121

3-3. Adjusting the seats

3

Be

fore
 dri
ving

3

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

■

Operating the driving position memory

after turning the engine switch off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact your Lexus dealer.

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to regis-
ter, and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

1

Check that the shift lever is in P.

2

Turn the engine switch to ON.

3

Recall the driving position that you
want to record.

4

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Cancelation procedure

1

Carry only the key you want to can-
cel and then close the driver’s door.

If 2 or more keys are in the vehicle, the

driving position cannot be canceled prop-

Registering/canceling/recall-
ing a driving position to an elec-
tronic key (including a card key)
(memory recall function)

122

3-3. Adjusting the seats

erly.

2

Turn the engine switch to ON.

3

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If it could not be canceled, the buzzer

sounds continuously for approximately 3

seconds.

■

Recall procedure

1

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display [if

equipped]). However, the seat will move to

a position slightly behind the recorded

position in order to make entering the

vehicle easier.

If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

2

Turn the engine switch to ACC or
ON, or fasten a seat belt.

The seat, steering wheel and head-up dis-

play (if equipped) will move to the

recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If a door other than the driver’s door is

unlocked with the smart access system

with push-button start, the driving posi-

tion cannot be recalled. In this case, press

the driving position button which has

been set.

■

Customization

The unlock door settings of the memory

recall function can be customized. (Cus-

tomizable features:



P.409)

123

3-3. Adjusting the seats

3

Be

fore
 dri
ving

■

Front seats

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while press-
ing the lock release button

.

■

Center rear seat

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while press-
ing the lock release button

.

■

Outboard rear seats

1

To fold

Pull up the head restraint while pressing
the lock release button

.

2

To use

Lift up and push down the head restraint to
the lowest lock position.

■

Adjusting the height of the head

restraints (front seats)

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

Head restraints

Head restraints are provided for all
seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints.

Failure to do so may result in death or

serious injury.

●

Use the head restraints designed for

each respective seat.

●

Adjust the head restraints to the cor-

rect position at all times.

●

After adjusting the head restraints,

push down on them and make sure

they are locked in position.

●

Do not drive with the head restraints

removed.

Vertical adjustment

A

A

A

124

3-3. Adjusting the seats

■

Adjusting the center rear seat head

restraint

Always raise the head restraint one level

from the stowed position when using.

The position of the head restraint for
the front seat can be adjusted forward
in 4 stages.

If the head restraint is pulled forward from
the foremost position, it will return to the
rearmost position.



Front and center rear seats

Pull the head restraint up while press-
ing the lock release button

.

If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. (



P.117)



Outboard rear seats

Pull the head restraint up while press-
ing the lock release buttons

.

If the head restraint touches the ceiling,
making the removal difficult, change
the seat angle. (



P.118)



Front and center rear seats

Align the head restraint with the instal-
lation holes and push it down to the
lock position.
Press and hold the lock release button

 when lowering the head restraint.

Horizontal adjustment (if
equipped)

Removing the head restraints

A

Installing the head restraints

A

A

125

3-3. Adjusting the seats

3

Be

fore
 dri
ving



Outboard rear seats

Align the head restraint with the instal-
lation holes and push it down to the
lowest lock position.

126

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors



Manual type

1

Hold the steering wheel and push
the lever down.

2

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.



Power type

Operating the switch moves the steer-
ing wheel in the following directions:

1

Up

2

Down

3

Toward the driver

4

Away from the driver

■

The steering wheel can be adjusted

when (power type)

The engine switch is in ACC or ON

*

.

*

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of engine switch mode.

■

Automatic adjustment of the steering

position (if equipped)

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.120)

■

Power easy access system (if equipped)

The steering wheel and driver’s seat move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.119)

■

After adjusting the steering wheel

(manual type)

Make sure that the steering wheel is

securely locked.

The horn may not sound if the steering

wheel is not securely locked.

Steering wheel

Adjustment procedure

127

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

Press on or close to the

 mark.

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.



Manual anti-glare inside rear view
mirror

Reflected light from the headlights of
vehicles behind can be reduced by
operating the lever.

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

■

After adjusting the steering wheel

(manual type)

Make sure that the steering wheel is

securely locked.

Otherwise, the steering wheel may move

suddenly, possibly causing an accident,

and resulting in death or serious injury.

Sounding the horn

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

128

3-4. Adjusting the steering wheel and mirrors

Normal position

Anti-glare position



Auto anti-glare inside rear view mir-
ror

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function
mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

 illuminates.

The function will set to ON mode each
time the engine switch is turned to ON.
Pressing the button turns the function to
OFF mode. (The indicator

 also turns

off.)

■

To prevent sensor error (vehicles with

auto anti-glare inside rear view mirror)

To ensure that the sensors operate prop-

erly, do not touch or cover them.

A
B

A

A

129

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

1

To select a mirror to adjust, press
the switch.

Left

Right

2

To adjust the mirror, press the
switch.

Up

Left

Down

Right

■

Mirror angle can be adjusted when

The engine switch is in ACC or ON.

■

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.260)

■

Auto anti-glare function (if equipped)

When the anti-glare inside rear view mirror

is set to automatic mode, the driver’s side

outside rear view mirror will activate in con-

junction with the anti-glare inside rear view

mirror to reduce reflected light. (



P.127)

■

Automatic adjustment of the mirror

angle (vehicles with driving position

memory)

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.119)

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

■

Important points while driving

Observe the following precautions while

driving.

Failing to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A

B

A

B

C

D

130

3-4. Adjusting the steering wheel and mirrors



Manual type

Push the mirror back in the direction of the
vehicle’s rear.



Power type

1

Fold

2

Extend

Putting the outside rear view mirror folding
switch in the neutral position sets the mir-
rors to automatic mode. Automatic mode
allows the folding or extending of the mir-
rors to be linked to locking/unlocking of
the doors.

■

Using automatic mode in cold weather

(power type)

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this event, after removing

any ice and snow from the door mirror,

operate the mirror using manual mode or

move it by hand.

■

Customization

The automatic mirror folding and extending

operation can be changed. (Customizable

features:



P.409)

When the mirror select switch is in the
“L” or “R” position, the outside rear
view mirrors will automatically angle
downwards when the vehicle is revers-
ing in order to give a better view of the
ground.
To disable this function, move the mir-
ror select switch to the neutral position
(between “L” and “R”)

■

Adjusting the mirror angle when
the vehicle is reversing

With the shift lever in R, adjust the mir-
ror angle at a desired position.
The adjusted angle will be memorized
and the mirror will automatically tilt to
the memorized angle whenever the
shift lever is shifted to R from next time.

WARNING

■

When the mirror defoggers are oper-

ating

Do not touch the rear view mirror sur-

faces, as they can become very hot and

burn you.

Folding and extending the mir-
rors

WARNING

■

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

Linked mirror function when
reversing (vehicles with driving
position memory)

131

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

The memorized downward tilt position of
the mirror is linked to the normal position
(angle adjusted with the shift lever in other
than R). Therefore, if the normal position is
changed after adjustment, the tilt position
will also change.
When the normal position is changed,
readjust the angle in reversing.

132

3-5. Opening, closing the windows and moon roof

3-5.Opening, closing the windows and moon roof

The power windows can be opened
and closed using the switches.

1

Closing

2

One-touch closing

*

3

Opening

4

One-touch opening

*

*

: To stop the window partway, operate

the switch in the opposite direction.

■

The power windows can be operated

when

The engine switch is in ON.

■

Operating the power windows after

turning the engine off

The power windows can be operated for

approximately 45 seconds even after the

engine switch is turned to ACC or OFF.

They cannot, however, be operated once

either front door is opened.

■

Jam protection function

If an object becomes jammed between the

window and the window frame while the

window is closing, window movement is

stopped and the window is opened slightly.

■

Catch protection function

If an object becomes caught between the

door and window while the window is open-

ing, window movement is stopped.

■

When the window cannot be opened or

closed

When the jam protection function or catch

protection function operates unusually and

the side window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

●

Stop the vehicle. With the engine switch

in ON, within 4 seconds of the jam pro-

tection function or catch protection func-

tion activating, continuously operate the

power window switch in the one-touch

closing direction or one-touch opening

direction so that the side window can be

opened and closed.

●

If the side window cannot be opened and

closed even when performing the above

operations, perform the following proce-

dure for function initialization.

1

Turn the engine switch to ON.

2

Pull and hold the power window switch

in the one-touch closing direction and

completely close the side window.

3

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

4

Press and hold the power window

switch in the one-touch opening direc-

tion. After the side window is com-

pletely opened, continue holding the

switch for an additional 1 second or

more.

5

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

6

Pull and hold the power window switch

in the one-touch closing direction

again. After the side window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

closed or opened, have the vehicle

inspected by your Lexus dealer.

Power windows

Opening and closing the power
windows

133

3-5. Opening, closing the windows and moon roof

3

Be

fore
 dri
ving

■

Door lock linked window operation

●

The power windows can be opened and
closed using the mechanical key.

*



(



P.377)

●

The power windows can be opened using
the wireless remote control.

*

 (



P.96)

*

: These settings must be customized at

your Lexus dealer.

■

Power windows open warning buzzer

The buzzer sounds and “Window Open” is

shown on the multi-information display in

the instrument cluster when the engine

switch is turned off and the driver’s door is

opened with the power windows open.

■

Customization

Setting (e.g. linked door lock operation)

can be changed.

(Customizable features:



P.409)

This function is designed to prevent
children from accidentally opening or
closing a passenger window.
Press the switch.

WARNING

Observe the following precautions.

Failing to do so may result in death or

serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.133)

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

●

When exiting the vehicle, turn the

engine switch off, carry the key and

exit the vehicle along with the child.

There may be accidental operation,

due to mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

●

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental opera-
tion (window lock switch)

134

3-5. Opening, closing the windows and moon roof

The indicator

 will come on and the

passenger window will be locked.

■

The power windows can be operated

when

The engine switch is in ON.

■

When the battery is disconnected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the battery.

*

: If equipped

■

Opening and closing

1

Opens the moon roof

*

The moon roof tilts up and then fully opens.

2

Closes the moon roof

*

*

: Lightly press either side of the moon roof

switch to stop the moon roof partway.

■

Tilting up and down

1

Tilt the moon roof up

*

2

Tilt the moon roof down

*

*

: Lightly press either side of the moon roof

switch to stop the moon roof partway.

A

Moon roof

*

Use the overhead switches to open
and close the moon roof and tilt it
up and down.

Operating the moon roof

135

3-5. Opening, closing the windows and moon roof

3

Be

fore
 dri
ving

■

The moon roof can be operated when

The engine switch is in ON.

■

Operating the moon roof after turning

the engine off

The moon roof can be operated for approx-

imately 45 seconds after the engine switch

is turned to ACC or OFF. It cannot, how-

ever, be operated once either front door is

opened.

■

Jam protection function

If an object is detected between the moon

roof and the frame while the moon roof is

closing or tilting down, travel is stopped and

the moon roof opens slightly.

■

Sunshade

The sunshade can be opened and closed

manually. However, the sunshade will open

automatically when the moon roof is

opened.

■

Door lock linked moon roof operation

●

The moon roof can be opened and
closed using the mechanical key.

*



(



P.377)

●

The moon roof can be opened using the
wireless remote control.

*

 (



P.96)

*

: These settings must be customized at

your Lexus dealer.

■

When the moon roof does not close nor-

mally

Perform the following procedure:

1

Stop the vehicle.

2

Press and hold the “CLOSE” switch.

*

The moon roof will close, reopen and pause

for approximately 10 seconds. Then it will

close again and stop at the completely

closed position.

3

Check to make sure that the moon roof

is completely closed and then release

the switch.

*

: If the switch is released at the incorrect

time, the procedure will have to be per-
formed again from the beginning.

If the moon roof does not fully close even

after performing the above procedure cor-

rectly, have the vehicle inspected by your

Lexus dealer.

■

If the moon roof does not move normally

If the moon roof does not open or close

normally or the automatic opening function

does not operate, perform the following ini-

tialization procedure.

1

Stop the vehicle.

2

Press and hold the “DOWN” switch.

*

The moon roof will stop at the tilt-up posi-

tion. After that, it will open, close, tilt up, tilt

down, and stop at the fully closed position.

3

Confirm that the moon roof has com-

pletely stopped and release the switch.

*

: If you release the switch while the moon

roof is moving, perform the procedure
again from the beginning.

If, after performing the above procedures

correctly, the moon roof still does not open

or close normally or the automatic opening

function does not operate, have the vehicle

inspected by your Lexus dealer.

■

Moon roof open warning buzzer

The buzzer sounds and “Moon Roof Open”

is shown on the multi-information display in

the instrument cluster when the engine

switch is turned off and the driver’s door is

opened with the moon roof open.

■

Customization

Some functions can be customized.

(



P.409)

WARNING

Observe the following precautions.
Failure to do so may cause death or seri-

ous injury.

■

Opening the moon roof

●

Do not allow any passengers to put

their hands or heads outside the vehi-

cle while it is moving.

●

Do not sit on top of the moon roof.

136

3-5. Opening, closing the windows and moon roof

WARNING

■

Opening and closing the moon roof

●

The driver is responsible for moon roof

opening and closing operations.

In order to prevent accidental opera-

tion, especially by a child, do not let a

child operate the moon roof. It is possi-

ble for children and other passengers

to have body parts caught in the moon

roof.

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the moon roof is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the moon roof, operate the moon roof

after checking to make sure that there

is no possibility of any passenger hav-

ing any of their body parts caught in

the moon roof. Also, do not let a child

operate moon roof by the wireless

remote control or mechanical key. It is

possible for children and other pas-

sengers to get caught in the moon

roof.

●

When exiting the vehicle, turn the

engine switch off, carry the key and

exit the vehicle along with the child.

There may be accidental operation,

due to mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the moon roof is fully closed.

Also, the jam protection function is not

designed to operate while the moon

roof switch is being pressed. Take care

so that your fingers, etc. do not get

caught.
