6-3. Do-it-yourself maintenance

■

When to register the position of
each wheel

It is necessary to register the position
of each wheel after performing a tire
rotation.
Wheel position registration can be
performed by oneself. Wheel position
registration is performed by driving
forward with moderate left and right
turns. However, depending on the driv-
ing conditions and driving environ-

ment, registration may take some time
to complete.

■

Registering the position of each
wheel

Park the vehicle in a safe place, turn
the engine switch off and wait 15
minutes or more.

Start the engine.

The wheel position registration procedure

cannot be performed while the vehicle is

moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Tire rotation”.

Select “Continue”.

A message indicating that wheel position

registration is being performed will be dis-

played on the multi-information display.

“---” will be displayed for the tire inflation

pressure of each tire and wheel position

registration will begin.

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

When wheel position registration is com-

plete, a message indicating that registra-

tion has been completed and the inflation

pressure of each tire will be displayed on

the multi-information display.
Even if it is not possible to drive continu-

ously at approximately 25 mph (40 km/h)

or more, registration can be completed by

driving for a long time. However, if registra-

tion does not complete after driving for 1

hour or more, park the vehicle in a safe

place and leave it with the engine switch in

ON for approximately 15 minutes or more,

and then perform the driving procedure

again.

NOTICE

■

Repairing or replacing tires, wheels,

tire pressure warning valves, trans-

mitters and tire valve caps

●

When removing or fitting the wheels,

tires or the tire pressure warning

valves and transmitters, contact your

Lexus dealer as the tire pressure warn-

ing valves and transmitters may be

damaged if not handled correctly.

●

Make sure to install the tire valve caps.

If the tire valve caps are not installed,

water could enter the tire pressure

warning valves, corrode the valve, and

cause sticking and air leaks.

●

When replacing tire valve caps, do not

use tire valve caps other than those

specified. The cap may become stuck.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact your Lexus

dealer or other qualified service shop as

soon as possible. Make sure to replace

the tire pressure warning valve and trans-

mitter when replacing the tire. (



P.441)

Registering the position of each
wheel

443

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

When performing wheel position regis-

tration

●

Normally, wheel position registration can

be completed within approximately 30

minutes.

●

Wheel position registration is performed

while driving at a vehicle speed of

approximately 25 mph (40 km/h) or

more.

■

Wheel position registration procedure

●

If the engine switch is turned off while

registering the wheel position, the next

time the engine switch is turned to ON,

the wheel position registration will

resume and it will not be necessary to

restart the procedure.

●

While the position of each wheel is being

determined and the inflation pressures

are not being displayed, if the inflation

pressure of a tire drops, the tire pressure

warning light will come on.

■

If the wheel position cannot be regis-

tered easily

●

In the following situations, wheel position

registration may take longer than usual to

be completed or may not be possible.

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads

●

If wheel position registration does not

complete after driving for 1 hour or more,

park the vehicle in a safe place for

approximately 15 minutes and then drive

the vehicle again.

●

If the vehicle is reversed during wheel

position registration, all data collected

until then will be cleared. Perform driving

again.

■

When you need to setting the tire
pressure

In the following situations, it will be nec-
essary to perform the tire inflation
pressure setting procedure of the tire

pressure warning system.



When the specified tire inflation
pressure has changed, such as due
to carried load, etc.



When the tire inflation pressure is
changed such as when the tire size
is changed.

If the tire inflation pressure has been
adjusted to the specified level, perform
the tire inflation setting procedure by
selecting specified inflation pressure
on the center display. (



P.443)

When the tire inflation pressure is to be
other than specified, such as when tires
other than the specified size are used,
etc., set the tire inflation pressure using
the current pressure. Make sure to
adjust the tire inflation pressure of each
tire to the appropriate level before per-
forming tire pressure setting. The tire
pressure warning system operates
based on this tire inflation pressure.
(



P.444)

■

Setting by selecting a specified tire
inflation pressure

Park the vehicle in a safe place and
then start the engine.

The tire inflation pressure cannot be set

while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Set indicated air pressure”
and then select the desired front
and rear tire pressures. (



P.448)

Select “OK”.

The tire pressure warning light will slowly

Setting the tire pressure

444

6-3. Do-it-yourself maintenance

blink 3 times.
After setting the tire inflation pressure, a

message indicating that setting has been

completed will be displayed on the

multi-information display.

■

Setting using the current tire infla-
tion pressure

Adjust the tire inflation pressure of
each tire to the appropriate level.

Make sure to adjust the tire inflation pres-

sure with the tires cold.

Start the engine.

The tire inflation pressure cannot be set

while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select “Set current air pressure”.

Select “Continue”.

The tire pressure warning light will slowly

blink 3 times and a message indicating that

tire inflation pressure is being set will be

displayed on the multi-information display.
After setting the tire inflation pressure, a

message indicating that setting has been

completed will be displayed on the

multi-information display.

■

Warning performance of the tire pres-

sure warning system (Setting using the

current tire inflation pressure)

●

When performing the tire pressure set-

ting using the current tire inflation pres-

sure, the warning timing of the tire

pressure warning system will vary

according to the conditions under which

tire pressure setting was performed.

Therefore, a warning may be output even

if the tire inflation pressure drops slightly

or if the tire inflation pressure increases

above that when the tire inflation pres-

sure was set.

●

Make sure to perform the tire pressure

setting procedure after adjusting the tire

inflation pressure. Also, make sure the

tires are cold before performing the tire

pressure setting procedure or adjusting

the tire inflation pressure.

■

Tire inflation pressure setting proce-

dure (Setting using the current tire infla-

tion pressure)

●

If the engine switch is turned off while set-

ting the tire inflation pressure, the next

time the engine switch is turned to ON,

the setting procedure will resume and it

will not be necessary to restart the proce-

dure.

●

If the tire inflation pressure setting proce-

dure is started unnecessarily, adjust the

tire inflation pressure to the specified

level with the tires cold and then perform

setting by selecting a specified tire infla-

tion pressure, or perform the tire inflation

pressure setting procedure with the cur-

rent tire inflation pressure.

445

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

If the tire inflation pressure cannot be

set easily

●

Normally, it takes approximately 3 min-

utes to complete the setting procedure to

the current tire inflation pressure.

●

If the tire pressure warning light does not

blink 3 times when starting the tire infla-

tion pressure setting procedure, the pro-

cedure may not have started. Perform the

procedure again from the beginning.

●

If tire inflation pressure setting procedure

cannot be completed after performing

the above procedure, contact your Lexus

dealer.

■

When to register ID codes

The tire pressure warning valve and
transmitter is equipped with a unique
ID code. When new tire pressure
warning valves and transmitters are
installed, new ID codes must be regis-
tered in the tire pressure warning com-
puter.

■

How to registration ID code

Before performing ID code registra-
tion, make sure that no wheels with tire
pressure warning valve and transmit-
ters installed are near the vehicle.

Park the vehicle in a safe place, turn
the engine switch off and wait 15
minutes or more.

Start the engine.

The ID code registration procedure cannot

be performed while the vehicle is moving.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Check if the desired wheel set (“Set
1” or “Set 2”) is displayed.

ID codes will be registered to the displayed

wheel set.
To change the wheel set to be registered,

select the displayed set, and then select the

wheel set you wish to register.
If ID codes have already been registered

for that wheel set, the tire pressure warning

light will slowly blink 3 times, and a mes-

sage indicating that change is occurring

will be displayed on the multi-information

display.

Select “New tire registration”.

Select “Continue”.

The tire pressure warning light will slowly

blink 3 times and a message indicating that

ID code registration is being performed

will be displayed on the multi-information

display. Wheel set changing will be can-

celed and registration will begin.
When registration is being performed, the

tire pressure warning light will blink for

approximately 1 minute then illuminate and

WARNING

■

When setting using the current tire

inflation pressure

Make sure to adjust the tire inflation

pressure of each tire to the appropriate

level before performing tire pressure set-

ting. Otherwise, the tire pressure warn-

ing light may not illuminate even if the tire

inflation pressure drops or may illuminate

even though the tire inflation pressure is

normal.

Registering ID codes

446

6-3. Do-it-yourself maintenance

“---” will be displayed for the inflation pres-

sure of each tire on the multi-information

display.

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

When registration is complete, the tire

pressure warning light will turn off and a

message indicating that registration has

been completed will be displayed on the

multi-information display.
Registration may take longer than normal

to complete if the vehicle speed cannot be

maintained at approximately 25 mph (40

km/h) or more. If registration cannot be

completed after driving for 1 hour or more,

perform the registration procedure again

from the beginning.

If the tire inflation pressure of the
wheel set installed differs from that
of the previous set, it will be neces-
sary to perform the tire inflation
pressure setting procedure of the
tire pressure warning system.
(



P.443)

If the specified tire inflation pressure is the

same, it will not be necessary to perform

the tire inflation pressure setting proce-

dure.

■

When registering ID codes

●

Normally, wheel position registration can

be completed within approximately 30

minutes.

●

ID code registration is performed while

driving at a vehicle speed of approxi-

mately 25 mph (40 km/h) or more.

●

ID codes can be registered by yourself,

but depending on the driving conditions

and driving environment, registration

may take some time to complete.

●

When using a wheel set which all of the

ID codes have already been registered,

the wheel set can be changed in a short

amount of time. (



P.447)

■

If ID codes are not registered easily

●

In the following situations, ID code regis-

tration may take longer than usual to be

completed or may not be possible.

• When the vehicle has not been parked

for approximately 15 minutes or more

before being driven

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads

• Vehicle is driven near other vehicles and

system cannot recognize tire pressure

warning valve and transmitters of your

vehicle over those of other vehicles

• Wheel with tire pressure warning valve

and transmitter installed is inside or near

the vehicle

●

If the vehicle is reversed during registra-

tion, all data collected until then will be

cleared. Perform driving again.

●

If registration does not complete after

driving for 1 hour or more, perform the ID

code registration procedure again from

the beginning.

●

If the tire pressure warning light does not

blink 3 times when starting ID code reg-

istration procedure, the procedure may

not have started. Perform the procedure

again from the beginning.

●

If the ID codes cannot be registered even

when performing the above procedure,

contact your Lexus dealer.

■

Canceling ID code registration

To cancel ID code registration after it has

been started, select “New tire registration”

again on the center display.
If ID code registration has been canceled,

the tire pressure warning light will turn off.

447

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

If the warning light does not turn off, ID
code registration may not have been can-
celled correctly. To cancel registration,
select “New tire registration” again on the
center display.

Your vehicle is equipped with a tire
pressure warning system with a func-
tion to register two sets of ID codes.
This allows for registration of a second
wheel set, for example a winter set.



The wheel set can be changed only
if a second wheel set has been regis-
tered to the system. If a second
wheel set has not been registered,
“Set 2 (Unregistered)” will be dis-
played and it will not be possible to
change to the selected wheel set.

ID codes can be registered by yourself.
(



P.445)



Only a change between both regis-
tered wheel set is possible, mixing
between these wheel sets is not sup-
ported.



While registering ID codes, it may
not be possible to change between
wheel sets normally. Cancel regis-
tration before changing between
wheel sets.

■

Changing ID codes between dif-
ferent wheel sets

Install the desired wheel set.

Select

on the center display.

Select “Vehicle customize”.

Select “Tire pressure”.

Select the wheel set (“Set 1” or “Set
2”) displayed for the set selection
setting.

Select the wheel set you wish to
register, and then select “OK”.

The tire pressure warning light will slowly

blink 3 times, a message indicating that

change is occurring will be displayed, and

the wheel set change will begin.
Wheel set change will begin and the tire

pressure warning light will blink for 1 min-

ute and then illuminate. Also, while the

change is being performed, “---” will be

displayed for the tire inflation pressure of

each tire on the multi-information display.
After approximately 2 minutes, the wheel

set change will complete, the tire pressure

warning light will turn off, and a completion

message will be displayed on the

multi-information display.
If changing does not complete after

approximately 4 minutes, a message indi-

cating that the change could not be com-

pleted will be displayed.
Check which wheel set is installed and per-

form the change procedure again from the

beginning.

If the specified tire inflation pres-
sure of the wheel set installed dif-
fers from that of the previous set, it
will be necessary to perform the
tire inflation pressure setting proce-
dure of the tire pressure warning
system. (



P.443)

If the specified tire inflation pressure is the

Selecting wheel set

448

6-3. Do-it-yourself maintenance

same, it will not be necessary to perform

the tire inflation pressure setting proce-

dure.



P.442)

■

If “Tire Set Switching Incomplete Try

Tire Set Registration Again See

Owner's Manual” is displayed

The wheel set change could not be com-

pleted.
Check which wheel set is installed and per-

form the change procedure again from the

beginning.

The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
(



P.516)

Tire valve
Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure
gauge onto the tire valve.

Tire inflation pressure

Checking the specified tire infla-
tion pressure

Inspection and adjustment pro-
cedure

449

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Read the pressure using the gauge
gradations.

If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.

After completing the tire inflation
pressure measurement and adjust-
ment, apply soapy water to the
valve and check for leakage.

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure

every two weeks, or at least once a month.

Do not forget to check the spare.

■

Effects of incorrect tire inflation pres-

sure

Driving with incorrect tire inflation pressure

may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor han-

dling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating, have it

checked by your Lexus dealer.

■

Instructions for checking tire inflation

pressure

When checking tire inflation pressure,

observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at

least 3 hours or has not been driven for

more than 1 mile or 1.5 km, you will get an

accurate cold tire inflation pressure read-

ing.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly

inflated based only on its appearance.

●

It is normal for the tire inflation pressure

to be higher after driving as heat is gen-

erated in the tire. Do not reduce tire infla-

tion pressure after driving.

●

Never exceed the vehicle capacity

weight.

Passengers and luggage weight should

be placed so that the vehicle is balanced.

WARNING

■

Proper inflation is critical to save tire

performance

Keep your tires properly inflated.

If the tires are not properly inflated, the

following conditions may occur which

could lead to an accident resulting in

death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from

overheated tires

●

Air leaking from between tire and

wheel

●

Wheel deformation and/or tire dam-

age

●

Greater possibility of tire damage

while driving (due to road hazards,

expansion joints, sharp edges in the

road, etc.)

NOTICE

■

When inspecting and adjusting tire

inflation pressure

Be sure to put the tire valve caps back on.

If a valve cap is not installed, dirt or mois-

ture may get into the valve and cause an

air leak, resulting in decreased tire infla-

tion pressure.

450

6-3. Do-it-yourself maintenance

When replacing wheels, care should
be taken to ensure that they are equiv-
alent to those removed in load capac-
ity, diameter, rim width and inset

Replacement wheels are available at
your Lexus dealer.

: Conventionally referred to as offset.

Lexus does not recommend using the
following:



Wheels of different sizes or types



Used wheels



Bent wheels that have been straight-
ened

■

When replacing wheels

The wheels of your vehicle are equipped

with tire pressure warning valves and trans-

mitters that allow the tire pressure warning

system to provide advance warning in the

event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pres-

sure warning valves and transmitters must

be installed. (



P.441)

Wheels

If a wheel is bent, cracked or heavily
corroded, it should be replaced.
Otherwise, the tire may separate
from the wheel or cause a loss of
handling control.

Wheel selection

WARNING

■

When replacing wheels

●

Do not use wheels that are a different

size from those recommended in the

Owner’s Manual, as this may result in a

loss of handling control.

●

Never use an inner tube in a leaking

wheel which is designed for a tubeless

tire.

Doing so may result in an accident,

causing death or serious injury.

■

When installing the wheel nuts

Never use oil or grease on the wheel

bolts or wheel nuts.

Oil and grease may cause the wheel nuts

to be excessively tightened, leading to

bolt or disc wheel damage. In addition,

the oil or grease can cause the wheel

nuts to loosen and the wheel may fall off,

causing an accident and resulting in

death or serious injury. Remove any oil or

grease from the wheel bolts or wheel

nuts.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.

Doing so could cause the tire to leak air

during driving, possibly causing an acci-

dent.

NOTICE

■

Replacing tire pressure warning

valves and transmitters

●

Because tire repair or replacement

may affect the tire pressure warning

valves and transmitters, make sure to

have tires serviced by your Lexus

dealer or other qualified service shop.

In addition, make sure to purchase

your tire pressure warning valves and

transmitters at your Lexus dealer.

451

6-3. Do-it-yourself maintenance

Mai
nte

e a

are



Use only Lexus wheel nuts and
wrenches designed for use with
your aluminum wheels.



When rotating, repairing or chang-
ing your tires, check that the wheel
nuts are still tight after driving 1000
miles (1600 km).



Be careful not to damage the alumi-
num wheels when using tire chains.



Use only Lexus genuine balance
weights or equivalent and a plastic
or rubber hammer when balancing
your wheels.

Turn the engine switch off.

Open the glove box. Slide off the
damper.

Push in each side of the glove box
to disconnect the claws. Then pull
out the glove box and disconnect
the lower claws.

NOTICE

●

Ensure that only genuine Lexus wheels

are used on your vehicle.

Tire pressure warning valves and trans-

mitters may not work properly with

non-genuine wheels.

Aluminum wheel precautions

Air conditioning filter

The air conditioning filter must be
changed regularly to maintain air
conditioning efficiency.

WARNING

Do not use the Remote Air Conditioning

System. Doing so may result in the air

conditioning system operating during the

procedure, possibly resulting in injury.

Removing the air conditioning
filter

452

6-3. Do-it-yourself maintenance

Unlock the filter cover ( ), pull the
filter cover out of the claws ( ),
and remove the filter cover.

Remove the filter case.

There may be foreign objects on top of the

air conditioning filter.

Remove the air conditioning filter
from the filter case and replace it
with a new one.

The “

UP” marks shown on the filter

and the filter case should be pointing up.

■

Checking interval

Inspect and replace the air conditioning fil-

ter according to the maintenance schedule.

In dusty areas or areas with heavy traffic

flow, early replacement may be required.

(For scheduled maintenance information,

please refer to the “Owner’s Manual Sup-

plement” or “Scheduled Maintenance”.)

■

If air flow from the vents decreases dra-

matically

The filter may be clogged. Check the filter

and replace if necessary.

■

Air conditioning filter with deodorizing

function

When fragrances are placed in your vehi-

cle, the deodorizing effect may become

significantly weakened in a short period.

When an air conditioning odor comes out

continuously, replace the air conditioning

filter.

NOTICE

■

When using the air conditioning sys-

tem

●

Make sure that a filter is always

installed. Using the air conditioning

system without a filter may cause dam-

age to the system.

●

The filter is replaceable. When clean-

ing the filter, do not clean with water or

an air gun.

■

To prevent damage to the filter cover

When moving the filter cover in the

direction of arrow to release the fitting,

pay attention not to apply excessive force

to the claws. Otherwise, the claws may

be damaged.

453

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart access system with push-but-

ton start and wireless remote control will

not function properly.

●

The operational range will be reduced.

■

When the card key battery needs to be

replaced (if equipped)

The battery for the card key is available only

at your Lexus dealer can replace the bat-

tery for you.



Flathead screwdriver



Small flathead screwdriver



Lithium battery CR2032

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Lexus

dealer, local electrical appliance shops or

camera stores.

●

Replace only with the same or equivalent

type recommended by the manufacturer.

●

Dispose of used batteries according to

the local laws.

Take out the mechanical key.

Remove the cover.

To prevent damage to the key, cover the tip

of the flathead screwdriver with a tape.

Remove the depleted battery.

Insert a new battery with the “+” terminal

facing up.

Electronic key battery

Replace the battery with a new one
if it is depleted.
As the key may be damaged if the
following procedure is not per-
formed properly, it is recom-
mended that key battery
replacement be performed by your
Lexus dealer.

You will need the following items:

Replacing the battery

454

6-3. Do-it-yourself maintenance

WARNING

■

Battery precautions

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not swallow the battery. Doing so

may cause chemical burns.

●

A coin battery or button battery is

used in the electronic key. If a battery is

swallowed, it may cause severe chemi-

cal burns in as little as 2 hours and may

result in death or serious injury.

●

Keep away new and removed batteries

from children.

●

If the cover cannot be firmly closed,

stop using the electronic key and stow

the key in the place where children

cannot reach, and then contact your

Lexus dealer.

●

If you accidentally swallow a battery or

put a battery into a part of your body,

get emergency medical attention

immediately.

■

To prevent battery explosion or leak-

age of flammable liquid or gas

●

Replace the battery with a new battery

of the same type. If a wrong type of

battery is used, it may explode.

●

Do not expose batteries to extremely

low pressure due to high altitude or

extremely high temperatures.

●

Do not burn, break or cut a battery.

NOTICE

■

When replacing the battery

Use a flathead screwdriver of appropri-

ate size. Applying excessive force may

deform or damage the cover.

■

For normal operation after replacing

the battery

Observe the following precautions to

prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery to

rust.

●

Do not touch or move any other com-

ponent inside the remote control.

●

Do not bend either of the battery ter-

minals.

455

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Turn the engine switch off.

Open the fuse box cover.



Engine compartment

Push in the claw and remove the lid.
• Type A

• Type B



Driver’s side instrument panel

Remove the lid.

Remove the fuse with the pullout
tool.
Only some fuses can be removed
using the pullout tool.

Check if the fuse is blown.

Replace the blown fuse with a new fuse of

an appropriate amperage rating. The

amperage rating can be found on the fuse

box lid.
Many types of fuse are used on this vehicle.

This illustration shows a common type of

fuse used on this vehicle.



Type A

Normal fuse

Checking and replacing
fuses

If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.

Checking and replacing fuses

456

6-3. Do-it-yourself maintenance

Blown fuse



Type B

Normal fuse
Blown fuse



Type C

Normal fuse
Blown fuse



Type D

Normal fuse
Blown fuse

■

After a fuse is replaced

●

When installing the lid, make sure that the

tab is installed securely.

●

If the lights do not turn on even after the

fuse has been replaced, a bulb may need

replacement. (



P.458)

●

If the replaced fuse blows again, have the

vehicle inspected by your Lexus dealer.

■

If there is an overload in a circuit

The fuses are designed to blow, protecting

the wiring harness from damage.

■

When replacing light bulbs

Lexus recommends that you use genuine

Lexus products designed for this vehicle.

Because certain bulbs are connected to cir-

cuits designed to prevent overload,

non-genuine parts or parts not designed for

this vehicle may be unusable.

WARNING

■

To prevent system breakdowns and

vehicle fire

Observe the following precautions.

Failure to do so may cause damage to

the vehicle, and possibly a fire or injury.

●

Never use a fuse of a higher amperage

rating than that indicated, or use any

other object in place of a fuse.

●

Always use a genuine Lexus fuse or

equivalent.

Never replace a fuse with a wire, even

as a temporary fix.

●

Do not modify the fuses or fuse boxes.

NOTICE

■

Before replacing fuses

Have the cause of electrical overload

determined and repaired by your Lexus

dealer as soon as possible.

457

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Adjustment bolt A
Adjustment bolt B

Make sure the vehicle has a full
tank of gasoline and the area
around the headlight is not
deformed.

Park the vehicle on level ground.

Make sure the tire inflation pres-
sure is at the specified level.

Have someone sit in the driver’s
seat.

Bounce the vehicle several times.

Using a Phillips-head screwdriver,
turn bolt A in either direction.

Remember the turning direction and the

number of turns.

Turn bolt B the same number of
turns and in the same direction as
step

If the headlight cannot be adjusted using

this procedure, take the vehicle to your

Lexus dealer to adjust the headlight aim.

Headlight aim

Vertical movement adjusting
bolts

Before checking the headlight
aim

Adjusting the headlight aim

458

6-3. Do-it-yourself maintenance

■

LED Lights

The lights consist of a number of LEDs. If

any of the LEDs burn out, take your vehicle

to your Lexus dealer to have the light

replaced.

■

Condensation build-up on the inside of

the lens

Temporary condensation build-up on the

inside of the lens of any light does not indi-

cate a malfunction. Contact your Lexus

dealer for more information in the following

situations:

●

Large drops of water have built up on the

inside of the lens.

●

Water has built up inside the headlight.

Light bulbs

If any lights burn out, have it
replaced by your Lexus dealer.

459

When trouble

ari

ses

When trouble arises

7-1. Essential information

Emergency flashers..................

460

If your vehicle has to be stopped in

an emergency..........................

460

If the vehicle is submerged or

water on the road is rising ...

461

7-2. Steps to take in an emergency

If your vehicle needs to be towed

........................................................

463

If you think something is wrong

........................................................

465

Fuel pump shut off system .....

466

If a warning light turns on or a

warning buzzer sounds .......

467

If a warning message is displayed

........................................................

477

If you have a flat tire..................

484

If the engine will not start .......

492

If you lose your keys.................

493

If the fuel filler door cannot be

opened........................................

494

If the electronic key does not

operate properly ....................

494

If a door cannot be opened using

the door opener switch........

496

If the vehicle battery is discharged

........................................................

498

If your vehicle overheats ........

504

If the vehicle becomes stuck

........................................................

506

460

7-1. Essential information

7-1.Essential information

Press the switch.

All the turn signal lights will flash. To turn
them off, press the switch once again.

■

Emergency flashers

●

If the emergency flashers are used for a

long time while the engine is not operat-

ing, the battery may discharge.

●

If any of the SRS airbags deploy (inflate)

or in the event of a strong rear impact, the

emergency flashers will turn on automati-

cally.

The emergency flashers will turn off auto-

matically after operating for approxi-

mately 20 minutes. To manually turn the

emergency flashers off, press the switch

twice. (The emergency flashers may not

turn on automatically depending on the

force of the impact and conditions of the

collision.)

Steadily step on the brake pedal
with both feet and firmly depress it.

Do not pump the brake pedal repeatedly

as this will increase the effort required to

slow the vehicle.

Shift the shift position to N.



If the shift position is shifted to N

After slowing down, stop the vehi-
cle in a safe place by the road.

Stop the engine.



If the shift position cannot be shifted
to N

Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.

To stop the engine, press and hold
the engine switch for 2 consecutive

Emergency flashers

The emergency flashers are used to
warn other drivers when the vehicle
has to be stopped on the road due
to a breakdown, etc.

Operating instructions

If your vehicle has to be
stopped in an emergency

Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:

Stopping the vehicle

461

7-1. Essential information

n t

ris

seconds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by
the road.



If the door can be opened, open the
door and exit the vehicle.



If the door cannot be opened, open
the window using the power window
switch and ensure an escape route.



If the window can be opened, exit
the vehicle through the window.



If the door and window cannot be
opened due to the rising water,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle and then
open the door after waiting for the
rising water to enter the vehicle, and
exit the vehicle. When the outside
water level exceeds half the height
of the door, the door cannot be
opened from the inside due to water
pressure.

■

Water level exceeds the floor

When the water level exceeds the floor and

time has passed, the electrical equipment

will get damaged, the power windows will

WARNING

■

If the engine has to be turned off while

driving

Power assist for the brakes and steering

wheel will be lost, making the brake

pedal harder to depress and the steering

wheel heavier to turn. Decelerate as

much as possible before turning off the

engine.

If the vehicle is submerged
or water on the road is rising

This vehicle is not designed to be
able to drive on roads that are
deeply floodedwith water. Do not
drive on roads where the roads may
be submerged or the water may be
rising. It is dangerous to remain in
the vehicle, if it is anticipated that
the vehicle will be flooded or set
adrift. Remain calm and follow the
following.

462

7-1. Essential information

not operate, the engine stop, and the vehi-

cle may not be able to get moving.

■

Using an emergency escape hammer

Laminated glass

is used in the windshield

and the windows on this vehicle.
Laminated glass cannot be shattered with
an emergency hammer

: Contact your Lexus dealer or aftermar-

ket accessory manufacturer for further
information about an emergency ham-
mer.

: If equipped

■

How to distinguish laminated glass

When looking from the cross-sectional

view point, laminated glass is two sheets of

glass pasted together.

Laminated glass
Tempered glass

WARNING

■

Caution while driving

Do not drive on roads where the roads

may be submerged or the water may be

rising. Otherwise the vehicle may be

damaged and cannot move, as well as

become flooded and set adrift, which

may lead to death.

463

7-2. Steps to take in an emergency

n t

ris

7-2.Steps to take in an emergency



From the front (2WD models)

Release the parking brake.
Turn automatic mode off. (



P.193)



From the front (AWD models)

Use a towing dolly under the rear
wheels.



From the rear

Use a towing dolly under the front
wheels.

If your vehicle needs to be
towed

If towing is necessary, we recom-
mend having your vehicle towed by
your Lexus dealer or commercial
towing service, using a wheel-lift
type truck or flatbed truck.

Use a safety chain system for all
towing, and abide by all state/pro-
vincial and local laws.

Towing with a wheel-lift type
truck

WARNING

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

■

When towing the vehicle



2WD models

Be sure to transport the vehicle with the

front wheels raised or with all four wheels

raised off the ground. If the vehicle is

towed with the front wheels contacting

the ground, the drivetrain and related

parts may be damaged.

464

7-2. Steps to take in an emergency

When using a flat-bed truck to trans-
port the vehicle, use tire strapping
belts. Refer to the owner’s manual of
the flat-bed truck for the tire strapping
method.
In order to suppress vehicle movement
during transportation, set the parking
brake and turn the engine switch off.

WARNING



AWD models

Be sure to transport the vehicle with all

four wheels raised off the ground. If the

vehicle is towed with the tires contacting

the ground, the drivetrain or related

parts may be damaged, the vehicle may

fly off the truck.

NOTICE

■

To prevent damage to the vehicle

when towing using a wheel-lift type

truck

●

Do not tow the vehicle from the rear

when the engine switch is off. The

steering lock mechanism is not strong

enough to hold the front wheels

straight.

●

When raising the vehicle, ensure ade-

quate ground clearance for towing at

the opposite end of the raised vehicle.

Without adequate clearance, the vehi-

cle could be damaged while being

towed.

■

Towing with a sling-type truck

Do not tow with a sling-type truck to pre-

vent body damage.

Using a flatbed truck

NOTICE

■

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

465

7-2. Steps to take in an emergency

When trouble

ari

ses



Fluid leaks under the vehicle
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
continually points higher than nor-
mal



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the engine



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact your Lexus dealer as soon as
possible.

Visible symptoms

Audible symptoms

Operational symptoms

467

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(red)

(Canada)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and contact your Lexus
dealer. Continuing to drive the vehicle may be dangerous.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the parking brake system



Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

Indicates that the engine coolant temperature is too high



Immediately stop the vehicle in a safe place.
Handling method (



P.504)

468

7-2. Steps to take in an emergency

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Malfunction indicator lamp

■

SRS warning light

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and contact your Lexus
dealer.

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and contact your Lexus
dealer.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The electronic engine control system;



The electronic throttle control system;



The electronic automatic transmission control system; or



The stop & start system



Immediately stop the vehicle in a safe place and contact your Lexus
dealer.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system;



The front passenger occupant classification system; or



The seat belt pretensioner system



Have the vehicle inspected by your Lexus dealer immediately.

469

7-2. Steps to take in an emergency

When trouble

ari

ses

■

ABS warning light

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Electric power steering system warning light (warning buzzer)

■

Low fuel level warning light

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning;



Drive-Start Control is malfunctioning; or



Drive-Start Control is operating;



Follow the instructions displayed on the multi-information display.

When a buzzer does not sound:
Brake Override System is operating



Release the accelerator pedal and depress the brake pedal.

Warning light

Details/Actions

(red/yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system



Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

Indicates that remaining fuel is approximately 2.6 gal. (10.1 L, 2.2 Imp.
gal.) or less



Refuel the vehicle.

470

7-2. Steps to take in an emergency

■

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is not
fastened. Once the engine switch is turned to ON, the buzzer sounds. If the seat belt is still
unfastened, the buzzer sounds intermittently for a certain period of time after the vehicle
reaches a certain speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front passenger that his
or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermit-
tently for a certain period of time after the vehicle reaches a certain speed.

■

Rear passengers’ seat belt reminder light (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his or
her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermittently
for a certain period of time, after the seat belt is fastened and unfastened and the vehicle
reaches a certain speed.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat
belt also needs to be fastened to make the warning light (warning
buzzer) turn off.

Warning light

Details/Actions

Warns the second and/or third seat passengers to fasten their seat belts.
An indicator corresponding to an unfastened second or third seat seat
belt will illuminate.



Fasten the seat belt.

471

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Tire pressure warning light (warning buzzer)

■

Stop & Start cancel indicator (warning buzzer)

■

PCS warning light (warning buzzer)

■

LTA indicator (warning buzzer)

Warning light

Details/Actions

When the light comes on (a buzzer sounds):



Low tire inflation pressure from natural causes



After the temperature of the tires has lowered sufficiently, check
the inflation pressure of each tire and adjust them to the specified
level.



Low tire inflation pressure from flat tire



Immediately stop the vehicle in a safe place and perform the nec-
essary actions. (



P.474)

When the light comes on after blinking for approximately 1 minute (a
buzzer does not sounds):
Malfunction in the tire pressure warning system



Have the system checked by your Lexus dealer.

Warning light

Details/Actions

(flashes)

Indicates a malfunction in the Stop & Start system



Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Collision System).



Follow the instructions displayed on the multi-information display.

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Control)
system is disabled, the PCS warning light will illuminate.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-information display.

472

7-2. Steps to take in an emergency

■

LDA indicator (warning buzzer)

■

PDA indicator (warning buzzer)

■

Dynamic radar cruise control indicator (warning buzzer)

■

Cruise control indicator (warning buzzer)

■

Driving assist information indicator

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the LDA (Lane Departure Alert).



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the PDA (Proactive Driving Assist).



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

Indicates either of the following systems may be malfunctioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Follow the instructions displayed on the multi-information display.

Indicates one of the following systems is malfunctioning or disabled.



PKSB (Parking Support Brake)



RCD (Rear Camera Detection)



BSM (Blind Spot Monitor)



RCTA (Rear cross traffic alert)



Safe Exit Assist (with door opening control)



Follow the instructions displayed on the multi-information display.

473

7-2. Steps to take in an emergency

When trouble

ari

ses

: If equipped

■

Intuitive parking assist OFF indicator (warning buzzer)

■

Slip indicator

: If equipped

■

Parking brake indicator

Warning light

Details/Actions

(if equipped)

When a buzzer sounds:
Indicates a malfunction in the intuitive parking assist function



Have the vehicle inspected by your Lexus dealer immediately.

When a buzzer sounds:
Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-information display.
(



P.482)

Warning light

Details/Actions

(illuminates)

Indicates a malfunction in:



The VSC system;



The TRAC system;



The Trail Mode function

;



The Trailer Sway Control

; or



The hill-start assist control system



Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

(flashes)

(U.S.A.)

(flashes)

(Canada)

It is possible that the parking brake is not fully engaged or released



Operate the parking brake switch once again.

This light comes on when the parking brake is not released. If the light
turns off after the parking brake is fully released, the system is operating
normally.

Lexus TX350 (2024 year). Manual in english - page 14
