3-2. Opening, closing and locking the doors

fore
dri
ving

27.6 in. (50 to 70 cm) from the
rear bumper.

Kick sensor

Hands Free Power Back Door
operation detection area

Smart access system with push-
button start operation detection
area (



P.113)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling it back.

• Perform the entire kick operation

within 1 second.

• The Hands Free Power Back Door

will not start operating while a foot is
detected under the rear bumper.

• Operate the Hands Free Power

Back Door without contacting the
rear bumper with your foot.

• If another electronic key is in the

cabin or luggage compartment, it
may take slightly longer than normal

for the operation to occur.

Kick sensor

Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the back door will
automatically fully open/close.

If a foot is moved under the rear bumper

while the back door is operating, the back

door will stop moving.

■

Luggage compartment light

●

The luggage compartment light turns on

when the back door is opened.

●

If the luggage compartment light is left on

when the engine switch is turned off, the

light will go off automatically after 20

minutes.

■

Power back door operating conditions

With the power back door operations set to

ON, it can automatically open and close for

the following conditions:

●

The power back door is unlocked. How-

ever, the power back door will operate if

it is locked, in the following situations:

• When the electronic key is being carried

and the power back door opener switch

is pressed

• When the wireless remote control is

used

●

When the engine switch is in ON, in addi-

tion to the above for the opening opera-

tions, the back door operates for any of

A
B

106

3-2. Opening, closing and locking the doors

the following conditions:

• Parking brake is engaged

• The brake pedal is depressed

• The shift lever is in P

: When configured with the customization

function so that it can be operated after
being unlocked, operate the back door
after it has been unlocked.

■

Hands Free Power Back Door operat-

ing conditions

●

When the Hands Free Power Back Door

operation setting is turned on

●

When an electronic key is carried within

the operation range

■

Back door closer

In the event that the back door is left slightly

open, the back door closer will automati-

cally close it to the fully closed position.

Whatever the state of the engine switch, the

back door closer operates.

■

Operation of the power back door

●

A buzzer sounds and the emergency

flashers flash twice to indicate that the

back door is opening/closing.

●

When the power back door operations

are OFF, the power back door does not

operate but it can be opened and closed

by hand.

●

When the power back door automati-

cally opens, if an abnormality due to peo-

ple or objects is detected, operation will

stop.

■

Back door reserve lock function

This function reserves locking of all doors

beforehand, when the power back door is

open.
When the following procedure is per-

formed, all the doors except the power

back door are locked and then power back

door will also be locked at the same time it

is closed.

Close all doors, except the back door.

During the power back door closing

operation, lock the doors using the

smart access system with push-button

start (



P.96) or the wireless remote

control. (



P.94)

A buzzer sounds and the emergency flash-

ers flash to indicate that all the doors have

been closed and locked.
Before leaving the vehicle, make sure that

all the doors are closed and locked. The

doors may not be locked due to the jam

protection function or door lock prevention

function.

■

Close & lock function

When the power back door is open, this

function closes the power back door and

then locks all of the doors simultaneously.
When the following procedures are per-

formed and there are no electronic keys for

the vehicle within the vehicle, all of the

doors will lock when the power back door is

completely closed.

Close all of the doors except the power

back door.

While carrying an electronic key, press
the

switch on the lower part of

the power back door (



P.103).

A different buzzer than the normal one will

sound and then the power back door will

begin closing automatically. When the

power back door is closed, all of the doors

will lock simultaneously and operation sig-

nals will indicate that all of the doors have

been locked.

■

Situations in which the close & lock

function may not operate properly

In the following situations, the close & lock

function may not operate properly:

●

If the

switch on the lower part of

the power back door (



P.103) is

pressed by a hand which is holding an

electronic key

●

If the

switch on the lower part of

the power back door (



P.103) is

pressed when the electronic key is in a

bag, etc. that is placed on the ground

●

If the

switch on the lower part of

the power back door (



P.103) is

pressed with the electronic key not near

the vehicle

107

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Situations in which the Hands Free

Power Back Door may not operate

properly

In the following situations, the Hands Free

Power Back Door may not operate prop-

erly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Back Door again.

●

When operated while a person is too

close to the rear bumper

●

When an external radio wave source

interferes with the communication

between the electronic key and the vehi-

cle (



P.114)

●

When the vehicle is parked near an elec-

trical noise source or a metallic object

which affects the sensitivity of the Hands

Free Power Back Door, such as a pay

parking spot, gas station, electrically

heated road, fluorescent light or iron

plate

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn

the Hands Free Power Back Door opera-

tion setting off.

■

Preventing unintentional operation of

the Hands Free Power Back Door

When an electronic key is in the operation

range, the Hands Free Power Back Door

may operate unintentionally, so be careful

in the following situations.

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Back

Door, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the
Hands Free Power Back Door operation
setting off.

■

When reconnecting the battery

To enable the power back door to operate

properly, close the back door manually.

■

Jam protection function

Sensors are installed in the right and left

sides of the power back door. When the

door is automatically closing and the sen-

sors are pushed due to an object being

clamped, etc., the jam protection function

108

3-2. Opening, closing and locking the doors

operates.
From that position the door automatically
moves a little in the opposite direction and
then the function stops.

■

If the back door opener is inoperative

The back door can be unlocked from the

inside.

Remove the cover.

To protect the cover, place a rag between

the flathead screwdriver and the cover as

shown in the illustration.

Move the lever.

■

Customization

Some functions can be customized. (Cus-

tomizable features:



P.408)

WARNING

■

Back door closer

●

In the event that the back door is left

slightly open, the back door closer will

automatically close it to the fully closed

position. It takes several seconds

before the back door closer begins to

operate. Be careful not to catch fingers

or anything else in the back door, as

this may cause bone fractures or other

serious injuries.

●

Be careful not to catch fingers or any-

thing else when using the back door

closer as it still operates when the

power back door system is canceled.

■

Power back door

Observe the following precautions when

operating the power back door.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the back door is about to open or

close.

●

If the power back door system is dis-

abled, while the back door is operating

automatically, the automatic opera-

tion is stopped. The back door then

has to be operated manually. Take

extra care in this situation, as the back

door may open or close suddenly.

109

3-2. Opening, closing and locking the doors

fore
dri
ving

WARNING

●

If the operating conditions of the

power back door (



P.105) are no

longer met, a buzzer may sound and

the back door may stop opening or

closing. The back door then has to be

operated manually. Take extra care

when on an incline, as the back door

may open or close abruptly.

●

On an incline, the back door may sud-

denly shut after it opens. Make sure

the back door is fully open and secure.

●

In the following situations, the power

back door may detect an abnormality

and automatic operation may be

stopped. In this case, the back door

has to be operated manually. Take

extra care in this situation, as the back

door may open or close suddenly.

• When the back door contacts an

obstacle

• When the battery voltage suddenly

drops, such as when the engine switch

is turned to ON or the engine is

started during automatic operation

●

If a bicycle carrier or similar heavy

object is attached to the back door, the

power back door may not operate,

causing itself to malfunction, or the

back door may suddenly shut again

after being opened, causing some-

one’s hands, arms, head or neck to be

caught and injured. When installing an

accessory part to the back door, using

a genuine Lexus part is recommended.

■

Jam protection function

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the back door fully closes. Be

careful not to get fingers caught or

anything else.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

■

Hands Free Power Back Door

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

Exhaust gases cause the exhaust pipes

to become quite hot. When operating

the Hands Free Power Back Door, be

careful not to touch the exhaust pipe.

●

Do not operate the Hands Free Power

Back Door if there is little space under

the rear bumper.

NOTICE

■

Back door spindles

The back door is equipped with spindles

that hold the back door in place.

Observe the following precautions.

Failure to do so may cause damage to

the back door spindle

, resulting in

malfunction.

●

Do not attach any foreign objects,

such as stickers, plastic sheets, or

adhesives to the spindle rod.

●

Do not touch the spindle rod with

gloves or other fabric items.

110

3-2. Opening, closing and locking the doors

The power back door system can be
enabled/disabled on the multi-infor-
mation display. (



P.77)

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches, select “Vehicle Set-
tings” and then press “OK”.

NOTICE

●

Do not attach any accessories other

than genuine Lexus parts to the power

back door.

●

Do not place your hand on the spindle

or apply lateral forces to it.

■

To prevent back door closer malfunc-

tion

Do not apply excessive force to the back

door while the back door closer is oper-

ating. Applying excessive force may

cause the back door closer to malfunc-

tion.

■

To prevent damage to the power

back door

●

Make sure that there is no ice between

the back door and frame that would

prevent movement of the back door.

Operating the power back door when

excessive load is present on the back

door may cause a malfunction.

●

Do not apply excessive force to the

back door while the power back door

is operating.

●

Take care not to damage the sensors

(installed on the right and left edges of

the power back door) (



P.107) with a

knife or other sharp object. If the sen-

sor is disconnected, the power back

door will not close automatically.

■

Close & lock function

When closing the power back door

using the close & lock function, a differ-

ent buzzer than the normal one will

sound before the operation begins.
To check that the operation has started

correctly, check that a different buzzer

than the normal one has sounded.
Additionally, when the power back door

is fully closed and locked, operation sig-

nals will indicate that all of the doors have

been locked.
Before leaving the vehicle, make sure

that the operation signals have operated

and that all of the doors are locked.

■

Hands Free Power Back Door pre-

cautions

Observe the following to ensure that the

power back door function operates

properly:

●

Do not apply coatings that have a rain

clearing (hydrophilic) effect, or other

coatings, to the lower center part of

the rear bumper.

●

Do not subject the rear bumper to a

strong impact.

If the rear bumper has been subjected

to a strong impact, the Hands Free

Power Back Door may not operate

properly. If the Hands Free Power

Back Door does not operate in the fol-

lowing situations, have the vehicle

inspected by your Lexus dealer.

• The kick sensor or its surrounding area

has been subjected to a strong impact.

• The lower center part of the rear

bumper is scratched or damaged.

●

Do not disassemble the rear bumper.

●

Do not attach stickers to the rear

bumper.

●

Do not paint the rear bumper.

Canceling the power back door
system (vehicles with power
back door)

111

3-2. Opening, closing and locking the doors

fore
dri
ving

Press

of the meter con-

trol switches, select

and

then press “OK”.

Press

of the meter con-

trol switches, and then select “Sys-
tem Settings”.

ON and OFF will be switched
when “OK” is pressed.

If the power back door is disabled, it will
remain disabled unless it is enabled on the
multi-information display. (It will not be
enabled even when the engine switch is
turned off and then back to ON.)

The Hands Free Power Back Door
(kick sensor) can be enabled/disabled
on the multi-information display.
(



P.77)

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches, select the “Vehicle
Settings” and then press “OK”.

Press

of the meter con-

trol switches, select

and

then press “OK”.

Press

of the meter con-

trol switches, and then select
“KICK SENSOR”.

ON and OFF will be switched
when “OK” is pressed.

If the Hands Free Power Back Door is dis-

abled, it will remain disabled unless it is
enabled on the multi-information display.
(It will not be enabled even when the
engine switch is turned off and then back to
ON.)

The open position of the power back
door can be adjusted.

Stop the back door in the desirable
position. (



P.103)

Press and hold the power back
door switch on the back door for 2
seconds.

• When the settings are completed,

the buzzer sounds 4 times.

• When opening the back door the

next time, the back door will stop at
that position.

■

Returning the back door automatic stop

position to the initial settings

Press and hold the power back door switch

on the back door for 7 seconds.
After the buzzer sounds 4 times, it sounds
twice more. When the power back door
does the opening operation the next time,
the door will open to the initial settings posi-
tion.

Canceling the Hands Free
Power Back Door (vehicles with
kick sensor)

Adjusting the open position of
the back door (vehicles with
power back door)

112

3-2. Opening, closing and locking the doors

■

Customization

The opening position can be set with the

navigation system or multimedia system.

(



P.408)

Priority for the stop position is given to the
last position set by either the

switch,

navigation system or multimedia system.

■

Antenna location

Antennas outside the cabin

Antennas inside the cabin

Antenna inside the luggage compart-
ment

Antenna outside the luggage compart-
ment

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key (including the card
key) on your person, for example in
your pocket. The driver should
always carry the electronic key.



Locks and unlocks the doors
(



P.96)



Locks and unlocks the back door
(



P.100)



Starts the engine (



P.148)

113

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Effective range (areas within which the

electronic key is detected)

When locking or unlocking the doors

The system can be operated when the elec-
tronic key is within about 2.3 ft. (0.7 m) of
an outside front door handle. (Only the
doors detecting the key can be operated.)

When starting the engine or changing
engine switch modes

The system can be operated when the elec-
tronic key is inside the vehicle.

■

If an alarm sounds or a warning message

is displayed

An alarm sounds and warning messages

are displayed on the multi-information dis-

play to protect against unexpected acci-

dents or theft of the vehicle resulting from

erroneous operation. When a warning

message is displayed, take appropriate

measures based on the displayed message.
When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

●

When an Interior alarm pings repeatedly

■

If “Key Detected in Vehicle” is shown on

the multi-information display

An attempt was made to lock the doors

using the smart access system with push-

button start while the electronic key was still

inside the vehicle. Retrieve the electronic

key from the vehicle and lock the doors

again.

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the battery from being dis-

charged while the vehicle is not in operation

for a long time.

●

In the following situations, the smart

access system with push-button start may

take some time to unlock the doors.

• The electronic key has been left in an

area of approximately 6 ft. (2 m) of the

outside of the vehicle for 10 minutes or

longer.

• The smart access system with push-but-

ton start has not been used for 5 days or

longer.

●

If the smart access system with push-but-

ton start has not been used for 14 days or

longer, the doors cannot be unlocked at

any doors except the driver’s door. In this

case, take hold of the driver’s door han-

dle, or use the wireless remote control or

the mechanical key, to unlock the doors.

Situation

Correction proce-

dure

An attempt was
made to lock the
vehicle while a door
was open.

Close all of the
doors and lock the
doors again.

Situation

Correction proce-

dure

The engine switch
was turned to ACC
while the driver’s
door was open (The
driver’s door was
opened when the
engine switch was in
ACC).

Turn the engine
switch off and close
the driver’s door.

The engine switch
was turned off while
the driver’s door was
open.

Close the driver’s
door.

114

3-2. Opening, closing and locking the doors

■

Turning an electronic key to battery-

saving mode

●

When battery-saving mode is set, battery

depletion is minimized by stopping the

electronic key from receiving radio

waves.

Press

twice while pressing and

holding .
Confirm that the electronic key indicator

flashes 4 times. While the battery-saving

mode is set, the smart access system with

push-button start cannot be used. To cancel

the function, press any of the electronic key

buttons.

●

Electronic keys that will not be used for

long periods of time can be set to the bat-

tery-saving mode in advance.

■

Conditions affecting operation

The smart access system with push-button

start uses weak radio waves. In the follow-

ing situations, the communication between

the electronic key and the vehicle may be

affected, preventing the smart access sys-

tem with push-button start, wireless remote

control and engine immobilizer system

from operating properly. (Ways of coping:



P.376)

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit

radio waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Another vehicle’s electronic key or a

wireless key that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

●

When the electronic key is placed near a

battery charger or electronic devices

●

When the vehicle is parked in a pay park-

ing spot where radio waves are emitted.

■

Note for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is on the instrument

panel, luggage room, floor, or in the door

pockets or glove box when the engine is

started or engine switch modes are

changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the door

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

115

3-2. Opening, closing and locking the doors

fore
dri
ving

or unlocked by anyone. However, only

the doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

engine if the electronic key is near the

window.

●

The doors may unlock if a large amount

of water splashes on the door handle,

such as in the rain or in a car wash when

the electronic key is within the effective

range. (The doors will automatically be

locked after approximately 60 seconds if

the doors are not opened and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock sensor while

wearing gloves may delay or prevent

lock operation. Remove the gloves and

touch the lock sensor again.

●

When the lock operation is performed

using the lock sensor, recognition signals

will be shown up to two consecutive

times. After this, no recognition signals

will be given.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In that case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 6 ft.

(2 m) or more away from the vehicle.

(Take care to ensure that the key is not

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



P.114)

●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a buzzer may sound outside the

vehicle and “Key Detected in Vehicle”

may be shown on the multi-information

display. To turn off the alarm, lock all the

doors.

●

The lock sensor may not work properly if

it comes into contact with ice, snow, mud,

etc. Clean the lock sensor and attempt to

operate it again.

●

A sudden approach to the effective

range or door handle may prevent the

doors from being unlocked. In this case,

return the door handle to the original

position and check that the doors unlock

before pulling the door handle again.

●

If there is another electronic key in the

detection area, it may take slightly longer

to unlock the doors after the door handle

is gripped.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 6 ft. (2 m)

of the vehicle.

●

The smart access system with push-but-

ton start can be deactivated in advance.

●

Setting the electronic key to battery-sav-

ing mode helps to reduce key battery

depletion. (



P.114)

■

To operate the system properly

Make sure to carry the electronic key when

operating the system. Do not get the elec-

tronic key too close to the vehicle when

operating the system from the outside of

the vehicle.
Depending on the position and holding

condition of the electronic key, the key may

not be detected correctly and the system

may not operate properly. (The alarm may

go off accidentally, or the door lock preven-

tion may not operate.)

■

If the smart access system with push-

button start does not operate properly

●

If the doors cannot be locked or

unlocked, perform the following.

• Bring the electronic key close to the door

handle and perform a lock or unlock

operation.

• Use the wireless remote control.
If the doors cannot be locked or unlocked
by perform the above, use the mechanical
key. (



P.376)

For Canada: However, if the mechanical
key is used while the alarm system is set, the

116

3-2. Opening, closing and locking the doors

warning will sound. (



P.61)

●

If the engine cannot be started, refer to

P.377

■

Customization

Settings (e.g. smart access system with

push-button start) can be changed. (Cus-

tomizable features:



P.407)

If the smart access system with push-button

start has been deactivated by a customized

setting, refer to the explanations for the fol-

lowing operations.

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (



P.96, 376)

●

Starting the engine and changing engine

switch modes:



P.377

●

Stopping the engine:



P.149

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should keep

away from the smart access system

with push-button start antennas.

(



P.112)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

your Lexus dealer for details, such as

the frequency of radio waves and tim-

ing of the emitted radio waves. Then,

consult your doctor to see if you

should disable the entry function.

●

Users of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask your Lexus dealer for details on dis-
abling the entry function.

117

3-3. Adjusting the seats

fore
dri
ving

3-3.Adjusting the seats

Seat position adjustment switch

Seat cushion (front) angle adjust-
ment switch

Seatback angle adjustment switch

Vertical height adjustment switch

Lumbar support adjustment switch
(for driver’s side)

■

When adjusting the seat

●

Make sure that any surrounding passen-

gers or objects are not contact the seat.

●

Take care when adjusting the seat so that

the head restraint does not touch the ceil-

ing.

■

Power easy access system (if equipped)

The driver’s seat and steering wheel move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.119)

■

Jam protection function (vehicles with

driving position memory)

While the driving position is recalled or the

power easy access system is operating, if an

object is stuck behind the front seat, the

front seat will stop and then slightly move

forward.
When the jam protection function operates,

the seat stops at a position other than the

set seat position. Check the seat position.

Front seats

The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.

Adjustment procedure

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough space

around the feet so they do not get

stuck.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose con-

trol of the vehicle.

118

3-3. Adjusting the seats

■

Before folding down the rear seat-
backs

Park the vehicle in a safe place.

Apply the parking brake firmly and shift the

shift lever to P. (



P.157)

Adjust the position of the front seat
and the angle of the seatback.
(



P.117)

Depending on the position of the front

seat, if the seatback is folded backward, it

may interfere with the operation of the rear

seat.

Lift up and push down the head
restraints of the rear outboard
seats, and lower the head restraint
of the rear center seat. (



P.123)

Stow the armrest of the rear seat if
it is pulled out. (



P.292)

This step is not necessary when operating

the left side seat only.

■

Folding down rear seatbacks

Pull the seatback lock release lever
and fold the seatback down.

■

Returning the rear seatbacks

To avoid trapping the seat belt
between the seat and the inside of the
vehicle, pass the seat belt inside the
seat belt guide

and then return the

seatback securely to the locked posi-
tion.

Rear seats

The seatbacks of the rear seats can
be folded down.

Folding down the rear seatbacks

WARNING

■

When folding the rear seatbacks

down

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not attempt to fold the seatbacks

down while driving.

●

Stop the vehicle on level ground, set

the parking brake and shift the shift

lever to P.

●

Do not allow anyone to sit on a folded

seatback or in the luggage compart-

ment while driving.

●

Do not allow children to enter the lug-

gage compartment.

●

Do not operate the rear seat if it is

occupied.

●

Be careful not to get feet or hands

caught in the moving parts or joints of

the seats during operation.

●

Do not allow children to operate the

seat.

119

3-3. Adjusting the seats

fore
dri
ving

: If equipped

When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows driver to enter
and exit the vehicle easily.



The shift lever has been shifted to P.



The engine switch has been turned
off.



The driver’s seat belt has been

WARNING

■

After returning the rear seatback to

the upright position

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Make sure that the seatback is

securely locked in position by lightly

pushing it back and forth. If the seat-

back is not securely locked, the red

marking will be visible on the seatback

lock release lever. Make sure that the

red marking is not visible.

●

Check that the seat belts are not

twisted or caught in the seatback.

Driving position memory

This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Enabling easier driver entry and
exit (power easy access system)

120

3-3. Adjusting the seats

unfastened.

When any of the following has been
performed, the driver’s seat and steer-
ing wheel automatically return to their
original positions.



The engine switch has been turned
to ACC or ON.



The driver’s seat belt has been fas-
tened.

■

Operation of the power easy access

system

When exiting the vehicle, the power easy

access system may not operate if the seat is

already close to the rearmost position, etc.

■

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized. (Customizable features:



P.409)

Check that the shift lever is in P.

Turn the engine switch to ON.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display (if equipped)
to the desired positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

■

Seat positions that can be memorized

(



P.117)

The adjusted positions other than the posi-

tion adjusted by lumbar support switch can

be recorded.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Check that the shift lever is in P.

Turn the engine switch to ON.

Recording a driving position into
memory

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

Lexus UX200 (2022 year). Manual in english - page 6
