WARNING

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets caught just before the
electronic sunshade fully closes.
Also, the jam protection function is not designed to operate while the moon roof
switch is being pressed.
Take care so that your fingers, etc. do not get caught.

Opening the electronic sunshade

Press the   switch.

The electronic sunshade will open.
If the

 switch is pressed and held, the electronic

sunshade will fully open automatically.

*1

Closing the electronic sunshade

Press the   switch.

The electronic sunshade will close.
If the

 switch is pressed and held, the electronic

sunshade will fully close automatically.

*2

*1 :

Lightly press either end of the

switch to stop the electronic sunshade while it is

operating.

*2 :

Lightly press either end of the

 switch to stop the electronic sunshade while it is

operating.

4-3. Adjusting the temperature/environment inside the vehicle

248

Illuminating the interior

Using the interior lights

Location of the interior lights

A

Rear interior light

B

Front interior light

C

Personal lights

D

Door trim ornament lights

*

E

Inside door handle lights

*1

F

Door courtesy lights

*

G

Center console light

**1

H

Outer foot lights

I

Footwell lights

*1

●

When the engine switch is in ON, the door trim ornament lights, inside door handle
lights, center console light, footwell lights will turn on. However, if the instrument
panel light control switch is turned to minimum, the footwell lights will turn off.

●

When the shift position is in a position other than P, the brightness of the door trim
ornament lights, inside door handle lights, center console light, footwell lights will
reduce intensity.

* :

If equipped

4-4. Illuminating the interior

249

4

Interior feat

ur

es

INFORMATION

■

Each lights automatic on/off

●

Illuminated entry system: The lights automatically turn on/off according to engine
switch mode, the presence of the electronic key, whether the doors are locked/un-
locked, and whether the doors are opened/closed.

●

If the interior lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.

■

Automatic illumination of the interior lights

If any of the SRS airbags deploy (inflate) or in the event of a strong rear impact, the
interior lights will turn on automatically. The interior lights will turn off automatically after
approximately 20 minutes.
The interior lights can be turned off manually. However, in order to help prevent further
collisions, it is recommended that they be left on until safety can be ensured. (The interior
lights may not turn on automatically depending on the force of the impact and conditions
of the collision.)

■

Using the voice control system

*

The following operations can be performed using the voice control system:

●

Turning interior light on/off

●

Changing color of each lights

For details, refer to the"Multimedia owner's manual".

NOTICE

■

Removing light lenses

Never remove the lens for the front interior light and personal lights. Otherwise, the lights
will be damaged. If the lens need to remove, contact any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer.

■

To prevent battery discharge

Do not leave the lights on longer than necessary when the engine is off.

 Related Links

Customizable features(P. 650)

*1 :

The illumination color can also be changed.

*

Refer to the "Multimedia owner's manual"

to change the settings.

4-4. Illuminating the interior

250

Interior lights

INFORMATION

■

The front interior lights may not operate normally when

The front interior lights may not operate normally in the following situations:

●

When water, dirt, etc., have adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

Turning the interior lights on/off

Touch the light.

The front interior light will turn on/off each time it is
touched.
The rear interior light will also turn on/off.
However, when the rear interior light has already been
turned on, it will not be controlled by front interior light
operations.

Linking the opening/closing of the doors to the front interior light operation

Press the

 switch.

The link between the front interior light operation and
doors will change between ON/OFF each time the

 switch is pressed.

The operation of the rear interior lights will also be
linked to the opening/closing of the doors.

When the door link is turned on, the indicator

 will

illuminate.

Turning the rear interior light on/off

Press the

 switch.

The rear interior light will turn on/off each time the

 switch is pressed.

Operation of the rear interior light is linked to the
turning on/off of the front interior light.

4-4. Illuminating the interior

251

4

Interior feat

ur

es

When the rear interior light has been turned on by front interior light operation, the rear
interior light cannot be turned off by pressing the switch.

Personal lights

INFORMATION

■

The personal lights may not operate normally when

The personal lights may not operate normally in the following situations:

●

When water, dirt, etc., have adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

Using the personal lights

Touch the light.

The personal lights will turn on/off each time they are
touched.

4-4. Illuminating the interior

252

Using the interior features

Location of the storage features

WARNING

Do not leave eyeglasses, lighters or spray cans in the storage spaces, as the following
may occur when cabin temperature becomes high:

●

Eyeglasses may be deformed by heat or cracked if they come into contact with other
stored items.

●

Lighters or spray cans may explode. If they come into contact with other stored items,
a lighter may catch fire or a spray can may release gas, causing a fire hazard.

A

Glove box

B

Auxiliary boxes

C

Card holders

D

Bottle holders

E

Console box

F

Cup holders

G

Coin box

INFORMATION

■

Glove box light and console box light

The glove box light and the console box light turn on when the tail lights are on.

4-5. Using the interior features

253

4

Interior feat

ur

es

Using the auxiliary boxes

Press in the lid.

WARNING

●

Do not store items heavier than 200 g (0.44 lb.). Doing so may cause the auxiliary
box to open and the items inside may fall out, resulting in an accident.

●

When driving or when the auxiliary box is not in use, keep the lid closed. In the event of
sudden braking or sudden swerving, an accident may occur due to an occupant being
struck by the items stored inside.

Push the lid.

To close, press in and release the lid.

WARNING

When driving or when the auxiliary box is not in use, keep the lid closed. In the event of
sudden braking or sudden swerving, an accident may occur due to an occupant being
struck by the items stored inside.

▶

Type A

▶

Type B

4-5. Using the interior features

254

Location of the card holders

Using the glove box

WARNING

When driving or when the glove box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, the front passenger may strike the
glove box lid or stowed items may fly out, possibly leading to an accident.

To open the glove box, pull the lever. The glove box can be locked and unlocked
using the mechanical key.



1

To open the glove box, pull the lever.

2

Lock with the mechanical key.

3

Unlock with the mechanical key.

INFORMATION

■

Glove box light

The glove box light turns on when the tail lights are on.

Use the cup holders

WARNING

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury.
If possible, cover hot drinks to prevent burns.

4-5. Using the interior features

255

4

Interior feat

ur

es

▶

Front

▶

Rear

Pull down the armrest.

Locations of the bottle holders

NOTICE

When using a bottle holder, observe the following precautions.

●

Do not place open bottles, glass cups, or paper cups containing liquid in the bottle
holders.
The liquid may spill out and glass cups may break.

●

When storing a bottle, close the cap.

▶

Front

4-5. Using the interior features

256

INFORMATION

■

Bottle holders

A bottle may not be able to be stored depending on its size or shape.

Using the console box

WARNING

When driving or when the console box is not in use, keep it closed.
If left open, in the event of sudden braking or swerving, an occupant may strike the
console box lid or stowed items may fly out, possibly leading to an accident.

To open the console box, lift the lid while pushing the button.

The console box can be opened from either side.

INFORMATION

■

Console box light

The console box light turns on when the tail lights are on.

▶

Rear

4-5. Using the interior features

257

4

Interior feat

ur

es

Using the coin box

WARNING

When driving or when the coin box is not in use, keep it closed.
If left open, in the event of sudden braking or sudden swerving, the driver may strike the
coin box lid or stowed items may fly out, possibly leading to an accident.

Push the knob up to open the
lid.

4-5. Using the interior features

258

Convenient interior features

Function and operation of the USB charging port

NOTICE

■

To prevent damage to the USB charging ports

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

Rear console: When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the USB charging ports.

●

Do not disassemble or modify the USB charging ports.

■

To prevent damage to external devices

●

Do not leave external devices in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to an external device.

●

Do not push down on or apply unnecessary force to an external device or the cable of
an external device while it is connected.

■

To prevent battery discharge

Do not use the USB charging ports for a long period of time with the engine stopped.

The USB charging ports are used to supply 3.0 A of electricity at 5 V to external
devices.
The USB charging ports are for charging only. They are not designed for data
transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to the manual
included with the device before using a USB charging port.

INFORMATION

■

The USB charging ports can be used when

The engine switch is in ACC or ON mode.

■

Situations in which the USB charging ports may not operate correctly

●

If a device which consumes more than 3.0 A at 5 V is connected.

●

If a device designed to communicate with a personal computer, such as a USB
memory device, is connected

●

If the connected external device is turned off (depending on device)

4-5. Using the interior features

259

4

Interior feat

ur

es

●

If the temperature inside the vehicle is high, such as after the vehicle has been parked
in the sun

■

About connected external devices

Depending on the connected external device, charging may occasionally be suspended
and then start again. This is not a malfunction.

Use the USB charging port

▶

Instrument panel

▶

On the rear console

Open the lid.

Function and operation of the power outlet (12 VDC)

NOTICE

■

To prevent damage to the power outlet (12 VDC)

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

When the power outlets (12 VDC) are not in use, close the lids. If a foreign object or
liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the power outlets (12 VDC) ports.

4-5. Using the interior features

260

NOTICE

■

To prevent battery discharge

Do not use the power outlets (12 VDC) for a long period of time with the engine stopped.

The power outlet can be used to supply power for devices which operate on 12
VDC at less than 10A (power consumption of 120 W).

When connecting multiple devices, make sure that the total power consumption of all the
connected devices is less than 120 W.

INFORMATION

■

The power outlet can be used when

The engine switch is in ACC or ON.

■

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery packs.
If such devices are left connected, the engine switch may not be turned off normally.

Using the accessory sockets (12 VDC)

▶

On the instrument panel (left-hand drive vehicles)

▶

On the rear console

Open the lid.

4-5. Using the interior features

261

4

Interior feat

ur

es

▶

In the luggage compartment

Open the lid.

Function and operation of the wireless charger

A portable device, such as a smartphone or mobile battery, can be charged by
just placing it on the charging area, provided the device is compatible with the Qi
wireless charging standard created by the Wireless Power Consortium.

WARNING

■

Caution while driving

When charging a portable device while driving, for safety reasons, the driver should not
operate the portable device.

■

Precautions for when driving

Do not charge small, lightweight portable devices, such as wireless earbuds, while driv-
ing. Lightweight devices may fly off of the charging tray, possibly leading to an accident.

■

Caution regarding interference with electronic devices

People with implantable cardiac pacemakers, cardiac resynchronization therapy pace-
makers or implantable cardioverter defibrillators, as well as any other electrical medical
device, should consult their physician about the usage of the wireless charger.
Operations of the wireless charger may have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.

●

Do not put any metallic objects between the charging area and the portable device
while charging.

●

Do not attach metallic objects, such as aluminum stickers, to the charging area.

●

Do not charge portable devices with aluminum stickers or other metallic objects
attached to the side which touches the charging area.

●

Do not store items on the wireless charger instead of in an auxiliary box.

4-5. Using the interior features

262

WARNING

●

Do not apply force or impact to the wireless charger.

●

Do not disassemble, modify or remove the wireless charger.

●

Do not attempt to charge portable devices which are not compatible with the Qi
wireless charging standard.

●

Do not allow magnetic objects to come near the wireless charge

●

Do not perform charging if the charging area is dirty

●

When not using the wireless charger, to prevent foreign matter or liquids from con-
tacting it, make sure to close the lid.

●

Do not cover the wireless charger with a cloth or other object while charging.

NOTICE

■

Preventing malfunction and corruption of data

●

Do not bring magnetic cards, such as credit cards, or magnetic recording media, etc.,
close to the charger while charging, otherwise, data may be erased.
Additionally, do not bring precision instruments such as wrist watches, close to the
wireless charger, as such objects may malfunction.

●

Do not perform charging with a contactless smart card, such as a credit card, between
the charging surface of a portable device and the charging area. The IC chip in the
card may become extremely hot, possibly damaging the portable device or smart
card.Failure to do so may result in the possibility of fire, equipment failure or damage,
or burns due to heat.
Be extra careful to not charge a portable device with a case or cover which a
contactless smart card can be inserted.

●

Do not leave portable devices in the vehicle. The temperature inside the vehicle may
become high, when in direct sunlight, possibly damaging the device.

■

To prevent battery discharge

When the engine is stopped, do not use the wireless charger for longer than necessary.

INFORMATION

■

The wireless charger can be operated when

The engine switch is in ACC or ON.

■

About connected portable devices

4-5. Using the interior features

263

4

Interior feat

ur

es
