Mazda Mazdaspeed 6 (2007 year). Instruction

Black plate (25,1)

qPregnant Women and Persons with Serious Medical Conditions

Pregnant women should always wear seat belts. Ask your doctor for specific
recommendations.
The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS.
The shoulder belt should be worn across your shoulder properly, but never across the
stomach area.
Persons with serious medical conditions also should wear seat belts. Check with your
doctor for any special instructions regarding specific medical conditions.

qEmergency Locking Mode

In the emergency locking mode, the belt remains comfortable on the occupant and the
retractor will lock in position during a collision. When the seat belt is fastened, it will
always be in the emergency locking mode until it is switched to automatic locking mode by
pulling it all the way out to its full length. If the belt feels tight and hinders comfortable
movement while the vehicle is stopped or in motion, it may be in the automatic locking
mode because the belt has been pulled too far out. To return to the belt to the more
comfortable emergency locking mode, wait until the vehicle has stopped in a safe, level
area, retract the belt fully to convert it back to emergency locking mode and then extend it
around you again.

qAutomatic Locking Mode

Always use the automatic locking mode to keep the child-restraint system from shifting to
an unsafe position in the event of an accident. To enable seat belt automatic locking mode,
pull it all the way out and connect it as instructed on the child-restraint system. It will
retract down to the child-restraint system and stay locked on it. See the section on child
restraint (page 2-24).

Seat Belt Systems

2-13

Mazdaspeed6_8V77-EA-06F_Edition1 Page25
Tuesday, May 9 2006 10:43 AM

Black plate (26,1)

Seat Belt (Except Center-
Rear Position)

NOTE

When using the center-rear seat belt,
refer to

“Center-Rear Position Seat

Belt

” (page 2-18).

qFastening the Seat Belt

1. Grasp the tongue.

2. Slowly pull out the lap/shoulder belt.

Tongue

Belt

3. Insert the tongue into the buckle until

you hear a click.

Buckle

Tongue

WARNING

Positioning the Shoulder Portion of
the Seat Belt:
Improper positioning of the shoulder
portion of the seat belt is dangerous.
Always make sure the shoulder
portion of the seat belt is positioned
across your shoulder and near your
neck, but never under your arm, on
your neck, or on your upper arm.

4. Position the lap belt as low as possible,

not on the abdominal area, then adjust
the shoulder belt so that it fits snugly
against your body.

Keep low on
hip bone

Too high

Take up slack

WARNING

Positioning the Lap Portion of the
Seat Belt:
The lap portion of the seat belt worn
too high is dangerous. In a collision,
this would concentrate the impact
force directly on the abdominal area,
causing serious injury. Wear the lap
portion of the belt snugly and as low
as possible.

2-14

Seat Belt Systems

Mazdaspeed6_8V77-EA-06F_Edition1 Page26
Tuesday, May 9 2006 10:43 AM

Black plate (27,1)

qUnfastening the Seat Belt

Depress the button on the buckle. If the
belt does not fully retract, pull it out and
check for kinks or twists. Then make sure
it remains untwisted as it retracts.

Button

NOTE

If a belt does not fully retract, inspect it
for kinks and twists. If it is still not
retracting properly, have it inspected at
an Authorized Mazda Dealer.

qShoulder Belt Adjuster (Front

Seat Belts)

Adjust the height of the shoulder belt if
the seat belt touches your neck, or if it
crosses your arm instead of your shoulder.
To raise the shoulder belt adjuster, push
the adjuster up. To lower the shoulder belt
adjuster, pull the knob and slide it down.
Make sure the adjuster is locked.

WARNING

Seat Belt Systems

2-15

Mazdaspeed6_8V77-EA-06F_Edition1 Page27
Tuesday, May 9 2006 10:43 AM

Black plate (28,1)

Front Seat Belt Pretensioner
and Load Limiting Systems

For optimum protection, the driver and
front passenger seat belts are equipped
with pretensioner and load limiting
systems. For both these systems to work
properly you must wear the seat belt
properly.

Pretensioners:
In moderate or severe frontal or near-
frontal accidents, the front air bag and
pretensioner systems deploy
simultaneously when the seat belt is worn.
If the front seat occupant is not wearing a
seat belt, that person's pretensioner will
not fire even if the air bag does. The front
seat belt retractors remove slack quickly
as the air bags are expanding.
In addition, the pretensioner system for
the front passenger, like the front
passenger air bag, is designed to only
deploy in accordance with the total seated
weight on the front passenger seat. Any
time the air bags and seat belt
pretensioners have fired they must be
replaced. For details, refer to the front
passenger seat weight sensors (page 2-48).

Load limiter:
The load limiting system releases belt
webbing in a controlled manner to reduce
belt force on the occupant's chest. While
the most severe load on a seat belt occurs
in frontal collisions, the load limiter has
an automatic mechanical function and can
activate in any accident mode with
sufficient occupant movement.
Even if the pretensioners have not fired,
the load limiting function must be
checked by an Authorized Mazda Dealer.

WARNING

Wear seat belts only as recommended
in this owner's manual:
Incorrect positioning of the driver and
front passenger seat belts is
dangerous. Without proper
positioning, the pretensioner and load
limiting systems cannot provide
adequate protection in an accident
and this could result in serious injury.
For more details about wearing seat
belts, refer to

“Fastening the seat

belts

” (page 2-14).

2-16

Seat Belt Systems

Mazdaspeed6_8V77-EA-06F_Edition1 Page28
Tuesday, May 9 2006 10:43 AM

Black plate (29,1)

WARNING

Have your seat belts changed
immediately if the pretensioner or load
limiter has been expended:
One or both front air bags may deploy,
and the corresponding pretensioner(s)
may also deploy at the same time.
While it is safer to use a crash-used
seat belt that was used in an accident
than no seat belt at all, using a seat
belt with an expended pretensioner or
load limiter loaded reduces the safety
available to you. Like the air bags, the
seat belt pretensioners will only
function once. After they are
expended, they will not function again
and must be replaced immediately. If
the seat belt pretensioners are not
replaced, the risk of injury in a
collision will increase. Always have an
Authorized Mazda Dealer inspect the
seat belt pretensioners and air bags
after any collision. Expended seat belt
pretensioners and air bags must be
replaced after any collision which
caused them to deploy. Additionally,
the load limiter will only limit loads on
the chest once in a collision and this is
another reason to have the front seat
belts inspected.

Do not modify the components or
wiring, or use electronic testing
devices on the pretensioner system:
Modifying the components or wiring
of the pretensioner system, including
the use of electronic testing devices is
dangerous. You could accidentally
activate it or make it inoperable which
would prevent it from activating in an
accident. The occupants or repairers
could be seriously injured.

WARNING

Properly dispose of the pretensioner
system:
Improper disposal of the pretensioner
system or a vehicle with non-
deactivated pretensioners is
dangerous. Unless all safety
procedures are followed, injury could
result. Ask an Authorized Mazda
Dealer how to safely dispose of the
pretensioner system or how to scrap a
pretensioner-equipped vehicle.

NOTE

The pretensioner system will activate
in a moderate or greater frontal or
near-frontal collision. The
pretensioner system for the front
passenger is designed to only deploy
in accordance with the total seated
weight on the front passenger seat. It
will not activate in most rollovers,
side or rear impacts.

Some smoke (non-toxic gas) will be
released when the air bags and
pretensioners deploy. This does not
indicate a fire. This gas normally has
no effect on occupants, however,
those with sensitive skin may
experience light skin irritation. If
residue from the deployment of the
air bags or the front pretensioner
system gets on the skin or in the
eyes, wash it off as soon as possible.

Seat Belt Systems

2-17

Mazdaspeed6_8V77-EA-06F_Edition1 Page29
Tuesday, May 9 2006 10:43 AM

Black plate (30,1)

qAir Bag/Front Seat Belt Pretensioner

Systems Warning Light

If the air bag/front seat belt pretensioner
system is working properly, the warning
light illuminates when the ignition switch
is turned to the ON position or after the
engine is cranked. The warning light turns
off after a specified period of time.

A system malfunction is indicated if the
warning light constantly flashes,
constantly illuminates or does not
illuminate at all when the ignition switch
is turned to the ON position. If either of
these occur, consult an Authorized Mazda
Dealer as soon as possible. The system
may not work in an accident.

WARNING

Never tamper with the air bag/
pretensioner systems and always have
an Authorized Mazda Dealer perform
all servicing and repairs:
Self-servicing or tampering with the
systems is dangerous. An air bag/
pretensioner could accidentally
activate or become disabled causing
serious injury or death.

Center-Rear Position Seat
Belt

Before using the center-rear lap/shoulder
belt make sure tongue (A) and anchor
buckle (B) are fastened.

(A)

(B)

qFastening the Seat Belt

1. Grasp the tongue (C).

2. Slowly pull out the lap/shoulder belt.

3. Insert the tongue (C) into the buckle

(D) until you hear a click.

(C)

(D)

(B)

(A)

2-18

Seat Belt Systems

Mazdaspeed6_8V77-EA-06F_Edition1 Page30
Tuesday, May 9 2006 10:43 AM

Black plate (31,1)

WARNING

Fastening the Center-Rear Seat Belt
with Only One Buckle:
Fastening the center-rear seat belt
with only one buckle is dangerous. If
only one pair of seat belt tongue and
buckle, either tongue (A) and anchor
buckle (B) or tongue (C) and anchor
buckle (D), is fastened, the seat belt
cannot provide full protection. In a
sudden stop or collision, the user
could slide under the belt and suffer
serious injuries. Always make sure
that both pairs of seat belt tongues and
buckles are fastened properly.

4. Position the lap belt as low as possible,

not on the abdominal area, then adjust
the shoulder belt so that it fits snugly
against your body.

WARNING

qUnfastening the Seat Belt

Depress the button on the buckle. If the
belt does not fully retract, pull it out and
check for kinks or twists. Then make sure
it remains untwisted as it retracts.

Button

NOTE

If a belt does not fully retract, inspect it
for kinks and twists. If it is still not
retracting properly, have it inspected at
an Authorized Mazda Dealer.

Seat Belt Systems

2-19

Mazdaspeed6_8V77-EA-06F_Edition1 Page31
Tuesday, May 9 2006 10:43 AM

Black plate (32,1)

qUnfastening the Lap Portion of

the Seat Belt

Insert a small object such as a key in the
anchor buckle (B) slot.

(B)

(A)

NOTE

To encourage rear seat passengers to
wear their seat belts, we suggest leaving
the center-rear lap position of the belt
fastened at all times.

qFastening the Lap Portion of the

Seat Belt

Grasp tongue (A) and insert it into the
anchor buckle (B) until you hear a click. It
is now secure for passenger use.

qStowing and pulling out the

Center-Rear Position Seat Belt

The center-rear position seat belt can be
stowed using the following procedure.

CAUTION

When stowing the seat belt, make sure
the belt is locked securely into the
recess. If the seat belt is not properly
stowed, it might get caught in the seats
and be damaged.

To stow the seat belt, retract the belt, put
tongues (A) and (C) together and insert
them into the recess.

(A)

(C)

To pull out the seat belt, slide tongues
with your finger, and slowly pull out the
seat belt from the recess.

NOTE

Pulling out the seat belt all the way out
will switch it to automatic locking
mode. If automatic locking mode is not
needed, retract the seat belt fully to
convert it back to emergency locking
mode.

2-20

Seat Belt Systems

Mazdaspeed6_8V77-EA-06F_Edition1 Page32
Tuesday, May 9 2006 10:43 AM

Black plate (33,1)

Seat Belt Extender

If your seat belt is not long enough, even
when fully extended, a seat belt extender
may be available to you at no charge from
your Authorized Mazda Dealer.
This extender will be only for you and for
the particular vehicle and seat. Even if it
plugs into other seat belts, it may not hold
in the critical moment of a crash.
When ordering an extender, only order
one that provides the necessary additional
length to fasten the seat belt properly.
Please contact your Authorized Mazda
Dealer for more information.

WARNING

Do not use a seat belt extender unless
it is necessary:
Using a seat belt extender when not
necessary is dangerous. The seat belt
will be too long and not fit properly. In
an accident, the seat belt will not
provide adequate protection and you
could be seriously injured. Only use
the extender when it is required to
fasten the seat belt properly.

Do not use an improper extender:
Using a seat belt extender that is for
another person or a different vehicle
or seat is dangerous. The seat belt will
not provide adequate protection and
the user could be seriously injured in
an accident. Only use the extender
provided for you and for the particular
vehicle and seat. NEVER use the
extender in a different vehicle or seat.

WARNING

Do not use an extender that is too
long:
Using an extender that is too long is
dangerous. The seat belt will not fit
properly. In an accident, the seat belt
will not provide adequate protection
and you could be seriously injured. Do
not use the extender or choose one
shorter in length if the distance
between the extender's buckle and the
center of the user's body is less than
15cm (6 in).

NOTE

When not in use, remove the seat belt
extender and store it in the vehicle. If
the seat belt extender is left connected,
the seat belt extender might get
damaged as it will not retract with the
rest of the seat belt and can easily fall
out of the door when not in use and be
damaged. In addition, the seat belt
warning light will not illuminate and
function properly.

Seat Belt Systems

2-21

Mazdaspeed6_8V77-EA-06F_Edition1 Page33
Tuesday, May 9 2006 10:43 AM

Black plate (34,1)

Seat Belt Warning Light/Beep

The seat belt warning light illuminates
and a beep sound will be heard if the
driver's seat belt is not fastened when the
ignition switch is turned to the ON
position.

Conditions of operation

Condition

Result

The driver's seat belt is not
fastened when the ignition
switch is turned to the ON
position.

The warning light
flashes and a beep
sound will be heard
for about 6 seconds.

The driver's seat belt is
fastened while the warning
light and the beep sound are
activated.

The warning light
turns off and the beep
sound stops.

The driver's seat belt is
fastened before the ignition
switch is turned to the ON
position.

The warning light will
not illuminate and the
beep sound will not be
heard.

qBelt Minder

NOTE

The belt minder can be deactivated.
Consult an Authorized Mazda Dealer to
deactivate and restore the seat belt
minder.

Driver seated/Front passenger not
seated

The belt minder is a supplemental
warning to the seat belt warning function.
If the driver's seat belt is not fastened
when the ignition switch is turned to the
ON position, the warning light/beep
operates to give you further reminders
according to the chart below.

Condition

Vehicle speed

Between 0

― 20

km/h

― 12 mph)

20 km/h

(12 mph) or

Seat belt

Indicator

Beep

: Fastened
: Unfastened
: Illuminated

: Flashing

: Beep

Once the beep sound is heard, it continues
sounding even if the vehicle speed lowers
to 20 km/h (12 mph) or less until the
seatbelt is fastened or the beep sound
period has passed.

2-22

Seat Belt Systems

Mazdaspeed6_8V77-EA-06F_Edition1 Page34
Tuesday, May 9 2006 10:43 AM

Black plate (35,1)

Driver seated/Front passenger seated

The seat belt warning light/beep reminds
the front passenger to fasten the seat belt
according to the chart below.

Condition

Vehicle speed

Between 0

― 20

km/h

― 12 mph)

20 km/h

(12 mph) or

Seat belt
(Driver)

Seat belt
(Passenger)

Indicator

Beep

: Fastened
: Unfastened
: Illuminated

: Flashing

: Beep

Once the beep sound is heard, it continues
sounding even if the vehicle speed lowers
to 20 km/h (12 mph) or less until the
seatbelt is fastened or the beep sound
period has passed.

NOTE

To allow the front passenger seat
weight sensor to function properly,
do not place and sit on an additional
seat cushion on the front passenger
seat. The sensor may not function
properly because the additional seat
cushion could cause sensor
interference.

Placing packages, luggage, pets or
other items on the front passenger
seat may cause the front passenger
belt minder warning light and beep
to operate depending on the weight
of the item.

Seat Belt Systems

2-23

Mazdaspeed6_8V77-EA-06F_Edition1 Page35
Tuesday, May 9 2006 10:43 AM

Black plate (36,1)

Child Restraint Precautions

Mazda strongly urges the use of child-restraint systems for children small enough to use
them.

You are required by law to use a child-restraint system for children in the U.S. and Canada.
Check your local and state or provincial laws for specific requirements regarding the safety
of children riding in your vehicle.

Whatever child-restraint system you consider, please pick the appropriate one for the age
and size of the child, obey the law and follow the instructions that come with the individual
child-restraint system.

A child who has outgrown child-restraint systems should sit in the rear and use seat belts,
both lap and shoulder. If the shoulder belt crosses the neck or face, move the child closer to
the center of the vehicle in the outboard seats, and towards the buckle on the right if the
child is seated on the center seat.

Statistics confirm that the rear seat is the best place for all children up to 12 years of age,
and more so with a supplemental restraint system (air bags).

A rear-facing child-restraint system should NEVER be used on the front seat with the air
bag system activated. The front passenger's seat is also the least preferred seat for other
child-restraint systems.

To reduce the chance of injuries caused by deployment of the front passenger air bag, the
front passenger seat weight sensors work as a part of the supplemental restraint system.
This system deactivates the front passenger front and side air bags and also the front
passenger seat belt pretensioner system when the total seated weight on the front passenger
seat is less than approximately 30 kg (66 lb).

When an infant or small child sits on the front passenger seat, the system shuts off the front
passenger front and side air bags and seat belt pretensioner system, so make sure the front
passenger air bag deactivation indicator light illuminates.

Even if the front passenger air bag is shut off, Mazda strongly recommends that children be
properly restrained and child-restraint systems of all kinds are properly secured on the rear
seats which are the best place for children.

For more details, refer to

“Front passenger seat weight sensors” (page 2-48).

2-24

Child Restraint

Mazdaspeed6_8V77-EA-06F_Edition1 Page36
Tuesday, May 9 2006 10:43 AM

Black plate (37,1)

WARNING

Use the correct size child-restraint system:
For effective protection in vehicle accidents and sudden stops, a child must be
properly restrained using a seat belt or child-restraint system depending on age and
size. If not, the child could be seriously injured or even killed in an accident.

Follow the manufacturer's instructions and always keep the child-restraint system
buckled down:
An unsecured child-restraint system is dangerous. In a sudden stop or a collision it
could move causing serious injury or death to the child or other occupants. Make sure
any child-restraint system is properly secured in place according to the child-restraint
system manufacturer's instructions. When not in use, remove it from the vehicle or
fasten it with a seat belt, or latch it down to BOTH LATCH lower anchors for LATCH
child-restraint systems and the corresponding tether anchor.

Always secure a child in a proper child-restraint system:
Holding a child in your arms while the vehicle is moving is extremely dangerous. No
matter how strong the person may be, he or she cannot hold onto a child in a sudden
stop or collision and it could result in serious injury or death to the child or other
occupants. Even in a moderate accident, the child may be exposed to air bag forces
that could result in serious injury or death to the child, or the child may be slammed
into an adult, causing injury to both child and adult.

Never use a rear-facing child-restraint system in the front seat with an air bag that
could deploy:
Rear-facing child-restraint systems on the front seat are particularly dangerous even
though you may feel assured that a front passenger air bag will not deploy based on
the fact that the front passenger air bag deactivation indicator light illuminates.
The child-restraint system can be hit by a deploying air bag and moved violently
backward resulting in serious injury or death to the child.

Child Restraint

2-25

Mazdaspeed6_8V77-EA-06F_Edition1 Page37
Tuesday, May 9 2006 10:43 AM

Black plate (38,1)

WARNING

Do not install a front-facing child-restraint system on the front passenger seat unless
it is unavoidable:
In a collision, the force of a deploying air bag could cause serious injury or death to
the child. If installing a front-facing child-restraint system on the front passenger seat
is unavoidable, move the front passenger seat as back as possible.

Seating a child in a child-restraint system on the front passenger seat is dangerous:
Vehicles equipped with front passenger seat weight sensors are also equipped with a
front passenger air bag deactivation indicator light (page 2-33). Even with the front
passenger seat weight sensors, if you must use the front passenger seat for children,
seating a child in a child-restraint system on the front passenger seat under the
following conditions increases the danger of the front passenger air bag deploying
and could result in serious injury or death to the child.

The total seated weight of the child with the child-restraint system on the front
passenger seat is approximately 30 kg (66 lb) or more with a child in the child-
restraint system.

Luggage or other items are placed on the seat with the child in the child-restraint
system.

A rear passenger or luggage push or pull down on the front passenger seatback.

A rear passenger puts their feet on the front seat rails.

Luggage or other items are placed on the seatback or hung on the head restraint.

The seat is washed.

Liquids are spilled on the seat.

The front passenger seat is moved backward, pushing into luggage or other items
placed behind it.

The front passenger seatback contacts the rear seat.

Luggage or other items are placed between the front passenger seat and driver seat.

Any accessories, which might increase the total seated weight on the front
passenger seat, are attached to the front passenger seat.

The designated positions with seat belts on the rear seats are the safest places for
children. Always use seat belts and child restraints.

2-26

Child Restraint

Mazdaspeed6_8V77-EA-06F_Edition1 Page38
Tuesday, May 9 2006 10:43 AM

Black plate (39,1)

WARNING

Do not allow a child to lean over or against the side window of a vehicle with side and
curtain air bags:
It is dangerous to allow anyone to lean over or against the side window, the area of
the front passenger seat, the front and rear window pillars and the roof edge along
both sides from which the side and curtain air bags deploy, even if a child-restraint
system is used. If the vehicle is equipped with side and curtain air bags, the impact of
inflation could cause serious injury or death to the child. Furthermore, leaning over
or against the front door could block the side and curtain air bags and eliminate the
advantages of supplemental protection. With the front air bag and the additional side
air bag that comes out of the front seat, the rear seat is always a better location for
children. Do not allow a child to lean over or against the side window, even if the child
is seated in a child-restraint system.

Never use one seat belt on more than one person at a time:
Using one seat belt for more than one person at a time is dangerous. A seat belt used
in this way cannot spread the impact forces properly and the two passengers could be
crushed together and seriously injured or even killed. Never use one belt for more
than one person at a time and always operate the vehicle with each occupant properly
restrained.

CAUTION

A seat belt or child-restraint system can become very hot in a closed vehicle during
warm weather. To avoid burning yourself or a child, check them before you or your child
touches them.

NOTE

Your Mazda is equipped with LATCH lower anchors for attachment of specially
designed LATCH child-restraint systems in the rear seat. When using these anchors to
secure a child-restraint system, refer to

“LATCH Child-Restraint Systems” (page 2-35).

Child Restraint

2-27

Mazdaspeed6_8V77-EA-06F_Edition1 Page39
Tuesday, May 9 2006 10:43 AM

Black plate (40,1)

Installing Child-Restraint
Systems

Accident statistics reveal that a child is
safer in the rear seat. The front passenger's
seat is clearly the worst choice for any
child under 12, and with rear-facing child-
restraint systems it is clearly unsafe due to
air bags.

Some child-restraint systems now come
with tethers and therefore must be
installed on the seats that take tethers to
be effective. In your Mazda, tethered
child-restraint systems can only be
accommodated in the three positions on
the rear seat.

Even if your vehicle is equipped with
front passenger seat weight sensors (page
2-48), which automatically deactivates the
front passenger air bag, a rear seat is the
safest place for a child of any age or size.

Some child-restraint systems also employ
specially designed LATCH attachments;
refer to

“LATCH Child-Restraint

Systems

” (page 2-35).

WARNING

Tethered Child-Restraint Systems
Work Only on Tether-Equipped Rear
Seats:
Installation of a tether equipped child-
restraint system in the front
passenger's seat defeats the safety
design of the system and will result in
an increased chance of serious injury
if the child-restraint system goes
forward without benefit of being
tethered.
Place tether equipped child-restraint
systems where there are tether
anchors.

qRear Outboard Seat Child-

Restraint System Installation

Follow these instructions when using a
child-restraint system, unless you are
attaching a LATCH-equipped child-
restraint system to the rear LATCH lower
anchors. Refer to

“LATCH Child-

Restraint Systems

” (page 2-35).

NOTE

Follow the child-restraint system
manufacturer's instructions carefully. If
you are not sure whether you have a
LATCH system or tether, check in the
child-restraint system manufacturer's
instructions and follow them
accordingly. Depending on the type of
child-restraint system, it may not
employ seat belts which are in
automatic locking mode.

2-28

Child Restraint

Mazdaspeed6_8V77-EA-06F_Edition1 Page40
Tuesday, May 9 2006 10:43 AM

Mazda Mazdaspeed 6 (2007 year). Instruction - part 2
