6-3. Do-it-yourself maintenance
between it and the key.
rag.
3 Remove the depleted battery
6 Operate the
or
switch
using a small flathead screw-
and check that the doors can be
driver.
locked/unlocked.
When removing the cover, the elec-
X Vehicles with a smart entry &
tronic key module may stick to the
start system
cover and the battery may not be visi-
ble. In this case, remove the electronic
1 Release the lock and remove
key module in order to remove the bat-
the mechanical key.
tery.
When removing the battery, use a
screwdriver of an appropriate size.
Insert a new battery with the “+” termi-
nal facing up.
2 Remove the key cover.
Use a screwdriver of an appropriate
size. Forcedly prying may cause the
cover damaged.
4 When installing the key cover
To prevent damage to the key, cover
the tip of the flathead screwdriver with a
and mechanical key, install by
conducting step 2 and step 1
with the directions reversed.
5 Operate the
or
switch
and check that the doors can be
locked/unlocked.
6-3. Do-it-yourself maintenance
353
WARNING
Checking and replacing
fuses
QRemoved battery and other parts
These parts are small and if swal-
lowed by a child, they can cause
If any of the electrical compo-
choking. Keep away from children.
nents do not operate, a fuse
Failure to do so could result in death
or serious injury.
may have blown. If this hap-
pens, check and replace the
Q Lithium battery precautions
fuses as necessary.
CAUTION
RISK OF EXPLOSION IF BATTERY
IS REPLACED BY AN INCORRECT
TYPE.
Checking and replacing
DISPOSE OF USED BATTERIES
fuses
ACCORDING TO THE INSTRUC-
TIONS
1 Turn the power switch off.
2 Open the fuse box cover.
NOTICE
X Engine compartment: type A
Q When replacing the battery
fuse box
Use a flathead screwdriver of appro-
priate size. Applying excessive force
Push the tabs in and lift
the lid off.
may deform or damage the cover.
Q For normal operation after
replacing the battery
Observe the following precautions to
6
prevent accidents:
O Always work with dry hands.
Moisture may cause the battery to
rust.
O Do not touch or move any other
component inside the remote con-
X Engine compartment: type B
trol.
fuse box
O Do not bend either of the battery
terminals.
Push the tabs in and lift the lid off.
Q When removing the battery cover
(vehicles without a smart entry &
start system)
Do not forcibly remove the battery
cover, otherwise it may be damaged.
If the battery cover is difficult to
remove, lift the edge to remove it.
354
6-3. Do-it-yourself maintenance
X Under the driver’s side instru-
X Under the right-hand rear seat
ment panel (left-hand drive vehi-
Remove the 12-volt battery cover.
cles)
(→P.329)
Remove the lid.
Make sure to push the claw when
removing/installing the lid.
3 Remove the fuse with the pull-
out tool.
Only type A fuse can be
X Under the passenger’s side
removed using the pullout tool.
instrument panel (right-hand
drive vehicles)
Remove the cover, connector (if
equipped) and then remove the lid.
Make sure to push the claw when
removing/installing the lid.
4 Check if the fuse is blown.
Replace the blown fuse with a new fuse
of an appropriate amperage rating. The
amperage rating can be found on
the
fuse box lid.
X Type A
6-3. Do-it-yourself maintenance
355
Normal fuse
Blown fuse
Blown fuse
QAfter a fuse is replaced
X Type B
O When installing the lid, make sure that
the tab is installed securely.
OIf the lights do not turn on even after
the fuse has been replaced, a bulb
may need replacement. (→P.357)
OIf the replaced fuse blows again, have
the vehicle inspected by any autho-
rized Mazda retailer or Mazda autho-
rized repairer, or any reliable repairer.
QIf there is an overload in a circuit
The fuses are designed to blow, protect-
Normal fuse
ing the wiring harness from damage.
Q When replacing light bulbs
Blown fuse
Mazda recommends that you use genu-
X Type C
ine Mazda products designed for this
vehicle.
Because certain bulbs are connected to
circuits designed to prevent overload,
non-genuine parts of parts not designed
for this vehicle may be unusable.
WARNING
6
Q To prevent system breakdowns
and vehicle fire
Observe the following precautions.
Failure to do so may cause damage
Normal fuse
to the vehicle, and possibly a fire or
injury.
Blown fuse
O Never use a fuse of a higher
X Type D
amperage rating than that indi-
cated, or use any other object in
place of a fuse.
OAlways use a genuine Mazda fuse
or equivalent.
Never replace a fuse with a wire,
even as a temporary fix.
ODo not modify the fuses or fuse
boxes.
Normal fuse
356
6-3. Do-it-yourself maintenance
NOTICE
Light bulbs
QBefore replacing fuses
Have the cause of electrical overload
You may replace the following
determined and repaired by any
bulbs by yourself. The diffi-
authorized Mazda retailer or Mazda
culty level of replacement var-
authorized repairer, or any reliable
repairer as soon as possible.
ies depending on the bulb. As
there is a danger that compo-
Q When installing the fuse box
cover (Engine compartment: type
nents may be damaged, we
A and type B fuse boxes)
recommend that replacement
Press the fuse box cover, when
is carried out by any autho-
installing, after aligning all of the claw
rized Mazda retailer or Mazda
positions. Otherwise, the claws may
be damaged.
authorized repairer, or any reli-
able repairer.
Preparing for light bulb
replacement
Check the wattage of the light bulb
to be replaced. (→P.428)
Bulb locations
X Front
Front position lights (bulb type)
Front turn signal lights (bulb
type)
Front fog lights (bulb type)
Headlights (bulb type)
6-3. Do-it-yourself maintenance
357
X Rear
Mazda authorized repairer, or any reli-
able repairer to have the light replaced.
O Headlights (bulb type)
OFront position lights (bulb type)
OFront turn signal lights (bulb type)
OFront fog lights (bulb type)
O Rear turn signal lights (bulb type)
O License plate light
Q Condensation build-up on the
inside of the lens
Temporary condensation build-up on the
License plate light
inside of the headlight lens does not
Rear turn signal lights (bulb
indicate a malfunction. Contact any
authorized Mazda retailer or Mazda
type)
authorized repairer, or any reliable
Q Lights that need to be
repairer for more information in the fol-
lowing situations:
replaced by any authorized
O Large drops of water have built up on
Mazda retailer or Mazda autho-
the inside of the lens.
rized repairer, or any reliable
O Water has built up inside the head-
repairer
light.
z
Headlights (LED type)
Q When replacing light bulbs
z
Front fog lights (LED type)
→P.356
6
z
Front position lights (LED type)
Replacing light bulbs
z
Front turn signal lights (LED
type)
Q Headlights (bulb type)
z
Daytime running lights
1 Unplug the connector.
z
Side turn signal lights
z
Tail lights
z
Stop lights
z
Back-up light
z
Rear fog light
z
Rear turn signal lights (LED type)
z
High mounted stoplight
QLED light bulbs
The lights other than the following lights
each consist of a number of LEDs. If any
of the LEDs burn out, take your vehicle
to any authorized Mazda retailer or
358
6-3. Do-it-yourself maintenance
2 Turn the bulb base counter-
light is leaking through the mounting.
clockwise.
Q Front position lights (bulb
type)
3 Replace the light bulb.
1 Turn the bulb base counter-
4 Install the bulb base.
clockwise.
Align the 3 tabs on the light bulb with
the mounting and insert.
2 Remove light bulb.
5 Plug the connector.
3 When installing, reverse the
6 Secure the bulb base.
steps listed.
Shake the bulb base gently to check
that it is not loose, turn the headlights
on once and visually confirm that no
6-3. Do-it-yourself maintenance
359
Q Front turn signal lights (bulb
2 Remove the screws and clips.
type)
1 Turn the bulb base counter-
clockwise.
2 Remove the light bulb.
3 Partly remove the fender liner.
6
3 When installing, reverse the
steps listed.
4 Unplug the connector.
Q Front fog lights (bulb type)
1 To allow enough working space,
turn the steering wheel.
360
6-3. Do-it-yourself maintenance
5 Turn the bulb base counter-
8 Reinstall the fender liner.
clockwise.
9 Reinstall the screws
and clips.
6 Set a new light bulb.
Align the 3 tabs on the light bulb with
the mounting, and insert. Turn it clock-
wise to set.
7 Set the connector.
Q Rear turn signal lights (bulb
Shake the bulb base gently to check
type)
that it is not loose, turn the front fog
lights on once and visually confirm that
1 Open the back door.
no light is leaking through the mount-
ing.
2 Remove the 2 bolts and pull the
lamp assembly toward the rear
of the vehicle to remove it.
6-3. Do-it-yourself maintenance
361
3 Turn the bulb base counter-
installing it.
clockwise.
4 Remove the light bulb.
7 Install the 2 bolts.
5 When installing the light bulb,
6
install by conducting 3 and 4
with the directions reversed.
6 Install the lamp assembly.
Align the guides
and pins
on the
lamp assembly with the mounting when
362
6-3. Do-it-yourself maintenance
Q License plate light
2 Remove the light bulb.
1 Remove the lens.
3 Install a new light bulb.
1 Insert a
small flathead screw-
4 Install the lens.
driver,
etc., into either the right
or left hole of the lens.
2 Tilt the screwdriver in the direc-
tion of the arrow shown in the
illustration so as to release the
fitting portion, and then remove
the lens.
To prevent damage to the vehicle, wrap
the tip of the screwdriver with tape.
Lens
Fitting portion
1 Fit the lens into either the right
or left fitting portion.
6-3. Do-it-yourself maintenance
363
2 Push the lens into place.
After installation, confirm that the lens is
properly installed by gently pulling it.
Fitting portion
WARNING
QReplacing light bulbs
O Turn off the lights. Do not attempt to
replace the bulb immediately after
turning off the lights. The bulbs
become very hot and may cause
burns.
O Do not touch the glass portion of
the light bulb with bare hands.
When it is unavoidable to hold the
glass portion, use and hold with a
clean dry cloth to avoid getting
moisture and oils on the bulb. Also,
if the bulb is scratched or dropped,
it may blow out or crack.
O Fully install light bulbs and any
parts used to secure them. Failure
to do so may result in heat damage,
fire, or water entering the light unit.
This may damage the lights or
6
cause condensation to build up on
the lens.
Q To prevent damage or fire
Make sure bulbs are fully seated and
locked.
364
6-3. Do-it-yourself maintenance
365
When trouble arises
7
7-1.
Essential information
Emergency flashers
366
If your vehicle has to be
stopped in an emergency 366
If the vehicle is trapped in rising
water
367
7-2.
Steps to take in an emer-
gency
If your vehicle needs to be
towed
369
If you think something is wrong
........................................372
If a warning light turns on or a
warning buzzer sounds
374
If a warning message is dis-
played
383
If you have a flat tire (vehicles
with an emergency tire punc-
ture repair kit)
386
7
If you have a flat tire (vehicles
with a spare tire)
397
If the hybrid system will not
start
405
If you lose your keys
407
If the electronic key does not
operate properly (vehicles
with a smart entry & start sys-
tem)
407
If the 12-volt battery is dis-
charged
409
If your vehicle overheats
414
If the vehicle becomes stuck
........................................418
366
7-1. Essential information
Emergency flashers
If your vehicle has to be
stopped in an emer-
The emergency flashers are
gency
used to warn other drivers
when the vehicle has to be
Only in an emergency, such as
stopped on the road due to a
if it becomes impossible to
breakdown, etc.
stop the vehicle in the normal
way, stop the vehicle using the
following procedure:
Operating instructions
Press the switch.
Stopping the vehicle
All the turn signal lights will flash.
1 Steadily step on the brake pedal
To turn them off, press the switch once
with both feet and firmly depress
again.
it.
Do not pump the brake pedal repeat-
edly as this will increase the effort
required to slow the vehicle.
2
Shift the shift lever to N.
X If the shift lever is shifted to N
3
After slowing down, stop the
vehicle in a safe place by the
road.
QEmergency flashers
4
Stop the hybrid system.
OIf the emergency flashers are used for
X If the shift lever cannot be shifted
a long time while the hybrid system is
to N
not operating (while the “READY” indi-
cator is not illuminated), the 12-volt
3
Keep depressing the brake
battery may discharge.
pedal with both feet to reduce
OIf any of the SRS airbags deploy
vehicle speed as much as possi-
(inflate) or in the event of a strong rear
impact, the emergency flashers will
ble.
turn on automatically.
4
Perform the following proce-
The emergency flashers will turn off
automatically after operating for
dure to stop the hybrid system:
approximately 20 minutes. To manu-
X Vehicles without a smart entry &
ally turn the emergency flashers off,
press the switch twice.
start system
(The emergency flashers may not turn
Turn the power switch to ACC.
on automatically depending on the
force of the impact and conditions of
the collision.)
7-1. Essential information
367
If the vehicle is trapped
in rising water
In the event the vehicle is sub-
merged in water, remain calm
and perform the following.
z
Remove the seat belt first.
z
If the door can be opened, open
X Vehicles with a smart entry &
the door and exit the vehicle.
start system
z
If the door cannot be opened,
Press and hold the power switch for 2
open the window using the
consecutive seconds or more, or press
power window switch and exit
it briefly 3 times or more in succession.
the vehicle through the window.
z
If the window cannot be opened
using the power window switch,
remain calm, wait until the water
level inside the vehicle rises to
the point that the water pressure
inside of the vehicle equals the
water pressure outside of the
vehicle, and then open the door
5 Stop the vehicle in a safe place
and exit the vehicle.
by the road.
7
WARNING
Q If the hybrid system has to be
turned off while driving
OPower assist for the steering wheel
will be lost, making the steering
wheel heavier to turn. Decelerate
as much as possible before turning
off the hybrid system.
O Vehicles without a smart entry &
start system: Never attempt to
remove the key, as doing so will
lock the steering wheel.
368
7-1. Essential information
WARNING
Q Using an emergency hammer* for
emergency escape
The front side windows and rear side
windows, as well as the rear window
can be shattered with an emergency
hammer* used for emergency
escape.
However, an emergency hammer
cannot shatter the windshield as it is
laminated glass.
*: Contact any authorized Mazda
retailer or Mazda authorized
repairer, or any reliable repairer, or
aftermarket accessory manufac-
turer for further information about
an emergency hammer.
QEscaping the vehicle from the
window
There are cases where escaping the
vehicle from the window is not possi-
ble due to seating position, passenger
body type, etc.
When using an emergency hammer,
consider your seat location and the
size of the window opening to ensure
that the opening is accessible and
large enough to escape.
7-2. Steps to take in an emergency
369
If your vehicle needs to
QWhile towing
be towed
OWhen towing using cables or
chains, avoid sudden starts, etc.
which place excessive stress on the
If towing is necessary, we rec-
towing eyelets, cables or chains.
The towing eyelets, cables or
ommend having your vehicle
chains may become damaged, bro-
towed by any authorized
ken debris may hit people, and
Mazda retailer or Mazda autho-
cause serious damage.
rized repairer, or any reliable
ODo not turn the power switch off.
repairer or commercial towing
There is a possibility that the steer-
ing wheel is locked and cannot be
service, using a wheel-lift type
operated.
truck or flatbed truck.
QInstalling towing eyelets to the
Use a safety chain system for
vehicle
all towing, and abide by all
Make sure that towing eyelets are
state/provincial and local laws.
installed securely.
If not securely installed, towing eye-
lets may come loose during towing.
WARNING
Observe the following precautions.
Failure to do so may result in death or
NOTICE
serious injury.
Q To prevent damage to the vehicle
Q When towing the vehicle
when towing using a wheel-lift
type truck
Be sure to transport the vehicle with
the front wheels raised or with all four
ODo not tow the vehicle from the rear
wheels raised off the ground. If the
when the power switch is off. The
vehicle is towed with the front wheels
steering lock mechanism is not
contacting the ground, the drivetrain
strong enough to hold the front
7
and related parts may be damaged or
wheels straight.
electricity generated by the operation
OWhen raising the vehicle, ensure
of the motor may cause a fire to occur
adequate ground clearance for tow-
depending on the nature of the dam-
ing at the opposite end of the raised
age or malfunction.
vehicle. Without adequate clear-
ance, the vehicle could be dam-
aged while being towed.
Q To prevent damage to the vehicle
when towing with a sling-type
truck
Do not tow with a sling-type truck,
either from the front or rear.
Q To prevent damage to the vehicle
during emergency towing
Do not secure cables or chains to the
suspension components.
370
7-2. Steps to take in an emergency
X From the rear
Situations when it is neces-
sary to contact dealers
before towing
The following may indicate a prob-
lem with your transmission. Contact
any authorized Mazda retailer or
Mazda authorized repairer, or any
reliable repairer or commercial tow-
ing service before towing.
Use a towing dolly under the front
z The hybrid system warning mes-
wheels.
sage is shown on the multi-infor-
mation display and the vehicle
Towing with a sling-type
does not move.
truck
z The vehicle makes an abnormal
sound.
Do not tow with a sling-type truck to
prevent body damage.
Towing with a wheel-lift type
truck
X From the front
Using a flatbed truck
When using a flat-bed truck to
transport the vehicle, use tire strap-
Release the parking brake.
ping belts. Refer to the owner’s
Turn automatic mode off. (→P.179)
manual of the flat-bed truck for the
tire strapping method.
In order to suppress vehicle move-
ment during transportation, set the
parking brake and turn the power
switch off.
7-2. Steps to take in an emergency
371
1 Take out the wheel nut wrench,
flathead screwdriver and towing
eyelet. (→P.398)
2 Remove the eyelet cover using
a flathead screwdriver.
To protect the bodywork, place a rag
between the screwdriver and the vehi-
cle body as shown in the illustration.
Emergency towing
If a tow truck is not available in an
emergency, your vehicle may be
3
Insert the towing eyelet into the
temporarily towed using cables or
hole and tighten partially by
chains secured to the emergency
hand.
towing eyelets. This should only be
attempted on hard surfaced roads
for a short distance at under 30
km/h (18 mph).
A driver must be in the vehicle to
steer and operate the brakes.
The
7
vehicle’s wheels, drive train, axles,
steering and brakes must be in
good condition.
4
Tighten down the towing eyelet
Emergency towing proce-
securely using a wheel nut
dure
wrench*1, 2 or hard metal bar.
To have your vehicle towed by
*1: If equipped
another vehicle, the towing eyelet
*2: If your vehicles does not provide a
must be installed to your vehicle.
wheel nut wrench, you can purchase
Install the towing eyelet using the
it from any authorized Mazda retailer
following procedure.
or Mazda authorized repairer, or any
372
7-2. Steps to take in an emergency
reliable repairer.
If you think something is
wrong
If you notice any of the follow-
ing symptoms, your vehicle
probably needs adjustment or
repair. Contact any authorized
Mazda retailer or Mazda autho-
rized repairer, or any reliable
5 Securely attach cables or chains
repairer as soon as possible.
to the towing eyelet.
Take care not to damage the vehicle
Visible symptoms
body.
z Fluid leaks under the vehicle.
6 Enter the vehicle being towed
(Water dripping from the air con-
and start the hybrid system.
ditioning after use is normal.)
If the hybrid system does not start, turn
the power switch to ON.
z Flat-looking tires or uneven tire
7 Shift the shift lever to N and
wear
release the parking brake.
z Engine coolant temperature
When the shift lever cannot be
gauge needle continually points
shifted: →P.176
higher than normal.
Turn automatic mode off. (→P.179)
Audible symptoms
QWhile towing
If the hybrid system is off, the power
z Changes in exhaust sound
assist for the brakes and steering will
not function, making steering and brak-
z Excessive tire squeal when cor-
ing more difficult.
nering
QWheel nut wrench*1, 2
z Strange noises related to the
Wheel nut wrench is installed in luggage
suspension system
compartment. (→P.398)
z Pinging or other noises related to
*1: If equipped
the hybrid system
*2: If your vehicles does not provide a
wheel nut wrench, you can purchase
it from any authorized Mazda retailer
Operational symptoms
or Mazda authorized repairer, or any
reliable repairer.
z Engine missing, stumbling or
running roughly
z Appreciable loss of power
7-2. Steps to take in an emergency
373
z Vehicle pulls heavily to one side
when braking
z Vehicle pulls heavily to one side
when driving on a level road
z Loss of brake effectiveness,
spongy feeling, pedal almost
touches the floor
7
374
7-2. Steps to take in an emergency
If a warning light turns on or a warning buzzer sounds
Calmly perform the following actions if any of the warning lights
comes on or flashes. If a light comes on or flashes, but then goes
off, this does not necessarily indicate a malfunction in the system.
However, if this continues to occur, have the vehicle inspected by
any authorized Mazda retailer or Mazda authorized repairer, or any
reliable repairer.
Actions to the warning lights or warning buzzers
Q Brake system warning light (warning buzzer)
Warning light
Details/Actions
Indicates that:
z The brake fluid level is low; or
z The brake system is malfunctioning
Immediately stop the vehicle in a safe place and contact
(Red)
any authorized Mazda retailer or Mazda authorized repairer,
or any reliable repairer. Continuing to drive the vehicle may
be dangerous.
Q Brake system warning light
Warning light
Details/Actions
Indicates a malfunction in:
z The regenerative braking system;
z The electronically controlled brake system; or
z The parking brake system
(Yellow)
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
Q High coolant temperature warning light* (warning buzzer)
Warning light
Details/Actions
Indicates that the engine coolant temperature is excessively high
Immediately stop the vehicle in a safe place.
Handling method (P.414)
*: This light illuminates on the multi-information display.
7-2. Steps to take in an emergency
375
Q Hybrid system overheat warning light* (warning buzzer)
Warning light
Details/Actions
Indicates the hybrid system has overheated
Stop the vehicle in a safe place.
Handling method (P.414)
*: This light illuminates on the multi-information display.
Q Charging system warning light*
Warning light
Details/Actions
Indicates a malfunction in the vehicle’s charging system
Immediately stop the vehicle in a safe place and contact
any authorized Mazda retailer or Mazda authorized repairer,
or any reliable repairer.
*: This light illuminates on the multi-information display.
Q Low engine oil pressure warning light* (warning buzzer)
Warning light
Details/Actions
Indicates that the engine oil pressure is excessively low
Immediately stop the vehicle in a safe place and contact
any authorized Mazda retailer or Mazda authorized repairer,
or any reliable repairer.
*: This light illuminates on the multi-information display.
Q Malfunction indicator lamp (warning buzzer)
7
Warning light
Details/Actions
Indicates a malfunction in:
z The hybrid system;
z The electronic engine control system; or
z The electronic throttle control system
Immediately stop the vehicle in a safe place and contact
any authorized Mazda retailer or Mazda authorized repairer,
or any reliable repairer.
376
7-2. Steps to take in an emergency
Q SRS warning light (warning buzzer)
Warning light
Details/Actions
Indicates a malfunction in:
z The SRS airbag system; or
z The seat belt pretensioner system
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
Q ABS warning light
Warning light
Details/Actions
Indicates a malfunction in:
z The ABS; or
z The brake assist system
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
Q Brake Override System warning light/Drive-Start Control warning
light* (warning buzzer)
Warning light
Details/Actions
When a buzzer sounds:
Indicates a malfunction in:
z The Brake Override System; or
z The Drive-Start Control system
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
Indicates that the shift position was changed and Drive-Start Con-
trol was operated while depressing the accelerator pedal.
Momentarily release the accelerator pedal.
When a buzzer does not sound:
Indicates that the accelerator and brake pedals are being
depressed simultaneously, and the Brake Override System is
operating.
Release the accelerator pedal and depress the brake pedal.
*: This light illuminates on the multi-information display.
7-2. Steps to take in an emergency
377
Q Electric power steering system warning light (warning buzzer)
Warning light
Details/Actions
Indicates a malfunction in the EPS (Electric Power Steering) sys-
(Red)
tem
or
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
(Yellow)
Q Low fuel level warning light
Warning light
Details/Actions
Vehicles without rear wiper: Indicates that remaining fuel is
approximately 5.0 L (1.4 gal., 1.2 Imp. gal.) or less
Vehicles with rear wiper: Indicates that remaining fuel is approxi-
mately 5.4 L (1.5 gal., 1.2 Imp. gal.) or less
Refuel the vehicle.
Q Driver’s and front passenger’s seat belt reminder light (warning
buzzer*)
Warning light
Details/Actions
Warns the driver and/or front passenger to fasten their seat belts
Fasten the seat belt.
7
If the front passenger’s seat is occupied, the front passen-
ger’s seat belt also needs to be fastened to make the warn-
ing light (warning buzzer) turn off.
*: Driver’s and front passenger’s seat belt warning buzzer:
The driver’s and front passenger’s seat belt warning buzzer sounds to alert the
driver and front passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.
Q Rear passengers’ seat belt reminder lights*1 (warning buzzer*2)
Warning light
Details/Actions
Warns the rear passengers to fasten their seat belts
Fasten the seat belt.
*1: This light illuminates on the multi-information display.
378
7-2. Steps to take in an emergency
*2: Rear passengers’ seat belt warning buzzer:
The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger
that his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer
sounds intermittently for a certain period of time after the vehicle reaches a certain
speed.
Q Tire pressure warning light
Warning light
Details/Actions
When the light comes on after blinking for approximately 1 minute
(a buzzer does not sounds):
Malfunction in the tire pressure warning system
Have the system checked by any authorized Mazda retailer
or Mazda authorized repairer, or any reliable repairer.
When the light comes on (a buzzer sounds):
Low tire inflation pressure from natural causes
Adjust the tire inflation pressure to the specified cold tire
inflation pressure level. (P.426)
Low tire inflation pressure from flat tire
Immediately stop the vehicle in a safe place.
Handling method (P.381)
Q LTA indicator* (warning buzzer)
Warning light
Details/Actions
Indicates a malfunction in the LTA (Lane Tracing Assist)
Follow the instructions displayed on the multi-information
(Orange)
display. (P.222)
(if equipped)
*: This light illuminates on the multi-information display.
7-2. Steps to take in an emergency
379
Q parking assist-sensor OFF indicator (warning buzzer)
Warning light
Details/Actions
Indicates a malfunction in the parking assist-sensor function
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
(Flashes)
Indicates that the system is temporarily unavailable, possibly due
(if equipped)
to a sensor being dirty or covered with ice, etc.
Follow the instructions displayed on the multi-information
display. (P.248)
QRCTA OFF” indicator (warning buzzer)
Warning light
Details/Actions
Indicates a malfunction in the RCTA (Rear Crossing Traffic Alert)
function
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
(Flashes)
Indicates that the rear bumper around the radar sensor is covered
(if equipped)
with dirt, etc. (→P.242)
Follow the instructions displayed on the multi-information
display. (P.252)
Q PKSB OFF indicator
7
Warning light
Details/Actions
When a buzzer sounds:
Indicates a malfunction in the PKSB (Parking Support Brake) sys-
tem
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
(if equipped)
When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possibly due
to a sensor being dirty or covered with ice, etc.
Follow the instructions displayed on the multi-information
display. (P.259, 383)
380
7-2. Steps to take in an emergency
Q PCS warning light
Warning light
Details/Actions
When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Collision
System).
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
When a buzzer does not sound:
(Flashes or illumi-
The PCS (Pre-Collision System) has become temporarily unavail-
nates)
(if equipped)
able, corrective action may be necessary.
Follow the instructions displayed on the multi-information
display. (P.201, 383)
If the PCS (Pre-Collision System) or VSC (Vehicle Stability Con-
trol) system is disabled, the PCS warning light will illuminate.
P.274
Q Slip indicator
Warning light
Details/Actions
Indicates a malfunction in:
z The VSC system;
z The TRC system; or
z The hill-start assist control system
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
repairer immediately.
Q Parking brake indicator
Warning light
Details/Actions
It is possible that the parking brake is not fully engaged or
released
Operate the parking brake switch once again.
This light comes on when the parking brake is not released. If the
(Flashes)
light turns off after the parking brake is fully released, the system is
operating normally.
7-2. Steps to take in an emergency
381
Q Brake hold operated indicator
Warning light
Details/Actions
Indicates a malfunction in the brake hold system
Have the vehicle inspected by any authorized Mazda
retailer or Mazda authorized repairer, or any reliable
(Flashes)
repairer immediately.
Q When the tire pressure warning
Q Warning buzzer
light comes on
In some cases, the buzzer may not be
Inspect the tires to check if a tire is
heard due to being in a noisy location or
punctured.
audio sound.
If a tire is punctured: →P.386, 397
QFront passenger detection sensor,
If none of the tires are punctured:
seat belt reminder and warning
Turn the power switch off then turn it to
buzzer
ON. Check if the tire pressure warning
OIf luggage is placed on the front pas-
light comes on or blinks.
senger seat, the front passenger
X If the tire pressure warning light blinks
detection sensor may cause the warn-
for approximately 1 minute then stays
ing light to flash and the warning
on
buzzer to sound even if a passenger
There may be a malfunction in the tire
is not sitting in the seat.
pressure warning system. Have the
OIf a cushion is placed on the seat, the
vehicle inspected by any authorized
sensor may not detect a passenger,
Mazda retailer or Mazda authorized
and the warning light may not operate
repairer, or any reliable repairer immedi-
properly.
ately.
QIf the malfunction indicator lamp
X If the tire pressure warning light
comes on while driving
comes on
For some models, the malfunction indi-
1
After the temperature of the tires has
7
cator lamp will come on if the fuel tank
lowered sufficiently, check the infla-
becomes completely empty. If the fuel
tion pressure of each tire and adjust
tank is empty, refuel the vehicle immedi-
them to the specified level.
ately. The malfunction indicator lamp will
2
If the warning light does not turn off
go off after several trips.
even after several minutes have
elapsed, check that the inflation
If the malfunction indicator lamp does
pressure of each tire is at the speci-
not go off, contact any authorized
fied level and perform initialization.
Mazda retailer or Mazda authorized
(→P.336)
repairer, or any reliable repairer as soon
as possible.
QThe tire pressure warning light may
come on due to natural causes
QElectric power steering system
warning light (warning buzzer)
The tire pressure warning light may
come on due to natural causes such as
When the 12-volt battery charge
natural air leaks and tire inflation pres-
becomes insufficient or the voltage tem-
sure changes caused by temperature. In
porarily drops, the electric power steer-
this case, adjusting the tire inflation
ing system warning light may come on
pressure will turn off the warning light
and the warning buzzer may sound.
(after a few minutes).
382
7-2. Steps to take in an emergency
QWhen a tire is replaced with a spare
QWhen the electric power steer-
tire
ing system warning light comes
Vehicles with a compact spare tire: The
on
compact spare tire is not equipped with
When the light comes on yellow, the
a tire pressure warning valve and trans-
assist to the power steering is
mitter. If a tire goes flat, the tire pressure
restricted. When the light comes on
warning light will not turn off even
red, the assist to the power steering is
though the flat tire has been replaced
lost and handling operations of the
with the spare tire. Replace the spare
steering wheel become extremely
tire with the repaired tire and adjust the
heavy.
tire inflation pressure. The tire pressure
When steering wheel operations are
warning light will go off after a few min-
heavier than usual, grip the steering
utes.
wheel firmly and operate it using more
Vehicles with a full-size spare tire: The
force than usual.
spare tire is also equipped with a tire
pressure warning valve and transmitter.
QIf the tire pressure warning light
The tire pressure warning light will turn
comes on
on if the tire inflation pressure of the
Be sure to observe the following pre-
spare tire is low. If a tire goes flat, the
cautions.
tire pressure warning light will not turn
Failure to do so could cause a loss of
off even though the flat tire has been
vehicle control and result in death or
replaced with the spare tire. Replace the
serious injury.
spare tire with the repaired tire and
adjust the tire inflation pressure. The tire
OStop your vehicle in a safe place as
pressure warning light will go off after a
soon as possible. Adjust the tire
few minutes.
inflation pressure immediately.
QConditions that the tire pressure
O Vehicles with a compact spare tire
warning system may not function
and full-size spare tire: If the tire
properly
pressure warning light comes on
even after tire inflation pressure
→P.334
adjustment, it is probable that you
have a flat tire. Check the tires. If a
WARNING
tire is flat, change it with the spare
tire and have the flat tire repaired
Q If both the ABS and the brake
by the nearest any authorized
system warning lights remain on
Mazda retailer or Mazda authorized
Stop your vehicle in a safe place
repairer, or any reliable repairer.
immediately and contact any autho-
rized Mazda retailer or Mazda autho-
O Vehicles with emergency tire punc-
rized repairer, or any reliable repairer.
ture repair kit: If the tire pressure
The vehicle will become extremely
warning light comes on even after
unstable during braking, and the ABS
tire inflation pressure adjustment, it
system may fail, which could cause
is probable that you have a flat tire.
an accident resulting in death or seri-
Check the tires. If a tire is flat, repair
ous injury.
the flat tire by using emergency tire
puncture repair kit.
O Avoid abrupt maneuvering and
braking.
If the vehicle tires deteriorate, you
could lose control of the steering
wheel or the brakes.















Content      ..     10      11      12      13     ..
