137

3-3. Adjusting the seats

fore
driving



Seat adjustment switches (on some
models)

Down

■

Rear seats

Display the home screen on the
Rear Multi Operation Panel
(



P.336) and then touch “Seat”.

Touch “Left” or “Right”.

Touch then the desired adjust-
ment button , , , or to
adjust the head restraint.

Up
Backward
Down
Forward

The head restraint moves while the adjust-

ment button is touched.

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

■

Front seat head restraints (power head

restraints)

Depending on the position of the front seat,

the front head restraint may not be able to

be adjusted upward if it is close to the ceil-

ing.

■

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■

Adjusting the rear seat head restraints

(manual head restraints)

Always raise the head restraint one level

from the stowed position when using.

B C D

B
C
D

Adjusting a head restraint verti-
cally (manual head restraints)

138

3-3. Adjusting the seats

The position of the head restraint can
be adjusted forward in 4 stages.

If the head restraint is pulled forward from
the foremost position, it will return to the
rearmost position.

Push the sides of the head restraint.

Pull the head restraint up while press-
ing the lock release button .

■

Removing the head restraints (power

head restraints)

For removal and installation of the head

restraint, ask any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer.

Align the head restraint with the instal-
lation holes and push it down to the
lock position.
Press and hold the lock release button

when lowering the head restraint.

Adjusting a head restraint hori-
zontally (manual head restraints)

Adjusting the side supports (if
equipped)

Removing the head restraints
(manual head restraints)

Installing the head restraints
(manual head restraints)

139

3-4. Adjusting the steering wheel and mirrors

fore
driving

3-4.Adjusting the steering wheel and mirrors

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The steering wheel can be adjusted

when

The engine switch is in ACCESSORY or
IGNITION ON mode

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of engine switch mode.

■

Automatic adjustment of the steering

position

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.131)

■

Power easy access system

The steering wheel and driver’s seat move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.131)

■

Customization

Some functions can be customized.

(



P.476)

Press on or close to the

mark.

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

Sounding the horn

140

3-4. Adjusting the steering wheel and mirrors

: If equipped

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.

Turn the automatic anti-glare function
mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the engine switch is turned to IGNI-
TION ON mode.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

■

To prevent sensor error

To ensure that the sensors operate properly,

do not touch or cover them.

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

141

3-4. Adjusting the steering wheel and mirrors

fore
driving

: If equipped

Camera indicator

Indicates that the camera is operating nor-
mally.

Icon display area

Displays icons, adjusting gauge, etc.
(



P.143)

Select button

Press to change the setting of the item you
want to adjust.

Menu button

Press to display the icon display area and
select the item you want to adjust.

Lever

Operate to change between digital mirror
mode and optical mirror mode.

Operate the lever to change between
digital mirror mode and optical mirror
mode.

Digital Rearview Mirror

The Digital Rearview Mirror is a
system that uses the camera on the
rear of the vehicle and displays its
image on the display of the Digital
Rearview Mirror.

The Digital Rearview Mirror can be
changed between optical mirror
mode and digital mirror mode by
operating the lever.

The Digital Rearview Mirror allows
the driver to see the rear view
despite obstructions, such as the
head restraints, luggage or rear
sunshade ensuring rear visibility.
Also, the rear seats are not dis-
played and privacy of the passen-
gers is enhanced.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before using the Digital Rearview

Mirror

●

Make sure to adjust the mirror before

driving. (



P.142)

• Change to optical mirror mode and

adjust the position of the Digital Rear-

view Mirror so that the area behind

your vehicle can be viewed properly.

• Change to digital mirror mode and

adjust the display settings.

●

As the range of the image displayed by

the Digital Rearview Mirror is different

from that of the optical mirror, make

sure to check this difference before

driving.

System components

Changing modes

142

3-4. Adjusting the steering wheel and mirrors

Digital mirror mode

Displays an image of the area behind the
vehicle.

will illuminate in this mode.

Optical mirror mode

Turns off the display of the Digital Rearview
Mirror allows it to be used as an optical
mirror.

■

Digital mirror mode operating condi-

tion

The engine switch is turned to IGNITION

ON mode.
When the engine switch is changed from

IGNITION ON mode to off or ACCES-

SORY mode, the image will disappear after

several seconds.

■

When using the Digital Rearview Mir-

ror in digital mirror mode

●

If it is difficult to see the displayed image

due to light reflected off the Digital Rear-

view Mirror, the camera being dirty, or if

lights of a vehicle behind your vehicle or

the displayed image are bothering you,

change to optical mirror mode.

●

When the trunk is open, the Digital Rear-

view Mirror image may not display prop-

erly. Before driving, make sure the trunk

is closed.

●

If the display is difficult to see due to

reflected light, close the sunshade for the

moon roof.

●

Any of the following conditions may

occur when driving in the dark, such as at

night. None of them indicates that a mal-

function has occurred.

• Colors of objects in the displayed image

may differ from their actual color.

• Depending on the height of the lights of

the vehicle behind, the area around the

vehicle may appear white and blurry.

• Automatic image adjustment for brighter

surrounding image may cause flickering.

If it is difficult to see the displayed image or
flickering bothers you, change to optical
mirror mode.

●

The Digital Rearview Mirror may

become hot while it is in digital mirror

mode.

This is not a malfunction.

●

Depending on your physical condition or

age, it may take longer than usual to focus

on the displayed image. In this case,

change to optical mirror mode.

●

Do not let passengers stare at the dis-

played image when the vehicle is being

driven, as doing so may cause motion

sickness.

■

When the system malfunctions

If the symbol shown in the illustration is dis-

played when using the Digital Rearview

Mirror in digital mirror mode, the system

may be malfunctioning. The symbol will dis-

appear in a few seconds. Operate the lever,

change to optical mirror mode and have the

vehicle inspected by any authorized Lexus

retailer or Lexus authorized repairer, or any

reliable repairer.

■

Adjusting the mirror height

The height of the rear view mirror can

Adjusting the mirror

143

3-4. Adjusting the steering wheel and mirrors

fore
driving

be adjusted to suit your driving pos-
ture.
Change to optical mirror mode, adjust-
ing the height of the rear view mirror by
moving it up and down.

■

Display settings (digital mirror
mode)

Settings of the display in the digital mir-
ror mode, on/off operation of the auto-
matic anti-glare function, etc. can be
changed.

Press the menu button.

The icons will be displayed.

Press the menu button repeatedly
and select the item you want to
adjust.

Press

to change the set-

ting.

The icons will disappear if a button is not

operated for approximately 5 seconds or

more.

: This is a function for the optical mirror

mode, however, the setting can also be
changed while using the digital mirror
mode.

■

Enabling/disabling the automatic
anti-glare function (optical mirror
mode)

The automatic anti-glare function in the
optical mirror mode can be ena-
bled/disabled. The setting can be
changed in both the digital mirror
mode and the optical mirror mode.



When using the digital mirror mode



P.143

Icons

Settings

Select to adjust the brightness of
the display.

Select to adjust the area dis-
played up/down.

Select to adjust the area dis-
played to the left/right.

Select to adjust the angle of the
displayed image.

Select to zoom in/out the dis-
played image.

Select to enable/disable the
automatic anti-glare function.

Responding to the brightness of
the headlights of vehicles
behind, the reflected light is
automatically adjusted.
The automatic anti-glare func-
tion is enabled each time the
engine switch is changed to
IGNITION ON mode.

144

3-4. Adjusting the steering wheel and mirrors



When using the optical mirror mode

Press the menu button.

The icons will be displayed.

Press the menu button repeatedly
and select

The setting display will be displayed.

Press

to enable

(“ON”)/disable (“OFF”) the auto-
matic anti-glare function.

The icons will disappear if a button is not

operated for approximately 5 seconds or

more.

■

Adjusting the display (digital mirror

mode)

●

If the displayed image is adjusted, it may

appear distorted. This is not a malfunc-

tion.

●

If the brightness of the Digital Rearview

Mirror is set too high, it may cause eye

strain. Adjust the Digital Rearview Mirror

to an appropriate brightness. If your eyes

become tired, change to optical mirror

mode.

●

The brightness of the Digital Rearview

Mirror will change automatically accord-

ing to the brightness of the area in front of

your vehicle.

■

To prevent the light sensors from mal-

functioning

To prevent the light sensors from malfunc-

tioning, do not touch or cover them.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

While driving

●

Do not adjust the position of the Digital

Rearview Mirror or adjust the display

settings while driving.

Stop the vehicle and operate the Digi-

tal Rearview Mirror control switches.

Failure to do so may cause a steering

wheel operation error, resulting in an

unexpected accident.

●

Always pay attention to the vehicle’s

surroundings.

The size of the vehicles and other objects

may look different when in digital mirror

mode and optical mirror mode.

When backing up, make sure to directly

check the safety of the area around your

vehicle, especially behind the vehicle.

Additionally, if a vehicle approaches from

the rear in the dark, such as at night, the

surrounding area may appear dim.

■

To prevent causes of fire

If the driver continues using the Digital

Rearview Mirror while smoke or odor

comes from the mirror, it may result in

fire. Stop using the system immediately

and contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

145

3-4. Adjusting the steering wheel and mirrors

fore
driving

■

Cleaning the mirror surface

If the mirror surface is dirty, the image
on the display may be difficult to see.
Clean the mirror surface gently using a
soft dry cloth.

■

Cleaning the camera

If the camera lens is dirty or covered
with foreign matter, such as water
droplets, snow, mud, etc., the displayed
image may not be clear. In this case,
rinse the camera lens with a large
quantity of water and then wipe it clean
with a soft cloth dampened with water.
Dirt on the camera lens can be cleaned
by operating the dedicated camera
cleaning washer. (



P.195)

■

The camera

The camera for the Digital Rearview Mirror

is located as shown.

Cleaning the Digital Rearview
Mirror

NOTICE

■

To prevent the Digital Rearview Mir-

ror from malfunctioning

●

Do not use detergents, such as thinner,

benzine, and alcohol to clean the mir-

ror. They may discolor, deteriorate or

damage the mirror surface.

●

Do not smoke, use matches, use ciga-

rette lighters or allow open flames

near the mirror. It may damage the

mirror or cause a fire.

●

Do not remove, disassemble or modify

the mirror.

■

To prevent the camera from malfunc-

tioning

●

Observe the following precautions,

otherwise the Digital Rearview Mirror

may not operate properly.

• Do not strike or hit the camera or sub-

ject it to a strong impact, as the camera

installation position and angle may be

changed.

• Do not remove, disassemble or modify

the camera.

• When washing the camera, rinse it

with a large quantity of water and then

wipe it clean with a soft cloth damp-

ened with water.

Do not strongly rub the camera lens,

as it may be scratched and will not be

able to transmit a clear image.

• Do not allow organic solvent, car wax,

window cleaner or glass coat to

adhere to the camera cover. If this hap-

pens, wipe it off as soon as possible.

• Do not apply hot water to the camera

in cold weather, as the sudden change

of temperature may cause the camera

to not operate properly.

• When using a high pressure washer to

wash the vehicle, do not directly spray

the camera and its surrounding area,

as doing so may cause the camera to

not operate properly.

●

Do not subject the camera to a strong

impact as this could cause a malfunc-

tion.

If this happens, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer as soon as pos-

sible.

146

3-4. Adjusting the steering wheel and mirrors

If you notice any of the following symptoms, refer to the following table for the likely
cause and the solution.
If the symptom is not resolved by the solution, have the vehicle inspected by any
authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer.

If you notice any symptoms

Symptom

Likely cause

Solution

The image is difficult to
see.

The mirror surface is dirty.

Clean the mirror surface
gently, using a soft dry cloth.

Sunlight or headlights are shining
directly into the Digital Rearview
Mirror.

Change to optical mirror
mode.
(If the light is coming through
the moon roof, close the sun-
shade.)

• The vehicle is in a dark area.
• The vehicle is near a TV tower,

broadcasting station, electric
power plant, or other location
where strong radio waves or
electrical noise may be pres-
ent.

• The temperature around the

camera is extremely high/low.

• The ambient temperature is

extremely low.

• It is raining or humid.
• Sunlight or headlights are shin-

ing directly into the camera
lens.

• The vehicle is under fluores-

cent lights, sodium lights, mer-
cury lights, etc.

• Exhaust gas is obstructing the

camera.

Change to optical mirror
mode.
(Change back to digital mir-
ror mode when the condi-
tions have improved.)

147

3-4. Adjusting the steering wheel and mirrors

fore
driving

The image is difficult to
see.

Foreign matters (such as water
droplets, snow, mud, etc.) is on
the camera lens.



Operate the dedicated
camera cleaning washer
and clean the camera lens.
(



P.195)



Change to optical mirror
mode.



Rinse the camera with a
large quantity of water,
wipe it clean with a soft
cloth dampened with water,
and then change back to
digital mirror mode.

The image is out of
alignment.

The trunk is not fully closed.

Fully close the trunk.

The camera or its surrounding
area has received a strong
impact.

Change to optical mirror
mode and have the vehicle
inspected by any authorized
Lexus retailer or Lexus
authorized repairer, or any
reliable repairer.

The display is dim and

is displayed.

The system may be malfunction-
ing.

Change to optical mirror
mode and have the vehicle
inspected by any authorized
Lexus retailer or Lexus
authorized repairer, or any
reliable repairer.

goes off.

Symptom

Likely cause

Solution

148

3-4. Adjusting the steering wheel and mirrors

is displayed.

The Digital Rearview Mirror is
extremely hot.
(The display will gradually
become more dim. If the temper-
ature continues to increase, the
Digital Rearview Mirror will turn
off.)

Reducing the cabin tempera-
ture is recommended to
reduce the temperature of
the mirror.
(

will disappear when the

mirror becomes cool.)

does not disappear

even though the mirror is
cool, have the vehicle
inspected by any authorized
Lexus retailer or Lexus
authorized repairer, or any
reliable repairer.

The lever cannot be
operated properly.

The lever may be malfunctioning.

Change to optical mirror
mode and have the vehicle
inspected by your any author-
ized Lexus retailer or Lexus
authorized repairer, or any
reliable repairer.
(To change to optical mirror
mode, press and hold the
menu button for approxi-
mately 10 seconds.)

Symptom

Likely cause

Solution

149

3-4. Adjusting the steering wheel and mirrors

fore
driving

To select a mirror to adjust, press
the switch.

The indicator comes on.

Left
Right

Pressing the same switch again will put the

switch in neutral.

To adjust the mirror, press the
switch.

Up
Right
Down
Left

■

Mirror angle can be adjusted when

The engine switch is in ACCESSORY or

IGNITION ON mode.

■

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.342)

■

Auto anti-glare function

When the anti-glare inside rear view mirror

is set to automatic mode, the outside rear

view mirrors will activate in conjunction with

the anti-glare inside rear view mirror to

reduce reflected light. (



P.140, 143)

■

Automatic adjustment of the mirror

angle

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.131)

■

Linked mirror function when reversing

When either “L” or “R” of the mirror select

switch is selected, the outside rear view mir-

rors will automatically angle downwards

when the vehicle is reversing in order to

give a better view of the ground.

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

■

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A
B

A
B
C
D

150

3-4. Adjusting the steering wheel and mirrors

To disable this function, select neither “L”

nor “R”.
To set the mirror angle used when the vehi-

cle is reversing, adjust the mirror angle at a

desired position with the shift position in R.
The adjusted angle will be memorized and

the mirror will automatically tilt to the mem-

orized angle whenever the shift position is

shifted to R from next time.
The memorized downward tilt position of

the mirror is linked to the normal position

(angle adjusted with the shift position in

other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt

position will also change.
When the normal position is changed, read-

just the angle in reversing.

■

Using the switch

Press the switch to fold the mirrors.

Press it again to extend them to the original
position.

■

Setting automatic mode

Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator

will come on.

Pressing the switch once more will return
to manual mode.

■

When disconnecting and reconnecting

battery terminals

The automatic folding/extending mirror

function will return to off as default. To turn

the function on, press the switch again to

select on.

■

Using automatic mode in cold weather

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this case, remove any ice and

snow from the door mirror, then either

operate the mirror using manual mode or

move the mirror by hand.

■

Customization

Some functions can be customized.

(



P.476)

WARNING

■

When the mirror defoggers are oper-

ating

Do not touch the rear view mirror sur-

faces, as they can become very hot and

burn you.

Folding and extending the mir-
rors

151

3-4. Adjusting the steering wheel and mirrors

fore
driving

WARNING

■

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

152

3-5. Opening, closing the windows and moon roof

3-5.Opening, closing the windows and moon roof

The power windows can be opened
and closed using the switches.
Operating the switch moves the win-
dows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway, operate the

switch in the opposite direction.

■

The power windows can be operated

when

The engine switch is in IGNITION ON

mode.

■

When the driver’s power window switch

is used to open a rear power window

(vehicles with rear door sunshades)

If a rear door sunshade is extended or being

extended when the driver’s power window

switch is pushed, only the rear door sun-

shade will be retracted. To open the rear

power window from the driver’s seat, push

the driver’s power window switch again.

■

Operating the power windows after

turning the engine off

The power windows can be operated for

approximately 45 seconds even after the

engine switch is turned to ACCESSORY

mode or turned off. They cannot, however,

be operated once either front door is

opened.

■

Jam protection function

If an object becomes jammed between the

window and the window frame while the

window is closing, window movement is

stopped and the window is opened slightly.

■

Catch protection function

If an object becomes caught between the

door and window while the window is open-

ing, window movement is stopped.

■

When the side window cannot be

opened or closed

When the jam protection function or catch

protection function operates unusually and

the side window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

●

Stop the vehicle. With the engine switch

in IGNITION ON mode, within 4 sec-

onds of the jam protection function or

catch protection function activating, con-

tinuously operate the power window

switch in the one-touch closing direction

or one-touch opening direction so that

the side window can be opened and

closed.

●

If the side window cannot be opened and

closed even when performing the above

operations, perform the following proce-

dure for function initialization.

Turn the engine switch to IGNITION

ON mode.

Pull and hold the power window switch

in the one-touch closing direction and

completely close the side window.

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

Power windows

Opening and closing the power
windows

Content .. 6 7 8 9 ..
