Mazda B4000 4WD Truck (2004 year). Instruction

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

Your vehicle is equipped with a remote entry system which allows you to:
• unlock the vehicle doors without

a key.

• lock all the vehicle doors without

a key.

• activate the personal alarm.

If there is any potential remote keyless entry problem with your vehicle,
ensure ALL remote entry transmitters are taken to the dealership, to
aid in troubleshooting.

Unlocking the doors

1. Press

and release to unlock the driver’s door. Note: The interior

lamps will illuminate.

2. Press

and release again within three seconds to unlock all the

doors.

Locking the doors

• Press

and release to lock all the doors. The park lamps will flash

once to confirm lock; if any of the doors are not properly closed, the
lamps will not flash.

• Pressing

a second time within two seconds will cause all doors to

lock, the parking lamps to flash, and the horn to sound one time in
order to confirm locking.

Locks and Security

Power door lock disabled

The UNLOCK feature on your power
door locks will not work from inside
the vehicle when:

• the ignition has been turned to the OFF position, and
• 20 seconds elapse after all vehicle doors are closed and locked using

the remote entry transmitter, or the power door lock control (while
the accompanying door is open).

The UNLOCK feature will work again after:
• a door has become ajar,
• the ignition is turned to the ON position, or
• using the UNLOCK

control on your remote entry transmitter.

Sounding a personal alarm

Press

to activate the alarm. The horn will sound for a maximum of

30 seconds and the parklamps will flash for a maximum of 3 minutes.
Press again or turn the ignition to ON to deactivate, or wait for the alarm
to timeout in 3 minutes.

Note: The personal alarm will only operate when the ignition is in the
OFF or ACC position.

Replacing the battery

The remote entry transmitter uses one coin type three-volt lithium
battery CR2032 or equivalent. The typical operating range for your
remote entry transmitter is approximately 10 meters (33 feet). A
decrease in the operating range could be caused by:
• weather conditions,
• nearby radio towers,
• structures around the vehicle and
• other vehicles parked next to the vehicle.

UNLOCK

LOCK

Locks and Security

To replace the battery:

1. Twist a thin coin between the

two halves of the remote entry
transmitter near the key ring.
DO NOT TAKE THE FRONT
PART OF THE REMOTE
ENTRY TRANSMITTER
APART. Damage to the
transmitter may result in
operation failure.

2. Remove the old battery.

3. Insert the new battery. Refer to the diagram inside the remote entry

transmitter for the correct orientation of the battery.

4. Snap the two halves back together.

Note: Replacement of the battery will not cause the remote transmitter
to become deprogrammed from your vehicle. The remote transmitter
should operate normally after battery replacement.

Replacing lost remote entry transmitters

If you would like to have your remote entry transmitter reprogrammed
because you lost one, or would like to buy additional remote entry
transmitters, you can either reprogram them yourself, or take all
remote entry transmitters to your authorized dealer for
reprogramming.

How to reprogram your remote entry transmitters

You must have all remote entry transmitters (maximum of four)
available before beginning this procedure.

To reprogram the remote entry transmitters:

1. Ensure the vehicle is electronically unlocked.

2. Put the key in the ignition.

Locks and Security

3. Turn the key from the 2

(LOCK) position to 3 (OFF).

4. Cycle eight times rapidly (within 10 seconds) between the 3 (OFF)

position and 4 (ON). Note: The eighth turn must end in the 4 (ON)
position. The instrument lights in the cluster will come on for a bulb
check in the 4 (ON) position.

5. The doors will lock, then unlock, to confirm that the programming

mode has been activated.

6. Within 20 seconds press any button on the remote entry transmitter.

Note: If more than 20 seconds have passed you will need to start
the procedure over again.

7. The doors will lock, then unlock, to confirm that this remote entry

transmitter has been programmed.

8. Repeat Step 6 to program each additional remote entry transmitter.

9. Turn the ignition to the 3 (OFF) position after you have finished

programming all of the remote entry transmitters.

10. The doors will lock, then unlock, to confirm that the programming

mode has been exited.

Illuminated entry

The interior lamps illuminate when the remote entry system is used to
unlock the door(s) or sound the personal alarm.

The illuminated entry system will turn off the interior lights if:
• the ignition switch is turned to the ON position, or
• the remote transmitter lock control is pressed, or
• after 25 seconds of illumination.
The dome lamp control (if equipped) must not be set to the OFF
position for the illuminated entry system to operate.

Locks and Security

The inside lights will not turn off if:
• they have been turned on with the dimmer control, or
• any door is open.
The battery saver will shut off the interior lamps 30 minutes after the
last door is closed, even if the dimmer control is on.

SECURILOCK

PASSIVE ANTI-THEFT SYSTEM

SecuriLock

y passive anti-theft system is an engine immobilization

system. This system is designed to prevent the engine from being started
unless a coded key programmed to your vehicle is used.

The SecuriLock

y passive anti-theft system is not compatible with

non-Mazda aftermarket remote start systems. Use of these systems may
result in vehicle starting problems and a loss of security protection.

Your vehicle comes with two coded keys; additional coded keys may be
purchased from your dealer. The dealer can program your spare keys to
your vehicle or you can program the keys yourself. Refer to
Programming spare keys for instructions on how to program the coded
key.

Note: A maximum of eight keys can be coded to your vehicle.

Note: Large metallic objects, electronic devices that are used to
purchase gasoline or similar items, or a second coded key on the same
key chain may cause vehicle starting issues. You need to prevent these
objects from touching the coded key while starting the engine. These
objects will not cause damage to the coded key, but may cause a
momentary issue if they are too close to the key when starting the
engine. If a problem occurs, turn the ignition off, remove all objects on
the key chain away from the coded key and restart the engine.

Theft indicator

The theft indicator is located in the instrument cluster.
• When the ignition is in the OFF position, the indicator will flash once

every 2 seconds to indicate the SecuriLock

y system is functioning as

a theft deterrent.

• When the ignition is in the ON position, the indicator will glow for 3

Automatic arming

The vehicle is armed immediately
after switching the ignition to the 3
(OFF) position.

The theft indicator will flash every
two seconds when the vehicle is
armed.

Automatic disarming

Switching the ignition to the 4 (ON) position with a coded key disarms
the vehicle.

The theft indicator will illuminate
for three seconds and then go out.
Note: If the theft indicator stays on
for an extended period of time or
flashes rapidly, have the system
serviced by your dealer.

Replacement keys

If your keys are lost or stolen and you don’t have an extra coded key,
you will need to have your vehicle towed to a dealership. The key codes
need to be erased from your vehicle and new coded keys will need to be
programmed.

Replacing coded keys can be very costly. Store an extra programmed key
away from the vehicle in a safe place to help prevent any
inconveniences. Please visit an authorized dealer to purchase additional
spare or replacement keys.

Programming spare keys

You can program your own coded keys to your vehicle. Please read and
understand the entire procedure before you begin.

Locks and Security

Tips:
• A maximum of eight keys can be coded to your vehicle.

• Only use Securilocky keys.

• You must have two previously programmed coded keys (keys that

already operate your vehicle’s engine) and the new unprogrammed
key(s) readily accessible.

• If you do not have at least 2 previously programmed keys, you must take

your vehicle to your dealer to have the spare key(s) programmed.

1. Insert a previously programmed

coded key into the ignition.

2. Turn the ignition from the 3

(OFF) position to the 4 (ON)
position. Keep the ignition in
the 4 (ON) position for at least
one second, but no more than
10 seconds.

3. Turn the ignition to the 3 (OFF)

position, and remove the coded
key from the ignition.

4. Within ten seconds of removing the previously programmed coded key,

insert the other previously programmed coded key into the ignition.

5. Turn the ignition from the 3 (OFF) position to the 4 (ON) position.

Keep the ignition in the 4 (ON) position for at least one second but
not more than 10 seconds.

6. Turn the ignition to the 3 (OFF) position, and remove the second

key from the ignition.

7. Within twenty seconds of removing the previously programmed coded

key, insert the unprogrammed key (new/valet key) into the ignition.

8. Turn the ignition from the 3 (OFF) position to the 4 (ON) position.

Keep the ignition in the 4 (ON) position for at least one second.

9. Your new unprogrammed key is now programmed.

If the key has been successfully programmed it will start the vehicle’s
engine and the theft indicator light will illuminate for three seconds and
then go out. If the key was not successfully programmed, it will not start
your vehicle’s engine and the theft indicator light will flash on and off. If
failure repeats, bring your vehicle to your dealer to have the new key(s)
programmed.
To program additional new unprogrammed key(s), repeat this procedure
from step 1 for each additional key.

Locks and Security

SEATING

Adjusting the front manual seat (if equipped)

WARNING: Never adjust the driver’s seat or seatback when the
vehicle is moving.

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

Lift the release bar to move seat
forward or backward. Ensure that
the seat is locked into place.

Pull lever located at the side of the
seat cushion up to adjust seatback.

Seating and Safety Restraints

Seating and Safety Restraints

60/40 seat (if equipped)

To gain access to the storage
compartment in your armrest (if
equipped), lift the latch to open lid.

The 60/40 seat cupholder (if
equipped) is detachable for
cleaning.
• Firmly grasp the bottom of the

cup holder and pull up.

To re-attach:
• Slide the cupholder over the two pins located on the front of the 60%

driver’s seat.

• Press down until it is firmly latched into place.

Using the manual lumbar support (if equipped)

Turn the lumbar support control
clockwise to increase firmness.

Turn the lumbar support control
counterclockwise to increase
softness.

Passenger side rear access (if equipped)

Pull up on the recliner handle. The
seat will lean forward. Lift the
release bar to move the seat forward
to access the rear area of the cab.

Seating and Safety Restraints

To return seat to original position, slide the seat bottom back, then push
the seatback up to lock it in place. The seat will lock, and you will have
to use the release bar to move the seat back to the original position.

REAR SEATS

Center facing jump seat (2–door Cab Plus) (if equipped)

To open, pull inboard and down on the seat handle.

To stow the seat, pull seat bottom back to the fully upright position.

WARNING: Do not install a child seat in a center facing jump
seat.

Center facing jump seat (4 door CabPlus 4) (if equipped)

To open, pull seat assembly down,
then raise seatback.

To stow the seat, fold seat back
down and raise seat assembly to the
fully upright position.

WARNING: Do not install a
child seat in a center facing
jump seat.

SAFETY RESTRAINTS

Safety restraints precautions

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

WARNING: To reduce the risk of injury, make sure children sit
where they can be properly restrained.

WARNING: Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot protect the
child from injury in a collision.

WARNING: All occupants of the vehicle, including the driver,
should always properly wear their safety belts, even when an
air bag (SRS) is provided.

WARNING: It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or killed. Do
not allow people to ride in any area of your vehicle that is not
equipped with seats and safety belts. Be sure everyone in your
vehicle is in a seat and using a safety belt properly.

WARNING: In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing a safety
belt.

WARNING: Each seating position in your vehicle has a specific
safety belt assembly which is made up of one buckle and one
tongue that are designed to be used as a pair. 1) Use the
shoulder belt on the outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never swing the safety belt
around your neck over the inside shoulder. 3) Never use a
single belt for more than one person.

WARNING: On four-door Cab Plus 4 vehicles, do not open the
rear door when the rear seat belt is still buckled.

Seating and Safety Restraints

Combination lap and shoulder belts

1. Insert the belt tongue into the

proper buckle (the buckle
closest to the direction the
tongue is coming from) until
you hear a snap and feel it
latch. Make sure the tongue is
securely fastened in the buckle.

2. To unfasten, push the release

button and remove the tongue
from the buckle.

The front outboard safety restraints in the vehicle are combination lap
and shoulder belts. The front passenger outboard safety belt has two
types of locking modes described below:

Energy Management Feature

• This vehicle has a safety belt system with an energy management

feature at the front outboard seating positions to help further reduce
the risk of injury in the event of a head-on collision.

• This safety belt system has a retractor assembly that is designed to

pay out webbing in a controlled manner. This feature is designed to
help reduce the belt force acting on the occupant’s chest.

Vehicle sensitive mode

This is the normal retractor mode, which allows free shoulder belt length
adjustment to your movements and locking in response to vehicle
movement. For example, if the driver brakes suddenly or turns a corner
sharply, or the vehicle receives an impact of approximately 8 km/h (5
mph) or more, the combination safety belts will lock to help reduce
forward movement of the driver and passengers.

Seating and Safety Restraints

Automatic locking mode (outboard front passenger seating
position only) for use with child safety seats

In this mode, the shoulder belt is automatically pre-locked. The belt will
still retract to remove any slack in the shoulder belt.
The automatic locking mode is not available on the driver safety belt.

When to use the automatic locking mode

• Any time a child safety seat is installed in a passenger front seat.

Refer to Safety Restraints for Children, Safety Seats for Children,
or Passenger air bag On/Off switch later in this chapter.

How to use the automatic locking mode (Outboard front passenger
seating position only) for use with child safety seats

• Buckle the combination lap and

shoulder belt.

• Grasp the shoulder portion and

pull downward until the entire
belt is pulled out.

• Allow the belt to retract. As the belt retracts, you will hear a clicking

sound. This indicates the safety belt is now in the automatic locking
mode.

How to disengage the automatic locking mode

Disconnect the combination lap/shoulder belt and allow it to retract
completely to disengage the automatic locking mode and activate the
vehicle sensitive (emergency) locking mode.

Seating and Safety Restraints

WARNING: After any vehicle collision, the entire seat belt
system should be checked for proper operation by a qualified
technician. Verify that the

(automatic locking retractors” in all

outboard seating positions are functioning properly.
Additionally check that the

(automatic locking mode( feature

for child safety seat in the passenger outboard seating position
is functioning properly.

WARNING: BELT AND RETRACTOR ASSEMBLY MUST BE
REPLACED if the seat belt assembly “automatic locking
retractor” feature or any other seat belt function is not
operating properly when checked according to the procedures in
Workshop Manual.

WARNING: Failure to replace the Belt and Retractor assembly
could increase the risk of injury in collisions.

Safety belt pretensioner

Your vehicle is equipped with safety belt pretensioners at the driver and
front outboard passenger seating positions. Both pretensioners will fire if
the front airbags fire, whether or not there is a belted occupant in either
front outboard seat.

The safety belt pretensioners are designed to activate during certain
frontal or near-frontal collisions with sufficient longitudinal deceleration.
A safety belt pretensioner is a device which tightens the webbing of the
lap and shoulder belts in such a way that they fit more snugly against
the body.

The driver and front outboard passenger safety belt system (including
retractors, buckle assembly, pretensioner assembly with seat and height
adjusters) must be replaced if the vehicle is involved in a collision that
results in the activation of the safety belt pretensioners. Refer to the
Safety belt maintenance section in this chapter.

WARNING: Failure to replace the safety belt assembly after a
crash has occurred could result in severe personal injuries in
the event of a collision.

Seating and Safety Restraints

Front safety belt height adjustment

Your vehicle has safety belt height adjustments for the driver and front
passenger. Adjust the height of the shoulder belt so the belt rests across
the middle of your shoulder.
• Regular Cab and 4–door Cab Plus

• 2–door Cab Plus

To lower the shoulder belt height, push the button and slide the height
adjuster down. To raise the height of the shoulder belt, slide the height
adjuster up. Pull down on the height adjuster to make sure it is locked in
place.

WARNING: Position the safety belt height adjusters so that the
belt rests across the middle of your shoulder. Failure to adjust
the safety belt properly could reduce the effectiveness of the
seat belt and increase the risk of injury in a collision.

Lap belts

Adjusting the center lap belt

The lap belt does not adjust automatically.

Seating and Safety Restraints

WARNING: The lap belts should fit snugly and as low as
possible around the hips, not around the waist. Failure to
position the lap belt correctly may cause serious injury in an
accident.

Insert the tongue into the correct
buckle (the buckle closest to the
direction the tongue is coming
from). To lengthen the belt, turn the
tongue at a right angle to the belt
and pull across your lap until it
reaches the buckle.

To tighten the belt, pull the loose
end of the belt through the tongue
until it fits snugly across the hips.

Shorten and fasten the belt when not in use to keep the belt
away from door openings and available after unfolding the seats.

Adjusting the rear center facing jump seat lap belt (if equipped)

The center facing rear jump seat lap belt will adjust automatically. To
fasten, grasp the tongue, and with a continuous motion, pull out enough
webbing to buckle the tongue into the correct buckle. If you did not pull
out enough webbing to reach the buckle, allow the tongue to retract fully
before trying to pull it out again.

WARNING: The lap belts should fit snugly and as low as
possible around the hips, not around the waist. Failure to
position the lap belt correctly may cause serious injury in an
accident.

Mazda B4000 4WD Truck (2004 year). Instruction - part 4
