Lexus LX600 (2022 year). Manual in english - page 25

412

5-5. Using the storage features



Rear doors



Rear side trims

■

Bottle holders

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending

on its size or shape.



Instrument panel

Press the button



Front



Rear (if equipped)

Press the button to open the lid.

NOTICE

■

Items that should be not stowed in the

bottle holders

Do not place open bottles or glass and

paper cups containing liquid in the bottle

holders. The contents may spill and

glasses may break.

Card holder

Auxiliary boxes

413

5-5. Using the storage features

Inte
rior f
ea

tures



Rear side trims (if equipped)



Front (if equipped)



Rear (if equipped)

WARNING

■

Caution while driving

Do not leave the auxiliary box open while

driving.
Items stored in it may fall out and cause

death or serious injury in case of an acci-

dent or sudden stop.

Open tray (if equipped)

WARNING

■

Items unsuitable for the open tray

Observe the following precautions when

putting items in the open tray. Failure to

do so may cause items to be thrown out

of the tray in the event of sudden braking

or steering. In these cases, the items may

interfere with pedal operation or cause

driver distraction, resulting in an acci-

dent.

●

Do not store items in the tray that can

easily shift or roll out.

●

Do not stack items in the tray higher

than the tray’s edge.

●

Do not put items in the tray that may

protrude over the tray’s edge.

414

5-5. Using the storage features

Raise the hook to use.

The cargo hooks are provided for securing
loose items.



4-passenger or 5-passenger mod-
els



7-passenger models

Open the deck board.

Luggage compartment fea-
tures

WARNING

■

Caution while driving

Keep the deck board closed.
In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by an open

deck board or the items stored inside.

Cargo hooks

WARNING

■

When cargo hooks are not in use

To avoid injury, always return the hooks

to their stowed positions when not in use.

Grocery bag hooks

NOTICE

■

To prevent damage to the grocery

bag hooks

Do not hang any object heavier than 6.6

lb. (3 kg) on the grocery bag hooks.

Storage compartment (4-pas-
senger or 5-passenger models)

415

5-5. Using the storage features

Inte
rior f
ea

tures

Open the deck board.

The warning reflector itself is not included
as an original equipment.



4-passenger or 5-passenger mod-
els



7-passenger models

■

Warning reflector

Depending on the size and shape of the

warning reflector case, you may not be able

Warning reflector holder

416

5-5. Using the storage features

to store it.

■

Installing the luggage cover

Install one side of the luggage
cover to the holder. While pushing
that side in, install the other side to
the opposite holder.

Pull out the luggage cover and
secure it to the hook brackets.

■

Removing the luggage cover

Detach the both ends of the lug-
gage cover from the holder and
retract it.

Push one end of the luggage cover
inward and remove it from the
holder.

After remove the luggage cover, remove it

from the vehicle.

■

When installing the luggage cover

Keep the “TOP” mark on the luggage cover

ends upward.

Luggage cover (5-passenger or
7-passenger models) (if
equipped)

417

5-5. Using the storage features

Inte
rior f
ea

tures

■

Pulling out the luggage cover

Pull out the luggage cover and secure
it to the hook brackets.

■

Retracting the luggage cover

Detach the both ends of the luggage
cover from the holder and retract it.

■

Removing the luggage cover

Lexus does not recommend that the lug-

gage cover is removed by yourself. If it is

necessary to remove the luggage cover,

contact your Lexus dealer.

WARNING

■

Luggage cover

●

Do not allow children to climb on the

luggage cover. Climbing on the lug-

gage cover could result in damage to

the luggage cover, possibly causing

death or serious injury to the child.

●

Do not put your fingers or arms

between the luggage cover and its

surrounding part. Fingers or arms may

become jammed, resulting in serious

injury.

Luggage cover (4-passenger
models)

WARNING

■

Luggage cover

●

Do not allow children to climb on the

luggage cover. Climbing on the lug-

gage cover could result in damage to

the luggage cover, possibly causing

death or serious injury to the child.

●

Do not put your fingers or arms

between the luggage cover and its

surrounding part. Fingers or arms may

become jammed, resulting in serious

injury.

NOTICE

■

To prevent damage to the luggage

cover

Do not place an object between the seat-
back and luggage cover

418

5-6. Using the other interior features

5-6.Using the other interior features

While the engine is running, the cool
box, which is cooled by the air condi-
tioning, can be used.

While pressing the button, lift up
and open the lid.

The cool box can be opened from right, left

or back side of the cool box.

Turns the cool box on/off

When on, the indicator light

comes on.

If the front air conditioning system is not in

use, the front air conditioning system is

automatically turned on when the cool box

is turned on.

■

While the cool box is on

• The front air conditioning system cannot

be turned off.

• To adjust the temperature of the cool

box, the cool box may stop operating

temporarily.

■

When the outside temperature is 32°F

(0°C) or below

The cool box may not operate.

■

Tray in the cool box

The tray in the cool box can be moved left

or right, or can be removed.

■

Items unsuitable for the cool box

●

Drinks in unsealed containers

●

Fragile items, perishables or anything

with strong odor

●

Owner’s manual, electronic devices,

CDs, etc.

■

When cleaning the inside of the cool

box

Wipe dirt off with a cloth dampened with

water. Directly applying water may cause a

malfunction.

Other interior features

Cool box (if equipped)

WARNING

■

Caution while driving

Keep the cool box closed while driving.
Injuries may result in the event of sudden

braking, sudden swerving or an accident.

■

When opening and closing the cool

box

Take care to prevent your fingers etc.

from being caught.

419

5-6. Using the other interior features

Inte
rior f
ea

tures

To set the visor in the forward posi-
tion, flip it down.

To set the visor in the side position,
flip down, unhook, and swing it to
the side.

To use the side extender, place the
visor in the side position, then slide
it backward.

Slide the cover to open.

The light turns on when the cover is
opened.

■

Automatic light off to prevent battery

discharge

If the vanity lights remain on when the

engine switch is turned to OFF, the lights

will go off automatically after 20 minutes.

■

12 V DC

Please use a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
When using electronic goods, make
sure that the power consumption of all
the connected power outlets is less
than 120 W.



Front

Open the lid.



Rear side of the console (if
equipped)

Open the lid.

NOTICE

■

To prevent battery discharge

Do not leave the cool box on longer than

necessary when the engine is not run-

ning.

Sun visors

Vanity mirrors

NOTICE

■

To prevent battery discharge

Do not leave the vanity lights on for

extended periods while the engine is off.

Power outlet

420

5-6. Using the other interior features

Open the lid.



Inside of the rear console box (if
equipped)

Push the button to release the lock,
and then lift the lid to open the console
box.

The console box can be opened from
either side.

Open the lid.

■

120 V AC

Accessories that use less than 100 W.
Open the lid.

■

The power outlet can be used when



12 V DC

The engine switch is in ACC or ON.



120 V AC

The engine switch is in ON.

■

When turning the engine switch off

Disconnect electrical devices with charging

functions, such as mobile battery packs.

If such devices are left connected, the

engine switch may not be turned off nor-

mally.

421

5-6. Using the other interior features

Inte
rior f
ea

tures

The USB Type-C charging ports are
used to supply 3 A of electricity at 5 V
to external devices.
The USB Type-C charging ports are
for charging only. They are not
designed for data transfer or other
purposes.
Depending on the external device, it
may not charge properly. Refer to the
manual included with the device
before using a USB charging port.

■

Using the USB Type-C charging
ports



Front



Rear side of the console (if
equipped)

Open the lid.

WARNING

■

Rear side of the console

Do not put anything on the rear side of

the console or close the lid when any-

thing is on the lid. Also, close the lid when

the power outlet is not in use.
In the event of sudden braking or sudden

swerving, an injury many occur due to an

occupant being struck by the open lid or

the items stored inside.

NOTICE

■

When power outlet is not in use

To avoid damaging the power outlet,

close the power outlet lid when the

power outlet is not in use.
Foreign objects or liquids that enter the

power outlet may cause a short circuit.

■

To prevent blown fuse (120 V AC)

Do not use a 120 V AC appliance that

requires more than 100 W. If a 120 V

AC appliance that consumes more than

100 W is used, the protection circuit will

cut the power supply.

■

To prevent battery discharge

Do not use the power outlet longer than

necessary when the engine is off.

■

Appliances that may not operate

properly (120 V AC)

The following 120 V AC appliances may

not operate properly even if their power

consumption is under 100 W:

●

Appliances with high initial peak watt-

age

●

Measuring devices that process pre-

cise data

●

Other appliances that require an

extremely stable power supply

USB Type-C charging ports (if
equipped)

422

5-6. Using the other interior features



Auxiliary box (if equipped)

Press the button to open the lid.



Inside of the rear console box (if
equipped)

Push the button to release the lock,
and then lift the lid to open the console
box.

The console box can be opened from
either side.



Rear side trims (if equipped)

Open the lid.

■

The USB Type-C charging ports can be

used when

The engine switch is in ACC or ON.

■

Situations in which the USB Type-C

charging ports may not operate cor-

rectly

●

If a device which consumes more than 3

A at 5 V is connected

●

If a device designed to communicate with

a personal computer, such as a USB

memory device, is connected

●

If the connected external device is turned

off (depending on device)

423

5-6. Using the other interior features

Inte
rior f
ea

tures

●

If the temperature inside the vehicle is

high, such as after the vehicle has been

parked in the sun

■

About connected external devices

Depending on the connected external

device, charging may occasionally be sus-

pended and then start again. This is not a

malfunction.

A portable device can be charged by
just placing Qi standard wireless
charge compatible portable devices
according to the Wireless Power Con-
sortium, such as smartphones and
mobile batteries, etc., on the charge
area.
This function cannot be used with por-
table devices that are larger than the
charging tray. Also, depending on the
portable device, it may not operate as
normal. Please read the operation
manual for portable devices to be
used.

■

The “Qi” logo

The “Qi” logo is a trademark of the
Wireless Power Consortium.

WARNING

■

Rear side of the console

Do not put anything on the rear side of

the console or close the lid when any-

thing is on the lid. Also, close the lid when

the USB Type-C charging ports is not in

use.
In the event of sudden braking or sudden

swerving, an injury many occur due to an

occupant being struck by the open lid or

the items stored inside.

NOTICE

■

To prevent damage to the USB Type-

C charging ports

●

Do not insert foreign objects into the

ports.

●

Do not spill water or other liquids into

the ports.

●

When the USB Type-C charging ports

are not in use, close the lids. If a foreign

object or liquid enters a port may

cause a short circuit.

●

Do not apply excessive force to or

impact the USB Type-C charging

ports.

●

Do not disassemble or modify the USB

Type-C charging ports.

■

To prevent damage to external

devices

●

Do not leave external devices in the

vehicle. The temperature inside the

vehicle may become high, resulting in

damage to an external device.

●

Do not push down on or apply unnec-

essary force to an external device or

the cable of an external device while it

is connected.

■

To prevent battery discharge

Do not use the USB Type-C charging

ports for a long period of time with the

engine stopped.

Wireless charger (if equipped)

424

5-6. Using the other interior features

■

Name for all parts



Front (if equipped)

Operation indicator light

Charge area

Charging tray

Approximately 2.4 in. (6 cm)

Approximately 2.8 in. (7 cm)

: Portable devices and wireless chargers

contain charging coils.
The charging coil in the wireless charger
can be moved within the charge area
near the center of the charging tray. If
the charging coil inside a portable
device is detected in the charge area,
the charging coil inside the wireless
charger will move toward it and start
charging. If the charging coil inside a
portable device moves outside of the
charge area, charging will automatically
stop.
If 2 or more portable devices are placed
on the charging tray, their charging coils
may not be properly detected and they
may not be charged.



Rear (if equipped)

Power supply switch

Operation indicator light

Charging tray

Charge area

Approximately 2.4 in. (6 cm)

Approximately 2.8 in. (7 cm)

: Portable devices and wireless chargers

A
B
C
D

E
F

425

5-6. Using the other interior features

Inte
rior f
ea

tures

may not be properly detected and they
may not be charged.

■

Using the wireless charger



Front (if equipped)

Place the portable device on the
charging tray

Place the charging side of the portable
device down with the center of the device
in the center of the charge area.
Depending on the portable device, the
charging coil may not be located in the
center of the device. In this case, place the
portable device so that its charging coil is
in the center of the charge area.
When charging, the operation indicator
light (orange) comes on.
If charging is not occurring, try placing the
portable device as close to the center of
the charging area as possible.
When charging is complete, the operation
indicator light (green) comes on.



Rear (if equipped)

Press the power supply switch of
the wireless charger.

Switches on and off with each press of the

power supply switch.
When turned on, the operation indicator

light (green) comes on.
Even with the engine off, the on/off state of

the power supply switch is memorized.

Place the portable device on the
charging tray

Place the charging side of the portable

device down with the center of the device

in the center of the charge area.
Depending on the portable device, the

charging coil may not be located in the

center of the device. In this case, place the

portable device so that its charging coil is

in the center of the charge area.
When charging, the operation indicator

light (orange) comes on.
If charging is not occurring, try placing the

portable device as close to the center of

the charging area as possible.
When charging is complete, the operation

indicator light (green) comes on.

■

Recharging function



When charging is complete and
after a fixed time in the charge sus-
pension state, charging restarts.



When a portable device is moved
significantly in the charge area, the

426

5-6. Using the other interior features

charging coil is disconnected and
charging is stopped momentarily.
However, if there is a charging coil
in the charge area, the charging coil
inside the wireless charger will
move toward it and then charging
restarts.

■

Rapid charging function



The following portable devices sup-
port rapid charging.

• Portable devices compliant with WPC

Ver1.2.4 and compatible with rapid
charging

• iPhone’s with an iOS version that sup-

ports 7.5 W charging (iPhone 8 and
later models)



When a portable device that sup-
ports rapid charging is charged,
charging automatically switches to
the rapid charging function.

■

Lighting conditions of operation indicator light

: Only displayed on the front wireless device.

: Charging power will not be output during standby. A metallic object will not be heated,

if it is placed on the charging tray in this state.

: Depending on the portable device, there are cases where the operation indicator light

will continue being lit up orange even after the charging is complete.

■

When the wireless charger does not operate properly

When the wireless charger does not operate properly, handle the probable cause
based on the following tables.

Operation indicator light

Conditions

Charging tray side Center display side

Turning off

Disappear

When the Wireless charger power supply is

off

Green (comes on)

Gray

On Standby (charging possible state)

When charging is complete

Orange (comes on)

Blue

When placing the portable device on the

charging area (detecting the portable device)

Charging

427

5-6. Using the other interior features

Inte
rior f
ea

tures

Operation indicator light

Suspected causes/Handling method

Charging tray side

Center Display side

Orange (Flashing

repeatedly once every

second)

Gray

Vehicle to wireless charger commu-
nication failure



If the engine is running, stop and
then restart the engine.

If the engine switch is in ACC, start
the engine. (



P.188)

Green (Flashing repeat-

edly once every second)

Disappear

Wireless charger and multimedia
system communication failure



If the engine is running, stop and
then restart the engine.

If the engine switch is in ACC, start
the engine. (



P.188)

Green (comes on)

Blue

AM radio stations are being auto-
matically selected



Wait until the system has com-
pleted the automatic selection of
AM radio stations. In the case
that automatic selection cannot
be completed, stop automatic
selection.

The smart access system with push-
button start is detecting the key.



Wait until key detection has com-
pleted.

Content .. 23 24 25 26 ..
