199

4-5. Using the driving support systems

Driving

■

TRAC (Traction Control)

Helps to maintain drive power and pre-
vent the drive wheels from spinning
when starting the vehicle or accelerat-
ing on slippery roads

■

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

■

VGRS (Variable Gear Ratio Steer-
ing) (if equipped)

Adjusts the front wheel turning angle in
accordance with the vehicle speed and
steering wheel movement

■

DRS (Dynamic Rear Steering) (if
equipped)

Contributes to the turning characteris-
tics and responsiveness of the vehicle
by adjusting the rear wheel angle of the
vehicle in accordance with steering
wheel movement.

■

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

■

Adaptive Variable Suspension Sys-
tem (if equipped)

By independently controlling the
damping force of the shock absorbers
for each of the 4 wheels according to
the road and driving conditions, this
system combines riding comfort with
superior vehicle stability, and helps
good vehicle posture.

■

LDH (Lexus Dynamic Handling
system) (if equipped)

Provides integrated control of the
VGRS, DRS and EPS. Contributes to
turning characteristics at low speeds,
responsiveness at medium speeds and
safety at high speeds by controlling the
steering angle of the front and rear
wheels in accordance with the steering
wheel operation and vehicle speed.

■

VDIM (Vehicle Dynamics Inte-
grated Management)

Provides integrated control of the
ABS, brake assist, TRAC, VSC,
hill-start assist control, EPS and VGRS
systems
Helps to maintain vehicle stability when
swerving on slippery road surfaces by
controlling the brakes, engine output,
steering assist, and steering ratio

■

When the TRAC/VSC systems are

operating

The slip indicator light will flash while the

TRAC/VSC systems are operating.

■

Disabling the TRAC system

If the vehicle gets stuck in mud, dirt or snow,

the TRAC system may reduce power from
the engine to the wheels. Pressing the

switch to turn the system off may make it

easier for you to rock the vehicle in order to

free it.
To turn the TRAC system off, quickly press

200

4-5. Using the driving support systems

and release the

switch.

The “Traction Control Turned Off” will be
shown on the multi-information display.

Press the

switch again to turn the sys-

tem back on.

■

Turning off both TRAC and VSC sys-

tems

To turn the TRAC and VSC systems off,
press and hold the

switch for more

than 3 seconds while the vehicle is stopped.
The VSC OFF indicator light will come on
and the “Traction Control Turned Off” will
be shown on the multi-information display.

Press the

switch again to turn the sys-

tems back on.

: On vehicles with PCS (Pre-Collision

System), pre-collision brake assist,
pre-collision braking, and steering con-
trol (performed through cooperative
control of PCS and LDH) (if equipped)
will also be disabled. The Pre-Collision
System warning light will come on and a
message will be displayed on the
multi-information display. (



P.166)

■

When the message is displayed on the

multi-information display showing that

TRAC has been disabled even if the

switch has not been pressed

TRAC is temporary deactivated. If the infor-

mation continues to show, contact your

Lexus dealer.

■

Operating conditions of hill-start assist

control

When the following four conditions are met,

the hill-start assist control will operate:

●

The shift lever is in a position other than P

or N (when starting off forward/back-

ward on an upward incline).

●

The vehicle is stopped.

●

The accelerator pedal is not depressed.

●

The parking brake is not engaged.

●

Engine switch is turned to IGNITION

ON mode

■

Automatic system cancelation of

hill-start assist control

The hill-start assist control will turn off in any

of the following situations:

●

The shift lever is moved to P or N.

●

The accelerator pedal is depressed.

●

The parking brake is engaged.

●

2 seconds at maximum elapsed after the

brake pedal is released

●

Engine switch is turned to off

■

VGRS is disabled when

VGRS may stop operating in the following

situations.

In this event, the steering wheel may move

from its straight forward position, but it will

return when the system restarts.

●

When the steering wheel is operated for

an extended period of time while the

vehicle is stopped or is moving very

slowly

(on vehicles with LDH, DRS is disabled

together with VGRS)

●

When the steering wheel has been held

fully to the left or right

The center position of the steering wheel

may change when VGRS is disabled. How-

201

4-5. Using the driving support systems

Driving

ever, the position will return to normal after

VGRS is reactivated.

■

When the battery is disconnected (vehi-

cles with VGRS)

The steering wheel may move from its

straight forward position, but this will be

corrected automatically when driving.

■

Sounds and vibrations caused by the

ABS, brake assist, VSC, TRAC, hill-start

assist control and VGRS systems

●

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the engine is

started or just after the vehicle begins to

move. This sound does not indicate that a

malfunction has occurred in any of these

systems.

●

Any of the following conditions may

occur when the above systems are oper-

ating. None of these indicates that a mal-

function has occurred.

• Vibrations may be felt through the vehicle

body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

• The brake pedal may pulsate slightly after

the ABS is activated.

• The brake pedal may move down slightly

after the ABS is activated.

■

EPS, VGRS and DRS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

■

Automatic reactivation of TRAC/VSC

systems

After turning the TRAC and VSC systems

off, the systems will be automatically

re-enabled in the following situations:

●

When the engine switch is turned off

●

If only the TRAC system is turned off, the

TRAC will turn on when vehicle speed

increases

If both the TRAC and VSC systems are
turned off, automatic re-enabling will not
occur when vehicle speed increases.

■

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

steering input or stop the vehicle and turn

the engine off. The EPS system should

return to normal within 10 minutes.

WARNING

■

The ABS does not operate effectively

when

●

The limits of tire gripping performance

have been exceeded (such as exces-

sively worn tires on a snow covered

road).

●

The vehicle hydroplanes while driving

at high speed on wet or slick roads.

■

Stopping distance when the ABS is

operating may exceed that of normal

conditions

The ABS is not designed to shorten the

vehicle’s stopping distance. Always main-

tain a safe distance from the vehicle in

front of you, especially in the following

situations:

●

When driving on dirt, gravel or

snow-covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with potholes

or uneven surfaces

■

TRAC/VSC may not operate effec-

tively when

Directional control and power may not

be achievable while driving on slippery

road surfaces, even if the TRAC/VSC

system is operating. Drive the vehicle

carefully in conditions where stability and

power may be lost.

202

4-5. Using the driving support systems

WARNING

■

Hill-start assist control does not oper-

ate effectively when

●

Do not overly rely on hill-start assist

control. Hill-start assist control may

not operate effectively on steep

inclines and roads covered with ice.

●

Unlike the parking brake, hill-start

assist control is not intended to hold

the vehicle stationary for an extended

period of time. Do not attempt to use

hill-start assist control to hold the vehi-

cle on an incline, as doing so may lead

to an accident.

■

When the TRAC/VSC is activated

The slip indicator light flashes. Always

drive carefully. Reckless driving may

cause an accident. Exercise particular

care when the indicator light flashes.

■

When the TRAC/VSC systems are

turned off

Be especially careful and drive at a speed

appropriate to the road conditions. As

these are the systems to help ensure

vehicle stability and driving force, do not

turn the TRAC/VSC systems off unless

necessary.

■

Replacing tires

Make sure that all tires are of the speci-

fied size, brand, tread pattern and total

load capacity. In addition, make sure that

the tires are inflated to the recom-

mended tire inflation pressure level.
The ABS, TRAC and VSC systems will

not function correctly if different tires are

installed on the vehicle.

Contact your Lexus dealer for further

information when replacing tires or

wheels.

■

Handling of tires and the suspension

Using tires with any kind of problem or

modifying the suspension will affect the

driving assist systems, and may cause a

system to malfunction.

203

4-6. Driving tips

Driving

4-6.Driving tips



Use fluids that are appropriate to
the prevailing outside temperatures.

• Engine oil
• Engine coolant
• Washer fluid



Have a service technician inspect
the condition of the battery.



Have the vehicle fitted with four
snow tires or purchase a set of tire
chains for the rear tires.

Ensure that all tires are the specified size
and brand, and that chains match the size
of the tires.

: Tire chains cannot be mounted on vehi-

cles with front and rear tires of differing
sizes and vehicles with LDH and 19-inch
tires.

Perform the following according to the
driving conditions:



Do not try to forcibly open a window
or move a wiper that is frozen. Pour

Winter driving tips

Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.

Preparation for winter

WARNING

■

Driving with snow tires

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in a loss of

vehicle control and cause death or seri-

ous injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air

pressure.

●

Do not drive in excess of 75 mph (120

km/h), regardless of the type of snow

tires being used.

●

Use snow tires on all, not just some

wheels.

■

Driving with tire chains

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in the vehicle

being unable to be driven safely, and may

cause death or serious injury.

●

Do not drive in excess of the speed

limit specified for the tire chains being

used, or 30 mph (50 km/h), which-

ever is lower.

●

Avoid driving on bumpy road surfaces

or over potholes.

●

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

●

Slow down sufficiently before entering

a curve to ensure that vehicle control is

maintained.

●

Do not use LDA (Lane Departure

Alert with steering control) system.

NOTICE

■

Repairing or replacing snow tires

Request repairs or replacement of snow

tires from Lexus dealers or legitimate tire

retailers.

This is because the removal and attach-

ment of snow tires affects the operation

of the tire pressure warning valves and

transmitters.

Before driving the vehicle

204

4-6. Driving tips

warm water over the frozen area to
melt the ice. Wipe away the water
immediately to prevent it from
freezing.



To ensure proper operation of the
climate control system fan, remove
any snow that has accumulated on
the air inlet vents in front of the
windshield.



Check for and remove any excess
ice or snow that may have accumu-
lated on the exterior lights, vehicle’s
roof, chassis, around the tires or on
the brakes.



Remove any snow or mud from the
bottom of your shoes before getting
in the vehicle.

Accelerate the vehicle slowly, keep a
safe distance between you and the
vehicle ahead, and drive at a reduced
speed suitable to road conditions.



Park the vehicle and move the shift
lever to P without setting the park-
ing brake. The parking brake may
freeze up, preventing it from being
released. If the vehicle is parked
without setting the parking brake,
make sure to block the wheels.
Failure to do so may be dangerous
because it may cause the vehicle to
move unexpectedly, possibly lead-
ing to an accident.

When the parking brake is in automatic

mode, release the parking brake after shift-
ing the shift lever to P. (



P.135)



If the vehicle is parked without set-
ting the parking brake, confirm that
the shift lever cannot be moved out
of P

: The shift lever will be locked if it is

attempted to be shifted from P to any
other position without depressing the
brake pedal. If the shift lever can be
shifted from P, there may be a problem
with the shift lock system. Have the vehi-
cle inspected by your Lexus dealer
immediately.



Vehicles with front and rear tires of
the same size except for vehicles
with LDH and 19-inch tires

Use the correct tire chain size when
mounting the tire chains.
Chain size is regulated for each tire
size.

Side chain (0.12 in. [3 mm] in diam-
eter)
Cross chain (0.16 in. [4 mm] in
diameter)

When driving the vehicle

When parking the vehicle

Selecting tire chains

205

4-6. Driving tips

Driving



Vehicles with front and rear tires of
differing sizes and vehicles with
LDH and 19-inch tires

Tire chains cannot be mounted.

Snow tires should be used instead.

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

■

Tire chain installation

Observe the following precautions when

installing and removing chains:

●

Install and remove tire chains in a safe

location.

●

Install tire chains on the rear tires. Do not

install tire chains on the front tires.

●

Install tire chains on rear tires as tightly as

possible. Retighten chains after driving

1/4



1/2 mile (0.5



1.0 km).

●

Install tire chains following the instruc-

tions provided with the tire chains.

Regulations on the use of tire
chains

NOTICE

■

Fitting tire chains

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

207

Interio

r fe

atures

Interior features

5-1. Remote Touch/Display

Remote Touch............................

208

Center Display............................

210

5-2. Using the air conditioning system

Automatic air conditioning system

.........................................................

213

Heated steering wheel/seat heat-

ers/seat ventilators.................

221

5-3. Using the interior lights

Interior lights list.........................

223

5-4. Using the storage features

List of storage features............

225

Trunk features.............................

227

5-5. Using the other interior features

Other interior features ...........

228

Garage door opener...............

230

Compass.......................................

235

208

5-1. Remote Touch/Display

5-1.Remote Touch/Display

■

Switches



Vehicles with a 10.3-inch display

“MAP” button

Press this button to display the vehicle’s
current position.

“MENU” button

Press this button to display the menu
screen.

Back button

Press this button to display the previous
screen.

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter

and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, such as changing map
scalings and scrolling list screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.



Vehicles with a 7-inch display

“HOME” button

Press this button to display the “Home”
screen.

“MENU” button

Press this button to display the menu
screen.

Back button

Press this button to display the previous
screen.

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter
and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain

Remote Touch

The Remote Touch can be used to
operate the Center Display.

For details on the Remote touch,
refer to “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Remote Touch operation

209

5-1. Remote Touch/Display

Interio

r fe

atures

finger movements on the touchpad can
perform functions, such as scrolling list
screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.

■

Using the touchpad

Select: Touch the touchpad to
select the desired button on the
screen.
Enter: Buttons on the screen can be
selected by either depressing or
double tapping the touchpad.
Once a button has been selected,
the screen will change.

■

Touch operation

Operations are performed by touching
the touchpad with your finger.



Trace

Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.



Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.



Flick

Quick and short movement along the
touchpad with you finger. Move the list
screen.



Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

210

5-1. Remote Touch/Display

■

Menu screen

Press the “MENU” button on the
Remote Touch to display the menu
screen.
The displays shown in the illustrations
are used for example only and may dif-
fer from the actual vehicle.



Vehicles with a 10.3-inch display



Vehicles with a 7-inch display

NOTICE

■

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

●

Do not allow food, liquid, stickers or lit

cigarettes to contact the Remote

Touch.

●

Do not subject the Remote Touch to

excessive pressure or strong impact.

●

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

Center Display

Center Display overview

Switch

Function

Select to display the
“Destination”
screen.

Select to display the
audio control
screen.

211

5-1. Remote Touch/Display

Interio

r fe

atures

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

: This function is not available on some

models.

■

Split-screen display (Vehicles with a 10.3-inch display)

Different information can be displayed on the left and right sides of the screen. For
example, air conditioning system screen can be displayed and operated while the
fuel consumption information screen is being displayed. The large screen on the
left of the display is called the main display, and the small screen to the right is
called the side display.

Select to display the
hands-free control
screen.

Select to display the
“Apps” screen.

*1, 2

When an Apple
CarPlay/Android
Auto connection is
established and this
button displays
“Apple Car-
Play”/“Android
Auto”, select to dis-
play the Apple Car-
Play/Android Auto
screen.

*1, 2

Select to display the
information screen.

(



P.78)

Switch

Function

Select to display the
setup screen.

Select to display the
air conditioning con-
trol screen.
(



P.214)

Select to adjust the
contrast and bright-
ness of the screens,
turn the screen off,
etc.

*1, 2

Switch

Function

212

5-1. Remote Touch/Display

■

Main display (Vehicles with a
10.3-inch display)

For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

■

Side display (Vehicles with a
10.3-inch display)

The following functions can be dis-
played and operated on the side dis-
play.
Select

to display the desired

screen.

Navigation system

Audio

Vehicle information (



P.80)

Air conditioning system (



P.216)

Show/hide the side display

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

■

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B
C

213

5-2. Using the air conditioning system

Interio

r fe

atures

5-2.Using the air conditioning system

Left-hand side temperature control switch
Automatic mode switch
Off switch
Fan speed down switch
Fan speed up switch
Air flow mode switch
Right-hand side temperature control switch
DUAL mode switch
A/C switch
Outside/recirculated air mode switch
Rear window defogger and outside rear view mirror defoggers switch
Windshield defogger switch

Automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.

Press the “MENU” button on the Remote Touch, then select “Climate” to dis-
play the air conditioning control screen. (



P.210)

The air conditioning system can be displayed and operated on the side display.

Air conditioning controls

A
B
C
D

E
F

214

5-2. Using the air conditioning system

■

Adjusting the temperature setting

To adjust the temperature setting,
touch and slide your finger up or down
on the sensor.

The temperature setting can also be
adjusted by touching on the sensor.
When the temperature setting is changed,
a buzzer sounds.

is not pressed, the system will

blow ambient temperature air or heated
air.

■

Fan speed setting

Press

to increase the fan

speed.

Press

to decrease the fan

speed.

■

Change the airflow mode

To change the airflow, press

The air outlets used are switched each time
the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.

■

Other functions



Switching between outside air and
recirculated air modes (



P.216)



Defogging the windshield (



P.217)



Defogging the rear window and
outside rear view mirrors (



P.217)

Display the air conditioning control
screen

Air conditioning control screen

A
B

C
D

215

5-2. Using the air conditioning system

Interio

r fe

atures

Display the option control screen
(



P.215)

Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tem-
perature setting
Function on/off indicators

When the function is on, the indicator illu-
minates on the control screen.

Display the sub function menu
(



P.215)

Using the Remote Touch, select the button
on the screen and activate it by pressing on
or double tapping the Remote Touch Pad.

■

Option control screen

Select

on the air conditioning con-

trol screen to display the option control
screen. The functions can be switched
on and off.

Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode) (



P.216)

Select to set eco mode on/off
(



P.218)

Set cooling and dehumidification
function on/off

If the “A/C” indicator is turned off, the sys-
tem will blow ambient temperature air or
heated air.

Removing pollen from the air
(Micro dust and pollen filter)
(



P.217)

■

Sub function menu

When the sub function button on the
Remote Touch is pressed, the following
functions can be switched on and off.

Set automatic mode on/off
(



P.216)

Turn the fan off
Set cooling and dehumidification
function on/off

If the “A/C” indicator is turned off, the sys-
tem will blow ambient temperature air or
heated air.

Adjust the temperature for driver
and passenger seats separately
(“DUAL” mode) (



P.216)

Select to set eco mode on/off
(



P.218)

E
F

B
C

Content .. 10 11 12 13 ..
