Lexus LS500 (2022 year). Manual in english

118

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

senger’s seat seatback

The seatback will move while a button is
touched and held.

: Vehicles with a foldable head restraint

■

Operating the front passenger’s seat

from the rear seat

●

In the following situations, the front pas-

senger’s seat cannot be operated using

the Rear Multi Operation Panel:

• The engine switch is in ACCESSORY

mode or off.

• The rear seat belt is not fastened and

weight is not detected on the rear seat.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.
• The weight of an occupant or heavy

object, etc. is detected on the front pas-

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the engine switch is turned off.
• The front passenger’s seat belt is fas-

tened.

• The front passenger’s door is open. (The

front seat will not move forward.)

: Vehicles with foldable head restraint:

Even when the engine switch is in
ACCESSORY mode or off, the front
passenger seat position and seatback
angle can be adjusted.

●

If the rear armrest is stowed while the

seat position is being adjusted, the opera-

tion will stop.

■

Canceling an operation

To cancel an operation, press and hold the

button of the Rear Multi Opera-

tion Panel or press it 3 times in quick suc-

cession.

■

When the front passenger’s seat is

folded forward



P.117

Pneumatic chambers built into the
front seat apply pressure to the occu-
pant’s body at different modes and
intensities.

Press the seat switch.

Using the Remote Touch pad,
select “Driver Seat Refresh” or
“Passenger Seat Refresh”.

Select the desired mode.



“Centripetal”

Applies pressure sequentially from the
front of the seat cushion to top of the seat-
back



“Centrifugal”

Applies pressure sequentially from the top
of the seatback to the front of the seat
cushion



“Upper Body”

Applies pressure sequentially from the bot-
tom to the top of the seatback



“Lower Body”

Applies pressure sequentially from the
front to the back of the seat cushion

Front seat refresh system (if
equipped)

119

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving



“Lumbar”

Applies pressure sequentially from the bot-
tom to the top of the lumbar area of the
seatback

Select the desired intensity and
then confirm the setting.

The intensity can be adjusted in 5 steps.
To stop the operation select “Stop”.
If a seat is not occupied, do not operate the

front seat refresh system for that seat.

■

Refresh system

●

Operating conditions

• The engine switch is in IGNITION ON

mode.

• The temperature in the cabin is not

extremely high.

• For the front passenger’s seat: The weight

of an occupant is detected on the front

passenger’s seat or the front passenger’s

seat belt is fastened.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the engine switch is turned off.

●

Automatic stop function

• The operation will be canceled automati-

cally after approximately 15 minutes.

• If the power easy ac

cess system begins

operating, the front seat refresh system

will stop.

WARNING

■

Important points while driving

Do not adjust the driver’s seat refresh

system while driving.

Using it may affect your ability to control

the vehicle, possibly leading to an acci-

dent resulting in death or serious injury.

■

Using the refresh system

●

Those who are pregnant, have recently

given birth, or suffer from ailments

requiring rest (heart disease etc.)

should consult a doctor before use.

●

Do not allow children to use the

refresh function.

●

Do not use immediately after consum-

ing a meal or alcohol, or for an

extended period of time.

●

If you feel sick while using the refresh

function, immediately discontinue use.

120

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

: If equipped

■

Automatic operation

The seat can be moved to preset posi-
tions.

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Touch the desired preset button.

When the operating conditions are not

Power rear seat

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

When adjusting the rear seat with an

ottoman, make sure there is sufficient

space so that a foot does not get

caught between the ottoman and front

passenger seat. (if equipped)

●

Vehicles with a rear seat entertainment

system: When the rear seat is moving

to the Entertainment Mode position,

do not allow hands near the rear dis-

play. Otherwise, a hand or finger may

be caught, possibly causing injury.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose control

of the vehicle.

■

Using the ottoman (if equipped)

●

Do not sit on the ottoman.

If someone sits on the ottoman, the seat
belt cannot be fitted properly, and they
may be thrown from the seat, resulting in
death or serious injury in the event of an
accident or sudden braking.

●

When getting in or out of the vehicle,

retract the ottoman. If the ottoman is

not retracted, it may cause a fall, result-

ing in injury.

●

Do not operate the ottoman when the

vehicle is moving.

●

Do not allow anyone to put their hands

or feet under the rear seat when stow-

ing the ottoman.

NOTICE

■

To prevent an ottoman malfunction (if

equipped)

●

Do not place any objects in the rear

seat footwell that could prevent the

operation of the ottoman.

●

Do not place heavy luggage on the

ottoman.

●

Do not place any objects under the

ottoman while it is raised for use. These

objects may interfere with the ottoman

being folded, causing damage to the

ottoman or the objects themselves.

■

To prevent a rear display malfunction

(if equipped)

Do not attempt to move the rear display

by hand, as doing so may damage the

rear display.

Adjustment procedure

121

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving

met, the preset buttons will be grayed out.

: Moves the rear seat

to the upright position (Business
Mode)

: Moves the rear seat

with an ottoman to a slightly reclined
position (Entertainment Mode) (if
equipped)

Vehicles without a rear seat entertainment
system: Moves the front passenger’s seat
forward.
Vehicles with a rear seat entertainment
system: Moves the front passenger’s seat
and rear display to allow the rear display to
be comfortably viewed.

: Moves the rear seat with an

ottoman to a deeply reclined position
(Relaxation Mode) (if equipped)

Moves the front passenger’s seat forward
and folds the seatback and head restraint
forward.
To stop the front passenger seat while it is
moving, touch “STOP”.

■

Manual operation

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Touch the button for the desired
adjustment.

Select the part you wish to adjust.
Adjust the position of the selected
part.

The part will move while a button is
touched.

■

Adjustment of the rear seat

●

When a rear seat is close to a front seat,

the operation of the rear seat may be

restricted.

●

If the rear armrest is stowed while the

seat position is being adjusted, the opera-

tion will stop.

■

Operating conditions of Business Mode

When the rear seat belt is not fastened and

weight is not detected on the rear seat,

Business Mode cannot be selected.
Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.

■

The rear seat with an ottoman cannot be

moved to Entertainment Mode/Relax-

ation Mode when (if equipped)

In the following situations, Entertainment

Mode or Relaxation Mode cannot be

selected:

●

The engine switch is in ACCESSORY

mode or off.

●

The rear seat belt is not fastened and

weight is not detected on the rear seat.

A
B

122

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.

●

The weight of an occupant or heavy

object, etc. is detected on the front pas-

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the engine switch is turned off.

●

The front passenger’s seat belt is fas-

tened.

●

The front passenger’s door is open.

■

When the front passenger’s seat is

folded forward



P.117

■

Automatic angle adjustment of the rear

displays (if equipped)

When a seat is adjusted, the angle of the

rear display will be adjusted automatically

to maintain an optimal viewing angle for the

rear display from the rear seat.

■

Operation after the engine switch is

turned off

After a certain time elapses after the engine

switch is turned off, the following parts of

the rear seats will move to their neutral

positions.

●

Shoulder bolster

●

Lumbar/pelvic support

■

Canceling an operation

To cancel an operation, press and hold the

button of the Rear Multi Opera-

tion Panel or press it 3 times in quick suc-

cession.

■

Pre-collision seatbacks for the passen-

ger seats



P.207, 219

■

Customization

Some functions can be customized.

(



P.474)

Press the seat switch.

Select “Return”

of “Rear”.

The rear seat will move to the upright posi-

tion.

■

Operation of the rear seats from the

front seats

In the following situations, the rear seats

cannot be operated from the front seats.

●

When the armrest is stowed and weight

of an occupant, heavy object, etc. is

detected on a rear seat

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.

●

When the armrest is stowed and a rear

seat belt is fastened.

Returning the rear seat from the
front seats

WARNING

■

When returning the rear seats to the

neutral position

To avoid injuring the rear passengers,

wait until they have gotten out of the

vehicle before operating the switch.

123

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving

The rear seat relaxation system utilizes
pneumatic chambers and dedicated
heaters, and applies pressure to the
occupant’s body at different modes
and intensities.
To display the rear seat relaxation sys-
tem screen, display the home screen
on the Rear Multi Operation Panel
(



P.318) and then touch “Relaxation”.

Touch to select the desired rear
seat.
Touch to select the desired mode.

When a button is touched, operation will
begin.

Touch to adjust the intensity.

The intensity can be adjusted in 5 steps.

Touch to turn the spot heaters
on/off.
Touch to stop the operation.

If a seat is not occupied, do not operate the
rear seat relaxation system for that seat.

■

Relaxation system

●

Operating conditions

• The engine switch is in IGNITION ON

mode.

• The temperature in the cabin is not

extremely high.

• The weight of an occupant is detected on

the rear seat or the rear seat belt is fas-

tened.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.

●

Automatic stop function

• The operation will be

canceled automati-

cally after approximately 15 minutes.

• If the door for a seat that the relaxation

system is currently being used is opened,

the relaxation system will stop operating.

The following functions will cause the
rear seats to move automatically.

■

Seat return function linked to the
door opening operation

The rear seat will return to the upright
position automatically when the rear
door is opened for easier entry and exit
of the vehicle.
For the rear seat with an ottoman (if
equipped): When the rear door on the

Rear seat relaxation system (if
equipped)

WARNING

■

Using the relaxation system

●

Those who are pregnant, have recently

given birth, or suffer from ailments

requiring rest (heart disease etc.)

should consult a doctor before use.

●

Do not allow children to use the relax-

ation function.

●

Do not use immediately after consum-

ing a meal or alcohol, or for an

extended period of time.

●

If you feel sick while using the relax-

ation function, immediately discon-

tinue use.

Automatic Seat Operation

124

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

side with the rear seat with an ottoman
is opened, the seatback of the rear seat
with an ottoman will move to a more
upright position. The seatback will
move to the upright position after the
door is closed and the system deter-
mines that the rear passenger has
exited.
However, if the armrest is stowed, the
rear seat will not move.

■

Shift-linked rear seat reclining
function

When the shift position is shifted from
P, to enhance rear visibility for the
driver, the rear seats will recline slightly.
However, the shift-linked rear seat
reclining function will not operate in
the following situations:



The weight of an occupant or heavy
object, etc. is detected on a rear
seat.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the engine
switch is turned off and the doors are
locked.



A rear seat belt is fastened.



A rear door is open.



The armrest is stowed.

When a front seat is close to a rear
seat, the rear seats may not operate or
the range of movement may be
restricted.

■

Changing automatic seat opera-
tion settings

The settings can be changed on the
Rear Multi Operation Panel. (



P.318)

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Touch .

Touch a button to change the set-
ting.

Rear right seat automatic operation
Rear right seatback movement
amount when door-linked rear seat
return function operates

Rear left seat automatic operation

: Vehicles with a rear seat with an ottoman

A
B

125

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.



Driver’s seat

When all of the following have been
performed, the seat and steering
wheel are automatically adjusted to a
position that allows driver to enter and
exit the vehicle easily.
• The shift position has been shifted to

• The engine switch has been turned

off.

• The driver’s seat belt has been

unfastened.

When the driver’s seat adjustment
switches are in front passenger mode
(



P.115), the seat and steering wheel will

not move.

On vehicles with adjustable seat cush-
ion side bolsters, when the driver’s
door is opened with the engine switch
off, the seat cushion side bolsters will
lower if they are in the default position.
When any of the following has been
performed, the seat and steering
wheel automatically return to their
original positions.
• The engine switch has been turned

to ACCESSORY mode or IGNI-
TION ON mode.

• The driver’s seat belt has been fas-

tened.



Front passenger’s seat

If all of the following have been per-
formed while the vehicle is stopped,
the lumbar support, pelvic support,
shoulder bolster (if equipped), seat-
back side bolster (if equipped), and hip
support (if equipped) will be moved to
their default position. On vehicles with
adjustable seat cushion side bolsters,
the seat cushion side bolsters will
lower.
• The passenger’s seat belt has been

unfastened.

• The front passenger’s door is

opened.

Driving position memory

This feature automatically adjusts
the positions of the front seats,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.

Up to 3 different driving positions
can be recorded.

Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

126

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

■

Operation of the power easy access sys-

tem

●

When exiting the vehicle, the power easy

access system may not operate if the seat

is already in the rearmost or uppermost

position or close to the rear seat.

●

If the seat position is adjusted during

power easy access system operation, the

automatic operation will stop. (The seat

will change to manual operation.)

●

If the seat position is adjusted during or

after the power easy access system oper-

ation when the driver is exiting the vehi-

cle, the power easy access system will not

operate when entering the vehicle.

■

Seat cushion side bolster adjustment (if

equipped)

If the seat cushion side bolsters have been

lowered, when the front door is closed, the

seat cushion side bolsters will move to their

default position.
If the seat is adjusted while the seat cushion

side bolsters are moving to the default posi-

tion, their movement will be temporarily

suspended. (The seat cushion side bolsters

will move to the default position after a cer-

tain amount of time.)

■

Customization

Some functions can be customized.

(



P.474)

Turn the engine switch to IGNI-
TION ON mode.

Check that the shift position is in P.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display (if equipped)
to the desired positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”

button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.
When the driver’s seat adjustment

switches are in front passenger mode

(



P.115), the position of the driver’s seat

cannot be registered.

To record the position of the front pas-
senger’s seat, adjust the front passen-
ger’s seat to the desired position and
perform step

using the buttons on

the front passenger’s side.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Turn the engine switch to IGNI-
TION ON mode.

Check that the shift position is in P.

Recording a driving position into
memory

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

127

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

When the driver’s seat adjustment

switches are in front passenger mode

(



P.115), a driving position cannot be

recalled.

■

To stop the position recall operation

part-way through

Perform any of the following operations:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Press the mode change button.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

■

Recalling a driving position

If a driving position is recalled, the move-

ment of the front seat may be stopped part-

way if the seat moves close to the rear seat.
If a rear passenger is determined to be in

the vehicle, the rearward movement of the

front seat may be stopped partway to

ensure sufficient space for the rear passen-

ger.

■

Recalling the front passenger’s seat

position (vehicles with a rear seat with

an ottoman)

If the ottoman of the rear seat is extended,

the front passenger’s seat position cannot

be recalled.

■

Operating the driving position memory

after turning the engine switch off

Driver’s seat:

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.
Front passenger’s seat:

Recorded seat positions can be recalled up

to 180 seconds after the front passenger’s

door is opened.

■

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact your Lexus dealer.

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to register,
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Turn the engine switch to IGNI-
TION ON mode.

Check that the shift position is in P.

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

Registering/canceling/recall a
driving position to an electronic
key (including a card key) (mem-
ory recall function)

128

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Cancelation procedure

Carry only the key you want to cancel
and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be canceled
properly.

Turn the engine switch to IGNI-
TION ON mode.

Check that the shift position is in P.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display [if

equipped]). However, the seat will move to

a position slightly behind the recorded

position in order to make entering the vehi-

cle easier.
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the engine switch to ACCES-
SORY mode or IGNITION ON
mode, or fasten a seat belt.

The seat, steering wheel and head-up dis-

play (if equipped) will move to the

recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If a door other than the driver’s door is

unlocked with the smart access system

with push-button start, the driving posi-

tion cannot be recalled. In this case, press

the driving position button which has

been set.

■

Customization

Some functions can be customized.

(



P.474)

129

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving

: If equipped

Turn the engine switch to IGNI-
TION ON mode.

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Adjust the rear seat to the desired
position and then touch “SET”.

Touch “1” or “2”.

If the preset is being used, the previously

recorded seat position will be overwritten.

■

In order to correctly use the position

memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Turn the engine switch to IGNI-
TION ON mode.

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Touch “1” or “2”.

When the operating conditions are not

met, the buttons will be grayed out.
To stop the operation touch “STOP”.
If the seat is adjusted while a memorized

position is being recalled, the automatic

operation will stop. (The seat will change to

manual operation.)

■

Operating condition

The weight of an occupant is detected on

the rear seat or the rear seat belt is fas-

tened.
Once weight is detected on the seat, the
seat will be judged as occupied until the
rear door is opened then closed or the
engine switch is turned off.

■

Recalling a rear seat position

If a memorized rear seat position is recalled,

the seat may stop part-way to ensure suffi-

cient space for the rear passenger.

■

Recalling the ottoman position (if

equipped)

When a seat position is recalled, the otto-

man will not raise or extend. The ottoman

position can only be recalled if the memo-

rized position is lower and shorter than the

current position.

Rear seat position memory

The rear seat position can be mem-
orized and recalled with the touch
of a button.

Recording a position into mem-
ory

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the rear passengers do not strike the

front seats.

Recalling the memorized posi-
tion

130

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

■

Front seats



Center Display

Press the seat switch.

Using the Remote Touch pad,
select “Driver Seat Adjustment” or
“Passenger Seat Adjustment”.

Select then the desired adjust-
ment

button , , ,

adjust the head restraint.

Up
Backward
Down
Forward

The head restraint moves while the adjust-

ment button is selected.

Head restraints

Head restraints are provided for all
seats.

Vehicles with power rear seat: The
head restraint for the rear center
seat is integrated into the seatback
and cannot be adjusted.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

●

Use the head restraints designed for

each respective seat.

●

Adjust the head restraints to the cor-

rect position at all times.

●

Manual type: After adjusting the head

restraints, push down on them and

make sure they are locked in position.

●

Do not drive with the head restraints

removed.

Adjusting a head restraint verti-
cally and horizontally (power
head restraints)

131

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

fore
dri
ving



Seat adjustment switches (on some
models)

Down

■

Rear seats

Display the home screen on the
Rear Multi Operation Panel
(



P.318) and then touch “Seat”.

Touch “Left” or “Right”.

Touch then the desired adjust-
ment

button , , ,

adjust the head restraint.

Up
Backward
Down
Forward

The head restraint moves while the adjust-

ment button is touched.

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

■

Front seat head restraints (power head

restraints)

Depending on the position of the front seat,

the front head restraint may not be able to

be adjusted upward if it is close to the ceil-

ing.

■

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■

Adjusting the rear seat head restraints

(manual head restraints)

Always raise the head restraint one level

from the stowed position when using.

B C D

B
C
D

Adjusting a head restraint verti-
cally (manual head restraints)

132

3-3. Adjusting the seats

LEXUS LS500 Owner's Manual

The position of the head restraint can
be adjusted forward in 4 stages.

If the head restraint is pulled forward from
the foremost position, it will return to the
rearmost position.

Push the sides of the head restraint.

Pull the head restraint up while press-
ing the lock release button .

■

Removing the head restraints (power

head restraints)

For removal and installation of the head

restraint, contact your Lexus dealer.

Align the head restraint with the instal-
lation holes and push it down to the
lock position.
Press and hold the lock release button

when lowering the head restraint.

Adjusting a head restraint hori-
zontally (manual head restraints)

Adjusting the side supports (if
equipped)

Removing the head restraints
(manual head restraints)

Installing the head restraints
(manual head restraints)

133

3-4. Adjusting the steering wheel and mirrors

LEXUS LS500 Owner's Manual

fore
dri
ving

3-4.Adjusting the steering wheel and mirrors

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The steering wheel can be adjusted

when

The engine switch is in ACCESSORY or
IGNITION ON mode

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of engine switch mode.

■

Automatic adjustment of the steering

position

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.125)

■

Power easy access system

The steering wheel and driver’s seat move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.125)

■

Customization

Some functions can be customized.

(



P.474)

Press on or close to the

mark.

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

Sounding the horn

Lexus LS500 (2022 year). Manual in english - page 7
