Lexus RX350h (2024 year). Manual in english

218

4-2. Driving procedures

Right turn

Lane change to the right (move the
lever partway and release it)

The right hand signals will flash 3 times.

Lane change to the left (move the
lever partway and release it)

The left hand signals will flash 3 times.

Left turn

■

Turn signals can be operated when

The power switch is in ON.

■

If the indicator flashes faster than usual

Have the vehicle inspected by your Lexus

dealer.

■

If the turn signals stop flashing before a

lane change has been performed

Operate the lever again.

■

Using the manual mode

The parking brake can be set and
released manually.

Parking brake indicator (U.S.A.)
Parking brake indicator (Canada)

Pull the switch to set the parking
brake.

The parking brake indicator light will turn
on.
Pull and hold the parking brake switch if an
emergency occurs and it is necessary to

Turn signal lever

Operating instructions

Parking brake

The parking brake can be set or
released automatically or manually.

In automatic mode, the parking
brake can be set or released auto-
matically according to the shift
lever operation.

Also, even in automatic mode, the
parking brake can be set or
released manually.

Operating instructions

A
B

219

4-2. Driving procedures

Driving

operate the parking brake while driving.

Press the switch to release the
parking brake.

• Operate the parking brake switch while

depressing the brake pedal.

• Using the parking brake automatic

release function, the parking brake can
be released by depressing the accelera-
tor pedal. When using this function,
slowly depress the accelerator pedal.
(



P.219)

Make sure that the parking brake indicator
light turn off.
If the parking brake indicator light flash,
operate the switch again. (



P.516)

■

Turning the automatic mode on

While the vehicle is stopped, pull and
hold the parking brake switch until a
buzzer sounds and a message is shown
on the multi-information display.
When the automatic mode is turned
on, the parking brake operates as fol-
lows.



When the shift position is shifted
from P, the parking brake will be
released, and the parking brake
indicator light will turn off.



When the shift position is shifted to
P, the parking brake will be set, and
the parking brake indicator light will
turn on.

Operate the shift lever and P position
switch with the vehicle stopped and the
brake pedal depressed.

The auto function may not operate if the
shift lever is moved extremely quickly. In
this situation, apply the parking brake man-
ually. (



P.218)

■

Turning the automatic mode off

While the vehicle is stopped and
depressing the brake pedal, press and
hold the parking brake switch until a
buzzer sounds and a message is shown
on the multi-information display.

■

Parking brake operation

●

When the power switch is not in ON, the

parking brake cannot be released using

the parking brake switch.

●

When the power switch is not in ON,

automatic mode (automatic brake setting

and releasing) is not available.

■

Parking brake automatic release func-

tion

When all of the following conditions are

met, the parking brake can be released by

depressing the accelerator pedal.

●

The driver’s door is closed

●

The driver is wearing the seat belt

●

The shift lever is in a forward driving posi-

tion or reverse driving position

●

The malfunction indicator lamp or brake

system warning light is not illuminated.

When depressing the accelerator pedal,

depress it slowly.
If the parking brake is not released when

the accelerator pedal is depressed, release

the parking brake manually.
When the shift position is shifted from P, the

parking brake will be released automati-

cally.

■

Parking brake automatic lock function

The parking brake will be set automatically

under the following conditions:

●

The brake pedal is not depressed

●

The driver’s door is open

●

The driver’s seat belt is not fastened

●

The shift position is in a position other

than P or N

(Vehicles with Lexus Teammate Advanced

Park: The shift position is in P during

Advanced Park operation.)

220

4-2. Driving procedures

●

The malfunction indicator lamp and

brake system warning light are not illumi-

nated

■

If “Parking Brake Temporarily Unavail-

able” is displayed on the multi-informa-

tion display

If the parking brake is operated repeatedly

over a short period of time, the system may

restrict operation to prevent overheating. If

this happens, refrain from operating the

parking brake. Normal operation will return

after about 1 minute.

■

If “EPB Activation Stopped Incom-

pletely” or “Parking Brake Unavailable”

is displayed on the multi-information

display

Operate the parking brake switch. If the

message does not disappear after operat-

ing the switch several times, the system may

be malfunctioning. Have the vehicle

inspected by your Lexus dealer.

■

Parking brake operation sound

When the parking brake operates, a motor

sound (whirring sound) may be heard. This

does not indicate a malfunction.

■

Parking brake indicator light

●

Depending on the power switch mode,

the parking brake indicator light will turn

on and stay on as described below:

ON: Comes on until the parking brake is

released.

Not in ON: Stays on for approximately 15

seconds.

●

When the power switch is turned off with

the parking brake set, the parking brake

indicator light will stay on for about 15

seconds. This does not indicate a mal-

function.

■

When the parking brake switch mal-

functions

Automatic mode (automatic brake setting

and releasing) will be turned on automati-

cally.

■

Parking the vehicle



P.179

■

Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven

with the parking brake engaged. “Parking

Brake ON” is displayed on the multi-infor-

mation display (with the vehicle reaching a

speed of 3 mph [5 km/h]).

■

If the brake system warning light comes



P.510

■

Usage in winter time



P.395

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle alone.

The parking brake may be released unin-

tentionally by a child and there is the dan-

ger of the vehicle moving that may lead

to an accident resulting in death or seri-

ous injury.

■

Parking brake switch

Do not set any objects near the parking

brake switch. Objects may interfere with

the switch and may lead the parking

brake to unexpectedly operate.

■

Parking brake automatic lock func-

tion

Never use the automatic parking brake

engagement function in place of normal

parking brake operation. This function is

designed to reduce the risk of a collision

due to the driver forgetting to engage the

parking brake. Over-reliance on this

function to park the vehicle safely may

lead to an accident resulting in death or

serious injury.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, shift the

shift position to P, set the parking brake

and make sure that the vehicle does not

move.

221

4-2. Driving procedures

Driving

Turns the brake hold system on

The brake hold standby indicator (green)

comes on. While the system is holding

the brake, the brake hold operated indica-
tor (yellow)

comes on.

NOTICE

■

When the system malfunctions

Stop the vehicle in a safe place and

check the warning messages.

■

When the vehicle 12-volt battery is

discharged

The parking brake system cannot be acti-

vated. (



P.548)

■

When the parking brake cannot be

released due to a malfunction

Driving the vehicle with the parking

brake set will lead to brake components

overheating, which may affect braking

performance and increase brake wear.

Have the vehicle inspected by your

Lexus dealer immediately if this occurs.

Brake Hold



RX500h

The brake hold system keeps the
brake applied when the shift posi-
tion is in D, M or N with the system
on and the brake pedal has been
depressed to stop the vehicle. The
system releases the brake when the
accelerator pedal is depressed with
the shift position in D or M to allow
smooth start off.



RX350h

The brake hold system keeps the
brake applied when the shift posi-
tion is in D, S or N with the system
on and the brake pedal has been
depressed to stop the vehicle. The
system releases the brake when the
accelerator pedal is depressed with
the shift position in D or S to allow
smooth start off.

Enabling the system

222

4-2. Driving procedures

■

Brake hold system operating conditions

The brake hold system cannot be turned on

in the following conditions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat belt.

●

The parking brake is engaged.

●

“EPB Activation Stopped Incompletely”

or “Parking Brake Malfunction Visit Your

Dealer” is displayed on the multi-infor-

mation display.

If any of the conditions above are detected

when the brake hold system is enabled, the

system will turn off and the brake hold

standby indicator light will go off. In addi-

tion, if any of the conditions are detected

while the system is holding the brake, a

warning buzzer will sound and a message

will be shown on the multi-information dis-

play. The parking brake will then be set

automatically.

■

Brake hold function

●

If the brake pedal is left released for a

period of about 3 minutes after the sys-

tem has started holding the brake, the

parking brake will be set automatically. In

this case, a warning buzzer sounds and a

message is shown on the multi-informa-

tion display.

●

To turn the system off while the system is

holding the brake, firmly depress the

brake pedal and press the button again.

●

The brake hold function may not hold the

vehicle when the vehicle is on a steep

incline. In this situation, it may be neces-

sary for the driver to apply the brakes. A

warning buzzer will sound and the

multi-information display will inform the

driver of this situation. If a warning mes-

sage is shown on the multi-information

display, read the message and follow the

instructions.

●

When do not wish for the parking brake

to operate automatically, press and hold

the brake hold switch until the standby

indicator (green) turns off, and then turn

the power switch off.

■

When the parking brake is set automati-

cally while the system is holding the

brakes

Perform any of the following operations to

release the parking brake.

●

Depress the accelerator pedal. (The

parking brake will not be released auto-

matically if the seat belt is not fastened.)

●

Operate the parking brake switch with

the brake pedal depressed.

Make sure that the parking brake indicator

light goes off. (



P.218)

■

When an inspection at your Lexus

dealer is necessary

When the brake hold standby indicator

(green) does not illuminate even when the

brake hold switch is pressed with the brake

hold system operating conditions met, the

system may be malfunctioning. Have the

vehicle inspected at your Lexus dealer.

■

If “Brake Hold Malfunction Press Brake

to Deactivate Visit Your Dealer” or

“Brake Hold Malfunction Visit Your

Dealer” is displayed on the multi-infor-

mation display

The system may be malfunctioning. Have

the vehicle inspected by your Lexus dealer.

■

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

■

If the brake hold operated indicator

flashes



P.517

223

4-2. Driving procedures

Driving

■

Customization

Some functions can be customized.

(



P.585)

WARNING

■

When the vehicle is on a steep incline

Take care when using the brake hold sys-

tem on a steep incline, exercise caution.

The brake hold function may not hold

brakes in such situations.

Also, the system may not activate

depending on the angle of the slope.

■

When stopped on a slippery road

The system cannot stop the vehicle when

the gripping ability of the tires has been

exceeded. Do not use the system when

stopped on a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not designed

for use when parking the vehicle for a

long period of time. Turning the power

switch off while the system is holding the

brake may release the brake, which

would cause the vehicle to move. When

operating the power switch, depress the

brake pedal, shift the shift position to P

and set the parking brake.

ASC (Active Sound Control)
(RX500h)

The ASC system is designed to
allow the driver to feel the state of
driving, such as accelerating and
decelerating, more strongly. The
vehicle’s response to the driver’s
accelerator operation and shift
operation are sonically empha-
sized.

224

4-3. Operating the lights and wipers

4-3.Operating the lights and wipers

Operating the

switch turns on

the lights as follows:

U.S.A.
Canada

The side marker, parking, tail,

license plate, instrument panel
lights, and daytime running lights
(



P.224) turn on.

The headlights and all lights

listed above (except daytime run-
ning lights) turn on.

The headlights, daytime run-

ning lights (



P.224) and all the

lights listed above turn on and off
automatically.
(When the power switch is in ON.)

(U.S.A.) Off

■

AUTO mode can be used when

The power switch is in ON.

■

Daytime running light system

●

The daytime running lights illuminate

using the same lights as the parking lights

and illuminate brighter than the parking

lights.

●

To make your vehicle more visible to

other drivers during daytime driving, the

daytime running lights turn on automati-

cally when all of the following conditions

are met. (The daytime running lights are

not designed for use at night.)

• The hybrid system is started

• The parking brake is released
• The headlight switch is in the

position

: When the surroundings are bright

The daytime running lights remain on after

they illuminate, even if the parking brake is

set again.

●

For the U.S.A.: Daytime running lights

can be turned off by operating the switch.

●

Compared to turning on the headlights,

the daytime running light system offers

greater durability and consumes less

electricity, so it can help improve fuel

economy.

■

Headlight control sensor

The sensor may not function properly if an

object is placed on the sensor, or anything

that blocks the sensor is affixed to the wind-

shield.

Doing so interferes with the sensor detect-

ing the level of ambient light and may cause

the automatic headlight system to malfunc-

tion.

Headlight switch

The headlights can be operated
manually or automatically.

Operating instructions

A
B

225

4-3. Operating the lights and wipers

Driving

■

Automatic light off system

●

When the headlights are on: The head-

lights and tail lights turn off 30 seconds

after the driver’s door is opened and

closed if the power switch is turned off.
(The lights turn off immediately if

the key is pressed after all the doors are

closed.)

●

When only the tail lights are on: The tail

lights turn off automatically if the power

switch is turned off and the driver’s door

is opened.

To turn the lights on again, turn the power

switch to ON, or turn the light switch off
once and then back to

■

Automatic headlight leveling system (if

equipped)

The level of the headlights is automatically

adjusted according to the number of pas-

sengers and the loading condition of the

vehicle to ensure that the headlights do not

interfere with other road users.

■

Light reminder buzzer

A buzzer sounds when the power switch is

turned to ACC or OFF and the driver’s

door is opened while the lights are turned

on.

■

Windshield wiper linked headlight illu-

mination

When driving during daytime with the
headlight switch turned to

, if the wind-

shield wipers are used, the headlights will

turn on automatically after several seconds

to help enhance the visibility of your vehicle.

■

12-volt battery-saving function

In order to prevent the 12-volt battery of the

vehicle from discharging, if the headlights

and/or tail lights are on when the power

switch is turned off the 12-volt battery sav-

ing function will operate and automatically

turn off all the lights after approximately 20

minutes. When the power switch is turned

to ON, the 12-volt battery-saving function

will be disabled.

When any of the following are performed,

the 12-volt battery-saving function is can-

celed once and then reactivated. All the

lights will turn off automatically 20 minutes

after the 12-volt battery-saving function has

been reactivated:

●

When the headlight switch is operated

●

When a door is opened or closed

■

When unlocking the doors (welcome

lamp)

The parking lights automatically turn on

when the surroundings are dark and the

doors are unlocked using the entry function

or wireless remote control if the light switch
is in the

position.

■

Customization

Some functions can be customized.

(



P.585)

With the headlights on, push the
lever away from you to turn on the

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Turning on the high beam head-
lights

226

4-3. Operating the lights and wipers

high beams.

Pull the lever toward you to the center
position to turn the high beams off.

Pull the lever toward you and
release it to flash the high beams
once.

You can flash the high beams with the
headlights on or off.

When any of the following conditions is
met, while the headlights (low beam)
are on, the cornering lights will addi-
tionally turn on and light up the direc-
tion of movement for the vehicle. This is
to ensure excellent visibility when
either driving at intersections or park-
ing at night.



The steering wheel is operated



The turn signal lever is operated



The shift position is in R (both left
and right side cornering lights)

■

Cornering light control

●

When vehicle speed is approximately 22

mph (35 km/h) or higher, the cornering

lights will not turn on.

●

After the lights remain illuminated for 30

minutes, they automatically turn off.

: If equipped



According to the vehicle speed, the
brightness and illuminated area of
the high beams are adjusted.



The high beams are illuminated so
that the area around a vehicle ahead
is shaded. (Shaded high beam)

The shaded high beam helps ensure for-
ward visibility while reducing the dazzling
effect on the drivers of vehicles ahead.

Cornering lights (if equipped)

AHS (Adaptive High-beam
System)

The Adaptive High-beam System
uses a front camera located on the
upper portion of the windshield to
detect the brightness of the lights of
vehicles ahead, streetlights, etc.,
and automatically controls the light
distribution of the headlights.

WARNING

■

For safe use

Do not overly rely on the Adaptive

High-beam System. Always drive safely,

taking care to observe your surroundings

and turning the high beams on or off

manually if necessary.

■

To prevent unintentional operation of

the Adaptive High-beam System

When it is necessary to disable the sys-

tem:



P.244

System controls

227

4-3. Operating the lights and wipers

Driving

Area illuminated by the high beams
Area illuminated by the low beams



According to the distance to a pre-
ceding vehicle, the illuminated area
of the low beams is adjusted.

Press the Adaptive High-beam Sys-
tem switch.

Turn the headlight switch to the

position.

When the headlight switch lever is in the

low beam position, the AHS will be

enabled and the AHS indicator will illumi-

nate.

■

System operating conditions

●

When all of the following conditions are

met, the high beams will illuminate and

the system will operate:

• The vehicle speed is approximately 19

mph (30 km/h) or more.

• The area ahead of the vehicle is dark.

●

When all of the following conditions are

met, the headlights will change to the

shaded high beams according to the

position of vehicles ahead:

• The vehicle speed is approximately 19

mph (30 km/h) or more

• The area ahead of the vehicle is dark.

• There is a vehicle ahead with lights on.

• There are few streetlights or other lights

on the road ahead.

●

If any of the following conditions are met,

the system will change to the low beams:

• The vehicle speed is approximately 16

mph (25 km/h) or lower.

• The area ahead of the vehicle is not dark.

• There are many vehicles ahead.

• There are many streetlights or other

lights on the road ahead.

■

Front camera detection

●

In the following situations, the high beams

may not be automatically changed to the

shaded high beams:

• When a vehicle cuts in front of your vehi-

cle

• When another vehicle crosses in front of

the vehicle

• When vehicles ahead are repeatedly

detected and then hidden due to

repeated curves, road dividers or road-

side trees

• When a vehicle ahead approaches from

Using the Adaptive High-beam
System

A
B

228

4-3. Operating the lights and wipers

a far lane

• When a vehicle ahead is far away

• When a vehicle ahead has no lights

• When the lights of a vehicle ahead are

dim

• When a vehicle ahead is reflecting strong

light, such as the headlights of your vehi-

cle

• Situations in which the sensors may not

operate properly:



P.249

●

The high beams may change to the

shaded high beams if a vehicle ahead that

is using fog lights without its headlights

turned on is detected.

●

House lights, street lights, traffic signals,

and illuminated billboards or signs and

other reflective objects may cause the

high beams to change to the shaded high

beams, cause the high beams not to

change to the shaded high beams, or

change the area that is not illuminated.

●

The following may change the speed at

which the shaded areas change or the

timing at which the headlights change to

the low beams:

• The brightness of lights of vehicles ahead

• The movement and direction of vehicles

ahead

• The distance between the vehicle and a

vehicle ahead

• When a vehicle ahead only has lights illu-

minated on one side

• When a vehicle ahead is a two-wheeled

vehicle

• The condition of the road (gradient,

curve, condition of the road surface, etc.)

• The number of passengers and amount of

luggage

●

The light distribution control of the head-

lights may not match the driver’s expecta-

tions

●

Bicycles and other small vehicles may not

be detected.

●

In the following situations, the system may

not be able to correctly detect the bright-

ness of the surroundings. This may cause

the low beams to remain on or the high

beams to flash or dazzle pedestrians or

vehicles ahead. In such a case, it is neces-

sary to manually change between the

high beams and low beams.

• When there are lights similar to head-

lights or tail lights in the surrounding area

• When headlights or tail lights of vehicles

ahead are turned off, dirty, changing

color, or not aimed properly

• When the headlights are repeatedly

changing between the high beams and

low beams.

• When use of the high beams is inappro-

priate or when the high beams may be

flashing or dazzling pedestrians or other

drivers.

• When the vehicle is used in an area in

which vehicles travel on the opposite side

of the road of the country for which the

vehicle was designed, for example using

a vehicle designed for right-hand traffic in

a left-hand traffic area, or vice versa

• When it is necessary to disable the sys-

tem:



P.244

• Situations in which the sensors may not

operate properly:



P.249

■

Customization

The settings of some functions can be

changed. (



P.585)

■

Changing to the high beams

Push the lever forward.

The AHS indicator will turn off and the high

beam indicator will turn on.
Pull the lever to its original position to

enable the Adaptive High-beam System

again.

Turning the high beams on/off
manually

229

4-3. Operating the lights and wipers

Driving

■

Changing to the low beams

Press the Adaptive High-beam Sys-
tem switch.

The AHS indicator will turn off.
Press the switch to enable the Adaptive

High-beam System again.

It is recommended to switch to the low
beams when use of the high beams is
inappropriate or when the high beams
may cause problems or distress to
other drivers or pedestrians nearby.

Pull the lever rearward and then
return it to its original position.

The high beams will illuminate while the

lever is pulled, however, after the lever is

returned to its original position, the low

beams will remain on for a certain amount

of time. After this, the Adaptive High-beam

System will operate.

Press the Automatic High Beam
switch.

Turn the headlight switch to the

position.

Temporarily changing to the low
beams

AHB (Automatic High
Beam)

The Automatic High Beam uses a
front camera located on the upper
portion of the windshield to detect
the brightness of the lights of vehi-
cles ahead, streetlights, etc., and
automatically changes the head
lights between the high beams and
low beams.

WARNING

■

For safe use

Do not overly rely on the Automatic High

Beam. Always drive safely, taking care to

observe your surroundings and turning

the high beams on or off manually if nec-

essary.

■

To prevent unintentional operation of

the Automatic High Beam System

When it is necessary to disable the sys-

tem:



P.244

Using the Automatic High Beam
system

230

4-3. Operating the lights and wipers

When the headlight switch lever is in the

low beam position, the AHB system will be

enabled and the AHB indicator will illumi-

nate.

■

Automatic operating conditions of the

high beams

●

When all of the following conditions are

met, the high beams will illuminate auto-

matically:

• The vehicle speed is approximately 21

mph (34 km/h) or more.

• The area ahead of the vehicle is dark.

• There are no vehicles ahead with lights

on.

• There are few streetlights or other lights

on the road ahead.

●

If any of the following conditions are met,

the headlights will change to the low

beams:

• Vehicle speed drops below approxi-

mately 17 mph (27 km/h).

• The area ahead of the vehicle is not dark.

• There is a vehicle ahead with lights on.

• There are many streetlights or other

lights on the road ahead.

■

Front camera detection

●

In the following situations, the high beams

may not be automatically changed to the

low beams:

• When a vehicle cuts in front of your vehi-

cle

• When another vehicle crosses in front of

the vehicle

• When vehicles ahead are repeatedly

detected and then hidden due to

repeated curves, road dividers or road-

side trees

• When a vehicle ahead approaches from

a far lane

• When a vehicle ahead is far away

• When a vehicle ahead has no lights

• When the lights of a vehicle ahead are

dim

• When a vehicle ahead is reflecting strong

light, such as own headlights

• Situations in which the sensors may not

operate properly:



P.249

●

The headlights may change to the low

beams if a vehicle ahead that is using fog

lights without its headlights turned on is

detected.

●

House lights, street lights, traffic signals,

and illuminated billboards or signs may

cause the high beams to change to the

low beams, or the low beams to remain

on.

●

The following may change the timing at

which the headlights change to the low

beams:

• The brightness of lights of vehicles ahead

• The movement and direction of vehicles

ahead

• The distance between the vehicle and a

vehicle ahead

• When a vehicle ahead only has lights illu-

minated on one side

• When a vehicle ahead is a two-wheeled

vehicle

• The condition of the road (gradient,

curve, condition of the road surface, etc.)

• The number of passengers and amount of

luggage

●

The headlights may change between the

high beams and low beams unexpectedly.

●

Bicycles and other small vehicles may not

be detected.

●

In the following situations, the system may

not be able to correctly detect the bright-

ness of the surroundings. This may cause

the low beams to remain on or the high

beams to flash or dazzle pedestrians or

vehicles ahead. In such a case, it is neces-

sary to manually change between the

high beams and low beams.

• When there are lights similar to head-

lights or tail lights in the surrounding area

• When headlights or tail lights of vehicles

ahead are turned off, dirty, changing

color, or not aimed properly

• When the headlights are repeatedly

changing between the high beams and

low beams.

231

4-3. Operating the lights and wipers

Driving

• When use of the high beams is inappro-

priate or when the high beams may be

flashing or dazzling pedestrians or other

drivers.

• When the vehicle is used in an area in

which vehicles travel on the opposite side

of the road of the country for which the

vehicle was designed, for example using

a vehicle designed for right-hand traffic in

a left-hand traffic area, or vice versa

• When it is necessary to disable the sys-

tem:



P.244

• Situations in which the sensors may not

operate properly:



P.249

■

Temporarily reducing front camera sen-

sitivity

The sensitivity of the front camera can be

temporarily reduced.

Turn the power switch off with the fol-

lowing conditions met.

●

The headlight switch is in the

position.

●

The headlight switch lever is in the low

beam position.

●

The Automatic High Beam switch is on.

Turn the power switch to ON.

Within 60 seconds after performing

step 2, push the headlight switch lever

to the high beam position then pull it to

the original position quickly 10 times,

then leave the lever in its original posi-

tion.

If the sensitivity is changed, the Auto-

matic High Beam indicator will blink 3

times.

■

Changing to the high beams

Push the lever forward.

The AHB indicator will turn off and the

high beam indicator will turn on.
Pull the lever to its original position to

enable the Automatic High Beam system

again.

■

Changing to the low beams

Press the Automatic High Beam
switch.

The AHB indicator will turn off.
Press the switch to enable the Automatic

High Beam system again.

It is recommended to switch to the low
beams when use of the high beams is
inappropriate or when the high beams
may cause problems or distress to
other drivers or pedestrians nearby.

Pull the lever rearward and then
return it to its original position.

The high beams will illuminate while the

lever is pulled, however, after the lever is

returned to its original position, the low

beams will remain on for a certain amount

of time. After this, the Automatic High

Beam system will operate.

Turning the high beams on/off
manually

Temporarily changing to the low
beams

233

4-3. Operating the lights and wipers

Driving

Operating the

lever operates

the wipers or washer as follows:

When

is selected, the wipers will

operate automatically when the sen-
sor detects falling rain. The system
automatically adjusts wiper timing in
accordance with rain volume and vehi-
cle speed.

(U.S.A.) or

(Canada)

Off

Rain-sensing wiper operation

(U.S.A.) or

(Canada)

Low speed operation

(U.S.A.) or

(Canada)

High speed operation

(U.S.A.) or

(Canada)

Temporary operation

When is

selected, the sensor sen-

sitivity can be adjusted by turning the
switch ring.

Windshield wipers and
washer

Operating the lever can switch
between automatic operation and
manual operation, or can use the
washer.

NOTICE

■

When the windshield is dry

Do not use the wipers, as they may dam-

age the windshield.

Operating the wiper lever

234

4-3. Operating the lights and wipers

Increases the sensitivity

Decreases the sensitivity

Washer/wiper dual opera-

tion

Pulling the lever operates the wipers and
washer.
(After operating several times, the wipers
operate once more time after a short delay
to prevent dripping. However, the dripping
prevention does not operate while the
vehicle is moving.)
Vehicles with headlight cleaners:
When the power switch is in ON and the
headlights are on, if the lever is pulled, the
headlight cleaners will operate once. After
this, the headlight cleaners will operate
every 5th time the lever is pulled.

■

The windshield wipers and washer can

be operated when

The power switch is in ON.

■

Operating the windshield wipers and
washer using the voice control system

: If equipped

The following operation can be performed

using the voice control system.

●

Operating the windshield wipers only

once

●

Operating the windshield washer (it can

be performed only when the vehicle is

stopped)

For details regarding the voice control sys-

tem, refer to the “MULTIMEDIA

OWNER’S MANUAL”.

■

Effects of vehicle speed on wiper opera-

tion

With low speed windshield wiper operation

selected, wiper operation will be switched

from low speed to intermittent wiper opera-

tion when the vehicle is stationary. (How-

ever, when the sensor sensitivity is adjusted

to the highest level, the mode will not

switch.)

■

Raindrop sensor

●

The raindrop sensor judges the amount

of raindrops.

An optical sensor is adopted. It may not

operate properly when sunlight from the

rising or setting of the sun intermittently

strikes the windshield, or if bugs, etc. are

present on the windshield.

●

If the wiper switch is turned to the

position while the power switch is in ON,

the wipers will operate once to show that

AUTO mode is activated.

●

When the sensor sensitivity ring is turned
toward high while in

position, the

wipers will operate once to indicate that

the sensor sensitivity is enhanced.

●

If the temperature of the raindrop sensor

is 185°F (85°C) or higher, or 5°F

(-15°C) or lower, automatic operation

may not occur. In this case, operate the

235

4-3. Operating the lights and wipers

Driving

wipers in any mode other than AUTO

mode.

■

If no windshield washer fluid sprays

Check that the washer nozzles are not

blocked, if there is washer fluid in the

washer fluid tank.

■

Front door opening linked windshield

wiper stop function

When

is selected and the windshield

wipers are operating, if a front door is

opened, the operation of the windshield

wipers will be stopped to prevent anyone

near the vehicle from being sprayed by

water from the wipers, provided the vehicle

is stopped with the parking brake applied or

the shift position in P. When the front door is

closed, wiper operation will resume.

When the windshield wipers are not
being used, they retract to below the
hood. To enable the windshield wipers
to be lifted when parking in cold condi-
tions or when replacing a windshield
wiper insert, change the rest position of
the windshield wipers to the service
position using the wiper lever.

■

Raising the wipers to the service
position

Within approximately 45 seconds of
turning the power switch off, move the

wiper lever to the

(U.S.A.) or

(Canada) position and hold it for
approximately 2 seconds or more.

The wipers will move to the service posi-
tion.

WARNING

■

Caution regarding the use of wind-

shield wipers in AUTO mode

The windshield wipers may operate

unexpectedly if the sensor is touched or

the windshield is subject to vibration in

AUTO mode. Take care that your fingers,

etc. do not become caught in the wind-

shield wipers.

■

Caution regarding the use of washer

fluid

When it is cold, do not use the washer

fluid until the windshield becomes warm.

The fluid may freeze on the windshield

and cause low visibility. This may lead to

an accident, resulting in death or serious

injury.

NOTICE

■

When the washer fluid tank is empty

Do not operate the switch continually as

the washer fluid pump may overheat.

■

When a nozzle becomes blocked

In this case, contact your Lexus dealer.

Do not try to clear it with a pin or other

object. The nozzle will be damaged.

■

To prevent 12-volt battery discharge

Do not leave the wipers on longer than

necessary when the hybrid system is off.

Changing the windshield wiper
rest position/Lifting the wind-
shield wipers

236

4-3. Operating the lights and wipers

■

Lifting the windshield wipers

While holding the hook portion of the
wiper arm, lift the windshield wiper
from the windshield.

Hook portion

■

Lowering the windshield wipers to the

retracted position

With the windshield wipers placed on the

windshield, turn the power switch to ON

and then move the wiper lever to an operat-

ing position. When the wiper switch is

turned off, the windshield wipers will stop at

the retracted position.

■

Operating the windshield wipers and
washer using the voice control system

: If equipped



For the U.S.A.

The windshield wipers can be moved to the

service position using the voice control

system. (Operation is possible only when

the vehicle is stopped with the wiper switch
in .)



For Canada

The windshield wipers can be moved to the

service position using the voice control

system. (Operation is possible only when

the vehicle is stopped with the wiper switch
in .)
For details regarding the voice control sys-

tem, refer to the “MULTIMEDIA

OWNER’S MANUAL”.

NOTICE

■

When lifting the windshield wipers

●

Do not lift the windshield wipers when

they are in the retracted position

below the hood. Otherwise, they may

contact the hood, possibly resulting in

damage to a windshield wiper and/or

the hood.

●

Do not lift a windshield wiper by the

wiper blade. Otherwise, the wiper

blade may be deformed.

●

Do not operate the wiper lever when

the windshield wipers are lifted. Oth-

erwise, the windshield wipers may

contact the hood, possibly resulting in

damage to the windshield wipers

and/or hood.

237

4-3. Operating the lights and wipers

Driving

Operating the

switch operates

the rear wiper as follows:

(U.S.A.) or

(Canada) Off

(U.S.A.) or

(Canada) Inter-

mittent operation

(U.S.A.) or

(Canada) Nor-

mal operation

Washer/wiper dual opera-

tion

Pushing the lever operates the wiper and
washer.
The wiper will automatically operate a cou-
ple of times after the washer squirts.
Vehicles with camera cleaning washer: The
washer will automatically operate and
clean the rear camera.

: Refer to “MULTIMEDIA OWNER’S

MANUAL”.

■

The rear window wiper and washer can

be operated when

The power switch is in ON.

■

Operating the rear window wiper and
washer using the voice control system

: If equipped

The following operation can be performed

using the voice control system.

●

Operating the rear window wiper only

once

●

Operating the rear window washer (it

can be performed only when the vehicle

is stopped)

For details regarding the voice control sys-

tem, refer to the “MULTIMEDIA

OWNER’S MANUAL”.

■

If no washer fluid sprays

Check that the washer nozzle is not

blocked if there is washer fluid in the washer

fluid tank.

Rear window wiper and
washer

NOTICE

■

When the rear window is dry

Do not use the wiper, as it may damage

the rear window.

Operating the wiper lever

238

4-3. Operating the lights and wipers

■

Reverse-linked rear window wiper func-

tion

When the shift position is shifted to R when

the front wipers are operating, the rear win-

dow wiper will operate once.

■

Back door opening linked rear window

wiper stop function

When the rear window wiper is operating, if

the back door is opened while the vehicle is

stopped, operation of the rear window

wiper will be stopped to prevent anyone

near the vehicle from being sprayed by

water from the wiper. When the back door

is closed, wiper operation will resume.

NOTICE

■

When the washer fluid tank is empty

Do not operate the switch continually as

the washer fluid pump may overheat.

■

When a nozzle becomes blocked

In this case, contact your Lexus dealer.

Do not try to clear it with a pin or other

object. The nozzle will be damaged.

■

To prevent 12-volt battery discharge

Do not leave the wiper on longer than

necessary when the hybrid system is off.

239

4-4. Refueling

Driving

4-4.Refueling



Close all the doors and windows,
and turn the power switch off.



Confirm the type of fuel.

■

Fuel types



P.574

■

Fuel tank opening for unleaded gasoline

To help prevent incorrect fueling, your vehi-

cle has a fuel tank opening that only accom-

modates the special nozzle on unleaded

fuel pumps.

Opening the fuel tank cap

The fuel tank of your vehicle has a
special structure, which requires a
reduction in fuel tank pressure
before refueling. After the opener
switch has been pressed, it will take
several seconds until the vehicle is
ready for refueling.

Before refueling the vehicle

WARNING

■

When refueling the vehicle

Observe the following precautions while

refueling the vehicle. Failure to do so may

result in death or serious injury.

●

After exiting the vehicle and before

opening the fuel door, touch an

unpainted metal surface to discharge

any static electricity. It is important to

discharge static electricity before refu-

eling because sparks resulting from

static electricity can cause fuel vapors

to ignite while refueling.

●

Always hold the grips on the fuel tank

cap and turn it slowly to remove it.

A whooshing sound may be heard

when the fuel tank cap is loosened.

Wait until the sound cannot be heard

before fully removing the cap. In hot

weather, pressurized fuel may spray

out of the filler neck and cause injury.

●

Do not allow anyone that has not dis-

charged static electricity from their

body to come close to an open fuel

tank.

●

Do not inhale vaporized fuel.

Fuel contains substances that are

harmful if inhaled.

●

Do not smoke while refueling the vehi-

cle.

Doing so may cause the fuel to ignite

and cause a fire.

●

Do not return to the vehicle or touch

any person or object that is statically

charged.

This may cause static electricity to

build up, resulting in a possible ignition

hazard.

■

When refueling

Observe the following precautions to

prevent fuel overflowing from the fuel

tank:

●

Securely insert the fuel nozzle into the

fuel filler neck.

●

Stop filling the tank after the fuel noz-

zle automatically clicks off.

●

Do not top off the fuel tank.

240

4-4. Refueling

Press the switch to open the fuel
filler door.

The fuel filler door will open within about

10 seconds of the switch being pressed.

Before refueling is possible, a message will

be shown on the multi-information display

in the instrument cluster to indicate the

progress of the fuel filler door opener.

Turn the fuel tank cap slowly and
remove it, then put it into the holder
on the fuel filler door.

■

If the fuel filler door cannot be opened

Consult your Lexus dealer.

After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the oppo-
site direction.

NOTICE

■

Refueling

●

Finish refueling within 30 minutes. If

more than 30 minutes passes, the

internal valve closes. In this condition,

fuel may overflow during the refueling

process.

Press the fuel filler door opener switch

again.

●

Make sure that the fuel filler door lock

is not pushed by the fuel nozzle boot,

etc. If the lock is held, the internal valve

closes and fuel may overflow. To pre-

vent it, press the fuel filler door opener

switch again.

●

Do not spill fuel during refueling.

Doing so may damage the vehicle,

such as causing the emission control

system to operate abnormally or dam-

aging fuel system components or the

vehicle’s painted surface.

Opening the fuel tank cap

Closing the fuel tank cap

242

4-5. Using the driving support systems

4-5.Using the driving support systems

This Owner’s Manual contains infor-
mation for Ver. 2. For the latest infor-
mation about the controls, use,
warnings/precautions, etc. of each
function of Lexus Safety System +
3/Traffic Jam Assist, refer to the Digital
Owner’s Manual at the Owner’s Man-
ual website.
If the software of this system has been
updated after initial purchase of the
vehicle, before using this system, be
sure to read the Owner’s Manual
which corresponds to the software ver-

sion of the system.

■

Precautions for use

●

Be aware that some functions may tem-

porarily be disabled if a legal or safety

related issue occurs.

●

If a connected services contract has not

been entered or has expired, software

updates will not be able to be performed

wirelessly.

If the software of this system has been
updated after initial purchase of the
vehicle, to access the appropriate
Owner’s Manual, it is necessary to
check the software version of the sys-
tem and then visit the Owner’s Manual
website.

The software version of the system can
be checked using Lexus App.

Access the following URL using a
computer or smartphone:



For U.S.A. owners

https://drivers.lexus.com/lexusdrivers/
resources/owners-manuals/manual?
om=om0e218u.rx.2024.2309.hev.vh

Lexus Safety System +
3/Traffic Jam Assist software
update

It is necessary to enter a connected
services contract, provided by
Lexus, to use these functions. For
details, contact your Lexus dealer.

WARNING

■

For safe use

When the Lexus Safety System + 3/Traf-

fic Jam Assist software is updated, the

operating methods of functions may

change. Using this system without know-

ing the correct operating methods may

lead to an accident resulting in death or

serious injury.

●

Make sure to read the Digital Owner’s

Manual which corresponds to the soft-

ware version of the system, available at

the Owner’s Manual website, before

using this system.

Content of the Lexus Safety Sys-
tem + 3/Traffic Jam Assist
Owner’s Manual

Checking your vehicle’s Lexus
Safety System + 3/Traffic Jam
Assist version

Checking the version using Lexus
App

Using your vehicle’s Lexus Safety
System + 3/Traffic Jam Assist ver-
sion

243

4-5. Using the driving support systems

Driving



For Canadian owners

https://www.lexus.ca/lexus/
know-your-lexus/manual?
om=om0e218u.rx.2024.2309.hev.vh

Select the file which includes the
previously checked system version.

If a software update is available, a noti-
fication will be displayed by Lexus App.
Follow the instructions displayed on the
screen.

■

Software update precautions

●

After a software update has been per-

formed, it will not be possible to revert to

a previous version.

●

Depending on the communication envi-

ronment and the content of an update, a

software update may take several hours.

Although an update will be suspended

when the power switch is turned off, it will

resume when the power switch is

changed back to ON.

●

Lexus Safety System + 3/Traffic Jam

Assist can still be used while a software

update is being performed.

■

What can be checked using the Lexus

App

The following items can be checked or per-

formed.

●

Software version, update details, precau-

tions, use methods, etc.

●

Software update

Updating the software

244

4-5. Using the driving support systems

Lexus Safety System + 3

The Lexus Safety System + 3 con-
sists of the driving assist systems
and contributes to a safe and com-
fortable driving experience:

WARNING

■

Lexus Safety System + 3

The Lexus Safety System + 3 operates

under the assumption that the driver will

drive safely, and is designed to help

reduce the impact to the occupants in a

collision and assist the driver under nor-

mal driving conditions.

As there is a limit to the degree of recog-

nition accuracy and control performance

that this system can provide, do not

overly rely on this system. The driver is

solely responsible for paying attention to

the vehicle’s surroundings and driving

safely.

■

For safe use

●

Do not overly rely on this system. The

driver is solely responsible for paying

attention to the vehicle’s surroundings

and driving safely. This system may not

operate in all situations and provided

assistance is limited. Over-reliance on

this system to drive the vehicle safely

may lead to an accident resulting in

death or serious injury.

●

Do not attempt to test the operation of

the system, as it may not operate prop-

erly, possibly leading to an accident.

●

If attention is necessary while perform-

ing driving operations or a system mal-

function occurs, a warning message or

warning buzzer will be operated. If a

warning message is displayed on the

display, follow the instructions dis-

played.

●

Depending on external noise, the vol-

ume of the audio system, etc. it may be

difficult to hear the warning buzzer.

Also, depending on the road condi-

tions, it may be difficult to recognize

the operation of the system.

■

When it is necessary to disable the

system

In the following situations, make sure to

disable the system.

Failure to do so may lead to the system

not operating properly, possibly leading

to an accident resulting in death or seri-

ous injury.

●

When the vehicle is tilted due to being

overloaded or having a flat tire

●

When driving at extremely high

speeds

●

When towing another vehicle

●

When the vehicle is being transported

by a truck, ship, train, etc.

●

When the vehicle is raised on a lift and

the tires are allowed to rotate freely

●

When inspecting the vehicle using a

drum tester such as a chassis dyna-

mometer or speedometer tester, or

when using an on vehicle wheel bal-

ancer

●

When the vehicle is driven in a sporty

manner or off-road

●

When using an automatic car wash

●

When a sensor is misaligned or

deformed due to a strong impact

being applied to the sensor or the area

around the sensor

●

When accessories which obstruct a

sensor or light are temporarily

installed to the vehicle

●

When a compact spare tire or tire

chains are installed to the vehicle or an

emergency tire puncture repair kit has

been used

245

4-5. Using the driving support systems

Driving

■

AHS (Adaptive High-beam Sys-
tem)



P.226

: If equipped

■

AHB (Automatic High Beam)



P.229

■

PCS (Pre-Collision System)



P.253

■

LTA (Lane Tracing Assist)



P.263

■

LDA (Lane Departure Alert)



P.271

■

LCA (Lane Change Assist)



P.268

: If equipped

■

FCTA (Front Cross Traffic Alert)



P.282

: If equipped

■

PDA (Proactive Driving Assist)



P.277

■

RSA (Road Sign Assist)



P.285

: If equipped

■

Dynamic radar cruise control



P.287

■

Cruise control



P.298

■

Emergency Driving Stop System



P.303

■

Traffic Jam Assist



P.305

: If equipped

■

Driver monitor



P.251

: If equipped

Various sensors are used to obtain the
necessary information for system
operation.

■

Sensors which detect the sur-
rounding conditions

Front radar sensor
Front camera

Front side radar sensors

Rear side radar sensors

WARNING

●

When the tires are excessively worn or

the inflation pressure of the tires is low

●

When tires other than the manufac-

turer specified size are installed

●

When the vehicle cannot be driven

stably, due to a collision, malfunction,

etc.

Driving assist systems

Sensors used by Lexus Safety
System + 3

A
B
C
D

246

4-5. Using the driving support systems

: If equipped

■

Sensors which detect the driver
condition

Driver monitor camera

: If equipped

WARNING

■

To prevent malfunction of the radar

sensors

Observe the following precautions.

Failure to do so may lead to a radar sen-

sor not operating properly, possibly lead-

ing to an accident resulting in death or

serious injury.

●

Keep the radar sensors and radar sen-

sor covers clean at all times.

Clean the front of a radar sensor or the

front or back of a radar sensor cover if it

is dirty or covered with water droplets,

snow, etc.
When cleaning the radar sensor and

radar sensor cover, use a soft cloth to

remove dirt so as to not damage them.

Radar sensor
Radar sensor cover

A
B

Radar sensor
Radar sensor cover

●

Vehicles with front side radar sensors:

Keep the surrounding area of the front

side radar sensors on the front bumper

clean at all times.

●

Do not attach accessories, stickers

(including transparent stickers), alumi-

num tape, etc. to a radar sensor or

radar sensor cover and their surround-

ing area.

●

Do not subject a radar sensor or its

surrounding area to impact.

If a radar sensor, the front grille, or

front bumper has been subjected to a

impact, have the vehicle inspected by

your Lexus dealer.

●

Do not disassemble the radar sensors.

●

Do not modify or paint the radar sen-

sors or radar sensor cover, or replace

them with anything other than Lexus

genuine parts.

●

In the following situations, recalibra-

tion of the radar sensors will be neces-

sary. For details, contact your Lexus

dealer.

• When a radar sensor is removed and

installed, or replaced

• When the front bumper or the front

grille has been replaced

A
B

247

4-5. Using the driving support systems

Driving

WARNING

■

Radar sensor cover with a heater (if

equipped)

When the system determines that snow

may pile up over the radar sensor cover,

the heater will operate automatically. If

the area around the radar sensor cover is

to be touched, such as during cleaning,

make sure that the radar sensor cover is

cool enough to prevent burns.

■

To prevent malfunction of the front

camera

Observe the following precautions.

Failure to do so may lead to the front

camera not operating properly, possibly

leading to an accident resulting in death

or serious injury.

●

Always keep the windshield clean.

• If the windshield is dirty or covered

with an oily film, water droplets, snow,

etc., clean the windshield.

• Even if a glass coating agent is applied

to the windshield, it will still be neces-

sary to use the windshield wipers to

remove water droplets, etc. from the

area of the windshield in front of the

front camera.

• If the inner side of the windshield

where the front camera is installed is

dirty, contact your Lexus dealer.

●

Do not attach stickers (including trans-

parent stickers) or other items to the

area of the windshield in front of the

front camera (shaded area in the illus-

tration).

Approximately 1.6 in. (4 cm)
Approximately 1.6 in. (4 cm)

●

If the part of the windshield in front of

the front camera is fogged up or cov-

ered with condensation or ice, use the

windshield defogger to remove the

fog, condensation, or ice.

●

If water droplets cannot be properly

removed from the area of the wind-

shield in front of the front camera by

the windshield wipers, replace the

wiper insert or wiper blade.

●

Do not attach window tint to the wind-

shield.

●

Replace the windshield if it is damaged

or cracked.

If the windshield has been replaced,

recalibration of the front camera will

be necessary. For details, contact your

Lexus dealer.

●

Do not allow liquids to contact the

front camera.

●

Do not allow bright lights to shine into

the front camera.

A
B

248

4-5. Using the driving support systems

■

Precautions for use

Vehicles with a display audio: It is necessary

to enter a connected services contract,

provided by Lexus, to use these functions.

For details, contact your Lexus dealer.

●

Radar Cruise Control: Extended resume

time

WARNING

●

Do not damage the lens of the front

camera or allow it to become dirty.

When cleaning the inside of the wind-

shield, do not allow glass cleaner to

contact the lens of the front camera.

Do not touch the lens of the front cam-

era.

If the lens of the front camera is dirty or

damaged, contact your Lexus dealer.

●

Do not subject the front camera to a

strong impact.

●

Do not change the position or orienta-

tion of the front camera or remove it.

●

Do not disassemble the front camera.

●

Do not modify any parts around the

front camera, such as the inside rear

view mirror or ceiling.

●

Do not attach accessories which may

obstruct the front camera to the hood,

front grille, or front bumper. For details,

contact your Lexus dealer.

●

If a surfboard or other long object is to

be mounted on the roof, make sure

that it will not obstruct the front cam-

era.

●

Do not modify or change the head-

lights and other lights.

■

Front camera installation area on the

windshield

If the system determines that the wind-

shield may be fogged up, it will automati-

cally operate the heater to defog the part

of the windshield around the front cam-

era. When cleaning, etc., be careful not

to touch the area around the front cam-

era until the windshield has cooled suffi-

ciently, as touching it may cause burns.

■

Precautions for the driver monitor

camera (if equipped)

Observe the following precautions.

Failure to do so may lead to malfunction

of the driver monitor camera and the sys-

tems not operating properly, possibly

leading to an accident resulting in death

or serious injury.

●

Do not subject the driver monitor

camera or its surrounding area to

strong impact.

●

If subjected to a strong impact, the

driver monitor camera may move out

of alignment and the driver may no

longer be detected correctly. In this

case, have the vehicle inspected by

your Lexus dealer.

●

Do not disassemble or modify the

driver monitor camera.

●

Do not attach accessories, stickers

(including transparent stickers), etc. to

the driver monitor camera or its sur-

rounding area.

●

Do not allow the driver monitor cam-

era or its surrounding area to get wet.

●

Do not cover the driver monitor cam-

era or place anything in front of it.

●

Keep the lens of the driver monitor

camera free from damage.

●

Do not touch the lens of the driver

monitor camera or allow it to become

dirty.

When there is dirt or fingerprints on the

camera lens, clean it with a dry, soft cloth

so as to not mark or damage it.

●

When cleaning the lens, do not use

detergents or organic solvents that

may damage plastic.

249

4-5. Using the driving support systems

Driving



P.287

●

Traffic Jam Assist (if equipped)



P.305

■

Situations in which the sensors may not

operate properly

●

When the height or inclination of the

vehicle has been changed due to modifi-

cations

●

When the windshield is dirty, fogged up,

cracked or damaged

●

When the ambient temperature is high or

low

●

When mud, water, snow, dead insects,

foreign matter, etc., is attached to the

front of the sensor

●

When in inclement weather such as

heavy rain, fog, snow, or a sandstorm

●

When water, snow, dust, etc. is thrown up

in front of the vehicle, or when driving

through mist or smoke

●

When the headlights are not illuminated

while driving in the dark, such as at night

or when in a tunnel

●

When the lens of a headlight is dirty and

illumination is weak

●

When the headlights are misaligned

●

When a headlight is malfunctioning

●

When the headlights of another vehicle,

sunlight, or reflected light shines directly

into the front camera

●

When the brightness of the surrounding

area changes suddenly

●

When driving near a TV tower, broad-

casting station, electric power plant,

radar equipped vehicles, etc., or other

location where strong radio waves or

electrical noise may be present

●

When a wiper blade is blocking the front

camera

●

When in a location or near objects which

strongly reflect radio waves, such as the

following:

• Tunnels

• Truss bridges

• Gravel roads

• Rutted, snow-covered roads

• Walls

• Large trucks

• Manhole covers

• Guardrail

• Metal plates

●

When near a step or protrusion

●

When a detectable vehicle is narrow,

such as a small mobility vehicle

●

When a detectable vehicle has a small

front or rear end, such as an unloaded

truck

●

When a detectable vehicle has a low

front or rear end, such as a low bed trailer

●

When a detectable vehicle has extremely

high ground clearance

●

When a detectable vehicle is carrying a

load which protrudes from its cargo area

●

When a detectable vehicle has little

exposed metal, such as a vehicle which is

partially covered with cloth, etc.

●

When a detectable vehicle is irregularly

shaped, such as a tractor, sidecar, etc.

●

When the distance between the vehicle

and a detectable vehicle has become

extremely short

●

When a detectable vehicle is at an angle

●

When snow, mud, etc. is attached to a

detectable vehicle

●

When driving on the following kinds of

roads:

• Roads with sharp curves or winding

roads

Lexus RX350h (2024 year). Manual in english - page 7
