Black plate (248,1)

qChanging the Source

Press the mode switch (

) to change

the audio source (FM1 radio

→ FM2

radio

→ AM radio → CD player →

SIRIUS1

→ SIRIUS2 → SIRIUS3 →

AUX

→ BT audio → USB/iPod →

cyclical).
Without Bluetooth® Hands-Free

With Bluetooth® Hands-Free

NOTE

CD, USB, iPod, SIRIUS digital satellite radio,
and BT audio modes cannot be selected in the
following cases:

USB device, iPod, SIRIUS digital satellite
radio unit, or BT audio unit is not equipped
on the audio system.

CD has not been inserted.

The AUX mode is unavailable unless you
connect a commercially available portable
audio unit (such as an MP3 player) to the
auxiliary jack. Connect a portable audio unit
or similar product on the market to the
auxiliary jack to listen to music or audio over
the vehicle's speakers. Change the audio
source to AUX mode (page 6-52).

qSeek Switch

Without Bluetooth® Hands-Free

6-50

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page248
Monday, May 23 2016 7:35 PM

Black plate (249,1)

With Bluetooth® Hands-Free

When listening to the radio or SIRIUS
digital satellite radio

Press the seek switch up or down. The
radio switches to the next/previous stored
station in the order that it was stored
(1

―6).

(Radio)
Press and hold the seek switch in the up or
down position to seek all usable stations
at a higher or lower frequency whether
programmed or not.
(SIRIUS digital satellite radio)
Press and hold the seek switch in the up or
down position to seek all usable stations
at a higher or lower channel whether
programmed or not.

NOTE

During radio reception
Radio stations which have been previously
stored in the auto memory tuning can be called
up by pressing the seek switch up or down
while any radio station stored in the auto
memory tuning is being received. Radio
stations can be called up in the order they
were stored with each press of the switch up or
down.

When playing a CD, USB, iPod, or BT
audio

Press the seek switch up to skip to the
next track.
Press the seek switch down to repeat the
current track.
Press and hold the seek switch in the up or
down position to continuously switch the
tracks up or down.

qMute Switch

Press the mute switch ( ) once to mute
audio, press it again to resume audio
output.

NOTE

If the ignition is switched off with the audio
muted, the mute will be canceled.
Therefore, when the engine is restarted, the
audio is not muted. To mute the audio again,
press the mute switch (

Without Bluetooth® Hands-Free

Interior Comfort

Audio System

6-51

Some models.

Mazda5_8FN4-EA-16G_Edition1 Page249
Monday, May 23 2016 7:35 PM

Black plate (250,1)

AUX/USB/iPod Mode

Audio can be heard from the vehicle's
speakers by connecting a commercially-
available portable audio unit to the
auxiliary jack.
A commercially-available, non-impedance
(3.5 ) stereo mini plug cable is required.
Contact an Authorized Mazda Dealer for
details.
In addition, audio can be played from the
vehicle audio device by connecting USB
device or an iPod to the USB port.
To use the auxiliary jack/USB port, pull
up its cover.

USB port

Auxiliary jack

How to use AUX mode ....... page 6-53
How to use USB mode ........ page 6-54
How to use iPod mode ......... page 6-58
Error Indications .................. page 6-60

WARNING

Do not adjust the portable audio unit
or a similar product while driving the
vehicle:

Adjusting the portable audio unit or
a similar product while driving the
vehicle is dangerous as it could
distract your attention from the
vehicle operation which could lead to
a serious accident. Always adjust the
portable audio unit or a similar
product while the vehicle is stopped.

Do not allow the connection plug cord
to get tangled with the parking brake
or the shift lever:

Allowing the plug cord to become
tangled with the parking brake or
the shift lever is dangerous as it
could interfere with driving, resulting
in an accident.

CAUTION

Ø Always close the auxiliary jack/

USB port lid when it is not in use.
If foreign matter or liquid
penetrate the auxiliary jack/USB
port, it may cause a malfunction.

Ø Depending on the portable audio

device, noise may occur when the
device is connected to the vehicle
accessory socket. (If noise occurs,
do not use the accessory socket.)

Ø Do not place objects or apply force

to the auxiliary jack with the plug
connected.

6-52

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page250
Monday, May 23 2016 7:35 PM

Black plate (251,1)

NOTE

This mode may not be usable depending on
the portable audio device to be connected.

Before using the auxiliary jack/USB port,
refer to the instruction manual for the
portable audio device.

Use a commercially-available, non-
impedance (3.5

) stereo mini plug for

connecting the portable audio unit to the
auxiliary jack. Before using the auxiliary
jack, read the manufacturer's instructions
for connecting a portable audio unit to the
auxiliary jack.

To prevent discharging of the battery, do
not use the auxiliary input for long periods
with the engine off or idling.

When connecting a device to the auxiliary
jack or USB port, noise may occur
depending on the connected device. If the
device is connected to the vehicle's
accessory socket, the noise can be reduced
by unplugging it from the accessory socket.

Insert the plug to the auxiliary jack/USB
port securely.

Insert or pull out the plug with the plug
perpendicular to the auxiliary jack/USB
port hole.

Insert or remove the plug by holding its
base.

qHow to use AUX mode

Audio Unit

Audio Control
Switches

1. Switch the ignition to ACC or ON.

2. Press the power/volume dial to turn the

audio system on.

3. Press the source change button (

) of

the audio unit or the mode switch
(

) of the audio control switches

on the steering wheel to change to the
AUX mode.

NOTE

When the device is not connected to the
auxiliary jack, the mode does not switch to
the AUX mode.

Set the volume of the portable audio unit to
the maximum within the range that the
sound does not become distorted, then
adjust the volume using the power/volume
dial of the audio unit or the up/down switch
of the audio control switch.

Audio adjustments other than audio volume
can only be done using the portable audio
device.

If the connection plug is pulled out from the
auxiliary jack while in AUX mode, noise
may occur.

Interior Comfort

Audio System

6-53

Mazda5_8FN4-EA-16G_Edition1 Page251
Monday, May 23 2016 7:35 PM

Black plate (252,1)

qHow to use USB mode

Play/Pause button/File dial

Track up/Fast-forward button

Folder up button

Repeat button

Random button

Scan button

Track down/Reverse button

Source change button

Scroll button

Folder down button

Text button

Type

Playable data

USB mode

MP3/WMA/AAC file

Playback

1. Switch the ignition to ACC or ON.

2. Press the power/volume dial to turn the

audio system on.

3. Press the source change button (

) of

the audio unit or the mode switch
(

) of the audio control switches

on the steering wheel to switch to the
USB mode and start playback.

NOTE

When the USB device is not connected, the
mode does not switch to USB mode.

When there is no playable data in the USB
device,

“NO CONTENTS” is indicated.

Playback of the USB device is in the order
of the folder numbers. Folders which have
no MP3/WMA/AAC files are skipped.

Do not remove the USB device while in the
USB mode. The data may be damaged.

Pause

To stop playback, press the Play/Pause
button (

Press the button again to resume
playback.

Fast-forward/Reverse

Press and hold the fast-forward button
(

) to advance through a track at high

speed.

6-54

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page252
Monday, May 23 2016 7:35 PM

Black plate (253,1)

Press and hold the reverse button (

) to

reverse through a track at high speed.

Track search

Press the track up button (

) once to

skip forward to the beginning of the next
track.
Press the track down button (

) within a

few seconds after playback begins to track
down to the beginning of the previous
track.
Press the track down button (

) after a

few seconds have elapsed to start
playback from the beginning of the
current track.

Folder search

To change to the previous folder, press the
folder down button (

), or press the

folder up button (

) to advance to the

next folder.

Music Scan

This function scans the titles in a folder
currently being played and plays ten
seconds of each song to aid you in finding
a song you want to listen to.
Press the scan button (

) during

playback to start the scan play operation
(the track number will flash). Press the
scan button (

) again to cancel scan

playback.

NOTE

If the unit is left in scan, normal playback will
resume where scan was selected.

Repeat playback

(Track repeat)

1. Press the repeat button (

) during

playback to play the current track
repeatedly.

“TRACK RPT” is

displayed.

2. To cancel the repeat playback, press the

button again after 3 seconds.

(Folder repeat)

1. Press the repeat button (

) during

playback, and then press the button
again within 3 seconds to play the
tracks in the current folder repeatedly.

“FOLDER RPT” is displayed.

2. Press the button again to cancel the

repeat playback.

Random playback

Tracks are randomly selected and played.

(Folder random)

1. Press the random button (

) during

playback to play the tracks in the folder
randomly.

“FOLDER RDM” is

displayed.

2. To cancel the random playback, press

the button again after 3 seconds.

(All random)

1. Press the random button (

) during

playback, and then press the button
again within 3 seconds to play the
tracks on the USB device randomly.

“ALL RDM” is displayed.

2. Press the button again to cancel the

random playback.

Interior Comfort

Audio System

6-55

Mazda5_8FN4-EA-16G_Edition1 Page253
Monday, May 23 2016 7:35 PM

Black plate (254,1)

Switching the display

For files with a file name and other
information that have been input, the
display switches between display of the
file name and other information each time
the text button (

) is pressed during

playback.

File name

Folder name

Album name

Song name

Artist name

Folder number/File number

File number/Elapsed time

NOTE

The information (artist name, music name)
is displayed only when the USB device
information in the USB device has
information which can be displayed on the
screen.

This unit cannot display some characters.
Characters which cannot be displayed are
indicated by an asterisk (

Display scroll

Only 12 characters can be displayed at
one time.

To display the rest of the characters of a
long title, press the scroll button (

The display scrolls the next 12 characters.
Press the scroll button (

) again after

the last 12 characters have been displayed
to return to the beginning of the title.

NOTE

The number of characters which can be
displayed is restricted.

Error Messages

When the message

“CHECK USB” is

displayed, it indicates that there is some
error in the USB device. Verify that the
content recorded in the USB device has
MP3/WMA/AAC files and re-connect
correctly. If the message reappears, have
the unit checked by an Authorized Mazda
Dealer.

6-56

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page254
Monday, May 23 2016 7:35 PM

Black plate (255,1)

MEMO

6-57

Mazda5_8FN4-EA-16G_Edition1 Page255
Monday, May 23 2016 7:35 PM

Black plate (256,1)

qHow to use iPod mode

Category down button

Track up/Fast-forward button

Category up button

Repeat button

List up button

Random button

Scan button

Track down/Reverse button

Play/Pause button/File dial

Source change button

Scroll button

List down button

Text button

Connectable iPod is as follows:

iPod: 5G

iPod classic

iPod nano: 1/2/3/4/5/6G

iPod touch

iPhone

: 3G/3GS/4

*1 For only iPod functions

NOTE

The iPod functions on the iPod cannot be
operated while it is connected to the unit
because the unit controls the iPod functions.

Playback

1. Switch the ignition to ACC or ON.

2. Press the power/volume dial to turn the

audio system on.

3. Press the source change button (

) of

the audio unit or the mode switch
(

) of the audio control switches

on the steering wheel to switch to the
iPod mode and start playback.

NOTE

When an iPod is not connected, the mode
does not switch to the iPod mode.

When there is no playable data in the iPod,
“NO CONTENTS” is flashed.

Do not remove the iPod while in the iPod
mode. Otherwise, the data could be
damaged.

Pause

To stop playback, press the Play/Pause
button (

Press the button again to resume
playback.

6-58

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page256
Monday, May 23 2016 7:35 PM

Black plate (257,1)

Fast-forward/Reverse

Press and hold the fast-forward button
(

) to advance through a track at high

speed.
Press and hold the reverse button (

) to

reverse through a track at high speed.

Track search

Press the track up button (

) once to

skip forward to the beginning of the next
track.
Press the track down button (

) within a

few seconds after playback begins to track
down.
Press the track down button (

) after a

few seconds have elapsed to start
playback from the beginning of the track.
The time required to track down/start
playback from the beginning of a track
varies depending on iPod software
version.

Category search

Press the category down button (

) to

select the previous category and press the
category up button (

) to select the next

category.

NOTE

The types of categories include Playlist, Artist,
Album, Song, Podcast, Genre, Composer, and
Audio book.

List search

Press the list down button (

) to select

the previous list and press the list up
button (

) to select the next list.

NOTE

When the selected category is Song or Audio
book, there is no list.

Music Scan

This function scans the titles in a list
currently being played and plays ten
seconds of each song to aid you in finding
a song you want to listen to.
Press the scan button (

) during

playback to start the scan play operation
(the track number will flash). Press the
scan button (

) again to cancel scan

playback.

NOTE

If the unit is left in scan, normal playback will
resume where scan was selected.

Repeat playback

1. Press the repeat button (

) during

playback to play the current track
repeatedly.

“RPT” is displayed.

2. Press the button again to cancel the

repeat playback.

Random playback

Tracks are randomly selected and played.

(Song random)

1. Press the random button (

) during

playback to play the tracks in the list
randomly.

“SONG RDM” is displayed.

2. To cancel the random playback, press

the button again after 3 seconds.

(Album random)

1. Press the random button (

) during

playback, and then press the button
again within 3 seconds to play the
tracks on the iPod randomly.

“ALBUM RDM” is displayed.

2. Press the button again to cancel the

random playback.

Interior Comfort

Audio System

6-59

Mazda5_8FN4-EA-16G_Edition1 Page257
Monday, May 23 2016 7:35 PM

Black plate (258,1)

NOTE

The track number being played randomly is in
the order of the iPod shuffle table.

Switching the display

For files with a file name and other
information that have been input, the
display switches between display of the
file name and other information each time
the text button (

) is pressed during

playback.

File number/Elapsed time

File number

Category (Playlist title/Genre
title/Composer title/Podcast title)

Artist name

Album name

Song name

NOTE

The information (artist name, music name)
is displayed only when the iPod has
information which can be displayed.

This unit cannot display some characters.
Characters which cannot be displayed are
indicated by an asterisk (

Display scroll

Only 12 characters can be displayed at
one time.

To display the rest of the characters of a
long title, press the scroll button (

The display scrolls the next 12 characters.
Press the scroll button (

) again after

the last 12 characters have been displayed
to return to the beginning of the title.

NOTE

The number of characters which can be
displayed is restricted.

Error Messages

If the message

“CHECK iPod” is

displayed, it indicates that there is a
malfunction in the iPod. Verify that the
content recorded in the iPod has playable
files and connect correctly. If the message
reappears, have the unit checked by an
Authorized Mazda Dealer.

qError Indications

If you see an error indication on the
display, find the cause in the chart. If you
cannot clear the error indication, take the
vehicle to an Authorized Mazda Dealer.

Indication

Cause

Solution

CHECK USB

USB device
malfunction

Verify that the content
recorded in the USB
device has
MP3/WMA/AAC files
and re-connect correctly.
If the error indication
continues to display,
consult an Authorized
Mazda Dealer.

CHECK iPod

iPod
malfunction

Verify that the content
recorded in the iPod has
playable files and
re-connect correctly.
If the error indication
continues to display,
consult an Authorized
Mazda Dealer.

6-60

Interior Comfort

Audio System

Mazda5_8FN4-EA-16G_Edition1 Page258
Monday, May 23 2016 7:35 PM

Black plate (259,1)

Safety Certification

This CD player is made and tested to meet exacting safety standards. It meets FCC
requirements and complies with safety performance standards of the U.S. Department of
Health and Human Services.

CAUTION

Ø This CD player should not be adjusted or repaired by anyone except qualified

service personnel.
If servicing is required, contact an Authorized Mazda Dealer.

Ø Use of controls or adjustments or performance of procedures other than those

specified herein may result in hazardous laser exposure. Never operate the CD
player with the top case of the unit removed.

Ø Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

NOTE

For CD player section:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

NOTE

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.

Interior Comfort

Audio System

6-61

Mazda5_8FN4-EA-16G_Edition1 Page259
Monday, May 23 2016 7:36 PM

Black plate (260,1)

Bluetooth® Audio

qWhat is Bluetooth® Audio?

Bluetooth

audio outline

By programming portable audio devices
equipped with the Bluetooth

communication function to the vehicle's
Bluetooth

unit, you can listen to music

or audio recorded on these audio devices
from the vehicle's speakers. Bluetooth

audio devices do not need to be plugged
into the auxiliary jack.
After programming, operate the audio
system's control panel to play/stop the
music or audio.

CAUTION

Ø Always program audio devices to

the Bluetooth

audio system

while the vehicle is stopped.

Ø Because only specified Bluetooth

audio devices can be used, consult
an Authorized Mazda Dealer when
purchasing or changing devices.
Bluetooth

audio devices which

correspond to specified
Bluetooth

versions and profiles

can be Bluetooth

-connected to

the vehicle's Bluetooth

unit.

However, even among these
devices are ones which cannot be
Bluetooth

-connected or have

limited functionality. Each device
to be used with the vehicle's
Bluetooth

unit needs to be

checked individually for
compatibility. Consult an
Authorized Mazda Dealer
concerning device compatibility.
Phone: 800-430-0153
Web: www.mazdahandsfree.ca

Applicable Bluetooth

specification

Ver. 2.0 or higher

Audio profile

A2DP (Advanced Audio Distribution
Profile) Ver. 1.0

AVRCP (Audio/Video Remote Control
Profile) Ver. 1.0/1.3

A2DP is a profile which transmits only
audio to the Bluetooth

unit. If your

Bluetooth

audio device corresponds only

to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, the
Bluetooth

audio device can be operated

by controlling the device itself, the same
as when a portable audio system without
the Bluetooth

communication function is

connected to the AUX terminal.

Function

A2DP

A2DP·AVRCP

Ver. 1.0

Ver. 1.3

Playback

Yes

Pause

Yes

File (Track)
up/down

Yes

Reverse

Yes

Fast-forward

Yes

Text display

Yes

Yes: Available
No: Not available

6-62

Interior Comfort

Some models.

Bluetooth® Audio

Mazda5_8FN4-EA-16G_Edition1 Page260
Monday, May 23 2016 7:36 PM

Black plate (261,1)

NOTE

The system may not operate normally
depending on the Bluetooth

audio device.

To make sure that your Bluetooth

audio

device is Ver. 1.0 or 1.3, refer to the
Owner's Manual for the Bluetooth

audio

device.

It may not be possible to play a Bluetooth

audio device if it is placed anywhere
transmission is compromised, such as
inside a metal container or the trunk. Move
the Bluetooth

audio device to a location

where transmission is possible.

Battery consumption of Bluetooth

audio

devices is higher while Bluetooth

connected.

If a non-Bluetooth

device is to be used, a

commercially-available Bluetooth

adapter

is required. When playing an audio device
with a Bluetooth

adapter installed,

programming of the audio device may not
be possible or audio may not be heard from
the vehicle speakers if the connection of the
adapter and the device is poor. If this
happens, check if the Bluetooth

adapter is

properly connected.

qBluetooth® Audio Preparation

Bluetooth

audio device set-up

Bluetooth

audio programming, changes,

deletions, and display of programmed
device information can be performed.

1. The mode changes as follows each

time the audio control dial is pressed.
Select

“BT SETUP”.

* Depending on the mode selected, the

indication changes.

2.Turn the audio control dial and select a

desired mode.

Interior Comfort

Bluetooth® Audio

6-63

Mazda5_8FN4-EA-16G_Edition1 Page261
Monday, May 23 2016 7:36 PM

Black plate (262,1)

Display

Mode

Function

PAIR DEVICE

Pairing
program mode

Bluetooth

audio

device programming

LINK CHANGE

Link change
mode

Changing link
to Bluetooth

audio device

PAIR DELETE

Pairing
deletion mode

Deleting link
to Bluetooth

audio device

DEVICE INFO

Device
information
display mode

Displaying
vehicle's
Bluetooth

unit
information

3. Press the audio control dial to

determine the mode.

Bluetooth

audio device programming

Any Bluetooth

audio device must be

programmed to the vehicle's Bluetooth

unit before it can be listened to over the
vehicle's speakers.
A maximum of seven devices including
Bluetooth

audio devices and hands-free

mobile phones can be programmed to one
vehicle.

NOTE

Always perform Bluetooth

audio device

programming while the vehicle is stopped.

If a Bluetooth

device has already been

programmed to the vehicle as a hands-free
mobile phone, it does not need to be
programmed again when using the device
as a Bluetooth

audio device. Conversely, it

does not need to be programmed again as a
hands-free mobile phone if it has already
been programmed as a Bluetooth

audio

device.

Look around to be sure other likely
Bluetooth

audio devices are not in range

when you start to program. If in doubt,
move your car to another location. The
transmission range of a Bluetooth

audio

device is about 10 m (32 ft). Therefore, if
there is another Bluetooth

audio device

within a 10 m (32 ft) radius of the vehicle,
the device may be identified and
programmed instead.

Device registration can also be done using
voice recognition (page 6-75).

Concerning the operation of a Bluetooth

audio device itself, refer to its instruction
manual.
Some Bluetooth

audio devices have PIN

codes (four digits). Refer to the audio
device's instruction manual because the
programming procedure differs depending
on whether it has a PIN code or not.

Programming a Bluetooth

audio

device which has a four-digit PIN code

1. Using the audio control dial, select the

pairing program mode

“PAIR DEVICE” in the “BT SETUP”
mode. (Refer to

“Bluetooth

audio

device set-up

” for details.)

6-64

Interior Comfort

Bluetooth® Audio

Mazda5_8FN4-EA-16G_Edition1 Page262
Monday, May 23 2016 7:36 PM

Black plate (263,1)

2. Press the audio control dial to

determine the mode.
After

“ENTER PIN” is displayed on

the information display for three
seconds,

“PIN 0000” is displayed and

the PIN code can be input.

3. Input the PIN code of your Bluetooth

audio device by pressing channel
preset buttons 1 to 4 while

“PIN 0000”

is displayed.
Press channel preset button 1 to input
the first digit, 2 for the second, 3 for
the third, and 4 for the forth. For
example, if the PIN code were

“4213”,

press channel preset button 1 four
times (1, 2, 3, 4), button 2 twice (1, 2),
button 3 once (1), and button 4 three
times (1, 2, 3). If the

“PIN 0000”

display disappears before finishing the
PIN code input, repeat the procedure
from Step 1.

NOTE

Some devices accept only a particular pairing
code (Usually,

“0000” or “1234”).

If pairing cannot be completed, refer to the
owner's manual of your mobile device, and try
those numbers if necessary.

4. Press the audio control dial while the

input PIN code is displayed.

“PAIRING” flashes on the display.

5. Operate the Bluetooth

audio device

and set it to the program mode while

“PAIRING” is flashing.

6. When the programming is completed,

“ ” and “PAIR SUCCESS” are
displayed after about 10-30 seconds,
after which

“PAIR SUCCESS”

continues to be displayed for three
seconds, and then the unit returns to the
normal display.

NOTE

Some Bluetooth

audio devices need a

certain amount of time before the

“ ”

symbol is displayed.

If the programming failed,

“Err” flashes

for three seconds then it returns to
“PAIR DEVICE”.

Programming cannot be performed while
the vehicle is moving. If you attempt to
perform programming while the vehicle is
moving,

“PAIR DISABLE” is displayed and

it returns to

“PAIR DEVICE”.

If seven Bluetooth

audio devices have

already been programmed to the vehicle,
programming cannot be performed and
“MEMORY FULL” is displayed. Delete
one programmed device to program
another one.

Programming a Bluetooth

audio

device which does not have a four-digit
PIN code

1. Using the audio control dial, select the

pairing program mode

“PAIR DEVICE” in the “BT SETUP”
mode. (Refer to

“Bluetooth

audio set

” for details.)

2. Press the audio control dial to

determine the mode.
After

“ENTER PIN” is displayed on

the information display for three
seconds,

“PIN 0000” is displayed and

the PIN code can be input.

3. Press the audio control dial while

“PIN 0000” is displayed.

“PAIRING” flashes on the display.

4. Operate the Bluetooth

audio device

and set it to the program mode while

“PAIRING” is flashing.

5. As the Bluetooth

audio device

requires a PIN code, input

“0000”.

Interior Comfort

Bluetooth® Audio

6-65

Mazda5_8FN4-EA-16G_Edition1 Page263
Monday, May 23 2016 7:36 PM

Content .. 14 15 16 17 ..
