If Trouble Arises
Flat Tire
Locking Lug Nuts
To install the antitheft lug nut
If your Mazda is equipped with the
1. Place the special key on top of the
optional antitheft wheel lug nuts, a
nut, and be sure to hold the key
special key must be used to unlock the
square to it. If you hold the key at
locking lug nut for each wheel. The key
an angle, you may damage both key
is stored in the glove compartment,
and nut. Do not use a power
center console storage, storage box, or
impact wrench.
trunk. Register the key and lug nuts
2. Place the lug wrench on top of the
with the lock manufacturer by filling
special key, apply pressure, and
out the registration card and mailing it
turn it clockwise.
in using the accompanying envelope. If
Nut tightening torque
the key is lost, consult an Authorized
Mazda Dealer or use the lock
108147 (1214,
N·m (kgf·m, ft·lbf)
manufacturer’s order form to order a
80108)
new key.
Mounting the Spare Tire
Antitheft wheel lug nuts cannot be
installed on a steel wheel spare tire.
1. Remove dirt and grime from the
When installing a temporary spare tire,
mounting surfaces of the wheel and
use one of the original lug nuts in place
hub, including the hub bolts, with a
of the locking lug nut. The original lug
cloth.
nuts are stored inside your Mazda.
1. Antitheft lug nut
2. Special key
To remove an antitheft lug nut
WARNING
1. Obtain the special key for the
antitheft lug nut.
Make sure the mounting surfaces
2. Place the special key on top of the
of the wheel, hub and lug nuts are
antitheft lug nut, and be sure to
clean before changing or replacing
hold the key square to it. If you
tires:
hold the key at an angle, you may
When changing or replacing a tire,
damage both key and nut. Do not
not removing dirt and grime from
use a power impact wrench.
the mounting surfaces of the wheel,
3. Place the lug wrench on top of the
hub and hub bolts is dangerous.
key and apply pressure. Turn the
The lug nuts could loosen while
wrench counterclockwise.
driving and cause the tire to come
off, resulting in an accident.
2. Mount the spare tire.
7-10
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Flat Tire
3.
Install the lug nuts with the beveled
Nut tightening torque
edge inward; tighten them by hand.
108147 (1214,
N·m (kgf·m, ft·lbf)
80108)
WARNING
Always securely and correctly
tighten the lug nuts:
Improperly or loosely tightened lug
nuts are dangerous. The wheel
could wobble or come off. This
could result in loss of vehicle
WARNING
control and cause a serious
accident.
Do not apply oil or grease to lug
nuts and bolts and do not tighten
Be sure to reinstall the same nuts
the lug nuts beyond the
you removed or replace them with
recommended tightening torque:
metric nuts of the same
Applying oil or grease to lug nuts
configuration:
and bolts is dangerous. The lug nuts
Because the wheel studs and lug
could loosen while driving and
nuts on your Mazda have metric
cause the tire to come off, resulting
threads, using a non-metric nut is
in an accident. In addition, lug nuts
dangerous. On a metric stud, it
and bolts could be damaged if
would not secure the wheel and
tightened more than necessary.
would damage the stud, which
4.
Turn the jack handle
could cause the wheel to slip off
counterclockwise using the lug
and cause an accident.
wrench and lower the vehicle.
6.
(Aluminum wheel equipped
5.
Use the lug wrench to tighten the
vehicle)
nuts in the order shown.
Remove the center cap by tapping
it from the backside of the wheel
using the lug wrench.
7.
(Without flat tire belt)
Store the damaged and/or flat tire
in the rear cargo area.
(With flat tire belt)
Open the luggage mat.
8.
Remove the belt for securing the
flat tire.
If you are unsure of how tight the
nuts should be, have them
inspected at an Authorized Mazda
Dealer.
7-11
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Flat Tire
9. Put the flat tire into the liftgate on
13.Thread the belt through the buckle,
the left and toward the back.
then pull the belt end to secure the
flat tire.
10.Fold the right side of the rear
seatback forward.
14.Return the seatback on the right
11.Thread the belt through the rear
side of the rear seat to its original
seat as shown in the figure.
position.
15.Remove the tire blocks and store
the tools and jack.
16.Check the inflation pressure. Refer
to Tires on page 9-8.
17.Have the flat tire repaired or
replaced as soon as possible.
WARNING
12.Thread the buckle through the
Do not drive with any tires that have
wheel as shown in the figure and
incorrect air pressure:
secure it so that the buckle does
Driving on tires with incorrect air
not contact the wheel.
pressure is dangerous. Tires with
incorrect pressure could affect
handling and result in an accident.
When you check the regular tires' air
pressure, check the spare tire, too.
NOTE
To prevent the jack and tool from
rattling, store them properly.
7-12
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Battery Runs Out
Jump-Starting
Jump-Starting
Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If
you feel unsure about jump-starting, we strongly recommend that you have a
competent service technician do the work.
WARNING
Follow These Precautions Carefully:
To ensure safe and correct handling of the battery, read the following precautions
carefully before using the battery or inspecting it.
Keep flames and sparks away from open battery cells and do not allow
metal tools to contact the positive (+) or negative (-) terminal of the battery when
working near a battery. Do not allow the positive (+) terminal to contact the
vehicle body:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced
during normal battery operation, could ignite and cause the battery to explode. An
exploding battery can cause serious burns and injuries. Keep all flames including
cigarettes and sparks away from open battery cells.
Keep all flames and sparks away from open battery cells because hydrogen
gas is produced from open battery cells while charging the battery or adding
battery fluid:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced
during normal battery operation, could ignite and cause the battery to explode. An
exploding battery can cause serious burns and injuries. Keep all flames including
cigarettes and sparks away from open battery cells.
Do not jump-start a frozen battery or one with a low fluid level:
Jump-starting a frozen battery or one with a low fluid level is dangerous. It may
rupture or explode, causing serious injury.
Connect the negative cable to a good ground point away from the battery:
Connecting the end of the second jumper cable to the negative (-) terminal of the
discharged battery is dangerous.
A spark could cause the gas around the battery to explode and injure someone.
7-13
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Battery Runs Out
Route the jumper cables away from parts that will be moving:
Connecting a jumper cable near or to moving parts (cooling fans, belts) is
dangerous. The cable could get caught when the engine starts and cause serious
injury.
CAUTION
Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and
other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in
series or a 24 V motor generator set).
1. Move the booster vehicle so that its battery is as close as possible to your
vehicle's battery.
2. Make sure that the power such as for the headlights and air conditioner is turned
off.
3. Remove the battery cover.
4. Turn off the booster vehicle's engine and connect the jumper cables in the
following order.
Make sure that the jumper cables are securely connected so that they do not
disconnect due to engine vibrations.
1st lead
Positive (+) terminal on the discharged battery
Positive (+) terminal on booster vehicle's battery
2nd lead
Negative (-) terminal on booster vehicle's battery
7-14
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Battery Runs Out
Location shown in the figure (do not connect to the negative (-) terminal of
the battery)
5. Start the booster vehicle's engine and rev the engine.
6. Start the engine of your vehicle. Run the engines for about 3 minutes to
temporarily charge the battery of your vehicle.
7. Disconnect the jumper cables in the reverse order of their connection.
8. Install the battery cover.
9. Have your vehicle inspected by an Authorized Mazda Dealer as soon as possible.
7-15
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Emergency Starting
Starting a Flooded Engine
Push-Starting
Starting a Flooded Engine
Push-Starting
If the engine fails to start, it may be
Do not push-start your Mazda.
flooded (excessive fuel in the engine).
WARNING
Follow this procedure:
Never tow a vehicle to start it:
1. If the engine does not start within 5
Towing a vehicle to start it is
seconds on the first try, wait 10
dangerous. The vehicle being towed
seconds and try again.
could surge forward when its engine
2. Make sure the parking brake is on.
starts, causing the 2 vehicles to collide.
3. Depress the accelerator all the way
The occupants could be injured.
and hold it there.
4. Depress the clutch pedal (manual
transmission) or the brake pedal
CAUTION
(automatic transmission), then
Do not push-start a vehicle that has a
press the push button start. If the
manual transmission. It can damage
engine starts, release the
the emission control system.
accelerator immediately because
the engine will suddenly rev up.
5. If the engine fails to start, crank it
NOTE
without depressing the accelerator.
You cannot start a vehicle with an
automatic transmission by pushing it.
If the engine still does not start using
the previous procedure, have your
vehicle inspected by an Authorized
Mazda Dealer.
7-16
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Overheating
Open the hood ONLY after steam is
Overheating
no longer escaping from the engine:
Steam from an overheated engine is
Overheating
dangerous. The escaping steam could
If the engine coolant temperature
seriously burn you.
gauge indicates overheating and the
If the engine coolant temperature
high engine coolant temperature
gauge indicates overheating and the
warning indication is displayed, the
high engine coolant temperature
vehicle loses power or you hear a loud
warning indication is displayed:
knocking or pinging noise, the engine
is probably too hot.
1.
Drive safely to the side of the road
WARNING
and park off the right-of-way.
2.
Put a vehicle with an automatic
transmission in park (P), a manual
transmission in neutral.
3.
Apply the parking brake.
Pull over to a safe location, then
4.
Turn off the air conditioner.
switch the ignition off and make sure
5.
Check whether coolant or steam is
the fan is not running before
escaping from the engine
attempting to work near the cooling
compartment.
fan:
Working near the cooling fan when it is
If steam is coming from the engine
running is dangerous. The fan could
compartment:
continue running indefinitely even if
Do not go near the front of the
the engine has stopped and the engine
vehicle. Stop the engine.
compartment temperature is high. You
Wait until the steam dissipates,
could be hit by the fan and seriously
then open the hood and start the
injured.
engine.
If neither coolant nor steam is
escaping:
Do not remove either
Open the hood and idle the engine
cooling system cap when the engine
until it cools.
and radiator are hot:
When the engine and radiator are hot,
CAUTION
scalding coolant and steam may shoot
out under pressure and cause serious
If the cooling fan does not operate
injury.
while the engine is running, the
engine temperature will increase.
Stop the engine and call an
Authorized Mazda Dealer.
6.
Make sure the cooling fan is
operating, then turn off the engine
after the temperature has
decreased.
7-17
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Overheating
7. When cool, check the coolant level.
SKYACTIV-G 2.5T
If it is low, look for coolant leaks
from the radiator and hoses.
If you find a leak or other damage, or
if coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.
SKYACTIV-G 2.0 and SKYACTIV-G
2.5
1. Coolant reservoir
2. Cooling fan
3. Cooling system cap
If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required
(page 6-19).
CAUTION
1. Cooling system cap
2. Cooling fan
If the engine continues to overheat or
3. Coolant reservoir
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.
7-18
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Emergency Towing
Towing Description
WARNING
Towing Description
Always tow an AWD vehicle with all
four wheels off the ground:
We recommend that towing be done
Towing an AWD vehicle with either the
only by an Authorized Mazda Dealer
front or rear wheels on the ground is
or a commercial tow-truck service.
dangerous as the drive train could be
damaged, or the vehicle could trail
Proper lifting and towing are necessary
away from the tow truck and cause an
to prevent damage to the vehicle.
accident. If the drive train has been
Particularly when towing an AWD
damaged, transport the vehicle on a
vehicle, where all the wheels are
flatbed truck.
connected to the drive train, proper
transporting of the vehicle is absolutely
essential to avoid damaging the drive
system. Government and local laws
must be followed.
CAUTION
¾ Do not tow the vehicle pointed
backward with driving wheels on the
1. Wheel dollies
ground. This may cause internal
damage to the transmission.
A towed FWD vehicle should have its
drive wheels (front wheels) off the
ground. If excessive damage or other
conditions prevent this, use wheel
dollies.
When towing a FWD vehicle with the
rear wheels on the ground, release the
¾ Do not tow with sling-type
parking brake.
equipment. This could damage your
Refer to Electric Parking Brake (EPB) on
vehicle. Use wheel-lift or flatbed
page 4-64.
equipment.
A towed AWD vehicle must have all its
wheels off the ground.
7-19
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Emergency Towing
¾ If the parking brake cannot be
Tiedown Hooks
released when towing the vehicle,
transport the vehicle with all front
Tiedown Hooks
and rear wheels raised off the ground
as shown in the figure. If the vehicle
is towed without raising the wheels
CAUTION
off the ground, the brake system
Do not use the front and rear tiedown
could be damaged.
eyelets for towing the vehicle.
They have been designed only for
securing the vehicle to a transport
vessel during shipping.
Using the eyelets for any other purpose
could result in the vehicle being
damaged.
1. Remove the tiedown eyelet and the
lug wrench from the luggage
1. Wheel dollies
compartment (page 7-3).
2. Wrap a flathead screwdriver or
similar tool with a soft cloth to
prevent damage to a painted
bumper, and open the cap located
on the front or rear bumper.
Front
7-20
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Emergency Towing
Rear
Rear
1. Lug wrench
2. Tiedown eyelet
CAUTION
Do not use excessive force as it may
damage the cap or scratch the
4. Hook the tying rope to the tiedown
painted bumper surface.
eyelet.
NOTE
CAUTION
Remove the cap completely and
If the tiedown eyelet is not securely
store it so as not to lose it.
tightened, it may loosen or
3. Securely install the tiedown eyelet
disengage from the bumper when
using the lug wrench.
tying the vehicle. Make sure that
Front
the tiedown eyelet is securely
tightened to the bumper.
1. Lug wrench
2. Tiedown eyelet
7-21
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Brake System Warning Indication/
If a Warning Light Turns
Warning Light
On or Flashes
If a Warning Light Turns On or
Flashes
If any warning light turns on/flashes,
take appropriate action for each light.
This warning has the following
There is no problem if the light turns
functions:
off, however if the light does not turn
Warning light inspection
off or turns on/flashes again, consult
an Authorized Mazda Dealer.
For an operation check, make sure that
The details for some warnings can be
the light turns on when the ignition is
viewed on the center display or
switched on, and turns off a few
multi-information display in the
seconds later or when the engine is
instrument cluster.
started.
Center display
When the light turns on
1. Select “Information” on the home
If the brake system warning light
screen.
remains illuminated the brake fluid
2. Select “Vehicle Status Monitor”.
may be low or there could be a
3. Select the applicable warning to
problem with the brake system. Park
view the warning details.
the vehicle in a safe place immediately
and contact an Authorized Mazda
NOTE
Dealer.
You can also display the currently
Refer to Inspecting Brake/Clutch Fluid
occurring warning by sliding the
Level on page 6-21.
commander knob to the left while on
the home screen of the center display.
WARNING
Multi-information display
Do not drive with the brake system
1. Press the INFO switch on the
warning light illuminated. Contact an
steering switch to display the
Authorized Mazda Dealer to have the
warning indication screen.
brakes inspected as soon as possible:
Refer to Multi-information Display
Driving with the brake system warning
on page 4-14.
light illuminated is dangerous. It
indicates that your brakes may not
work at all or that they could
completely fail at any time. If this light
remains illuminated, after checking
that the parking brake is fully released,
have the brakes inspected
immediately.
7-22
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Charging System Warning
CAUTION
Indication/Warning Light
¾ In addition, the effectiveness of the
braking may diminish so you may
need to depress the brake pedal
more strongly than normal to stop
the vehicle.
If the warning light illuminates while
driving, it indicates a malfunction of
Electronic Brake Force Distribution
the alternator or of the charging
System Warning
system.
Drive to the side of the road and park
off the right-of-way. Consult an
Authorized Mazda Dealer.
CAUTION
If the electronic brake force
Do not continue driving when the
distribution control unit determines
charging system warning light is
that some components are operating
illuminated because the engine could
incorrectly, the control unit may
stop unexpectedly.
illuminate the brake system warning
light and the ABS warning light
Engine Oil Warning Indication/
simultaneously. The problem is likely to
Warning Light
be the electronic brake force
distribution system.
WARNING
Do not drive with both the brake
This warning light indicates low engine
system warning light and ABS warning
oil pressure.
light illuminated. Have the vehicle
towed to an Authorized Mazda
CAUTION
Dealer to have the brakes inspected as
soon as possible:
Do not run the engine if the oil
Driving when the brake system warning
pressure is low. Otherwise, it could
light and ABS warning light are
result in extensive engine damage.
illuminated simultaneously is
If the light illuminates or the warning
dangerous.
indication is displayed while driving:
When both lights are illuminated, the
1. Drive to the side of the road and
rear wheels could lock more quickly in
park off the right-of-way on level
an emergency stop than under normal
ground.
circumstances.
2. Turn off the engine and wait 5
minutes for the oil to drain back
into the oil pan.
7-23
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
3. Inspect the engine oil level (page
CAUTION
6-18). If it's low, add the
appropriate amount of engine oil
Do not drive the vehicle with the high
while being careful not to overfill.
engine coolant temperature warning
light illuminated. Otherwise, it could
CAUTION
result in damage to the engine.
Do not run the engine if the oil
Power Steering Malfunction
level is low. Otherwise, it could
Indication/Indicator Light
result in extensive engine damage.
4. Start the engine and check the
warning light.
If the light remains illuminated even
though the oil level is normal or after
The message is displayed if the electric
adding oil, stop the engine
power steering has a malfunction.
immediately and have your vehicle
If the message is displayed, stop the
towed to an Authorized Mazda Dealer.
vehicle in a safe place and do not
operate the steering wheel. There is no
High Engine Coolant Temperature
problem if the indication turns off
Warning Indication
when the engine is restarted after
some time has passed. If the indication
displays even after the engine is
restarted, contact an Authorized
Mazda Dealer if the message is
displayed continuously.
Displays if the engine coolant
temperature has increased excessively.
NOTE
“Elevated Engine Coolant Temp. Drive
If the message is displayed, the
Slowly” displayed
power steering will not operate
normally. In this case, the steering
Drive slowly to reduce engine load
wheel can still be operated,
until you can find a safe place to stop
however, the operation may feel
the vehicle and wait for the engine to
heavy compared to normal, or the
cool down.
steering wheel could vibrate when
“Excessive Engine Coolant Temp. Stop
turning.
the Vehicle in a Safe Location”
Repeatedly jerking the steering
displayed
wheel left and right while the vehicle
is stopped or moving extremely
This indicates the possibility of
slowly will cause the power steering
overheating. Park the vehicle in a safe
system to go into protective mode
place immediately and stop the
which will make the steering feel
engine.
heavy, but this does not indicate a
Refer to Overheating on page 7-17.
problem. If this occurs, park the
vehicle safely and wait several
minutes for the system to return to
normal.
7-24
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
ABS Warning Indication/Warning
Brake Control System Warning
Light
Indication/Warning Light
If the ABS warning light stays on while
The warning light illuminates when the
you're driving, the ABS control unit has
system has a malfunction. Have your
detected a system malfunction. If this
vehicle inspected at an Authorized
occurs, your brakes will function
Mazda Dealer.
normally as if the vehicle had no ABS.
Electric Parking Brake (EPB)
Should this happen, consult an
Indication/Indicator Light
Authorized Mazda Dealer as soon as
possible.
NOTE
When the engine is jump-started to
charge the battery, uneven rpm
occurs and the ABS warning light
This warning has the following
may illuminate. If this occurs, it is the
functions:
result of the weak battery and does
Parking brake warning/Indicator light
not indicate an ABS malfunction.
inspection
Recharge the battery.
The brake assist system does not
The light illuminates when the parking
operate while the ABS warning light
brake is applied with the ignition
is illuminated.
switched to START or ON. It turns off
when the parking brake is released.
Master Warning Indication
When the light is flashing
The light flashes if the Electric Parking
Brake (EPB) has a malfunction. If the
light remains flashing even if the
Electric Parking Brake (EPB) switch is
The indication displays if the system
operated, consult an Authorized
has a malfunction.
Mazda Dealer as soon as possible.
Check the reason for the indication
displaying on the center display or
multi-information display.
Refer to If a Warning Light Turns On or
Flashes on page 7-22.
7-25
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Brake Override Warning Indication
WARNING
If the check engine light turns on, do
not disconnect the battery cables.
If the battery cables are disconnected
This message is displayed when the
and then reconnected, the engine
accelerator pedal and brake pedal are
could be damaged and catch on fire.
depressed at the same time while
driving.
Automatic Transmission Warning
Release the accelerator pedal and
Indication/Warning Light*
depress the brake pedal.
Check Engine Indication/Light
The indication/light illuminates when
the transmission has a problem.
If this light illuminates while driving,
CAUTION
the vehicle may have a problem. It is
important to note the driving
If the automatic transmission warning
conditions when the light illuminated
indication/light illuminates, the
and consult an Authorized Mazda
transmission has an electrical problem.
Dealer.
Continuing to drive your Mazda in this
The check engine light may illuminate
condition could cause damage to your
in the following cases:
transmission. Consult an Authorized
Mazda Dealer as soon as possible.
The engine's electrical system has a
problem.
The emission control system has a
problem.
The fuel-filler cap is missing or not
tightened securely.
The fuel tank level being very low or
approaching empty.
If the check engine light remains on, or
it flashes continuously , do not drive at
high speeds and consult an Authorized
Mazda Dealer as soon as possible.
7-26
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
AWD Warning Indication/
“Mismatched Tire Diameters. Vehicle
Warning Light*
Now in Front Wheel Drive” is
displayed/When the light is turned on
The indication is displayed/the light
turns on under the following
conditions. Inspect the tire sizes or tire
pressures on all 4 wheels. Contact an
Authorized Mazda Dealer if the
“AWD Malfunction. Front Wheel
indication remains on or the warning
Drive Only. Have the Vehicle
light remains illuminated.
Inspected” is displayed/When the
light is turned on
When any of the tire diameter is
different.
The indication is displayed/the light
When any of the tire pressure is
turns on under the following
incorrect.
conditions. The system may have a
malfunction. Have the vehicle checked
TCS/DSC Indication/Indicator
at an Authorized Mazda Dealer.
Light (Turns on)
When there is a malfunction in the
AWD system.
“Excessive AWD System Load. Drive
Slowly Until Warning Light Turns Off.
Vehicle Now in Front Wheel Drive” is
If the light stays on, the TCS, DSC or
displayed/When the light is flashing
the brake assist system may have a
The indication is displayed/the light
malfunction and they may not operate
flashes under the following conditions.
correctly. Take your vehicle to an
Park the vehicle in a safe place and
Authorized Mazda Dealer.
check that the warning indication light
Air Bag/Front Seat Belt
turns off/ the warning light stops
Pretensioner System Warning
flashing, and then drive the vehicle.
Indication/Warning Light
Contact an Authorized Mazda Dealer
if the indication is continuously
displayed.
When the differential oil temperature
is excessively high.
When there is a large difference
A system malfunction is indicated if the
between the front and rear wheel
warning light constantly flashes,
rotation, such as when trying to
constantly illuminates or does not
remove the vehicle from mud.
illuminate at all when the ignition is
switched ON. If any of these occur,
consult an Authorized Mazda Dealer
as soon as possible. The system may
not operate in an accident.
*Some models.
7-27
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Do not ignore the TPMS warning light
WARNING
when it is turned on or flashing:
Continuing to drive the vehicle while
Never tamper with the air bag/
ignoring the illumination/flashing of
pretensioner systems and always have
the TPMS warning light is dangerous
an Authorized Mazda Dealer perform
because a tire may burst which could
all servicing and repairs:
lead to an accident. Take appropriate
Self-servicing or tampering with the
measures as soon as possible.
systems is dangerous. An air bag/
pretensioner could accidentally
KEY Warning Indication/Warning
activate or become disabled causing
Light (Red)
serious injury or death.
Tire Pressure Monitoring System
(TPMS) Warning Indication/
Warning Light (Flashing)
“Keyless Entry System Malfunction.
Have the Vehicle Inspected” is
displayed
This message is displayed if the
If there is a problem with the TPMS or
advanced keyless entry & push button
the voltage of a tire pressure sensor
start system has a problem.
decreases, the TPMS warning light
Contact an Authorized Mazda Dealer.
flashes and a message is displayed on
the multi-information display. Have
CAUTION
your vehicle inspected by an
Authorized Mazda Dealer.
If the message is indicated, or the push
button start indicator light (amber)
WARNING
flashes, the engine may not start. If the
engine cannot be started, try starting it
Do not drive the vehicle at high
using the emergency operation for
speeds if the TPMS warning light turns
starting the engine, and have the
on or flashes:
vehicle inspected at an Authorized
Driving the vehicle at high speeds
Mazda Dealer as soon as possible.
while the TPMS warning light is turned
Refer to Emergency Operation for
on or flashing is dangerous because
Starting the Engine on page 4-9.
the brake performance and the
steering wheel operability will be
reduced. If the vehicle is driven at high
speeds or the brakes are suddenly
applied, it could lead to an accident.
Gradually apply the brakes to lower the
vehicle's speed.
7-28
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
“Key Not Detected” is displayed
High Beam Control System (HBC)
Warning Indication/Warning Light
If the presence of the key cannot be
(Amber)*
detected (dead battery, battery
malfunction, no key), it is displayed
when the driver attempts to start the
engine (push button start operation,
brake pedal depression).
Displayed when it is determined that
a key that was in the vehicle has
The light remains turned on if there is a
been removed from the vehicle. (Key
problem with the system. Have your
taken out warning. Other than
vehicle inspected at an Authorized
IG-OFF).
Mazda Dealer.
Security Indicator Light
i-ACTIVSENSE Warning
Indication/Warning Light*
If the security indicator light flashes
continuously while you are driving, do
The indication displays if the system
not shut off the engine. Go to an
has a malfunction.
Authorized Mazda Dealer and have it
Check the reason for the indication
checked. If the engine is shut off while
displaying on the center display or
the indicator light is flashing, you will
multi-information display.
not be able to restart it.
Refer to If a Warning Light Turns On or
Make sure the key is within the
Flashes on page 7-22.
operational range for signal
Exterior Light Warning Indication/
transmission. Switch the ignition off,
Warning Light
and then restart the engine. If the
engine does not start after 3 or more
tries, contact an Authorized Mazda
Dealer.
NOTE
Because the electronic codes are reset
This light illuminates if there is a
when the immobilizer system is
malfunction in the exterior lights
repaired, the keys are needed. Make
(except license plate lights). Have your
sure to bring all the keys to an
vehicle inspected by an Authorized
Authorized Mazda Dealer so that they
Mazda Dealer.
can be programmed.
*Some models.
7-29
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Check Fuel Cap Warning
CAUTION
Indication/Warning Light
Do not drive the vehicle while an
exterior light has a malfunction. Poor
visibility, and not being able to signal
braking and turns may cause an
accident. In addition, if the vehicle is
driven with the lights not turned on, it
If the check fuel cap warning light
may conflict with laws and regulations
illuminates while driving, the fuel-filler
due to poor maintenance.
cap may not be installed properly.
Low Fuel Warning Indication/
Action to be taken
Warning Light
Stop the engine and reinstall the
fuel-filler cap.
Refer to Refueling on page 3-33.
Engine Oil Level Warning
Indication/Warning Light
The warning indication/warning light
displays/turns on when the ignition is
switched ON and the remaining fuel is
about 9 L (2.3 US gal, 1.9 Imp gal) or
the remaining distance to empty is 50
km (31 miles) or shorter. The warning
This warning light indicates that the
light flashes when the vehicle
engine oil level is around the MIN
continues to be driven with the
mark (page 6-18).
warning indication/warning light
displayed/turned on and the
CAUTION
remaining fuel in the tank is near
empty.
Do not continue to drive the vehicle
with the engine oil level warning
NOTE
indication/warning light displayed/
The light illumination timing may vary
turned on. If the vehicle continues to
because fuel inside the fuel tank moves
be driven with an insufficient amount
around according to the driving
of engine oil, it could cause damage to
conditions and the vehicle posture.
the engine.
Action to be taken
Action to be taken
Add fuel. If the light is flashing, refuel
Add 1 L (0.26 US gal, 0.22 Imp gal) of
as soon as possible.
engine oil (page 6-17).
7-30
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Seat Belt Warning Indication/
Action to be taken
Warning Light (Front seat)
Fasten the seat belts.
Seat Belt Warning Light (Rear seat)
(Red)
The seat belt warning light turns on if
If the rear seat belts are not fastened
the driver or front passenger's seat is
while the ignition is switched ON , the
occupied and the seat belt is not
driver and the passenger are alerted by
fastened with the ignition switched
the warning light.
ON.
The warning light operates even if there
If the driver or front passenger's seat
is no passenger on the rear seat.
belt is unfastened (only when the front
passenger's seat is occupied) and if the
NOTE
vehicle is driven at about 20 km/h (12
If a rear seat belt is not fastened by a
mph) or faster, or about 10 km/h (6
certain period of time after the engine
mph) or faster for a continuous 30
has been started, the warning light
seconds, with the seat belt unfastened,
turns off.
the warning light flashes for a certain
Action to be taken
period. After a short time, the warning
light stops flashing, but remains
Fasten the seat belts.
illuminated.
Low Washer Fluid Level Warning
NOTE
Indication/Warning Light*
The warning light flashes for about 6
seconds if the driver or front
passenger's seat is not fastened
when the ignition is switched ON.
(Except Mexico)
Placing heavy items on the front
This warning light indicates that little
passenger's seat may cause the front
washer fluid remains.
passenger's seat belt warning
Action to be taken
function to operate depending on
the weight of the item.
Add washer fluid (page 6-21).
To allow the front passenger
occupant classification sensor to
function properly, do not place and
sit on an additional seat cushion on
the front passenger's seat. The
sensor may not function properly
because the additional seat cushion
could cause sensor interference.
If a small child is seated on the front
passenger's seat, the warning light
may not operate.
*Some models.
7-31
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Door-Ajar/Liftgate-Ajar Warning
WARNING
Indication/Warning Light
Do not drive the vehicle at high
speeds if the TPMS warning light turns
on or flashes:
Driving the vehicle at high speeds
while the TPMS warning light is turned
on or flashing is dangerous because
the brake performance and the
steering wheel operability will be
reduced. If the vehicle is driven at high
speeds or the brakes are suddenly
The light turns on if any door/liftgate is
applied, it could lead to an accident.
not closed securely.
Gradually apply the brakes to lower the
Action to be taken
vehicle's speed.
Close the door/liftgate securely.
Do not ignore the TPMS warning light
Tire Pressure Monitoring System
when it is turned on or flashing:
(TPMS) Warning Indication/
Continuing to drive the vehicle while
Warning Light (Turns on)
ignoring the illumination/flashing of
the TPMS warning light is dangerous
because a tire may burst which could
lead to an accident. Take appropriate
measures as soon as possible.
If a tire pressure decreases below the
NOTE
specified air pressure, the TPMS
While the TPMS is learning the tire
warning light turns on.
positions, such as immediately after a
At the same time, a message and the
tire position has been changed, the tire
tire pressure of each tire are displayed
pressure at the tire position prior to it
on the multi-information display
being changed is displayed until the
alternately. In addition, the tire (s) with
system completes the learning. For this
low air pressure is displayed in yellow.
reason, the tire pressures displayed for
the tire positions may be different from
the actual tire pressures at the tire
positions.
Action to be taken
Adjust the tire pressures to the
appropriate pressures.
Refer to Tire Inflation Pressure on page
6-31.
7-32
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
KEY Indicator Light (Green)
CAUTION
(Flashing)
¾ Adjust the tire pressures while the
tires are cool. Because the air
pressure in the tires fluctuates
depending on the temperature,
before adjusting the tire pressures,
let the vehicle sit for an hour or drive
“Low Key Fob Battery. Replace
it only within a 1.6 km (1 mile)
Battery” is displayed/When the light
distance. If the tire pressures are
is flashing
adjusted while the tires are warm,
the tire pressures may decrease
When the key battery is low, the
below the specified air pressure after
indication is displayed when the
cooling down which could turn on
ignition is switched OFF.
the warning light. In addition,
Action to be taken
because the air pressure in the tires
decreases when the ambient
Replace the key battery.
temperature is low, if the ambient
temperature increases, an
illuminated TPMS warning light may
turn off. Under any circumstances,
always adjust the tire pressures while
the tires are cool.
¾ After adjusting the tire pressures, the
TPMS warning light turns off. If the
TPMS warning light does not turn off,
drive the vehicle at a speed of about
25 km (16 mph) or faster for 3
minutes or longer and make sure the
warning light turns off.
If the TPMS warning light remains on
even after adjusting the tire pressures,
one of the tires may have a puncture.
7-33
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Multi-information Display
Message Indicated on Multi-information Display
If there is a notification from the vehicle, a message is displayed on the
multi-information display. Check the information and take the necessary action.
1. Multi-information display
If the warning light turns on/flashes simultaneously or a symbol is indicated on the
display, check the information regarding the warning light or symbol.
Refer to If a Warning Light Turns On or Flashes on page 7-22.
Display*1*2
Content
Action to be taken
This message is indicated when there
Depress the brake pedal. Cancel the
is a problem with the brake related
Depress Brake Pedal.
AUTOHOLD function and have your
system while the vehicle is being held
Brake Hold Disabled
vehicle inspected at an Authorized
in a stop position by the AUTOHOLD
Mazda Dealer.
function.
This message indicates the possibility
Steep Slope. Continue
of the vehicle not being held in the
Depress and hold your foot on the
Pressing Brake Pedal to
stopped position by the AUTOHOLD
brake pedal.
Hold Stopped Position
function, such as on steep slopes.
This message is indicated when the
Depress Brake Pedal and
Operate the Electric Parking Brake
Electric Parking Brake (EPB) switch is
Operate Switch to Re-
(EPB) switch while depressing the
operated without depressing the
lease Elec. Parking Brake
brake pedal.
brake pedal.
This message is indicated when the
Depress Brake Pedal and
cancel operation is done without de-
Cancel the AUTOHOLD function stop
Operate Switch to Re-
pressing the brake pedal while the
hold control while depressing the
lease
vehicle is being held in the stopped
brake pedal.
position by the AUTOHOLD function.
7-34
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Display*1*2
Content
Action to be taken
This message is indicated when the
Mazda Radar Cruise Control
Mazda Radar Cruise
(MRCC), Mazda Radar Cruise Con-
Have your vehicle inspected by an
Control Canceled. Drive
trol with Stop & Go function (MRCC
Authorized Mazda Dealer.
Safely
with Stop & Go function), and the
Traffic Jam Assist (TJA) have been can-
celed other than by the driver.
This message is indicated when the
Distance & Speed Alert
Distance & Speed Alert (DSA) have
Have your vehicle inspected by an
Operation Canceled
been canceled other than by the driv-
Authorized Mazda Dealer.
Drive Safely
er.
Cruise Control Opera-
This message is indicated when the
Have your vehicle inspected by an
tion Canceled. Drive
Cruise Control have been canceled
Authorized Mazda Dealer.
Safely
other than by the driver.
This message is indicated after the
Emergency Braking Acti-
Smart Brake Support (SBS) brakes op-
vated. Depress Brake
Depress the brake pedal.
erate and when the Smart Brake Sup-
Pedal to Hold Stop
port (SBS) is canceled.
Touch the key against push button
This message is indicated when the
Touch Key Fob to Push
start to start the engine.
key battery is weak (battery dead or
Button Start Switch
Refer to Engine Start Function When
damaged key).
Key Battery is Dead on page 4-8.
This message is indicated when the
When starting the engine, press the
Depress Brake Pedal to
push button start is pressed without
push button start with the brake ped-
Start Vehicle
depressing the brake pedal.
al depressed.
This message is indicated when the
When starting the engine, press the
Depress Clutch Pedal to
push button start is pressed without
push button start with the clutch
Start Vehicle
depressing the clutch pedal.
pedal depressed.
This message is indicated when the
Check Gear Selector
selector lever is shifted to the P or R
Check the selector lever position.
Lever Position
position while driving.
This message is indicated when AU-
Close Door and Fasten
TOHOLD is about to operate and a
When the AUTOHOLD is turned on,
Seat Belt
door is opened or a seat belt is unfas-
close the doors and fasten seat belts.
tened.
Wiper Blades Must Be
This message is indicated when the
Return the wiper arms to the initial
on Windshield Before
ignition is switched ON with the wip-
positions.
Operating
er arms at the service positions.
7-35
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Display*1*2
Content
Action to be taken
This message is indicated when there
Windshield Wiper Range
is snow or dirt accumulation on the
Remove foreign matter from the
of Motion Reduced. Re-
windshield and the wiper operation
windshield.
move Obstruction(s)
range is narrowed.
This message is indicated when the
Vehicle Not Switched
Switch the ignition OFF before leaving
driver’s door is opened without
Off
the vehicle.
switching the ignition OFF.
Displays when the push button start
Gear Selector Lever Not
is pressed while the selector lever is
Shift the selector lever to the P posi-
in Park
in a position other than P, and the ig-
tion and then switch the ignition OFF.
nition is switched to ACC.
Excessive Transmission
This message is indicated when the
Drive slowly to reduce load on the
Temperature. Drive
internal temperature of the automatic
automatic transmission.
Slowly
transmission is high.
Excessive Transmission
This message is indicated when the
Park the vehicle in a safe place imme-
Temp. Stop Vehicle in a
automatic transmission fluid temper-
diately and contact an Authorized
Safe Location
ature is abnormally high.
Mazda Dealer.
*1
A pop-up is displayed when a warning occurs.
*2
One screen displays four rows. If the entire message cannot be displayed on the screen, it switches to
another screen.
7-36
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Seat Belt Warning Beep
Warning Sound is
Front seat
Activated
Except Mexico
Lights-On Reminder
If the driver's seat belt is not fastened
The lights-on reminder is operable
when the ignition is switched ON, a
beep sound will be heard for about 6
when the time setting*1 of the auto
seconds. If the driver or the front
headlight off function is off.
passenger's seat belt is not fastened
If the ignition is switched OFF with the
and if the vehicle is driven at about 20
exterior lights turned on and the
km/h (12 mph) or faster, or about 10
driver’s door is opened, a sound is
km/h (6 mph) or faster for a
activated.
continuous 30 seconds, with the seat
Operate the headlight switch to turn
belt unfastened, a sound is activated
off the exterior lights.
continuously for a certain period.
*1
If the light switch is left on, the
Until a seat belt is fastened or a given
auto headlight off function
period of time has elapsed, the beep
automatically turns off the lights
sound will not stop even if the vehicle
about 30 seconds after switching
speed falls below 20 km/h (12 mph).
the ignition off. The time setting
can be changed.
NOTE
Refer to the Settings section in the
To allow the front passenger
Mazda Connect Owner's Manual.
occupant classification sensor to
NOTE
function properly, do not place and
sit on an additional seat cushion on
When the ignition is switched to
the front passenger's seat. The
ACC, the “Ignition Not Switched OFF
sensor may not function properly
(STOP) Warning Beep” (page 7-38)
because the additional seat cushion
overrides the lights-on reminder.
could cause sensor interference.
A personalized function is available
If a small child is seated on the front
to change the sound volume for the
passenger's seat, the warning beep
lights-on reminder.
may not operate.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
7-37
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Mexico
Ignition Not Switched Off (STOP)
Warning Beep
If the vehicle speed exceeds about 20
km/h (12 mph) with the driver or front
If the driver's door is opened with the
passenger's seat belt unfastened, a
ignition switched to ACC, a beep will
warning beep sounds continuously. If
be heard continuously in the cabin to
the seat belt remains unfastened, the
notify the driver that the ignition has
beep sound stops once and then
not been switched OFF (STOP). Under
continues for about 90 seconds. The
this condition, the keyless entry system
beep stops after the driver or front
will not operate, the vehicle cannot be
passenger's seat belt is fastened.
locked, and the battery voltage will be
Until a seat belt is fastened or a given
depleted.
period of time has elapsed, the beep
sound will not stop even if the vehicle
Key Removed from Vehicle
Warning Beep
speed falls below 20 km/h (12 mph).
Vehicles with advanced keyless
NOTE
function
Placing heavy items on the front
passenger's seat may cause the front
If the key is taken out of the vehicle
passenger's seat belt warning
while the ignition is switched to ACC
function to operate depending on
or ON, and all the doors are closed, a
the weight of the item.
sound is activated 6 times outside of
To allow the front passenger seat
the vehicle and a sound is activated 1
weight sensor to function properly,
time in the vehicle.
do not place and sit on an additional
Vehicles without advanced keyless
seat cushion on the front passenger's
function
seat. The sensor may not function
properly because the additional seat
If the key is taken out of the vehicle
cushion could cause sensor
while the ignition is switched to ACC
interference.
or ON, and all the doors are closed, a
If a small child is seated on the front
sound is activated 1 time in the
passenger's seat, the warning beep
vehicle.
may not operate.
NOTE
Rear seat
Make sure that you leave the vehicle
while carrying the key, or switch the
The warning beep only sounds if a seat
ignition OFF.
belt is unfastened after being fastened.
7-38
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Touch Sensor Inoperable Warning
Key Left-in-luggage Compartment
Beep (With the advanced keyless
Warning Beep (With the advanced
function)
keyless function)
A warning beep is activated to notify
If the key is left in the luggage
the driver that the doors are not locked
compartment with all the doors locked
when all of the following conditions
and the liftgate closed, a beep will be
are met:
heard outside for about 10 seconds to
notify the driver that the key is in the
The ignition is switched OFF.
luggage compartment. In this case,
All the doors and liftgate are not fully
take out the key by pressing the electric
closed.
liftgate opener and opening the
The lock is operated 3 times within 5
liftgate. The key taken out of the
seconds.
luggage compartment may not operate
Check the ignition and whether the
because its functions have been
doors and liftgate are open or closed,
temporarily stopped. To restore the
and then operate the lock again.
key's functions, perform the applicable
procedure (page 3-8).
Liftgate Door-lock Switch
Inoperable Warning Beep (With
Key Left-in-vehicle Warning Beep
the advanced keyless function)
(With the advanced keyless
function)
When the door-lock switch on the
liftgate is pressed under any of the
If all the doors and luggage
following conditions, a warning sound
compartment are locked using another
is activated.
key while the key is left in the cabin,
the beep which sounds outside of the
The ignition is switched to a position
vehicle will be heard for about 10
other than OFF.
seconds to notify the driver that the
Any door is open.
key is in the cabin. In this case, take
Liftgate is automatically operating.*
out the key by opening the door. A key
Make sure that none of the above
taken out of the vehicle using this
conditions are present, and then press
method may not operate because its
the door-lock switch again.
functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure
(page 3-8).
*Some models.
7-39
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Power Liftgate Warning Beep*
Electric Parking Brake (EPB)
Warning Beep
If system operation precautions are
necessary, the driver is notified by the
The warning buzzer is activated under
warning sound.
the following conditions:
Warning beep
What to check
The vehicle is driven with the parking
brake applied.
The conditions re-
The Electric Parking Brake (EPB)
quired for the power
switch is pulled while the vehicle is
The beep sounds 3
liftgate to operate have
driven.
times
not been met, such as
You attempt to start driving the
an object being stuck
vehicle while the conditions for
in the liftgate.
releasing the Electric Parking Brake
The vehicle is being
(EPB) automatically have not been
The beep sound con-
driven with the liftgate
met.
tinues
open. Stop the vehicle
and close the liftgate.
AUTOHOLD Warning Beep
Warning light flashes/message is
Low Fuel Warning Beep
displayed and beep sound is activated
When the low fuel warning light
simultaneously for about 5 seconds
flashes, a warning beep is activated
when using AUTOHOLD function or
once at the same time.
when AUTOHOLD switch is operated.
Because a problem with AUTOHOLD
Brake Override Warning Beep
function has occurred, AUTOHOLD
A warning beep is activated when the
function does not operate even if
accelerator pedal and brake pedal are
AUTOHOLD switch is operated.
depressed at the same time while
driving. Only depress the brake pedal.
If the warning light flashes/message is
displayed and the beep sound is
Shift Position Warning Beep
activated simultaneously, have your
vehicle inspected at an Authorized
A sound is activated when the push
Mazda Dealer.
button start is pressed while the
selector lever is in a position other
Vehicle Problem Warning Beep
than P, and the ignition is switched to
ACC. Check the selector lever
If any of the following problems occur,
position.
a warning beep is activated. Check the
information regarding the warning
indication in the instrument cluster or
on the center display.
Automatic transmission problem
Increase in automatic transmission
internal temperature
Brake fluid amount decrease
Engine oil level sensor problem
Electric Parking Brake (EPB) problem
Engine hydraulic pressure decrease
7-40
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Engine coolant temperature increase
Check based on the beep sound.
Engine system problem
Warning beep type
Notification content
Blind Spot Monitoring (BSM)
The vehicle speed is
System Warning Beep*
slower than 25 km/h
The beep sounds 1
(16 mph) and the
The Blind Spot Monitoring (BSM)
time while the Mazda
Mazda Radar Cruise
warning beep operates when the turn
Radar Cruise Control
Control (MRCC) sys-
signal lever is operated to the side
(MRCC) is operating
tem has been can-
where the Blind Spot Monitoring
celed.
(BSM) warning light is illuminated.
The distance between
Front Cross Traffic Alert (FCTA)
The beep sounds in-
your vehicle and the
Warning Beep*
termittently while the
vehicle ahead is too
Mazda Radar Cruse
close. Check the safety
The Front Cross Traffic Alert (FCTA)
Control (MRCC) is op-
of the surrounding
warning beep is activated if there is a
erating.
area and reduce vehi-
possibility of collision with a vehicle
cle speed.
approaching from the front on the left
and right sides of the vehicle.
Mazda Radar Cruise Control with
Rear Cross Traffic Alert (RCTA)
Stop & Go function (MRCC with
Warning Beep*
Stop & Go function) System
Warnings
The Rear Cross Traffic Alert (RCTA)
warning beep is activated if there is a
The Mazda Radar Cruise Control with
possibility of collision with a vehicle
Stop & Go function (MRCC with Stop
approaching from the rear on the left
& Go function) system warnings notify
and right sides of the vehicle.
the driver of system malfunctions and
cautions on use when required.
Lane Departure Warning Sound*
Check based on the beep sound.
While the system is operating, if the
Warning beep type
Notification content
system determines that the vehicle may
If a malfunction occurs
depart from the lane, it sounds a
The beep sounds 1
in the system, make
warning sound.
time while the Mazda
sure that the Mazda
Radar Cruise Control
NOTE
Radar Cruise Control
with Stop & Go func-
The volume of the Lane Departure
with Stop & Go func-
tion (MRCC with Stop
Warning System (LDWS) warning
tion (MRCC with Stop
& Go function) is op-
sound can be changed.
& Go function) has
erating
Refer to the Settings section in the
been canceled.
Mazda Connect Owner's Manual.
The beep sounds in-
The distance between
Mazda Radar Cruise Control
termittently while the
your vehicle and the
(MRCC) System Warnings*
Mazda Radar Cruise
vehicle ahead is too
Control with Stop &
close. Check the safety
The Mazda Radar Cruise Control
Go function (MRCC
of the surrounding
(MRCC) system warnings notify the
with Stop & Go func-
area and reduce vehi-
driver of system malfunctions and
tion) is operating.
cle speed.
cautions on use when required.
*Some models.
7-41
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09















Content      ..     14      15      16      17     ..
