P.517)

●

The power windows can be opened using
the wireless remote control.

(



P.106)

: These settings must be customized at

your Lexus dealer.

■

Alarm

The alarm may be triggered if the alarm is

set and a power window is closed using the

door lock linked power window operation

function. (



P.69)

■

Power windows open warning buzzer

A buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the power switch is

turned off and the driver’s door is opened

with the power windows open.

■

Customization

Some functions can be customized.

(



WARNING

Observe the following precautions.

Failing to do so may result in death or

serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (

P.154)

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

●

When exiting the vehicle, turn the

power switch off, carry the key and exit

the vehicle along with the child. There

may be accidental operation, due to

mischief, etc., that may possibly lead to

an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

154

3-5. Opening, closing the windows and moon roof

This function can be used to prevent
children from accidentally opening or
closing a passenger window.
Press the switch.

The indicator

will come on and the pas-

senger windows will be locked.
The passenger windows can still be
opened and closed using the driver’s
switch even if the lock switch is on.

■

The power windows can be operated

when

The power switch is in ON.

■

When the 12-volt battery is discon-

nected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the 12-volt battery.

: If equipped

■

Opening and closing the elec-
tronic sunshade

Opens the electronic sunshade

Closes the electronic sunshade

: Lightly press either end of the

switch to stop the electronic sunshade
while it is operating.

: Lightly press either end of the

switch to stop the electronic sunshade
while it is operating.

■

Tilting the panoramic moon roof up
and down

Tilts the panoramic moon roof up
(press)

When the panoramic moon roof is tilted
up, the electronic sunshade will open to the
half-open position of the roof.

: Lightly press the

switch again to

WARNING

●

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental operation
(window lock switch)

Panoramic moon roof

Use the overhead switches to oper-
ate the panoramic moon roof and
electronic sunshade.

Operating the panoramic moon
roof

155

3-5. Opening, closing the windows and moon roof

fore
dri
ving

stop the panoramic moon roof partway.

Tilts the panoramic moon roof down
(press and hold)

The panoramic moon roof can be tilted
down only when it is in the tilt-up position.

■

Opening and closing the pan-
oramic moon roof

Opens the panoramic moon roof

The panoramic moon roof and electronic
sunshade will open.
The panoramic moon roof can be opened
from the tilt-up position.

Closes the panoramic moon roof

The panoramic moon roof stops at the
tilt-up position.

Press and hold the

switch again to fully

close the panoramic moon roof.

: Lightly press either end of the

switch to stop the electronic sunshade
while it is operating.

: Lightly press either end of the

switch to stop the electronic sunshade
while it is operating.

■

The panoramic moon roof can be oper-

ated when

The power switch is in ON.

■

Operating the panoramic moon roof

after turning the hybrid system off

The panoramic moon roof and electronic

sunshade can be operated for approxi-

mately 45 seconds after the power switch is

turned to ACC or turned off. They cannot,

however, be operated once the driver’s

door is opened.

■

Jam protection function

If an object is detected between the pan-

oramic moon roof and the frame in the fol-

lowing situations, travel is stopped and the

panoramic moon roof opens slightly:

●

The panoramic moon roof is closing or

tilting down.

●

The electronic sunshade is closing.

■

Door lock linked panoramic moon roof

operation

●

The panoramic moon roof can be

opened and closed using the mechanical
key.

(



P.517)

●

The panoramic moon roof can be

opened using the wireless remote con-
trol.

(

P.106)

●

The alarm may be triggered if the alarm is

set and the panoramic moon roof is

closed using the door lock linked moon

roof operation function. (



P.69)

: These settings must be customized at

your Lexus dealer.

■

Closing both the panoramic moon roof

and electronic sunshade

Press the

switch.

The electronic sunshade will close to the

half-open position and pause. The pan-

oramic moon roof will then fully close. Then

the electronic sunshade will fully close.

156

3-5. Opening, closing the windows and moon roof

■

When the panoramic moon roof or elec-

tronic sunshade does not close normally

Perform the following procedure:

Stop the vehicle.

Turn the power switch to ON.

Press and hold the

switch or

switch. Continue pressing the switch for

approximately 10 seconds after the

panoramic moon roof or electronic

sunshade closes and reopens. The pan-

oramic moon roof and electronic sun-
shade will start to close.

Check that the panoramic moon roof

and electronic sunshade are fully closed

and release the switch.

: If the switch is released at the incorrect

time, the procedure will have to be per-
formed again from the beginning.

If the panoramic moon roof or electronic

sunshade does not fully close even after

performing the above procedure correctly,

have the vehicle inspected by your Lexus

dealer.

■

Panoramic moon roof open warning

buzzer

A buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the power switch is

turned off and the driver’s door is opened

with the panoramic moon roof open.

■

Customization

Some functions can be customized.

(



WARNING

Observe the following precautions.

Failing to do so may cause death or seri-

ous injury.

■

Opening and closing the electronic

sunshade

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the electronic sunshade is being

operated.

●

Do not let a child operate the elec-

tronic sunshade. Closing the elec-

tronic sunshade on someone can

cause death or serious injury.

■

Opening the panoramic moon roof

●

Do not allow any passengers to put

their hands or heads outside the vehi-

cle while it is moving.

●

Do not sit on top of the panoramic

moon roof.

■

Opening and closing the panoramic

moon roof

●

The driver is responsible for pan-

oramic moon roof opening and closing

operations. In order to prevent acci-

dental operation, especially by a child,

do not let a child operate the pan-

oramic moon roof. It is possible for

children and other passengers to have

body parts caught in the panoramic

moon roof.

157

3-5. Opening, closing the windows and moon roof

fore
dri
ving

WARNING

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the panoramic moon roof is

being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the panoramic moon roof, operate the

panoramic moon roof after checking

to make sure that there is no possibility

of any passenger having any of their

body parts caught in the panoramic

moon roof. Also, do not let a child

operate panoramic moon roof by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the pan-

oramic moon roof.

●

When exiting the vehicle, turn the

power switch off, carry the key and exit

the vehicle along with the child. There

may be accidental operation, due to

mischief, etc., that may possibly lead to

an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the panoramic moon roof or

electronic sunshade is fully closed.

Also, the jam protection function is not

designed to operate while the switch is

being pressed. Take care so that your

fingers, etc. do not get caught.

■

To prevent burns or injuries

Do not touch the area between the

underside of the panoramic moon roof

and the electronic sunshade. Your hand

may get caught and you could injure

yourself. Also, if the vehicle is left in direct

sunlight for a long time, the underside of

the panoramic moon roof could become

very hot and could cause burns.

NOTICE

■

To prevent damage to the panoramic

moon roof

●

Before opening the panoramic moon

roof, make sure that there are no for-

eign objects, such as stones or ice,

around the opening.

●

Do not hit the surface or edge of the

panoramic moon roof with hard

objects.

●

Do not continuously press the

switch or

switch after the pan-

oramic moon roof has been fully

opened or closed.

■

After the vehicle has been washed or

rained on

Before opening the panoramic moon

roof, wipe any water off the panoramic

moon roof. Otherwise, water may enter

the cabin when the panoramic moon roof

is opened.

158

3-6. Favorite settings

3-6.Favorite settings

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering
wheel are automatically adjusted to a
position that allows driver to enter and
exit the vehicle easily.

• The shift position has been shifted to

• The power switch has been turned

off.

• The driver’s seat belt has been

unfastened.

When any of the following has been
performed, the seat and steering
wheel automatically return to their
original positions.
• The power switch has been turned

to ACC or ON.

• The driver’s seat belt has been fas-

tened.

■

Operation of the power easy access sys-

tem

When exiting the vehicle, the power easy

access system may not operate if the seat is

already close to the rearmost position, etc.

■

Jam protection function

While the power easy access system is

operating, if an object is stuck behind the

front seat, the front seat will stop and then

slightly move forward. When the jam pro-

tection function operates, the seat stops at a

position other than the set seat position.

Check the seat position.

■

Customization

Some functions can be customized.

(

Check that the shift position is in P.

Turn the power switch to ON.

Driving position memory

This feature automatically adjusts
the driver’s seat, steering wheel,
outside rear view mirrors and
head-up display (if equipped) to
make entering and exiting the vehi-
cle easier or to suit your prefer-
ences.

Up to 3 different driving positions
can be recorded.

Each electronic key can be regis-
tered to recall your preferred driv-
ing position.

Power easy access system
(driver’s side only)

WARNING

■

While the power easy access system

is operating and the steering wheel

and seat is moving

Be careful not to get body parts or lug-

gage caught. Failure to do so may cause

an injury or damage to the luggage.

Recording a driving position into
memory

159

3-6. Favorite settings

fore
dri
ving

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display (if equipped)
to the desired positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

■

Seat positions that can be memorized

(

P.131)

The adjusted positions other than the posi-

tion adjusted by lumbar support switch can

be recorded.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Check that the shift position is in P.

Turn the power switch to ON.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following operations:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

■

Jam protection function

While the driving position is recalled or the

power easy access system is operating, if an

object is stuck behind the front seat, the

front seat will stop and then slightly move

forward. When the jam protection function

operates, the seat stops at a position other

than the set seat position. Check the seat

position.

■

Operating the driving position memory

after turning the power switch off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

160

3-6. Favorite settings

contact your Lexus dealer.

■

Using the voice control system

: If equipped

The following operations can be performed

using the voice control system:

●

Driving position registration

●

Driving position recall (only when the

shift position is in P)

For details, refer to the “MULTIMEDIA

OWNER’S MANUAL”

■

Identifying a driver with the elec-
tronic key assigned and registered
in My Settings

The driving positions can be automati-
cally recalled for each registered
driver by registering electronic key
assignments in My Settings.



Driving position registration proce-
dure

When the shift position is shifted to P after
driving the vehicle, the current driving
position will be recorded.



Driving position recall procedure

Carry only the key that has been
assigned and registered in My Set-
tings, and then unlock and open the
driver’s door using the smart
access system with push-button
start or wireless remote control.

The driving position other than the steering

wheel and head-up display (if equipped)

will move to the recorded position. How-

ever, the seat will move to a position slightly

behind the recorded position in order to

make entering the vehicle easier.

If the driving position is in a position that

has already been recorded, the driving

position will not move.

Turn the power switch to ON.

The seat, steering wheel and head-up dis-

play (if equipped) (only when the power

switch is in ON) will move to the recorded

position.



Memory recall function cancelation
procedure

Initialize the driver registered settings in
My Settings.
For information on initializing driver regis-
tered settings, refer to the “MULTIMEDIA
OWNER’S MANUAL”.

■

Identifying a driver with face infor-
mation assigned and registered in
My Settings

The driving positions can be automati-
cally recalled for each registered
driver by registering face information
in the face authentication system and
registering the face information assign-
ment in My Settings.



Driving position registration proce-
dure

When the shift position is shifted to P after
driving the vehicle, the current driving
position will be recorded.



Driving position recall procedure

Turn the power switch to ACC or ON.
After face authentication is performed
successfully, the seat, outside rear view
mirrors, steering wheel, and head-up dis-
play (if equipped) (only when the power
switch is turned on) will move to the regis-
tered driving position . They will not move if
already in the registered driving position.



Memory recall function cancelation
procedure

Registering/canceling/recall a
driving position to an electronic
key (memory recall function)

161

3-6. Favorite settings

fore
dri
ving

Delete face information from the face
authentication system.
For information on deleting fingerprint
information, refer to the “MULTIMEDIA
OWNER’S MANUAL”.

■

Vehicles without a My Settings
function

Each electronic key can be registered
to automatically recall your preferred
driving position.



Driving position registration proce-
dure

Record your driving position to button
“1” or “2” before performing the follow-
ing:
Carry only the key you want to register,
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Check that the shift position is in P.

Turn the power switch to ON.

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.



Driving position recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the

head-up display [if equipped]).
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the power switch to ON.

The head-up display (if equipped) will

move to the recorded position.



Memory recall function cancelation
procedure

Carry only the key you want to cancel
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be canceled
properly.

Check that the shift position is in P.

Turn the power switch to ON.

While pressing the “SET” button,
press and hold the door lock switch

162

3-6. Favorite settings

(either lock or unlock) until the
buzzer sounds twice.

If it button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recalling the driving position using the

memory recall function (vehicles with

the My setting)

Different driving positions can be regis-

tered for each electronic key. Therefore, the

driving position that is recalled may be dif-

ferent depending on the key being carried.

■

Recalling the driving position using the

memory recall function (vehicles with-

out the My setting)

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If a door other than the driver’s door is

unlocked with the smart access system

with push-button start, the driving posi-

tion cannot be recalled. In this case, press

the driving position button which has

been set.

■

Jam protection function

While the driving position is recalled or the

power easy access system is operating, if an

object is stuck behind the front seat, the

front seat will stop and then slightly move

forward. When the jam protection function

operates, the seat stops at a position other

than the set seat position. Check the seat

position.

■

Customization

Some functions can be customized.

(



: If equipped

An individual can be identified using
the following authentication devices:



Electronic key/Digital key

An individual is identified when the smart
access system with push-button start
detects their electronic key/digital key.
(

P.104, 126)



Face authentication system

An individual is identified at the open-
ing/closing of the door when face informa-
tion registered using the driver monitor
camera is identified. (



P.231)

My Settings

By identifying an individual through
a device, such as an electronic key,
the driving position and vehicle set-
tings recorded for that driver can
be recalled when the vehicle is
entered.

By assigning an authentication
device to a driver in advance, the
driver can enter the vehicle with
their preferred settings.

Settings for up to 3 drivers can be
recorded by My Settings.

For details on how to assign/delete
electronic keys, set driver names,
perform initialization, change driv-
ers manually, or delete a driver,
refer to the “MULTIMEDIA
OWNER’S MANUAL”.

Types of assigned authentication
devices

163

3-6. Favorite settings

fore
dri
ving

Individual identification by face authentica-
tion is prioritized than by electronic
key/digital key

, if the latter has identified

with another registered driver.



Bluetooth

devices

An individual can be identified if the same
Bluetooth

device that was used as a

hands-free phone the last time the vehicle
was entered is connected to the audio sys-
tem.
If an individual is identified by detecting an
electronic key, identification by Bluetooth

device will not be performed.

: If equipped

When an individual is identified from
an authentication device, settings for
the following functions are recalled.



Driving position (memory recall
function)

After an individual is identified, the driving
position that was set when driving was last
completed (with shift position set to P) is
recalled when the following operation is
performed.

However, when a Bluetooth

device is

used to identify an individual, the driving
position is not recalled.
• When an individual is identified from a

digital key

: Unlocking the doors using

the smart access system with push-but-
ton start

• When an individual is identified from the

face authentication system

: After the

driver monitor identifies face informa-
tion, turning the power switch to ACC or
ON.



Meter displays

, head-up dis-

play

*1,2

, and center display

When an individual is identified, the vehicle
settings used when the power switch was
last turned off are recalled.



Safe driving support function

When an individual is identified, the vehicle
settings used when the power switch was
last turned off are recalled.



Vehicle settings available on the
center display

When an individual is identified, the vehicle
settings used when the power switch was
last turned off are recalled.

: If equipped

: Some settings are excluded

Recalled functions

165

Driving

4-1. Before driving

Driving the vehicle.....................

167

Cargo and luggage...................

173

Vehicle load limits......................

176

Trailer towing (vehicles without

towing package)......................

177

Trailer towing (vehicles with tow-

ing package)..............................

177

Dinghy towing .............................

187

4-2. Driving procedures

Power (ignition) switch ............

188

Automatic transmission...........

192

Turn signal lever..........................

198

Parking brake ..............................

198

Brake Hold....................................

201

ASC (Active Sound Control)

........................................................

203

4-3. Operating the lights and wipers

Headlight switch........................

204

AHS (Adaptive High-beam Sys-

tem)..............................................

207

AHB (Automatic High Beam)

.........................................................

210

Fog light switch ...........................

213

Windshield wipers and washer

.........................................................

213

Rear window wiper and washer

.........................................................

217

4-4. Refueling

Opening the fuel tank cap......

219

4-5. Using the driving support sys-

tems

Lexus Safety System + 3 software

update..........................................

222

Lexus Safety System +3..........

224

Driver monitor.............................

231

PCS (Pre-Collision System)

.......................................................

233

LTA (Lane Tracing Assist) ....

243

LCA (Lane Change Assist)

.......................................................

248

LDA (Lane Departure Alert)

........................................................

251

PDA (Proactive driving assist)

.......................................................

257

FCTA (Front Cross Traffic Alert)

.......................................................

262

RSA (Road Sign Assist)..........

265

Dynamic radar cruise control

.......................................................

267

Cruise control ............................

279

Emergency Driving Stop System

.......................................................

284

Traffic Jam Assist ......................

286

BSM (Blind Spot Monitor)....

292

Safe Exit Assist...........................

296

Intuitive parking assist..............

301

RCTA (Rear Cross Traffic Alert)

function........................................

310

RCD (Rear Camera Detection)

........................................................

315

166

PKSB (Parking Support Brake)

.........................................................

318

Parking Support Brake function

(static objects front and rear of the
vehicle/static objects around the
vehicle) .......................................

322

Parking Support Brake function

(moving vehicles rear of the vehi-
cle)................................................

326

Parking Support Brake function

(pedestrians rear of the vehicle)
........................................................

327

Lexus Teammate Advanced Park

........................................................

329

Driving mode select switch...

363

Trail Mode....................................

364

Driving assist systems..............

365

4-6. Driving tips

Hybrid electric vehicle driving tips

........................................................

372

Winter driving tips ....................

374

Utility vehicle precautions.....

376

Driving

167

4-1. Before driving

Driving

4-1.Before driving

■

Starting the hybrid system



P.188

■

Driving

With the brake pedal depressed,
shift the shift position to D.
(



Check that the shift position indicator

shows D.

If the parking brake is set, release
the parking brake. (

If the parking brake is in automatic mode,

the parking brake will be released auto-

matically. (

P.199)

Gradually release the brake pedal
and gently depress the accelerator
pedal to accelerate the vehicle.

■

Stopping

Depress the brake pedal.

If necessary, set the parking brake.
(



If the vehicle is to be stopped for an

extended period of time, shift the shift posi-

tion to P. (



■

Parking the vehicle

Depress the brake pedal to stop the
vehicle completely.

If the parking brake is released, set
the parking brake. (

Shift the shift position to P.
(



Check that the shift position indicator

shows P and the parking brake indicator is

illuminated.

Press the power switch to stop the
hybrid system.

Slowly release the brake pedal.

Lock the door, making sure that you
have the electronic key on your
person.

If parking on a hill, block the wheels as

needed.

■

Starting off on a steep uphill

Firmly depress the brake pedal and
shift the shift position to D.
(

The hill-start assist control will be activated.

Set the parking brake. (



Release the brake pedal and gently
depress the accelerator pedal to
accelerate the vehicle.

Release the parking brake.
(

■

For fuel-efficient driving

Keep in mind that hybrid electric vehicles

are similar to conventional vehicles, and it is

necessary to refrain from activities such as

sudden acceleration. (

P.372)

■

Driving in the rain

●

Drive carefully when it is raining, because

visibility will be reduced, the windows

may become fogged-up, and the road

will be slippery.

●

Drive carefully when it starts to rain,

because the road surface will be espe-

cially slippery.

●

Refrain from high speeds when driving on

an expressway in the rain, because there

may be a layer of water between the tires

and the road surface, preventing the

steering and brakes from operating prop-

erly.

Driving the vehicle

The following procedures should be
observed to ensure safe driving:

Driving procedure

168

4-1. Before driving

■

Engine speed while driving

In the following conditions, the engine

speed may become high while driving. This

is due to automatic up-shifting control or

down-shifting implementation to meet driv-

ing conditions. It does not indicate sudden

acceleration.

●

The vehicle is judged to be driving uphill

or downhill

●

When the accelerator pedal is released

●

When the brake pedal is depressed

■

Restraining the hybrid system output

(Brake Override System)

●

When the accelerator and brake pedals

are depressed at the same time, the

hybrid system output may be restrained.

●

A warning message is displayed on the

multi-information display while the sys-

tem is operating.

■

Breaking in your new Lexus

To extend the life of the vehicle, observing

the following precautions is recommended:

●

For the first 200 miles (300 km):

Avoid sudden stops.

●

For the first 500 miles (800 km):

Do not tow a trailer. (vehicles with towing
package)

●

For the first 1000 miles (1600 km):

• Do not drive at extremely high speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low gears.

• Do not drive at a constant speed for

extended periods.

■

Operating your vehicle in a foreign

country

Comply with the relevant vehicle registra-

tion laws and confirm the availability of the

correct fuel. (

P.533)

■

Idling time before engine stop

To prevent damage to the turbocharger,

allow the hybrid system to idle immediately

after high-load driving.

■

Eco-friendly driving



P.80

Driving condition

Idling time

Normal city driving or
high-speed driving (at the
highway speed limit or rec-
ommended speed)

Not neces-

sary

Steep hill driving, continuous
driving (race track driving
etc.), or towing a trailer or
another vehicle (vehicles with
towing package)

Approxi-

mately 1

minute

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

When starting the vehicle

Always keep your foot on the brake

pedal while stopped with the “READY”

indicator is illuminated. This prevents the

vehicle from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamiliar with

the location of the brake and accelera-

tor pedals to avoid depressing the

wrong pedal.

• Accidentally depressing the accelera-

tor pedal instead of the brake pedal

will result in sudden acceleration that

may lead to an accident.

• When backing up, you may twist your

body around, leading to a difficulty in

operating the pedals. Make sure to

operate the pedals properly.

• Make sure to keep a correct driving

posture even when moving the vehicle

only slightly. This allows you to depress

the brake and accelerator pedals

properly.

169

4-1. Before driving

Driving

WARNING

• Depress the brake pedal using your

right foot. Depressing the brake pedal

using your left foot may delay

response in an emergency, resulting in

an accident.

●

The driver should pay extra attention

to pedestrians when the vehicle is

powered only by the electric motor

(traction motor). As there is no engine

noise, the pedestrians may misjudge

the vehicle’s movement. Even though

the vehicle is equipped with the

Acoustic Vehicle Alerting System,

drive with care as pedestrians in the

vicinity may still not notice the vehicle if

the surrounding area is noisy.

●

Do not drive the vehicle over or stop

the vehicle near flammable materials.

The exhaust system and exhaust gases

can be extremely hot. These hot parts

may cause a fire if there is any flamma-

ble material nearby.

●

During normal driving, do not turn off

the hybrid system. Turning the hybrid

system off while driving will not cause

loss of steering or braking control,

however, power assist to the steering

will be lost. This will make it more diffi-

cult to steer smoothly, so you should

pull over and stop the vehicle as soon

as it is safe to do so.

In the event of an emergency, such as if

it becomes impossible to stop the vehi-

cle in the normal way:



P.482

●

Use engine braking (downshift) to

maintain a safe speed when driving

down a steep hill.

Using the brakes continuously may

cause the brakes to overheat and lose

effectiveness. (

●

Do not adjust the positions of the

steering wheel, the seat, or the inside

or outside rear view mirrors while driv-

ing.

Doing so may result in a loss of vehicle

control.

●

Always check that all passengers’

arms, heads or other parts of their

body are not outside the vehicle.

●

This vehicle is not designed for

extreme off-roading.

• When driving in sand or mud is

unavoidable, drive carefully and avoid

continuous driving on sand or mud.

• Do not drive on extremely rocky roads

or extremely uneven roads.

●

Do not drive across a river or through

other bodies of water.

This may cause electric/electronic

components to short circuit, damage

the hybrid system or cause other seri-

ous damage to the vehicle.

●

Do not drive in excess of the speed

limit. Even if the legal speed limit per-

mits it, do not drive over 85 mph (140

km/h) unless your vehicle has

high-speed capability tires. Driving

over 85 mph (140 km/h) may result in

tire failure, loss of control and possible

injury. Be sure to consult a tire dealer

to determine whether the tires on your

vehicle are high-speed capability tires

or not before driving at such speeds.

■

When driving on slippery road sur-

faces

●

Sudden braking, acceleration and

steering may cause tire slippage and

reduce your ability to control the vehi-

cle.

●

Sudden acceleration, engine braking

due to shifting, or changes in engine

speed could cause the vehicle to skid.

●

After driving through a puddle, lightly

depress the brake pedal to make sure

that the brakes are functioning prop-

erly. Wet brake pads may prevent the

brakes from functioning properly. If the

brakes on only one side are wet and

not functioning properly, steering con-

trol may be affected.

170

4-1. Before driving

WARNING

■

When shifting the shift position

●

Do not let the vehicle roll backward

while a forward driving position is

selected, or roll forward while the shift

position is in R.

Doing so may result in an accident or

damage to the vehicle.

●

Do not shift the shift position to P while

the vehicle is moving.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

Do not shift the shift position to R while

the vehicle is moving forward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

Do not shift the shift position to a driv-

ing position while the vehicle is moving

backward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

Changing the shift position to N while

the vehicle is moving will disengage

the hybrid system. Regenerative brak-

ing is not available with the hybrid sys-

tem disengaged.

●

Be careful not to change the shift posi-

tion with the accelerator pedal

depressed. Changing the shift posi-

tion to any positions other than P or N

may lead to unexpected rapid acceler-

ation of the vehicle that may cause an

accident and result in death or serious

injury.

After changing the shift position, make

sure to confirm the current shift posi-

tion displayed on the shift position indi-

cator inside the meter.

■

If you hear a squealing or scraping

noise (brake pad wear limit indica-

tors)

Have the brake pads checked and

replaced by your Lexus dealer as soon as

possible.

Rotor damage may result if the pads are

not replaced when needed.

It is dangerous to drive the vehicle when

the wear limits of the brake pads and/or

those of the brake discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator pedal

unnecessarily.

If the shift position is in any position

other than P or N, the vehicle may

accelerate suddenly and unexpect-

edly, causing an accident.

●

In order to prevent accidents due to

the vehicle rolling away, always keep

depressing the brake pedal while

stopped with the “READY” indicator is

illuminated, and apply the parking

brake as necessary.

●

If the vehicle is stopped on an incline,

in order to prevent accidents caused

by the vehicle rolling forward or back-

ward, always depress the brake pedal

and securely apply the parking brake

as needed.

●

Avoid revving or racing the engine.

Running the engine at high speed

while the vehicle is stopped may cause

the exhaust system to overheat, which

could result in a fire if combustible

material is nearby.

■

When the vehicle is parked

●

Do not leave glasses, cigarette lighters,

spray cans, or soft drink cans in the

vehicle when it is in the sun.

Doing so may result in the following:

• Gas may leak from a cigarette lighter

or spray can, and may lead to a fire.

171

4-1. Before driving

Driving

WARNING

• The temperature inside the vehicle

may cause the plastic lenses and plas-

tic material of glasses to deform or

crack.

• Soft drink cans may fracture, causing

the contents to spray over the interior

of the vehicle, and may also cause a

short circuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in the

vehicle. If a cigarette lighter is in a

place such as the glove box or on the

floor, it may be lit accidentally when

luggage is loaded or the seat is

adjusted, causing a fire.

●

Do not attach adhesive discs to the

windshield or windows. Do not place

containers such as air fresheners on

the instrument panel or dashboard.

Adhesive discs or containers may act

as lenses, causing a fire in the vehicle.

●

Do not leave a door or window open if

the curved glass is coated with a met-

allized film such as a silver-colored

one. Reflected sunlight may cause the

glass to act as a lens, causing a fire.

●

Always apply the parking brake, shift

the shift position to P, stop the hybrid

system and lock the vehicle.

Do not leave the vehicle unattended

while the “READY” indicator is illumi-

nated.

If the vehicle is parked with the shift

position in P but the parking brake is

not set, the vehicle may start to move,

possibly leading to an accident.

●

Do not touch the exhaust pipes while

the “READY” indicator is illuminated

or immediately after turning the hybrid

system off.

Doing so may cause burns.

■

When taking a nap in the vehicle

Always turn the hybrid system off. Other-

wise, if you accidentally move the shift

lever or depress the accelerator pedal,

this could cause an accident or fire due

to hybrid system overheating. Addition-

ally, if the vehicle is parked in a poorly

ventilated area, exhaust gases may col-

lect and enter the vehicle, leading to

death or a serious health hazard.

■

When braking

●

When the brakes are wet, drive more

cautiously.

Braking distance increases when the

brakes are wet, and this may cause one

side of the vehicle to brake differently

than the other side. Also, the parking

brake may not securely hold the vehi-

cle.

●

If the electronically controlled brake

function does not operate, do not fol-

low other vehicles closely and avoid

hills or sharp turns that require brak-

ing.

In this case, braking is still possible, but

the brake pedal should be depressed

more firmly than usual. Also, the brak-

ing distance will increase. Have your

brakes fixed immediately.

●

The brake system consists of 2 or more

individual hydraulic systems; if one of

the systems fails, the other(s) will still

operate. In this case, the brake pedal

should be depressed more firmly than

usual and the braking distance will

increase. Have your brakes fixed

immediately.

■

If the vehicle becomes stuck

Do not spin the wheels excessively when

any of the tires is up in the air, or the vehi-

cle is stuck in sand, mud, etc. This may

damage the driveline components or

propel the vehicle forward or backward,

causing an accident.

172

4-1. Before driving

When the following unusual operation
is performed with the accelerator
pedal depressed, the hybrid system
output may be restrained.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator and

brake pedals at the same time during

driving, as this may restrain the hybrid

system output.

●

Do not use the accelerator pedal or

depress the accelerator and brake

pedals at the same time to hold the

vehicle on a hill.

■

Avoiding damage to vehicle parts

●

Do not turn the steering wheel fully in

either direction and hold it there for an

extended period of time.

Doing so may damage the power

steering.

●

When driving over bumps on the road,

drive as slowly as possible to avoid

damaging the wheels, underside of the

vehicle, etc.

●

Make sure to idle the engine immedi-

ately after high-load driving. Stop the

engine only after the turbocharger has

cooled down.

Failure to do so may cause damage to

the turbocharger.

■

If you get a flat tire while driving

A flat or damaged tire may cause the fol-

lowing situations. Hold the steering

wheel firmly and gradually depress the

brake pedal to slow down the vehicle.

●

It may be difficult to control your vehi-

cle.

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnormally.

Information on what to do in case of a flat

tire (

P.505)

■

When encountering flooded roads

Do not drive on a road that has flooded

after heavy rain etc. Doing so may cause

the following serious damage to the vehi-

cle:

●

Engine stalling

●

Short in electrical components

●

Engine damage caused by water

immersion

In the event that you drive on a flooded

road and the vehicle is flooded, be sure

to have your Lexus dealer check the fol-

lowing:

●

Brake function

●

Changes in quantity and quality of oil

and fluid used for the engine, transmis-

sion, transaxle, etc.

●

Lubricant condition for bearings and

suspension joints (where possible),

and the function of all joints, bearings,

etc.

If the shift control system is damaged by

flooding, it may not be possible to shift

the shift position to P, or from P to other

positions. In this case, contact your Lexus

dealer.

■

When parking the vehicle

Always set the parking brake and shift

the shift position to P. Failure to do so

may cause the vehicle to move or the

vehicle may accelerate suddenly if the

accelerator pedal is accidentally

depressed.

Sudden start restraint control
(Drive-Start Control [DSC])

173

4-1. Before driving

Driving



When the shift position is shifted to
R



When the shift position is shifted
from P or R to forward drive shift
position such as D

When the system operates, a message
appears on the multi-information display.
Read the message and follow the instruc-
tion.

: Depending on the situation, the shift

position may not be changed.

■

Drive-Start Control (DSC)

When the TRAC is turned off (

P.367),

sudden start restraint control also does not

operate. If your vehicle have trouble escap-

ing from the mud or fresh snow due to sud-

den start restraint control operation,

deactivate TRAC (

P.367) so that the

vehicle may become able to escape from

the mud or fresh snow.
Also, sudden start restraint control will not

operate in the following conditions:
• When Trail Mode is turned on

Cargo capacity depends on the total
weight of the occupants.
(Cargo capacity) = (Total load capac-
ity) — (Total weight of occupants)
Steps for Determining Correct Load
Limit —
(1) Locate the statement “The com-
bined weight of occupants and cargo
should never exceed XXX kg or XXX
lbs.” on your vehicle’s placard.
(2) Determine the combined weight of
the driver and passengers that will be
riding in your vehicle.
(3) Subtract the combined weight of
the driver and passengers from XXX
kg or XXX lbs.
(4) The resulting figure equals the
available amount of cargo and luggage
load capacity.
For example, if the “XXX” amount
equals 1400 lbs. and there will be five
150 lb passengers in your vehicle, the
amount of available cargo and luggage
load capacity is 650 lbs. (1400

−

750



150) = 650 lbs.)

(5) Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not safely
exceed the available cargo and lug-

Cargo and luggage

Take notice of the following infor-
mation about storage precautions,
cargo capacity and load.

Capacity and distribution

174

4-1. Before driving

gage load capacity calculated in Step
4.
(6) If your vehicle will be towing a
trailer, load from your trailer will be
transferred to your vehicle. Consult
this manual to determine how this
reduces the available cargo and lug-
gage load capacity of your vehicle.
(



P.176)

Vehicles without towing package: Lexus
does not recommend towing a trailer with
your vehicle. Your vehicle is not designed
for trailer towing.

Cargo capacity
Total load capacity (vehicle capac-
ity weight) (



When 2 people with the combined
weight of A lb. (kg) are riding in your
vehicle, which has a total load capacity
(vehicle capacity weight) of B lb. (kg),
the available amount of cargo and lug-
gage load capacity will be C lb. (kg) as
follows:

lb. (kg) - A

lb. (kg) = C

lb. (kg)

: A =Weight of people

: B =Total load capacity

: C =Available cargo and luggage load

In this condition, if 3 more passengers with
the combined weight of D lb. (kg) get on,
the available cargo and luggage load will
be reduced E lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb. (kg)

: D =Additional weight of people

: E =Available cargo and luggage load

As shown in the example above, if the
number of occupants increases, the
cargo and luggage load will be
reduced by an amount that equals the
increased weight due to the additional
occupants. In other words, if an
increase in the number of occupants
causes an excess of the total load
capacity (combined weight of occu-
pants plus cargo and luggage load),
you must reduce the cargo and lug-
gage on your vehicle.

Calculation formula for your
vehicle

WARNING

■

Things that must not be carried in the

luggage compartment

The following things may cause a fire if

loaded in the luggage compartment:

●

Receptacles containing gasoline

●

Aerosol cans

■

Storage precautions

Observe the following precautions.

Failure to do so may prevent the pedals

from being depressed properly, may

block the driver’s vision, or may result in

items hitting the driver or passengers,

possibly causing an accident.

●

Stow cargo and luggage in the lug-

gage compartment whenever possi-

ble.

175

4-1. Before driving

Driving

WARNING

●

Do not stack cargo and luggage in the

luggage compartment higher than the

seatbacks.

●

When you fold down the rear seats,

long items should not be placed

directly behind the front seats.

●

Never allow anyone to ride in the lug-

gage compartment. It is not designed

for passengers. They should ride in

their seats with their seat belts prop-

erly fastened.

●

Do not place cargo or luggage in or on

the following locations.

• At the feet of the driver

• On the front passenger or rear seats

(when stacking items)

• On the luggage cover

• On the instrument panel

• On the dashboard

●

Secure all items in the occupant com-

partment.

■

Capacity and distribution

●

Do not exceed the maximum axle

weight rating or the total vehicle

weight rating.

●

Even if the total load of occupant’s

weight and the cargo load is less than

the total load capacity, do not apply the

load unevenly. Improper loading may

cause deterioration of steering or

braking control which may cause

death or serious injury.

■

When using a roof luggage carrier

Observe the following precautions:

●

Place the cargo so that its weight is dis-

tributed evenly between the front and

rear axles.

●

If loading long or wide cargo, never

exceed the vehicle overall length or

width. (



●

Before driving, make sure the cargo is

securely fastened on the roof luggage

carrier.

●

Loading cargo on the roof luggage

carrier will make the center of gravity

of the vehicle higher. Avoid high

speeds, sudden starts, sharp turns,

sudden braking or abrupt maneuvers,

otherwise it may result in loss of con-

trol or vehicle rollover due to failure to

operate this vehicle correctly and

result in death or serious injury.

●

If driving for a long distance, on rough

roads, or at high speeds, stop the vehi-

cle now and then during the trip to

make sure the cargo remains in its

place.

●

Do not exceed 154 lb. (70 kg) cargo

weight on the roof luggage carrier.

NOTICE

■

When loading cargo (vehicles with a

panoramic moon roof)

Be careful not to scratch the surface of

the panoramic moon roof.

176

4-1. Before driving

■

Total load capacity and seating capacity

These details are also described on the tire

and loading information label. (



P.467)

Vehicle load limits

Vehicle load limits include total
load capacity, seating capacity,
trailer weight rating and cargo
capacity.



Total load capacity (vehicle
capacity weight):

P.532

Total load capacity means the com-
bined weight of occupants, cargo
and luggage.



Seating capacity:



P.532

Seating capacity means the maxi-
mum number of occupants whose
estimated average weight is 150 lb.
(68 kg) per person.



TWR (Trailer Weight Rating)
(vehicles with towing package):



P.182, 532

TWR means the maximum gross
trailer weight (trailer weight plus its
cargo weight) that your vehicle is
able to tow.



TWR (Trailer Weight Rating)
(vehicles without towing pack-
age)

Lexus does not recommend towing
a trailer with your vehicle.



Cargo capacity

Cargo capacity may increase or
decrease depending on the weight
and the number of occupants.

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to the tires,

but also degrade steering and braking

ability, resulting in an accident.

177

4-1. Before driving

Driving

■

Matching trailer ball height to trailer

coupler height

No matter which class of tow hitch applies,

Trailer towing (vehicles with-
out towing package)

Lexus does not recommend towing
a trailer with your vehicle. Lexus
also does not recommend the
installation of a tow hitch or the use
of a tow hitch carrier for a wheel-
chair, scooter, bicycle, etc. Your
vehicle is not designed for trailer
towing or for the use of tow hitch
mounted carriers.

Trailer towing (vehicles with
towing package)

Your vehicle is designed primarily
as a passenger-and-load-carrying
vehicle. Towing a trailer can have an
adverse impact on handling, per-
formance, braking, durability, and
fuel consumption. For your safety
and the safety of others, you must
not overload your vehicle or trailer.
You must also ensure that you are
using appropriate towing equip-
ment, that the towing equipment
has been installed correctly and
used properly, and that you employ
the requisite driving habits.

Vehicle-trailer stability and braking
performance are affected by trailer
stability, brake performance and
setting, trailer brakes, the hitch and
hitch systems (if equipped).

To tow a trailer safely, use extreme
care and drive the vehicle in accor-
dance with your trailer’s character-
istics and operating conditions.

Lexus warranties do not apply to
damage or malfunction caused by
towing a trailer for commercial pur-
poses.

Contact your Lexus dealer for fur-
ther information about additional
requirements such as a towing kit,
etc.

178

4-1. Before driving

for a more safe trailer hookup, the trailer

ball setup must be the proper height for the

coupler on the trailer.

Coupler
Trailer ball

■

Before towing

Check that the following conditions are

met:

●

Ensure that your vehicle’s tires are prop-

erly inflated. (

P.537)

●

Trailer tires are inflated according to the

trailer manufacturer’s recommendation.

●

All trailer lights work as required by law.

●

All lights work each time you connect

them.

●

The trailer ball is set at the proper height

for the coupler on the trailer.

●

The trailer is level when it is hitched.

Do not drive if the trailer is not level, and

check for improper tongue weight, over-

loading, worn suspension, or other possi-

ble causes.

●

The trailer cargo is securely loaded.

●

The rear view mirrors conform to all

applicable federal, state/provincial or

local regulations. If they do not, install

rear view mirrors appropriate for towing

purposes.

■

Adaptive Variable Suspension System

The suspension can be switched for

improvement in driveability. (



P.366)

■

When towing a trailer

Disable the following systems, as the sys-

tems may not operate properly.

●

LTA (Lane Tracing Assist) (



P.243)

●

LDA (Lane Departure Alert) (



P.251)

●

Dynamic radar cruise control (

P.267)

●

Cruise control (

P.279)

●

BSM (Blind Spot Monitor) (



P.292)

●

PKSB (Parking Support Brake) (

P.318)

●

Intuitive parking assist (



P.301)

●

RCD (Rear Camera Detection) function

(



P.315)

■

Break-in schedule

If your vehicle is new or equipped with any

new power train components (such as an

engine, hybrid transmission, rear differential

or wheel bearing), Lexus recommends that

you do not tow a trailer until the vehicle has

been driven for over 500 miles (800 km).
After the vehicle has been driven for over

500 miles (800 km), you can start towing.

However, for the next 500 miles (800 km),

drive the vehicle at a speed of less than 50

mph (80 km/h) when towing a trailer, and

avoid full throttle acceleration.

■

Maintenance

●

If you tow a trailer, your vehicle will

require more frequent maintenance due

to the additional load. (See “Warranty

and Services Guide”, “Owner’s Manual

Supplement” or “Scheduled Mainte-

nance”.)

●

Retighten the fixing bolts of the towing

ball and bracket after approximately 600

miles (1000 km) of trailer towing.

■

If trailer sway occurs

One or more factors (crosswinds, passing

vehicles, rough roads, etc.) can adversely

affect handling of your vehicle and trailer,

179

4-1. Before driving

Driving

causing instability.

●

If trailer swaying occurs:

• Firmly grip the steering wheel. Steer

straight ahead.

Do not try to control trailer swaying by

turning the steering wheel.

• Begin releasing the accelerator pedal

immediately but very gradually to reduce

speed.

Do not increase speed. Do not apply

vehicle brakes.

If you make no extreme correction with the

steering or brakes, your vehicle and trailer

should stabilize. (if enabled, Trailer Sway

Control can also help to stabilize the vehicle

and trailer.)

●

After the trailer swaying has stopped:

• Stop in a safe place. Get all occupants

out of the vehicle.

• Check the tires of the vehicle and the

trailer.

• Check the load in the trailer.

Make sure the load has not shifted.

Make sure the tongue weight is appropri-

ate, if possible.

• Check the load in the vehicle.

Make sure the vehicle is not overloaded

after occupants get in.

If you cannot find any problems, the speed

at which trailer swaying occurred is beyond

the limit of your particular vehicle-trailer

combination. Drive at a lower speed to pre-

vent instability. Remember that swaying of

the towing vehicle-trailer increases as

speed increases.

WARNING

■

Trailer towing precautions

To tow a trailer safely, use extreme care

and drive the vehicle in accordance with

the trailer’s characteristics and operating

conditions. Failure to do so could cause

an accident resulting in death or serious

injury. Vehicle stability and braking per-

formance are affected by trailer stability,

brake setting and performance, and the

hitch. Your vehicle will handle differently

when towing a trailer.

■

To avoid accident or injury

●

Do not exceed the TWR, unbraked

TWR, GCWR, GVWR or GAWR.

●

If the gross trailer weight is over 2000

lb. (907 kg), a sway control device with

sufficient capacity is required.

●

Adjust the tongue weight within the

appropriate range. Place heavier loads

as close to the trailer axle as possible.

●

Do not exceed 65 mph (104 km/h),

the posted towing speed limit or the

speed limit for your trailer as set forth

in your trailer owner’s manual, which-

ever is lowest. Slow down sufficiently

before making a turn, in cross winds,

on wet or slippery surface, etc. to help

avoid an accident. If you experience a

vehicle-trailer instability from reduc-

ing a certain speed, slow down and

make sure you keep your vehicle

speed under the speed of which you

experience the instability.

●

Do not make jerky, abrupt or sharp

turns.

●

Do not apply the brakes suddenly as

you may skid, resulting in jackknifing

and loss of vehicle control. This is

especially true on wet or slippery sur-

faces.

●

Do not exceed the trailer hitch assem-

bly weight, gross vehicle weight, gross

axle weight and trailer tongue weight

capacities.

●

Slow down and downshift before

descending steep or long downhill

grades. Do not make sudden down-

shifts while descending steep or long

downhill grades.

180

4-1. Before driving

■

GCWR (Gross Combination
Weight Rating)

The maximum allowable gross combi-
nation weight. The gross combination
weight is the sum of the total vehicle
weight (including the occupants, cargo
and any optional equipment installed
on the vehicle) and the weight of the

trailer being towed (including the
cargo in the trailer).

■

GVWR (Gross Vehicle Weight
Rating)

The maximum allowable gross vehicle
weight. The gross vehicle weight is the
total weight of the vehicle. When tow-
ing a trailer, it is the sum of the vehicle
weight (including the occupants, cargo
and any optional equipment installed
on the vehicle) and the tongue weight.

■

GAWR (Gross Axle Weight Rat-
ing)

The maximum allowable gross axle
weight. The gross axle weight is the
load placed on each axle (front and
rear).

WARNING

●

Vehicle-trailer instability is more likely

on steep long downhills. Before

descending steep or long downhill

grades, slow down and downshift. Do

not make sudden downshifts when

descending steep or long downhill

grades. Avoid holding the brake pedal

down too long or applying the brakes

too frequently. This could cause the

brakes to overheat and result in

reduced braking efficiency.

●

Do not tow a trailer when the compact

spare tire is installed on your vehicle.

■

When towing a trailer

Lexus recommends trailers with brakes

that conform to any applicable federal

and state/provincial regulations.

●

If the gross trailer weight exceeds

unbraked TWR, trailer brakes are

required. Lexus recommends trailers

with brakes that conform to all applica-

ble federal and state/provincial regula-

tions.

●

Never tap into your vehicle’s hydraulic

system, as this will lower the vehicle’s

braking effectiveness.

●

Never tow a trailer without using a

safety chain securely attached to both

the trailer and the vehicle. If damage

occurs to the coupling unit or hitch

ball, there is danger of the trailer wan-

dering into another lane.

Towing related terms

181

4-1. Before driving

Driving

Front GAWR
Rear GAWR

■

TWR (Trailer Weight Rating)

The maximum allowable gross trailer
weight. The gross trailer weight is the
sum of the trailer weight and the weight
of the cargo in the trailer.
TWR is calculated assuming base vehi-
cle with one driver, one front passen-
ger, towing package (if available), hitch
and hitch systems (if required).

Additional optional equipment, passengers
and cargo in the vehicle will reduce the
trailer weight rating so as not to exceed
GCWR, GVWR and GAWR.
If the gross trailer weight exceeds 3000
lb. (1360 kg), it is recommended to use a
trailer with 2 or more axles.

With brakes

■

Unbraked TWR (Unbraked Trailer
Weight Rating)

The trailer weight rating for towing a
trailer without a trailer service brake
system.

Without brakes

■

Tongue Weight

The load placed on the trailer hitch ball.
(

P.182)



The gross trailer weight must never
exceed 5000 lb. (2265 kg).



The gross combination weight must
never exceed 10500 lb. (4750 kg).



The gross vehicle weight must never
exceed the GVWR indicated on the
Certification Label. (





The gross axle weight on each axle

Weight limits

182

4-1. Before driving

must never exceed the GAWR indi-
cated on the Certification Label.
(


