T–36

WARNING AND INDICATOR SYSTEM

Specifications

End Of Sie

26

TCS OFF light

ABS/TCS HU/CM

X

Vehicles with TCS

27

DSC OFF light

DSC HU/CM

X

Vehicles with DSC

28

Fuel-level warning light

Fuel gauge sender unit

—

—

Item

Specification

Speedometer

Meter type

Stepping motor type

Indication range

(km/h)

0—240

 (mph

{km/h})

0—150 {0—240}

Input signal communication system

CAN system

Input signal
source

Vehicles with ABS (ABS/TCS)
HU/CM

ABS (ABS/TCS) HU/CM

Vehicles with DSC

DSC HU/CM

Vehicles without ABS

PCM

Rated voltage

(V)

DC 12

Tachometer

Meter type

Stepping motor type

Indication range

(rpm)

0—8,000

Red zone

(rpm)

6,500—8,000

Input signal communication system

CAN system

Input signal source

PCM

Rated voltage

(V)

DC 12

Fuel gauge

Meter type

Stepping motor type (Reset-to-zero type)

Input signal communication system

Conventional communication system

Input signal source

Fuel tank gauge unit

Rated voltage

(V)

DC 12

Water
temperature
gauge

Meter type

Stepping motor type (Medium range stabilized type)

Input signal communication system

CAN system

Input signal source

PCM

Rated voltage

(V)

DC 12

Odometer/
Tripmeter

Display

LCD

Indication digits

Odometer: 6 digits, Tripmeter: 4 digits

Input signal communication system

CAN system

Input signal
source

Vehicles with ABS (ABS/TCS)
HU/CM

ABS (ABS/TCS) HU/CM

Vehicles with DSC

DSC HU/CM

Vehicles without ABS

PCM

Rated voltage

(V)

DC 12

No.

Warning and indicator light

Input signal source

CAN system

Note

WARNING AND INDICATOR SYSTEM

T–37

T

T

SYSTEM WIRING DIAGRAM

A6E811855430T02

.

A6E8118T002

1

Key reminder switch

2

Ignition key illumination

3

Speedometer

4

Tachometer

5

Fuel gauge

6

Water temperature gauge

7

Microcomputer

8

Odometer/tripmeter

9

Odometer/tripmeter switch

10

Fuel-level warning light

11

Generator warning light

12

Door ajar warning light

13

Seat belt warning light

14

HOLD indicator light

15

Air bag system warning light

16

Security light

17

Cruise set indicator light

18

Cruise main indicator light

19

To PCM, ABS (ABS/TCS) HU/CM (with (ABS/TCS))
or DSC HU/CM (with DSC)

20

Audio unit

21

Panel light control switch

22

Fuel gauge sender unit

23

Brake fluid-level sensor

24

Door switch (driver’s side)

25

Door switch (passenger’s side)

26

Door switch (rear left side)

27

Door switch (rear right side)

28

Buckle switch

29

SAS unit

30

Door lock timer unit

31

Theft-deterrent control module

32

Cruise actuator

33

To microcomputer

T–38

WARNING AND INDICATOR SYSTEM

.

End Of Sie

A6E8118T003

1

Turn switch

2

Flasher unit

3

Hazard warning switch

4

Turn light (left)

5

Turn light (right)

6

Front fog light relay

7

Front fog light switch

8

Rear fog light relay

9

Rear fog light switch

10

TNS relay

11

Headlight relay

12

Headlight switch

13

Headlight (left)

14

Headlight (right)

15

TCS OFF light

16

Washer fluid-level warning light

17

Turn indicator light (left)

18

Turn indicator light (right)

19

Front fog light indicator light

20

Rear fog light indicator light

21

Instrument cluster illumination

22

DSC/TCS indicator light

23

DSC OFF light

24

ABS warning light

25

Brake system warning light

26

Oil pressure warning light

27

High beam indicator light

28

Selector indicator drive circuit

29

Washer fluid-level sensor

30

Parking brake switch

31

Oil pressure switch

32

To microcomputer

WARNING AND INDICATOR SYSTEM

T–39

T

T

INPUT/OUTPUT CHECK MODE

A6E811855430T03

•

The microcomputer built into instrument cluster detects the quality of input signal or individual part.

•

Input/output check mode has both input circuit check and individual part check functions.

•

The operating order of the input/output check mode is the same as that of the current MPV (LW) model.

•

A comparison of available DTCs for the Mazda6 and the current MPV (LW) model is shown below.

Input circuit check

X: Applied

—: Not applied

Individual circuit check

X: Applied

—: Not applied

End Of Sie

PID/DATA MONITOR AND RECORD

A6E811855430T04

•

The PID/DATA monitoring items for the instrument cluster is as shown in the table below.

Monitor item table

—: Not applicable

End Of Sie

No.

Mazda6

MPV (LW)

Parts sending input signal

01

X

X

Buckle switch

04

X

X

Door switch

05

—

X

Door lock-link switch

07

—

X

Rear window defroster switch

08

X

X

TNS relay

09

—

X

Headlight switch

10

—

X

PCM

11

—

X

PCM

22

X

X

Fuel gauge sender unit

24

—

X

ECT sensor

29

—

X

Rear fog light switch

31

—

X

Key reminder switch

40

—

X

Front fog light relay

41

—

X

P positionswitch

No.

Mazda6

MPV (LW)

Parts sending input signal

12

X

X

Speedometer

13

X

X

Tachometer

14

X

X

Buzzer

15

—

X

Rear fog light relay

16

X

X

Fuel-level warning light

17

—

X

Rear window defroster indicator light

18

X

X

Ignition key illumination

20

—

X

Rear window defroster relay

21

—

X

Door lock timer unit

23

X

X

Fuel gauge

25

X

X

Water temperature gauge

26

X

X

LCD

27

—

X

Interior light

42

—

X

Key interlock solenoid

PID item

Definition

Unit/Condition

Terminal

CCNT_HE

Continuous codes

Number of continuous codes

—

ECT_GAUGE

Temperature gauge

°

C

°

F

2W,  2X

FUEL

Fuel flow

l/min

2M

ODOMETR

Total distance

km

mile

2W, 2X

SPEEDSG

Speedometer

km/h

mile/h

RPM

Tachometer

rpm
