Lexus LX600 (2022 year). Manual in english - page 30

494

7-2. Steps to take in an emergency



Fluid leaks under the vehicle
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
needle continually points higher
than normal.



Engine oil pressure gauge continu-
ally points lower than normal.



Voltmeter continually points higher
or lower than normal.



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the engine



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact your Lexus dealer as soon as
possible.

Visible symptoms

Audible symptoms

Operational symptoms

495

7-2. Steps to take in an emergency

hen t
ro

ises

Follow the procedure below to restart
the engine after the system is activated.

Turn the engine switch to ACC or
OFF.

Restart the engine.

Fuel pump shut off system

To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.

Restarting the engine

NOTICE

■

Before starting the engine

Inspect the ground under the vehicle.
If you find that fuel has leaked onto the

ground, the fuel system has been dam-

aged and is in need of repair. Do not

restart the engine.

496

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(Canada)

(Red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer. Continuing to drive the vehi-
cle may be dangerous.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in:



The parking brake system; or



The electronically controlled brake system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer.

497

7-2. Steps to take in an emergency

hen tro

ises

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Malfunction indicator lamp

■

SRS warning light

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer.

Warning light

Details/Actions

Indicates that the engine is overheating



Immediately stop the vehicle in a safe place.
Handling method (



P.528)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The electronic engine control system;



The electronic throttle control system;



The electronic automatic transmission control system;
or



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by your Lexus dealer
immediately.

498

7-2. Steps to take in an emergency

■

ABS warning light

■

Power steering system warning light (warning buzzer)

■

PCS warning light (warning buzzer)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The Multi-terrain ABS; or



The brake assist system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Red)

(Yellow)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes or illuminates)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-
Collision System).



Have the vehicle inspected by your Lexus dealer
immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily
unavailable, corrective action may be necessary.



Follow the instructions displayed on the multi-infor-
mation display. (



P.218, 509)

If the PCS (Pre-Collision System) or VSC (Vehicle Stabil-
ity Control) system is disabled, the PCS warning light will
illuminate.



P.229

499

7-2. Steps to take in an emergency

hen tro

ises

■

LTA indicator (warning buzzer)

■

BSM OFF indicator (warning buzzer)

■

RCTA OFF indicator (warning buzzer)

■

RCD OFF indicator (warning buzzer)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.238)

Warning light

Details/Actions

Indicates a malfunction in the BSM (Blind Spot Monitor)
function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the rear bumper around the radar sensor is
covered with dirt, etc. (



P.258)



Follow the instructions displayed on the multi-infor-
mation display. (



P.257, 506)

Warning light

Details/Actions

Indicates a malfunction in the RCTA (Rear Cross Traffic
Alert) function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the rear bumper around the radar sensor is
covered with dirt, etc. (



P.258)



Follow the instructions displayed on the multi-infor-
mation display. (



P.268, 506)

Warning light

Details/Actions

Indicates a malfunction in the RCD (Rear Camera Detec-
tion) function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the function temporarily cannot be used due
to the camera being dirty, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.274, 506)

500

7-2. Steps to take in an emergency

■

Intuitive parking assist OFF indicator (warning buzzer)

■

PKSB OFF indicator (warning buzzer)

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

Warning light

Details/Actions

Indicates a malfunction in the intuitive parking assist func-
tion



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.263, 506)

Warning light

Details/Actions

Indicates a malfunction in the PKSB (Parking Support
Brake) system



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.279, 506)

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



Parking Support Brake function (Static Objects Front
and Rear of the Vehicle) is operating.



Follow the instructions displayed on the multi-infor-
mation display.

When a buzzer does not sound:
Brake Override System is operating.



Release the accelerator pedal and depress the brake
pedal.

501

7-2. Steps to take in an emergency

hen tro

ises

■

Stop & Start cancel indicator

■

Slip indicator light

■

Low speed four-wheel drive indicator

■

Center differential lock indicator

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the Stop & Start system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The Trailer Sway Control system



The Active TRAC system;



The hill-start assist control system;



The downhill assist control system;



The Multi-terrain Select; or



The Crawl Control



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the four-wheel drive system
when the light flashes rapidly.



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the center differential lock sys-
tem when the light flashes rapidly.



Have the vehicle inspected by your Lexus dealer
immediately.

502

7-2. Steps to take in an emergency

■

Parking brake indicator

■

Brake hold operated indicator (warning buzzer)

■

Low fuel level warning light

■

Tire pressure warning light

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)

(Canada)

It is possible that the parking brake is not fully engaged or
released



Operate the parking brake switch once again.

This light comes on when the parking brake is not
released. If the light turns off after the parking brake is fully
released, the system is operating normally.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates that remaining fuel is approximately 3.2 gal.
(12.0 L, 2.6 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by your Lexus dealer.

When the light comes on:
Low tire inflation pressure such as



Natural causes



Flat tire



Immediately stop the vehicle in a safe place.
Handling method (



P.504)

503

7-2. Steps to take in an emergency

hen tro

ises

■

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is
not fastened. Once the engine switch is turned to ON, the buzzer sounds. If the seat belt
is still unfastened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front passenger that
his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain speed.

■

Rear passengers’ seat belt reminder light (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his
or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermit-
tently for a certain period of time, after the seat belt is fastened and unfastened and the
vehicle reaches a certain speed.

■

Warning buzzer

In some cases, the buzzer may not be heard

because of noisy place or an audio sound.

■

Front passenger detection sensor, seat

belt reminder and warning buzzer

●

If luggage is placed on the front passen-

ger seat, the front passenger detection

sensor may cause the warning light to

flash and the warning buzzer to sound

even if a passenger is not sitting in the

seat.

●

If a cushion is placed on the seat, the sen-

sor may not detect a passenger, and the

warning light may not operate properly.

■

SRS warning light

This warning light system monitors the air-

bag sensor assembly, front impact sensors,

side impact sensors (front door), side

impact sensors (front), side impact sensors

(rear), safing sensor (rear), front passenger

occupant classification sensors, driver’s

seat position sensor, driver’s seat belt

buckle switch, rear seat belt buckle

switches, “AIR BAG ON” indicator light,

“AIR BAG OFF” indicator light, front pas-

senger’s seat belt buckle switch, driver’s

seat belt pretensioner, front passenger’s

seat belt pretensioner and force limiter,

rear seat belt pretensioners (if equipped),

airbags, interconnecting wiring and power

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their
seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

Warning light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

504

7-2. Steps to take in an emergency

sources. (



P.33)

■

If the malfunction indicator lamp comes

on while driving

First check the following:

●

Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several driving

trips.
If the light does not go off even after several

trips, contact your Lexus dealer as soon as

possible.

■

Electric power steering system warning

light (warning buzzer)

When the battery charge becomes insuffi-

cient or the voltage temporarily drops, the

electric power steering system warning

light may come on and the warning buzzer

may sound.

■

When the tire pressure warning light

comes on

Inspect the tires to check if a tire is punc-

tured.
If a tire is punctured:



P.511

If none of the tires are punctured:
Turn the engine switch to OFF then turn it

to ON. Check if the tire pressure warning

light comes on or blinks.



If the tire pressure warning light blinks for

approximately 1 minute then stays on

There may be a malfunction in the tire pres-
sure warning system. Have the vehicle
inspected by your Lexus dealer immedi-
ately.



If the tire pressure warning light comes

After the temperature of the tires has

lowered sufficiently, check the inflation

pressure of each tire and adjust them to

the specified level.

If the warning light does not turn off

even after several minutes have

elapsed, check that the inflation pres-

sure of each tire is at the specified level

and perform initialization. (



P.469)

■

The tire pressure warning light may

come on due to natural causes

The tire pressure warning light may come

on due to natural causes such as natural air

leaks and tire inflation pressure changes

caused by temperature. In this case, adjust-

ing the tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a spare tire

The spare tire is also equipped with the tire

pressure warning valve and transmitter. The

tire pressure warning light will turn on if the

tire inflation pressure of the spare tire is low.

If a tire goes flat, even though the flat tire is

replaced with the spare tire, the tire pres-

sure warning light does not turn off.

Replace the spare tire with the repaired tire

and adjust the proper tire inflation pressure.

The tire pressure warning light will turn off

after a few minutes.

■

Conditions that the tire pressure warn-

ing system may not function properly



P.468

WARNING

■

If a warning light comes on or a warn-

ing buzzer sounds when a warning

message is shown on the multi-infor-

mation display

Check and follow the message shown on

the multi-information display.
Failure to do so may result in death or

serious injury.

■

If both the ABS and the brake system

warning lights remain on

Stop your vehicle in a safe place immedi-

ately and contact your Lexus dealer. The

vehicle will become extremely unstable

during braking, and the ABS system may

fail, which could cause an accident

resulting in death or serious injury.

505

7-2. Steps to take in an emergency

hen t
ro

ises

WARNING

■

When the electric power steering

system warning light comes on

When the light comes on yellow, the

assist to the power steering is restricted.

When the light comes on red, the assist

to the power steering is lost and handling

operations of the steering wheel become

extremely heavy.

When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using more

force than usual.

■

If the tire pressure warning light

comes on

Be sure to observe the following precau-

tions. Failure to do so could cause a loss

of vehicle control and result in death or

serious injury.

●

Stop your vehicle in a safe place as

soon as possible. Adjust the tire infla-

tion pressure immediately.

●

If the tire pressure warning light comes

on even after tire inflation pressure

adjustment, it is probable that you have

a flat tire. Check the tires. If a tire is flat,

change it with the spare tire and have

the flat tire repaired by the nearest

Lexus dealer.

●

Avoid abrupt maneuvering and brak-

ing. If the vehicle tires deteriorate, you

could lose control of the steering

wheel or the brakes.

■

If a blowout or sudden air leakage

should occur

The tire pressure warning system may

not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if pro-

vided), should be checked monthly when

cold and inflated to the inflation pressure

recommended by the vehicle manufac-

turer on the vehicle placard or tire infla-

tion pressure label (tire and load

information label). (If your vehicle has

tires of a different size than the size indi-

cated on the vehicle placard or tire infla-

tion pressure label [tire and load

information label], you should determine

the proper tire inflation pressure for

those tires.)

As an added safety feature, your vehicle

has been equipped with a tire pressure

monitoring system (TPMS-tire pressure

warning system) that illuminates a low

tire pressure telltale (tire pressure warn-

ing light) when one or more of your tires

is significantly under-inflated. Accord-

ingly, when the low tire pressure telltale

(tire pressure warning light) illuminates,

you should stop and check your tires as

soon as possible, and inflate them to the

proper pressure. Driving on a signifi-

cantly under-inflated tire causes the tire

to overheat and can lead to tire failure.

Under-inflation also reduces fuel effi-

ciency and tire tread life, and may affect

the vehicle’s handling and stopping abil-

ity.

Please note that the TPMS (tire pressure

warning system) is not a substitute for

proper tire maintenance, and it is the

driver’s responsibility to maintain correct

tire pressure, even if under-inflation has

not reached the level to trigger illumina-

tion of the TPMS low tire pressure telltale

(tire pressure warning light).

506

7-2. Steps to take in an emergency

WARNING

Your vehicle has also been equipped

with a TPMS (tire pressure warning sys-

tem) malfunction indicator to indicate

when the system is not operating prop-

erly. The TPMS (tire pressure warning

system) malfunction indicator is com-

bined with the low tire pressure telltale

(tire pressure warning light). When the

system detects a malfunction, the telltale

will flash for approximately one minute

and then remain continuously illumi-

nated. This sequence will continue upon

subsequent vehicle start-ups as long as

the malfunction exists. When the mal-

function indicator is illuminated, the sys-

tem may not be able to detect or signal

low tire pressure as intended.

TPMS (tire pressure warning system)

malfunctions may occur for a variety of

reasons, including the installation of

replacement or alternate tires or wheels

on the vehicle that prevent the TPMS

(tire pressure warning system) from

functioning properly. Always check the

TPMS (tire pressure warning system)

malfunction telltale after replacing one

or more tires or wheels on your vehicle

to ensure that the replacement or alter-

nate tires and wheels allow the TPMS

(tire pressure warning system) to con-

tinue to function properly.

NOTICE

■

To ensure the tire pressure warning

system operates properly

Do not install tires with different specifi-

cations or manufacturers, as the tire

pressure warning system may not oper-

ate properly.

If a warning message is dis-
played

The multi-information display
shows warnings of system malfunc-
tions, incorrectly performed opera-
tions, and messages that indicate a
need for maintenance. When a
message is shown, perform the cor-
rection procedure appropriate to
the message.

If a warning message is displayed
again after the appropriate actions
have been performed, contact your
Lexus dealer.

507

7-2. Steps to take in an emergency

hen tro

ises

The warning lights and warning buzzers operate as follows depending on the con-
tent of the message. If a message indicates the need for inspection by a dealer,
have the vehicle inspected by your Lexus dealer immediately.

: A buzzer sounds the first time a message is shown on the multi-information display.

■

Warning messages

The warning messages explained below

may differ from the actual messages

according to operation conditions and vehi-

cle specifications.

■

Warning buzzer

In some cases, the buzzer may not be heard

because of noisy place or an audio sound.

■

If a message that indicates the need for

visiting your Lexus dealer is displayed

The system or part shown on the multi-

information display is malfunctioning. Have

the vehicle inspected by your Lexus dealer

immediately.

■

If a message about an operation is

shown

●

If a message about an operation of the

accelerator pedal or brake pedal is

shown

• A warning message about an operation

of the brake pedal may be shown while

the driving assist systems such as PCS

(Pre-Collision system) or the dynamic

radar cruise control with full-speed range

is operating. If a warning message is

shown, be sure to decelerate the vehicle

or follow an instruction shown on the

multi-information display.

• A warning message is shown when Brake

Override System operates. (



P.167)

• A warning message is shown when

Drive-Start Control or Parking Support

Brake (



P.171, 275) operates. Follow

the instructions on the multi-information

display.

●

If a message about an operation of the

engine switch is shown

An instruction for operation of the engine
switch is shown when the incorrect proce-

Messages and warnings

Warning

light

Warning buzzer

Warning



Sounds

• Indicates an important situation, such as when a

system related to driving is malfunctioning or that
danger may result if the correction procedure is
not performed

• Indicates a situation, such as when damage to the

vehicle or danger may result

Comes on

or flashes

Sounds

Indicates an important situation, such as when the
systems shown on the multi-information display
may be malfunctioning



Does not sound

• Indicates a condition, such as malfunction of

electrical components, their condition, or indi-
cates the need for maintenance

• Indicates a situation, such as when an operation

has been performed incorrectly, or indicates
how to perform an operation correctly

508

7-2. Steps to take in an emergency

dure for starting the engine is performed or
the engine switch is operated incorrectly.
Follow the instructions shown on the multi-
information display to operate the engine
switch again.

●

If a message about a shift lever operation

is shown

To prevent the shift lever from being oper-
ated incorrectly or the vehicle from moving
unexpectedly, a message that requires
shifting the shift lever may be shown on the
multi-information display. In that case, fol-
low the instruction of the message and shift
the shift lever.

●

If a message or image about an

open/close state of a part or replenish-

ment of a consumable is shown

Confirm the part indicated by the multi-
information display or a warning light, and
then perform the coping method such as
closing the open door or replenishing a
consumable.

■

If a message that indicates the need for

referring to Owner’s Manual is dis-

played

●

If the following messages are shown, fol-

low the instructions, accordingly.

• “Engine Coolant Temp High Stop in a

Safe Place” (



P.528)

• “Blind Spot Monitor Unavailable”

(



P.257)

• “Rear Cross Traffic Alert Unavailable”

(



P.268)

• “Rear Camera Detection Unavailable”

(



P.274)

●

If the following messages are shown,

there may be a malfunction.

Immediately have the vehicle inspected

by your Lexus dealer.

• “Transmission Oil Temp. High Stop in a

safe place and See owner’s manual”

• “Smart Entry & Start System malfunction”

• “Brake Hold Unavailable” (



P.201)

●

If the following messages are shown,

there may be a malfunction.

Immediately stop the vehicle in a safe

place and contact your Lexus dealer.

Continuing to drive the vehicle may be

dangerous.

• “Oil Pressure Low”

• “Braking Power Low”

●

If “12-Volt Battery Charging System Mal-

function Stop in a Safe Place” is shown

Indicates a malfunction in the vehicle’s
charging system. Pull over and stop the
vehicle as soon as it is safe to do so. While
the message is displayed, the functions of
the air conditioning, etc. may be partially
limited in order to reduce the power con-
sumption of the battery.

■

If “Shift into P before exiting vehicle” is

shown

Message is displayed when the driver’s

door is opened without turning the engine

switch to OFF with the shift lever in any

position other than P.
Shift the shift lever to P.

■

If “Auto Power Off to Conserve Bat-

tery” is shown

Power was turned off due to the automatic

power off function.
Next time when starting the engine,

increase the engine speed slightly and

maintain that level for approximately 5 min-

utes to recharge the battery.

■

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level may be low. Check the

level of the engine oil, and add engine oil if

necessary. This message may be displayed

if the vehicle is stopped on a slope. Move

the vehicle to a level surface and check if

the message disappears.

■

If “Maintenance Required Soon” is dis-

played

Indicates that all maintenance according to

the driven distance on the maintenance
schedule

should be performed soon.

Comes on approximately 4500 miles

(7200 km) after the message has been

reset. If necessary, perform maintenance.

Please reset the message after the mainte-

nance is performed. (



P.448)

509

7-2. Steps to take in an emergency

hen t
ro

ises

: Refer to the separate “Scheduled Main-

tenance” or “Owner’s Manual Supple-
ment” for the maintenance interval
applicable to your vehicle.

■

If “Maintenance Required Visit Your

Dealer” is displayed

Indicates that all maintenance is required to

correspond to the driven distance on the
maintenance schedule

Comes on approximately 5000 miles

(8000 km) after the message has been

reset. (The indicator will not work properly

unless the message has been reset.) Per-

form the necessary maintenance. Please

reset the message after the maintenance is

performed. (



P.448)

: Refer to the separate “Scheduled Main-

tenance” or “Owner’s Manual Supple-
ment” for the maintenance interval
applicable to your vehicle.

■

If “Oil Maintenance Required Soon” is

displayed

Indicates that the engine oil should be

scheduled to be changed.
Check the engine oil and change it if neces-

sary. After changing the engine oil, make

sure to reset the message. (



P.459)

■

If “Oil Maintenance Required” is dis-

played

Indicates that the engine oil should be

changed.
Check and change the engine oil, and oil fil-

ter by your Lexus dealer. After changing

the engine oil, make sure to reset the mes-

sage. (



P.459)

■

If a message that indicates the malfunc-

tion of front camera is displayed

The following systems may be suspended

until the problem shown in the message is

resolved. (



P.218, 496)

●

PCS (Pre-Collision System)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

RSA (Road Sign Assist)

●

Dynamic radar cruise control with full-

speed range

: If equipped

■

If a message that indicates the malfunc-

tion of radar sensor is displayed

The following systems may be suspended

until the problem shown in the message is

resolved. (



P.218, 496)

●

PCS (Pre-Collision System)

●

LTA (Lane Tracing Assist)

●

Dynamic radar cruise control with full-

speed range

■

If “Radar Cruise Control Unavailable

See Owner’s Manual” is shown

The dynamic radar cruise control with full-

speed range is suspended temporarily or

until the problem shown in the message is

resolved. (causes and coping methods:



P.218)

■

If “Radar Cruise Control Unavailable” is

shown

The dynamic radar cruise control with full-

speed range cannot be used temporarily.

Use the system when it becomes available

again.

■

If a following message is shown, take

appropriate action and confirm that the

message has disappeared.

• “CRAWL Unavailable See Owner’s

Manual” (



P.358)

• “Turn Assist Function Unavailable Check

System Operation Conditions”

(



P.359)

• “Turn Assist Function Unavailable Acti-

vate CRAWL” (



P.357)

WARNING

■

If a warning light comes on or a warn-

ing buzzer sounds when a warning

message is shown on the multi-infor-

mation display

Check and follow the message displayed

on the multi-information display. Failure

to do so may result in death or serious

injury.

Content .. 28 29 30 31 ..
