443

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

Warning messages

The warning messages explained below

may differ from the actual messages

according to operation conditions and vehi-

cle specifications.

■

Warning buzzer

In some cases, the buzzer may not be heard

due to being in a noisy location or audio

sound.

■

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level is low. Check the level

of the engine oil, and add if necessary.
This message may appear if the vehicle is

stopped on a slope. Move the vehicle to a

level surface and check to see if the mes-

sage disappears.

NOTICE

■

To ensure the tire pressure warning

system operates properly

Do not install tires with different specifi-

cations or makers, as the tire pressure

warning system may not operate prop-

erly.

If a warning message is dis-
played

The multi-information display
shows warnings for system malfunc-
tions and incorrectly performed
operations, and messages that indi-
cate a need for maintenance.
When a message is displayed, per-
form the appropriate corrective
action for the message.
If a warning message is displayed
again after the appropriate actions
have been performed, contact any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.
Additionally, if a warning light
comes on or flashes at the same
time that a warning message is dis-
played, take the appropriate cor-
rective action for the warning light.
(



P.435)

444

7-2. Steps to take in an emergency

■

If “Engine Stopped Steering Power

Low” is displayed

This message is displayed if the engine is

stopped while driving.
When steering wheel operations are heav-

ier than usual, grip the steering wheel firmly

and operate it using more force than usual.

■

If “Auto Power Off to Conserve Battery”

is displayed

Power was turned off due to the automatic

power off function. Next time when starting

the engine, increase the engine speed

slightly and maintain that level for approxi-

mately 5 minutes to recharge the battery.

■

If “Headlight System Malfunction Visit

Your Dealer” is displayed

The following systems may be malfunction-

ing. Have the vehicle inspected by any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer imme-

diately.

●

The LED headlight system

●

The automatic headlight leveling system

●

AHS (Adaptive High-beam System) (if

equipped)

●

AHB (Automatic High Beam) (if

equipped)

●

Multi Weather Lights

■

If “Radar Cruise Control Unavailable

See Owner's Manual” is displayed (on

some models)

The dynamic radar cruise control with

full-speed range system is suspended tem-

porarily or until the problem shown in the

message is resolved. (causes and coping

methods:



P.206, 211)

■

If “Radar Cruise Control Unavailable” is

displayed (on some models)

The dynamic radar cruise control with

full-speed range system cannot be used

temporarily. Use the system when it

becomes available again.

■

If a message that indicates the malfunc-

tion of front camera is displayed

The following systems may be suspended

until the problem shown in the message is

resolved. (



P.206, 211, 440)

●

PCS (Pre-Collision system) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

AHS (Adaptive High-beam System) (if

equipped)

●

AHB (Automatic High Beam) (if

equipped)

●

RSA (Road Sign Assist) (if equipped)

●

Dynamic radar cruise control with

full-speed range (if equipped)

■

If a message that indicates the malfunc-

tion of radar sensor is displayed

The following systems may be suspended

until the problem shown in the message is

resolved. (



P.206, 211, 440)

●

PCS (Pre-Collision system) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

Dynamic radar cruise control with

full-speed range (if equipped)

■

If “Oil Maintenance Required Soon” is

displayed

Indicates that the engine oil should be

scheduled to be changed.
Check the engine oil and change it if neces-

sary. After changing the engine oil, make

sure to reset the message. (



P.397)

■

If “Oil Maintenance Required” is dis-

played

Indicates that the engine oil should be

changed.
Check and change the engine oil, and oil fil-

ter by any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer. After changing the engine oil,

make sure to reset the message. (



P.397)

■

If “Shift System Malfunction Shifting

Unavailable Drive to a Safe Place and

Stop” or “Shift System Malfunction

Driving Unavailable” is displayed

There is a malfunction in the shift control

system. Have the vehicle inspected by any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer imme-

diately.

445

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If a message that indicates the need for

the shift lever operation is displayed

To prevent the shift lever from being oper-

ated incorrectly or the vehicle from moving

unexpectedly, a message that requires shift-

ing the shift position may be displayed on

the multi-information display. In that case,

follow the instruction of the message and

shift the shift position.

■

If a message that indicates the need for

visiting your Lexus dealer is displayed

The system or part shown on the

multi-information display is malfunctioning.

Have the vehicle inspected by any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer immedi-

ately.

■

If a message that indicates the need for

referring to Owner’s Manual is dis-

played

●

If any of the following messages are

shown on the multi-information display,

follow the instructions.

• “Engine Coolant Temp High” (



P.458)

• “Battery  Low”  (



P.452)

• “Transmission Fluid Temp High” (



P.172)

●

If any of the following messages are

shown on the multi-information display, it

may indicate a malfunction. Have the

vehicle inspected by any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer immedi-

ately.

• “Entry & Start System Malfunction”

• “Shift System Malfunction Apply Parking

Brake Securely When Parking See

Owner's Manual”

• “P Switch Malfunction Apply Parking

Brake Securely When Parking See

Owner's Manual”

• “Shift System Unavailable Apply Parking

Brake Securely When Parking See

Owner's Manual”

• “Shift System Malfunction See Owner's

Manual”

• “Shift System Malfunction Stop in a Safe

Place See Owner's Manual”

• “Battery Low Shifting Unavailable See

Owner's Manual”

●

If any of the following messages are

shown on the multi-information display, it

may indicate a malfunction. Immediately

stop the vehicle and contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

• “Braking Power Low”

• “Charging System Malfunction”

• “Oil Pressure Low”

NOTICE

■

If “High Power Consumption Partial

Limit On AC/Heater Operation” is

displayed frequently

There is a possible malfunction relating

to the charging system or the battery

may be deteriorating. Have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

446

7-2. Steps to take in an emergency

Take your vehicle to the nearest
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer, or authorized tire dealer as
soon as possible if any tire goes flat.



For XXX/XXRXX size tires

The vehicle can be driven for a maximum
of 80 km (50 miles) at a speed below 80
km/h (50 mph) after the tire pressure
warning light comes on. (



P.439)



For XXX/XXRFXX size tires

The vehicle can be driven for a maximum
of 160 km (100 miles) at a speed below 80
km/h (50 mph) after the tire pressure
warning light comes on. (



P.439)

A run-flat tire has a

 or

 mark

on the side wall.

■

In some conditions (such as at high tem-

peratures)

For XXX/XXRXX size tires: You cannot

continue driving for up to 50 km (80

miles).
For XXX/XXRFXX size tires: You cannot

continue driving for up to 100 km (160

miles).

■

For the detailed information on run-flat

tires

See the tire warranty booklet.

If you have a flat tire

Your vehicle is not equipped with a
spare tire, but instead you can con-
tinue driving the vehicle with
run-flat tires even if any tire goes
flat.

In this case, slow down and drive
with extra caution.

Run-flat tires

NOTICE

■

When replacing the tires

When removing or fitting the wheels,

tires or the tire pressure warning valve

and transmitter, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer as the

tire pressure warning valve and transmit-

ter may be damaged if not handled cor-

rectly.

■

When driving over bumps

If a vehicle has a flat tire, the vehicle

height will be lower than usual. Ensure

that nothing strikes the bottom of the

vehicle.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer or other

qualified service shop as soon as possi-

ble. Make sure to replace the tire pres-

sure warning valve and transmitter when

replacing the tire. (



P.406)

447

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

One of the following may be the cause
of the problem:



There may not be sufficient fuel in
the vehicle’s tank.
Refuel the vehicle.



The engine may be flooded.
Try to restart the engine again fol-
lowing correct starting procedures.
(



P.169)



There may be a malfunction in the
engine immobilizer system.
(



P.63)



There may be a malfunction in the
shift control system.

*

 (



P.172, 444)

*

: It may not be possible to shift the shift

position from P.

One of the following may be the cause
of the problem:



The battery may be discharged.
(



P.452)



The battery terminal connections
may be loose or corroded.
(



P.401)

The engine starting system may be
malfunctioning due to an electrical
problem such as electronic key battery
depletion or a blown fuse. However, an
interim measure is available to start the
engine. (



P.447)

One of the following may be the cause
of the problem:



One or both of the battery terminals
may be disconnected. (



P.401)



The battery may be discharged.
(



P.452)



There may be a malfunction in the
steering lock system.

Contact any authorized Lexus retailer or
Lexus authorized repairer, or any reliable
repairer if the problem cannot be repaired,
or if repair procedures are unknown.

When the engine does not start, the

If the engine will not start

If the engine will not start even
though correct starting procedures
are being followed (



P.169), con-

sider each of the following points:

The engine will not start even
though the starter motor oper-
ates normally.

The starter motor turns over
slowly, the interior lights and
headlights are dim, or the horn
does not sound or sounds at a low
volume.

The starter motor does not turn
over

The starter motor does not turn
over, the interior lights and head-
lights do not turn on, or the horn
does not sound.

Starting the engine in an emer-
gency

448

7-2. Steps to take in an emergency

following steps can be used as an
interim measure to start the engine if
the engine switch is functioning nor-
mally.
Do not use this starting procedure
except in cases of emergency.

1

Press the parking brake switch to
check that the parking brake is set.
(



P.180)

Parking brake indicator will come on.

2

Turn the engine switch to ACCES-
SORY mode.

3

Press and hold the engine switch
for about 15 seconds while
depressing the brake pedal firmly.

Even if the engine can be started using
the above steps, the system may be
malfunctioning. Have the vehicle
inspected by any authorized Lexus
retailer or Lexus authorized repairer,
or any reliable repairer.

If you lose your keys

New genuine mechanical keys can
be made by any authorized Lexus
retailer or Lexus authorized
repairer, or any reliable repairer
using another mechanical key and
the key number stamped on your
key number plate.

Keep the plate in a safe place such
as your wallet, not in the vehicle.

NOTICE

■

When an electronic key is lost

If the electronic key remains lost, the risk

of vehicle theft increases significantly.

Visit any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer immediately with all remaining

electronic keys and the card key (if

equipped) that were provided with your

vehicle.

449

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

Remove the cover inside the trunk and
pull the lever.

■

When the electronic key does not work

properly

●

Make sure that the smart entry & start

system has not been disabled using the

Remote Touch or at any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer. If it has been disa-

bled, re-enable it.

●

Check if battery-saving mode is set. If it is

set, cancel the function. (



P.116)

■

Unlocking the door

Use the mechanical key (



P.100) in

If the fuel filler door cannot
be opened

If the fuel filler door opener switch
cannot be operated, contact any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer to service the vehicle. In
case where refueling is urgently
necessary, the following procedure
can be used to open the fuel filler
door.

Opening the fuel filler door

If the electronic key does not
operate properly

If communication between the
electronic key and vehicle is inter-
rupted (



P.116) or the electronic

key cannot be used because the
battery is depleted, the smart entry
& start system and wireless remote
control cannot be used. In such
cases, the doors and trunk can be
opened and the engine can be
started by following the procedure
below.

NOTICE

■

In case of a smart entry & start system

malfunction or other key-related

problems

Take your vehicle with all the electronic

keys provided with your vehicle, to any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

Locking and unlocking the
doors, unlocking the trunk

450

7-2. Steps to take in an emergency

order to perform the following opera-
tions:

1

Pull the driver’s door handle and
insert the mechanical key.

2

Unlock the door.

3

Remove the key, return the handle,
and then pull the handle again.

■

Locking the door

1

With the door open, push down the
inside lock button.



For the front doors

2

Close the door while pulling the
door handle.



For the rear doors

2

Close the door.

■

Trunk

Turn the mechanical key clockwise to
open.

■

Key linked functions

1

Closes the windows and the moon roof
(turn and hold)

2

Opens the windows and the moon roof
(turn and hold)

These settings must be customized at any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

451

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

1

Depress the brake pedal.

2

Touch the Lexus emblem side of the
electronic key to the engine switch.

When the electronic key is detected, a

buzzer sounds and the engine switch will

turn to IGNITION ON mode.
When the smart entry & start system is

deactivated in customization setting, the

engine switch will turn to ACCESSORY

mode.

3

Firmly depress the brake pedal and
check that

 is shown on the

multi-information display.

4

Press the engine switch.

In the event that the engine still cannot
be started, contact any authorized

Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

■

Stopping the engine

Set the parking brake, shift the shift position

to P and press the engine switch as you nor-

mally do when stopping the engine.

■

Electronic key battery

As the above procedure is a temporary

measure, it is recommended that the elec-

tronic key battery be replaced immediately

when the battery is depleted. (



P.419)

■

Alarm

Using the mechanical key to lock the doors

or trunk will not set the alarm system.

If a door or trunk is unlocked using the

mechanical key when the alarm system is

set, the alarm may be triggered. (



P.65)

■

Changing engine switch modes

Release the brake pedal and press the

engine switch in step

3

 above. The engine

does not start and modes will be changed

each time the switch is pressed. (



P.171)

WARNING

■

When using the mechanical key and

operating the power windows or

moon roof

Operate the power window or moon

roof after checking to make sure that

there is no possibility of any passenger

having any of their body parts caught in

the window or moon roof.

Also, do not allow children to operate the

mechanical key. It is possible for children

and other passengers to get caught in

the power window or moon roof.

Starting the engine

452

7-2. Steps to take in an emergency

If you have a set of jumper (or booster)
cables and a second vehicle with a
12-volt battery, you can jump start your
vehicle by following the steps below.



Method connecting jumper (or
booster) cables to the battery

1

Confirm that the electronic key is
being carried.

When connecting the jumper (or booster)

cables, depending on the situation, the

alarm may activate and doors locked.

(



P.66)

2

Open the trunk lid and remove the
luggage mat. (



P.367)

In the event that the trunk opener cannot

be used, use the mechanical key to open

the trunk. (



P.449)

3

Connect a positive jumper cable clamp to   on your vehicle and connect the
clamp on the other end of the positive cable to   on the second vehicle. Then,

If the vehicle battery is dis-
charged

The following procedures may be
used to start the engine if the vehi-
cle’s battery is discharged.
You can also call any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

Restarting the engine

A

B

453

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

connect a negative cable clamp to   on the second vehicle and connect the
clamp at the other end of the negative cable to  .

Positive (+) battery terminal (your vehicle)
Positive (+) battery terminal (second vehicle)
Negative (-) battery terminal (second vehicle)
Negative (-) battery terminal (your vehicle)

4

Start the engine of the second vehi-
cle. Increase the engine speed
slightly and maintain at that level for
approximately 5 minutes to
recharge the battery of your vehi-
cle.

5

Open and close any of the doors of
your vehicle with the engine switch
off.

6

Maintain the engine speed of the
second vehicle and start the engine
of your vehicle by turning the
engine switch to IGNITION ON
mode.

7

Once the vehicle’s engine has
started, remove the jumper cables
in the exact reverse order from
which they were connected.

8

Press the Stop & Start cancel
switch to disable the Stop & Start
system. (



P.285)



Method connecting jumper (or
booster) cables to the exclusive
jump starting terminal

1

Confirm that the electronic key is
being carried.

When connecting the jumper (or booster)

cables, depending on the situation, the

alarm may activate and doors locked.

(



P.66)

2

Open the hood. Remove the ser-
vice cover. (



P.389, 395)

3

Open the fuse box cover.

C

D

A
B
C
D

454

7-2. Steps to take in an emergency

Push the tab in and lift the lid off.

4

Open the exclusive jump starting
terminal cover.

5

Remove the engine cover.
(



P.394)

6

Connect a positive jumper cable clamp to   on your vehicle and connect the
clamp on the other end of the positive cable to   on the second vehicle. Then,
connect a negative cable clamp to   on the second vehicle and connect the
clamp at the other end of the negative cable to  .



LS500



LS350

A

B

C

D

455

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

Exclusive jump starting terminal (your vehicle)
Positive (+) battery terminal (second vehicle)
Negative (-) battery terminal (second vehicle)
Solid, stationary, unpainted metallic point away from the exclusive jump starting
terminal and any moving parts as shown in the illustration

7

Start the engine of the second vehi-
cle. Increase the engine speed
slightly and maintain at that level for
approximately 5 minutes to
recharge the battery of your vehi-
cle.

8

Open and close any of the doors of
your vehicle with the engine switch
off.

9

Maintain the engine speed of the
second vehicle and start the engine
of your vehicle by turning the
engine switch to IGNITION ON
mode.

10

Once the vehicle’s engine has
started, remove the jumper cables
in the exact reverse order from
which they were connected.

11

Close the exclusive jump starting
terminal cover, and reinstall the fuse
box cover to its original position.

12

Install the service cover. (



P.395)

13

Install the engine cover. (



P.395)

14

Press the Stop & Start cancel
switch to disable the Stop & Start
system. (



P.285)

Once the engine starts, have the vehi-
cle inspected at any authorized Lexus
retailer or Lexus authorized repairer,
or any reliable repairer as soon as pos-
sible.

■

Starting the engine when the battery is

discharged

The engine cannot be started by push-start-

ing.

■

To prevent battery discharge

●

Turn off the headlights and the audio sys-

A
B
C
D

456

7-2. Steps to take in an emergency

tem while the engine is off. (Except when

the engine is stopped by the Stop & Start

system.)

●

Turn off any unnecessary electrical com-

ponents when the vehicle is running at a

low speed for an extended period, such

as in heavy traffic.

■

When the battery is removed or dis-

charged

●

Information stored in the ECU is cleared.

When the battery is depleted, have the

vehicle inspected at any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

Some systems may require initialization.

(



P.492)

■

When removing the battery terminals

When the battery terminals are removed,

the information stored in the ECU is

cleared. Before removing the battery termi-

nals, contact any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer as soon as possible.

■

Charging the battery

The electricity stored in the battery will dis-

charge gradually even when the vehicle is

not in use, due to natural discharge and the

draining effects of certain electrical appli-

ances. If the vehicle is left for a long time,

the battery may discharge, and the engine

may be unable to start. (The battery

recharges automatically during driving.)

■

After jump starting the vehicle

Be sure to disable the Stop & Start system

so that the battery can be charged.

(



P.285)

■

When recharging or replacing the bat-

tery

●

In some cases, it may not be possible to

unlock the doors using the smart entry &

start system when the battery is dis-

charged. Use the wireless remote control

or the mechanical key to lock or unlock

the doors.

●

The engine may not start on the first

attempt after the battery has recharged

but will start normally after the second

attempt. This is not a malfunction.

●

The engine switch mode is memorized by

the vehicle. When the battery is recon-

nected, the system will return to the

mode it was in before the battery was dis-

charged. Before disconnecting the bat-

tery, turn the engine switch off.

If you are unsure what mode the engine

switch was in before the battery dis-

charged, be especially careful when

reconnecting the battery.

●

For a while after the battery terminals

have been disconnected and recon-

nected, for a while after the battery has

been replaced, the Stop & Start system

may not automatically stop the engine for

approximately 5 to 60 minutes.

●

If the battery discharges, it may not be

possible to shift the shift position to other

positions. In this case, the vehicle cannnot

be towed without lifting both rear wheels

because the rear wheels will be locked.

■

When replacing the battery

●

Use a Central Degassing type battery

(European Regulations).

●

Use a genuine battery specifically

designed for use with the Stop & Start

system or a battery with equivalent speci-

fications to a genuine battery. If an unsup-

ported battery is used, Stop & Start

system functions may be restricted to

protect the battery.

Also, battery performance may decrease

and the engine may not be able to restart.

Contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer for details.

●

Use a battery with the same case size as

the previous battery and an equivalent

20 hour rate capacity (20HR) or greater.

• If the sizes differ, the battery cannot be

properly secured.

• If the 20 hour rate capacity is low, even if

the time period where the vehicle is not

used is a short time, the battery may dis-

charge and the engine may not be able to

start.

●

Use a battery with a handle. If a battery

without a handle is used, removal is more

457

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

difficult.

●

After replacing, firmly attach the follow-

ing items to the exhaust hole of the bat-

tery.

• Use the exhaust hose that was attached

to the battery before replacing and con-

firm that it is firmly connected to the hole

section of the vehicle.

• Use the exhaust hole plug included with

the battery replaced or the one installed

on the battery prior to the replacement.

(Depending on the battery to be

replaced, the exhaust hole may be

plugged.)

Exhaust hole plug
Exhaust hole
Exhaust hose

For details, consult any authorized Lexus
retailer or Lexus authorized repairer, or
any reliable repairer.

WARNING

■

When removing the battery terminals

Always remove the negative (-) terminal

first. If the positive (+) terminal contacts

any metal in the surrounding area when

the positive (+) terminal is removed, a

spark may occur, leading to a fire in addi-

tion to electrical shocks and death or

serious injury.

A
B
C

■

Avoiding battery fires or explosions

Observe the following precautions to

prevent accidentally igniting the flamma-

ble gas that may be emitted from the bat-

tery:

●

Make sure each jumper cable is con-

nected to the correct terminal and that

it is not unintentionally in contact with

any other than the intended terminal.

●

Do not allow the other end of the

jumper cable connected to the “+” ter-

minal to come into contact with any

other parts or metal surfaces in the

area, such as brackets or unpainted

metal.

●

Do not allow the + and - clamps of the

jumper cables to come into contact

with each other.

●

Do not smoke, use matches, cigarette

lighters or allow open flame near the

battery.

■

Battery precautions

The battery contains poisonous and cor-

rosive acidic electrolyte, while related

parts contain lead and lead compounds.

Observe the following precautions when

handling the battery:

●

When working with the battery, always

wear safety glasses and take care not

to allow any battery fluids (acid) to

come into contact with skin, clothing

or the vehicle body.

●

Do not lean over the battery.

●

In the event that battery fluid comes

into contact with the skin or eyes,

immediately wash the affected area

with water and seek medical attention.

Place a wet sponge or cloth over the

affected area until medical attention

can be received.

●

Always wash your hands after handling

the battery support, terminals, and

other battery-related parts.

458

7-2. Steps to take in an emergency

1

Stop the vehicle in a safe place and
turn off the air conditioning system,
and then stop the engine.

2

If you see steam:
Carefully lift the hood after the
steam subsides.
If you do not see steam:
Carefully lift the hood.

3

After the engine has cooled down
sufficiently, inspect the hoses and
radiator core (radiator) for any
leaks.

WARNING

●

Do not allow children near the battery.

■

After recharging the battery

Have the battery inspected at any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer as soon as possible.

If the battery is deteriorating, continued

use may cause the battery to emit a mal-

odorous gas, which may be detrimental

to the health of passengers.

■

When replacing the battery

●

When the vent plug and indicator are

close to the hold down clamp, the bat-

tery fluid (sulfuric acid) may leak.

●

For information regarding battery

replacement, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

After replacing, securely attach the

exhaust hose and exhaust hole plug to

the exhaust hole of the replaced bat-

tery. If not properly installed, gases

(hydrogen) may leak into the vehicle

interior, and there is the possible dan-

ger of the gas igniting and exploding.

NOTICE

■

When handling jumper cables

When connecting the jumper cables,

ensure that they do not become entan-

gled in the cooling fan or engine drive

belt.

■

To prevent damaging the vehicle

The exclusive jump starting terminal is to

be used when charging the battery from

another vehicle in an emergency. It can-

not be used to jump start another vehicle.

If your vehicle overheats

The following may indicate that
your vehicle is overheating.



The engine coolant temperature
gauge (



P.74, 77) is in the red

zone or a loss of engine power is
experienced. (For example, the
vehicle speed does not increase.)



“Engine Coolant Temp High Stop
in a Safe Place See Owner’s
Manual” is shown on the
multi-information display.



Steam comes out from under the
hood.

Correction procedures
