Lexus NX450H+ (2022 year). Manual in english

Vehicle load limits

Vehicle load limits include total load capacity, seating capacity, towing capacity and
cargo capacity.

Vehicle load limit terminology and definitions

WARNING

Do not overload the vehicle. It may not only cause damage to the tires, but also degrade
steering and braking ability, resulting in an accident.

■

Total load capacity (vehicle capacity weight)

Total load capacity means the combined weight of occupants, cargo and luggage.

■

Seating capacity

Seating capacity means the maximum number of occupants whose estimated
average weight is 150 lb. (68 kg) per person.

■

TWR (Trailer Weight Rating) (vehicles with towing package)

TWR means the maximum gross trailer weight (trailer weight plus its cargo weight)
that your vehicle is able to tow.

■

TWR (Trailer Weight Rating) (vehicles without towing package)

Lexus does not recommend towing a trailer with your vehicle.

■

Cargo capacity

Cargo capacity may increase or decrease depending on the weight and the
number of occupants.

INFORMATION

■

Total load capacity and seating capacity

These details are also described on the tire and loading information label.

1-4. Vehicle load limits

Preparations for safe driving with children in the vehicle

Riding with children

If a child which is not large enough to correctly wear a seat belt intended for adults
is to ride in the vehicle, use a child restraint system. Child restraint systems are
designed to keep children safe.
To ensure safety, observe the following when children are in the vehicle.

●

Make sure that children always wear a seat belt.
If a child is not wearing a seat belt, in a collision, they may collide with a window,
other passenger, or the interior of the vehicle. Also, if a child is riding on the
lap of another passenger, in a collision, they may collide with a window, other
passenger, or the interior of the vehicle.

●

Seat children in the rear seats.
It is recommended that children sit in the rear seats to avoid accidental contact
with the driver's controls.

●

Do not allow children to operate equipment such as the doors, windows, etc.
Do not let children operate equipment such as the doors, power windows, seats,
etc. as a part of their body may become pinched.
To prevent children from opening and closing the doors and power windows, use
the child-protector locks and window lock switch.

WARNING

●

Never leave children unattended in the vehicle, and never allow children to have or
use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.

●

Do not leave children unattended in the vehicle.
Children may accidentally cause the vehicle to move, leading to an accident, or start a
fire.

●

Do not leave people or animals in the vehicle.
The temperature inside the vehicle can become extremely high during the daytime,
possibly leading to heat stroke or death.

●

Do not allow children to ride on the lap of a passenger.
If a child is riding on the lap of another passenger, in a collision, they may collide with a
window, another passenger, or the interior of the vehicle. Make sure that children wear
a seat belt or use a child restraint system.

●

Use a child restraint system for small children.

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

WARNING

If a child which is not large enough to correctly wear a seat belt is to ride in the vehicle,
use a child restraint system.

●

Use child restraint systems correctly.
Child restraint systems are designed to protect children in a collision or sudden stop.
Make sure to securely install child restraint systems and use them correctly.

●

Replace child restraint systems which have been involved in a collision.
If the vehicle has been involved in a collision, it is possible that an installed child
restraint system has been damaged and will not be able to deliver the same level of
impact absorption performance, even if the outside of it looks normal.

●

When a child restraint system is not in use, secure it so that it does not interfere with
driving.
When removing a child restraint system, store it outside of the vehicle or securely in
the luggage compartment.

Seating positions for children

It is recommended that children sit in the rear seats to avoid accidental contact
with the driver’s controls. In the event of an accident, the force of deployment of the
SRS front passenger airbag can cause death or serious injury to a child seated on
the front passenger’s seat. Do not allow a child to ride on the front passenger’s seat
unless it is unavoidable.

WARNING

●

When installing a child restraint system to the front passenger’s seat is unavoidable,
move the seat as far back as possible, and install the child restraint system so that it
faces forward. If the child restraint system is not installed correctly, in the event of an
accident, the force of deployment of the SRS front passenger airbag can cause death
or serious injury.

●

Never install a rear-facing child restraint system on the front passenger seat even if the
"AIR BAG OFF" indicator light is illuminated. In the event of an accident, the force of
the rapid inflation of the front passenger airbag can cause death or serious injury to
the child if the rear-facing child restraint system is installed on the front passenger seat.

●

A forward-facing child restraint system may be installed on the front passenger seat
only when it is unavoidable. A child restraint system that requires a top tether strap
should not be used in the front passenger seat since there is no top tether strap anchor
for the front passenger seat.

●

A forward-facing child restraint system may be installed on the front passenger seat
only when it is unavoidable. When installing a forward-facing child restraint system on

1-5. Preparations for safe driving with children in the vehicle

WARNING

the front passenger seat, move the seat as far back as possible, and raise the seat to
the upper most position, even if the "AIR BAG OFF" indicator light is illuminated. If
the head restraint interferes with the child restraint system installation and the head
restraint can be removed, remove the head restraint.

●

Do not allow children to lean against the doors, roof side rails, or pillars. In the event
of an accident, the force of deployment of an SRS airbag can cause death or serious
injury to a child.

●

When adjusting the driver’s seat, if it contacts a child or child restraint system, install
the child restraint system to the rear seat behind the front passenger’s seat.

●

Adjust the front passenger seat so that it does not interfere with the child or child
restraint system.

●

If a child which is over 100 cm tall is to ride in the vehicle, use a booster seat. When
using a booster seat, make sure that the seat belt is worn correctly.

Preventing the rear doors from being opened from the inside of the
vehicle (child-protector lock)

The door cannot be opened from inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children from
opening the rear doors. Push down on each
rear door switch to lock both rear doors.

INFORMATION

■

Door opening method when using a child-protector lock

Unlock the door and pull the exterior door handle to open the door. If it is necessary to
open the door from inside the vehicle, open the rear door window and pull the exterior
door handle.

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

Child restraint system

Points to remember

The laws of all 50 states of the U.S.A. as well as Canada now require the use of
child restraint systems.

●

Prioritize and observe the warnings, as well as the laws and regulations for child
restraint systems.

●

Use a child restraint system until the child becomes large enough to properly
wear the vehicle’s seat belt.

●

Choose a child restraint system that suits your vehicle and is appropriate to the
age and size of the child.

WARNING

■

When a child is riding

Observe the following precautions. Failure to do so may result in death or serious injury.

●

For effective protection in automobile accidents and sudden stops, a child must be
properly restrained, using a seat belt or child restraint system which is correctly
installed. For installation details, refer to the operation manual enclosed with the child
restraint system. General installation instruction is provided in this manual.

●

Lexus strongly urges the use of a proper child restraint system that conforms to the
weight and size of the child, installed on the rear seat. According to accident statistics,
the child is safer when properly restrained in the rear seat than in the front seat.

●

Holding a child in your or someone else’s arms is not a substitute for a child restraint
system. In an accident, the child can be crushed against the windshield or between the
holder and the interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not properly fixed in place, the child or other passengers
may be seriously injured or even killed in the event of sudden braking, sudden swerving,
or an accident.

●

If the vehicle were to receive a strong impact from an accident, etc., it is possible that
the child restraint system has damage that is not readily visible. In such cases, do not
reuse the restraint system.

●

For Puerto Rico: Depending on the child restraint system, installation may be difficult
or impossible. In those cases, check whether the child restraint system is suitable for
installment in the vehicle. Be sure to install and observe the usage rules after carefully
reading the child restraint system fixing method in this manual, as well as the operation
manual enclosed with the child restraint system.

1-5. Preparations for safe driving with children in the vehicle

WARNING

●

Except for Puerto Rico: Make sure you have complied with all installation instructions
provided with the child restraint system manufacturer and that the system is properly
secured.

●

Keep the child restraint system properly secured on the seat even if it is not in use. Do
not store the child restraint system unsecured in the passenger compartment.

●

If it is necessary to detach the child restraint system, remove it from the vehicle.

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

Child restraint system installation method

Child restraint system fixed with a child restraint LATCH anchor

WARNING

■

When installing a child restraint system

Observe the following precautions. Failure to do so may result in death or serious injury.

●

When using LATCH anchors, make sure that the area around the anchors is free of
objects and that the seat belt will not be caught behind the child restraint system.

●

Follow all installation instructions provided by the child restraint system manufacturer.

●

Never attach two child restraint system attachments to the same anchor. In a collision,
one anchor may not be strong enough to hold two child restraint system attachments
and may break. If the LATCH anchors are already in use, use the seat belt to install a
child restraint system in the center seat.

●

When securing some types of child restraint systems in rear seats, it may not be
possible to properly use the seat belts in positions next to the child restraint without
interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly
across your shoulder and low on your hips. If it does not, or if it interferes with the child
restraint, move to a different position. Failure to do so may result in death or serious
injury.

●

If the seat is adjusted, reconfirm the security of the child restraint system.

Laws and regulations pertaining to anchors

The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifications
can be used.
This vehicle is designed to conform to SAE J1819.

With rigid lower attachments

LATCH anchors are provided for the each rear seat. (Buttons displaying the
location of the anchors are attached to the seats.)

1-5. Preparations for safe driving with children in the vehicle

LATCH anchor

Canada only

Latch the buckles onto the LATCH anchors.

●

For owners in Canada:
The symbol on a child restraint system indicates the presence of a lower connector
system.

If the child restraint has a top tether strap, follow the child restraint manufactur-
er’s operation manual regarding the installation, using the top tether strap to
latch onto the top tether strap anchor.

After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.

With flexible lower attachments

LATCH anchors are provided for the each rear seat. (Buttons displaying the
location of the anchors are attached to the seats.)

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

LATCH anchor

Canada only

Latch the buckles onto the LATCH anchors.

●

For owners in Canada:
The symbol on a child restraint system indicates the presence of a lower connector
system.

After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.

When installing in the rear center seat

There are no LATCH anchors behind the rear center seat.
However, the inboard LATCH anchors of the outboard seats, which are 15.7
in. (400 mm) apart, can be used if the child restraint system manufacturer's
instructions permit use of those anchors with the anchor spacing stated.
Child restraint systems with rigid lower attachments cannot be installed in the
center seat. This type of child restraint system can only be installed in the outboard
seat.

1-5. Preparations for safe driving with children in the vehicle

Using an anchor bracket (for top tether strap)

WARNING

■

When installing a child restraint system

Observe the following precautions. Failure to do so may result in death or serious injury.

●

Firmly attach the top tether strap and make sure that the belt is not twisted.

●

Do not attach the top tether strap to anything other than the anchor bracket.

●

After securing a child restraint system, never adjust the seat.

●

Follow all installation instructions provided by the child restraint system manufacturer.

●

Outboard rear seats: When installing the child restraint system with the head restraint
being raised, after the head restraint has been raised and then the anchor bracket has
been fixed, do not lower the head restraint.

●

Rear center seat: When installing the child restraint system with the head restraint
being lowered, be sure to have the top tether strap pass over the top of the head
restraint. If the belt passes below the head restraint, it is possible that the child restraint
system may not be securely fixed.

Laws and regulations pertaining to anchors

The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifications
can be used.
This vehicle is designed to conform to SAE J1819.

Fixing the top tether strap to the anchor bracket

Anchor brackets are provided for each rear seat.
Use anchor brackets when fixing the top tether strap.
Install the child restraint system in accordance to the operation manual enclosed
with the child restraint system.
Latch the hook onto the anchor bracket and tighten the top tether strap.
Make sure the top tether strap is securely latched.

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

Anchor brackets

Top tether strap

Hook

Child restraint system fixed with a seat belt

WARNING

■

When installing a child restraint system

Observe the following precautions. Failure to do so may result in death or serious injury.

●

Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.

●

Ensure that the belt and plate are securely locked and the seat belt is not twisted.

●

Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.

●

After securing a child restraint system, never adjust the seat.

●

Follow all installation instructions provided by the child restraint system manufacturer.

●

When installing a child restraint system in the rear center seat, adjust both seatbacks
at the same angle. Otherwise, the child restraint system cannot be securely restrained
and this may cause death or serious injuries in the event of sudden braking, sudden
swerving or an accident.

■

Do not use a seat belt extender

If a seat belt extender is used when installing a child restraint system, the seat belt will
not securely hold the child restraint system, which could cause death or serious injury
to the child or other passengers in the event of sudden braking, sudden swerving or an
accident.

1-5. Preparations for safe driving with children in the vehicle

Installing child restraint system using a seat belt (child restraint lock function
belt)

A child restraint system for a small child or baby must itself be properly restrained
on the seat with the lap portion of the lap/shoulder belt.
Install the child restraint system in accordance to the operation manual enclosed
with the child restraint system.

Rear-facing - Infant seat/convertible

Adjust the rear seat

If there is a gap between the child seat and the seatback, adjust the seatback until good
contact is achieved.

Place the child restraint system on the rear
seat facing the rear of the vehicle.

Run the seat belt through the child restraint
system and insert the plate into the buckle.
Make sure that the belt is not twisted.

Fully extend the shoulder belt and allow it to
retract to put it in lock mode. In lock mode,
the belt cannot be extended.

1-5. Preparations for safe driving with children in the vehicle

Befor

e driving

While pushing the child restraint system
down into the rear seat, allow the shoulder
belt to retract until the child restraint system is
securely in place.

After the shoulder belt has retracted to a point
where there is no slack in the belt, pull the belt to
check that it cannot be extended.

After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.

Forward-facing - Convertible

Adjust the seat

●

When using the front passenger seat
If installing the child restraint system to the front passenger seat is unavoidable, refer
to

→

P.103

●

When using the rear seat
If there is a gap between the child seat and the seatback, adjust the seatback angle
until good contact is achieved.

If the head restraint interferes with the child restraint system installation and the
head restraint can be removed, remove the head restraint. Otherwise, put the
head restraint in the upper most position.

Place the child restraint system on the seat
facing the front of the vehicle.

Run the seat belt through the child restraint
system and insert the plate into the buckle.
Make sure that the belt is not twisted.

1-5. Preparations for safe driving with children in the vehicle

100

Fully extend the shoulder belt and allow it to
retract to put it in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child restraint system into
the rear seat, allow the shoulder belt to re-
tract until the child restraint system is securely
in place.

After the shoulder belt has retracted to a point
where there is no slack in the belt, pull the belt to
check that it cannot be extended.

After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.

Booster seat

If installing the child restraint system to the front passenger seat is unavoidable,
refer to

→

P.103

High back type: If the head restraint interferes with your child restraint system,
and the head restraint can be removed, remove the head restraint. Otherwise,
put the head restraint in the upper most position.

Place the child restraint system on the seat facing the front of the vehicle.

Booster type

1-5. Preparations for safe driving with children in the vehicle

101

Befor

e driving

High back type

Sit the child in the child restraint system. Fit
the seat belt to the child restraint system
according to the manufacturer’s instructions
and insert the plate into the buckle. Make
sure that the belt is not twisted.

Check that the shoulder belt is correctly posi-
tioned over the child’s shoulder and that the lap
belt is as low as possible.

WARNING

■

When installing a child restraint system

Observe the following precautions. Failure to do so may result in death or serious
injury.
When a booster seat is installed, always ensure that the shoulder belt is positioned
across the center of the child’s shoulder. The belt should be kept away from the child’s
neck, but not so that it could fall off the child’s shoulder.

■

When installing a booster seat

To prevent the belt from going into ALR lock mode, do not fully extend the shoulder
belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort
to the child.

Removing a child restraint system

●

Press the buckle release button and fully re-
tract the seat belt.

When releasing the buckle, the child restraint sys-
tem may spring up due to the rebound of the seat
cushion. Release the buckle while holding down the
child restraint system.
Since the seat belt automatically reels itself, slowly
return it to the stowing position.

1-5. Preparations for safe driving with children in the vehicle

102

Installing a child restraint system to the front passenger's seat

Do not install a child restraint system to the front passenger's seat unless it is
unavoidable. In the event of an accident, the force of deployment of an SRS airbag
can cause death or serious injury to a child.
If installation of a child restraint system to the front passenger's seat is unavoidable,
adjust the front passenger's seat as follows:

●

Move the seat to the rearmost position

●

Move the seat to the uppermost position

●

Adjust the seatback angle to the most upright position.
Adjust the seatback angle of the front passenger's seat until good contact is
achieved.

●

Remove the head restraint
If the head restraint cannot be removed, move it to the uppermost position.

WARNING

●

When installing a child restraint system to the front passenger's seat, move the seat as
far back as possible. In the event of an accident, the force of deployment of an SRS
airbag can cause death or serious injury to a child.

●

Make sure that the child's body will not contact the doors, roof side rails, or pillars. In
the event of an accident, the force of deployment of an SRS airbag can cause death or
serious injury to a child.

●

When using a booster seat, make sure that the seat belt is worn correctly.

●

Choose a child restraint system appropriate to the age and size of the child.

Installing a child restraint system to the front passenger's seat

●

Make sure to appropriately adjust the front passenger's seat before installing the
child restraint system.

Install the child restraint system according to the user's manual included with it.

1-5. Preparations for safe driving with children in the vehicle

103

Befor

e driving

Lexus NX450H+ (2022 year). Manual in english - page 5
