Lexus NX450H+ (2022 year). Manual in english - page 18

Using the personal lights

Touch the light.

The personal lights will turn on/off each time they are
touched.

4-4. Illuminating the interior

299

Interior feat

Using the interior features

Location of the storage features

WARNING

Do not leave eyeglasses, lighters or spray cans in the storage spaces, as the following
may occur when cabin temperature becomes high:

●

Eyeglasses may be deformed by heat or cracked if they come into contact with other
stored items.

●

Lighters or spray cans may explode. If they come into contact with other stored items,
a lighter may catch fire or a spray can may release gas, causing a fire hazard.

Glove box

Auxiliary boxes

Card holders

Bottle holders

Console box

Cup holders

Coin box

INFORMATION

■

Glove box light and console box light

The glove box light and the console box light turn on when the tail lights are on.

4-5. Using the interior features

300

Using the auxiliary boxes

Press in the lid.

WARNING

●

Do not store items heavier than 0.44 lb. (200 g). Doing so may cause the auxiliary
box to open and the items inside may fall out, resulting in an accident.

●

When driving or when the auxiliary box is not in use, keep the lid closed. In the event of
sudden braking or sudden swerving, an accident may occur due to an occupant being
struck by the items stored inside.

Push the lid.

To close, press in and release the lid.

WARNING

▶

Type A

▶

Type B

4-5. Using the interior features

301

Interior feat

Location of the card holders

Using the glove box

WARNING

When driving or when the glove box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, the front passenger may strike the
glove box lid or stowed items may fly out, possibly leading to an accident.

To open the glove box, pull the lever. The glove box can be locked and unlocked
using the mechanical key.

To open the glove box, pull the lever.

Lock with the mechanical key.

Unlock with the mechanical key.

INFORMATION

■

Glove box light

The glove box light turns on when the tail lights are on.

Use the cup holders

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury.
If possible, cover hot drinks to prevent burns.

4-5. Using the interior features

302

▶

Front

▶

Rear

Pull down the armrest.

Locations of the bottle holders

NOTICE

When using a bottle holder, observe the following precautions.

●

Do not place open bottles, glass cups, or paper cups containing liquid in the bottle
holders.
The liquid may spill out and glass cups may break.

●

When storing a bottle, close the cap.

▶

Front

4-5. Using the interior features

303

Interior feat

INFORMATION

■

Bottle holders

A bottle may not be able to be stored depending on its size or shape.

Using the console box

WARNING

When driving or when the console box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, an occupant may strike the
console box lid or stowed items may fly out, possibly leading to an accident.

To open the console box, lift the lid while pushing the button.

The console box can be opened from either side.

INFORMATION

■

Console box light

The console box light turns on when the tail lights are on.

▶

Rear

4-5. Using the interior features

304

Using the coin box

WARNING

When driving or when the coin box is not in use, keep it closed.
If left open, in the event of sudden braking or sudden swerving, the driver may strike the
coin box lid or stowed items may fly out, possibly leading to an accident.

Push the knob up to open the
lid.

4-5. Using the interior features

305

Interior feat

Convenient interior features

Function and operation of the USB charging port

NOTICE

■

To prevent damage to the USB charging ports

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

Rear console: When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the USB charging ports.

●

Do not disassemble or modify the USB charging ports.

■

To prevent damage to external devices

●

Do not leave external devices in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to an external device.

●

Do not push down on or apply unnecessary force to an external device or the cable of
an external device while it is connected.

■

To prevent 12-volt battery discharge

Do not use the USB charging ports for a long period of time with the hybrid system
stopped.

The USB charging ports are used to supply 3.0 A of electricity at 5 V to external
devices.
The USB charging ports are for charging only. They are not designed for data
transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to the manual
included with the device before using a USB charging port.

INFORMATION

■

The USB charging ports can be used when

The power switch is in ACC or ON.

■

Situations in which the USB charging ports may not operate correctly

●

If a device which consumes more than 3.0 A at 5 V is connected.

●

If a device designed to communicate with a personal computer, such as a USB
memory device, is connected

●

If the connected external device is turned off (depending on device)

4-5. Using the interior features

306

●

If the temperature inside the vehicle is high, such as after the vehicle has been parked
in the sun

■

About connected external devices

Depending on the connected external device, charging may occasionally be suspended
and then start again. This is not a malfunction.

Use the USB charging port

▶

Instrument panel

▶

On the rear console

Open the lid.

Function and operation of the power outlet (12 VDC)

NOTICE

■

To prevent damage to the power outlet (12 VDC)

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

When the power outlets (12 VDC) are not in use, close the lids. If a foreign object or
liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the power outlets (12 VDC) ports.

4-5. Using the interior features

307

Interior feat

NOTICE

■

To prevent 12-volt battery discharge

Do not use the power outlets (12 VDC) for a long period of time with the hybrid system
stopped.

The power outlet can be used to supply power for devices which operate on 12
VDC at less than 10A (power consumption of 120 W).

When connecting multiple devices, make sure that the total power consumption of all the
connected devices is less than 120 W.

INFORMATION

■

The power outlet can be used when

The power switch is in ACC or ON.

■

When stopping the hybrid system

Disconnect electrical devices with charging functions, such as mobile battery packs.
If such devices are left connected, the hybrid system may not stop normally.

Using the accessory sockets (12 VDC)

▶

Instrument panel

Remove the cap.

▶

On the rear console

4-5. Using the interior features

308

Open the lid.

▶

In the luggage compartment

Open the lid.

Function and operation of the wireless charger

A portable device, such as a smartphone or mobile battery, can be charged by
just placing it on the charging area, provided the device is compatible with the Qi
wireless charging standard created by the Wireless Power Consortium.

WARNING

■

Caution while driving

When charging a portable device while driving, for safety reasons, the driver should not
operate the portable device.

■

Precautions for when driving

Do not charge small, lightweight portable devices, such as wireless earbuds, while driv-
ing. Lightweight devices may fly off of the charging tray, possibly leading to an accident.

■

Caution regarding interference with electronic devices

People with implantable cardiac pacemakers, cardiac resynchronization therapy pace-
makers or implantable cardioverter defibrillators, as well as any other electrical medical
device, should consult their physician about the usage of the wireless charger.
Operations of the wireless charger may have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.

●

Do not put any metallic objects between the charging area and the portable device
while charging.

●

Do not attach metallic objects, such as aluminum stickers, to the charging area.

●

Do not charge portable devices with aluminum stickers or other metallic objects
attached to the side which touches the charging area.

* :

If equipped

4-5. Using the interior features

309

Interior feat

WARNING

●

Do not store items on the wireless charger instead of in an auxiliary box.

●

Do not apply force or impact to the wireless charger.

●

Do not disassemble, modify or remove the wireless charger.

●

Do not attempt to charge portable devices which are not compatible with the Qi
wireless charging standard.

●

Do not allow magnetic objects to come near the wireless charge

●

Do not perform charging if the charging area is dirty

●

When not using the wireless charger, to prevent foreign matter or liquids from con-
tacting it, make sure to close the lid.

●

Do not cover the wireless charger with a cloth or other object while charging.

NOTICE

■

Preventing malfunction and corruption of data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording media, etc.,
close to the charger while charging, otherwise, data may be erased.
Additionally, do not bring precision instruments such as wrist watches, close to the
wireless charger, as such objects may malfunction.

●

Do not perform charging with a contactless smart card, such as a credit card, between
the charging surface of a portable device and the charging area. The IC chip in the
card may become extremely hot, possibly damaging the portable device or smart
card.Failure to do so may result in the possibility of fire, equipment failure or damage,
or burns due to heat.
Be extra careful to not charge a portable device with a case or cover which a
contactless smart card can be inserted.

●

Do not leave portable devices in the vehicle. The temperature inside the vehicle may
become high, when in direct sunlight, possibly damaging the device.

■

To prevent 12-volt battery discharge

When the hybrid system is stopped, do not use the wireless charger for longer than
necessary.

INFORMATION

■

The wireless charger can be operated when

The power switch is in ACC or ON.

■

About connected portable devices

4-5. Using the interior features

310

●

Portable devices compatible with the Qi wireless charging standard can be charged
by the wireless charger. However, compatibility with all devices which meet the Qi
wireless charging standard is not guaranteed.

●

The wireless charger is designed to supply low power electricity (5 W or less) to a
cellular phone, smartphone, or other portable device.

●

Failure to do so may result in the possibility of fire,However, portable devices, such as
the following, can be charged with more than 5 W.

•

7.5 W charging compatible iPhones can be charged at 7.5 W or less.

•

Portable devices which conform to WPC Ver 1.2.4

（

Extended Power profile

）

can be charged at 10 W or less.

■

Using the smart access system with push-button start

During charging, when the smart access system with push-button start searches for an
electronic key, charging may be temporarily suspended.

■

If a cover or accessory is attached to the portable device

Do not charge a portable device if a cover or accessory which is not Qi compatible is
attached.
Even if a device is “Qi” compatible, charging may not be possible if a cover or accessories
are attached. (

→

P.313

）

■

Charging precautions

While charging, the wireless charger and the portable device will become warm. This is
not a malfunction.
If a portable device becomes warm while charging and charging stops due to the
protection function of the portable device, wait until the portable device cools down and
charge it again.
Also, to decrease the temperature inside the wireless charger, a fan may operate. This
does not indicate a malfunction.

■

Sound generated during operation

Operation sounds may be heard when the power switch is pressed to change to ACC or
ON, or when a portable device is being detected. This does not indicate a malfunction.

■

“Qi” symbol

The “Qi” logo is a trademark of the Wireless Power Consortium.

4-5. Using the interior features

311

Interior feat

Names of the parts of the wireless charger

Operation indicator light

Charging area

Charging tray

Use the wireless charger

●

Place a portable device on the charging tray.

Depending on the portable device, its charging coil
may not be in the center of the device. In this case,
place the portable device so that its charging coil is
centered in the charging area.
While charging, the operation indicator light on the
charging tray (orange) will be illuminated.
If charging does not begin, move the portable de-
vice as close to the center of the charging area as possible.
When charging is complete, the operation indicator light on the charging tray (green)
will illuminate.

INFORMATION

■

AM radio broadcast linked function during charging

●

During charging, if noise occurs when listening to the AM radio, the charging
frequency is automatically changed to reduce the noise.

●

When automatically seeking AM radio stations, charging will be suspended to
prevent charging noise from being detected as a radio station. Charging will
resume automatically when seek tuning is stopped.

■

Recharging function

●

If a certain amount of time has elapsed since charging completed and the portable
device has not been moved, the wireless charger will restart charging.

●

If a portable device is moved significantly within the charging area, the charging coil
may disconnect and charging may temporarily be stopped. However, if a charging

4-5. Using the interior features

312

coil is detected within the charging area, the charging coil inside the wireless
charger will move near the other coil and charging will resume.

■

Rapid charging function

Portable devices, such as the following, can be rapidly charged.

●

Rapid charging capable devices which conform to WPC Ver1.2.4 EPP

（

Extended

Power profile)

●

7.5 W charging capable iPhones (iPhone 8 and later)

■

Situations in which the wireless charger may not operate correctly

In the following situations, the wireless charger may not operate correctly:

●

When a portable device is fully charged

●

When a portable device is being charged by a wired connection.

●

When there is foreign matter between the charging area and portable device

●

When the temperature of a portable device becomes high while charging

●

When the temperature near the charging tray is 95 °F (35 °C) or more due to
being in direct sunlight, etc.

●

When a portable device is placed with its charging surface facing up

●

When a portable device is not centered on the charging area

●

When a portable device is larger than the charging tray

●

When a foldable portable device is placed outside of the charging area

●

When the vehicle is near a TV tower, electric power plant, fuel station, radio station,
large display, airport, or other facility that generates strong radio waves or electrical
noise

●

When the any of the following objects are between or attached to a portable device
and cause a gap of 0.08 in. (2 mm) or more between the charging surface of a
portable device and the charging area:

•

Thick cases or covers

•

Thick decorations

•

Cases or covers which the charging surface is not flat, but is grooved or changes
in thickness

•

Accessories, such as finger rings, straps, etc.

●

When the portable device is in contact with, or is covered by any of the following
metallic objects:

•

Cards covered with metal, such as aluminum foil

•

Cigarette boxes that have aluminum foil inside

•

Metallic wallets or bags

4-5. Using the interior features

313

Interior feat

•

Coins

•

Heat packs

•

Recorded media such as CDs and DVDs

•

Metallic decorations

•

Metallic cases or covers

●

When wireless keys (that emit radio waves) other than those of your vehicle are
being used nearby

●

When 2 or more portable devices are placed on the charging tray at the same time

In situations other than above, if the wireless charger does not operate properly
or the operation indicator light blinks continuously, the wireless charger may be
malfunctioning.
Contact your Lexus dealer.

Wireless charger operation indicator light status

The operation indicator light of the wireless charger indicates the operating state
of the wireless charger as follows:

Operation indicator light

State

Charging tray

Center dis-

play

Off

The Wireless charger is off

Green (illumi-

nated)

Gray

Standby (charging is possible)

(1)

Charging is complete

(2)

Orange (illu-

minated)

Blue

A portable device has been placed on the charging area
(identifying the portable device)

A portable device, such as the following, is being rapidly
charged

●

Rapid charging capable devices which conform to
WPC Ver 1.2.4.

●

7.5 W charging capable iPhone (iPhone 8 and later)

(1)

While in standby, charging power is not output. If a metal object is placed on the

charging tray in this state, the object will not heat up.

(2)

Depending on the portable device, the operation indicator light may stay illuminated

(orange) after charging has completed.

4-5. Using the interior features

314

Content .. 16 17 18 19 ..
