Mazda 5 (2017 year). Instruction

Black plate (264,1)

6. When the programming is completed,

“ ” and “PAIR SUCCESS” are
displayed after about 10-30 seconds,
after which

“PAIR SUCCESS”

continues to be displayed for three
seconds, and then the unit returns to the
normal display.

NOTE

If pairing cannot be completed, try

“1234”

instead. Refer to the owner's manual of
your mobile device for the right PIN code.

Some Bluetooth

audio devices need a

certain amount of time before the

“ ”

symbol is displayed.

If the programming failed,

“Err” flashes

for three seconds then it returns to
“PAIR DEVICE”.

Programming cannot be performed while
the vehicle is moving. If you attempt to
perform programming while the vehicle is
moving,

“PAIR DISABLE” is displayed and

it returns to

“PAIR DEVICE”.

If seven Bluetooth

audio devices have

already been programmed to the vehicle,
programming cannot be performed and
“MEMORY FULL” is displayed. Delete
one programmed device to program
another one.

Changing the link to a Bluetooth

audio device

If several devices have been programmed,
the Bluetooth

unit links the device last

programmed. If you would like to link a
different programmed device, it is
necessary to change the link. The order of
device priority after the link has been
changed is maintained even when the
ignition is switched off.

1. Using the audio control dial, select the

link change mode

“LINK CHANGE”

in the

“BT SETUP” mode. (Refer to

“Bluetooth

audio device set-up

” for

details.)

2. Press the audio control dial to

determine the mode.

3. The name of the currently linked

Bluetooth

audio device is displayed.

If no Bluetooth

audio device is

currently linked, the name of the first
device among the programmed devices
is displayed.

6-66

Interior Comfort

Bluetooth® Audio

Mazda5_8FN4-EA-16G_Edition1 Page264
Monday, May 23 2016 7:36 PM

Black plate (265,1)

4. Turn the audio control dial to select the

name of the device you would like to
link.

Device name 1

Device name 2

Device name 3

Device name 4

Device name 5

Device name 6

Device name 7

5. Press the audio control dial to select the

device you would like to link.
The

“ ” symbol disappears, and

“PAIRING” flashes in the display.

NOTE

When

“GO BACK” is selected and the audio

control dial is pressed, the display returns to
“LINK CHANGE”.

6. If the link to the desired device is

successful, the

“ ” symbol is

displayed again, together with

“LINK CHANGED”.

“LINK CHANGED” is displayed for
three seconds, then it returns to the
normal display.

NOTE

Some Bluetooth

audio devices need a

certain amount of time before the

“ ”

symbol is displayed.

If a hands-free type mobile phone has been
the most recently programmed device, the
Bluetooth

unit links this device. If you

would like to use a Bluetooth

audio type

device which has been previously
programmed to the Bluetooth

unit, the link

must be changed to this device.

If an error occurs while trying to link a
device,

“Err” flashes in the display for

three seconds, and the display returns to
“LINK CHANGE”. If this occurs, check the
programming status of the Bluetooth

audio device and the location of the device
in the vehicle (not in the trunk or a metal-
type box), and then try the link operation
again.

Device selection can also be done using
voice recognition (page 6-86).

How to confirm the device currently
linked

Switch to the link-change mode. (Refer to

“Changing the link to a Bluetooth

audio

device

”)

The device name displayed first is the
device which is currently linked.

Deleting the link to a Bluetooth

audio

device

1. Using the audio control dial, select the

pairing delete mode

“PAIR DELETE”

in the

“BT SETUP” mode. (Refer to

“Bluetooth

audio device set-up

” for

details.)

2. Press the audio control dial to

determine the mode.

3. The name of the first device among the

programmed devices is displayed.

Interior Comfort

Bluetooth® Audio

6-67

Mazda5_8FN4-EA-16G_Edition1 Page265
Monday, May 23 2016 7:36 PM

Black plate (266,1)

4. Rotate the audio control dial and select

the name of the programmed device
you would like to delete.

Device name 1

Device name 2

Device name 3

Device name 4

Device name 5

Device name 6

Device name 7

NOTE

Only the names of programmed devices can be
displayed. If only one device is programmed,
only the name for this device is displayed.

5. If a selection other than

“GO BACK”

is made and the audio control dial is
pressed,

“SURE ? NO” is displayed.

6. Rotate the audio control dial clockwise

and switch the display to

“SURE ?

YES

”.

NOTE

The display changes as follows depending on
whether the audio control dial is rotated
clockwise or counterclockwise.
-Clockwise:

“SURE ? YES” displayed

-Counterclockwise:

“SURE ? NO” displayed

7. Press the audio control dial to delete

the selected device.

NOTE

Select

“GO BACK” and press the audio

control dial to return to the

“PAIR DELETE”

display.

“PAIR DELETED” is displayed for
three seconds after the deletion is
completed, and then it returns to the
normal display.

NOTE

If an error occurs while trying to delete the
programmed device,

“Err” flashes in the

display for three seconds and the display
returns to

“LINK DELETE”.

Bluetooth

audio device information

display

1. Using the audio control dial, select the

pair device information display mode

“DEVICE INFO” in the “BT SETUP”
mode. (Refer to

“Bluetooth

audio

device set-up

” for details.)

2. Press the audio control dial to

determine the mode.

3. The name of the Bluetooth

unit

device is displayed.

6-68

Interior Comfort

Bluetooth® Audio

Mazda5_8FN4-EA-16G_Edition1 Page266
Monday, May 23 2016 7:36 PM

Black plate (267,1)

4. Rotate the audio control dial to select

the information for the Bluetooth

unit

which you would like to view.

Device name

BT address

NOTE

When

“GO BACK” is selected and the audio

control dial is pressed, the display returns to
“DEVICE INFO”.

qHow to Use the Bluetooth®

Audio System

Switching to Bluetooth

audio mode

To listen to music or voice audio recorded
to a Bluetooth

audio device, switch to

the Bluetooth

audio mode to operate the

audio device using the audio system
control panel.
Any Bluetooth

audio device must be

programmed to the vehicle's Bluetooth

unit before it can be used. (Refer to

“Bluetooth

audio device programming

”)

1. Switch the ignition to ACC or ON.

2. Turn on the Bluetooth

audio device's

power.
Make sure that the

“ ” symbol is

displayed in the information display.
The symbol is not displayed if an
unprogrammed Bluetooth

audio

device is being used or the vehicle's
Bluetooth

unit has a malfunction.

NOTE

Some Bluetooth

audio devices need a certain

amount of time before the

“ ” symbol is

displayed.

3. Press the source change button (

) to

switch to the Bluetooth

audio mode

and start playback.
If the current device version is lower
than AVRCP Ver. 1.3:

“BT Audio” is displayed.
If the current device is AVRCP Ver.
1.3:
The playback time is displayed.

NOTE

If the Bluetooth

audio device does not

begin playback, press the Play/Pause
button (

If the mode is switched from Bluetooth

audio mode to another mode (radio mode),
audio playback from the Bluetooth

audio

device stops.

If a call is received on a hands-free mobile
phone during playback from the Bluetooth

audio device, the playback is stopped.
Playback from the Bluetooth

audio device

resumes after the call ends.

Playback

1. To listen to a Bluetooth

audio device

over the vehicle's speaker system,
switch the mode to Bluetooth

audio

mode. (Refer to

“Switching to

Bluetooth

audio mode

”)

2. To stop playback, press the Play/Pause

button (

3. Press the button again to resume

playback.

Interior Comfort

Bluetooth® Audio

6-69

Mazda5_8FN4-EA-16G_Edition1 Page267
Monday, May 23 2016 7:36 PM

Black plate (268,1)

Selecting a file (track)

Short-press the track down button (

) or

turn the file dial counterclockwise: Selects
the beginning of the current file (track).
Short-press the track up button (

) or

turn the file dial clockwise: Selects the
next file (track).

Fast-forward/Reverse (only AVRCP
Ver. 1.3)

Fast-forward

Press and hold the track up button (

Reverse

Press and hold the track down button
(

Switching the display (only AVRCP
Ver. 1.3)

For files with a song title and other
information that have been input, the
display switches between display of the
song title and other information each time
the text button (

) is pressed during

playback.

Album title

Song title

Artist name

File number/ Playback time

NOTE

If title information is not available,
“NO TITLE” is displayed.

This unit cannot display some characters.
Characters which cannot be displayed are
indicated by an asterisk (

Display scroll

Only 12 characters can be displayed at
one time. To display the rest of the
characters of a long title, short-press the
scroll button (

). The display scrolls

the next 12 characters. Short-press the
scroll button (

) again after the last

12 characters have been displayed to
return to the beginning of the title.

6-70

Interior Comfort

Bluetooth® Audio

Mazda5_8FN4-EA-16G_Edition1 Page268
Monday, May 23 2016 7:36 PM

Black plate (269,1)

Bluetooth® Hands-Free

qWhat is Bluetooth® Hands-Free?

Bluetooth

Hands-Free Outline

By connecting a Bluetooth

equipped

device (Mobile phone) to the hands-free
unit equipped on the vehicle, making and
receiving calls is possible using the talk
button, pick-up button and hang-up button
located on the steering wheel, and saying
the voice commands.

WARNING

Perform phonebook registration related
operations while the vehicle is parked:

Performing phonebook registration
while driving the vehicle could be a
distraction to your driving and result
in an accident. In addition, a mistake
in performing the phonebook
operation could result in the loss of
important data.

Bluetooth

equipped device (Mobile

phone)

A Bluetooth

equipped device (Mobile

phone) communicates with the hands-free
unit equipped on the vehicle using radio
transmission (Bluetooth

For example, if the device (Mobile phone)
is placed in a coat pocket, the phone calls
can be made through your mobile service
without taking out and handling the
device (Mobile phone).

CAUTION

The types of devices (Mobile phone)
which can be connected to the
hands-free unit are limited.
Therefore, before purchasing or
changing your device (Mobile phone)
model, consult Mazda Bluetooth

Hands-Free Customer Service or visit
www.MazdaUSA.com/bluetooth for a
complete list of compatible phones.
Devices (Mobile phone) which can be
connected to the hands-free system
need to be compliant with
Bluetooth

specifications and the

appropriate profile. However, even
among these Bluetooth

devices

(Mobile phone) are some which will
not connect with your Mazda or will
have limited function. Therefore,
consult Mazda Bluetooth

Hands-

Free Customer Service for
information regarding device (Mobile
phone) compatibility:
Phone:800-430-0153
Web: www.mazdahandsfree.ca

Applicable Bluetooth

specification

Ver. 2.0 or higher
Response profile

HFP (Hands Free Profile) Ver. 1.5

DUN (Dial-up Networking Profile)
Ver. 1.1

PBAP (Phone Book Access Profile)
Ver. 1.0

A2DP (Advanced Audio Distribution
Profile) Ver. 1.0

OPP (Object Push Profile) Ver. 1.1

Interior Comfort

Bluetooth® Hands-Free

6-71

Some models.

Mazda5_8FN4-EA-16G_Edition1 Page269
Monday, May 23 2016 7:36 PM

Black plate (270,1)

NOTE

The Bluetooth

Hands-Free system is

operable several seconds after the ignition
is switched to ACC or ON (requires less
than 15 seconds).

If the ignition is switched off during a
hands-free call, the line is transferred to the
device (Mobile phone) automatically.

If the device (Mobile phone) is in a location
where radio reception is difficult such as a
metal container or in the trunk, the call may
not be connected using Bluetooth

. If

communication is not possible, change the
location of the device (Mobile phone).

qComponent Parts

Bluetooth

Hands-Free consists of the

following items:

Talk button

Pick-up button

Hang-up button

Information display

Microphone

Audio unit

Talk button, Pick-Up button and Hang-
Up button

Basic functions of Bluetooth

Hands-Free

can be used for such things as making
calls or hanging up using the talk button,
pick-up button and hang-up button on the
steering wheel.

NOTE

The talk button, pick-up button, and hang-up
button are operable with the audio unit turned
off.

Talk button

Hang-up
button

Pick-up button

Talk button operations

A short press or a long press of the talk
button is used to operate the system as
follows:

Short press (Press the button less than
0.7 sec.)

Long press (Press the button 0.7 sec. or
more.)

Information display

When available, the information display
shows telephone numbers, Bluetooth

Hands-Free messages, and operation
status.

Bluetooth phone connected

6-72

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page270
Monday, May 23 2016 7:36 PM

Black plate (271,1)

Microphone

The microphone is used for speaking
voice commands or exchanging
conversation.

Microphone

Audio unit

The audio unit is used for adjusting the
volume.

qVoice

To prevent the deterioration in voice
recognition rate and voice quality, the
following points must be observed:

It is not necessary to face the
microphone or approach it. Speak the
voice commands while maintaining a
safe driving position.

Close the windows and/or the
moonroof to reduce loud noises from
outside the vehicle, or turn down the
airflow of the climate control system
while Bluetooth

Hands-Free is being

used. Voice recognition may not
function correctly or voice quality may
deteriorate under the following
conditions.

A passenger is speaking.

Driving with the window and/or the
moonroof open.

Driving on bumpy roads.

Noise outside of the vehicle is loud.
(Construction sites, inside tunnels,
excess oncoming traffic, or heavy
rain.)

Operation noise from turn signals,
wipers, or the horn is heard.

A/C airflow is strong or wind is
blowing on the microphone.

There is noise coming from cargo
loaded in the vehicle.

Voice commands may not be
recognized depending on the voice. If
the voice commands are not recognized
correctly, repeat the commands in a
louder voice, at a natural pace, as if
speaking to another person.

Dialects or different wording other than
hands-free prompts cannot be
recognized by voice recognition. Speak
in the wording specified by the voice
commands.

NOTE

If the voice recognition performance is not
satisfactory, refer to

“Voice Recognition

Learning Function (Speaker Enrollment)

”

(page 6-90).

Please be aware that the voice recognition
may still make an error despite following
the previous points.

Interior Comfort

Bluetooth® Hands-Free

6-73

Mazda5_8FN4-EA-16G_Edition1 Page271
Monday, May 23 2016 7:36 PM

Black plate (272,1)

qFunction Restrictions While

Using Bluetooth® Hands-Free

Some functions are limited while
Bluetooth

Hands-Free is being used.

They include:

Beep sound and voice guidance related
to the audio unit are not heard.

Beep sound related to the A/C
operation is not heard.

qHow to Use This Section

Descriptions in the text are as follows:
Say: Voice commands to be spoken by
you.
Prompt: Voice guidance output from the
speaker.

NOTE

Say voice commands after the beep sound
[Beep] is heard.

Example)
Say: [Beep]

“Dial”

Prompt:

“Number, please”

Say: [Beep]

“XXXXXXXXXXX (Ex.

“555-1234”) (Telephone number)”

Bluetooth

Hands-Free Activation

Method

Press the pick-up button or talk button
with a short press.
The hands-free system is activated.
Functions of the hands-free telephone,
such as making and receiving calls, can be
used after the activation. (For details on
the telephone functions, refer to

“Basic

Bluetooth

Hands-Free Operation

” or

“Convenient Use of the Hands-Free
System

”.)

Tutorial

The tutorial explains how to use
Bluetooth

Hands-Free.

To activate the tutorial, do the following:

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Tutorial”

3. Follow the prompts to receive the

appropriate voice guidance
instructions.

qUseful Commands at Anytime,

Convenient Operations

Help function use

The help function informs the user of all
the available voice commands under the
current conditions.

1. Press the talk button with a short press.

2. Say: [Beep]

“Help”

3. Follow the prompts to receive the

appropriate voice guidance
instructions.

Cancel

The Bluetooth

Hands-Free system

transitions to standby status if the
following operation is performed while
the system is activating.
Press the hang-up button, or the talk
button with a long press.

Returning to previous operation

This command is for returning to the
previous operation while in the voice
recognition mode.
Say: [Beep]

“Go Back”

6-74

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page272
Monday, May 23 2016 7:36 PM

Black plate (273,1)

Voice guidance interrupt operation

Voice guidance can be skipped by
pressing the talk button with a short press
while it is being heard. A new voice input
command can then be spoken by the user.

Voice recognition mode cancel

If you want to cancel the voice
recognition mode during a call, the voice
recognition mode can be canceled without
having to end the call.
Press the talk button with a long press.

Basic Bluetooth® Hands-
Free Operation

qBluetooth® Hands-Free Preparation

Language setting

The available languages are English,
Spanish, and Canadian French. If the
language setting is changed, all of the
voice guidance and voice input
commands are done in the selected
language.

NOTE

If the language setting is changed, device
registration is maintained.
Phonebook records are not cleared, but
each language has a separate phonebook.
Therefore, entries created in one language
will need to be re-entered in the phonebook
of the new language.

Do these steps before you start driving.
These less used functions are too
distracting to undertake while driving until
you are fully familiar with the system.

Method 1

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Language”

5. Prompt:

“Select a language: English,

French, or Spanish.

”

6. Say: [Beep]

“French” (Speak the

desired language:

“English”, “French”

“Spanish”)

Interior Comfort

Bluetooth® Hands-Free

6-75

Mazda5_8FN4-EA-16G_Edition1 Page273
Monday, May 23 2016 7:36 PM

Black plate (274,1)

NOTE

Other language settings can also be made
while in the current setting by saying the name
of the language in the native pronunciation.

7. Prompt:

“French (Desired language)

selected. Is this correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Please wait. Switching to

French phonebook. French selected.

”

(Spoken in the newly selected
language).

Method 2

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“French” (Say the desired

language:

“English”, “French”, or

“Spanish”.) (Change the desired
language by saying the language
name.)

NOTE

Other language settings can also be made
while in the current setting by saying the name
of the language in the native pronunciation.

3. Prompt:

“Would you like to change

the language to French (Desired
language)?

”

4. Say: [Beep]

“Yes”

5. Prompt:

“Please wait. Switching to

French phonebook. French selected.

”

(Spoken in the newly selected
language).

Pairing code setting

The 4-digit pairing code setting for
registration of your cell phone (pairing)
can be set beforehand.

NOTE

The initial setting value is

“0000”.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.

”

6. Say: [Beep]

“Set pairing code”

7. Prompt:

“Your current pairing code is

XXXX. Do you want to change it to a
different pairing code?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Please say a 4-digit pairing

code.

”

10. Say: [Beep]

“YYYY”

11. Prompt:

“YYYY is this correct?”

12. Say: [Beep]

“Yes” or “No”

13. If

“Yes”, go to Step 14. If “No”, the

procedure returns to Step 9.

14. Prompt:

“Your new pairing code is

YYYY. Use this pairing code when
pairing devices to the Hands free
system. Do you want to pair a device
now?

”

15. Say: [Beep]

“Yes” or “No”

16. If

“Yes”, the system switches to the

device registration mode. If

“No”, the

system returns to standby status.

6-76

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page274
Monday, May 23 2016 7:36 PM

Black plate (275,1)

Device programming (Pairing)

To use Bluetooth

Hands-Free, the device

equipped with Bluetooth

has to be

programmed to the hands-free unit using
the following procedure.
A maximum of seven devices including
hands-free mobile phones and Bluetooth

audio devices can be programmed to one
vehicle.

NOTE

A device can be programmed only when the
vehicle is parked. If the vehicle starts to
move, the pairing procedure will end.
Programming is dangerous while driving -
pair up your device before you start
driving. Park the car in a safe place before
programming.

If a Bluetooth

device has already been

programmed to the vehicle as a Bluetooth

audio device, it does not need to be
programmed again when using the device
as a hands-free mobile phone. Conversely,
it does not need to be programmed again as
a Bluetooth

audio device if it has already

been programmed as a hands-free mobile
phone.

Since the communication range of a
Bluetooth

equipped device is about 10

meters (32 ft), if a device is placed within a
10-meter (32 ft) radius of the vehicle, it may
be detected/programmed unintentionally
while another device is being programmed.

1. Activate the Bluetooth

application of

the device.

NOTE

For the operation of the device, refer to its
instruction manual.

2. Press the pick-up button or talk button

with a short press.

3. Say: [Beep]

“Setup”

4. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

5. Say: [Beep]

“Pairing options”

6. Prompt:

“Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.

”

7. Say: [Beep]

“Pair”

8. Prompt:

“Start the pairing process on

your Bluetooth

device. Your pairing

code is 0000 (XXXX). Input this code
on your Bluetooth

device when

prompted on the device. See device
manual for instructions.

”

9. Using the device, perform a search for

the Bluetooth

device (Peripheral

device).

NOTE

For the operation of the device, refer to its
instruction manual.

10. Select

“Mazda” from the device list

searched by the device.

11. Input the 4-digit pairing code to the

device.

12. Prompt:

“Please say the name of the

device after the beep.

”

13. Say: [Beep]

“XXXX - - -” (Speak a

“device tag”, an arbitrary name for
the device.)
Example:

“Stan's device.”

NOTE

Speak a programmed

“device tag” within 10

seconds.
If more than two devices are to be
programmed, they cannot be programmed with
the same or similar

“device tag”.

Interior Comfort

Bluetooth® Hands-Free

6-77

Mazda5_8FN4-EA-16G_Edition1 Page275
Monday, May 23 2016 7:36 PM

Black plate (276,1)

14. Prompt:

“XXXXXX - - - (Ex.

“Stan's device”) (Device tag). Is this
correct?

”

15. Say: [Beep]

“Yes”

16. Prompt:

“Pairing complete”

After a device is registered, the system
automatically identifies the device. By
activating Bluetooth

Hands-Free again,

or by activating Bluetooth

Hands-Free

first after switching the ignition from OFF
to ACC, the system reads out a voice
guidance,

“XXXXXX - - - (Ex. “Stan's

device

”) (Device tag) is connected”.

NOTE

Device registration can also be done by
operating the audio unit.
Refer to Bluetooth® Audio Preparation on
page 6-63.

Depending on the device, the registration
status may be lost after a certain period of
time. If this occurs, repeat the entire
process from Step 1.

qMaking a Call Using a Telephone

Number

NOTE

Practice this while parked until you are
confident you can do it while driving in a non-
taxing road situation. If you are not completely
comfortable, make all calls from a safe
parking position, and move out only when fully
under control and you can devote your eyes
and mind to driving.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Dial”

3. Prompt:

“Number, please”

4. Say: [Beep]

“XXXXXXXXXXX

(Telephone number)

”

5. Prompt:

“XXXXXXXXXXX.

(Telephone number) After the beep,
continue to add numbers, or say Go-
Back to re-enter the last entered
numbers, or press the Pick-Up button
to execute dialing.

”

6. (Dialing)

Press the pick-up button or say

“Dial”,

then go to Step 7.
(Adding/inputting telephone
number)
Say,

“XXXX” (desired telephone

number), then go to Step 5.
(Telephone number correction)
Say,

“Go Back”. The prompt replies,

“Go Back. The last entered numbers
have been removed.

”. Then go back to

Step 3.

7. Prompt:

“Dialing”

NOTE

The

“Dial” command and a telephone number

can be combined.
Ex. In Step 2, say,

“Dial 123-4567”, then,

Steps 3 and 4 can be skipped.

6-78

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page276
Monday, May 23 2016 7:36 PM

Black plate (277,1)

qReceiving an Incoming Call

1. Prompt:

“Incoming call, press the

pickup button to answer

”.

2. To accept the call, press the pick-up

button.
To reject the call, press the hang-up
button.

Pick-up button

Hang-up
button

qHanging Up a Call

Press the hang-up button during the call.
A beep sound will confirm that call is
ended.

qVolume Adjustment

The power/volume dial of the audio unit
is used to adjust the volume. Turn the dial
to the right to increase volume, to the left
to decrease it.

NOTE

The volume can also be adjusted using the
volume button on the steering wheel.

The music volume of the audio unit cannot
be adjusted while Bluetooth Hands-Free is
being used.

Interior Comfort

Bluetooth® Hands-Free

6-79

Mazda5_8FN4-EA-16G_Edition1 Page277
Monday, May 23 2016 7:36 PM

Black plate (278,1)

Convenient Use of the
Hands-Free System

qPhonebook Usage

Phonebook registration

Phone numbers can be registered to the
Bluetooth

Hands-Free phonebook.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“New entry”

5. Prompt:

“Name please.”

6. Say: [Beep]

“XXXXX... (Ex. “Mary's

phone

”)” (Say a voice tag for the name

registered.)

7. Prompt:

“Adding XXXXX... (Ex.

“Mary's phone”) (Registered voice
tag). Is this correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Home, Work, Mobile, or

Other?

”

10. Say: [Beep]

“Mobile” (Say “Home”,

“Work”, “Mobile”, or “Other”, for the
desired location to be registered.)

11. Prompt:

“Mobile (Location to be

registered). Is this correct?

”

12. Say: [Beep]

“Yes”

13. Prompt:

“Number, please.”

14. Say: [Beep]

“XXXXXXXXXXX”

(Say the phone number to be
registered.)

15. Prompt:

“XXXXXXXXXXX

(Phone number registration). After the
beep, continue to add numbers, or say
Go-Back to re-enter the last entered
numbers, or press the Pick-Up button
to save the number.

”

16. (Registration)

Press the pick-up button or say

“Enter”, then go to Step 17.
(Adding/inputting telephone
number)
Say,

“XXXX” (desired telephone

number), then go to Step 15.
(Telephone number correction)
Say,

“Go Back”. The prompt replies,

“Go Back. The last entered numbers
have been removed.

”. Then go back

to Step 13.

17. Prompt:

“Number saved. Would you

like to add another number for this
entry?

”

18. Say: [Beep]

“Yes” or “No”.

19. If

“Yes”, an additional phone number

registration can be made for the same
entry.
If

“No”, the system returns to standby

status.

Import contact

Phonebook data from your device (Mobile
phone) can be sent and registered to your
Bluetooth

Hands-Free phonebook using

Bluetooth

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

6-80

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page278
Monday, May 23 2016 7:36 PM

Black plate (279,1)

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“Import contact”

5. Prompt:

“The hands free System is

ready to receive a contact from a
phone. Only a home, a work, and a
mobile number can be imported. This
process requires operation of a mobile
phone. Refer to the phone's manual for
more information.

”

6. Device (Mobile phone) operation:

Select one entry from the phonebook
and send it using Bluetooth

7. Prompt:

“X (Number of locations

which include data) numbers have been
imported. What name would you like
to use for these numbers?

”

8. Say: [Beep]

“XXXXX... (Ex. “Mary's

phone

”)” (Say a voice tag for the name

registered.)

9. Prompt:

“Adding XXXXX... (Ex.

“Mary's phone”) (Voice tag). Is this
correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“Number saved. Would you

like to import another contact?

”

12. Say: [Beep]

“Yes” or “No”

13. If

“Yes”, the procedure proceeds to

Step 5.
If

“No”, the system returns to standby

status.

Making calls using the phonebook

Telephone calls can be made by saying
the name of a person (voice tag) whose
phone number has been registered in
Bluetooth

Hands-Free in advance.

For the phonebook setting method, refer
to (page 6-84).

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Call”

3. Prompt:

“Name please.”

4. Say: [Beep]

“XXXXX... (Ex. “John's

phone

”)” (Say a voice tag registered in

the phonebook.)

5. Prompt:

“Calling XXXXX... (Ex.

“John's phone”) XXXX (Ex. “at
home

”). Is this correct?” (Voice tag and

phone number location registered in
phonebook).

6. Say: [Beep]

“Yes”

7. Prompt:

“Dialing”

NOTE

The

“Call” command and the voice tag can be

combined.
Ex. In Step 2, say,

“Call John's phone”, then,

Steps 3 and 4 can be skipped.

qRedialing Function

Redialing the number of the person
previously dialed using the phone is
possible.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Redial”

3. Prompt:

“Dialing”

Interior Comfort

Bluetooth® Hands-Free

6-81

Mazda5_8FN4-EA-16G_Edition1 Page279
Monday, May 23 2016 7:36 PM

Mazda 5 (2017 year). Instruction - part 17
