P.440

The audio system-linked display dis-

plays the operating state of the audio
system on the multi-information dis-
play.
Operations such as selecting the audio
source or track, etc. can be performed.

The following information is displayed
on the multi-information display.



Map



Route guidance to destination



Speed limit of the current road
(linked to the navigation system)
(U.S.A. only)



Street name



Compass

The operating state of the following
systems can be displayed on the
multi-information display or head-up
display (if equipped).



Dynamic radar cruise control
(

P.261)



Cruise control (

P.273)



LTA (Lane Tracing Assist) (



P.237)



LDA (Lane Departure Alert)
(

P.245)



LCA (Lane Change Assist) (if
equipped) (

P.242)



RSA (Road Sign Assist) (if
equipped) (

P.259)

Tire pressure

Audio system-linked display

Navigation system-linked dis-
play

Driving support system informa-
tion display

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators



PDA (Proactive Driving Assist)
(



P.251)



PCS (Pre-Collision System)
(



P.226)

Pop-up displays will be displayed on
the multi-information display or the
head-up display (if equipped) when
necessary.

When a pop-up display is displayed, a cur-
rent display may no longer be displayed. In
this case, the display will return after the
pop-up display disappears.

■

Driving support systems

Displays a warning/suggestion/advice
message or the operating state of a rel-
evant system.



Dynamic radar cruise control



LTA (Lane Tracing Assist)



LDA (Lane Departure Alert)



LCA (Lane Change Assist) (if
equipped)



PDA (Proactive Driving Assist)



PCS (Pre-Collision System)



RSA (Road Sign Assist) (if
equipped)



Safe Exit Assist



FCTA (Front Cross Traffic Alert) (if
equipped)

■

Warning message

Some warning messages are displayed
when necessary, according to certain
conditions.

■

Hands-free system status

Displayed when the hands-free system
is operated.

■

Suggestion function

Displays suggestions to the driver in
the following situations. To select a
response to a displayed suggestion,
use the steering switches.
Suggestion to enable the power back
door:
If the power back door system is dis-
abled (setting on the center display set
to off) and the power back door switch
on the instrument panel is operated, a
suggestion message will be displayed
asking if you wish to enable the power
back door system.
To enable the power back door system,
select “Yes”.

After enabling the power back door sys-
tem, press the power back door switch
again to open or close the power back
door.

■

Steering wheel switch operation
display



Vehicles without a head-up display

Displayed when an audio remote con-
trol switch or a talk switch on the steer-
ing wheel is operated.



Vehicles with a head-up display

When a steering wheel switch is
touched, the icon of each switch and a
function guide is displayed. (

P.83)

■

Navigation system-linked informa-
tion

Depending on the situation, navigation

Pop-up display information

fore
dri
ving

Before driving

3-1. Key information

Keys ...................................................

Digital Key.......................................

3-2. Opening, closing and locking the

doors

Side doors .....................................

100

Power back door........................

105

Smart access system with

push-button start.....................

120

3-3. Adjusting the seats

Front seats.....................................

125

Rear seats......................................

126

Head restraints............................

133

3-4. Adjusting the steering wheel and

mirrors

Steering wheel.............................

135

Inside rear view mirror.............

136

Digital Rear-view Mirror.........

137

Outside rear view mirrors......

145

3-5. Opening, closing the windows

and moon roof

Power windows...........................

147

Panoramic moon roof ..............

149

3-6. Favorite settings

Driving position memory ........

153

My Settings...................................

157

3-1. Key information

3-1.Key information

The following keys are provided with
the vehicle.

Electronic keys

• Operating the smart access system with

push-button start (



P.120)

• Operating the wireless remote control

function (

P.96)

Mechanical keys
Key number plate
Card key (electronic key) (if
equipped)

Operating the smart access system with
push-button start (

P.120)

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside

the card key should be used only if a

problem arises, such as when the card

key does not operate properly.

●

If it is difficult to take out the mechanical

key, push down the lock release button

using a pen tip etc. If it is still difficult to

pull it out, use a coin etc.

●

To store the mechanical key in the card

key, insert it while pressing the lock

release button.

●

If the battery cover is not installed and the

battery falls out or if the battery was

removed because the key got wet, rein-

stall the battery with the positive terminal

facing the Lexus emblem.

■

When riding in an aircraft

When bringing an electronic key onto an

aircraft, make sure you do not press any

buttons on the electronic key while inside

the aircraft cabin. If you are carrying an

electronic key in your bag, etc., ensure that

the buttons are not likely to be pressed acci-

dentally. Pressing a button may cause the

electronic key to emit radio waves that

could interfere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

(The card key battery life is about a year

and a half.)

●

If the battery becomes low, an alarm will

sound in the cabin and a message will be

shown on the multi-information display

when the engine is stopped.

Keys

The keys

3-1. Key information

fore
dri
ving

●

To reduce key battery depletion when the

electronic key is to not be used for long

periods of time, set the electronic key to

the battery-saving mode. (



●

As the electronic key always receives

radio waves, the battery will become

depleted even if the electronic key is not

used. The following symptoms indicate

that the electronic key battery may be

depleted. Replace the battery when nec-

essary.

• The smart access system with push-but-

ton start or the wireless remote control

does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface

does not turn on.

●

You can replace the battery by yourself

(

P.453). However, as there is a danger

that the electronic key may be damaged,

it is recommended that replacement is

carried out by your Lexus dealer.

●

To avoid serious deterioration, do not

leave the electronic key within 3 ft. (1 m)

of the following electrical appliances that

produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and

battery chargers

• Recharging cellular phones or cordless

phones

• Table lamps

• Induction cookers

●

If the electronic key is near the vehicle for

longer than necessary, even if the smart

access system with push-button start is

not used, the key battery may become

depleted faster than normal. When not

using the smart access system with

push-button start, it is recommended not

to stay with the electronic key near the

vehicle longer than necessary.

■

Replacing the battery

P.453

■

The electronic key function is sus-

pended when

The electronic key function may be sus-

pended when the electronic key is kept

unmoved in a same location for a certain

period, such as it is left on a same place. This

is to reduce battery consumption. The func-

tion will be restored automatically when the

electronic key is moved, such as it is picked

up.

■

Confirmation of the registered key

number

The number of keys already registered to

the vehicle can be confirmed. Ask your

Lexus dealer for details.

■

If “A New Key has been Registered

Contact Your Dealer for Details” is

shown on the multi-information display

This message will be displayed each time

the driver’s door is opened when the doors

are unlocked from the outside for approxi-

mately one week after a new electronic key

has been registered.

If this message is displayed but you have not

had a new electronic key registered, ask

your Lexus dealer to check if an unknown

electronic key (other than those in your

possession) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to

strong shocks or bend them.

●

Do not expose the keys to high tem-

peratures for long periods of time.

●

Do not get the keys wet or wash them

in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic

materials to the keys or place the keys

close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else

to the surface of the electronic key.

●

Do not place the keys near objects that

produce magnetic fields, such as TVs,

audio systems and induction cookers.

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks all the doors (

Unlocks all the doors (



Opens the windows

and the pan-

oramic moon roof

*1, 2

(

Opens and closes the power back
door (



P.107)

Sounds the alarm

: These settings must be customized at

NOTICE

●

Do not place the keys near medical

electrical equipment such as low-fre-

quency therapy equipment or micro-

wave therapy equipment, and do not

receive medical attention with the keys

on your person.

■

Carrying the electronic key on your

person

Carry the electronic key 3.9 in. (10 cm)

or more away from electric appliances

that are turned on. Radio waves emitted

from electric appliances within 3.9 in. (10

cm) of the electronic key may interfere

with the key, causing the key to not func-

tion properly.

■

In case of a smart access system with

push-button start malfunction or

other key-related problems



P.493

■

When an electronic key is lost



P.493

■

Handling the card key (if equipped)

●

Do not apply excess force when insert-

ing the mechanical key into the card

key. Doing so may damage the card

key.

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the key,

immediately remove the battery cover

and wipe the battery and terminals. (To

remove the battery cover, lightly grasp

and pull it.) If the battery is corroded,

have your Lexus dealer replace the

battery.

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover. Forcibly removing the battery

cover may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

3-1. Key information

fore
dri
ving

your Lexus dealer.

: If equipped

■

Theft deterrent panic mode

When

is pressed for longer than

about one second, an alarm will sound

intermittently and the vehicle lights will flash

to deter any person from trying to break

into or damage your vehicle.
To stop the alarm, press any button on the

electronic key.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.494)

■

When required to leave the vehicle’s

key with a parking attendant

Lock the glove box as circumstances

demand. (

P.389)

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.493

■

If a wrong key is used

The key cylinder rotates freely, isolated

from the internal mechanism.

Using the mechanical key

3-1. Key information

: If equipped

■

Free/open source software information

This product contains Free/open source

software (FOSS). License information

and/or the source code of this FOSS can be

obtained at the following URL:
https://www.denso.com/global/en/

opensource/dkey/toyota/

In order to use the Digital Key, you
need to install the Lexus App. Register
the Vehicle to the customer’s Lexus
App profile, and subscribe to Remote
Services, and enroll in Digital Key.



A Digital Key can be used when the
smartphone and server can com-
municate. The Digital Key may
become unusable if the smartphone
is not connected to the Internet. Be
sure to carry the electronic key of
the vehicle if traveling to a location
with unreliable communications.



If the smartphone battery is
depleted, the smartphone cannot
be used as Digital Key. If the battery
level is low, be sure to charge the

smartphone prior to going out.



The Digital Key system is related to
the smart access system with
push-button start. If the smart
access system with push-button
start has been deactivated in the
vehicle customization setting, the
Digital Key will also be disabled.



Depending on the radio wave envi-
ronment, the Digital Key may not be
able to be used. (

P.122)



When transferring vehicle owner-
ship, make sure to delete the Digital
Keys.



If the vehicle is not operated for 14
days or more, the Digital Key will not
connect automatically. Therefore, it
may take some time before the sys-
tem operates after a door handle is
touched.



A part of the services may be
stopped for a certain period of time
due to server maintenance. How-
ever, registered Digital Keys can be
used during the maintenance.



A smartphone with the Digital Key
App enabled will be able to lock and
unlock the doors, start the engine
and perform any other operations
as same as the electronic key of the
vehicle. Be especially careful not to
lose the smartphone or allow it to be
stolen.

If the smartphone is lost or stolen, contact
your Lexus dealer immediately.



When taking your vehicle to a Lexus
dealer for an inspection or repairs,
make sure to bring an electronic

Digital Key

A smartphone can be used instead
of the electronic key of the vehicle
by installing the dedicated Digital
Key App on a smartphone. Also,
Digital Key can be shared with your
family or friends using the Digital
Key App.

Digital key usage conditions

Digital key precautions

100

3-2. Opening, closing and locking the doors

3-2.Opening, closing and locking the doors

■

Smart access system with
push-button start

Carry the electronic key to enable this
function.

Grip the driver’s door handle to
unlock the door. Holding the
driver’s door handle for approxi-
mately 2 seconds unlocks all the
doors. Grip any passenger door
handle to unlock all the doors.

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (indentation
on the surface of the door handle)
to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s
door. Pressing the button again within 5
seconds unlocks the other doors.
Press and hold to open the windows

and

panoramic moon roof

*1, 2

: This setting must be customized at your

Lexus dealer.

: If equipped

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the engine switch off.

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5

seconds while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

Side doors

The vehicle can be locked and
unlocked using the entry function,
wireless remote control or door
lock switches.

Unlocking and locking the doors
from the outside

101

3-2. Opening, closing and locking the doors

fore
dri
ving

To prevent unintended triggering of the

alarm, unlock the doors using the wireless

remote control and open and close a door

once after the settings have been changed.

(If a door is not opened within 60 seconds
after

is pressed, the doors will be

locked again and the alarm will automati-

cally be set.)

In a case that the alarm is triggered, imme-

diately stop the alarm. (



P.65)

■

Impact detection door lock release sys-

tem

If the vehicle is involved in a severe frontal

or rear collision, manual release handle

operation will be enabled for all of the

doors.

■

Operation signals

Doors:
A buzzer sounds and the emergency flash-

ers flash to indicate that the doors have

been locked/unlocked. (Locked: Once;

Unlocked: Twice)
Windows and panoramic moon roof:
A buzzer sounds.

■

Security feature

If a door is not opened within approximately

60 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

When the door cannot be locked by the

lock sensor on the surface of the door

handle

When the door cannot be locked even if the

lock sensor on the surface of the door han-

dle is touched by a finger, touch the lock

sensor with the palm.
When gloves are being worn, remove the

gloves.

■

Door lock buzzer

If an attempt to lock the doors using the

smart key system is made when a door is

not fully closed, a buzzer will sound continu-

ously for 5 seconds. Fully close the door to

stop the buzzer, and lock the doors again.

■

Setting the alarm

Locking the doors will set the alarm system.

(

P.65)

■

Conditions affecting the operation of

the smart access system with push-but-

ton start or wireless remote control



P.122

■

If the smart access system with

push-button start or the wireless remote

control does not operate properly

Use the mechanical key to lock and unlock

the doors. (

P.494)

Replace the key battery with a new one if it

is depleted. (

P.453)

■

If the battery is discharged

The doors cannot be locked and unlocked

using the smart access system with

push-button start or wireless remote con-

trol. Lock or unlock the doors using the

mechanical key. (



P.494)

Multi-information

display/Beep

Unlocking function

Exterior: Beeps 3

times

Holding the driver’s
door handle unlocks
only the driver’s
door.

Holding any of the
passenger door
handles unlocks all
the doors.

Exterior: Beeps

twice

Holding a door han-
dle unlocks all the
doors.

102

3-2. Opening, closing and locking the doors

■

Rear seat reminder function

As the first reminder so as not to forget lug-

gage, etc. in the rear seat, when the engine

switch is turned off after any of the following

conditions are met, a buzzer will sound and

a message will be displayed on the

multi-information display for approximately

6 seconds.
Also, as the second reminder, when the

doors are locked, a buzzer will sound and

the emergency flashers will flash for a few

seconds, and a message will be displayed

on the multi-information display

●

The engine is started within approxi-

mately 10 minutes after opening and

closing a rear door.

●

A rear door has been opened and closed

after the engine was started.

The second reminder will not be activated if

a rear door was opened before the doors

are locked.
However, if a rear door is opened and then

closed within approximately 2 seconds, the

rear seat reminder function may not oper-

ate.
The rear seat reminder function determines

that luggage, etc. has been placed in a rear

seat based on opening and closing of a rear

door. Therefore, depending on the situation,

the rear seat reminder function may not

operate and you may still forget luggage,

etc. in the rear seat, or it may operate

unnecessarily.

■

Customization

Some functions can be customized.

(



■

Door lock switches (to
lock/unlock)

Driver’s door: Locks all the doors
Doors other than the driver’s door:
Locks the doors

The indicator

comes on.

Driver’s door: Unlocks all the doors
Doors other than the driver’s door:

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant falling out,

resulting in death or serious injury.

●

Ensure that all doors are properly

closed and locked.

●

Do not press an inside door opener

switch while driving.

Be especially careful with the front doors,
as it can be opened even when the doors
are locked

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

When closing a door, swing it closed with

slight force applied to it. If you press on

the door by hand to close it, it may not be

closed completely.

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

Unlocking and locking the doors
from the inside

103

3-2. Opening, closing and locking the doors

fore
dri
ving

Unlocks the doors

The indicator

turns off.

Press the door opener switch of the
door handle to open the door.

Make sure to securely press the door
opener switch

on the inner side of the

door handle

■

If the vehicle battery is discharged

The doors cannot be locked or unlocked

using the smart access system with

push-button start or wireless remote con-

trol, and the door opener switches will not

operate.
Use the mechanical key to enable/disable

manual release handle operation. By

enabling manual release handle operation,

the door can be opened. (



P.496)

Press the front side of the door opener
switch to open the door.

Driver’s door: The door will open even if it
is locked.
When the door is unlocked, the door lock
indicator will turn off.

■

Inside door opener switch operating

conditions

When any of the following conditions are

met:

●

The vehicle speed is less than 2.5 mph (4

km/h) and the parking brake is engaged

●

The vehicle speed is less than 2.5 mph (4

km/h) and the brake pedal is depressed

●

The shift position is in P

■

When opening a door from inside the

vehicle

If the door is not fully unlatched, press the

door opener switch twice to open the door.

■

Manual release handles inside the vehi-

cle

The door opener switches inside the vehicle

can also be used to manually open the

doors.
A door can be opened through electronic

operation by pressing the door opener

switch, or it can be opened using the door

opener switch as a manual release handle

and pulling it twice.

Opening the doors from outside
the vehicle

Opening the doors from inside
the vehicle

105

3-2. Opening, closing and locking the doors

fore
dri
ving

Power back door

The power back door can be
opened using the power back door
opener switch, smart access system
with push-button start or wireless
remote control.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving the vehicle

Before driving the vehicle, make sure

that the power back door is fully closed. If

the power back door is not fully closed, it

may open unexpectedly while driving,

causing an accident.

■

Caution while driving

●

Keep the power back door closed

while driving.

If the power back door is left open, it may

hit nearby objects while driving or lug-

gage may be unexpectedly thrown out,

causing an accident.
In addition, exhaust gases may enter the

vehicle, causing death or a serious health

hazard. Make sure to close the power

back door before driving.

●

Never let anyone sit in the luggage

compartment. In the event of sudden

braking, sudden swerving or a colli-

sion, they are susceptible to death or

serious injury.

■

When children are in the vehicle

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not allow children to play in the lug-

gage compartment.

If a child is accidentally locked in the lug-

gage compartment, they could have heat

exhaustion or other injuries.

●

Do not allow a child to open or close

the power back door.

Doing so may cause the power back

door to move unexpectedly, or cause the

child’s hands, arms, head, or neck to be

caught by the closing power back door.

■

Operating the power back door

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in death or

serious injury.

●

Remove any heavy loads, such as snow

and ice, from the power back door

before opening it. Failure to do so may

cause the power back door to sud-

denly shut again after it is opened.

●

When opening or closing the power

back door, thoroughly check to make

sure the surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the power back door is about to open

or close.

●

Use caution when opening or closing

the power back door in windy weather

as it may move abruptly in strong wind.

106

3-2. Opening, closing and locking the doors

■

Smart access system with
push-button start

Carry the electronic key to enable this
function.

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

■

Wireless remote control

P.96

■

Door lock switch

P.102

WARNING

●

The power back door may suddenly

shut if it is not opened fully. It is more

difficult to open or close the back door

on an incline than on a level surface, so

beware of the back door unexpectedly

opening or closing by itself. Make sure

that the back door is fully open and

secure before using the luggage com-

partment.

●

When closing the power back door,

take extra care to prevent your fingers,

etc., from being caught.

●

When closing the power back door,

make sure to press it lightly on its outer

surface. If the back door handle is used

to fully close the power back door, it

may result in hands or arms being

caught.

●

Do not pull on the back door spindle

(



P.117) to close the power back

door, and do not hang on the back

door spindle.

Doing so may cause hands to be caught

or the back door spindle to break, caus-

ing an accident.

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, it may suddenly shut again after

being opened, causing someone’s

hands, arms, head or neck to be

caught and injured. When installing an

accessory part to the power back

door, using a genuine Lexus part is

recommended.

Unlocking and locking the
power back door from the out-
side

Unlocking and locking the
power back door from the inside

107

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Opening/closing the power back
door using the wireless remote
control

Press and hold the switch for approxi-
mately 1 second.

The power back door can be operated
whether it is locked

or unlocked.

Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.
Pressing and holding the switch again for
approximately 1 second will operate the
power back door in the opposite direction.

: Opening of the power back door when it

is locked can be disabled by a custom-
ized setting.

■

Opening/closing the power back
door from the inside

Press and hold the switch for approxi-
mately 1 second.

A buzzer will sound and the power back
door will automatically open or close.
However, if the power back door is locked,
it will not open.
Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.

Pressing and holding the switch again for
approximately 1 second will operate the
power back door in the opposite direction.

■

Back door opener switch



Open

When the power back door is unlocked:
Press the back door opener switch.
When the power back door is locked:
While carrying an electronic key, press and
hold the back door opener switch.
A buzzer will sound and the power back
door will automatically open.
Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.



Press the

switch.

A buzzer will sound and the power back
door will automatically close.

Pressing the

switch while the power

back door is closing will stop the operation.

Opening/closing the power back
door

108

3-2. Opening, closing and locking the doors

Pressing the switch again will open the
power back door automatically.



Close the back door and lock all
doors after moving away from the
back door (close & lock
[Walk-Away] function)

: This setting can be customized by your

Lexus dealer.

Close all of the doors except the
back door, carrying an electronic
key and press the

switch on the

lower part of the back door.

A different buzzer than the normal one will

sound and the close & lock (Walk-Away)

function will go into standby.

While the buzzer is sounding, move
away from the back door.

When the sensor detects that you are away

from the back door, the emergency flash-

ers will flash, and the buzzer will sound.

Depending on the direction of moving

away from the back door, the location and

how to hold the electronic key or circum-

stances, it may not be detected properly.

All the doors other than the back door will

be locked, and after the back door is

closed, the back door will also be locked.

When all the doors have been closed and

locked, the buzzer will sound and the

emergency flashers will flash.
The standby state is canceled if you do not

move away from the back door for 30 sec-

onds. To operate the function again, per-

form the procedure again from the

beginning.
If you approach the back door carrying the

electronic key, the back door operation will

stop, all the doors will be unlocked, and the

buzzer will sound and the emergency

flashers will flash.

If the

switch is pressed after the back

door operation has stopped, the close &

lock (Walk-Away) function will go into

standby again.



Close the back door and lock all
doors (close & lock function)

: This setting can be customized by your

Lexus dealer.

Press the

switch.

The power back door will close and all of
the doors will be locked at the same time.
A different buzzer than the normal one will
sound and the power back door will begin
closing automatically. When the power
back door is closed, all of the doors will
lock simultaneously and operation signals
will indicate that all of the doors have been
locked.

If the

switch is pressed while the power

back door is closing, the operation will
stop.
Pressing the switch again will open the
power back door automatically.

109

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Closing the power back door using
the back door handle

Lower the power back door using the
back door handle, then a buzzer will
sound and the power back door will
automatically close.

■

Hands Free Power Back Door (if
equipped)

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion range, approximately 19.7 to
23.6 in. (50 to 60 cm) from the
rear bumper.



Vehicles without tow hitch

Kick sensor
Hands Free Power Back Door
operation detection area
Smart access system with
push-button start operation detec-
tion area (





Vehicles with tow hitch

Kick sensor
Hands Free Power Back Door
operation detection area
Smart access system with
push-button start operation detec-
tion area (



Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation

110

3-2. Opening, closing and locking the doors

within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform
a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the power back door
will automatically fully open/close.

If kick operation is performed again in the

middle of back door operating, the opera-

tion will stop.

■

Closing and locking the back door
after moving away from the back
door using the kick sensor (Hands
Free close & lock [Walk-Away]
function)

*1, 2

: If equipped

: This setting can be customized by your

Lexus dealer.

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion range, approximately 19.7 to
23.6 in. (50 to 60 cm) from the
rear bumper.



Vehicles without tow hitch

Kick sensor
Hands Free Power Back Door
operation detection area
Smart access system with
push-button start operation detec-
tion area (





Vehicles with tow hitch

Kick sensor
Hands Free Power Back Door
operation detection area
Smart access system with

111

3-2. Opening, closing and locking the doors

fore
dri
ving

push-button start operation detec-
tion area (

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation
within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform
a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a different
buzzer than the normal one will
sound and the Hands Free close &

lock (Walk-Away) function will go
into standby.

While the buzzer is sounding, move
away from the back door.

When the sensor detects that you are away

from the back door, the emergency flash-

ers will flash, and the buzzer will sound.

Depending on the direction of moving

away from the back door, the location and

how to hold the electronic key or circum-

stances, it may not be detected properly.
All the doors other than the back door will

be locked, and after the back door is

closed, the back door will also be locked.

When all the doors have been closed and

locked, the buzzer will sound and the

emergency flashers will flash.
The standby state is canceled if you do not

move away from the back door for 30 sec-

onds. To operate the function again, per-

form the procedure again from the

beginning.
If you approach the back door carrying the

electronic key, the back door operation will

stop, all the doors will be unlocked, and the

buzzer will sound and the emergency

flashers will flash.
If the power back door is operated after

the back door operation has stopped, the

Hands Free close & lock (Walk-Away)

function will go into standby again.

■

Luggage compartment lights

●

The luggage compartment lights turn on

when the back door is opened.

●

When the engine switch is turned off, the

lights will go off automatically after 20

minutes.

■

Back door closer

In the event that the power back door is left

slightly open, the back door closer will auto-

matically close it to the fully closed position.

●

The back door closer can function when

the engine switch is in any mode.

●

The power back door can be opened

using the back door opener switch even if

the back door closer is operating.

112

3-2. Opening, closing and locking the doors

■

Power back door operating conditions

If the following conditions are met with the

power back door operation enabled, the

power back door can be opened and

closed automatically.

●

When an electronic key is being carried

and the back door opener switch is
pressed

●

When the wireless remote control is
used

●

When the engine switch is in ON, the

vehicle speed must be lower than 2 mph

(3 km/h) and one of the following condi-

tions must be met in addition to the above

conditions:

• The parking brake is engaged.

• The brake pedal is depressed.

• The shift position is in P.

: When the operation of the power back

door when it is locked has been disabled
by a customized setting, operate the
power back door after it has been
unlocked.

■

Operation of the power back door

●

When the power back door begins to

operate, the emergency flashers will flash

and a buzzer will sound.

●

When the power back door is disabled,

the power back door will not operate but

can be opened and closed manually.

●

The power back door turns to manual

operation when the back door opener

switch is pressed while the power back

door is in an automatic opening/closing

operation.

●

If anything obstructs the power back

door while opening, a buzzer will sound

and the power back door will stop imme-

diately. If anything obstructs the power

back door while closing, a buzzer will

sound and the power back door will auto-

matically move slightly in the opposite

direction and then stop.

■

Jam protection function

Sensors are installed in the right and left

sides of the power back door. When the

door is automatically closing and the sen-

sors are pushed due to an object being

caught, etc., the jam protection function will

operate.
From that position the door will automati-

cally move a little in the opposite direction

and then the function will stop.

■

Fall-down protection function

While the power back door is opening

automatically, applying excessive force to it

will stop the opening operation to prevent

the power back door from suddenly shut-

ting.

■

Back door closing assist

If the back door is lowered manually when

the back door is stopped at an open posi-

tion, the back door will fully close automati-

cally.

■

Back door reserve lock function

This function reserves the locking of the

power back door when the power back

door is open. If the following operations are

performed, all of the doors except the

power back door will lock and then the

power back door will lock when it is com-

pletely closed.

Close all of the doors, except the power

back door.

Perform an automatic closing operation

of the power back door and lock the

doors using the wireless remote control

(

P.96) or smart access system with

push-button start (



P.100) while the

power back door is closing.

Operation signals will indicate that all the

doors have been closed and locked.

(

P.101)

●

If the electronic key is placed inside the

vehicle after starting a close operation via

the door reserve lock function, the elec-

tronic key may become locked inside the

vehicle.

113

3-2. Opening, closing and locking the doors

fore
dri
ving

●

If the back door does not fully close due

to the operation of the jam protection

function, etc., while the back door is auto-

matically closing after a reserve lock

operation is performed, the reserve lock

function is canceled and all the doors will

unlock.

●

Before leaving the vehicle, make sure that

all the doors are closed and locked.

■

Close & lock (Walk-Away) function

operating conditions

This function can be operated when all of

the following conditions are met:

●

Close & lock (Walk-Away) function is
enabled

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the power

back door are closed.

●

The brake pedal is not depressed.

●

The engine switch is off.

●

The electronic key is within the effective

range (detection areas).

: This setting can be customized by your

Lexus dealer.

■

Situations in which the close & lock
(Walk-Away) function

may not operate

properly

In the following situations, the function may

not operate properly:

●

When the smart access system with

push-button start does not operate prop-

erly.

●

When the close & lock function does not

operate properly.

●

When moving away from the back door

while the close & lock (Walk-Away) func-

tion is in the standby state.

: This setting can be customized by your

Lexus dealer.

■

Close & lock function

operating condi-

tions

This function can be operated when all of

the following conditions are met:

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the power

back door are closed.

●

The engine switch is off.

: This setting can be customized by your

Lexus dealer.

■

Situations in which the close & lock
function

may not operate properly

In the following situations, the close & lock

function may not operate properly:

●

If the

switch on the lower part of the

power back door (



P.107) is pressed by

a hand which is holding an electronic key

●

If the

switch on the lower part of the

power back door (

P.107) is pressed

when the electronic key is in a bag, etc.

that is placed on the ground

●

If the

switch on the lower part of the

power back door (

P.107) is pressed

with the electronic key not near the vehi-

cle.

: This setting can be customized by your

Lexus dealer.

■

Hands Free Power Back Door operating

conditions (if equipped)

●

The Hands Free Power Back Door (kick

sensor) setting is on.

●

When an electronic key is carried within

the operation range.

■

Situations in which the Hands Free

Power Back Door may not operate

properly (if equipped)

In the following situations, the Hands Free

Power Back Door may not operate prop-

erly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while.

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Back Door again.

114

3-2. Opening, closing and locking the doors

●

When standing excessively close to the

rear bumper

●

When an external radio wave source

interferes with the communication

between the electronic key and the vehi-

cle (



P.122)

●

When the vehicle is parked near metal, or

an external radio wave or electrical noise

source which affects the sensitivity of the

Hands Free Power Back Door, such as a

pay parking spot, gas station, electrically

heated road, fluorescent light, or metal

plate

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the

Hands Free Power Back Door (kick sen-

sor) operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Back Door (if

equipped)

When an electronic key is in the operation

detection area, the Hands Free Power Back

Door may operate unintentionally, so be

careful in the following situations:

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Back

Door, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the

Hands Free Power Back Door (kick sensor)

operation setting off.

■

Hands Free close & lock (Walk-Away)
function

operating conditions

This function can be operated when all of

the following conditions are met:

●

Hands Free close & lock (Walk-Away)
function is enabled

●

Hands Free Power Back Door

enabled.

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the back door

are closed.

●

The brake pedal is not depressed.

●

The engine switch is off.

●

The electronic key is within the effective

range (detection areas).

: If equipped

: This setting can be customized by your

Lexus dealer.

115

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Situations in which the Hands Free close
& lock (Walk-Away) function

*1, 2

may

not operate properly

In the following situations, the function may

not operate properly:

●

When the smart access system with

push-button start does not operate prop-

erly.

●

When the close & lock function does not

operate properly.

●

When moving away from the back door

while the Hands Free close & lock

(Walk-Away) function is in the standby

state.

●

When the Hands Free Power Back Door
does not operate properly.

: If equipped

: This setting can be customized by your

Lexus dealer.

■

If the power back door stops the auto-

matic operation

When the automatic operation of the

power back door is enabled and the power

back door is left open for a long time, it may

stop the automatic operation.
To re-enable the automatic operation, fully

close the power back door manually.

■

When reconnecting the battery

To operate the power back door properly,

close the back door completely by hand

then operate for unlocking.

■

If the power back door opener is inoper-

ative

The power back door can be unlocked from

the inside

Remove the cover.

To prevent damage, cover the tip of the

screwdriver with a rag.

Loosen the screw.

Turn the cover.

Move the lever.

When installing, reverse the steps listed.

■

Customization

Some functions can be customized.

(

116

3-2. Opening, closing and locking the doors

WARNING

■

Back door closer

●

In the event that the power back door

is left slightly open, the back door

closer will automatically close it to the

fully closed position. It takes several

seconds before the back door closer

begins to operate. Be careful not to get

fingers caught or anything else in the

power back door, as this may cause

bone fractures or other serious inju-

ries.

●

Use caution when using the back door

closer as it still operates when the

power back door system is disabled.

■

Power back door

Observe the following precautions when

operating the power back door.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the power back door is about to open

or close.

●

If the power back door system is dis-

abled while the power back door is

operating, the power back door will

stop operating. The power back door

must then be operated manually. Take

extra care in this situation, as the

power back door may open or close

suddenly.

●

If the operating conditions of the

power back door (

P.112) are no lon-

ger met, a buzzer may sound and the

power back door may stop opening or

closing. The power back door must

then be operated manually. Take extra

care on an incline in this situation, as

the power back door may move sud-

denly.

●

On an incline, the power back door

may suddenly shut after it opens. Make

sure the power back door is fully open

and secure.

●

In the following situations, the power

back door may detect an abnormality

and automatic operation may be

stopped. In this case, the power back

door must then be operated manually.

Take extra care in this situation, as the

stopped power back door may sud-

denly open or close, causing an acci-

dent.

• When the power back door contacts

an obstacle

• When the battery voltage suddenly

drops, such as when the engine switch

is turned to ON or the engine is

started during automatic operation

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, the power back door may not

operate, causing a malfunction, or the

power back door may suddenly shut

again after being opened, causing

someone’s hands, arms, head or neck

to be caught and injured. When install-

ing an accessory part to the power

back door, using a genuine Lexus part

is recommended.

■

Jam protection function

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

117

3-2. Opening, closing and locking the doors

fore
dri
ving

WARNING

●

The jam protection function may not

work if something gets caught just

before the power back door fully

closes. Be careful not to get fingers

caught or anything else.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

■

Hands Free Power Back Door (if

equipped)

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

Exhaust gasses cause the exhaust

pipes to become quite hot. When

operating the Hands Free Power Back

Door, be careful not to touch the

exhaust pipe.

●

Do not operate the Hands Free Power

Back Door if there is little space under

the rear bumper.

■

Close & lock (Walk-Away) function

and Hands Free close & lock

(Walk-Away) function

*1, 2

: This setting can be customized by

your Lexus dealer.

: If equipped

The back door starts to close automati-

cally when leaving the back door. Check

the safety of the surrounding area to

make sure there are no obstacles or any-

thing that could cause any of your

belongings to get caught.

NOTICE

■

Back door spindles

The power back door is equipped with
spindles

that hold the power back

door in place.

Observe the following precautions.

Failure to do so may cause damage to
the back door spindle

, resulting in

malfunction.

●

Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives

to the spindle rod.

●

Do not attach any accessories other

than genuine Lexus parts to the power

back door.

●

Do not place your hand on the spindle

or apply lateral forces to it.

■

To prevent back door closer malfunc-

tion

●

Do not apply excessive force to the

power back door while the back door

closer is operating. Applying excessive

force may cause the back door closer

to malfunction.

●

If the power back door is opened and

closed repeatedly in a short amount of

time, the back door closer may stop

operating. In this case, manually open

the power back door once and wait for

a while before attempting to close it

again.

118

3-2. Opening, closing and locking the doors

NOTICE

■

To prevent malfunction of the power

back door

●

Make sure that there is no ice between

the power back door and frame that

would prevent movement of the power

back door. Operating the power back

door when excessive load is present

on the power back door may cause a

malfunction.

●

Do not apply excessive force to the

power back door while the power

back door is operating.

●

Take care not to damage the sensors

installed on the right and left edges of

the power back door (

P.112) with a

knife or other sharp object. If a sensor

is disconnected, the power back door

will not close automatically.

■

Close & lock function

: This setting can be customized by your

Lexus dealer.

When closing the power back door using

the close & lock function, a different

buzzer than the normal one will sound

before the operation begins.

To check that the operation has started

correctly, check that a different buzzer

than the normal one has sounded.

Additionally, when the power back door

is fully closed and locked, operation sig-

nals will indicate that all of the doors have

been locked.

Before leaving the vehicle, make sure

that the operational signals have oper-

ated and that all of the doors are locked.

■

Hands Free Power Back Door pre-

cautions (if equipped)

The kick sensor is located behind lower

center part of the rear bumper. Observe

the following to ensure that the Hands

Free Power Back Door function operates

properly:

●

Keep the lower center part of the rear

bumper clean at all times.

If the lower center part of the rear

bumper is dirty or covered with snow, the

Hands Free Power Back Door may not

operate. In this situation, clean off the dirt

or snow, move the vehicle from the cur-

rent position and then check if the Hands

Free Power Back Door operates. If it

does not operate, have the vehicle

inspected by your Lexus dealer.

●

Do not apply coatings that have a rain

clearing (hydrophilic) effect, or other

coatings, to the lower center part of

the rear bumper.

●

Do not park the vehicle near objects

that may move and contact the lower

center part of the rear bumper, such as

grass or trees.

If the vehicle has been parked for a while

near objects that may move and contact

the lower center part of the rear bumper,

such as grass or trees, the Hands Free

Power Back Door may not operate. In

this situation, move the vehicle from the

current position and then check if the

Hands Free Power Back Door operates.

If it does not operate, have the vehicle

inspected by your Lexus dealer.

●

Do not subject the rear bumper or its

surrounding area to a strong impact.

If the rear bumper or its surrounding area

has been subjected to a strong impact,

the Hands Free Power Back Door may

not operate properly.
If the Hands Free Power Back Door does

not operate in the following situations,

have the vehicle inspected by your Lexus

dealer.
• The kick sensor or its surrounding area

has been subjected to a strong impact.

• The lower center part of the rear

bumper is scratched or damaged.

●

Do not disassemble the rear bumper.

●

Do not attach stickers to the rear

bumper.

119

3-2. Opening, closing and locking the doors

fore
dri
ving

The power back door system can be
enabled/disabled on the center display.
(



Select

on the center display.

Select “Vehicle customize”.

Select “Door control”.

Select “Power back door”.

Select (ON)/

(OFF).

When OFF is selected and the operations
of the power back door is made to stop
from the center display, unless it is set to
ON, the operation of the power back door
will not return. (No return in the engine
switch operation)

The Hands Free Power Back Door
(kick sensor) can be enabled/disabled
on the center display. (



Select

on the center display.

Select “Vehicle customize”.

Select “Door control”.

Select “Hands free”.

Select (ON)/

(OFF).

When OFF is selected and the operations
of the Hands Free Power Back Door is
made to stop from the center display,
unless it is set to ON, the operation of the
Hands Free Power Back Door will not
return. (No return in the engine switch
operation)

The open position of the power back
door can be adjusted.

Stop the power back door at the
desired position. (

P.107)

Press and hold the

switch on

the lower part of the power back
door for 2 seconds.



When setting is complete, a buzzer
will sound 4 times.



The next time the power back door
is opened, it will stop at that position.

■

Returning the power back door opening

position to the default setting

Press and hold the

switch on the

lower part of the power back door for 7

seconds.
After the buzzer sounds 4 times, it sounds

NOTICE

●

Do not paint the rear bumper.

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, disable the Hands Free Power

Back Door (kick sensor).

Canceling the power back door
system

Canceling the Hands Free
Power Back Door (if equipped)

Adjusting the open position of
the power back door

120

3-2. Opening, closing and locking the doors

twice more. When the power back door
does the opening operation the next time,
the door will open to the initial settings
position.

■

Customization

The opening position can be set with the

center display.
Priority for the stop position is given to the
last position set by either the

switch

or center display.
(Customizable features:

■

Antenna location

Antennas outside the cabin
Antennas inside the cabin
Antenna outside the luggage compart-
ment

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key on your person, for
example in your pocket. The driver
should always carry the electronic
key.



Locks and unlocks the doors
(


