6-2. Lexus Climate Concierge

6-2.Lexus Climate Concierge

Select

The indicator on the Lexus Climate Con-
cierge control screen illuminates, and the
automatic air conditioning system, front
seat heaters and ventilators (if equipped),
and heated steering wheel (if equipped)
operate in automatic mode.
If any of the system is operated manually,
the indicator turns off. However, all other
functions continue to operate in automatic
mode.

When using the Lexus Climate Con-

cierge

Lexus Climate Concierge can be operated

on the sub function menu or option control

screen. (



P.349)

Automatic air conditioning system
(



P.346)

The temperature can be adjusted inde-
pendently for the driver seat and pas-
senger seat.

Front seat heaters and ventilators
(if equipped) (



P.357)

Heating or ventilation is automatically
selected according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc.
The seat heater and ventilator of the
front passenger seat operate in auto-
matic mode if a passenger is detected.

Heated steering wheel (if
equipped) (



P.357)

Heated steering wheel operates auto-
matically according to the set tem-
perature of the air conditioning system,
the outside temperature, etc.

Lexus Climate Concierge

The front seat heaters (if equipped),
seat ventilators (if equipped) and
heated steering wheel (if equipped)
are each automatically controlled
according to the set temperature of
the air conditioning system, the out-
side and cabin temperature, etc.
Lexus Climate Concierge allows a
comfortable condition to be main-
tained without adjusting each sys-
tem.
Press the “MENU” button on the
Remote Touch and select “Cli-
mate” to display the air condition-
ing control screen. Then, select

to display the Lexus Climate Con-
cierge control screen.

Turning on Lexus Climate Con-
cierge

Operation of each system

347

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

Outside/recirculated air mode switch

Airflow mode control switch

Right-hand side temperature control switch

Adjusting the temperature setting

Operate the temperature control
switch upwards to increase the tem-
perature and downwards to decrease
the temperature.

Setting the fan speed

Operate the fan speed control switch
upwards to increase the fan speed and
downwards to decrease the fan speed.

Press the off switch to turn the fan off.

Change the airflow mode

Operate the airflow mode control
switch upwards or downwards.

The mode changes as follows each time
the switch is operated.

Air flows to the upper body.

Air flows to the upper body and
feet.

Air flows to the feet.

Air flows to the feet and the wind-
shield defogger operates.

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.

The mode switches between outside air
mode (the indicator is off) and recirculated
air mode (the indicator is on) each time the
switch is pressed.

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the windshield defogger switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press the
windshield defogger switch again when the
windshield is defogged.

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window and to remove raindrops, dew
and frost from the outside rear view
mirrors.
Press the rear window and outside
rear view mirror defogger switch.

The defoggers will automatically turn off

A
B

348

6-3. Using the air conditioning system and defogger

after a period of time.

Windshield wiper de-icer (if
equipped)



P.351

Fogging up of the windows

The windows will easily fog up when the

humidity in the vehicle is high. Selecting

“A/C” will dehumidify the air from the

outlets and defog the windshield effec-

tively.

If you turn “A/C” off, the windows may

fog up more easily.

The windows may fog up if the recircu-

lated air mode is used.

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

Outside/recirculated air mode

Setting to the recirculated air mode tem-

porarily is recommended in preventing

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

Outside/recirculated air mode may

automatically switch depending on the

temperature setting or the inside tem-

perature.

Operation of the air conditioning sys-

tem in Eco drive mode

In Eco drive mode, the air conditioning

system is controlled as follows to priori-

tize electricity consumption efficiency

• Motor speed and compressor operation

controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic

mode is selected

To improve air conditioning perfor-

mance, perform the following operations

• Turn off eco air conditioning mode

(



P.349)

• Adjust the fan speed

• Turn off Eco drive mode

When the outside temperature is low

The dehumidification function may not

operate even when “A/C” is selected.

Ventilation and air conditioning odors

To let fresh air in, set the air conditioning

system to the outside air mode.

During use, various odors from inside

and outside the vehicle may enter into

and accumulate in the air conditioning

system. This may then cause odor to be

emitted from the vents.

To reduce potential odors from occur-

ring:

• It is recommended that the air condition-

ing system be set to outside air mode

prior to turning the vehicle off.

• The start timing of the blower may be

delayed for a short period of time imme-

diately after the air conditioning system is

started in automatic mode or pollen

removal mode.

Air conditioning filter



P.412

Customization

Settings (e.g. A/C automatic mode switch

operation) can be changed.

(Customizable features:



P.485)

WARNING

To prevent the windshield from fog-

ging up

Do not use the windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

349

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

Main control screen

Using the touchpad of the Remote
Touch, select the button on the screen.

can be adjusted by perform-

ing the following operations.
Flick operation: Move the pointer to
the desired item and flick the touchpad
up or down.

The item can be adjusted by one level.

Trace operation: After selecting the
desired item, slide your finger up or
down.

The item can be adjusted by the amount
that you trace.
Trace operation cannot be used while driv-
ing.

Sub menu

Selecting the sub menu item to switch the
main screen.

: Display the air conditioning control

screen

: Display the heated steering

wheel/front seat heater/seat ventilator
control screen (if equipped)

: Display the Lexus Climate Con-

cierge control screen

: Display the option control screen

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Select the air flow mode

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Adjust the right-hand side tem-
perature setting

Function on/off indicators

WARNING

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

NOTICE

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the EV

system is off.

Air conditioning control screen

C
D

350

6-3. Using the air conditioning system and defogger

When the function is on, the indicator illu-
minates on the control screen.

Sub function menu

When the sub function button on the
Remote Touch is pressed, the following
functions can be switched on and off.

: Set Lexus Climate Concierge

(



P.344)

“AUTO”: Set automatic mode on/off
(



P.352)

“Off”: Turn the fan off
“A/C”: Set cooling and dehumidification
function
“DUAL”: Adjust the temperature for driver
and front passenger seats separately
(“DUAL” mode) (



P.353)

: Changing the fan speed setting

during the automatic mode operation
(Blower customization)

: Set eco air conditioning mode

Option control screen

Select

on the sub menu to display

the option control screen.

The functions can be switched on and off.
When the function is on, the indicator illu-
minates on the screen.

Set Lexus Climate Concierge
(



P.344)

Adjusting the temperature for
driver and front passenger seats
separately (“DUAL” mode)
(



P.353)

Set eco air conditioning mode

Air conditioning and heater output is lim-
ited to prioritize electricity consumption
efficiency.

Cooling and dehumidification func-
tion

nanoe™ X

on/off

nanoe™ X is a nanoe™ generator.

Select front seat concentrated air-
flow mode (S-FLOW) (



P.354)

Prevent ice from building up on the
windshield and wiper blades
(Windshield wiper de-icer) (if
equipped)

Removing pollen from the air (Pol-
len removal mode)

: nanoe™ and the nanoe™ mark are

trademarks of Panasonic Corporation.

Side display (10.3-inch display
model)

Display the heated steering
wheel/front seat heaters/seat ven-
tilators control screen (if equipped)

351

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

(



P.360)

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Adjust the right-hand side tem-
perature setting

Set cooling and dehumidification
function on/off

Adjust the temperature for the
driver’s and front passenger’s seats
separately (“DUAL” mode)
(



P.353)

Select the air flow mode

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from

building up on the windshield and wiper

blades.
The windshield wiper de-icer will automati-
cally turn off after a period of time.

Eco air conditioning mode

When Eco drive mode is selected using the

driving mode select switch, eco air condi-

tioning mode turns on.
When a driving mode other than Eco drive

mode is selected, eco air conditioning

mode may turn off.

Pollen removal mode

Outside air mode switches to recirculated

air mode.
Pollen is removed from the air and the air

flows to the upper part of the body.
Usually the system will automatically turn

off after a period of time.
In order to prevent the windshield from fog-

ging up when the outside air is cold, the

dehumidification function may operate or

the outside/recirculated air mode may not

switch to recirculated air mode.

Pollen is filtered even if pollen removal

mode is turned off.

nanoe™ X

This vehicle incorporates a biocidal prod-

uct.
Ionised air generated by a device incorpo-

rated in the vehicle purifies the air in the

cabin by suppressing bacteria.
Active substances: Free radicals generated

in situ from ambient air or water.
nanoe™ helps to provide purified air by

emitting electrically charged water parti-

cles through the side vent on the driver’s
side

When the fan is turned on and nanoe™

on the option control screen is selected,

the nanoe™ X is activated.

When the fan is operated in the following

conditions, system performance will be

maximized. If the following conditions are

not met, performance will be limited.

• The ,

air

outlets

are

being used.

• The side vent on the driver’s side is open.

When nanoe™ is generated, a small

amount of ozone is emitted and may be

faintly smelled in some situations. How-

ever, this is approximately the same as

the amount that already exists in nature,

such as in forests, and it has no affect on

the human body.

A slight noise may be heard during oper-

ation. This is not a malfunction.

: nanoe™ X is a nanoe™ generator.

nanoe™ and the nanoe™ mark are trade-
marks of Panasonic Corporation.

: According to temperature and humidity

conditions, fan speed and direction of
the air flow, the nanoe™ system may not
operate at full capacity.

Blower customization

Fan speed setting during the automatic

mode operation can be customized.

C
D

352

6-3. Using the air conditioning system and defogger

To change the fan speed setting mode,
select

on the air conditioning con-

trol screen.

Each time

is selected, the fan speed

setting mode changes as follows.
“NORMAL”



“ECO”



“FAST”



“NORMAL”

Press the automatic mode switch
or select “AUTO” on the sub func-
tion menu (



P.349).

Adjust the temperature setting.

To stop the operation, press the off
switch or select “Off” on the sub
function menu (



P.349).

If the fan speed setting or air flow

modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other
than that operated is maintained.

Using automatic mode

Fan speed is adjusted automatically

according to the temperature setting and

the ambient conditions.

Therefore, the fan may stop for a while until

warm or cool air is ready to flow immedi-

ately after the automatic mode switch is

pressed or “AUTO” is selected.
Cool air may blow around the upper body

even when the heater is on due to sunlight.

Windshield fog detection function

When automatic mode is set, the humidity

sensor detects fog on the windshield and

controls the air conditioning system to pre-

vent fog.

WARNING

To prevent burns (vehicles with wind-

shield wiper de-icer)

Do not touch the glass at lower part of

the windshield or to the side of the front

pillars when the windshield wiper de-icer

is on.

nanoe™ X

Do not disassemble or repair the gener-

ator because it contains high voltage

parts. Contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer if the generator

needs repair.

NOTICE

To prevent damage to the nanoe™ X

Do not insert anything into the side vent

on the driver’s side, attach anything to it,

or use sprays around it. These things may

cause the generator not to work prop-

erly.

Using automatic mode

NOTICE

Humidity sensor

In order to detect fog on the windshield,

a sensor which monitors the temperature

of the windshield, the surround humidity,

etc., is installed.

Follow these points to avoid damaging

the sensor:

Do not disassemble the sensor

Do not spray the glass cleaner on the

sensor or subject it to strong impacts

Do not stick anything on the sensor

353

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

To turn on the “DUAL” mode, perform
any of the following procedures:



Select “DUAL” on the sub function
menu. (



P.349)



Select “DUAL” on the option con-
trol screen.



Adjust the front passenger’s side
temperature setting.

The indicator comes on when the “DUAL”
mode is on.

Location of air outlets

The air outlets and air volume changes
according to the selected air flow
mode.

Adjusting the position of and open-
ing and closing the air outlets



Front

Direct air flow to the left or right, up or
down

Turn the knob to open or close the vent

Open the outlet

Close the outlet



Rear

Direct air flow to the left or right, up
or down

Turn the knob to open or close the
vent

Adjusting the temperature for
driver and front passenger seats
separately (“DUAL” mode)

Air outlet layout and operations

354

6-3. Using the air conditioning system and defogger

This function automatically controls the
air conditioning airflow so that priority
is given to the front seats. When the
front passenger seat is not occupied,
airflow may switch to only the driver’s
seat. Unnecessary air conditioning is
suppressed, contributing to increased
electricity consumption efficiency.
Front seat concentrated airflow mode
operates in the following situations.



No passengers are detected in the
rear seats



The windshield defogger is not
operating



Pollen removal mode is not operat-
ing

While operating,

illuminates.

Manually turning front seat con-
centrated airflow mode on/off

In front seat concentrated airflow
mode, directing airflow to the front
seats only and to all seats can be
switched via switch operation. When
the mode has been switched manually,
automatic airflow control stops operat-
ing.

Select

on the option control

screen (



P.350) and switch the air-

flow.



Indicator illuminated: Airflow to the
front seats only



Indicator off: Airflow to all the seats

Operation of automatic airflow control

In order to maintain a comfortable inte-

rior, airflow may be directed to seats

without passengers immediately after the

EV system is started and at other times

depending on the outside temperature.

After the EV system is started, if passen-

gers move around inside or enter/exit

the vehicle, the system cannot accurately

detect the presence of passengers and

automatic airflow control will not oper-

ate.

Operation of manual airflow control

Even if the function is manually switched to

directing airflow to only the front seats,

when a rear seat is occupied, it may auto-

matically direct airflow to all seats.

To return to automatic airflow control

With the indicator off, turn the power

switch off.

After 60 minutes or more elapse, turn

the power switch to ON.

WARNING

To prevent the windshield defogger

from operating improperly

Do not place anything on the instrument

panel which may cover the air outlets.

Otherwise, air flow may be obstructed,

preventing the windshield defoggers

from defogging.

Front seat concentrated airflow
mode (S-FLOW)

355

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

Check the temperature setting of the
air conditioning system. (



P.347)

The Remote Air Conditioning System will
operate in accordance with the tempera-
ture settings of the air conditioning system.

Press and hold “A/C” on the wireless
remote control to operate the Remote
Air Conditioning System.

The system will shut off if a door is opened.
The system can be stopped by pressing
“A/C” twice.

Operating conditions

The system will only operate if all of the fol-

lowing conditions are met:

The power switch is OFF.

All doors are closed.

The hood is closed.

Remote Air Conditioning System auto-

matic shut-off

The system will automatically shut off under

the following conditions:

About 20 minutes have passed since

operation began

Any one of the operating conditions is

not met

The system may also shut off if the charge

level of the traction battery drops to low.

Conditions affecting operation

The system may not start in the following sit-

uations:

The charge level of the traction battery is

low

When the EV system is cool (for exam-

ple, after being left for a long time in low

temperatures)

Windshield defogger

When defogging the windshield using the

Remote Air Conditioning System, defog-

ging may be insufficient due to the power

being restricted more than during normal

air conditioning operation. Also, the outside

of the windshield may fog up due to the out-

side temperature, humidity or air condition-

ing set temperature.

Remote Air Conditioning
System

The Remote Air Conditioning Sys-
tem uses electrical energy stored in
the traction battery and allows the
air conditioning to be operated by
remote control.
If the Remote Air Conditioning
System is used while the charging
cable is connected to the vehicle,
the reduction of charge in the trac-
tion battery will be suppressed to
allow you to use electricity from an
external power source.

Charging will be conducted auto-
matically after the Remote Air Con-
ditioning System is stopped.

Before leaving the vehicle

Activating the Remote Air Con-
ditioning System

356

6-3. Using the air conditioning system and defogger

Security feature

Any unlocked doors will be automatically

locked when the system is operating. The

emergency flashers flash to indicate that the

doors have been locked.

Conditions affecting operation



P.197

While the Remote Air Conditioning

System is operating

Depending on the operating condition of

the Remote Air Conditioning System, the

electric fan may spin and an operating

noise may be heard.

However, this does not indicate a mal-

function.

The Remote Air Conditioning System

may stop operating temporarily if other

features that use electricity (for example,

the seat heater, lights, windshield wipers)

are in operation or if the charge level of

the 12-volt battery becomes low.

The headlights, windshield wiper, meter,

etc. will not operate.

The intrusion sensor will automatically be

canceled.

Electronic key battery depletion



P.174

When the electronic key battery is fully

depleted



P.414

Customization

Setting (e.g. Operation using “A/C” on the

wireless remote control) can be changed.

(Customizable features:



P.486)

WARNING

Precautions for the Remote Air Con-

ditioning System

Do not use the system if people are in

the vehicle.

Even when the system is in use, the

internal temperature may still reach a

high or low level due to features such

as the automatic shut-off. Children and

pets left inside the vehicle may suffer

heatstroke dehydration or hypother-

mia, or could result in death or serious

injury.

Depending on the surrounding envi-

ronment, signals from the wireless

switch may transmit further than

expected. Pay appropriate attention to

the vehicle’s surroundings and use the

switch only when necessary.

Do not operate “A/C” if the hood is

open. The air conditioning may oper-

ate unintentionally and objects may be

drawn into the electrical cooling fans.

NOTICE

To prevent the traction battery from

being discharged through incorrect

operation

Use “A/C” only when necessary.

357

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

: If equipped

Turns the heated steering wheel on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (2 segments lit)



Lo (1

segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

The heated steering wheel can be used

when

The power switch is in ON.

Customization

Steering wheel heating preference in auto-

matic mode can be changed. (Customiza-

ble features:



P.486)

Heated steering wheel

/seat

heaters

/seat ventilators



Heated steering wheel

Warms up the grip of the steering
wheel



Seat heaters

Warm up the seat upholstery



Seat ventilators

Maintain good airflow on the seat
upholstery by sucking air into the
seats

Press the “MENU” button on the
Remote Touch and select “Climate”
to display the air conditioning con-
trol screen. Then, select

on the

sub menu (



P.349) to display the

heated steering wheel/front seat
heaters/seat ventilators control
screen.

WARNING

To prevent minor burn injuries

Care should be taken if anyone in the fol-

lowing categories comes in contact with

the steering wheel or seats when the

heater is on:

Babies, small children, the elderly, the

sick and the physically challenged

Persons with sensitive skin

Persons who are fatigued

Persons who have taken alcohol or

drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

NOTICE

To prevent damage to the seat heat-

ers and seat ventilators

Do not put heavy objects that have an

uneven surface on the seat and do not

stick sharp objects (needles, nails, etc.)

into the seat.

To prevent 12-volt battery discharge

Do not use the functions when the EV

system is off.

Heated steering wheel

358

6-3. Using the air conditioning system and defogger

Front

Turns the seat heaters on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (3 segments lit)



Mid

(2 segments lit)



Lo (1 segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

Rear (outboard rear seats)

High heater temperature level

Low heater temperature level

When the rear seat heater is on, the
indicator illuminates on the seat heater
switch.
When not in use, put the switch in the
neutral position. The indicator will turn
off.

The seat heaters can be used when

The power switch is in ON.

Customization

Settings for the seat heaters can be

changed. (Customizable features:



P.486)

Turns the seat ventilators on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (3 segments lit)



Mid

(2 segments lit)



Lo (1 segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

The seat ventilators can be used when

The power switch is in ON.

Seat heaters

WARNING

To prevent causes of overheating and

minor burn injuries

Observe the following precautions when

using a seat heater

Do not cover the seat with a blanket or

cushion when using the seat heater.

Do not use seat heater more than nec-

essary.

Seat ventilators (front seats)

359

6-3. Using the air conditioning system and defogger

rio

r f

eat
ur

Air conditioning system-linked control

mode

When the seat ventilator fan speed level is

Hi, the seat ventilator fan speed becomes

higher according to the fan speed of the air

conditioning system.

Customization

Settings for the seat ventilators can be

changed. (Customizable features:



P.486)

Main display

Using the touchpad of the Remote
Touch, select the button on the screen.

can be adjusted by perform-

ing the following operations.
Flick operation: Move the pointer to
the desired item and flick the touchpad
up or down.

The item can be adjusted by one level.

Trace operation: After selecting the
desired item, trace the pad surface.

The item can be adjusted by the amount
that you trace.
Trace operation cannot be used while driv-
ing.

Adjust the seat ventilator fan speed
level

The seat ventilator can be adjusted in 3
levels.
When the seat ventilator is operated, the
fan speed level is displayed on the screen.

Adjust the front seat heater tem-
perature level

The front seat heater can be adjusted in 3
levels.
When the front seat heater is operated, the
temperature level is displayed on the
screen.

Adjust the heated steering wheel
temperature level

The heated steering wheel can be adjusted
in 2 levels.
When the heated steering wheel is oper-
ated, the temperature level is displayed on
the screen.

Automatic mode on/off indicators

When the automatic mode is on, the indi-
cator illuminates on the screen.

Sub function menu

When the sub function button on the
Remote Touch is pressed, the following
functions can be set to automatic mode.

: Left-hand side seat heater/seat

ventilator

: Heated steering wheel

: Right-hand side seat heater/seat

ventilator

Control screen

Lexus UX 300e (2022 year). Manual in english - page 20
