Lexus UX 300e (2022 year). Manual in english

110

2-2. Charging

: When using “My Room Mode”, the time required for charging to complete may

become longer than normal or the charging may not be completed.

: It is the time required for charging to complete approximately 75% of the maximum

charge capacity.

: It is the time required for charging to complete the maximum charge capacity.

: Depending on the type of the DC charger, the charging time displayed on the DC char-

ger may be longer than normal.

Charging time may increase when

In the following situations, charging time

may become longer than normal:

When the ambient temperature is hot or

cold.

When the vehicle is consuming a lot of

electricity, for example, when the head-

lights have been left on, etc.

When using My Room Mode.

When a power outage occurs during

charging.

When the power supply is interrupted.

When the voltage of the external power

source drops.

When the charge level of the 12-volt bat-

tery is low, such as when the vehicle has

not been started or charged for a long

period of time.

When selecting “Charging Current” set-

tings “16A” or “8A”.

When the traction battery heater oper-

ates.

When the traction battery cooler is oper-

ated before charging. (



P.111)

When there is a problem with the termi-

nal connections of the electrical socket.

When the traction battery temperature

becomes high immediately after high-

load driving.

When adjusting the power supply with

the charger.

When frequently and repeatedly using

DC charging.

This vehicle includes several functions
that are linked with charging.

My Room Mode (



P.139)

When the charging cable is connected
to the vehicle, electrical components
such as the air conditioning system and
audio system can be used by the
power supply from an external power
source

: Depending on the situation, electricity of

the traction battery may be consumed.

Traction battery heater

When the outside temperature is low
and the charging cable is connected to
the vehicle, this function automatically
warms the traction battery until it
reaches or exceeds a certain tempera-
ture.



The operation of this function is
stopped automatically when the
charging cable is disconnected or if
the charging cable is left connected
to the vehicle for approximately 3
days.



When the charging schedule is used
(



P.129), this function will operate

according to the schedule settings.

Charging-linked functions

111

2-2. Charging

ect
ric V
eh

icle

Traction battery warming control

This control operates after the
charging cable remains connected to
the vehicle for approximately 3 days
and the traction battery heater auto-
matically stops. It automatically insu-
lates the traction battery in extremely
low temperatures.



This control stops 31 days after the
charging cable is connected, even if
it is still connected to the vehicle.



When this control operates,
charging schedule settings are
ignored and charging starts imme-
diately.

Traction battery cooler

When the traction battery is hot and
the AC charging cable is connected to
the vehicle, this function cools the trac-
tion battery to protect it before AC
charging is performed.
The function may operate when con-
tinuously driving at high speeds such as
driving on highways or freeways, or
during DC charging.

Traction battery heater

Traction battery heater may operate

when charging is not being performed.

When Traction battery heater is operat-

ing, the charging indicator will illuminate.

When Traction battery heater is operat-

ing during charging, the charging may

take longer than normal.

The remaining charge of the traction bat-

tery declines when the traction battery

heater operates, it might be necessary to

recharge the traction battery again in

order to supplement the remaining

charge.

Traction battery cooler

For AC charging: Traction battery cooler

settings can be changed on the multi-

information display. (



P.111)

The AC charging indicator will illuminate

when the traction battery cooler is on

standby or operating.

When the charge level of the traction

battery is low, the traction battery cooler

may not operate, even if the temperature

of the traction battery is high.

When the following conditions are met

while the traction battery cooler is oper-

ating, the cooling operation will stop.

• The hood is opened

• The power switch is turned to ACC or

ON.

• The shift position is changed to any posi-

tion other than P

• The Remote Air Conditioning System is

operated (



P.355)

• “Charge Now” is turned on (



P.135)

• The remaining charge of the traction bat-

tery drops below a certain amount

The traction battery cooler operates

using power supplied by the traction bat-

tery and an external power source.

• While the traction battery cooler is oper-

ating, the charge of the traction battery

will increase and decrease within a cer-

tain range, and will not increase as during

AC charging.

• When the traction battery cooler oper-

ates, charger will recognize it as the bat-

tery being charged. If this function

operates while a charger which charges

a charging fee is connected to the vehi-

cle, AC charging fees will apply.

Changing of the traction battery cooler

setting

Press

of the meter control

switches and select

on the multi-

information display.

Press

of the meter control

switches and select “Vehicle Settings”,

and then press “OK”.

112

2-2. Charging

Press

of the meter control

switches and select “Charging Set-

tings”, and then press “OK”.

Press

of the meter control

switches and select “Battery Cooler”,

and then press “OK”.

Select “On” or “Off”, and then press

“OK”.

When selecting “Off”, the traction battery

output may be restricted depending on the

driving situation.

To enable the use of Electric Vehicle,
we recommend systematically
charging the vehicle.

Before leaving home
In order to use the Electric Vehicle,
charge the traction battery at home
before leaving.

The charging schedule function (



P.129)

can be used to set the system to automati-
cally fully charge the traction battery
before your desired departure time. It is
also possible to set the air conditioning to
make the interior in a comfortable state

Charging tips

This section explains methods for
using the charging function of this
vehicle and checking information
related to charging.

Systematically charging

113

2-2. Charging

ect
ric V
eh

icle

before your desired departure time.

On the way to the destination or at
the destination
When the remaining charge of the
traction battery gets low, recharge
the battery at the nearest charging
station.

When using DC charging, the charging
can be done in approximately 50 minutes
up until approximately 75% of the maxi-
mum charge capacity. (



P.109)

After returning home
In order to drive the next time,
charge the traction battery.

Settings the charging schedule allows you
to charge the traction battery at the
desired time such as late at night or early in
the morning. Furthermore, the charging
schedule can be set to automatically
charge the traction battery every day or at
the same time on certain days. (



P.129)

Information related to charging is dis-
played on the multi-information dis-
play.

While charging

When any door is opened during

charging, the current charging condi-
tion and estimated time

until charging

completed can be checked on the
multi-information display.
The time until charging completed may
not be displayed if the charging current
to the traction battery becomes
smaller and the charging time
becomes longer.

: During DC charging, the estimated time

will not be displayed.

After charging is complete

After charging is complete, when a
door is opened while the power switch
is off, a message detailing the results of
the charging is displayed. Also, a mes-
sage is displayed if an operation that
cannot be performed or a situation that
charging cannot be performed occurs
during charging is performed.

When a message is displayed, follow the
instructions displayed on the multi-infor-
mation display. (



P.150)

Checking information related to
charging

114

2-2. Charging

Charging current

The maximum current for the AC charging

is 32 A. However, the charging current

may become smaller than 32 A depending

on the maximum current of the AC char-

ger.

Safety functions

The EV system will not start while the

charging cable is connected to the vehi-

cle, even if the power switch is operated.

If the charging cable is connected while

the “READY” indicator is illuminated, the

EV system will stop automatically and

driving will not be possible.

When the charging cable is connected to

the vehicle, the shift position cannot be

changed from P to other positions.

This vehicle has been designed to
allow charging from an external power
source using an AC charging cable for
exclusive use with standard household
AC outlets.
However, the vehicle differs greatly
from standard household electrical
goods in the following ways, and incor-
rect usage could cause a fire or elec-
tric shock, possibly leading to death or
serious injury.



When charging, a large amount of
current will flow for a long time.
(



P.109)



Depending on the charging envi-
ronment, charging may be per-
formed outdoors.

To perform charging correctly, read the
precautions and then follow the charging

Things to know before
charging

Make sure to read the following
precautions before connecting the
charging cable to the vehicle and
charging the traction battery.

WARNING

Caution when charging

People with implantable cardiac pace-

makers or cardiac resynchronization

therapy-pacemakers should not

approach the vehicle while charging is

being performed. If it is necessary to

approach the vehicle, ask someone else

to do so.

Do not approach the onboard traction

battery charger, or charging cable

while charging is being performed.

Charging may affect the operation of

pacemakers.

Do not remain in the vehicle while

charging is being performed.

Charging may affect the operation of

pacemakers.

Do not enter the vehicle, even to

remove things from the luggage com-

partment while charging is being per-

formed.

Charging may affect the operation of

pacemakers.

When the charging cable is con-

nected to the vehicle

Do not operate the shift position.
In the unlikely event that the charging

cable has been damaged, the shift posi-

tion may change from P to other posi-

tions, it may cause the vehicle to move

unexpectedly, possibly leading to an

accident.

Charging precautions

115

2-2. Charging

ect
ric V
eh

icle

procedures. Charging should only be per-
formed by adults which properly under-
stand the charging procedures.



Do not allow children to use the
charging cable without supervision.
Also, keep the charging cable out of
reach of infants.



When charging with a charger,
make sure to follow the correct pro-
cedures for using each charger.



When charging using a public
charging station, check the setting
of the charging schedule function.

• If the charging schedule is set to “On”,

make sure to set it to “Off” or “Charge
Now” function to “On” before using a
public charging station. (



P.135)

• If the charging schedule is set to “On”,

charging will not start even if the AC
charging cable is connected. Also,
charging fee may occur due to the con-
nection of the AC charging cable.

Before performing charging make
sure that the following conditions are
met:



The parking brake is set. (



P.234)



The headlights the emergency flash-
ers and interior lights, etc., are
switched off.

If any of these lights are turned on, power
will be consumed by these features and
charging may take longer than normal.



The power switch is OFF.
(



P.224)

Before performing charging, make
sure that each part of the AC charging
cable is in good condition. (



P.92)

If the AC charging connector and DC

charging connector are used at the

same time

AC charging and DC charging cannot be

conducted simultaneously.
If the two connectors have been connected

to the vehicle, the battery will only be

charged through either one of the charging

modes that has started first. However, the

battery will not be recharged with the other

method even after the first mode is com-

pleted. To start the other mode, disconnect

the charging connector and then perform

the charging operation again.

Capacity reduction of the traction bat-

tery

The capacity of the traction battery will

decline gradually when the traction battery

is in use. The rate at which it declines will dif-

fer in accordance with environmental con-

ditions and the way in which the vehicle is

used. Observing the following can help

suppress the decline in the traction battery

capacity.

Avoid parking the vehicle in high tem-

perature areas, under direct sunlight

when the traction battery is fully charged.

Avoid accelerating and decelerating fre-

quently and suddenly.

Avoid frequent driving at high speed.

Use the charging schedule function as

much as possible in order to fully charged

the traction battery before starting off.

(



P.129)

Avoid frequent DC charging

Also, if the capacity of the traction battery
capacity reduces, the distance that can be
driven decreases. However, vehicle perfor-

Confirm the following before
charging

Inspecting the AC charging
cable

116

2-2. Charging

mance does not significantly become
worse.

When the remaining charge of the trac-

tion battery is low after charging

In the following situations, the remaining

charge of the traction battery after charging

completes may be less than normal in order

to protect the traction battery (the driving

range after the battery is fully charged may
be shorter).

Charging is performed when the outside

temperature is low or high

Charging is performed immediately after

high-load driving or in extreme heat

In any other situation, if the remaining
charge of the traction battery is significantly
lower than normal after charging com-
pletes, have the vehicle inspected by any
authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

: When this occurs, even if the remaining

charge display of the traction battery
shows that it is fully charged, the remain-
ing charge rapidly decreases faster than
normal.

How to use AC charging

This section explains the AC
charging procedure for the trac-
tion battery with the equipped AC
charging cable.
When using a public charging sta-
tion, make sure to check the opera-
tion instructions of the AC charger.
When the charging schedule is reg-
istered, make sure “Charge Now”
is turned on before charging.
(



P.135)

NOTICE

Handling the AC charging cable and

related parts

To prevent damage to the AC charging

cable and related parts, observe the fol-

lowing precautions.

When canceling charging or when

charging is completed, disconnect the

AC charging connector before dis-

connecting the plug from the electrical

socket.

When disconnecting the AC charging

connector, make sure that it is

unlocked.

Do not forcefully pull the AC charging

connector cap or AC charging inlet

cap.

Do not apply a vibration to the AC

charging connector while charging.

Charging may be stopped.

Do not insert anything but an AC

charging connector into the AC

charging inlet.

117

2-2. Charging

ect
ric V
eh

icle



P.114

Prepare the AC charging cable.



When using the Mode 2 AC
charging cable

Insert the plug of the AC charging
cable into the electrical socket of
the external power source.

Make sure to hold the body of the plug and

insert it firmly into the electrical socket. If

the electrical socket is equipped with a

remote switch, turn it on.
Check that the power indicator on the

CCID (Charging Circuit Interrupting

Device) is illuminated.
(If it is not illuminated, refer to P.143)
In order to reduce the load on the electri-

cal socket and plug, when inserting the

plug, use a string, etc., to hang the CCID

(Charging Circuit Interrupting Device) on

a hook or equivalent.
The CCID (Charging Circuit Interrupting

Device) can be hung by using the hole in

the back. Do not attach the CCID

(Charging Circuit Interrupting Device) to

the wall with screws.

NOTICE

When inserting the plug into or dis-

connecting the plug from the electrical

socket, make sure to hold the body of

the plug.

Do not damage the AC charging inlet

cap with a sharp object.

Do not forcefully pull the AC charging

cable if it is caught or entangled. If the

cable is entangled, disentangle it

before using.

Do not attempt to disassemble or

repair the AC charging inlet. Failure to

do so may cause an unexpected acci-

dent, resulting in serious injury. Please

contact any authorized Lexus retailer

or Lexus authorized repairer, or any

reliable repairer for repair and

replacement.

Confirm the following before
charging

When charging

118

2-2. Charging



When using the Mode 3 AC
charging cable (if equipped)

Remove the cap of the charging
plug and then connect the charging
plug to the charger.

When connecting the charging plug into

the charger, make sure that the identifica-

tion symbols are the same.
Make sure to hold the body of the charging

plug and insert it firmly and fully into the

charger.
Follow the instructions of the charger for

details regarding how to connect the AC

charging cable and how to start charging.

Depending on the charger, it may be nec-

essary to receive authorization to use it.

For details, refer to the information of the

charger.

Unlock AC charging port lid by
unlocking the doors. (



P.178)

Open the AC charging port lid
(right side of the vehicle). (



P.89)

The AC charging inlet light will illuminate.

Remove the AC charging inlet cap
and secure it as shown in the illus-
tration.

Remove the AC charging connec-
tor cap and secure it to the cable.

Make sure to hold the body of the
AC charging connector and insert

119

2-2. Charging

ect
ric V
eh

icle

it firmly and fully into the AC
charging inlet.

When connecting the AC charging con-

nector into the AC charging inlet, make

sure that the identification symbols are the

same.
When the AC charging connector is

inserted straight as far as possible, it will

automatically lock. Check that the AC

charging indicator illuminates. If the AC

charging indicator does not illuminate, the
AC charging connector is not locked.

: If the AC charging connector is not

firmly inserted, locking operation will be
performed several times.

Confirm that the AC charging indi-
cator is illuminated.

Charging will not start if the AC charging

indicator does not illuminate when the AC

charging connector is inserted. (



P.143)

Charging will not start if the AC charging

connector is not locked. However,

depending on the type of the charger of

the public charging station, the AC

charging connector will not be locked if

the operation to start the charging is not

performed.
If the AC charging indicator flashes, the

charging schedule has been registered.

(



P.120)

If the error warning indicator on the CCID

(Charging Circuit Interrupting Device)

flashes when the AC charging cable is

connected, check P.97 and follow the cor-

rection procedure.
The AC charging indicator will turn off

when charging is completed.

The AC charging indicator will also turn off

when charging is stopped for some reason

before completion. In this case, refer to

P.143

During AC charging

The charging starting time may differ

depending on vehicle conditions, but it

does not indicate a malfunction.

The surface of the CCID (Charging Cir-

cuit Interrupting Device) may become

hot, but it does not indicate a malfunction.

Depending on radio wave conditions,

interference may be heard on the radio.

The current charging condition and the

estimated time until charging completed

can be checked on the multi-information

display when a door is opened during

AC charging. (



P.113)

The surrounding area of the onboard

traction battery charger in the motor

compartment may become hot during

charging/after charging.

120

2-2. Charging

If the AC charging indicator flashes

after the AC charging connector is con-

nected

The charging schedule is registered and the

charging cannot be performed. To cancel

the charging schedule and start charging

immediately, perform any of the following:

Turn “Charge Now” to “On”. (



P.135)

While the AC charging indicator is flash-

ing, remove and reconnect the AC

charging connector within 5 seconds.

When using a AC charger with authen-

tication function at public charging sta-

tion

If the doors are unlocked during AC

charging, the AC charging connector will

be unlocked and the charging will be

stopped. In that case, the AC charger

authentication will be canceled and the

charging may not be able to restart. Recon-

nect the AC charging connector and per-

form the AC charger authentication.

When not using the vehicle for an

extended period of time



P.79

Charging time



P.109

Charging time may increase when



P.110

Safety functions

Charging will not start when the AC

charging connector is not locked. If the AC

charging indicator does not illuminate even

when the AC charging connector is

inserted, remove and reinsert the AC

charging connector, and check that the AC

charging indicator illuminates.

When the AC charging connector can-

not be connected to the AC charging

inlet



P.105

Changing the “Charging Current” set-

tings

Press

of the meter control

switches and select

on the multi-

information display.

Press

of the meter control

switches and select “Vehicle Settings”,

and then press “OK”.

Press

of the meter control

switches and select “Charging Settings”

and then press “OK”.

Press

of the meter control

switches and select “Charging Cur-

rent”, and then press “OK”.

Select “MAX”, “16A” or “8A”, and then

press “OK”.

The maximum current is restricted to the
selected upper limit value of 16A/8A

when charging. If the house breaker is

tripped when charging even with the upper

limit of the electric current changed, check

that the connected power supply satisfies

the required conditions to the charger.

: When charging current is restricted, the

time until the charge completed
becomes longer.

Changing the “Charging Limit” settings

The selected upper limit value is common to

AC charging and DC charging.

Press

of the meter control

switches and select

on the multi-

information display.

Press

of the meter control

switches and select “Vehicle Settings”,

and then press “OK”.

Press

of the meter control

switches and select “Charging Settings”

and then press “OK”.

Press

of the meter control

switches and select “Charging Limit”,

and then press “OK”.

121

2-2. Charging

ect
ric V
eh

icle

Select “Full” or “90%” and then press

“OK”.

When “90%” is selected, the upper limit of

the charge capacity will be restricted not to

exceed 90%.
If the setting is changed during DC

charging, charging may stop due to the

operation of the DC charger timer and the

traction battery cannot be fully charged.

WARNING

Caution when using AC charging

Observe the following precautions.
Failure to do so may cause an unex-

pected accident, resulting in death or

serious injury.

Connect the AC charging cable to a

power source suitable for charging.

(



P.107)

Make sure that the AC charging

cable, plug and electrical socket are

free of foreign matter and not

deformed or damaged.

Before charging, check that the AC

charging inlet does not have deforma-

tions, damage, corrosion, dirt and dust,

or other foreign materials such as

snow or ice attached to it. If anything is

attached to the inlet, be sure to com-

pletely remove the material before

connecting the AC charging connec-

tor.

Mode 3 AC charging cable: Before

inserting the charging plug into the

charger, make sure there is no dirt or

dust on the terminal areas. If there is

dirt or dust on these areas, remove it

completely before inserting the

charging plug.

Do not let the terminals of the AC

charging inlet get wet.

Only use electrical sockets where the

plug can be securely inserted.

Do not charge with the AC charging

cable bundled or coiled up otherwise it

may overheat.

Do not touch the terminals of the AC

charging connector or AC charging

inlet with sharp metal objects (needles

etc.) or hands, or short them with for-

eign objects.

When charging outdoors, make sure

to connect the plug to a raintight

socket that is certified for outdoor use.

Ensure the raintight cover closes com-

pletely. If the raintight cover cannot be

closed, replace a new one.

When using a AC charger, follow the

charging handling method to cancel

the charging.

If the AC charging cable or any

related parts become hot or emit any

smoke, strange smells or noise, stop

charging immediately.

Do not connect the plug of the AC

charging cable if the electrical socket

is submerged in water or snow.

When charging during rain or snow,

do not pull out or insert the plug with

wet hands. Also, do not get the electri-

cal socket and plug wet.

Do not charge the traction battery

when there is a possibility of lightning.

Be careful not to get the AC charging

cable caught in a side door or the back

door.

Do not drive over or park on the AC

charging cable, plug, AC charging

connector and CCID (Charging Cir-

cuit Interrupting Device).

Firmly insert the plug of the AC

charging cable into an electrical

socket.

Do not use an extension cord or con-

version plugs.

122

2-2. Charging

WARNING

Close the hood when using AC

charging. The cooling fans may sud-

denly start to run. Keep hands and

clothing (especially a tie, a scarf or a

muffler) away from the fans. Failure to

do so may cause the hands or clothing

to be caught, resulting in serious injury.

After connecting the AC charging

cable, confirm that it is not wound

around anything.

If the power indicator on the CCID

(Charging Circuit Interrupting

Device) does not illuminate after plug-

ging the AC charging cable into the

socket, unplug it immediately.

When connecting the AC charging

connector

Follow the handling procedures of the

AC charging cable to connect the AC

charging connector. If the connector is

not connected properly, the system can-

not recognize the connection, and it may

be possible to start the EV system. After

charging is completed, make sure to

remove the AC charging connector

from the AC charging inlet before start-

ing the EV system.
If the vehicle is started off with the con-

nector still connected, it could lead to an

accident, possibly resulting in death or

serious injury.

If the error warning indicator on the

CCID (Charging Circuit Interrupting

Device) illuminates or flashes during

charging

Electrical leakage may have been

detected in the power source circuit or

the AC charging cable or CCID

(Charging Circuit Interrupting Device)

may be malfunctioning. Refer to P.97

and follow the correction procedure. If

the error warning indicator does not turn

off even after performing the correction

procedure, immediately stop charging,

disconnect the AC charging cable and

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reli-

able repairer. Continuing to charge the

traction battery in this condition may lead

to an accident, possibly resulting in seri-

ous injury.

Onboard traction battery charger

The onboard traction battery charger is

located in the motor compartment.

Make sure to observe the following pre-

cautions regarding the onboard traction

battery charger. Failure to do so may

result in death or serious injury such as

burns and electric shocks.

The onboard traction battery charger

may become hot during charging. Do

not touch the onboard traction battery

charger, as doing so may result in

burns.

Do not disassemble, repair or modify

the onboard traction battery charger.

When the onboard traction battery

charger needs to be repaired, contact

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

NOTICE

When charging

Do not insert the plug of the AC

charging cable into the AC charging

inlet, as doing so may damage the AC

charging inlet.

123

2-2. Charging

ect
ric V
eh

icle

To prevent electrical shock, be sure to
remove by the following procedures.

Unlock the AC charging connec-
tor by unlocking the doors.
(



P.178)

The AC charging inlet light will illuminate.
If the AC charging connector is unlocked

during charging (while the AC charging

indicator is illuminated), AC charging will

be interrupted.

Make sure to hold the body of the
AC charging connector and pull it
towards you.

Install the AC charging connector
cap.

Install the AC charging inlet cap
and close the AC charging port lid.

Align the horizontal sections of the cap

and inlet, and then insert the cap straight

into the inlet.

NOTICE

Using an electric generator

Do not use an electric generator as a

power source for charging. If used, the

supplied voltage may be insufficient for

charging, charging may be unstable,

and/or the error warning indicator on

the CCID (Charging Circuit Interrupting

Device) of the AC charging cable may

flash.

Usable temperature range

Do not charge if the outside tempera-

ture is -30°C (-22°F) or below, as it is

likely that charging will take longer.

Do not leave the vehicle or the AC

charging cable in areas where the out-

side temperature is lower than -40°C

(-40°F).

Charging environment

Due to the environment in which the

power equipment is located, charging

may be unstable due to noise, the voltage

may be insufficient, and the error warn-

ing indicator on the CCID (Charging

Circuit Interrupting Device) of the AC

charging cable may flash.

Traction battery charge

When charging, if the supplied power is

low and the traction battery heater or

another high current function operates,

the driving range may be temporarily

decreased.

After charging

124

2-2. Charging



When using the Mode 2 AC
charging cable

Disconnect the plug of the AC
charging cable from the electrical
socket when the AC charging
cable will not be used for a long
period of time.

Hold the body of the plug when discon-

necting it.
Make sure to put the cable away immedi-

ately after disconnecting it. (



P.124)

When the plug is left connected to the

electrical socket, inspect the plug and

electrical socket once a month to check if

dirt and dust has accumulated.



When using the Mode 3 AC
charging cable (if equipped)

After removing the charging plug
from the charger, install the cap to
the charging plug.

Make sure to hold the body of the charging

plug when removing it.
Make sure to put the cable away immedi-

ately after disconnecting it. (



P.124)

When the outside temperature is low or

high

The needle of the SOC (State of Charge)

gauge (



P.161) may drop slightly when the

power switch is changed to ON, even if

charging has been completed and the trac-

tion battery is fully charged. However, this

does not indicate a malfunction.

When removing the AC charging con-

nector

Unlock the doors using the smart entry &

start system or wireless remote control to

unlock the AC charging connector, make

sure that the lock is released, and then pull

the AC charging connector towards you.

WARNING

After charging

Disconnect the plug from the electrical

socket if the AC charging cable will not

be used for a long time.
Dirt and dust may accumulate on the

plug or electrical socket, which could

cause a malfunction or fire, possibly lead-

ing to death or serious injury.

NOTICE

After charging

Store the AC charging cable out of

reach of infants and children.

After disconnecting the AC charging

connector from the AC charging inlet,

make sure to install the AC charging

inlet cap and AC charging connector

cap, and close the AC charging port

lid.

If either of these caps is not installed,

water or foreign matter may enter the

AC charging inlet and cause the vehi-

cle to malfunction.

After disconnecting the plug of the

AC charging cable from the electrical

socket, keep the AC charging cable in

a safe place free from moisture, dirt

and dust. The AC charging cable or

plug may be damaged if stepped on or

driven over by a vehicle.

125

2-2. Charging

ect
ric V
eh

icle



P.114

Unlock DC charging port lid by
unlocking the doors. (



P.178)

Open the DC charging port lid (left
side of the vehicle). (



P.89)

The DC charging inlet light will illuminate.

Remove the DC charging inlet cap
and secure it as shown in the illus-
tration.

How to use DC charging

This section explains the DC
charging procedure for the trac-
tion battery.
When using a DC charger, make
sure to check the operation
instructions of the DC charger.

WARNING

When using a DC charger

Observe the following precautions.

Failure to do so may cause an unex-

pected accident, resulting in death or

serious injury.

Use DC chargers conforming to

“CHAdeMO standard” at a public

charging station. DC charging cannot

use a DC charger that is not conform-

ing to the “CHAdeMO standard”.

Do not use the charging cable longer

than 30 meters.

Use DC charger with a charging cable

no longer than 30 meters.

Do not do charging with other charger
or other vehicle at the same time.

Confirm the following before
charging

When charging

Lexus UX 300e (2022 year). Manual in english - page 6
