Lexus UX (2022 year). Manual in english - page 18

321

5-1. Remote Touch

rior f
eat
ur



Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.



Flick

Quick and long movement along the
touchpad with your finger. Move the list
screen.



Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

Menu screen

Press the “MENU” button on the
Remote Touch to display the menu
screen.
The displays shown in the illustrations
are used for example only and may dif-
fer from the actual vehicle.

NOTICE

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

Do not allow the Remote Touch to

come into contact with food, liquid,

stickers or lit cigarettes.

Do not subject the Remote Touch to

excessive pressure or strong impact.

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

Center Display overview

322

5-1. Remote Touch



10.3-inch display model



7-inch display model

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

: If equipped

: This function is not made available in

some countries or areas.

Split-screen display (10.3-inch display model)

Different information can be displayed on the left and right of the screen. For
example, the air conditioning system screen can be displayed and operated while
the fuel consumption information screen is being displayed. The large screen on
the left of the display is called the main display, and the small screen to the right is
called the side display.

Switch

Function

Select to display the destination
screen.

*1, 2

Select to display the audio con-
trol screen.

Select to display the hands-free
control screen.

Select to display the application
screen.

*1, 3

Select to display the home
screen of Apple CarPlay.

*1, 3

Select to display the home
screen of Android Auto.

*1, 3

Select to display the information
screen.

(



P.119)

Select to display the setup
screen.

Select to display the air condi-
tioning control screen. (



329)

Select to adjust the contrast and
brightness of the screens, turn
the screen off, etc.

*1, 2

Switch

Function

323

5-1. Remote Touch

rior f
eat
ur

Main display

For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Side display (10.3-inch display
model)

The following functions can be dis-
played and operated on the side dis-
play.

Select

to display the desired

screen.

Navigation system

Audio

Vehicle information

Air conditioning system (



P.329)

Show/hide the side display.

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B

C
D

324

5-2. Lexus Climate Concierge

5-2.Lexus Climate Concierge

Select

The indicator on the Lexus Climate Con-
cierge control screen illuminates, and the
automatic air conditioning system, seat
heaters and ventilators (if equipped), and
heated steering wheel (if equipped) oper-
ate in automatic mode.
If any of the system is operated manually,
the indicator turns off. However, all other
functions continue to operate in automatic
mode.

When using the Lexus Climate Con-

cierge

Lexus Climate Concierge can be operated

on the sub function menu or option control

screen. (



P.329)

Automatic air conditioning system
(



P.326)

The temperature can be adjusted inde-
pendently for the driver seat and pas-
senger seat.

Seat heaters and ventilators (if
equipped) (



P.335)

Heating or ventilation is automatically
selected according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc.
The seat heater and ventilator of the
front passenger seat operate in auto-
matic mode if a passenger is detected.

Heated steering wheel (if
equipped) (



P.335)

Heated steering wheel operates auto-
matically according to the set tem-
perature of the air conditioning system,
the outside temperature, etc.

Lexus Climate Concierge

The seat heaters (if equipped), seat
ventilators (if equipped) and heated
steering wheel (if equipped) are
each automatically controlled
according to the set temperature of
the air conditioning system, the out-
side and cabin temperature, etc.
Lexus Climate Concierge allows a
comfortable condition to be main-
tained without adjusting each sys-
tem.
Press the “MENU” button on the
Remote Touch and select “Cli-
mate” to display the air condition-
ing control screen. Then, select

to display the Lexus Climate Con-
cierge control screen.

Turning on Lexus Climate Con-
cierge

Operation of each system

325

5-2. Lexus Climate Concierge

rior f
eat
ur

Seat heater/ventilator operation

When automatic mode is selected using the

seat heater/ventilator switch, passenger

detection is not performed.

326

5-3. Using the air conditioning system and defogger

5-3.Using the air conditioning system and defogger

Left-hand side temperature control switch

Fan speed control switch

Automatic mode switch

Off switch

Windshield defogger switch

Rear window and outside rear view mirror defogger switch

Automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
Press the “MENU” button on the Remote Touch, then select “Climate” to dis-
play the air conditioning control screen. (



P.321)

10.3-inch display model: The air conditioning system can be displayed and
operated on the side display.
The illustrations below are for left-hand drive vehicles.
The button positions will differ for right-hand drive vehicles.

Air conditioning controls

A
B
C
D

E
F

327

5-3. Using the air conditioning system and defogger

rior f
eat
ur

Outside/recirculated air mode switch

Airflow mode control switch

Right-hand side temperature control switch

Adjusting the temperature setting

Operate the temperature control
switch upwards to increase the tem-
perature and downwards to decrease
the temperature.

Setting the fan speed

Operate the fan speed control switch
upwards to increase the fan speed and
downwards to decrease the fan speed.

Press the off switch to turn the fan off.

Change the airflow mode

Operate the airflow mode control
switch upwards or downwards.

The mode changes as follows each time
the switch is operated.

Air flows to the upper body.

Air flows to the upper body and
feet.

Air flows to the feet.

Air flows to the feet and the wind-
shield defogger operates.

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.

The mode switches between outside air
mode (the indicator is off) and recirculated
air mode (the indicator is on) each time the
switch is pressed.

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the windshield defogger switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press the
windshield defogger switch again when the
windshield is defogged.

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window and to remove raindrops, dew
and frost from the outside rear view
mirrors.
Press the rear window and outside
rear view mirror defogger switch.

The defoggers will automatically turn off

A
B

328

5-3. Using the air conditioning system and defogger

after a period of time.

Windshield wiper de-icer (if
equipped)



P.331

Fogging up of the windows

The windows will easily fog up when the

humidity in the vehicle is high. Selecting

“A/C” will dehumidify the air from the

outlets and defog the windshield effec-

tively.

If you turn “A/C” off, the windows may

fog up more easily.

The windows may fog up if the recircu-

lated air mode is used.

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

Outside/recirculated air mode

Setting to the recirculated air mode tem-

porarily is recommended in preventing

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

Outside/recirculated air mode may

automatically switch depending on the

temperature setting or the inside tem-

perature.

Registering air conditioning settings to

electronic keys (vehicles with driving

position memory)

Unlocking the vehicle using an electronic

key and turning the power switch to ON

will recall that key’s registered air condi-

tioning settings.

When the power switch is turned off, the

current air conditioning settings will auto-

matically be registered to the electronic

key that was used to unlock the vehicle.

The system may not operate correctly if

more than one electronic key is in the

vicinity or if the smart entry & start system

is used to unlock a passenger door.

The doors that can recall the air condi-

tioning setting when unlocked using the

smart entry & start system can be
changed.

For details, contact any autho-

rized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

: The doors that can recall the driving posi-

tion memory are changed at the same
time.

Operation of the air conditioning sys-

tem in Eco drive mode

In Eco drive mode, the air conditioning

system is controlled as follows to priori-

tize fuel efficiency

• Engine speed and compressor operation

controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic

mode is selected

To improve air conditioning perfor-

mance, perform the following operations

• Turn off eco air conditioning mode

(



P.329)

• Adjust the fan speed

• Turn off Eco drive mode

When the outside temperature is low

The dehumidification function may not

operate even when “A/C” is selected.

Ventilation and air conditioning odors

To let fresh air in, set the air conditioning

system to the outside air mode.

During use, various odors from inside

and outside the vehicle may enter into

and accumulate in the air conditioning

system. This may then cause odor to be

emitted from the vents.

To reduce potential odors from occur-

ring:

• It is recommended that the air condition-

ing system be set to outside air mode

prior to turning the vehicle off.

• The start timing of the blower may be

delayed for a short period of time imme-

diately after the air conditioning system is

started in automatic mode.

329

5-3. Using the air conditioning system and defogger

rior f
eat
ur

Air conditioning filter



P.390

Customization

Settings (e.g. A/C automatic mode switch

operation) can be changed.

(Customizable features:



P.487)

Main control screen

Using the touchpad of the Remote
Touch, select the button on the screen.

can be adjusted by perform-

ing the following operations.
Flick operation: Move the pointer to
the desired item and flick the touchpad
up or down.

The item can be adjusted by one level.

Trace operation: After selecting the
desired item, slide your finger up or
down.

The item can be adjusted by the amount
that you trace.
Trace operation cannot be used while driv-
ing.

Sub menu

Selecting the sub menu item to switch the
main screen.

: Display the air conditioning control

screen

: Display the heated steering

wheel/seat heater/seat ventilator control
screen (if equipped)

: Display the Lexus Climate Con-

cierge control screen

: Display the option control screen

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Select the air flow mode

: Air flows to the upper body

: Air flows to the upper body and feet

WARNING

To prevent the windshield from fog-

ging up

Do not use the windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

NOTICE

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

Air conditioning control screen

C
D

330

5-3. Using the air conditioning system and defogger

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Adjust the right-hand side tem-
perature setting

Function on/off indicators

When the function is on, the indicator illu-
minates on the control screen.

Sub function menu

When the sub function button on the
Remote Touch is pressed, the following
functions can be switched on and off.

: Set Lexus Climate Concierge

(



P.324)

“AUTO”: Set automatic mode on/off
(



P.332)

“Off”: Turn the fan off
“A/C”: Set cooling and dehumidification
function
“DUAL”: Adjust the temperature for driver
and front passenger seats separately
(“DUAL” mode) (



P.332)

: Changing the fan speed setting

during the automatic mode operation
(Blower customization)

: Set eco air conditioning mode

Option control screen

Select

on the sub menu to display

the option control screen.

The functions can be switched on and off.
When the function is on, the indicator illu-
minates on the screen.

Set Lexus Climate Concierge
(



P.324)

Adjusting the temperature for
driver and front passenger seats
separately (“DUAL” mode)
(



P.332)

Set eco air conditioning mode

Air conditioning and heater output is lim-
ited to prioritize fuel economy.

Cooling and dehumidification func-
tion

nanoe™ X

on/off

nanoe™ X is a nanoe™ generator.

Select front seat concentrated air-
flow mode (S-FLOW) (



P.333)

Prevent ice from building up on the
windshield and wiper blades
(Windshield wiper de-icer) (if
equipped)

: nanoe™ and the nanoe™ mark are

trademarks of Panasonic Corporation.

331

5-3. Using the air conditioning system and defogger

rior f
eat
ur

Side display (10.3-inch display
model)

Display the heated steering
wheel/seat heaters/seat ventilators
control screen (



P.337)

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Adjust the right-hand side tem-
perature setting

Set cooling and dehumidification
function on/off

Adjust the temperature for the
driver’s and front passenger’s seats
separately (“DUAL” mode)
(



P.332)

Select the air flow mode

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from

building up on the windshield and wiper

blades.
The windshield wiper de-icer will automati-
cally turn off after a period of time.

Eco air conditioning mode

When Eco drive mode is selected using the

driving mode select switch, eco air condi-

tioning mode turns on.

When a driving mode other than Eco drive

mode is selected, eco air conditioning

mode may turn off.

nanoe™ X

This vehicle incorporates a biocidal prod-

uct.
Ionised air generated by a device incorpo-

rated in the vehicle purifies the air in the

cabin by suppressing bacteria.
Active substances: Free radicals generated

in situ from ambient air or water.
nanoe™ helps to provide purified air by

emitting electrically charged water parti-

cles through the side vent on the driver’s
side

When the fan is turned on and nanoe™

on the option control screen is selected,

the nanoe™ X is activated.

When the fan is operated in the following

conditions, system performance will be

maximized. If the following conditions are

not met, performance will be limited.

• The ,

air

outlets

are

being used.

• The side vent on the driver’s side is open.

When nanoe™ is generated, a small

amount of ozone is emitted and may be

faintly smelled in some situations. How-

ever, this is approximately the same as

the amount that already exists in nature,

such as in forests, and it has no affect on

the human body.

A slight noise may be heard during oper-

ation. This is not a malfunction.

: nanoe™ X is a nanoe™ generator.

nanoe™ and the nanoe™ mark are
trademarks of Panasonic Corporation.

: According to temperature and humidity

conditions, fan speed and direction of
the air flow, nanoe™ system may not
operate at full capacity.

Blower customization

Fan speed setting during the automatic

mode operation can be customized.

C
D

332

5-3. Using the air conditioning system and defogger

To change the fan speed setting mode,
select

on the air conditioning con-

trol screen.

Each time

is selected, the fan speed

setting mode changes as follows.
“NORMAL”



“ECO”



“FAST”



“NORMAL”

Press the automatic mode switch
or select “AUTO” on the sub func-
tion menu (



P.329).

Adjust the temperature setting.

To stop the operation, press the off
switch or select “Off” on the sub
function menu (



P.329).

When in automatic mode, the air outlet

modes and fan speed levels are not
displayed in the air conditioning con-
trol panel display.
If the fan speed setting or air flow
modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other
than that operated is maintained.

Using automatic mode

Fan speed is adjusted automatically

according to the temperature setting and

the ambient conditions.

Therefore, the fan may stop for a while until

warm or cool air is ready to flow immedi-

ately after the automatic mode switch is

pressed or “AUTO” is selected.
Cool air may blow around the upper body

even when the heater is on due to sunlight.

To turn on the “DUAL” mode, perform
any of the following procedures:



Select “DUAL” on the sub function
menu. (



P.329)



Select “DUAL” on the option con-
trol screen.



Adjust the front passenger’s side
temperature setting.

The indicator comes on when the “DUAL”
mode is on.

Location of air outlets

The air outlets and air volume changes

WARNING

To prevent burns (vehicles with wind-

shield wiper de-icer)

Do not touch the glass at lower part of

the windshield or to the side of the front

pillars when the windshield wiper de-icer

is on.

nanoe™ X

Do not disassemble or repair the gener-

ator because it contains high voltage

parts. Contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer if the generator

needs repair.

NOTICE

To prevent damage to the nanoe™ X

Do not insert anything into the side vent

on the driver’s side, attach anything to it,

or use sprays around it. These things may

cause the generator not to work prop-

erly.

Using automatic mode

Adjusting the temperature for
driver and front passenger seats
separately (“DUAL” mode)

Air outlet layout and operations

333

5-3. Using the air conditioning system and defogger

rior f
eat
ur

according to the selected air flow
mode.

Adjusting the position of and open-
ing and closing the air outlets



Front

Direct air flow to the left or right, up or
down

Turn the knob to open or close the vent

Open the outlet

Close the outlet



Rear

Direct air flow to the left or right, up
or down

Turn the knob to open or close the
vent

This function automatically controls the
air conditioning airflow so that priority
is given to the front seats. When the
front passenger seat is not occupied,
airflow may switch to only the driver’s
seat. Unnecessary air conditioning is
suppressed, contributing to increased

WARNING

To prevent the windshield defogger

from operating improperly

Do not place anything on the instrument

panel which may cover the air outlets.

Otherwise, air flow may be obstructed,

preventing the windshield defoggers

from defogging.

Front seat concentrated airflow
mode (S-FLOW)

334

5-3. Using the air conditioning system and defogger

fuel efficiency.
Front seat concentrated airflow mode
operates in the following situations.



No passengers are detected in the
rear seats



The windshield defogger is not
operating

While operating,

illuminates.

Manually turning front seat con-
centrated airflow mode on/off

In front seat concentrated airflow
mode, directing airflow to the front
seats only and to all seats can be
switched via switch operation. When
the mode has been switched manually,
automatic airflow control stops operat-
ing.

Select

on the option control

screen (



P.330) and switch the air-

flow.



Indicator illuminated: Airflow to the
front seats only



Indicator off: Airflow to all the seats

Operation of automatic airflow control

In order to maintain a comfortable inte-

rior, airflow may be directed to seats

without passengers immediately after the

hybrid system is started and at other

times depending on the outside tempera-

ture.

After the hybrid system is started, if pas-

sengers move around inside or enter/exit

the vehicle, the system cannot accurately

detect the presence of passengers and

automatic airflow control will not oper-

ate.

Operation of manual airflow control

Even if the function is manually switched to

directing airflow to only the front seats,

when a rear seat is occupied, it may auto-

matically direct airflow to all seats.

To return to automatic airflow control

With the indicator off, turn the power

switch off.

After 60 minutes or more elapse, turn

the power switch to ON.

335

5-3. Using the air conditioning system and defogger

rior f
eat
ur

: If equipped

Turns the heated steering wheel on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (2 segments lit)



Lo (1

segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

The heated steering wheel can be used

when

The power switch is in ON.

Customization

Steering wheel heating preference in auto-

matic mode can be changed. (Customiza-

ble features:



P.487)

Heated steering wheel

/seat

heaters

/seat ventilators



Heated steering wheel

Warms up the grip of the steering
wheel



Seat heaters

Warm up the seat upholstery



Seat ventilators

Maintain good airflow on the seat
upholstery by sucking air into the
seats

Press the “MENU” button on the
Remote Touch and select “Climate”
to display the air conditioning con-
trol screen. Then, select

on the

sub menu (



P.329) to display the

heated steering wheel/seat heat-
ers/seat ventilators control screen.

WARNING

To prevent minor burn injuries

Care should be taken if anyone in the fol-

lowing categories comes in contact with

the steering wheel or seats when the

heater is on:

Babies, small children, the elderly, the

sick and the physically challenged

Persons with sensitive skin

Persons who are fatigued

Persons who have taken alcohol or

drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

NOTICE

To prevent damage to the seat heat-

ers and seat ventilators

Do not put heavy objects that have an

uneven surface on the seat and do not

stick sharp objects (needles, nails, etc.)

into the seat.

To prevent 12-volt battery discharge

Do not use the functions when the hybrid

system is off.

Heated steering wheel

336

5-3. Using the air conditioning system and defogger

Seat heaters

Turns the seat heaters on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (3 segments lit)



Mid

(2 segments lit)



Lo (1 segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

Seat ventilators

Turns the seat ventilators on/off

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO (lit)



Hi (3 segments lit)



Mid (2

segments lit)



Lo (1 segment lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

The seat ventilators can be used when

The power switch is in ON.

Air conditioning system-linked control

mode

When the seat ventilator fan speed level is

Hi, the seat ventilator fan speed becomes

higher according to the fan speed of the air

conditioning system.

Customization

Settings for the seat heaters and ventilators

can be changed. (Customizable features:



P.487)

Main display

Using the touchpad of the Remote
Touch, select the button on the screen.

can be adjusted by perform-

ing the following operations.
Flick operation: Move the pointer to
the desired item and flick the touchpad
up or down.

The item can be adjusted by one level.

Trace operation: After selecting the
desired item, trace the pad surface.

The item can be adjusted by the amount
that you trace.

Seat heaters and ventilators
(front seats)

WARNING

To prevent causes of overheating and

minor burn injuries

Observe the following precautions when

using the seat heaters.

Do not cover the seat with a blanket or

cushion when using the seat heater.

Do not use seat heater more than nec-

essary.

Control screen

Content .. 16 17 18 19 ..
