires are cold, after the vehicle has
5. If you overfill the tire, release air by
been parked for at least 3 hours. As
pushing on the metal stem in the
you drive, the temperature in the tire
center of the valve. Then recheck
warms up, increasing the tire pressure.
the pressure with your tire gauge.
6. Replace the valve cap.
7. Repeat with each tire, including the
spare.
8-28
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
NOTE
Sidewall Area of the Tire: Area
Some spare tires require higher
between the bead area and the tread.
inflation pressure.
Tread Area of the Tire: Area on the
8. Visually inspect the tires to make
perimeter of the tire that contacts the
sure there are no nails or other
road when it's mounted on the
objects embedded that could poke
vehicle.
a hole in the tire and cause an air
leak.
Seating capacity means the total
9. Check the sidewalls to make sure
allowable number of vehicle
there are no gouges, cuts, bulges,
occupants. Seating capacity is
cracks or other irregularities.
described on the tire label.
Glossary of Terms
Production options weight is the
Tire Placard: A label indicating the OE
combination weight of installed regular
tire sizes, recommended inflation
production options weighing over 2.3
pressure, and the maximum weight the
kilograms in excess of the standard
vehicle can carry.
items which they replace, and not
Tire Identification Number (TIN): A
previously considered in the curb
number on the sidewall of each tire
weight or accessory weight, including
providing information about the tire
heavy duty brakes, ride levelers, roof
brand and manufacturing plant, tire
rack, heavy duty battery, and special
size, and date of manufacture.
trim.
Inflation Pressure: A measure of the
amount of air in a tire.
Rim is the metal support (wheel) for a
kPa: Kilopascal, the metric unit for air
tire or a tire and tube assembly upon
pressure.
which the tire beads are seated.
psi: Pounds per square inch, the
English unit for air pressure.
B-pillar: The structural member at the
side of the vehicle behind the front
door.
Original Equipment (OE): Describes
components originally equipped on
the vehicle.
Vehicle Load Limit: The maximum
value of the combination weight of
occupants and cargo.
Bead Area of the Tire: Area of the tire
next to the rim.
8-29
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Improper wheel alignment
Tire Maintenance
Out-of-balance wheel
Severe braking
Tire Maintenance
After rotation, inflate all tire pressures
Improper or inadequate vehicle
to specification on page 9-8 and
maintenance can cause tires to wear
inspect the lug nuts for tightness.
abnormally. Here are some important
maintenance points:
CAUTION
Tire Inflation Pressure
Rotate unidirectional tires and radial
Inspect all tire pressure monthly
tires that have an asymmetrical tread
(including the spare) when the tires are
pattern or studs only from front to rear,
cold. Maintain recommended
not from side to side. Tire performance
pressures for the best ride, top
will be weakened if rotated from side
handling, and minimum tire wear. Use
to side.
the pressures specified on the vehicle
tire information placard or tire label for
Replacing a Tire
optimum service.
WARNING
Tire Rotation
To equalize tread wear, rotate the tires
Always use tires that are in good
every 16,000 km (10,000 miles) at the
condition:
latest or sooner if irregular wear
Driving with worn tires is dangerous.
develops. Mazda recommends to
Reduced braking, steering, and
rotate every 8,000 km (5,000 miles) to
traction could result in an accident.
help increase tire life and distribute
wear more evenly.
If a tire wears evenly, a wear indicator
will appear as a solid band across the
tread.
Replace the tire when this happens.
1. Forward
Do not include (TEMPORARY USE
ONLY) spare tire in rotation.
1. New tread
Inspect the tires for uneven wear and
2. Worn tread
damage. Abnormal wear is usually
3. Tread wear indicator
caused by one or a combination of the
following:
You should replace the tire before the
band crosses the entire tread.
Incorrect tire pressure
8-30
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
NOTE
Vehicle Loading
Tires degrade over time, even when
they are not being used on the road. It
Vehicle Loading
is recommended that tires generally be
replaced when they are 6 years or
older. Heat caused by hot climates or
WARNING
frequent high loading conditions can
accelerate the aging process. You
Do not tow a trailer with this vehicle:
should replace the spare tire when you
Towing a trailer with this vehicle is
replace the other road tires due to the
dangerous because it has not been
aging of the spare tire. The period in
designed to tow a trailer and doing so
which the tire was manufactured (both
will affect the drive system which could
week and year) is indicated by a 4-digit
result in vehicle damage.
number.
This section will guide you in the
Refer to Tire Labeling on page 8-24.
proper loading of your vehicle, to keep
Safety Practices
your loaded vehicle weight within its
design rating capability. Properly
The way you drive has a great deal to
loading your vehicle will provide
do with your tire mileage and safety.
maximum return of vehicle design
So cultivate good driving habits for
performance. Before loading your
your own benefit.
vehicle, familiarize yourself with the
Observe posted speed limits and
following terms for determining your
drive at speeds that are safe for the
vehicle's weight ratings, from the
existing weather conditions
vehicle's Safety Certification Label and
Avoid fast starts, stops and turns
Tire and Load Information Label:
Avoid potholes and objects on the
road
WARNING
Do not run over curbs or hit the tire
against the curb when parking
Overloaded Vehicle:
Overloading a vehicle is dangerous.
The results of overloading can have
CAUTION
serious consequences in terms of
passenger safety. Too much weight on
If you feel a sudden vibration or ride
disturbance while driving or you
a vehicle's suspension system can
cause spring or shock absorber failure,
suspect your tire or vehicle has been
damaged, immediately reduce your
brake failure, handling or steering
problems, irregular tire wear, tire
speed. Drive with caution until you can
safely pull off the road. Stop and
failure or other damage.
inspect the tire for damage. If the tire
is under-inflated or damaged, deflate
it, remove the tire and rim and replace
it with your spare tire. If you cannot
detect a cause, have the vehicle towed
to the nearest vehicle or tire dealer to
have the vehicle inspected.
8-31
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Overloading makes a vehicle harder to
Base Curb Weight is the weight of the
drive and control. It also increases the
vehicle including a full tank of fuel
distance required for stopping. In cases
and all standard equipment. It does
of serious overloading, brakes can fail
not include passengers, cargo, or
completely, particularly on steep
optional equipment.
grades. The load a tire will carry safely
is a combination of the size of the tire,
Vehicle Curb Weight is the weight of
its load range, and corresponding
your new vehicle when you picked it
inflation pressure.
up from your dealer plus any
Never overload the vehicle and always
aftermarket equipment.
observe the vehicle's weight ratings
from the vehicle's Safety Certification
PAYLOAD
and Tire and Load Information labels.
Payload is the combination weight of
cargo and passengers that the vehicle
is designed to carry. The maximum
payload for your vehicle can be found
on the Tire and Load Information label
on the driver's door frame or door
pillar. Look for “THE COMBINATION
WEIGHT OF OCCUPANTS AND
CARGO SHOULD NEVER EXCEED XXX
kg or XXX lbs” for your maximum
payload. The payload listed on the tire
label is the maximum payload for the
vehicle as built by the assembly plant.
If any aftermarket or dealer installed
equipment has been installed on the
vehicle, the weight of the equipment
must be subtracted from the payload
listed on the tire label in order to be
accurate.
8-32
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
SAMPLE
GAW (Gross Axle Weight) is the total
weight placed on each axle (front and
rear) - including vehicle curb weight
and all payload.
GAWR (Gross Axle Weight Rating) is
the maximum allowable weight that
can be carried by a single axle (front or
rear). These numbers are shown on
the Safety Compliance Certification
CARGO
Label located on the driver's door
frame or door pillar. The total load on
each axle must never exceed its
GAWR.
Cargo Weight includes all weight
added to the Base Curb Weight,
GVW
including cargo and optional
equipment.
The cargo weight limit decreases
GVW (Gross Vehicle Weight) is the
depending on the number of vehicle
Vehicle Curb Weight + cargo +
occupants. The cargo weight limit can
passengers.
be calculated by subtracting the total
weight of the vehicle occupants from
GVWR (Gross Vehicle Weight Rating)
the “combination weight of occupants
is the maximum allowable weight of
and cargo should never exceed” value
the fully loaded vehicle (including all
on the tire label.
options, equipment, passengers and
cargo). The GVWR is shown on the
Examples: Based on a single occupant
Safety Compliance Certification Label
weight of 68 kg (150 lbs), and a value
located on the driver's door frame or
of 385 kg (849 lbs) for the
door pillar. The GVW must never
“combination weight of occupants and
exceed the GVWR.
cargo should never exceed”:
The cargo weight limit with one
SAMPLE
occupant is 385 kg (849 lbs) 68 kg
(150 lbs) = 317 kg (699 lbs)
The cargo weight limit with two
occupants is 385 kg (849 lbs) (68 ×
2) kg ( (150 × 2) lbs) = 249 kg (549
lbs)
If the weight of the occupant increases,
the cargo weight limit decreases by
that much.
8-33
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
WARNING
WARNING
Never Exceed Axle Weight Rating
Never Exceed GVWR or GAWR
Limits:
Specifications:
Exceeding the Safety Certification
Exceeding the GVWR or the GAWR
Label axle weight rating limits is
specified on the certification label is
dangerous and could result in death or
dangerous. Exceeding any vehicle
serious injury as a result of substandard
rating limitation could result in a
vehicle handling, performance, engine,
serious accident, injury, or damage to
transmission and/or structural
the vehicle.
damage, serious damage to the
Do not use replacement tires with
vehicle, or loss of control.
lower load carrying capacities than the
Always keep the vehicle within the axle
originals because they may lower the
weight rating limits.
vehicle's GVWR and GAWR
limitations. Replacement tires with a
higher limit than the originals do not
GCW
increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR
specified on the certification label.
GCW (Gross Combination Weight) is
the weight of the loaded vehicle
(GVW).
GCWR (Gross Combination Weight
Rating) is the maximum allowable
weight of the vehicle - including all
cargo and passengers - that the vehicle
can handle without risking damage.
The GCW must never exceed the
GCWR.
8-34
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Steps for Determining the Correct Load Limit
Steps for Determining the Correct Load Limit
Steps for Determining Correct Load Limit-
(1) Locate the statement “The combined weight of occupants and cargo should
never exceed XXX kg or XXX lbs.” on your vehicle's placard.
(2) Determine the combined weight of the driver and passengers that will be riding
in your vehicle.
(3) Subtract the combined weight of the driver and passengers from XXX kg or XXX
lbs.
(4) The resulting figure equals the available amount of cargo and luggage load
capacity. For example, if the “XXX” amount equals 1400 lbs. and there will be
five 150 lb passengers in your vehicle, the amount of available cargo and
luggage load capacity is 650 lbs. (1400 750 (5 × 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the
vehicle. That weight may not safely exceed the available cargo and luggage load
capacity calculated in Step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to
your vehicle. Consult this manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
8-35
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
9
Technical information about your Mazda.
Identification Numbers
9-2
Specifications
9-4
Vehicle Information Labels
Specifications
9-4
............................................ 9-2
9-1
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Identification Numbers
Chassis Number
Vehicle Information
Open the cover shown in the figure to
Labels
check the chassis number.
Vehicle Identification Number
The vehicle identification number
legally identifies your vehicle. The
number is on a plate attached to the
cowl panel located on the left corner
of the dashboard. This plate can easily
be seen through the windshield.
Vehicle Emission Control
Information Label (U.S.A. and
Canada)
Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
Tire Pressure Label
9-2
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Identification Numbers
Engine Number
1. Forward
9-3
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
Specifications
Engine
Specification
Item
SKYACTIV-G 2.0
SKYACTIV-G 2.5
SKYACTIV-G 2.5T
Type
DOHC-16V in-line, 4-cylinder
83.5 × 91.2 mm (3.29 ×
Bore × Stroke
89.0 × 100 mm (3.50 × 3.94 in)
3.59 in)
Displacement
1,997.6 ml (1,997.6 cc)
2,488.5 ml (2,488.5 cc)
Compression
13.0
10.5
ratio
Electrical System
Item
Classification
Battery*1
12V-60Ah/20HR
SKYACTIV-G 2.0, SKY-
Mazda Genuine spark
PE5R-18-110 or PE5S-18-110
Spark-plug
ACTIV-G 2.5
plug*2
number
Mazda Genuine spark
SKYACTIV-G 2.5T
PY8V-18-110
plug*2
*1
Check the battery installed on the vehicle and use a battery with an equal or higher performance.
However, the performance of the battery may vary even among the same battery types, consult an
Authorized Mazda Dealer for replacement.
*2
This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized
Mazda Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and platinum tips could be damaged.
Lubricant Quality
Lubricant
Classification
Engine oil
Refer to Recommended Oil on page 6-17.
Coolant
FL-22 type
Manual transmission oil
Mazda Long Life Gear Oil G7
Automatic transmission fluid
Mazda Genuine ATF FZ
Transfer case oil
Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil
Mazda Long Life Hypoid Gear Oil SG1
9-4
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
Lubricant
Classification
Brake/Clutch fluid
SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your
investment.
Capacities
(Approximate Quantities)
Item
Capacity
SKYAC-
With oil filter replacement
4.2 L (4.4 US qt, 3.7 Imp qt)
TIV-G 2.0
Without oil filter replacement
4.0 L (4.2 US qt, 3.5 Imp qt)
SKYAC-
With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
Engine oil
TIV-G 2.5
Without oil filter replacement
4.3 L (4.5 US qt, 3.8 Imp qt)
SKYAC-
With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
TIV-G 2.5T
Without oil filter replacement
4.6 L (4.9 US qt, 4.0 Imp qt)
Manual transmission
6.2 L (6.6 US qt, 5.5 Imp qt)
SKYAC-
Automatic
U.S.A. and Canada
6.5 L (6.9 US qt, 5.7 Imp qt)
TIV-G 2.0
transmis-
Mexico
6.6 L (7.0 US qt, 5.8 Imp qt)
sion
Coolant
SKYAC-
U.S.A. and Canada
6.5 L (6.9 US qt, 5.7 Imp qt)
TIV-G 2.5
Mexico
6.7 L (7.1 US qt, 5.9 Imp qt)
SKYAC-
For engine
8.2 L (8.7 US qt, 7.2 Imp qt)
TIV-G 2.5T
For water-cooled charge air cooler
1.6 L (1.7 US qt, 1.4 Imp qt)
Manual transmission oil
1.70 L (1.80 US qt, 1.50 Imp qt)
SKYACTIV-G 2.0
7.6 L (8.0 US qt, 6.7 Imp qt)
Automatic
SKYAC-
With Cylinder Deactivation
7.9 L (8.3 US qt, 7.0 Imp qt)
transmission
TIV-G 2.5
Without Cylinder Deactivation
7.6 L (8.0 US qt, 6.7 Imp qt)
fluid
SKYACTIV-G 2.5T
8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil
0.35 L (0.37 US qt, 0.31 Imp qt)
Rear differential oil
0.35 L (0.37 US qt, 0.31 Imp qt)
51.0 L (13.5 US gal, 11.2 Imp
FWD
gal)
Fuel tank
48.0 L (12.7 US gal, 10.6 Imp
AWD
gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
9-5
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
Dimensions
Item
Vehicle specification
Overall length
4,395 mm (173.0 in)
U.S.A. and Canada
1,795 mm (70.7 in)
Overall width
Mexico
1,797 mm (70.8 in)
Type A
1,579 mm (62.2 in)
U.S.A. and Canada
Overall height*1
Type B
1,567 mm (61.7 in)
Mexico
1,562 mm (61.5 in)
Front tread
1,563 mm (61.5 in)
Rear tread
1,563 mm (61.5 in)
Wheelbase
2,653 mm (104.4 in)
*1
The overall height is categorized according to the antenna type as follows:
Type A
1. Antenna
Type B
Except above.
Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Weight
Item
Automatic transmission
Manual transmission
FWD
AWD
GVWR (Gross Vehicle
1,861 kg (4,103 lbs)
1,902 kg (4,193 lbs)
1,972 kg (4,347 lbs)
Weight Rating)
GAWR (Gross Axle
Front
980 kg (2,161 lbs)
1010 kg (2,227 lbs)
1,030 kg (2,271 lbs)
Weight Rating)
Rear
885 kg (1,951 lbs)
895 kg (1,973 lbs)
945 kg (2,083 lbs)
9-6
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
SKYACTIV-G 2.5
Weight
FWD
AWD
Item
With Cylinder
Without Cylinder
With Cylinder
Without Cylinder
Deactivation
Deactivation
Deactivation
Deactivation
GVWR (Gross Vehicle
1,922 kg (4,273
1,913 kg (4,217
1,997 kg (4,403
1,987 kg (4,381
Weight Rating)
lbs)
lbs)
lbs)
lbs)
1,035 kg (2,282
1,025 kg (2,260
1,060 kg (2,337
1,050 kg (2,315
GAWR (Gross Axle
Front
lbs)
lbs)
lbs)
lbs)
Weight Rating)
Rear
890 kg (1,962 lbs)
940 kg (2,072 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVWR (Gross Vehicle
2,023 kg (4,460 lbs)
Weight Rating)
GAWR (Gross Axle
Front
1,092 kg (2,407 lbs)
Weight Rating)
Rear
934 kg (2,059 lbs)
Mexico
SKYACTIV-G 2.0, SKYACTIV-G 2.5
Item
Weight
GVW (Gross Vehicle
1,939 kg (4,275 lbs)
Weight)
SKYACTIV-G 2.5T
Weight
Item
With moonroof
Without moonroof
GVW (Gross Vehicle
2,039 kg (4,495 lbs)
2,042 kg (4,502 lbs)
Weight)
Light Bulbs
Exterior light/Interior light
All the light bulbs are the LED type.
The LED bulb cannot be replaced. We recommend an Authorized Mazda Dealer
when the replacement is necessary.
9-7
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-31.
Standard tire
(U.S.A. and Canada)
Inflation pressure
Tire size
Front
Rear
215/65R16 98H
250 kPa (36 psi)
250 kPa (36 psi)
SKYACTIV-G 2.0, SKYAC-
250 kPa (36 psi)
250 kPa (36 psi)
215/55R18 95H
TIV-G 2.5
SKYACTIV-G 2.5T
260 kPa (38 psi)
250 kPa (36 psi)
(Mexico)
Inflation pressure
Tire size
Front
Rear
250 kPa (2.5 bar, 36
250 kPa (2.5 bar, 36
215/65R16 98H
psi)
psi)
SKYACTIV-G 2.0, SKYAC-
250 kPa (2.5 bar, 36
250 kPa (2.5 bar, 36
TIV-G 2.5
psi)
psi)
215/55R18 95H
260 kPa (2.6 bar, 38
250 kPa (2.5 bar, 36
SKYACTIV-G 2.5T
psi)
psi)
9-8
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Specifications
Specifications
Temporary spare tire
(U.S.A. and Canada)
Tire size
Inflation pressure
T135/80D17 103M
420 kPa (60 psi)
(Mexico)
Tire size
Inflation pressure
185/65R16 93M*
320 kPa (3.2 bar, 46 psi)
195/55R17 92M*2
320 kPa (3.2 bar, 46 psi)
*1
SKYACTIV-G 2.0
*2
SKYACTIV-G 2.5, SKYACTIV-G 2.5T
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108147 N·m (1214 kgf·m, 80108 ft·lbf)
Fuses
Refer to Fuses on page 6-35.
9-9
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09















Content      ..     16      17      18
