OUTLINE

.

A6E3940T903

OUTLINE

F–9

F

34

Generator

35

Refrigerant pressure switch (middle)

36

PSP switch

37

Blower motor

38

Refrigerant pressure switch (high and low)

39

A/C switch

40

Brake switch

41

Neutral switch

42

Clutch switch

43

TR switch

44

Turbine speed sensor

45

HOLD switch

46

TFT sensor

47

Oil pressure switch

48

VSS

49

Ignition coil

50

Generator

51

Purge solenoid valve

52

VAD control solenoid valve

53

EGR valve

54

Variable tumble control solenoid valve

55

VIS control solenoid valve

56

OCV

57

Valve body

58

Brake light

59

L8, LF (Intensely hot area) and L3 engine models

60

MTX model

61

ATX model

62

L3 engine model

F–10

OUTLINE

Without Immobilizer System

.

A6E3940T902

OUTLINE

F–11

F

1

Heated oxygen sensor (front)

2

Heated oxygen sensor (rear)

3

TP sensor

4

MAP sensor

5

BARO sensor

6

ECT  sensor

7

MAF/IAT sensor

8

IAT sensor

9

MAF sensor

10

Controller area network (CAN)

11

Knock sensor

12

CKP sensor

13

CMP sensor

14

Fuel injector No.1

15

Fuel injector No.2

16

Fuel injector No.3

17

Fuel injector No.4

18

IAC

19

Oxygen sensor heater (front)

20

Oxygen sensor heater (rear)

21

A/C relay

22

Cooling fan relay

23

Cooling fan relay

24

Cooling fan relay

25

Cooling fan relay

26

Fuel pump relay

27

Ignition switch

28

Main relay

29

L8, LF (Intensely hot area) and L3 engine models

30

ATX model
