Lexus NX450H+ (2022 year). Manual in english

"Charging Stopped Due to Pulled Charging Connector"

Cause

Remedy

●

Charging connector is re-
moved while charging

●

After the hybrid battery
(traction battery) is fully
charged, the charging con-
nector is removed while the
hybrid battery (traction bat-
tery) is being recharged
again because electricity-
consuming functions

have

been used and the remaining
charge is now reduced.

If the charging connector is disconnected dur-
ing charging, charging will be suspended. To
continue charging, reconnect the charging
connector.

Charging connector is not se-
curely connected

Check the connection status of the charging
connector.

●

When connecting the charging connector,
make sure not to touch the latch release but-
ton. Insert the charging connector securely
until you hear a click. The charging connec-
tor may not be connected correctly if the
latch release button is pressed while insert-
ing.

●

After connecting the charging connector,
check that the latch release button is not
pressed and the charging indicator of the
charging port is turned on.

If charging cannot be carried out, even though
the proper procedures were followed, have the
vehicle inspected by your Lexus dealer.

Latch release button of charg-
ing connector was pressed
while charging

When the latch release button is pressed while
charging, charging stops. To continue charging,
reconnect the charging connector.

*1 :

Electricity is consumed when operating traction battery heater. Using My Room

Mode also consumes power.

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

657

When tr

ouble arises

"Charging Complete Limited Charge Due to Battery Temp"

Cause

Remedy

Charging was stopped to protect the
hybrid battery (traction battery) as it
continued to remain hot for a certain
period of time.

Allow the hybrid battery (traction bat-
tery) to cool down and perform charg-
ing again if the charging amount has
not reached the desired amount.

"Charging Stopped Check Charging Source"

Cause

Remedy

Problem in
power supply
from external
power source

Check the following items.

●

Plug is not disconnected

●

Plug is securely inserted

●

Power source indicator on the CCID (Charging Circuit Inter-
rupting Device) is illuminated

●

The circuit breaker has tripped

●

Extension cord is not used and outlet is not overloaded

●

Connected to a dedicated power line

●

Electrical leakage has occurred or not

If there is no problem with any of the above items, there may be
a problem with the outlet of the building. Contact an electrician
and request an inspection. (Contact the facility manager of the
charging station when there is a problem with charging station.)
If charging cannot be carried out, even though there is no prob-
lem with the power source path, there may be a malfunction in
the system. Have the vehicle inspected by your Lexus dealer.
Furthermore, if the error warning indicator on the CCID
(Charging Circuit Interrupting Device) is flashing, there may
be an electrical leakage. Consult your Lexus dealer.

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

658

Cause

Remedy

Charger has
stopped
charging

●

Charging may be canceled by an interruption of power sup-
ply depending on specifications of a charger. Refer to the
instructions provided with the charger.

•

When charging is stopped using the charger

•

Equipment with charging schedule function

•

Equipment that is not compatible with the charging schedule
function of the vehicle

●

Check if it is possible to charge with the AC charging cable
equipped to the vehicle. If charging cannot be carried out,
even when using the genuine AC charging cable, consult
your Lexus dealer.

Charger is not
compatible
with vehicle

Check if it is possible to charge with the AC charging cable
equipped to the vehicle.
If charging cannot be carried out, even when using the genuine
AC charging cable, consult your Lexus dealer.

Cause

Remedy

Power is being
consumed by
electrical com-
ponents of vehi-
cle

Check the following items, and then carry out charging again.

●

If the headlights and audio are turned on, turn them off.

●

Turn the power switch off.

If charging cannot be carried out, even after performing the
above, the 12-volt battery may not be sufficiently charged.
Operate the hybrid system for approximately 15 minutes or
more to charge the 12-volt battery.

Cause / Remedy

Malfunction occurred in charging system
Have the vehicle checked by your Lexus dealer.

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

659

When tr

ouble arises

"The Traction Battery Temp is low System put priority on charging to
preserve battery condition" (Alaska and Canada only)

Cause

Remedy

The traction battery
warming control
was operated

When the traction battery warming control operates, the
charging schedule is not used and charging is performed.
This is a control to protect the hybrid battery (traction
battery), and not a malfunction.

"Engine Started to Clean System EV Driving Unavailable"

Remedy

EV driving may be canceled in order to protect the hybrid system, etc.
In this case, perform driving with the gasoline engine until EV driving will be
returned to automatically.

"No New Fuel has been Added Recently Please refuel"

Cause

Remedy

Refueling has not been performed for a certain amount
of time, and the quality of the fuel in the fuel tank may
have decreased.

Refuel the vehicle im-
mediately.

"Shift System Malfunction Shifting Unavailable Drive to a Safe Place
and Stop"

Cause

Remedy

There is a malfunction in the shift
control system.

Have the vehicle checked by your Lexus
dealer immediately.

"Shift System Malfunction Driving Unavailable"

Cause

Remedy

There is a malfunction in the shift
control system.

Have the vehicle checked by your Lexus
dealer immediately.

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

660

If a message that indicates the need for the shift lever operation is
displayed

Cause

Remedy

To prevent the shift lever from being operated incorrectly
or the vehicle from moving unexpectedly, a message that
requires shifting the shift position may be displayed on
the multi-information display.

Follow the instruction
of the message and
shift the shift position.

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

661

When tr

ouble arises

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

"Key Battery Low Replace Key Battery"

Cause

Remedy

The electronic key has a low battery.

Replace the electronic key battery.

"System Malfunction Visit Your Dealer"

Cause

Remedy

Indicates one of the following systems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist)

●

AHB (Automatic High Beam)

●

AHS (Adaptive High-beam System)

●

Dynamic radar cruise control system

●

RSA (Road Sign Assist)

●

BSM (Blind Spot Monitor)

●

RCTA (Rear Cross Traffic Alert)

●

Automatic Rear Flashing Hazard Lights

●

Safe Exit Assist (with door opening control)

●

Have the vehicle inspected
by your Lexus dealer im-
mediately.

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

662

Cause

Remedy

●

Intuitive parking assist

●

PKSB (Parking Support Brake)

●

RCD (Rear camera detection)

●

Have the vehicle inspected
by your Lexus dealer im-
mediately.

Cause

Remedy

Indicates one of the following systems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist)

●

AHB (Automatic High Beam)

●

AHS (Adaptive High-beam System)

●

Dynamic radar cruise control system

●

RSA (Road Sign Assist)

●

BSM (Blind Spot Monitor)

●

RCTA (Rear Cross Traffic Alert)

●

Automatic Rear Flashing Hazard Lights

●

Safe Exit Assist (with door opening control)

●

Intuitive parking assist

●

PKSB (Parking Support Brake)

●

RCD (Rear camera detection)

●

Follow the following cor-
rection methods.

●

Check the voltage of the
12-volt battery

●

Remove any dirt or foreign
matter from the front/rear
side radar sensors

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

663

When tr

ouble arises

Cause

Remedy

Indicates one of the following systems is
disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA

（

Lane Change Assist

）

●

AHB (Automatic High Beam)

●

AHS

（

Adaptive High-beam System

）

●

Dynamic radar cruise control system

●

RSA (Road Sign Assist)

●

Follow the following correction
methods.

●

Using the windshield wipers, re-
move the dirt or foreign matter
from the windshield.

●

Using the air conditioning system,
defog the windshield.

●

Close the hood, remove any stick-
ers, etc. to clear the obstruction in
front of the front camera.

"System Stopped Front Camera Out of Temperature Range Wait until
Normal Temperature"

Cause

Remedy

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist)

●

AHB (Automatic High Beam)

●

AHS (Adaptive High-beam
System)

●

Dynamic radar cruise control
system

●

RSA (Road Sign Assist)

●

Follow the following correction methods.

●

If the front camera is hot, such as after the
vehicle is parked in the sun, use the air con-
ditioning system to decrease the tempera-
ture around the front camera

●

If a sunshade was used when the vehicle
was parked, depending on its type, the
sunlight reflected from the surface of the
sunshade may cause the temperature of the
front camera to become excessively high

●

If the front camera is cold, such after the
vehicle is parked in an extremely cold envi-
ronment, use the air conditioning system to
increase the temperature around the front
camera

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

664

"System Stopped Front Radar Sensor Blocked Clean Radar Sensor"

Cause

Remedy

Indicates one of the following
systems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change As-

sist)

●

AHB (Automatic High
Beam)

●

AHS (Adaptive High-beam
System)

●

Dynamic radar cruise con-
trol system

●

Follow the following correction methods.

●

Check if there is any foreign matter attached
to the radar sensor or radar sensor cover and
clean them if necessary.

→

P.373

●

This message may be displayed when driving in
an open area with few nearby vehicles or struc-
tures, such as a desert, grasslands, suburbs,
etc.
The message may be cleared by driving the
vehicle in an area with structures, vehicles, etc.
nearby.

"System Stopped Front Radar Sensor Out of Temperature Range Wait
until Normal Temperature"

Cause

Remedy

Indicates one of the following systems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist)

●

AHB (Automatic High Beam)

●

AHS (Adaptive High-beam System)

●

Dynamic radar cruise control system

●

The temperature of the ra-
dar sensor is outside of the
operating range. Wait for
the temperature to become
appropriate.

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

665

When tr

ouble arises

Cause

Remedy

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist)

●

AHB (Automatic High Beam)

●

AHS (Adaptive High-beam Sys-
tem)

●

Dynamic radar cruise control
system

●

Follow the following correction methods.

●

Check if there is any foreign matter attach-
ed to the radar sensor or radar sensor cov-
er and clean them if necessary.

→

P.373

●

The radar sensor may be misaligned and
will be adjusted automatically while driving.
Continue driving for a while.

Cause

Remedy

Indicates one of the following systems is disa-
bled.

●

RCD (Rear camera detection)

●

PKSB (Parking Support Brake)

●

Remove any dirt or foreign
matter from the front/rear
cameras.

"Check Engine"

Cause

Remedy

It may indicate a malfunc-
tion.

●

Have the vehicle inspected by your Lexus dealer
immediately.

"Hybrid System Malfunction"

Cause

Remedy

It may indicate a malfunc-
tion.

●

Have the vehicle inspected by your Lexus dealer
immediately.

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

666

"Accelerator System Malfunction"

Cause

Remedy

It may indicate a malfunc-
tion.

●

Have the vehicle inspected by your Lexus dealer
immediately.

"Plug-in Charging System Malfunction"

Cause

Remedy

It may indicate a malfunc-
tion.

●

Have the vehicle inspected by your Lexus dealer
immediately.

"Traction battery system malfunction"

Cause

Remedy

It may indicate a malfunc-
tion.

●

Have the vehicle inspected by your Lexus dealer
immediately.

"Hybrid System Stopped"

Cause

Remedy

The vehicle may have run
out of fuel.

●

Stop the vehicle in a safe place and, if the fuel level
is low, refuel the vehicle.

"Engine stopped No Fuel"

Cause

Remedy

The vehicle may have run
out of fuel.

●

Stop the vehicle in a safe place and, if the fuel level
is low, refuel the vehicle.

Cause

Remedy

The LCA function cannot be used as

the operating conditions have not been
met.

→

P.403

●

Operate the turn signal lever again
after all of the operating conditions
are met.

* :

If equipped

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

667

When tr

ouble arises

If the hybrid system will not start

When the hybrid system cannot be started even though the correct
starting procedure is being followed

Cause

Remedy

If the smart access system with push-
button start has been disabled by a
setting, the electronic key may not
operate normally.

Make sure that the smart access system
with push-button start has not been dis-
abled by a customization setting. If the
function has been disabled, enable it.

If the electronic key has been set to
battery saving mode, it may not op-
erate normally.

Check if electronic key has been set to
battery saving mode. If it is, cancel the
mode.

There may not be sufficient fuel in the
vehicle’s tank.

Refuel the vehicle.

There may be a malfunction in the
immobilizer system.

●

If the key is touching or is covered by
a metallic object, move the key away
from the object.

●

If the key is near to or touching a key to
the security system (key with a built-in
transponder chip) of another vehicle,
move the key away from the other key.

There may be a malfunction in the
steering lock system.

Contact your Lexus dealer.

The hybrid system may be malfunc-
tioning due to an electrical problem
such as electronic key battery deple-
tion or a blown fuse.

However, depending on the type of mal-
function, a temporary measure is available
to start the hybrid system.

There may be a malfunction in the
shift control system.

Contact your Lexus dealer.

There is a possibility that the temper-
ature of the hybrid battery (traction
battery) is extremely low (approxi-
mately below -22°F [-30°C]).

Try to start the hybrid system again after
the temperature of the hybrid battery in-
creases due to the outside temperature
increase etc.

*1 :

It may not be possible to shift the shift position from P.

9-3. If the hybrid system will not start

669

When tr

ouble arises

Starting the hybrid system in an emergency

Do not use this starting procedure except in cases of emergency.

Pull the parking brake switch to check that the parking brake is set.

Parking brake indicator will come on.

Check that the shift position is in P.

Change the power switch to ACC.

Press and hold the power switch for about 15 seconds while depressing the
brake pedal firmly.

Even if the hybrid system can be started using the above steps, the system may be
malfunctioning.
Have the vehicle checked by your Lexus dealer immediately.

Starting the hybrid system when the electronic key is not operating
normally

Ensure that the shift position is in P and depress the brake pedal.

Touch the Lexus emblem side of the electronic key to the power switch.

When the electronic key is detected, a buzzer will sound and the power switch mode
will change to ON.
If the smart access system with push-button start has been disabled by a customization
setting, the power switch mode will change to ACC.

Firmly depress the brake pedal and check that a message is shown on the
multi-information display.

Press the power switch.

In the event that the hybrid system still cannot be started, contact your Lexus dealer.

9-3. If the hybrid system will not start

670

INFORMATION

■

Stopping the hybrid system

Shift the shift position to P, set the parking brake and press the power switch as you
normally do when stopping the hybrid system.

■

Electronic key battery

As the above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immediately when the battery is depleted.

■

Changing power switch modes

Release the brake pedal and press the power switch in step

above. The hybrid

system will not start and the mode will be changed each time the switch is pressed.

Lexus NX450H+ (2022 year). Manual in english - page 40
