Mazda 6 (2021 year). Manual in english - page 6





When Driving
Instrument Cluster and Display
Lane-keep Assist System (LAS) &
Mazda Radar Cruise Control with
Lane Departure Warning System
Stop & Go function (MRCC with
(LDWS) Display
Stop & Go function) Display*
Displays the system status.
Displays the currently set system status.
Refer to Lane-keep Assist System (LAS)
Refer to Mazda Radar Cruise Control with
& Lane Departure Warning System
Stop & Go function (MRCC with Stop &
(LDWS) on page 4-164.
Go function) on page 4-150.
Traffic Sign Recognition System
Distance Recognition Support
(TSR) Display*
System (DRSS) Display*
Displays the traffic sign.
Displays the distance between your
vehicle and the vehicle ahead.
Refer to Traffic Sign Display Indication on
page 4-136.
Refer to Distance Recognition Support
System (DRSS) on page 4-140.
4-24
*Some models.
When Driving
Instrument Cluster and Display
Cruise Control Set Vehicle Speed
Message Display
Display*
A message such as the system operation
The vehicle speed preset using the cruise
status, a malfunction, or an abnormality is
control is displayed.
indicated.
Warning/indicator light in instrument
cluster turns on/flashes or symbol is
indicated on display at same time as
message
Check the information regarding the
warning/indicator light or indicated
symbol.
Refer to If a Warning Indication/Warning
Refer to Cruise Control on page 4-227.
Lights on page 4-26.
Refer to If a Indication/Indicator Lights on
Compass Display
page 4-29.
The direction the vehicle is moving is
Message only is indicated on display
displayed in one of eight directions while
the vehicle is being driven.
Follow the instructions indicated on the
display. For the display content, refer to
the next page.
Refer to If a Message Indicated on
Multi-information Display on page 7-41.
Display
Direction
N
North
S
South
E
East
W
West
NE
Northeast
NW
Northwest
SE
Southeast
SW
Southwest
*Some models.
4-25
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Instrument Cluster
Front Center of Headliner
Warning lights will appear in any of the highlighted areas
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Warning
Page
Brake System Warning Indication/Warning Light*1*2
7-25
Electronic Brake
Force Distribu-
tion System
ABS Warning Light*1
Warning
7-25
ABS warning
7-28
Charging System Warning Indication/Warning Light*1
7-25
Engine Oil Warning Light*1
7-25
High Engine Coolant Temperature Warning Indication
7-25
Power Steering Malfunction Indication
7-25
4-26
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Master Warning Indication
7-28
Electric Parking Brake (EPB) Warning Indication/Warning Light*1
7-28
Check Engine Light*1
7-28
*Selective Catalytic Reduction (SCR) system Warning Indication/Warning
7-28
Light*1
Automatic Transaxle Warning Indication
7-28
*AWD Warning Indication
7-28
Air Bag/Front Seat Belt Pretensioner System Warning Light*1
7-28
Flashing
7-28
Tire Pressure Monitoring System Warning Light*1
Turns on
7-35
Amber
7-28
KEY Warning Indication
White
(Amber/White)
7-35
High Beam Control System (HBC) Warning Indication/Warning Light*1
7-28
(Amber)
Blind Spot Monitoring (BSM) Warning Indication
7-28
Driver Attention Alert (DAA) Warning Indication
7-28
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
7-28
& Go function) Warning Indication
(Amber)
Lane-keep Assist System (LAS) & Lane Departure Warning System
7-28
(LDWS) Warning Indication
(Amber)
LED Headlight Warning Light*1
7-28
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) Warning In-
7-35
dication
*Some models.
4-27
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Low Fuel Warning Indication/Warning Light
7-35
Check Fuel Cap Warning Indication/Warning Light*1
7-35
Engine Oil Level Warning Light*1
7-35
Seat Belt Warning Light (Front seat)
7-35
Seat Belt Warning Light (Rear seat)
7-35
(Red)
Low Washer Fluid Level Warning Indication
7-35
Door-Ajar Warning Indication
7-35
Trunk lid-Ajar Warning Indication
7-35
Door-Ajar Warning Light
7-35
*1
The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2
The light turns on continuously when the parking brake is applied.
4-28
When Driving
Instrument Cluster and Display
Indication/Indicator Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Indicator
Page
Seat Belt Indicator Light (Rear seat)
2-27
(Green)
Front Passenger Air Bag Deactivation Indicator Light*1
2-68
Security Indicator Light*1
3-41
Wrench Indication
4-32
*Glow Indicator Light*1
4-32
*Diesel Particulate Filter Indication
4-236
Shift Position Indication
4-69
Lights-On Indication/Indicator Light
4-78
Headlight
High-Low Beam
4-82
Headlight High-Beam Indicator Light
Flashing the
Headlights
4-82
Turn and
Lane-Change
Signals
Turn Signal/Hazard Warning Indicator Lights
4-84
Hazard Warning
Flasher
4-91
AUTOHOLD Active Indicator Light*1
4-107
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-160
& Go function) indicator Light
*Some models.
4-29
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
Traction Control
System (TCS)
4-112
Dynamic Stabil-
TCS/DSC Indicator Light*1
ity Control
(DSC)
4-113
Turns on
7-28
DSC OFF Indicator Light*1
4-114
*Select Mode Indication
4-116
High Beam Control System (HBC) Indicator Light
4-124
(Green)
Malfunction
7-28
Blind Spot Monitoring (BSM) OFF Indicator Light*1
Except malfunc-
tion
4-131
Driver Attention Alert (DAA) Indication
4-145
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-155
& Go function) Main Indication
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-155
& Go function) Set Indication
(Green)
Lane-keep Assist System (LAS) & Lane Departure Warning System
4-167
(LDWS) Indication
Lane-keep Assist System (LAS) & Lane Departure Warning System
4-172
(LDWS) OFF Indicator Light*1
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
4-177
*Smart City Brake Support (SCBS) Indication
Smart City
Brake Support
[Reverse]
(SCBS R)
4-185
4-30
*Some models.
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
4-177
Smart City
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Indica-
Brake Support
tor Light*1
[Reverse]
(SCBS R)
4-185
Smart Brake
Support (SBS)
System
4-187
*Cruise Main Indication
4-228
(White)
*Cruise Set Indication
4-228
(Green)
*1
The light turns on when the ignition is switched on for an operation check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda Dealer.
*Some models.
4-31
When Driving
Instrument Cluster and Display
Wrench Indication
Glow Indicator Light
(SKYACTIV-D 2.2)
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to the Information section in the
Mazda Connect Owner's Manual.
When the ignition is switched ON, the
When the engine oil replacement period
glow indicator light turns on. The glow
has arrived.
indicator light turns off when preheating is
(SKYACTIV-D 2.2)
finished.
When the engine oil is deteriorated or
The maintenance period for the glow plug
exceeds the specified amount.
or a problem in the system may be
When fuel filter (sedimentor) draining
indicated under the following conditions.
is required. Consult an Authorized
Have your vehicle inspected by an
Mazda Dealer.
Authorized Mazda Dealer.
NOTE
The glow indicator light does not turn
on when the ignition is switched ON or
The wrench indication may display
it remains on.
earlier than the preset period depending
The glow indicator light is flashing.
on vehicle usage conditions.
Whenever the engine oil is replaced, a
NOTE
reset of the vehicle engine control unit is
If the vehicle is left with the ignition
necessary.
switched ON without starting the engine
Refer to the Information section in the
and a long period of time has elapsed
Mazda Connect Owner's Manual.
since preheating finished, the preheating
may be performed again and the glow
indicator light may turn on.
4-32
When Driving
Instrument Cluster and Display
Instrument Cluster (Type B)
Speedometer
page 4-33
Tachometer
page 4-33
Multi-information Display (Type B)
page 4-34
Dashboard Illumination
page 4-38
Speedometer
NOTE
When the tachometer needle enters the
The speedometer indicates the speed of the
STRIPED ZONE, this indicates to the
vehicle.
driver that the gears should be shifted
before entering the RED ZONE.
Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.
*1
STRIPED
ZONE
*1
RED ZONE
*1 The range varies depending on the type
of gauge.
4-33
When Driving
Instrument Cluster and Display
Multi-information Display (Type B)
Multi-information Display (Type B)
INFO switch
The multi-information display indicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor (Except SKYACTIV-D 2.2)
Remaining Diesel Exhaust Fluid (DEF) and Maximum Driving Distance Display
(SKYACTIV-D 2.2)
Blind Spot Monitoring (BSM) Display
Traffic Sign Recognition System (TSR) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display
Cruise Control Display
Compass Display
Message Display
4-34
When Driving
Instrument Cluster and Display
The screen content changes each time the INFO switch is pressed.
Press the INFO switch
*3
Current Fuel Economy,
Trip Meter A, Average
Warning message,
Fuel Economy, Outside
Outside Temperature,
Temperature,
Odometer, Fuel Gauge
Odometer, Fuel Gauge
Press the INFO switch
Press the INFO switch
Current Fuel Economy,
Engine Coolant
Trip Meter B, Average
Temperature Gauge,
Fuel Economy, Outside
Compass,
Temperature,
Distance-to-empty,
Odometer, Fuel Gauge
Outside Temperature,
Odometer, Fuel Gauge
Press the INFO switch
Press the INFO switch
*1
Engine Coolant
Temperature Gauge,
i-ACTIVSENSE display,
Maintenance Monitor,
Outside Temperature,
Outside Temperature,
Odometer, Fuel Gauge
Odometer, Fuel Gauge
*2
Press the INFO switch
Engine Coolant
Temperature Gauge,
Remaining Diesel
Exhaust Fluid (DEF),
Maximum Driving
Distance Display,
*1: Except SKYACTIV-D 2.2
Outside Temperature,
*2: SKYACTIV-D 2.2
*3: Displayed only when a warning occurs.
Odometer, Fuel Gauge
4-35
When Driving
Instrument Cluster and Display
Odometer, Trip Meter and Trip
Trip meter
Meter Selector
The driving distance for a specified
The odometer is constantly displayed on
interval is indicated. Two types (TRIP A,
the screen when the ignition is switched
TRIP B) of interval distance and the
ON, and the TRIP A or TRIP B screen can
average fuel economy for each can be
be displayed by operating the INFO
measured.
switch.
For instance, trip meter A can record the
INFO switch
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
Odometer,
The trip meter and average fuel economy
Trip meter A
can be reset by pressing the INFO switch
for 1.5 seconds or more while in each
mode.
Press the INFO switch
NOTE
Only the trip meters record tenths of
Odometer,
kilometers (miles).
Trip meter B
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
Odometer
disconnected).
The odometer records the total distance
The vehicle is driven over 9999.9 km
the vehicle has been driven.
(mile).
4-36
When Driving
Instrument Cluster and Display
Engine Coolant Temperature Gauge
Fuel Gauge
Displays the engine coolant temperature.
The fuel gauge shows approximately how
The blue range of the gauge indicates that
much fuel is remaining in the tank when
the engine coolant temperature is low, and
the ignition is switched ON. We
the red range of the gauge indicates that
recommend keeping the tank over 1/4 full.
the engine coolant temperature is high and
overheating.
Full
CAUTION
1/4 Full
If the high engine coolant temperature
warning light (red) flashes, there is a
possibility of overheating. Drive slowly to
reduce engine load until you can find a safe
place to stop the vehicle and wait for the
engine to cool down.
Empty
Refer to Overheating on page 7-20.
NOTE
(SKYACTIV-G 2.5T, SKYACTIV-D 2.2)
If the fuel level is low, (
) and ( ) turn an
If the engine coolant temperature is high
amber color. Refuel as soon as possible.
or the engine is hot, the engine output
If inconsistency in engine performance or
may be limited.
stalling occurs due to low fuel level
The temperature unit (Centigrade/
conditions, refuel the vehicle as soon as
Fahrenheit) of the engine coolant gauge
possible and add at least 10 L (2.7 US gal,
display changes in conjunction with the
2.2 Imp gal) of fuel.
temperature unit of the outside
Refer to Taking Action on page 7-35.
temperature display.
NOTE
Refer to the Settings section in the
After refueling, it may require some time
Mazda Connect Owner's Manual.
for the indicator to stabilize. In addition,
the indicator may deviate while driving
on a slope or curve since the fuel moves
in the tank.
4-37
When Driving
Instrument Cluster and Display
The direction of the arrow (
) indicates
The brightness decreases by rotating the
that the fuel-filler lid is on the left side
knob to the left. A beep sound will be
of the vehicle.
heard when the knob has been rotated to
the maximum dim position.
Dashboard Illumination
The brightness increases by rotating the
When the lights are turned on with the
knob to the right.
ignition switched ON, the brightness of
Dim
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
Bright
not dim.
NOTE
When the ignition is switched ON in the
Function for canceling illumination
early evening or at dusk, the dashboard
dimmer
illumination is dimmed for several
seconds until the light sensor detects the
The illumination dimmer can be canceled
by rotating the dashboard illumination
brightness of the surrounding area,
however, the dimming may cancel after
knob to the right until a beep sound is
the brightness is detected.
heard while the instrument cluster is
When the lights are turned on, the
dimmed with the ignition switched ON. If
lights-on indicator light in the
the instrument cluster's visibility is
instrument cluster turns on.
reduced due to glare from surrounding
Refer to Headlights on page 4-78.
brightness, cancel the illumination
dimmer.
The brightness of the instrument cluster
and dashboard illuminations can be
NOTE
adjusted by rotating the knob.
The illumination dimmer can be
canceled by pressing the dashboard
illumination knob.
When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
4-38
When Driving
Instrument Cluster and Display
Outside Temperature Display
Distance-to-empty
When the ignition is switched ON, the
This displays the approximate distance
outside temperature is displayed.
you can travel on the remaining fuel based
on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.
NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
NOTE
depending on the surroundings and
Even though the distance-to-empty
vehicle conditions:
display may indicate a sufficient amount
Significantly cold or hot temperatures.
of remaining driving distance before
Sudden changes in outside
refueling is required, refuel as soon as
temperature.
possible if the fuel level is very low or
The vehicle is parked.
the low fuel warning light illuminates.
The vehicle is driven at low speeds.
The display will not change unless you
add more than approximately 9 L (2.3
Changing the Temperature Unit of the
US gal, 1.9 Imp gal) of fuel.
Outside Temperature Display
The distance-to-empty is the
The outside temperature unit can be
approximate remaining distance the
switched between Celsius and Fahrenheit.
vehicle can be driven until all the
Settings can be changed by operating the
graduation marks in the fuel gauge
center display screen.
indicating the remaining fuel supply
Refer to the Settings section in the Mazda
disappear.
Connect Owner's Manual.
If there is no past fuel economy
NOTE
information such as after first
purchasing your vehicle or the
When the temperature unit indicated in the
outside temperature display is changed,
information is deleted when the battery
the temperature unit indicated in the
cables are disconnected, the actual
engine coolant gauge display changes in
distance-to empty/range may differ from
the amount indicated.
conjunction with it.
4-39
When Driving
Instrument Cluster and Display
Average Fuel Economy
Current Fuel Economy
The average fuel economy is calculated
This displays the current fuel economy by
every minute from the total traveled
calculating the amount of fuel
distance on the trip meter and the total fuel
consumption and the distance traveled.
consumption, and the average fuel
economy for either TRIP A or TRIP B is
displayed.
NOTE
Indicates the 0 position when the vehicle
speed is about 5 km/h (3 mph) or slower.
Maintenance Monitor (Except
SKYACTIV-D 2.2)
The average fuel economy and trip meters
The following maintenance period
can be reset by pressing the INFO switch
for 1.5 seconds or more while in each
notifications can be displayed by turning
the Maintenance Monitor on.
mode. After the data is cleared, the fuel
consumption is recalculated and the - - -
Scheduled Maintenance
km/L (- - - mpg) for the 1 minute prior to
Tire Rotation
it being displayed is indicated.
Oil Change
When the remaining days to the
maintenance period is 15 days or less, or
the remaining distance is 1,000 km (600
miles) or shorter, a message is indicated
when the ignition is switched ON.
For the setting method and indications for
the maintenance monitor, refer to the
Maintenance Monitor.
Refer to the Information section in the
Mazda Connect Owner's Manual.
4-40
When Driving
Instrument Cluster and Display
Remaining Diesel Exhaust Fluid
Blind Spot Monitoring (BSM)
(DEF) and Maximum Driving
Display
Distance Display (SKYACTIV-D
Displays the system status.
2.2)
The remaining amount of DEF and the
remaining-distance-to-empty indications
are displayed when the ignition is
switched ON.
Refer to Blind Spot Monitoring (BSM) on
page 4-126.
Lane-keep Assist System (LAS) &
Lane Departure Warning System
If the remaining amount of DEF is low or
(LDWS) Display*
there is a problem with the Selective
Catalytic Reduction (SCR) system and
Displays the system status.
there is less maximum remaining driving
distance, the remaining-distance-to-empty
indication is continuously displayed.
If the remaining amount of DEF is low or
Refer to Lane-keep Assist System (LAS)
there is a problem with the SCR system,
& Lane Departure Warning System
the SCR warning light turns on/flashes and
(LDWS) on page 4-164.
a warning message is displayed.
Refer to Selective Catalytic Reduction
Traffic Sign Recognition System
(SCR) System Indications on page 4-237.
(TSR) Display*
Displays the traffic sign.
Refer to Traffic Sign Display Indication on
page 4-136.
*Some models.
4-41
When Driving
Instrument Cluster and Display
Mazda Radar Cruise Control with
Cruise Control Set Vehicle Speed
Stop & Go function (MRCC with
Display*
Stop & Go function) Display*
The vehicle speed preset using the cruise
Displays the currently set system status.
control is displayed.
Refer to Cruise Control on page 4-227.
Compass Display
The direction the vehicle is moving is
Refer to Mazda Radar Cruise Control with
displayed in one of eight directions while
Stop & Go function (MRCC with Stop &
the vehicle is being driven.
Go function) on page 4-150.
Distance Recognition Support
System (DRSS) Display*
Displays the distance between your
Display
Direction
vehicle and the vehicle ahead.
N
North
S
South
E
East
W
West
NE
Northeast
NW
Northwest
SE
Southeast
SW
Southwest
Refer to Distance Recognition Support
System (DRSS) on page 4-140.
4-42
*Some models.
When Driving
Instrument Cluster and Display
Message Display
A message such as the system operation
status, a malfunction, or an abnormality is
indicated.
Warning/indicator light in instrument
cluster turns on/flashes or symbol is
indicated on display at same time as
message
Check the information regarding the
warning/indicator light or indicated
symbol.
Refer to If a Warning Indication/Warning
Lights on page 4-44.
Refer to If a Indication/Indicator Lights on
page 4-46.
Message only is indicated on display
Follow the instructions indicated on the
display. For the display content, refer to
the next page.
Refer to If a Message Indicated on
Multi-information Display on page 7-41.
4-43
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Instrument Cluster
Front Center of Headliner
Warning lights will appear in any of the highlighted areas
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Warning
Page
Brake System Warning Indication/Warning Light*1*2
7-25
Electronic Brake
Force Distribu-
tion System
ABS Warning Light*1
Warning
7-25
ABS warning
7-28
Charging System Warning Indication/Warning Light*1
7-25
Engine Oil Warning Light*1
7-25
High Engine Coolant Temperature Warning Light*1
7-25
(Red)
4-44
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Power Steering Malfunction Indication
7-25
Master Warning Indication
7-28
Electric Parking Brake (EPB) Warning Indication/Warning Light*1
7-28
Check Engine Light*1
7-28
*Selective Catalytic Reduction (SCR) system Warning Indication/Warning
7-28
Light*1
Automatic Transaxle Warning Indication
7-28
*AWD Warning Indication
7-28
Air Bag/Front Seat Belt Pretensioner System Warning Light*1
7-28
Flashing
7-28
Tire Pressure Monitoring System Warning Light*1
Turns on
7-35
Amber
7-28
KEY Warning Indication
White
(Amber/White)
7-35
*High Beam Control System (HBC) Warning Indication/Warning Light*1
7-28
(Amber)
Blind Spot Monitoring (BSM) Warning Indication
7-28
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
7-28
& Go function) Warning Indication
(Amber)
*Lane-keep Assist System (LAS) & Lane Departure Warning System
7-28
(LDWS) Warning Indication
LED Headlight Warning Light*1
7-28
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) Warning In-
7-35
dication
(Amber)
Low Fuel Warning Indication
7-35
*Some models.
4-45
When Driving
Instrument Cluster and Display
Signal
Warning
Page
Check Fuel Cap Warning Indication/Warning Light*1
7-35
Engine Oil Level Warning Light*1
7-35
Seat Belt Warning Light (Front seat)
7-35
Seat Belt Warning Light (Rear seat)
7-35
(Red)
*Low Washer Fluid Level Warning Indication
7-35
Door-Ajar Warning Indication
7-35
Trunk lid-Ajar Warning Indication
7-35
*1
The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2
The light turns on continuously when the parking brake is applied.
Indication/Indicator Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal
Indicator
Page
Seat Belt Indicator Light (Rear seat)
2-68
(Green)
*Front Passenger Air Bag Deactivation Indicator Light*1
2-68
Security Indicator Light*1
3-41
Wrench Indication
4-50
Low Engine Coolant Temperature Indicator Light
4-50
(Blue)
4-46
*Some models.
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
*Glow Indicator Light*1
4-50
*Diesel Particulate Filter Indication
4-236
Shift Position Indication
4-69
Lights-On Indication/Indicator Light
4-78
Headlight
High-Low Beam
4-82
Headlight High-Beam Indicator Light
Flashing the
Headlights
4-82
Turn and
Lane-Change
Signals
Turn Signal/Hazard Warning Indicator Lights
4-84
Hazard Warning
Flasher
4-91
AUTOHOLD Active Indicator Light*1
4-107
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-160
& Go function) indicator Light
Traction Control
System (TCS)
4-112
Dynamic Stabil-
TCS/DSC Indicator Light*1
ity Control
(DSC)
4-113
Turns on
7-28
DSC OFF Indicator Light*1
4-114
*Select Mode Indication
4-116
*High Beam Control System (HBC) Indicator Light
4-124
(Green)
*Some models.
4-47
When Driving
Instrument Cluster and Display
Signal
Indicator
Page
Malfunction
7-28
Blind Spot Monitoring (BSM) OFF Indicator Light*1
Except malfunc-
tion
4-131
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-155
& Go function) Main Indication
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
4-155
& Go function) Set Indication
(Green)
*Lane-keep Assist System (LAS) & Lane Departure Warning System
4-167
(LDWS) Indication
*Lane-keep Assist System (LAS) & Lane Departure Warning System
4-172
(LDWS) OFF Indicator Light*1
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
*Smart City Brake Support (SCBS) Indication
4-177
Smart City
Brake Support
(SCBS)
4-180
Advanced Smart
City Brake Sup-
port (Advanced
SCBS)
4-177
Smart City
*Smart Brake Support/Smart City Brake Support (SBS/SCBS) OFF Indica-
Brake Support
tor Light*1
(SCBS)
4-181
Smart Brake
Support (SBS)
System
4-187
*Cruise Main Indication
4-228
(White)
*Cruise Set Indication
4-228
(Green)
4-48
*Some models.
When Driving
Instrument Cluster and Display
*
1
The light turns on when the ignition is switched on for an operation check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda Dealer.
4-49
When Driving
Instrument Cluster and Display
Wrench Indication
Glow Indicator Light
(SKYACTIV-D 2.2)
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to the Information section in the
Mazda Connect Owner's Manual.
When the ignition is switched ON, the
When the engine oil replacement period
glow indicator light turns on. The glow
has arrived.
indicator light turns off when preheating is
(SKYACTIV-D 2.2)
finished.
When the engine oil is deteriorated or
The maintenance period for the glow plug
exceeds the specified amount.
or a problem in the system may be
When fuel filter (sedimentor) draining
indicated under the following conditions.
is required. Consult an Authorized
Have your vehicle inspected by an
Mazda Dealer.
Authorized Mazda Dealer.
NOTE
The glow indicator light does not turn
on when the ignition is switched ON or
The wrench indication may display
it remains on.
earlier than the preset period depending
The glow indicator light is flashing.
on vehicle usage conditions.
Whenever the engine oil is replaced, a
NOTE
reset of the vehicle engine control unit is
If the vehicle is left with the ignition
necessary.
switched ON without starting the engine
Refer to the Information section in the
and a long period of time has elapsed
Mazda Connect Owner's Manual.
since preheating finished, the preheating
may be performed again and the glow
indicator light may turn on.
Low Engine Coolant Temperature
Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
4-50
When Driving
Instrument Cluster and Display
Instrument Cluster (Type C)
Speedometer
page 4-51
Tachometer
page 4-51
Multi-information Display (Type C)
page 4-52
Dashboard Illumination
page 4-55
Speedometer
NOTE
When the tachometer needle enters the
The speedometer indicates the speed of the
STRIPED ZONE, this indicates to the
vehicle.
driver that the gears should be shifted
before entering the RED ZONE.
Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.
*1
STRIPED
ZONE
*1
RED ZONE
*1 The range varies depending on the type
of gauge.
4-51
When Driving
Instrument Cluster and Display
Multi-information Display (Type C)
Multi-information Display (Type C)
INFO switch
The multi-information display indicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Trip Computer
Cruise Control Display
Compass Display
4-52
When Driving
Instrument Cluster and Display
Odometer, Trip Meter and Trip
For instance, trip meter A can record the
Meter Selector
distance from the point of origin, and trip
meter B can record the distance from
The display mode can be changed from
where the fuel tank is filled.
odometer to trip meter A to trip meter B
and then back to odometer by pressing the
When trip meter A is selected, pressing the
selector while one of them is displayed.
selector again within 1 second will change
The selected mode will be displayed.
to trip meter B mode.
Dashboard illumination knob
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
The trip meter records the total distance
the vehicle is driven until the meter is
again reset. Return it to “0.0” by
depressing and holding the selector for 1
Odometer
second or more. Use this meter to measure
trip distances and to compute fuel
Press the dashboard
consumption.
illumination knob
Trip meter A
NOTE
Press the dashboard
If TRIP A is reset using the trip meter
illumination knob
when the function which synchronizes
(resets) the fuel economy monitor and
Trip meter B
the trip meter (TRIP A) is on, the fuel
Press the dashboard
economy data resets in conjunction with
illumination knob
TRIP A.
Refer to the Information section in the
Odometer
Mazda Connect Owner's Manual.
Only the trip meters record tenths of
The odometer records the total distance
kilometers (miles).
the vehicle has been driven.
The trip record will be erased when:
Trip meter
The power supply is interrupted
The trip meter can record the total distance
(blown fuse or the battery is
of two trips. One is recorded in trip meter
disconnected).
A, and the other is recorded in trip meter
The vehicle is driven over 9999.9 km
B.
(mile).
4-53
When Driving
Instrument Cluster and Display
Engine Coolant Temperature Gauge
Fuel Gauge
Displays the engine coolant temperature.
The fuel gauge shows approximately how
The white range of the gauge indicates
much fuel is remaining in the tank when
that the engine coolant temperature is low,
the ignition is switched ON. We
and the red range of the gauge indicates
recommend keeping the tank over 1/4 full.
that the engine coolant temperature is high
and overheating.
Full
1/4 Full
CAUTION
If the engine coolant temperature gauge
needle (white) flashes, there is a possibility
of overheating. Drive slowly to reduce
Empty
engine load until you can find a safe place
to stop the vehicle and wait for the engine
to cool down.
Refer to Overheating on page 7-20.
NOTE
If the low fuel warning light illuminates or
(SKYACTIV-G 2.5T)
the fuel level is very low, refuel as soon as
possible.
If the engine coolant temperature is high
If inconsistency in engine performance or
or the engine is hot, the engine output
stalling occurs due to low fuel level
may be limited.
conditions, refuel the vehicle as soon as
The temperature unit (Centigrade/
possible and add at least 10 L (2.7 US gal,
Fahrenheit) of the engine coolant gauge
2.2 Imp gal) of fuel.
display changes in conjunction with the
Refer to Taking Action on page 7-35.
temperature unit of the outside
temperature display.
NOTE
Refer to the Settings section in the
After refueling, it may require some time
Mazda Connect Owner's Manual.
for the indicator to stabilize. In addition,
the indicator may deviate while driving
on a slope or curve since the fuel moves
in the tank.
4-54















Content      ..     4      5      6      7     ..
