Lexus UX (2022 year). Manual in english

353

5-6. Using the other interior features

rior f
eat
ur

The “Qi” symbol

The “Qi” symbol is a trademark of the
Wireless Power Consortium.

Name for all parts

Operation indicator light

Power supply switch

Charge area

Using the wireless charger

Press the power supply switch of
the wireless charger.

Pressing the switch again turns the wireless

charger off.
When turned on, the operation indicator

light (green) comes on.
When the power switch is turned off, the

on/off state of the wireless charger will be

memorized.

Place a portable device on the
charging area with its charging sur-
face facing down.

While charging, the operation indicator

light (orange) will be illuminated.
If charging does not begin, move the por-

table device as close to the center of the

charging area as possible.
When charging is complete, the operation

indicator light (green) will illuminate.

Recharging function



If a certain amount of time has
elapsed since charging completed
and the portable device has not
been moved, the wireless charger
will restart charging.



If the portable device is moved
within the charging area, charging
will stop temporarily then restart.

A
B
C

354

5-6. Using the other interior features

Operation indicator light status

: Depending on the portable device, the

operation indicator light may stay illumi-
nated (orange) after charging has com-
pleted.



If the operation indicator light blinks

If an error is detected, the operation indi-
cator light will blink (orange). Take the
appropriate measures according to the
table below.
• Blinks (orange) at a one second interval

continuously

• Blinks (orange) 3 times repeatedly

• Blinks (orange) 4 times repeatedly

The wireless charger can be operated

when

The power switch is in ACC or ON.

Portable devices that can be charged

Portable devices compatible with the Qi

wireless charging standard can be

charged by the wireless charger. How-

ever, compatibility with all devices which

meet the Qi wireless charging standard is

not guaranteed.

The wireless charger is designed to sup-

ply low power electricity (5 W or less) to

a cellular phone, smartphone, or other

portable device.

If a cover or accessory is attached to the

portable device

Do not charge a portable device if a cover

or accessory which is not Qi compatible is

attached. Depending on the type of cover

and/or accessory attached, it may not be

possible to charge the portable device. If

the portable device is placed on the

charging area and does not charge, remove

the cover and/or accessories.

Operation indicator

light

State

Off

The Wireless char-
ger is off

Green (illuminated)

Standby (charging is
possible)

Charging is com-
plete

Orange (illumi-
nated)

A portable device
has been placed on
the charging area
(identifying the por-
table device)

Charging in prog-
ress

Suspected causes

Measure

Vehicle to charger
communication fail-
ure.

Contact any autho-
rized Lexus retailer
or Lexus authorized
repairer, or any reli-
able repairer.

Suspected causes

Measure

A foreign object
exists between the
portable device and
charging area.

Remove the foreign
object.

Portable device is
not positioned prop-
erly on the charging
area.

Move the portable
device toward the
center of the
charging area.

Suspected causes

Measure

The temperature of
the wireless charger
is excessively high.

Stop charging
immediately and
continue charging
after a while.

355

5-6. Using the other interior features

rior f
eat
ur

If interference is heard in AM radio

broadcasts while charging

Turn off the wireless charger and check if

the noise is reduced. If noise is reduced,

press and hold the power supply switch of

the wireless charger for 2 seconds. The fre-

quency of the wireless charger is changed

and noise may be reduced. When the fre-

quency is changed, the operation indicator

light will blink (orange) 2 times.

Charging precautions

If the electronic key cannot be detected

in the cabin, charging cannot be per-

formed. When a door is opened and

closed, charging may be temporarily sus-

pended.

While charging, the wireless charger and

the portable device will become warm.

This is not a malfunction.

If a portable device becomes warm while

charging and charging stops due to the

protection function of the portable

device, wait until the portable device

cools down and charge it again.

Sound generated during operation

When the power supply switch is turned on

or while a portable device is being identi-

fied, operation sounds may be heard. This is

not a malfunction.

Cleaning the wireless charger



P.364

Label indicating precautions for using

the wireless charger

There is a label on the vehicle front side of

the wireless charger. Follow the instructions

on the label.

WARNING

Caution while driving

When charging a portable device while

driving, for safety reasons, the driver

should not operate the portable device.

Caution regarding interference with

electronic devices

People who use cardiac pacemakers

should use the wireless charger sepa-

rated from the installation part of the car-

diac pacemaker by 22 cm (8.7 in.) or

more.

To prevent damage or burns

Observe the following precautions.

Failure to do so may result in the possibil-

ity of fire, equipment failure or damage,

or burns due to heat.

Do not put any metallic objects

between the charging area and the

portable device while charging.

Do not place containers with liquid

such as water on the wireless charger.

Do not attach metallic objects, such as

aluminum stickers, to the charging

area.

Do not cover the wireless charger with

a cloth or other object while charging.

356

5-6. Using the other interior features

Fold down the armrest for use.

WARNING

Do not attempt to charge portable

devices which are not compatible with

the Qi wireless charging standard.

Do not disassemble, modify or remove

the wireless charger.

Do not apply force or impact to the

wireless charger.

NOTICE

Conditions in which the wireless

charger may not operate correctly

In the following situations, the wireless

charger may not operate correctly:

When a portable device is fully

charged

When there is a foreign object

between the charging area and porta-

ble device

When a portable device becomes hot

while charging

When a portable device is placed on

the charging area with its charging

surface facing up

When a portable device is not cen-

tered on the charging area

When the vehicle is near a TV tower,

electric power plant, gas station, radio

station, large display, airport or other

facility that generates strong radio

waves or electrical noise

When the portable device is in contact

with, or is covered by any of the follow-

ing metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have aluminum

foil inside

• Metallic wallets or bags

• Coins

• Metal hand warmers

• Media such as CDs and DVDs

When wireless keys (that emit radio

waves) other than those of your vehi-

cle are being used nearby.

If in situations other than above the wire-

less charger does not operate properly

or the operation indicator light is blink-

ing, the wireless charger may be mal-

functioning. Contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

To prevent failure or damage to data

Do not bring magnetic cards, such as a

credit card, or magnetic recording

media, close to the wireless charger

while charging. Otherwise, data may

be erased due to the influence of mag-

netism.

Additionally, do not bring precision

instruments such as wrist watches,

close to the wireless charger, as such

objects may malfunction.

Do not leave portable devices in the

cabin. The temperature inside the

cabin may become high when parked

in the sun, and cause damage to the

device.

To prevent 12-volt battery discharge

Do not use the wireless charger for a

long period of time with the hybrid sys-

tem is stopped.

Armrest

357

5-6. Using the other interior features

rior f
eat
ur

The coat hooks are provided with the
rear assist grips.

An assist grip installed on the ceiling
can be used to support your body

while sitting on the seat.

NOTICE

To prevent damage to the armrest

Do not apply too much load on the arm-

rest.

Coat hooks

WARNING

Items that must not be hung on the

hook

Do not hang coat hangers or other hard

or sharp objects on the hook. If the SRS

curtain shield airbags deploy, these items

may become projectiles, causing death

or serious injury.

Assist grips

WARNING

Assist grips

Do not use the assist grip when getting in

or out of the vehicle or rising from your

seat.

NOTICE

To prevent damage to the assist grip

Do not hang any heavy object or put a

heavy load on the assist grip.

359

ain

ten

ce a
nd

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting the vehi-

cle exterior................................

360

Cleaning and protecting the vehi-

cle interior .................................

363

6-2. Maintenance

Maintenance requirements..

366

6-3. Do-it-yourself maintenance

Do-it-yourself service precautions

........................................................

368

Hood ..............................................

370

Positioning a floor jack.............

371

Engine compartment...............

372

12-volt battery.............................

377

Tires ................................................

380

Tire inflation pressure..............

388

Wheels ..........................................

389

Air conditioning filter...............

390

Cleaning the hybrid battery (trac-

tion battery) air intake vent and
filter ..............................................

392

Electronic key battery.............

395

Checking and replacing fuses

........................................................

397

Light bulbs....................................

400

360

6-1. Maintenance and care

6-1.Maintenance and care



Working from top to bottom, liber-
ally apply water to the vehicle body,
wheel wells and underside of the
vehicle to remove any dirt and dust.



Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.



For hard-to-remove marks, use car
wash soap and rinse thoroughly with
water.



Wipe away any water.



Wax the vehicle when the water-
proof coating deteriorates.

If water does not bead on a clean surface,
apply wax when the vehicle body is cool.

Self-restoring coat

The vehicle body has a self-restoring coat-

ing that is resistant to small surface

scratches caused in a car wash, etc.

The coating lasts for 5 to 8 years from

when the vehicle is delivered from the

plant.

The restoration time differs depending on

the depth of the scratch and outside tem-

perature. The restoration time may

become shorter when the coating is

warmed by applying warm water.

Deep scratches caused by keys, coins,

etc., cannot be restored.

Do not use wax that contain abrasives.

Automatic car washes

Before washing the vehicle:

• Fold the mirrors

• Turn off the power back door (if

equipped)

Start washing from the front of the vehicle.
Extend the mirrors before driving.

Brushes used in automatic car washes

may scratch the vehicle surface, parts

(wheel, etc.) and harm your vehicle’s

paint.

Rear spoiler may not be washable in

some automatic car washes. There may

also be an increased risk of damage to

vehicle.

High pressure car washes

As water may enter the cabin, do not bring

the nozzle tip near the gaps around the

doors or perimeter of the windows, or spray

these areas continuously.

Note for a smart entry & start system (if

equipped)

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In that case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the key in a position 2 m (6 ft.) or

more separate from the vehicle while the

vehicle is being washed. (Take care to

ensure that the key is not stolen.)

• Set the electronic key to battery-saving

mode to disable the smart entry & start

system. (



P.146)

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a buzzer may sound outside the

vehicle and “Key Detected in Vehicle”

may be shown on the multi-information

display. To turn off the alarm, lock all the

doors.

Wheels and wheel ornaments

Remove any dirt immediately by using a

neutral detergent.

Wash detergent off with water immedi-

Cleaning and protecting the
vehicle exterior

Perform cleaning in a manner
appropriate to each component
and its material.

Cleaning instructions

361

6-1. Maintenance and care

ain

ten

ce a
nd

ately after use.

To protect the paint from damage, make

sure to observe the following precau-

tions.

• Do not use acidic, alkaline or abrasive

detergent.

• Do not use hard brushes.

• Do not use detergent on the wheels

when they are hot, such as after driving or

parking in hot weather.

Brake pads and calipers

Rust may form if the vehicle is parked with

wet brake pads or disc rotors, causing them

to stick. Before parking the vehicle after it is

washed, drive slowly and apply the brakes

several times to dry the parts.

Bumpers

Do not scrub with abrasive cleaners.

Front side windows water-repellent

coating

The following precautions can extend the

effectiveness of the water-repellent coat-

ing.

• Remove any dirt, etc., from the front side

windows regularly.

• Do not allow dirt and dust to accumulate

on the windows for a long period.

Clean the windows with a soft, damp cloth
as soon as possible.
• Do not use wax or glass cleaners that

contain abrasives when cleaning the win-

dows.

• Do not use any metallic objects to

remove condensation build up.

When the water-repellent performance

has become insufficient, the coating can

be repaired. Contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

Plated portions

If dirt cannot be removed, clean the parts as

follows:

Use a soft cloth dampened with an

approximately 5% solution of neutral

detergent and water to clean the dirt off.

Wipe the surface with a dry, soft cloth to

remove any remaining moisture.

To remove oily deposits, use alcohol wet

wipes or a similar product.

WARNING

When washing the vehicle

Do not apply water to the inside of the

engine compartment. Doing so may

cause the electrical components, etc. to

catch fire.

When cleaning the windshield (vehi-

cles with rain-sensing windshield wip-

ers)

Set the wiper switch to off.

If the wiper switch is in AUTO, the wipers

may operate unexpectedly in the follow-

ing situations, and may result in hands

being caught or other serious injuries

and cause damage to the wiper blades.

Off

AUTO

When the upper part of the windshield

where the raindrop sensor is located is

touched by hand

When a wet rag or similar is held close

to the raindrop sensor

If something bumps against the wind-

shield

If you directly touch the raindrop sen-

sor body or if something bumps into

the raindrop sensor

362

6-1. Maintenance and care

WARNING

Precautions regarding the exhaust

pipe

Exhaust gasses cause the exhaust pipe to

become quite hot.

When washing the vehicle, be careful not

to touch the pipe until it has cooled suffi-

ciently, as touching a hot exhaust pipe

can cause burns.

Precaution regarding the rear

bumper

If the paint of the rear bumper is chipped

or scratched, the following systems may

not function correctly. If this occurs, con-

sult any authorized Lexus retailer or

Lexus authorized repairer, or any reli-

able repairer.

Lexus Safety System + (if equipped)

BSM (if equipped)

RCTA (if equipped)

PKSB (if equipped)

NOTICE

To prevent paint deterioration and

corrosion on the body and compo-

nents (aluminum wheels, etc.)

Wash the vehicle immediately in the

following cases:

• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the

paint surface

• If dead insects, insect droppings or

bird droppings are present on the

paint surface

• After driving in an area contaminated

with soot, oily smoke, mine dust, iron

powder or chemical substances

• If the vehicle becomes heavily soiled

with dust or mud

• If liquids such as benzene and gasoline

are spilled on the paint surface

If the paint is chipped or scratched,

have it repaired immediately.

To prevent the wheels from corroding,

remove any dirt and store in a place

with low humidity when storing the

wheels.

Cleaning the exterior lights

Wash carefully. Do not use organic

substances or scrub with a hard brush.

This may damage the surfaces of the

lights.

Do not apply wax to the surfaces of the

lights.

Wax may cause damage to the lenses.

When using an automatic car wash

(vehicles with rain-sensing windshield

wipers)

Set the wiper switch to the off position.

If the wiper switch is in AUTO, the wipers

may operate and the wiper blades may

be damaged.

363

6-1. Maintenance and care

ain

ten

ce a
nd



Remove dirt and dust using a vac-
uum cleaner. Wipe dirty surfaces
with a cloth dampened with luke-
warm water.



If dirt cannot be removed, wipe it off
with a soft cloth dampened with
neutral detergent diluted to approx-
imately 1%.
Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.

Shampooing the carpets

There are several commercial foaming-

type cleaners available. Use a sponge or

brush to apply the foam. Rub in overlapping

circles. Do not use water. Wipe dirty sur-

faces and let them dry. Excellent results are

obtained by keeping the carpet as dry as

possible.

Handling the seat belts

Clean with mild soap and lukewarm water

using a cloth or sponge. Also check the

belts periodically for excessive wear, fray-

ing or cuts.

Front side windows with UV protective

coating (vehicles with UV protective

coating)

The front side windows have UV protective

coating. To prevent any damage to the UV

protective coating, observe the following:

NOTICE

When using a high pressure car wash

When washing the vehicle, do not

spray the camera or its surrounding

area directly with a high pressure

washer. Shock applied from high pres-

sure water may cause the device to not

operate normally.

Do not spray water directly on the

radar which is equipped behind the

emblem. Otherwise it may cause the

device to be damaged.

Do not bring the nozzle tip close to

boots (rubber or resin manufactured

cover), connectors or the following

parts. The parts may be damaged if

they come into contact with high-pres-

sure water.

• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

Keep the cleaning nozzle at least 30

cm (11.9 in.) away from the vehicle

body. Otherwise resin section, such as

moldings and bumpers, may be

deformed and damaged. Also, do not

continuously hold the nozzle in the

same place.

Do not spray the lower part of the

windshield continuously.

If water enters the air conditioning sys-

tem intake located near the lower part

of the windshield, the air conditioning

system may not operate correctly.

Do not wash the underside of the vehi-

cle using a high pressure car washer.

Cleaning and protecting the
vehicle interior

Perform cleaning in a manner
appropriate to each component
and its material.

Protecting the vehicle interior

364

6-1. Maintenance and care

If the windows are dirty, gently wipe them

with a cloth soaked in water or lukewarm

water as soon as possible.

If the windows are very dirty, do not open

and close them repeatedly.

WARNING

Water in the vehicle

Do not splash or spill liquid in the vehi-

cle, such as on the floor, in the hybrid

battery (traction battery) air intake

vent, and in the luggage compartment.

(



P.84)

Doing so may cause the hybrid bat-

tery, electrical components, etc., to

malfunction or catch fire.

Do not get any of the SRS components

or wiring in the vehicle interior wet.

(



P.38)

An electrical malfunction may cause

the airbags to deploy or not function

properly, resulting in death or serious

injury.

Vehicles with wireless charger: Do not

let the wireless charger (



P.352) get

wet. Failure to do so may cause the

charger to become hot and cause

burns or could cause electric shock

resulting in death or serious injury.

Cleaning the interior (especially

instrument panel)

Do not use a polish wax or polish cleaner.

The instrument panel may reflect off the

windshield, obstructing the driver’s view

and leading to an accident, resulting in

death or serious injury.

NOTICE

Cleaning detergents

Do not use the following types of

detergent, as they may discolor the

vehicle interior or cause streaks or

damage to painted surfaces:

• Non-seat portions: Organic sub-

stances such as benzene or gasoline,

alkaline or acidic solutions, dye, and

bleach

• Seats: Alkaline or acidic solutions,

such as thinner, benzene, and alcohol

Do not use a polish wax or polish

cleaner. The instrument panel’s or

other interior part’s painted surface

may be damaged.

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio sys-

tem may be damaged if water comes into

contact with electrical components such

as the audio system above or under the

floor of the vehicle. Water may also

cause the body to rust.

When cleaning the inside of the wind-

shield (vehicles with Lexus Safety

System +)

Do not allow glass cleaner to contact the

lens. Also, do not touch the lens.

(



P.220)

Cleaning the inside of the rear win-

dow

Do not use a glass cleaner to clean the

rear window, as this may cause dam-

age to the rear window defogger

heater wires or antenna. Use a cloth

dampened with lukewarm water to

gently wipe the window clean. Wipe

the window in strokes running parallel

to the heater wires or antenna.

Be careful not to scratch or damage

the heater wires or antenna.

365

6-1. Maintenance and care

ain

ten

ce a
nd



Remove dirt using a water-damp-
ened soft cloth or synthetic chamois.



Wipe the surface with a dry soft
cloth to remove any remaining
moisture.

Cleaning the areas with satin-finish

metal accents

The metal areas use a layer of real metal for

the surface. It is necessary to clean them

regularly. If dirty areas are left uncleaned

for long periods of time, they may be diffi-

cult to clean.

Cleaning the leather



Remove dirt and dust using a vac-
uum cleaner.



Wipe off any excess dirt and dust
with a soft cloth dampened with
diluted detergent.
Use a diluted water solution of
approximately 5% neutral wool
detergent.



Wring out any excess water from
the cloth and thoroughly wipe off all
remaining traces of detergent.



Wipe the surface with a dry, soft

cloth to remove any remaining
moisture.
Allow the leather to dry in a shaded
and ventilated area.

Cleaning the synthetic leather



Remove dirt and dust using a vac-
uum cleaner.



If the area gets dirty, wipe it off with
a soft cloth dampened with water
and wrung out.



If dirt cannot be removed by wiping
with water, wipe it off using cleaner
for leather.

Caring for leather areas

Lexus recommends cleaning the interior of

the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.

Dirt on the synthetic leather areas

Ingrained dirt which has been left

uncleaned for long periods of time is diffi-

cult to clean. Lexus recommends cleaning

the area regularly.

NOTICE

Cleaning the front side windows

Do not use any compound or abrasive

product (e.g., glass cleaner, detergent,

wax) to clean the windows. It may dam-

age the coating.

Cleaning the areas with satin-
finish metal accents

Cleaning the leather areas

NOTICE

Preventing damage to leather sur-

faces

Observe the following precautions to

avoid damage to and deterioration of

leather surfaces:

Remove any dust or dirt from leather

surfaces immediately.

Do not expose the vehicle to direct

sunlight for extended periods of time.

Park the vehicle in the shade, espe-

cially during summer.

Do not place items made of vinyl, plas-

tic, or containing wax on the uphol-

stery, as they may stick to the leather

surface if the vehicle interior heats up

significantly.

366

6-2. Maintenance

6-2.Maintenance

Where to go for maintenance service?

In order to maintain your vehicle in the best

possible condition, Lexus recommends that

maintenance service operations as well as

other inspections and repairs be carried out

by authorized Lexus retailers or Lexus

authorized repairers, or any reliable repair-

ers. For repairs and services covered by

your warranty, please visit an authorized

Lexus retailer or repairer, who will use gen-

uine Lexus parts in repairing any difficulties

you may encounter. There can also be

advantages in utilizing authorized Lexus

retailer or repairers for non-warranty

repairs and services, as members of the

Lexus network will be able to expertly assist

you with any difficulties you may encounter.

Your Lexus retailer or Lexus authorized

repairer, or any reliable repairer will per-

form all of the scheduled maintenance on

your vehicle reliably and economically due

to their experience with Lexus vehicles.

Scheduled maintenance should be
performed at specified intervals
according to the maintenance sched-
ule.

For full details of your maintenance sched-
ule, refer to the “Lexus Service Booklet” or
“Lexus Warranty Booklet”.

What about do-it-yourself mainte-
nance?

Many maintenance items are easy to do
yourself if you have a little mechanical abil-
ity and a few basic automotive tools.
Note, however, that some maintenance
tasks require special tools and skills. These
are best performed by qualified techni-
cians. Even if you’re an experienced do-it-
yourself mechanic, we recommend that
repairs and maintenance be conducted by
any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer. Any authorized Lexus retailer or
repairer will keep a record of maintenance,
which could be useful should you ever
require Warranty Service. Should you
choose to select a qualified and equipped
professional other than an authorized
Lexus repairer to service or maintain your
vehicle, we recommend that you request
that a record of maintenance be kept.

Does your vehicle need repairs?

Be on the alert for changes in performance

and sounds, and visual tip-offs that indicate

service is needed. Some important clues

are:

Engine missing, stumbling or pinging

Appreciable loss of power

Maintenance requirements

To ensure safe and economical
driving, day-to-day care and regu-
lar maintenance are essential.
Lexus recommends the following
maintenance:

WARNING

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble serious injury or death.

Handling of the 12-volt battery

12-volt battery posts, terminals and

related accessories contain lead and

lead compounds which are known to

cause brain damage. Wash your hands

after handling. (



P.377)

Scheduled maintenance

Do-it-yourself maintenance

367

6-2. Maintenance

ain

ten

ce a
nd

Strange engine noises

A fluid leak under the vehicle (However,

water dripping from the air conditioning

system after use is normal.)

Change in exhaust sound (This may indi-

cate a dangerous carbon monoxide leak.

Drive with the windows open and have

the exhaust system checked immedi-

ately.)

Flat-looking tires, excessive tire squeal

when cornering, uneven tire wear

Vehicle pulls to one side when driven

straight on a level road

Strange noises related to suspension

movement

Loss of brake effectiveness, spongy feel-

ing brake pedal, pedal almost touches the

floor, vehicle pulls to one side when brak-

ing

Engine coolant temperature continually

higher than normal (



P.99, 103)

If you notice any of these clues, take your
vehicle to any authorized Lexus retailer or
Lexus authorized repairer, or any reliable
repairer as soon as possible. Your vehicle
may need adjustment or repair.

368

6-3. Do-it-yourself maintenance

6-3.Do-it-yourself maintenance

Do-it-yourself service pre-
cautions

If you perform maintenance by
yourself, be sure to follow the cor-
rect procedure as given in these
sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(



P.377)

• Grease
• Conventional wrench

(for terminal clamp
bolts)

Engine/power
control unit
coolant level
(



P.374)

• “Toyota Super Long

Life Coolant” or a sim-
ilar high quality eth-
ylene glycol-based
non-silicate, non-
amine, non-nitrite and
non-borate coolant
with long-life hybrid
organic acid technol-
ogy
“Toyota Super Long
Life Coolant” is pre-
mixed with 50% cool-
ant and 50% deion-
ized water.

• Funnel (used only for

adding coolant)

Hybrid battery
(traction bat-
tery) air intake
vent (



P.392)

• Vacuum cleaner, etc.
• Phillips screwdriver

Engine oil level
(



P.373)

• “Toyota Genuine

Motor Oil” or equiva-
lent

• Rag or paper towel
• Funnel (used only for

adding engine oil)

Fuses
(



P.397)

• Fuse with same

amperage rating as
original

Light bulbs
(



P.400)

• Bulb with same num-

ber and wattage rat-
ing as original

Radiator and
condenser
(



P.375)

−

Tire inflation
pressure
(



P.388)

• Tire pressure gauge
• Compressed air

source

Washer fluid
(



P.376)

• Water or washer fluid

containing antifreeze
(for winter use)

• Funnel (used only for

adding water or
washer fluid)

WARNING

The engine compartment contains many

mechanisms and fluids that may move

suddenly, become hot, or become elec-

trically energized. To avoid death or seri-

ous injury, observe the following

precautions.

When working on the engine com-

partment

Make sure that “IGNITION ON” on

the multi-information display and the

“READY” indicator are both off.

Items

Parts and tools

369

6-3. Do-it-yourself maintenance

ain

ten

ce a
nd

WARNING

Keep hands, clothing and tools away

from the moving fan and engine drive

belt.

Be careful not to touch the engine,

power control unit, radiator, exhaust

manifold, etc., right after driving as

they may be hot. Oil and other fluids

may also be hot.

Do not leave anything that may burn

easily, such as paper and rags, in the

engine compartment.

Do not smoke, cause sparks or expose

an open flame to fuel. Fuel fumes are

flammable.

Take care because brake fluid can

harm your hands or eyes and damage

painted surfaces. If fluid gets on your

hands or in your eyes, flush the

affected area with clean water imme-

diately. If you still experience discom-

fort, consult a doctor.

When working near the electric cool-

ing fans or radiator grille

Be sure the power switch is OFF.

With the power switch in ON, the elec-

tric cooling fans may automatically start

to run if the air conditioning is on and/or

the coolant temperature is high.

(



P.375)

Safety glasses

Wear safety glasses to prevent flying or

falling material, fluid spray, etc., from get-

ting in your eyes.

NOTICE

If you remove the air cleaner filter

Driving with the air cleaner filter

removed may cause excessive engine

wear due to dirt in the air.

If the fluid level is low or high

It is normal for the brake fluid level to go

down slightly as the brake pads wear or

when the fluid level in the accumulator is

high.

If the reservoir needs frequent refilling, it

may indicate a serious problem.

Lexus UX (2022 year). Manual in english - page 20
