1-1. For safe use

1-1.For safe use

Use only floor mats designed specifi-
cally for vehicles of the same model
and model year as your vehicle. Fix
them securely in place onto the carpet.

Insert the retaining hooks (clips)
into the floor mat eyelets.

Turn the upper knob of each retain-
ing hook (clip) to secure the floor
mats in place.

Always align the

marks

The shape of the retaining hooks (clips)

may differ from that shown in the illustra-

tion.

Before driving

Observe the following before start-
ing off in the vehicle to ensure
safety of driving.

Installing floor mats

WARNING

Observe the following precautions.

Failure to do so may cause the driver’s

floor mat to slip, possibly interfering with

the pedals while driving. An unexpect-

edly high speed may result or it may

become difficult to stop the vehicle. This

could lead to an accident, resulting in

death or serious injury.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for

other models or different model year

vehicles, even if they are Lexus Genu-

ine floor mats.

●

Only use floor mats designed for the

driver’s seat.

●

Always install the floor mat securely

using the retaining hooks (clips) pro-

vided.

●

Do not use two or more floor mats on

top of each other.

●

Do not place the floor mat bottom-

side up or upside-down.

■

Before driving

●

Check that the floor mat is securely

fixed in the correct place with all the

provided retaining hooks (clips). Be

especially careful to perform this

check after cleaning the floor.

●

With the engine stopped and the shift

lever in P, fully depress each pedal to

the floor to make sure it does not inter-

fere with the floor mat.

1-1. For safe use

For safety and security

Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (



P.121)

Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. (



P.121)

Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
(



P.137)

Wear the seat belt correctly.
(



P.31)

Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (



P.31)

Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. (



P.51)

For safe driving

For safe driving, adjust the seat and
mirror to an appropriate position
before driving.

Correct driving posture

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver to lose

control of the vehicle.

●

Do not place a cushion between the

driver or passenger and the seatback.

A cushion may prevent correct pos-

ture from being achieved, and reduce

the effectiveness of the seat belt and

head restraint.

●

Do not place anything under the front

seats.

Objects placed under the front seats

may become jammed in the seat

tracks and stop the seat from locking

in place. This may lead to an accident

and the adjustment mechanism may

also be damaged.

●

Always observe the legal speed limit

when driving on public roads.

●

When driving over long distances,

take regular breaks before you start to

feel tired.

Also, if you feel tired or sleepy while

driving, do not force yourself to con-

tinue driving and take a break immedi-

ately.

Correct use of the seat belts

1-1. For safe use

Make sure that you can see backward
clearly by adjusting the inside rear view
mirror (if equipped), Digital Rear-view
Mirror (if equipped) and outside rear
view mirrors properly. (



P.142, 143,

151)

Adjusting the mirrors

Seat belts

Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle.

WARNING

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

■

Wearing a seat belt

●

Ensure that all passengers wear a seat

belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by one

person only. Do not use a seat belt for

more than one person at once, includ-

ing children.

●

Lexus recommends that children be

seated in the rear seat and always use

a seat belt and/or an appropriate child

restraint system.

●

To achieve a proper seating position,

do not recline the seat more than nec-

essary. The seat belt is most effective

when the occupants are sitting up

straight and well back in the seats.

●

Do not wear the shoulder belt under

your arm.

●

Always wear your seat belt low and

snug across your hips.

●

Make sure that the seat belts are

removed from the hangers (



P.126,

130) when using the seat belts for the
second outboard seats or third seats

: If equipped

1-1. For safe use

For safety and security



Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.



Position the lap belt as low as possi-
ble over the hips.



Adjust the position of the seatback.
Sit up straight and well back in the
seat.



Do not twist the seat belt.

WARNING

■

Pregnant women

Obtain medical advice and wear the seat

belt in the proper way. (



P.31)

Women who are pregnant should posi-

tion the lap belt as low as possible over

the hips in the same manner as other

occupants, extending the shoulder belt

completely over the shoulder and avoid-

ing belt contact with the rounding of the

abdominal area.
If the seat belt is not worn properly, not

only the pregnant woman, but also the

fetus could suffer death or serious injury

as a result of sudden braking or a colli-

sion.

■

People suffering illness

Obtain medical advice and wear the seat

belt in the proper way. (



P.31)

■

When children are in the vehicle



P.58

■

Seat belt damage and wear

●

Do not damage the seat belts by allow-

ing the belt, plate, or buckle to be

jammed in the door.

●

Inspect the seat belt system periodi-

cally. Check for cuts, fraying, and

loose parts. Do not use a damaged

seat belt until it is replaced. Damaged

seat belt cannot protect an occupant

from death or serious injury.

●

Ensure that the belt and plate are

locked and the belt is not twisted.

If the seat belt does not function cor-

rectly, immediately contact your Lexus

dealer.

●

Replace the seat assembly, including

the belts, if your vehicle has been

involved in a serious accident, even if

there is no obvious damage.

●

Do not attempt to install, remove,

modify, disassemble or dispose of the

seat belts. Have any necessary repairs

carried out by your Lexus dealer. Inap-

propriate handling may lead to incor-

rect operation.

Correct use of the seat belts

1-1. For safe use

■

Child seat belt usage

The seat belts of your vehicle were princi-

pally designed for persons of adult size.

●

Use a child restraint system appropriate

for the child, until the child becomes large

enough to properly wear the vehicle’s

seat belt. (



P.51)

●

When the child becomes large enough to

properly wear the vehicle’s seat belt, fol-

low the instructions regarding seat belt

usage. (



P.30)

■

Seat belt extender

If your seat belts cannot be fastened

securely because they are not long enough,

a personalized seat belt extender is avail-

able from your Lexus dealer free of charge.

To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.

To release the seat belt, press the
release button

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sud-

den stop or on impact. It may also lock if you

lean forward too quickly. A slow, easy

motion will allow the belt to extend so that

you can move around fully.

■

Automatic locking retractor (ALR)

When a passenger’s shoulder belt is com-

pletely extended and then retracted even

slightly, the belt is locked in that position

and cannot be extended. This feature is

WARNING

■

Using a seat belt extender

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

●

Do not wear the seat belt extender if

you can fasten the seat belt without the

extender.

●

Do not use the seat belt extender

when installing a child restraint system

because the belt will not securely hold

the child restraint system, increasing

the risk of death or serious injury in the

event of an accident.

●

The personalized extender may not be

safe on another vehicle, when used by

another person, or at a different seat-

ing position other than the one origi-

nally intended.

NOTICE

■

When using a seat belt extender

When releasing the seat belt, press on

the buckle release button on the

extender, not on the seat belt.
This helps prevent damage to the vehicle

interior and the extender itself.

Fastening and releasing the seat
belt

1-1. For safe use

For safety and security

used to hold a child restraint system (CRS)

firmly. To free the belt again, fully retract the

belt and then pull the belt out once more.

Push the seat belt shoulder anchor
down while pressing the release
button .

Push the seat belt shoulder anchor
up while pressing the release but-
ton .

Move the height adjuster up and down as
needed until you hear a click.

If the seat belt comes into contact with
the neck, change the position where to
pass the seat belt.
Make sure that all occupants are wear-

ing their seat belts before driving the
vehicle. (



P.31)

Detach the button

Change the position where to pass
the seat belt.

After changing the position, attach the but-
ton .

If the seat belt obstructs the view
depending on the angle of the seat
back, the view can be improved by
using the seat belt rerouter.

Pull the seat belt rerouter from the
seatback pocket.

Adjusting the seat belt shoulder
anchor height (front seats)

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder belt is

positioned across the center of your

shoulder. The belt should be kept away

from your neck, but not falling off your

shoulder. Failure to do so could reduce

the amount of protection in an accident

and cause death or serious injuries in the

event of a sudden stop, sudden swerve

or accident.

Seat belt guide (if equipped)

Seat belt rerouter (if equipped)

1-1. For safe use

Slide the belt past the slot of the
seat belt rerouter.

The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehi-
cle is subjected to certain types of
severe frontal or side collision or a
vehicle rollover.

The pretensioners do not activate in the
event of a minor frontal impact, a minor
side impact or a rear impact.

■

Replacing the belt after the preten-

sioner has been activated

If the vehicle is involved in multiple colli-

sions, the pretensioner will activate for the

first collision, but will not activate for the

second or subsequent collisions.

■

PCS-linked seat belt pretensioner con-

trol

If the PCS (Pre-Collision System) deter-

mines that the possibility of a collision with a

vehicle is high, the seat belt pretensioners

will be prepared to operate.

Seat belt pretensioners (front
and second outboard seats)

WARNING

■

Seat belt pretensioners

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

●

Do not place anything, such as a cush-

ion, on the front passenger’s seat.

Doing so will disperse the passenger’s

weight, which prevents the sensor

from detecting the passenger’s weight

properly. As a result, the seat belt pre-

tensioner for the front passenger’s seat

may not activate in the event of a colli-

sion.

●

If the pretensioner has activated, the

SRS warning light will come on. In that

case, the seat belt cannot be used

again and must be replaced at your

Lexus dealer.

1-1. For safe use

For safety and security

■

Location of the SRS airbags (4-passenger models)



SRS front airbags

SRS driver airbag/front passenger airbag

Can help protect the head and chest of the driver and front passenger from impact with
interior components

SRS knee airbags

Can help provide driver and front passenger protection



SRS side and curtain shield airbags

SRS front side airbags

Can help protect the torso of the front seat occupants

SRS rear side airbags

Can help protect the torso of occupants in the rear seats

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They work
together with the seat belts to help reduce the risk of death or serious injury.

SRS airbag system

1-1. For safe use

SRS curtain shield airbags

• Can help protect primarily the head of occupants in the outer seats
• Can help prevent the occupants from being thrown from the vehicle in the event of vehi-

cle rollover

SRS seat cushion airbags

Can help restrain the rear seat occupants

■

Location of the SRS airbags (5-passenger and 7-passenger models)



SRS front airbags

SRS driver airbag/front passenger airbag

Can help protect the head and chest of the driver and front passenger from impact with
interior components

SRS knee airbags

Can help provide driver and front passenger protection



SRS side and curtain shield airbags

SRS front side airbags

Can help protect the torso of the front seat occupants

SRS rear side airbags

Can help protect the torso of occupants in the second outer seats

SRS curtain shield airbags

• Can help protect primarily the head of occupants in the outer seats
• Can help prevent the occupants from being thrown from the vehicle in the event of vehi-

1-1. For safe use

For safety and security

cle rollover

■

SRS airbag system components (4-passenger models)

Knee airbags

Front passenger airbag

Side impact sensors (front door)

Curtain shield airbags

Front side airbags

SRS warning light

Seat belt pretensioners and force limiters (front seats)

Side impact sensors (front)

Rear side airbags

Driver airbag

Seat belt pretensioners (rear seats)

Side impact sensors (rear)

Safing sensor (rear)

Rear seat belt buckle switches

Seat cushion airbags

A
B
C
D

E
F

N
O

1-1. For safe use

“AIR BAG ON” and “AIR BAG OFF” indicator lights

Driver’s seat position sensor

Front passenger occupant classification sensors

Driver’s and passenger’s seat belt buckle switch

Front impact sensors

Airbag sensor assembly

■

SRS airbag system components (5-passenger and 7-passenger models)

Knee airbags

Front passenger airbag

Side impact sensors (front door)

Curtain shield airbags

Front side airbags

SRS warning light

Seat belt pretensioners and force limiters (front seats)

Side impact sensors (front)

Rear side airbags (second outboard seats)

Driver airbag

R
S

A
B
C
D

E
F

1-1. For safe use

For safety and security

Seat belt pretensioners (second outboard seats)

Side impact sensors (rear)

Safing sensor (rear)

“AIR BAG ON” and “AIR BAG OFF” indicator lights

Driver’s seat position sensor

Front passenger occupant classification sensors

Driver’s and passenger’s seat belt buckle switch

Front impact sensors

Airbag sensor assembly

Your vehicle is equipped with ADVANCED AIRBAGS designed based on the
US motor vehicle safety standards (FMVSS208). The airbag sensor assembly
(ECU) controls airbag deployment based on information obtained from the sen-
sors etc. shown in the system components diagram above. This information
includes crash severity and occupant information. As the airbags deploy, a chemi-
cal reaction in the inflators quickly fills the airbags with non-toxic gas to help
restrain the motion of the occupants.

■

If the SRS airbags deploy (inflate)

●

Slight abrasions, burns, bruising etc., may

be sustained from SRS airbags, due to the

extremely high speed deployment (infla-

tion) by hot gases.

●

A loud noise and white powder will be

emitted.

●

Parts of the airbag module (steering

wheel hub, airbag cover and inflator) as

well as the front seats, parts of the front

and rear pillars, and roof side rails, may

be hot for several minutes. The airbag

itself may also be hot.

●

The windshield may crack.

●

All of the doors will be unlocked.

(



P.99)

●

The brakes and stop lights will be con-

trolled automatically. (



P.366)

●

The interior lights will turn on automati-

cally. (



P.404)

●

The emergency flashers will turn on auto-

matically. (



P.488)

●

Fuel supply to the engine will be stopped.

●

For Safety Connect subscribers, if any of

the following situations occur, the system

is designed to send an emergency call to

the response center, notifying them of the

vehicle’s location (without needing to

push the “SOS” button) and an agent will

attempt to speak with the occupants to

ascertain the level of emergency and

assistance required. If the occupants are

unable to communicate, the agent auto-

matically treats the call as an emergency

and helps to dispatch the necessary

emergency services. (



P.64)

• An SRS airbag is deployed.

• A seat belt pretensioner is activated.

• The vehicle is involved in a severe rear-

end collision.

■

SRS airbag deployment conditions (SRS

front airbags/SRS seat cushion airbags

(if equipped))

●

The SRS front airbags and SRS seat cush-

ion airbags will deploy in the event of an

impact that exceeds the set threshold

level (the level of force corresponding to

an approximately 12 - 18 mph [20 - 30

N
O

R
S

1-1. For safe use

km/h] frontal collision with a fixed wall

that does not move or deform).

However, this threshold velocity will be
considerably higher in the following situa-
tions:
• If the vehicle strikes an object, such as a

parked vehicle or sign pole, which can

move or deform on impact

• If the vehicle is involved in an underride

collision, such as a collision in which the

front of the vehicle underrides, or goes

under, the bed of a truck

●

Depending on the type of collision, it is

possible that only the seat belt preten-

sioners and SRS seat cushion airbags will

activate.

●

The SRS front airbags for the front pas-

senger will not activate if there is no pas-

senger sitting in the front passenger seat.

However, the SRS front airbags for the

front passenger may deploy if luggage is

put in the seat, even if the seat is unoccu-

pied.

●

Vehicles with SRS seat cushion airbags:

The SRS seat cushion airbags on the rear

seat will not operate if the occupant is not

wearing a seat belt.

■

SRS airbag deployment conditions (SRS

side and curtain shield airbags)

●

The SRS side and curtain shield airbags

will deploy in the event of an impact that

exceeds the set threshold level (the level

of force corresponding to the impact

force produced by an approximately

3300 lb. [1500 kg] vehicle colliding with

the vehicle cabin from a direction per-

pendicular to the vehicle orientation at an

approximate speed of 12 - 18 mph [20 -

30 km/h]).

●

Both SRS curtain shield airbags may

deploy in the event of a severe side colli-

sion.

●

Both SRS curtain shield airbags will

deploy in the event of vehicle rollover.

●

Both SRS curtain shield airbags may also

deploy in the event of a severe frontal

collision.

■

Conditions under which the SRS air-

bags may deploy (inflate), other than a

collision

The SRS front airbags, SRS side and curtain

shield airbags and SRS seat cushion airbags

(if equipped) may also deploy if a serious

impact occurs to the underside of your

vehicle. Some examples are shown in the

illustration.

●

Hitting a curb, edge of pavement or hard

surface

●

Falling into or jumping over a deep hole

●

Landing hard or falling

The SRS curtain shield airbags may also

deploy under the situations shown in the

illustration.

●

The angle of vehicle tip-up is marginal

●

The vehicle skids and hits a curb stone

■

Types of collisions that may not deploy

the SRS airbags (SRS front airbags/SRS

seat cushion airbags (if equipped))

The SRS front airbags and SRS seat cushion

airbags do not generally inflate if the vehicle

is involved in a side or rear collision, if it rolls

over, or if it is involved in a low-speed fron-

tal collision. But, whenever a collision of any

type causes sufficient forward deceleration

of the vehicle, deployment of the SRS front

airbags and SRS seat cushion airbags may

occur.

●

Collision from the side

1-1. For safe use

For safety and security

●

Collision from the rear

●

Vehicle rollover

■

Types of collisions that may not deploy

the SRS airbags (SRS side and curtain

shield airbags)

The SRS side and curtain shield airbags

may not activate if the vehicle is subjected

to a collision from the side at certain angles,

or a collision to the side of the vehicle body

other than the passenger compartment.

●

Collision from the side to the vehicle

body other than the passenger compart-

ment

●

Collision from the side at an angle

The SRS side airbags do not generally

inflate if the vehicle is involved in a frontal or

rear collision, if it rolls over, or if it is involved

in a low-speed side collision.

●

Collision from the front

●

Collision from the rear

●

Vehicle rollover

The SRS curtain shield airbags do not gen-

erally inflate if the vehicle is involved in a

rear collision, if it pitches end over end, or if

it is involved in a low-speed side or low-

speed frontal collision.

●

Collision from the rear

●

Pitching end over end

■

When to contact your Lexus dealer

In the following cases, the vehicle will

require inspection and/or repair. Contact

your Lexus dealer as soon as possible.

●

Any of the SRS airbags have been

inflated.

●

The front of the vehicle is damaged or

deformed, or was involved in an accident

that was not severe enough to cause the

SRS front airbags and SRS seat cushion

airbags (if equipped) to inflate.

●

A portion of a door or its surrounding

area is damaged, deformed or has had a

hole made in it, or the vehicle was

involved in an accident that was not

severe enough to cause the SRS side and

curtain shield airbags to inflate.

1-1. For safe use

●

The pad section of the steering wheel,

dashboard near the front passenger air-

bag or lower portion of the instrument

panel is scratched, cracked, or otherwise

damaged.

●

Vehicles with SRS seat cushion airbags:

The seat cushion surface is scratched,

cracked, or otherwise damaged.

●

The surface of the seats with the SRS side

airbag is scratched, cracked, or other-

wise damaged.

●

The portion of the front pillars, rear pillars

or roof side rail garnishes (padding) con-

taining the SRS curtain shield airbags

inside is scratched, cracked, or otherwise

damaged.

WARNING

■

SRS airbag precautions

Observe the following precautions

regarding the SRS airbags.

Failure to do so may cause death or seri-

ous injury.

●

The driver and all passengers in the

vehicle must wear their seat belts

properly.

The SRS airbags are supplemental

devices to be used with the seat belts.

●

The SRS driver airbag deploys with

considerable force, and can cause

death or serious injury especially if the

driver is very close to the airbag. The

National Highway Traffic Safety

Administration (NHTSA) advises:

Since the risk zone for the driver’s air-

bag is the first 2 - 3 in. (50 - 75 mm) of

inflation, placing yourself 10 in. (250

mm) from your driver airbag provides

you with a clear margin of safety. This

distance is measured from the center

of the steering wheel to your breast-

bone. If you sit less than 10 in. (250

mm) away now, you can change your

driving position in several ways:

• Move your seat to the rear as far as

you can while still reaching the pedals

comfortably.

• Slightly recline the back of the seat.

Although vehicle designs vary, many

drivers can achieve the 10 in. (250

mm) distance, even with the driver

seat all the way forward, simply by

reclining the back of the seat some-

what. If reclining the back of your seat

makes it hard to see the road, raise

yourself by using a firm, non-slippery

cushion, or raise the seat if your vehi-

cle has that feature.

1-1. For safe use

For safety and security

WARNING

• If your steering wheel is adjustable, tilt

it downward. This points the airbag

toward your chest instead of your

head and neck.

The seat should be adjusted as recom-

mended by NHTSA above, while still

maintaining control of the foot pedals,

steering wheel, and your view of the

instrument panel controls.

●

If the seat belt extender has been con-

nected to the front seat belt buckles

but the seat belt extender has not also

been fastened to the latch plate of the

seat belt, the SRS front airbags will

judge that the driver and front passen-

ger are wearing the seat belt even

though the seat belt has not been con-

nected. In this case, the SRS front air-

bags may not activate correctly in a

collision, resulting in death or serious

injury in the event of a collision. Be

sure to wear the seat belt with the seat

belt extender.

●

The SRS front passenger airbag also

deploys with considerable force, and

can cause death or serious injury

especially if the front passenger is very

close to the airbag. The front passen-

ger seat should be as far from the air-

bag as possible with the seatback

adjusted, so the front passenger sits

upright.

●

Improperly seated and/or restrained

infants and children can be killed or

seriously injured by a deploying air-

bag. An infant or child who is too small

to use a seat belt should be properly

secured using a child restraint system.

Lexus strongly recommends that all

infants and children be placed in the

rear seats of the vehicle and properly

restrained. The rear seats are safer for

infants and children than the front pas-

senger seat. (



P.51)

●

Do not sit on the edge of the seat or

lean against the dashboard.

●

Do not allow a child to stand in front of

the SRS front passenger airbag unit or

sit on the knees of a front passenger.

●

Do not allow the front seat occupants

to hold items on their knees.

●

Do not lean against the door, the roof

side rail or the front, side and rear pil-

lars.

1-1. For safe use

WARNING

●

Do not allow anyone to kneel on the

passenger seats toward the door or

put their head or hands outside the

vehicle.

●

Do not attach anything to or lean any-

thing against areas such as the dash-

board, steering wheel pad and lower

portion of the instrument panel.

These items can become projectiles

when the SRS driver, front passenger

and knee airbags deploy.

●

Do not attach anything to areas such

as a door, windshield, side windows,

front or rear pillar, roof side rail and

assist grip.

●

Do not hang coat hangers or other

hard objects on the coat hooks. All of

these items could become projectiles

and may cause death or serious injury,

should the SRS curtain shield airbags

deploy.

●

If a vinyl cover is put on the area where

the SRS knee airbag will deploy, be

sure to remove it.

●

Do not use seat accessories which

cover the parts where the SRS side air-

bags and SRS seat cushion airbags (if

equipped) inflate as they may interfere

with inflation of the SRS airbags. Such

accessories may prevent the SRS side

airbags and SRS seat cushion airbags

(if equipped) from activating cor-

rectly, disable the system or cause the

SRS side airbags and SRS seat cushion

airbags (if equipped) to inflate acci-

dentally, resulting in death or serious

injury.

●

Do not strike or apply significant levels

of force to the area of the SRS airbag

components or the front doors.

Doing so can cause the SRS airbags to

malfunction.

●

Do not touch any of the component

parts immediately after the SRS air-

bags have deployed (inflated) as they

may be hot.

●

If breathing becomes difficult after the

SRS airbags have deployed, open a

door or window to allow fresh air in, or

leave the vehicle if it is safe to do so.

Wash off any residue as soon as possi-

ble to prevent skin irritation.

●

If the areas where the SRS airbags are

stored, such as the steering wheel pad

and front and rear pillar garnishes, are

damaged or cracked, have them

replaced by your Lexus dealer.

●

Do not place anything, such as a cush-

ion, on the front passenger’s seat.

Doing so will disperse the passenger’s

weight, which prevents the sensor

from detecting the passenger’s weight

properly. As a result, the SRS front air-

bags for the front passenger may not

deploy in the event of a collision.

1-1. For safe use

For safety and security

WARNING

■

Modification and disposal of SRS air-

bag system components

Do not dispose of your vehicle or per-

form any of the following modifications

without consulting your Lexus dealer.

The SRS airbags may malfunction or

deploy (inflate) accidentally, causing

death or serious injury.

●

Installation, removal, disassembly and

repair of the SRS airbags

●

Repairs, modifications, removal or

replacement of the steering wheel,

instrument panel, dashboard, seats or

seat upholstery, front, side and rear pil-

lars, roof side rails, front door panels,

front door trims or front door speakers

●

Modifications to the front door panel

(such as making a hole in it)

●

Repairs or modifications of the front

fender, front bumper, or side of the

occupant compartment

●

Installation of a grille guard (bull bars,

kangaroo bar, etc.), snow plows,

winches or roof luggage carrier

●

Modifications to the vehicle’s suspen-

sion system

●

Installation of electronic devices such

as mobile two-way radios and CD

players

●

Modifications to your vehicle for a per-

son with a physical disability

1-1. For safe use

For safety and security

WARNING

■

Front passenger occupant classifica-

tion system precautions

Observe the following precautions

regarding the front passenger occupant

classification system.
Failure to do so may cause death or seri-

ous injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat

belt plate has not been left inserted

into the buckle before someone sits in

the front passenger seat.

●

Make sure the “AIR BAG OFF” indi-

cator light is not illuminated when

using the seat belt extender for the

front passenger seat. If the “AIR BAG

OFF” indicator light is illuminated, dis-

connect the extender tongue from the

seat belt buckle, and reconnect the

seat belt. Reconnect the seat belt

extender after making sure the “AIR

BAG ON” indicator light is illumi-

nated.

If you use the seat belt extender while

the “AIR BAG OFF” indicator light is

illuminated, the SRS airbags for the

front passenger will not activate, which

could cause death or serious injury in

the event of a collision.

●

Do not apply a heavy load to the front

passenger seat or equipment (e.g.

seatback pocket).

●

Do not put weight on the front passen-

ger seat by putting your hands or feet

on the front passenger seat seatback

from the rear passenger seat.

●

Do not let a rear passenger lift the

front passenger seat with their feet or

press on the seatback with their legs.

●

Do not put objects under the front pas-

senger seat.

●

Do not recline the front passenger

seatback so far that it touches a rear

seat. This may cause the “AIR BAG

OFF” indicator light to be illuminated,

which indicates that the SRS airbags

for the front passenger will not activate

in the event of a severe accident. If the

seatback touches the rear seat, return

the seatback to a position where it

does not touch the rear seat. Keep the

front passenger seatback as upright as

possible when the vehicle is moving.

Reclining the seatback excessively

may lessen the effectiveness of the

seat belt system.

●

If an adult sits in the front passenger

seat, the “AIR BAG ON” indicator

light is illuminated. If the “AIR BAG

OFF” indicator is illuminated, ask the

passenger to sit up straight, well back

in the seat, feet on the floor, and with

the seat belt worn correctly. If the “AIR

BAG OFF” indicator still remains illu-

minated, either ask the passenger to

move to the rear seat, or if that is not

possible, move the front passenger

seat fully rearward.

●

When it is unavoidable to install a for-

ward-facing child restraint system on

the front passenger seat, install the

child restraint system on the front pas-

senger seat in the proper order.

(



P.52)

●

Do not modify or remove the front

seats.

●

Do not kick the front passenger seat or

subject it to severe impact. Otherwise,

the SRS warning light may come on to

indicate a malfunction of the front pas-

senger occupant classification system.

In this case, contact your Lexus dealer

immediately.

●

Child restraint systems installed on the

rear seat should not contact the front

seatbacks.

●

Do not use a seat accessory, such as a

cushion and seat cover, that covers the

seat cushion surface.

1-1. For safe use

■

Adult

■

Child

■

Child restraint system with infant

WARNING

●

Do not modify or replace the uphol-

stery of the front seat.

Condition and operation in the front passenger occupant classification
system

Indicators/
warning lights

“AIR BAG ON” and “AIR BAG OFF” indica-
tor lights

“AIR BAG ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt
reminder light

Off

or flashing

Devices

Front passenger airbag

Activated

Front passenger knee airbag

Indicators/
warning lights

“AIR BAG ON” and “AIR BAG OFF” indica-
tor lights

“AIR BAG OFF” or “AIR
BAG ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt
reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated or activated

Front passenger knee airbag

Indicators/
warning lights

“AIR BAG ON” and “AIR BAG OFF” indica-
tor lights

“AIR BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt
reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

1-1. For safe use

For safety and security

■

Unoccupied

■

There is a malfunction in the system

: The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize him/her as an adult depending on
his/her physique and posture.

: In the event the front passenger is wearing a seat belt.

: In the event the front passenger does not wear a seat belt.

: For some children, child in seat, child in booster seat or child in convertible seat, the sys-

tem may not recognize him/her as a child. Factors which may affect this can be the phy-
sique or posture.

: Never install a rear-facing child restraint system on the front passenger seat. A forward-

facing child restraint system should only be installed on the front passenger seat when it
is unavoidable. (



P.52)

: In case the indicator light is not illuminated, consult this manual on how to install the child

restraint system properly. (



P.51)

■

Using the ottoman (if equipped)

The “AIR BAG ON” indicator may turn on if the ottoman is subject to a strong impact when

the ottoman is being used.

Indicators/
warning lights

“AIR BAG ON” and “AIR BAG OFF” indica-
tor lights

“AIR BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt
reminder light

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

Indicators/
warning lights

“AIR BAG ON” and “AIR BAG OFF” indica-
tor lights

“AIR BAG OFF”

SRS warning light

Driver’s and front passenger’s seat belt
reminder light

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the vehi-

cle even when the back door is closed,

open the windows and have the vehi-

cle inspected at your Lexus dealer as

soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the engine.

●

Do not leave the vehicle with the

engine running for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the engine running in an

area with snow build-up, or where it is

snowing. If snowbanks build up around

the vehicle while the engine is running,

exhaust gases may collect and enter

the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by your Lexus dealer.

1-2. Child safety

For safety and security

1-2.Child safety

Points to remember: P.51
Child restraint system: P.52
When using a child restraint system:
P.53
Child restraint system installation
method
• Fixed with a seat belt: P.55
• Fixed with a child restraint LATCH

anchor: P.59

• Using an anchor bracket (for top

tether strap): P.61

The laws of all 50 states of the U.S.A.
as well as Canada now require the use
of child restraint systems.



Prioritize and observe the warnings,
as well as the laws and regulations

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.102, 155)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, back door,
seats etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the side win-

dows, the moon roof or other features of

the vehicle. In addition, heat build-up or

extremely cold temperatures inside the

vehicle can be fatal to children.

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.

Use a child restraint system when
riding with a small child that cannot
properly use a seat belt. For the
child’s safety, install the child
restraint system to a rear seat. Be
sure to follow the installation method
that is in the operation manual
enclosed with the restraint system.

Table of contents

Points to remember

1-2. Child safety

for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat
belt.



Choose a child restraint system that
suits your vehicle and is appropriate
to the age and size of the child.

■

Types of child restraint system installation methods

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For instal-

lation details, refer to the operation

manual enclosed with the child

restraint system. General installation

instruction is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking,

sudden swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Make sure you have complied with all

installation instructions provided with

the child restraint system manufac-

turer and that the system is properly

secured.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the lug-

gage compartment.

Child restraint system

1-2. Child safety

For safety and security

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the seat as follows and install the
child restraint system.



Adjust the seatback angle to the
most upright position.

If there is a gap between the child seat and
the seatback, adjust the seatback angle
until good contact is achieved.



Move the front seat fully rearward. If
the passenger seat height can be
adjusted, move it to the upper most
position.



If the head restraint interferes with
the child restraint system installation

Installation method

Page

Seat belt attachment

P.55

Child restraint LATCH

anchors attachment

P.59

Anchor brackets (for top

tether strap) attachment

P.61

When using a child restraint sys-
tem

1-2. Child safety

and the head restraint can be
removed, remove the head
restraint. Otherwise, put the head
restraint in the upper most position.

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Never install a rear-facing child

restraint system on the front passen-

ger seat even if the “AIR BAG OFF”

indicator light is illuminated. In the

event of an accident, the force of the

rapid inflation of the front passenger

airbag can cause death or serious

injury to the child if the rear-facing

child restraint system is installed on the

front passenger seat.

●

A forward-facing child restraint sys-

tem may be installed on the front pas-

senger seat only when it is

unavoidable. A child restraint system

that requires a top tether strap should

not be used in the front passenger seat

since there is no top tether strap

anchor for the front passenger seat.

●

A forward-facing child restraint sys-

tem may be installed on the front pas-

senger seat only when it is

unavoidable. When installing a for-

ward-facing child restraint system on

the front passenger seat, adjust the

seatback angle to the most upright

position, move the seat to the rearmost

position, even if the “AIR BAG OFF”

indicator light is illuminated.

If the head restraint interferes with the

child restraint system installation and

the head restraint can be removed,

remove the head restraint.

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side airbags and curtain shield air-

bags inflate, and the impact could

cause death or serious injury to the

child.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

1-2. Child safety

For safety and security

A child restraint system for a small
child or baby must itself be properly
restrained on the seat with the lap por-
tion of the lap/shoulder belt.

■

Installing child restraint system
using a seat belt (child restraint
lock function belt)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

■

Rear-facing



Infant seat/con-

vertible seat

Adjust the second seat or the third
seat (if equipped)

If there is a gap between the child restraint

system and the seatback, adjust the seat-

back angle until good contact is achieved.

Place the child restraint system on
the second seat or the third seat (if
equipped) facing the rear of the
vehicle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

WARNING

●

Use a child restraint system suitable to

the age and size of the child and install

it to the rear seat.

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the right-

hand rear seat.

●

Adjust the front passenger seat so that

it does not interfere with the child

restraint system.

●

5-passenger and 7-passenger mod-

els: When installing a child restraint

system on the second center seat,

adjust both seat cushions to the same

position and align both seatbacks at

the same angle. The seatbacks must be

adjusted to the same angle. Other-

wise, the child restraint system cannot

be securely restrained and this may

cause death or serious injuries in the

event of sudden braking, sudden

swerving or an accident.

●

Child restraint system installed on the

third seat (if equipped) should not con-

tact the second seatbacks.

Child restraint system fixed with
a seat belt

1-2. Child safety

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system down into the second seat
or the third seat (if equipped), allow
the shoulder belt to retract until the
child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.58)

■

Forward-facing



Convertible

seat

Adjust the seat.

When using the front passenger seat: If

installing the child restraint system to the

front passenger seat is unavoidable, refer

to P.53 for front passenger seat adjust-

ment.
When using the second seat or the third

seat (if equipped): If there is a gap between

the child restraint system and the seatback,

adjust the seatback angle until good con-

tact is achieved.

If the head restraint interferes with
the child restraint system installa-
tion and the head restraint can be
removed, remove the head
restraint. (



P.137)

Place the child restraint system on
the seat facing the front of the vehi-
cle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock

1-2. Child safety

For safety and security

mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system into the second seat or the
third seat (if equipped), allow the
shoulder belt to retract until the
child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

If the child restraint has a top tether
strap, follow the child restraint
manufacturer’s operation manual
regarding the installation, using the
top tether strap to latch onto the
top tether strap anchor. (



P.61)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.58)

■

Booster seat

If installing the child restraint sys-
tem to the front passenger seat is
unavoidable, refer to P.53 for front
passenger seat adjustment.

High back type: If the head restraint
interferes with your child restraint
system, and the head restraint can
be removed, remove the head
restraint. Otherwise, put the head
restraint in the upper most position.
(



P.137)

Place the child restraint system on
the seat facing the front of the vehi-
cle.



Booster type



High back type

Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and

1-2. Child safety

insert the plate into the buckle.
Make sure that the belt is not
twisted.

Check that the shoulder belt is correctly

positioned over the child’s shoulder and

that the lap belt is as low as possible.

(



P.30)

■

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death.

If this occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

●

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

●

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

●

After securing a child restraint system,

never adjust the seat.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

When securing some types of child

restraint systems in second seats or

the third seas (if equipped), it may not

be possible to properly use the seat

belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different

position. Failure to do so may result in

death or serious injury.

1-2. Child safety

For safety and security

■

Child restraint LATCH anchors



5-passenger and 7-passenger
models

LATCH anchors are provided for the
second outboard seats. (Marks dis-
playing the location of the anchorages
are attached to the seats.)



4-passenger models

LATCH anchors are provided for the
each second seats. (Marks displaying
the location of the anchorages are
attached to the seats.)

■

When installing in the seats

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

Adjust the seatback angle to the
most upright position. When install-
ing a forward-facing child seat, if
there is a gap between the child
seat and the seatback, adjust the
seatback angle until good contact
is achieved.

If the head restraint interferes with
the child restraint system installa-
tion and the head restraint can be
removed, remove the head
restraint. Otherwise, put the head

WARNING

●

When installing a child restraint sys-

tem in the second center seat (if

equipped), adjust both seatbacks at

the same angle. Otherwise, the child

restraint system cannot be securely

restrained and this may cause death or

serious injuries in the event of sudden

braking, sudden swerving or an acci-

dent.

■

When installing a booster seat

To prevent the belt from going into ALR

lock mode, do not fully extend the shoul-

der belt. ALR mode causes the belt to

tighten only. This could cause injury or

discomfort to the child. (



P.32)

■

Do not use a seat belt extender

If a seat belt extender is used when

installing a child restraint system, the seat

belt will not securely hold the child

restraint system, which could cause

death or serious injury to the child or

other passengers in the event of sudden

braking, sudden swerving or an accident.

Child restraint system fixed with
a child restraint LATCH anchor

Lexus LX600 (2024 year). Manual in english - page 1
