109

3-3. Adjusting the seats

fore
driving

The seat and steering wheel

are auto-

matically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the driver’s seat and steer-
ing wheel

are automatically adjusted

to a position that allows driver to enter
and exit the vehicle easily.



The shift lever has been shifted to P.



The engine switch has been turned
off.



The driver’s seat belt has been
unfastened.

When any of the following has been
performed, the driver’s seat and steer-

ing wheel

automatically return to their

original positions.



The engine switch has been turned
to ACCESSORY mode or IGNI-
TION ON mode.



The driver’s seat belt has been fas-
tened.

: Power type

■

Operation of the power easy access sys-

tem

When exiting the vehicle, the power easy

access system may not operate if the seat is

already close to the rear position, etc.

■

Customization

Some functions can be customized.

(



P.354)

Check that the shift lever is in P.

Turn the engine switch to IGNI-
TION ON mode.

Adjust the driver’s seat, steering
wheel, and outside rear view mir-
rors to the desired positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

Power easy access sys-
tem/driving position mem-
ory/memory recall function

This feature automatically adjusts
the driver’s seat, steering wheel
and outside rear view mirrors to
make entering and exiting the vehi-
cle easier or to suit your prefer-
ences.

Power easy access system

Recording a driving position into
memory

110

3-3. Adjusting the seats

will be overwritten.

Check that the shift lever is in P.

Turn the engine switch to IGNI-
TION ON mode.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

■

Seat positions that can be memorized

(



P.107)

The adjusted positions other than the posi-

tion adjusted by lumbar support switch can

be recorded.

■

Operating the driving position memory

after turning the engine switch off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to register,
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Check that the shift lever is in P.

Turn the engine switch to IGNI-
TION ON mode.

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

Registering/canceling/recall a
driving position to an electronic
key (including a card key) (mem-
ory recall function)

111

3-3. Adjusting the seats

fore
driving

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Cancelation procedure

Carry only the key you want to cancel
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be canceled
properly.

Turn the engine switch to IGNI-
TION ON mode.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-

ing position, and then unlock and
open the driver’s door using the
smart entry & start system or wire-
less remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel). However, the seat will move to

a position slightly behind the recorded

position in order to make entering the vehi-

cle easier.
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the engine switch to ACCES-
SORY mode or IGNITION ON
mode, or fasten a seat belt.

The seat and steering wheel will move to

the recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If a door other than the driver’s door is

unlocked with the smart entry & start sys-

tem, the driving position cannot be

recalled. In this case, press the driving

position button which has been set.

■

Customization

Some functions can be customized.

(



P.354)

112

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors



Manual type

Hold the steering wheel and push
the lever down.

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.



Power type

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The steering wheel can be adjusted

when (power type)

The engine switch is in ACCESSORY or
IGNITION ON mode

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of engine switch mode.

■

Automatic adjustment of the steering

position (power type)

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.109)

■

Power easy access system (power type)

The steering wheel and driver’s seat move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.109)

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.
Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

113

3-4. Adjusting the steering wheel and mirrors

fore
driving

To sound the horn, press on or close to
the

mark.

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function

WARNING

■

After adjusting the steering wheel

(manual type)

Make sure that the steering wheel is

securely locked.
Otherwise, the steering wheel may move

suddenly, possibly causing an accident,

and resulting in death or serious injury.

Also, the horn may not sound if the steer-

ing wheel is not securely locked.

Horn

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.
Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

114

3-4. Adjusting the steering wheel and mirrors

mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the engine switch is turned to IGNI-
TION ON mode.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

■

To prevent sensor error

To ensure that the sensors operate properly,

do not touch or cover them.

To select a mirror to adjust, press
the switch.

Left
Right

Pressing the same switch again will put the

switch in neutral.

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

■

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A
B

115

3-4. Adjusting the steering wheel and mirrors

fore
driving

To adjust the mirror, press the
switch.

Up
Right
Down
Left

■

Mirror angle can be adjusted when

The engine switch is in ACCESSORY or

IGNITION ON mode.

■

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.231)

■

Auto anti-glare function (if equipped)

When the anti-glare inside rear view mirror

is set to automatic mode, the outside rear

view mirrors will activate in conjunction with

the anti-glare inside rear view mirror to

reduce reflected light. (



P.113)

■

Automatic adjustment of the mirror

angle

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.109)

■

Linked mirror function when reversing

(if equipped)

When either “L” or “R” of the mirror select

switch is selected, the outside rear view mir-

rors will automatically angle downwards

when the vehicle is reversing in order to

give a better view of the ground.
To disable this function, select neither “L”

nor “R”.
To set the mirror angle used when the vehi-

cle is reversing, adjust the mirror angle at a

desired position with the shift lever in R.
The adjusted angle will be memorized and

the mirror will automatically tilt to the mem-

orized angle whenever the shift lever is

shifted to R from next time.
The memorized downward tilt position of

the mirror is linked to the normal position

(angle adjusted with the shift lever in other

than R). Therefore, if the normal position is

changed after adjustment, the tilt position

will also change.
When the normal position is changed, read-

just the angle in reversing.

■

Using the switch

Press the switch to fold the mirrors.

Press it again to extend them to the original
position.

A
B
C
D

WARNING

■

When the mirror defoggers are oper-

ating

Do not touch the rear view mirror sur-

faces, as they can become very hot and

burn you.

Folding and extending the mir-
rors

116

3-4. Adjusting the steering wheel and mirrors

■

Setting automatic mode (if
equipped)

Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator

will come on.

Pressing the switch once more will return
to manual mode.

■

When disconnecting and reconnecting

battery terminals (vehicles with an auto-

matic folding/extending mirror func-

tion)

The automatic folding/extending mirror

function will return to off as default. To turn

the function on, press the switch again to

select on.

■

Using automatic mode in cold weather

(if equipped)

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this case, remove any ice and

snow from the door mirror, then either

operate the mirror using manual mode or

move the mirror by hand.

■

Customization

Some functions can be customized.

(



P.354)

WARNING

■

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

117

3-5. Opening, closing the windows and moon roof

fore
driving

3-5.Opening, closing the windows and moon roof

The power windows can be opened
and closed using the switches.
Operating the switch moves the win-
dows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway, operate the

switch in the opposite direction.

■

The power windows can be operated

when

The engine switch is in IGNITION ON

mode.

■

Operating the power windows after

turning the engine off

The power windows can be operated for

approximately 45 seconds after the engine

switch is turned to ACCESSORY mode or

turned off. They cannot, however, be oper-

ated once either door is opened.

■

Jam protection function

If an object becomes jammed between the

window and the window frame while the

window is closing, window movement is

stopped and the window is opened slightly.

■

Catch protection function

If an object becomes caught between the

door and window while the window is open-

ing, window movement is stopped.

■

When the window cannot be opened or

closed

When the jam protection function or catch

protection function operates unusually and

the door window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

●

Stop the vehicle. With the engine switch

in IGNITION ON mode, within 4 sec-

onds of the jam protection function or

catch protection function activating, con-

tinuously operate the power window

switch in the one-touch closing direction

or one-touch opening direction so that

the door window can be opened and

closed.

●

If the door window cannot be opened

and closed even when performing the

above operations, perform the following

procedure for function initialization.

Turn the engine switch to IGNITION

ON mode.

Pull and hold the power window switch

in the one-touch closing direction and

completely close the door window.

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

Press and hold the power window

switch in the one-touch opening direc-

tion. After the door window is com-

pletely opened, continue holding the

switch for an additional 1 second or

more.

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

Pull and hold the power window switch

in the one-touch closing direction

again. After the door window is com-

Power windows

Opening and closing the power
windows

118

3-5. Opening, closing the windows and moon roof

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

closed or opened, have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer.

■

Door lock linked window operation

●

The power windows can be opened and
closed using the mechanical key.

(



P.336)

●

The power windows can be opened and

closed using the wireless remote con-
trol.

(



P.96)

: These settings must be customized at

any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Power windows open warning buzzer

A buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the engine switch

is turned off and the driver’s door is opened

with the power windows open.

■

Customization

Some functions can be customized.

(



P.354)

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.119)

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

●

When exiting the vehicle, turn the

engine switch off, carry the key and

exit the vehicle along with the child.

There may be accidental operation,

due to mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

119

3-5. Opening, closing the windows and moon roof

fore
driving

This function can be used to prevent
children from accidentally opening or
closing a passenger window.
Press the switch.

The indicator

will come on and the pas-

senger windows will be locked.
The passenger window can still be opened
and closed using the driver’s switch even if
the lock switch is on.

■

When the battery is disconnected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the battery.

: If equipped

■

Opening and closing

Opens the moon roof

The moon roof tilts up and then fully opens.

Closes the moon roof

: Lightly press either way of the moon roof

switch to stop the moon roof partway.

■

Tilting up and down

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either way of the moon roof

WARNING

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

●

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental operation
(window lock switch)

Moon roof

Use the overhead switches to open
and close the moon roof and tilt it
up and down.

Operating the moon roof

120

3-5. Opening, closing the windows and moon roof

switch to stop the moon roof partway.

■

The moon roof can be operated when

The engine switch is in IGNITION ON

mode.

■

Operating the moon roof after turning

the engine off

The moon roof can be operated for approx-

imately 45 seconds after the engine switch

is turned to ACCESSORY mode or turned

off. It cannot, however, be operated once

either door is opened.

■

Jam protection function

If an object is detected between the moon

roof and the frame while the moon roof is

closing or tilting down, travel is stopped and

the moon roof opens slightly.

■

Sunshade

The sunshade can be opened and closed

manually. However, the sunshade will open

automatically when the moon roof is

opened.

■

Door lock linked moon roof operation

●

The moon roof can be opened and
closed using the mechanical key.

(



P.336)

●

The moon roof can be opened and

closed using the wireless remote con-
trol.

(



P.94)

: These settings must be customized at

any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

If the moon roof does not close normally

Perform the following procedure:

Stop the vehicle.

Press and hold the “CLOSE” switch.

The moon roof will close, reopen and pause

for approximately 10 seconds. Then it will

close again and stop at the completely

closed position.

Check to make sure that the moon roof

is completely closed and then release

the switch.

: If the switch is released at the incorrect

time, the procedure will have to be per-
formed again from the beginning.

If the moon roof does not fully close even

after performing the above procedure cor-

rectly, have the vehicle inspected by any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

■

If the moon roof does not move normally

If the moon roof does not open or close

normally or the automatic opening function

does not operate, perform the following ini-

tialization procedure.

Turn the engine switch to IGNITION

ON mode.

Operate the moon roof.

Depending on the kind of malfunction per-

form either of the following:



If the moon roof does not open when the

“OPEN” switch is pressed

Press and hold the “DOWN” switch or

“CLOSE” switch until the moon roof is

completely closed.

The moon roof will open and close a few

times before it closes completely.

Confirm that the moon roof has com-

pletely stopped and release the switch.



If the moon roof does not open com-

pletely automatically even though it tilts

up and opens while the “OPEN” switch is

being pressed and held

Press and hold the “OPEN” switch until

the moon roof opens completely.

Press and hold the “CLOSE” switch

until the moon roof closes completely.

Press and hold the “UP” switch until the

moon roof tilts up and stops.

Press and hold the “DOWN” switch

until the moon roof tilts down and stops

at the completely closed position.

If you release the switch while the moon

roof is moving, perform the procedure

again from the beginning.
If, after performing the above procedures

correctly, the moon roof still does not open

or close normally or the automatic opening

function does not operate, have the vehicle

121

3-5. Opening, closing the windows and moon roof

fore
driving

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer.

■

Moon roof open warning buzzer

A buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the engine switch

is turned off and the driver’s door is opened

with the moon roof open.

■

Customization

Some functions can be customized.

(



P.354)

WARNING

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

■

Opening the moon roof

●

Do not allow any passengers to put

their hands or heads outside the vehi-

cle while it is moving.

●

Do not sit on top of the moon roof.

■

Opening and closing the moon roof

●

The driver is responsible for moon roof

opening and closing operations. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the moon roof. It is possible for

children and other passengers to have

body parts caught in the moon roof.

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the moon roof is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the moon roof, operate the moon roof

after checking to make sure that there

is no possibility of any passenger hav-

ing any of their body parts caught in

the moon roof. Also, do not let a child

operate moon roof by the wireless

remote control or mechanical key. It is

possible for children and other passen-

gers to get caught in the moon roof.

●

When exiting the vehicle, turn the

engine switch off, carry the key and

exit the vehicle along with the child.

There may be accidental operation,

due to mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

122

3-5. Opening, closing the windows and moon roof

WARNING

●

The jam protection function may not

work if something gets caught just

before the moon roof is fully closed.

Also, the jam protection function is not

designed to operate while the moon

roof switch is being pressed. Take care

so that your fingers, etc. do not get

caught.

NOTICE

■

To prevent damage to the moon roof

●

Before opening, make sure that there

are no foreign objects such as stones

or ice around the opening.

●

Do not hit the face or edge of the

moon roof with hard objects.

■

Operating the moon roof

There is the possibility that water or rain

will get into the vehicle if you operate the

moon roof after a rainfall, snowfall or car

wash. Wipe the moon roof dry with a

cloth before operating it.

123

Driving

4-1. Before driving

Driving the vehicle.....................

124

Cargo and luggage...................

130

Trailer towing................................

131

4-2. Driving procedures

Engine (ignition) switch ...........

132

Automatic transmission...........

135

Turn signal lever .........................

140

Parking brake ...............................

141

ASC (Active Sound Control)

..........................................................

141

4-3. Operating the lights and wipers

Headlight switch.........................

142

AHB (Automatic High Beam)

.........................................................

144

Fog light switch ...........................

147

Windshield wipers and washer

.........................................................

147

4-4. Refueling

Opening the fuel tank cap......

153

4-5. Using the driving support sys-

tems

Lexus Safety System + .............

156

PCS (Pre-Collision System) ..

161

LDA (Lane Departure Alert with

steering control)......................

168

RSA (Road Sign Assist)...........

175

Dynamic radar cruise control

.........................................................

179

Cruise control .............................

187

BSM (Blind Spot Monitor).....

190

Lexus parking assist-sensor ..

198

Driving mode select switch ..

204

Launch control...........................

205

Active rear wing........................

207

TVD (Torque Vectoring Differen-

tial).................................................

210

Exhaust Gas Filter system........

211

Driving assist systems ...............

212

4-6. Driving tips

Winter driving tips......................

217

124

4-1. Before driving

4-1.Before driving

■

Starting the engine



P.132

■

Driving

With the brake pedal depressed,
shift the shift lever to D. (



P.135)

Release the parking brake.
(



P.141)

Gradually release the brake pedal
and gently depress the accelerator
pedal to accelerate the vehicle.

■

Stopping

With the shift lever in D, depress the
brake pedal.

If necessary, set the parking brake.

If the vehicle is to be stopped for an

extended period of time, shift the shift lever

to P or N. (



P.135)

■

Parking the vehicle

With the shift lever in D, depress the
brake pedal.

Set the parking brake (



P.141), and

shift the shift lever to P (



P.135).

Press the engine switch to stop the
engine.

Lock the door, making sure that you
have the electronic key on your
person.

If parking on a hill, block the wheels as

needed.

■

Starting off on a steep uphill

Make sure that the parking brake is
set and shift the shift lever to D.

Gently depress the accelerator
pedal.

Release the parking brake.

■

When starting off on an uphill

The hill-start assist control will activate.

(



P.212)

■

Driving in the rain

●

Drive carefully when it is raining, because

visibility will be reduced, the windows

may become fogged-up, and the road

will be slippery.

●

Drive carefully when it starts to rain,

because the road surface will be espe-

cially slippery.

●

Refrain from high speeds when driving on

an expressway in the rain, because there

may be a layer of water between the tires

and the road surface, preventing the

steering and brakes from operating prop-

erly.

■

Engine speed while driving

In the following conditions, the engine

speed may become high while driving. This

is due to automatic up-shifting control or

down-shifting implementation to meet driv-

ing conditions. It does not indicate sudden

acceleration.

●

The vehicle is judged to be driving uphill

or downhill

●

When the accelerator pedal is released

●

When the brake pedal is depressed while

sport mode is selected

■

Restraining the engine output (Brake

Override System)

●

When the accelerator and brake pedals

are depressed at the same time, the

engine output may be restrained.

●

A warning message is displayed on the

Driving the vehicle

The following procedures should be
observed to ensure safe driving:

Driving procedure

Content .. 4 5 6 7 ..
